All 2011 Cadillac vehicles now come standard
with Cadillac Premium Care Maintenance.
It’s a maintenance program that provides more
peace of mind by covering certain required
maintenance services during the first 4 years
or 50,000 miles of the vehicle’s operation.
To learn more, go to cadillac.com/premium-care.
1
e s c a l a d e
To learn more, please visit CADILLAC.COM
e x t
MODEL
Escalade EXT AWD
ENG INE AND DRIVET RAIN
Gen IV Vortec 6.2L V8 VVT engine with Active Fuel Management: 403 hp @ 5700 rpm and
417 lb.-ft. of torque @ 4300 rpm; E85 FlexFuel-capable
Available All-Wheel-Drive system: 40/60 front/rear torque split and full-time operation
Six-speed automatic transmission with Driver Shift Control manual mode and Tow/Haul mode
Rear locking differential
MAXIMU M CA PACITIE S AND DIME NSION S
Bed height (in.) 25.0
Bed length with Midgate up (in.) 63.0
Bed length with Midgate down (in.) 97.6
Bed width (in.) 50.0
Fuel tank (gal. approx.) 31
Payload (lbs.)
Seating 5
Trailering (lbs.)
3
1,251
4
7,600
KEY STANDARD FEATURES
EXTERIOR, CHASSIS AND SUSPENSION
Brakes Four-wheel disc, antilock braking system; twin-piston front calipers
Frame All-welded, fully boxed ladder-type
Level Control Automatic electronic rear level control system
Lighting System Xenon High-Intensity Discharge (HID) headlamps and halogen fog lamps
Mirrors Exterior rearview, heated, power-adjustable and power-folding with curb view assistance, LED turn-
signal indicators, puddle lamps and automatic dimming driver-side
Road-Sensing Suspension Front/five-link rear with bi-modal monotube shocks, computer-controlled realtime damping
StabiliTrak With Rollover Mitigation Computer-controlled, four-channel electronic stability control system
Traction Control All-speed with brake and engine intervention
Ultrasonic Rear Parking Assist
INTER IOR
Adaptive Remote Start/Keyless Entry Includes two remote transmitters, remote start, climate control
system and heated seat activation
2
2011
SELEC T SPECIFI C ATION S
INTER IOR (CONTINUED)
Adjustable Pedals Power-adjustable, with memory
5
Dual-stage driver and front passenger, front-impact; Automatic Occupant Sensing System; driver
Air Bags
and front passenger seat-mounted side-impact for thorax and pelvic protection; and head-curtain sideimpact with rollover protection for all outboard passenger rows
Audio System Bose® 5.1 Cabin Surround® Sound System, AudioPilot® noise compensation technology,
eight speakers equalized to the interior, steering wheel audio controls and independent rear-seat audio
controls with two earphone jacks
Bluetooth® Wireless Technology
Climate Control Dual-zone automatic electronic with individual settings for driver and front passenger
Driver Information Center (DIC) Up to 46 Driver-Information Messages
Navigation System
OnStar®
Rearview Camera Automatic operation when vehicle is put in Reverse
Seating Front seats with leather seating surfaces, heated and cooled seatbacks and cushions with three
temperature settings; 14-way power-adjustable seats, including four-way power lumbar; and memory settings for two drivers
Seating Second-row bench seat with folding center armrest and leather seating surfaces
Steering Wheel Controls Audio system, cruise control, OnStar and Hands-Free Calling buttons
Steering Wheel Power-adjustable steering column
Tire Pressure Monitoring System (excludes spare tire) Includes individual sensors with specific pressures
displayed in Driver Information Center
XM Radio
7
8
Full-featured eight-inch-diagonal touch-screen
Directions & Connections® Plan with Turn-by-Turn Navigation standard for the first year
9
With three trial months
PREMI UM COLLECTION
Power-Retractable Assist Steps
Rear-Seat Entertainment System In-dash DVD with roof-mounted flip-down eight-inch-diagonal screen, two
2-channel wireless headphones, auxiliary audio/video jacks, remote and game plug-in
LUXURY COLLECTION
Lighting System IntelliBeam headlamps with automatic high-/low-beam switching
Magnetic Ride Control Coil-over-shock front/ and five-link rear with magneto-rheological fluid-filled shocks
and computer-controlled real-time damping
Steering Wheel Heated
Sunroof Power, tilt-sliding with Express-Open/-Close and sunshade
Wheels 22-inch
10
seven-spoke chromed aluminum with all-season touring tires
6
For select phones
AVA ILABLE EX TER IOR C OLO RS (PR EM IUM CO LORS R EQU IR E ADDIT IONA L C OST )
SILVER LINING ME TALLIC GOLD MIST ME TALLIC
1
Whichever comes first. See dealer for details. 2 E85 is a combination of 85% ethanol and 15% gasoline. Go to gm.com/biofuels to see if there is an E85 fuel station near you. 3 Maximum payload capacity includes weight of driver, passengers, optional equipment and cargo. 4 Maximum
trailer ratings are calculated assuming a base vehicle, plus driver. See your Cadillac dealer for additional details.
when properly secured in a rear seat in the appropriate infant, child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with a passenger air bag. See the Owner’s Manual and child safety seat instructions for more safety information.
6
Go to gm.com/bluetooth to find out which phones are compatible with the vehicle. 7 Map coverage available in the United States, U.S. Virgin Islands, Puerto Rico and Canada.
9
Requires a subscription sold separately by XM after trial period. Available only in the 48 contiguous United States and District of Columbia. Visit gm.xmradio.com for details
performance characteristics. For important tire and wheel information, go to gmaccessorieszone.com or see your dealer for details.
GM, the GM Logo, Cadillac, the Cadillac Logo, and the slogans, emblems, vehicle model names, vehicle body designs and other marks appearing in this document are the trademarks and/or service marks of General Motors, its subsidiaries, affiliates or licensors. Bose, AudioPilot
and Cabin Surround are registered trademarks of the Bose Corp. ©2010 OnStar. All rights reserved. The Bluetooth word mark is a registered trademark owned by Bluetooth SIG, Inc. and any use of such mark by Cadillac is under license. SIRIUS, XM and all related marks and logos are
trademarks of SIRIUS XM Radio Inc. and its subsidiaries. ©2010 General Motors. All rights reserved. GM reserves the right to make changes at any time and without notice in prices, colors, materials, equipment, specifications, models and availability.
(LATE AVAILABIL ITY)
5
Always use safety belts and the correct restraint for your child’s age and size. Even in vehicles equipped with the Automatic Occupant Sensing System, children are safer
BLACK R AVEN
MOCHA STEEEL M ETALLIC
(LATE AVAILABIL ITY)
8
Visit onstar.com for coverage map, details and system limitations. Services vary by model and conditions.
10
Use only GM-approved tire and wheel combinations. Unapproved combinations may change the vehicle’s
WHITE DIA MOND TRICOAT
(PREMIUM COLOR)
