Cadent EA03586 User Manual

OPERATION MANUAL

iTero HDU

Wireless Foot Pedal

Optical Impression Device

P/N EA03586

for Intra-Oral Digital

FCC ID: UZ2EA03586

Impression

Operation Manual

iTero HDU Operation Manual Wireless Foot Pedal

Foot Pedal Maintenance

Checking Foot Pedal Battery

The foot pedal unit contains two AA 1.5V batteries. It
is recommended to keep back-up batteries of this type
in your office.

When battery is low, the following indications will be
provided by the system:

 Pressing a foot pedal causes no response within

the iTero Scanner software.

 A warning dialog requests that the battery be

replaced.

Replacing Foot Pedal Battery

To change the foot pedal battery, follow the instructions below:

1. Open the battery cover

2. Replace batteries with new ones and close the cover.

CAUTION: Be sure to follow local governing ordinances and recycling instructions
regarding disposal or recycling of batteries.

2 Publication EA03586-A

CAUTION: Refer to qualified service personnel for verifying that pedal dongle is
assembly on HDU cart.
