Caddy XL Parts List

Download
Parts List
January, 2009
r

Series XL - Tray Makeup Conveyors

XL-1 Express Line, XL-2 Express Line, XL-R Express Line, and XL-S Express Line
Part Description Part Numbe
Belt, Round, 1/2" Dia. Dura-San 6843-05 5" Efson Idler Pulley 6881-01 7 1/2" Efson Idler Pulley 6881-02 Spacer, Pulley (1 Per Idler Pulley) 6892-01 Tensioner Assembly, Tail End 6960-01 Double Drive Pulley 1" Bore (1/2 HP Motor) 6880-01 Double Drive Pulley 1 1/8" Bore (3/4 HP Motor) 6880-02 Belt Guide Short (2" Long) 6865-02 Belt Guide, Long (7" Long) 6909-01 Return Channel Cover (48" Long, 2 Finger Holes) 6885-01 5" Dia. Stem Caster 66-05 5" Dia. Stem Caster With Brake 70-65 Bushing Caster, Press in 6473-05 5" Dia. Platform Caster 74-05 5" Dia. Platform Caster With Brake 75-65 Bullet Foot With Thread 1326-01 Flanged Foot, Press in 1780-01
Electrical Information and Parts
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
r

Tray Makeup Conveyors - Slatted Belt Models

TR-10 Traymaster: Caddyflex Belt
TM-10 Tray Makeup: Caddyflex Belt with Belt Washer
Part Description Part Numbe
Belt Washer and Electrical Information and Parts
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
r

Tray Makeup Conveyors - Fabric Belt Models

SM-10 Servmaster: PVC Belt
Part Description Part Numbe
Belt Polytex, 10 Inch, White 3352-01 Pulley, Drive, 6" Dia. 3042-01 Pulley, Tail, 5" Dia. 3043-01 Lacing, Alligator 3293-01 5" Dia. Stem Caster 66-05 5" Dia. Stem Caster With Brake 70-05 5" Dia. Platform Swivel Caster 74-05 5" Dia. Platform Swivel Caster W/Brake 75-05 Bushing Caster, Press in 6473-01 Bullet Foot With Thread 1326-01 Flanged Foot, Press in 1780-01 Drive Shaft 4123-01 Bearing Flanged, (4 hole) Drive 1364-01 Tail Shaft 4122-01 Bearing Take-Up, 1" Bore 1366-01 Sprocket, #60, 21 Tooth (Trantorque) 6807-01 Trantorque Collet Hub 6810-01 Sprocket, #60, 21 Tooth (Keyway) 1319-01
Electrical Information and Parts
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
r

Tray Makeup Conveyors - Roller Models

RCF - RollerVeyor
RCC - RollerVeyor: Cantilever Supported, Mobile
Part Description Part Numbe
Roller Conveyor w/hardware 6947-01 5" Dia. Stem Caster 66-05 5" Dia. Stem Caster With Brake 70-65 Bushing Caster, Press in 6473-05 Bullet Foot With Thread 1326-01 Flanged Foot, Press in 1780-01
Electrical Information and Parts
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
r

Tray Makeup Conveyors - Skatewheel Models

SWF - SkateWheelVeyor
SWC - SkateWheelVeyor: Cantilever Supported, Mobile
SKW - SkateWheelVeyor: Mounted on Hot Food Table or Counter
Part Description Part Numbe
Electrical Information and Parts
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
y
r
r

TF Series - Hot Food Caddys

Open Type Enclosed Type Warming Cabinet
TF-602 Hot Food Caddy, 2 Well TF-622 Hot Food Caddy, 2 Well TF-603 Hot Food Caddy, 3 Well TF-623 Hot Food Caddy, 3 Well TF-604 Hot Food Caddy, 4 Well TF-624 Hot Food Caddy, 4 Well TF-605 Hot Food Caddy, 5 Well TF-625 Hot Food Caddy, 5 Well TF-606 Hot Food Caddy, 6 Well TF-626 Hot Food Caddy, 6 Well
Open T
TF-612 Hot Food Caddy, 2 Well TF-632 Hot Food Caddy, 2 Well TF-613 Hot Food Caddy, 3 Well TF-633 Hot Food Caddy, 3 Well TF-614 Hot Food Caddy, 4 Well TF-634 Hot Food Caddy, 4 Well
TF-616 Hot Food Caddy, Open Type TF-636 Hot Food Caddy, Enclosed Type
Hot Food Well Complete (No Drain) 3981-02 Hot Food Well Complete (1/2" Drain) 4166-01 Hot Food Well Heating Element 4358-02 Infinite Heat Switch 129-01 Knob 1939-01 Pilot Light 125-04 Lower Heating Elements 4359-01 Click Stat / Thermostat 217-01 Door Latch 476-01 Trim Extrusion 426-05 4" Dia. Swivel Caster Without Brake 72-05 4" Dia. Swivel Caster With Brake 73-05 Cord Assembly See Electrical Drawing
Push Handle, TF-602, 603, 604, 605 2207-01 Push Handle, TF-612, 613, 614 2207-02 Push Handle, TF-616 636 2207-04 Overhead Infra-Red Warmer, TF-602, 622 3076-01 Overhead Infra-Red Warmer, TF-603, 623 3077-01 Overhead Infra-Red Warmer, TF-612 3078-01 Overhead Infra-Red Warmer, TF-604, 624 3079-01 Overhead Infra-Red Warmer, TF-613, 616 3080-01 Overhead Infra-Red Warmer, TF-605 4864-01 Overhead Heating Element, TF-602, 622 4510-01 Overhead Heating Element, TF-612 4511-01 Overhead Heating Element, TF-604, 624 4512-01 Overhead Heating Element, TF-613, 616 4513-01 Overhead Heating Switch 4514-01
pe Slim Line Enclosed Type, Slim Line Warming Cabinet
6-Well Full Convenience
Part Description Part Numbe
Accessories
Part Description Part Numbe
r
r
r

Tray Delivery Trucks

Model Descriptions
TD-607-D 1 Door, 7 Trays TD-608-D 1 Door, 8 trays TD-610-D 1 Door, 10 trays TD-614-D 2 Doors, 14 Trays TD-616-D 2 Doors, 16 Trays TD-620-D 2 Doors, 20 Trays TD-621-D 3 Doors, 21 Trays TD-624-D 3 Doors, 24 Trays TD-630-D 3 Doors, 30 Trays TDC-20-D * 1 Door, 20 Trays TDC-20-DD * 1 Door each side, 20 Trays TDC-40-D * 2 Doors, 40 Trays TDC-40-DD * 2 Doors each side, 40 Trays
* Indicates trucks designed specifically for 14" x 18" trays Model TD-630-D shown
All Models
Description Part Numbe
Latch Assembly 4690-01 Nylon Striker 4877-02 Thumb Screw (TD) 1014-01 Spring (TD) 4982-01 Latch Cover (Cream Only) 4985-30 Push/Pull Handle (TD) 462-02 Push/Pull Handle (TDC) 4854-01 Screws for Handle 1013-23 Menu Holder 6653-01 5" Dia. Rigid Platform Caster 5" Dia. Swivel Platform Caster 6" Dia. Rigid Platform Caster 3073-05 6" Dia. Swivel Platform Caster 3072-05 Replacement Doors Contact Caddy for information.
(TD-614/TD-621 only) 76-05
(TD-614/TD-621 only) 74-05
Models TD-614, TD-616, TD-620
Description Part Numbe
Corner Bumper (L Shaped) 79-01 Corner Bumper Mounting Clip 6402-01 Short Bumper - 19.375" (End Panel) 4731-01 Long Bumper - 34.25" (Door or Back Panel) 4732-01 Short Channel (End Panel) 6351-01 Long Channel (Door or Back Panel) 6351-04 Vertical Corner Bumper - 12" 4691-01
Models TD-621, TD-624, TD-630
Description Part Numbe
Corner Bumper (L Shaped) 79-01 Corner Bumper Mounting Clip 6402-01 Short Bumper - 19.375" (End Panel) 4731-01 Long Bumper - 52.75" (Door or Back Panel) 4733-01 Short Channel (End Panel) 6351-01 Long Channel (Door or Back Panel) 6351-07 Vertical Corner Bumper - 12" 4691-01
r
r
r
r

Tray Delivery Trucks (continued)

Models TDC-20, TDC-24
Description Part Numbe
Corner Bumper (L Shaped) 79-01 Corner Bumper Mounting Clip 6402-01 Short Bumper (End Panel) 6443-01 Long Bumper (Door or Back Panel) 6433-02 Short Channel (End Panel) 6351-02 Long Channel (Door or Back Panel) 6351-03 Vertical Corner Bumper - 12" 4691-01
Model TDC-40
Description Part Numbe
Corner Bumper (L Shaped) 79-01 Corner Bumper Mounting Clip 6402-01 Short Bumper (End Panel) 6443-02 Long Bumper (Door or Back Panel) 6433-03 Short Channel (End Panel) 6451-03 Long Channel (Door or Back Panel) 6351-05 Long Channel (Door or Back Panel) 6351-03 Vertical Corner Bumper - 12" 4691-01
Model TD-614, 616, 621, 624
Description Part Numbe
End Panel, Teal, 28.87" X 13.25" 7024-01 Door Panel, Teal, 28.25" X 5" 7024-02 End Panel, Cranberry, 28.87" X 13.25" 7024-11 Door Panel, Cranberry, 28.25" X 5" 7024-12 End Panel, Grey, 28.87" X 13.25" 7024-21 Door Panel, Grey, 28.25" X 5" 7024-22 End Panel, Blue, 28.87" X 13.25" 7024-31 Door Panel, Blue, 28.25" X 5" 7024-32
Model TD-620, 630
Description Part Numbe
End Panel, Teal, 44.75" X 13.25" 7024-03 Door Panel, Teal, 44.25" X 5" 7024-04 End Panel, Cranberry, 44.75" X 13.25" 7024-13 Door Panel, Cranberry, 44.25" X 5" 7024-14 End Panel, Grey, 44.75" X 13.25" 7024-23 Door Panel, Grey, 44.25" X 5" 7024-24 End Panel, Blue, 44.75" X 13.25" 7024-33 Door Panel, Blue, 44.25" X 5" 7024-34
Replacement Bumpers
For other than grey neoprene, contact Caddy. Please have your model number available.
Replacement Graphics
Colors Available - Teal, Cranberry, Grey & Blue
r
r

Series 21-C Soiled Tray Conveyors

Part Description Part Numbe
Belt, Round, 1/2" Dia. Dura-San 6843-05 5" Idler Pulley 6881-01 7 1/2" Idler Pulley 6881-02 Spacer, Pulley (1 Per Idler Pulley) 6892-01 Tensioner Assembly, Tail End 6960-01 Double Drive Pulley 1" Bore (1/2 HP Motor) 6880-01 Double Drive Pulley 1 1/8" Bore (3/4 HP Motor) 6880-02 Belt Guide Short (2" Long) 6865-02 Belt Guide, Long (7" Long) 6909-01 Return Channel Cover (48" Long, 2 Finger Holes) 6885-01
45° and 90° Turn Components
Part Description Part Numbe
21-C Turn, Drive Pulley (3 Req'd. Per 45° Turn) (6 Req'd. Per 90° Turn)
6887-01
21-C Turn, Drive Bushing (3 Req'd. Per 45° Turn) (6 Req'd. Per 90° Turn)
21-C Turn, Return Pulley (2 Req'd. Per 45° Turn) (6 Req'd. Per 90° Turn)
21-C Turn,Return Bushing (2 Req'd. Per 45° Turn) (6 Req'd. Per 90° Turn)
Turn Pulley Mtg. Shaft (5 Req'd. Per 45° Turn) (12 Req'd. Per 90° Turn)
Bolt, 1/4-20, S/S, 1/2" (5 Req'd. Per 45° Turn) (12 Req'd. Per 90° Turn)
Electrical Information and Parts
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
6889-01
6888-01
6890-01
6933-01
1016-01
r
r

Soiled Tray Conveyors - Slatted Belt Models

CF-10 Soiled Tray: Caddyflex Belt with Belt Washer
Part Description Part Numbe
BU-10-10 Busmaster: Caddyflex Belt BV-10-10 Busing-Veyor: Caddyflex Belt with Belt Washer SV-10-10 Sorting-Veyor: Caddyflex Belt with Belt Washer
Part Description Part Numbe
Belt Washer and Electrical Information and Parts
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
r
r
r

Soiled Tray Conveyor - Beltwashers

Single Belt Conveyor 12" Beltwasher
Part Description Part Numbe
Nozzle, Vee Jet, 1/4" IPS 1374-01 Top Spray Pipe Assembly 6957-01 Bottom Spray Pipe Assembly 6957-02 Top Wiper Deflector 3183-16 Bottom Wiper Deflector 3183-13 Scrap Basket 6295-01 Roller Assembly, 12" 6952-01 1/2" IPS, Check Valve 6115-01 Tempering Valve 1569-01 3/8" IPS, Stop Valve 1351-01 3/8" IPS, Solenoid Valve (120V) 6618-03 3/8" IPS, Solenoid Valve (240V) 6618-04 Pressure Regulator 1568-02 3/8" IPS, Pressure Gauge 5405-01 1/2" IPS, Vacuum Breaker 1972-01 Vacuum Breaker Bracket 5271-01
Double Belt Conveyor 22" Beltwasher
Part Description Part Numbe
Nozzle, Vee Jet, 1/4" IPS 1374-01 Top Spray Pipe Assembly 6959-01 Bottom Spray Pipe Assembly 6959-02 Top Wiper Deflector 3183-16 Bottom Wiper Deflector 3183-13 Scrap Basket 6295-02 Roller Assembly, 22" 6952-02 1/2" IPS, Check Valve 6115-01 Tempering Valve 1569-01 3/8" IPS, Stop Valve 1351-01 3/8" IPS, Solenoid Valve (120V) 6618-03 3/8" IPS, Solenoid Valve (240V) 6618-04 Pressure Regulator 1568-02 3/8" IPS, Pressure Gauge 5405-01 1/2" IPS, Vacuum Breaker 1972-01 Vacuum Breaker Bracket 5271-01
Intermediate Swill Sink
Part Description Part Numbe
Scrap Basket 6295-03
BeltWasher Electrical Information and Parts
See electrical drawing or contact Caddy.
g
Heated Dish Dispensers
Series CM100H through CM500H
Description
Select Part Based on Volta
Heating Element 3878-01 3878-02 3878-01 Switch 124-01 124-01 124-01 Infinite Heat Switch 3430-01 129-01 129-01 Flanged Inlet 4052-01 4054-01 4054-01 Cord Assembly 4676-01 4677-01 4677-01 Plug 89-01 38-01 38-01 Cord Receptacle 4053-01 4055-01 4055-01 Hi Limit Clik Stat 127-01 127-01 127-01 Caster 72-05 72-05 72-05 Wheel Only 6385-02 6385-02 6385-02 Protective Trim 426-05 426-05 426-05 Lexan Cover for CM100H 3655-01 3655-01 3655-01 Lexan Cover for CM200H 3655-02 3655-02 3655-02 Lexan Cover for CM300H 3655-03 3655-03 3655-03 Lexan Cover for CM400H 3655-04 3655-04 3655-04 Lexan Cover for CM500H 3655-04 3655-04 3655-04 Cylinder for CM100H 6894-01 6894-01 6894-01 Cylinder for CM200H 6894-02 6894-02 6894-02 Cylinder for CM300H 6894-03 6894-03 6894-03 Cylinder for CM400H 6894-04 6894-04 6894-04 Cylinder for CM500H 6894-05 6894-05 6894-05 Guide Post - Black 894-01 894-01 894-01
e 120 Volt 208 Volt 240 Volt
Part Number
g
Super Heat Dish Dispensers
Series CM100SH through CM500SH
Description
Select Part Based on Volta
Casters 74-05 74-05 74-05 Casters With Brakes 75-05 75-05 75-05 Wheels Only 6385-02 6385-02 6385-02 Corner Bumpers 508-01 508-01 508-01 Perimeter Bumpers - Long 4012-03 4012-03 4012-03 Perimeter Bumpers - Short 4012-01 4012-01 4012-01 Aluminum Cover for CM300SH 5916-03 5916-03 5916-03 Cylinder Assembly for CM300SH 5899-01 5899-01 5899-01 Cylinder Assembly for CM400SH 7482-01 7482-01 7482-01 Protective Trim Extrusion 426-05 426-05 426-05 Cord Assembly 4008-01 4003-01 4003-01 Flanged Inlet 3919-01 3957-01 3957-01 Timer 3966-01 3966-01 3966-01 Timer Knob 4006-01 4006-01 4006-01 Timer Plate 4007-01 4007-01 4007-01 Pilot Light 125-05 125-04 125-04 Heating Element – 620 Watts 3980-01 3980-02 3980-01 Heating Element – 475 Watts 3878-01 3878-02 3878-01 Hi Limit Clik Stat 127-01 127-01 127-01 Plug 90-01 39-01 39-01 Cord Receptacle 3920-01 3958-01 3958-01
e 120 Volt 208 Volt 240 Volt
Part Number
g
High Heat Underliner Dispensers
Series CM100HH through CM500HH
Description
Select Part Based on Volta
Casters 74-05 74-05 74-05 Casters With Brakes 75-05 75-05 75-05 Wheels Only 6385-02 6385-02 6385-02 Corner Bumpers 508-01 508-01 508-01 Perimeter Bumpers - Long 4012-03 4012-03 4012-03 Perimeter Bumpers - Short 4012-01 4012-01 4012-01 Aluminum Cover for CM300HH 5916-03 5916-03 5916-03 Cylinder Assembly for CM300HH 5899-01 5899-01 5899-01 Cylinder Assembly for CM400HH 7482-01 7482-01 7482-01 Protective Trim Extrusion 426-05 426-05 426-05 Cord Assembly 4008-01 4003-01 4003-01 Flanged Inlet 3919-01 3957-01 3957-01 Timer 3966-01 3966-01 3966-01 Timer Knob 4006-01 4006-01 4006-01 Timer Plate 4007-01 4007-01 4007-01 Pilot Light 125-05 125-04 125-04 Heating Element – 620 Watts 3980-01 3980-02 3980-01 Heating Element – 475 Watts 3878-01 3878-02 3878-01 Hi Limit Clik Stat 127-01 127-01 127-01 Plug 90-01 39-01 39-01 Cord Receptacle 3920-01 3958-01 3958-01
e 120 Volt 208 Volt 240 Volt
Part Number
