Introduction
Thank you for purchasing the M16 Remote Controlled Microphone
Amplifier from CADAC Electronics plc.
CADAC is renowned for supplying arguably the highest quality audio
mixing consoles for the world-wide professional audio industry for
over 36 years. In all these years the driving force behind the company’s research and development program has been to strive for products that not only provide the exact functionality required but also
exceptional audio performance and reliability. This can be attested
throughout the world, with many hundreds of CADAC consoles
working day in day out in many of the world’s premier venues and
tours.
For over 30 years CADAC has been receiving high praise for its very
natural sounding microphone amplifier, and the release of the new
CADAC M16 encompasses the sound of that classic amplifier in a
compact 19” 3U rack multi-channel format that is equally suitable for
live, broadcast, as well as general applications. The M16 has been
engineered to deliver exceptional quality and reliability. Premium
quality performance is maintained throughout the signal path, resulting in a very wide bandwidth, flat frequency response, impressive
phase response and generous headroom.
iii
We trust that the CADAC M16 will bring many years of satisfaction
and thank you for your patronage.
The CADAC team
Revision 2005-7 M16 Microphone Amplifier
iv
Features
■ 16 channels of high performance microphone amplifiers.
■ Ideal solution for touring, broadcast or recording applications
when high quality microphone amplifiers are required.Each
channel output is provided with an integral 3-way active splitter.
■ Each output is designed to drive over long cable lengths in
excess of 500m
■ All channels are fitted with a switchable high pass filter.
■ An optical MADI output is provided to allow multi-channel con-
nection to digital consoles or workstations.
■ High build quality with hand tuned Common Mode Rejection and
Balanced circuitry on all I/O.
■ Front Panel control of all parameters, or remote control options.
■ Up to 32 x M16 units can be connected to one control system.
■ Audio interfaces directly with the CADAC D16, 16 x 16 Digital
Mix Matrix via dedicated buss link connectors.
■ Designed to exceed current EMC directives, and immune from
receiving or transmitting radio frequency interference.
Using the M16 Manual
In order to obtain the most out of your M16, please read the User
Manual carefully.
Prior to installing and using the M16, it is also important that you
have read both Safety Instructions and Important Information.
If you still have a problem that cannot be resolved by referring to this
manual, then please contact your local CADAC distributor.
All information provided within this user manual is provided in good
faith. CADAC follows a policy of continual product development;
changes to equipment specification may be made without prior notice.
M16 Microphone Amplifier Revision MA2005-7
Declaration of conformity
The Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility directive, amended by
92/31/EEC & 93/68/EEC
The Products Covered by this Declaration
M16 remote controlled microphone amplifier.
RM16 remote controller
The Basis on which Conformity is being Declared
The products identified above comply with the requirements of the
above EU Directives by meeting the following standards:
BS EN 55103-1:1997 Electromagnetic compatibility - Product
family standard for audio, video, audiovisual and entertainment lighting control
apparatus for professional use.
Part 1 – Emissions
v
BS EN 55103-2:1997 Electromagnetic Compatibility - Product
family standard for audio, video, audiovisual and entertainment lighting control
apparatus for professional use.
Part 2 – Immunity
BS EN 60065:1998 Audio, Video and similar electronic appa-
ratus. Safety requirements.
Signed:............................
Authority: General Manager
Date: 24 January 2005
Attention!
The attention of the specifier, purchaser, installer, or user is drawn
to special measures and limitations to use which must be observed
when these products are taken into service to maintain compliance
with the above directives. Details of these special measures and limitations to use are available on request, and are also contained in the
M16 Installation & User manual.
Revision 2005-7 M16 Microphone Amplifier
vi
M16 Microphone Amplifier Revision MA2005-7
1 Important Safety Instructions
1.1 Mains Cable
The supplied IEC mains cable must be correctly terminated before
use. Use only an approved AC plug or power distribution device.
Safety ground must be connected at all times.
Safety Earth = Green/Yellow
Live = Brown
Neutral = Blue
1.2 Changing the fuse
To avoid the risk of fire, use only the recommended fuse type as indicated in this manual and on the M16. Do not short-circuit the fuse
holder.
1-1
Before changing the fuse, always switch off the unit and remove the
IEC mains cable.
NOTE: Both Live and Neutral are fused, therefore the M16 fuse
holder contains TWO fuses. Do not make the mistake of thinking that one is a spare!
To replace a fuse, remove the fuse holder (located adjacent to the
IEC mains socket) by pulling the tab that projects slightly over the lip
of the socket.
Fuse holder
FIG 1-1. Remove the fuse holder
Revision MA2005-7 M16 Microphone Amplifier
1-2
Replace the blown fuse with an identical type. See Fuse Types below for further details.
Fuses
FIG 1-2. Replace the fuse
Refit the fuse holder, taking care to align it properly. The guide arm
of the fuse holder slots into the power connector assembly.
FIG 1-3. Refit the fuse holder
FIG 1-4. Push the fuse holder
home
1.3 Fuse Types
Fuse holder
Once in place, push the fuse holder home and confirm that it is fully
seated.
Push in fuse holder
Live: 90v - 250v: 2A Type T
Neutral: 90v - 250v: 2A Type T
M16 Microphone Amplifier Revision MA2005-7
1.4 Servicing
There are no serviceable parts contained within the M16. Refer all
servicing to your CADAC distributor.
1.5 Do not remove any covers
Within the M16 are areas where high and dangerous voltages are
present. Removing any covers will invalidate warranty.
1.6 Safety checklist
■ Install in accordance with CADAC’s instructions.
■ Do not place the apparatus on an unstable or uneven surface.
■ Do not insert objects through any apertures. Doing so could
result in damage to the unit or electric shock.
■ Do not use this apparatus near water.
■ Do not block any of the ventilation openings
■ Do not install near any heat sources.
■ Do not install near naked flames.
■ Protect the mains cable from being stressed or pinched.
■ For optimum results, do not use the M16 on the same electrical
circuit as industrial equipment, such as motors, stage machinery
or any other equipment that causes noise or switching transients
on the mains circuit.
■ Unplug this apparatus during lightning storms or when unused
for long periods of time.
■ Adjust only those controls that are covered by the operating
instructions.
■ Use only the mains cable provided with the M16. Other cables
may not have sufficient current rating.
■ Do not operate this unit with the cover removed.
■ Unplug the unit before cleaning.
1-3
Revision MA2005-7 M16 Microphone Amplifier
1-4
M16 Microphone Amplifier Revision MA2005-7
2 Important information
2.1 Unpacking
The packaging for the M16 is designed to safely contain and protect
the M16 from the rigours and stresses usually experienced during international shipment. Specially designed mouldings cushion and
support the M16, while also providing space to incorporate and protect the optional RM16 and PSU. Space is provided to safely include
additional M16 specific items.
The M16 packaging contains:
■ 1 x M16
■ 1 x set of rack mounting ears + fitting screws
■ 1 x IEC mains cable (either fitted with UK or US style plug, or
unwired depending on country of use)
■ 1 x BNC T-Piece Connector
■ 1 x BNC Terminator
■ 1 x operations manual
2-1
Optional RM16 if included within the M16 packaging:
■ 1 x optional RM16
■ 1 x optional RM16 power block (Wall Wart)
■ 1 x optional IEC mains cable (either fitted with UK or US style
plug, or unwired depending on country of use)
Please retain packaging until all items are accounted for and found
to be operating correctly.
Revision MA2005-7 M16 Microphone Amplifier
2-2
2.2 Operational considerations
AC mains voltage
The M16 is intended for use throughout the world and therefore the
internal power supply allows operation through the following AC
mains voltages:
Mains voltage: 90v - 250v AC
Mains frequency: 50/60Hz
AC mains connection
The rear panel of the M16 houses the AC mains inlet on an IEC style
connector. The mains cable supplied with the M16 is also fitted with
a moulded IEC connector. Excluding UK and USA models, no plug
has been fitted to this mains lead, therefore this will need to be wired
(see 1.1.Mains Cable). Obtain professional advice from a qualified
electrician if unsure.
2.3 Cleaning
Before cleaning the M16, make sure the unit is switched off and the
mains plug is removed from the socket.
Only use a mildly damp cloth to clean the M16. Never use any domestic or commercial cleaning agents as these can cause damage
to external surfaces and components.
2.4 Installation
When fixing the M16 into any 19” rack mount frame, take into account the stresses that can be exerted on the rack ears if they are
the only means of support. Damage to the chassis could especially
occur during transportation if the M16 is not supported on rails within
a flight case. CADAC strongly recommends that as well as fixing the
M16 to the frame via the rack ears, support rails also be employed.
M16 Microphone Amplifier Revision MA2005-7
3 The M16 Microphone Amplifier
3.1 M16 Front panel
1 2 3 4 5 8 9 10 11
3-1
18
16 17 12 13 14 15 7 6
FIG 3-1. M16 front panel layout
1. Channel Number
2. Signal Overload Indicator
3. Signal Present Indicator
4. PFL Switch
5. Mute Switch
6. Headphone Socket
7. Headphone Level Control
8. PFL Level Meter
9. Channel Gain
10.Gain Increment Switch
11.Gain Decrement Switch
12.Polarity Reverse
13.Pad Switch
14.Phantom Power Switch
15.High Pass Filter Switch
16.Remote Indicator
17.USB Indicator
18.USB port
Revision MA2005-7 M16 Microphone Amplifier
3-2
3.2 M16 Rear Panel
11 15 12 13
1 2 3 4 5 6 7 8 9 10 14
FIG 3-2. M16 rear panel layout
1. Mains Inlet, Fuse and Power switch
2. Ground Stud
3. RS-485 Remote Communications Output Connector
4. RS-485 Remote Communications Input Connector
5. Word Clock BNC Connector
6. Word Clock Input/Output Selector Switch
7. Fibre Optic Output Connector (Tx) for MADI Output.
8. Fibre Optic Input Connector (Rx). Not Used.
9. 64/32 56/28 MADI Protocol Switch.
10.96kHz, 48kHz Sample Rate Switch.
11.PFL IN
12.PFL OUT
13.Analogue Microphone Level Input Connectors
14.Analogue Line Level Output Connectors
15.Additional Analogue Outputs on 2 x 37-Way D-sub Connectors
M16 Microphone Amplifier Revision MA2005-7
3.3 Connecting up your M16
3.3.1 Mains power
Make sure that your IEC power connector is wired correctly (see 1.1
Mains Cable).
Fit the IEC cable to the rear power connector on the M16, making
sure that it is fitted securely and the cable is stress free.
3.3.2 Ground stud
The M16 has been designed to fully comply and exceed current
EMC directives (immunity from electro-magnetic radiation and radio
frequency interference). However, for optimum performance it is
also important to take into consideration the entire audio system and
minimize the potential for excessive ground loops occurring between
equipment and interference being induced within audio cabling.
A Ground Stud is provided on the rear panel of the M16 to allow connection to other audio devices in order to minimize ground potentials, as well as providing a connection point for the use of Parallel
Earth Conductors, which can reduce induced noise within audio cabling by up to 80% if used correctly.
3-3
System wiring and grounding techniques fall well outside the scope
of this User Manual, however, there are a number of reference
sources available. More information on this topic can also be found
on the Cadac Sound Check Zone at www.cadac-sound.com.
3.3.3 Audio Connections
Inputs
Connect the microphone input cables to the respective XLR-3F connectors on the rear panel of the M16, making sure that all the connectors mate securely.
Analogue Outputs
Each channel is provided with an active 3-way splitter. One set of
outputs (channels 1 - 16) is available on XLR-3M connectors, while
the remaining two sets of outputs are available on two 37-way D-sub
connectors (female). For D-sub wiring details, please see Connec-
tor wiring in Appendices.
NOTE: All three outputs are balanced and designed to drive
over long cable lengths in excess of 500m, with little degradation in audio performance. The three outputs are level compensated, whereby if one leg is shorted to ground, the other leg
doubles its amplitude to compensate.
Revision MA2005-7 M16 Microphone Amplifier
Loading...
