Cadac C-Type User Manual

'g8;2'

Audio Mixing Console

-056#..#6+10#n#95'4#1#07#.

CADAC Electronics One New Street Luton Bedfordshire LU1 5DX England Tel +44 (0) 1582 404 202 Fax +44 (0) 1582 412 799 email: info@cadac-s ound.com

While every effort has been taken to ensure the accuracy of the contents in this manual, CADAC Audio Mixing Consoles are being subject to conti nuous development, hen c e the information in this manual may no t reflect latest prod uct updates. © Copyright CADAC Electronics plc. 2005.

Table of conte nts iii

7DEOH#RI#FRQWHQWV

6(&7,21 3$*(

*HQHUDO#3UHFDXWLRQV 111111111111111111111111111111111111111111111111#Y

4 &RQQHFWLQJ#WKH#PL[HU#V\VWHPV 1111111111111111111111111111 #404

1.1 Console modularity ....................................................................... 1-1

1.2 Frame rear connections................................................................ 1-1

1.3 Connect Power supply systems....................................................1-2

1.4 Connecting the console frames ....................................................1-4

1.5 Switching ON ...... ............... .... .... ............... .... ............... .... .... ......... 1-7

5 ,QSXW#FKDQQHO#PRGXOH#:<44 111111111111111111111111111111111 #504

2.1 Input Channel 7911 - front panel .................................................. 2-2

2.2 Input Channel 7911 - rear panel ................................................... 2-9

6 'XDO#0RQR#*URXS#)#3OD\EDFN#0RGXOH#;396 11111111 #604

3.1 Dual Mono Group & Playback module 8063.................................3-2

3.2 Dual Mono Group & Playback 8063 - rear panel ..........................3-6

7 6WHUHR#JURXS#)#3OD\EDFN#0RGXOH#;397 111111111111111 #704

4.1 Stereo Group & Playback module 8064........................................ 4-2

4.2 Stereo Group & Playback 8064 - rear panel.................................4-6

8 $X[#*URXSV#2XWSXW#0RGXOH#;3981111111111111111111111111 #804

5.1 Auxiliary Group Outputs module 8065.......................................... 5-2

5.2 Aux Groups Output module 8065 - rear panel ..............................5-5

9 0RQLWRULQJ#0RGXOH#:<45 11111111111111111111111111111111111111 #904

6.1 Monitoring module 7912 - front panel ...........................................6-2

6.2 Monitoring module 7912 - rear panel............................................6-7

: 26&/#31*#)#&RPPXQLFDWLRQV#0RGXOH#:<4611111111 #:04

7.1 OSC/PNG & Communications module 7913 - front panel ............ 7-2

7.2 OSC, PNG & Comms Module - rear panel ................................... 7-8

; ([WHUQDO#FRQQHFWLRQV1111111111111111111111111111111111111111111 #;04

8.1 Group to external me te r ............................ .... ............... .... .... ......... 8-1

8.2 Stereo to external meter ...............................................................8-1

8.3 Musical Director’s Output.............................................................. 8-2

8.4 Producer’s Output......................................................................... 8-3

$SSHQGLFHV11111111111111111111111111111111111111111111111111111111#$330,

,QGH[11111111111111111111111111111111111111111111111111111111111111#,1'(;0,

Revision C2005-2 C-Type

iv Table of contents

C-Type Revision C2005-2

General Precautions v

*HQHUDO#3UHFDXWLRQV

'DPDJH

(QYLURQPHQW

&OHDQLQJ

7UDQVSRUW

6DIHW\#,QVWUXFWLRQV

Do not place heavy objects on the control surface, expose it to s harp objects or handle the console in any way that may cause damage e.g. rough handling and/or excessive vibration.

Do not subject the equipment to dirt, dus t, heat or vibration during oper ation or stor age. Never expose the console to rain or moisture in any form. Should the console become wet, turn it off and disconnect from mains without further delay. The console should be given suff icient time to dry out, before recommenc ing operation.

When cleaning the cons ole, never use chemicals, abra sive substances or sol vents. The console control panels should be cleaned using a soft brush and a dry lint-free cloth. For pe rsistent ma rk s, us e a sof t clo t h and is op r opyl alc oh ol. Switches and potentiometers do NOT require cleaning or lubrication. For faders, see below.

Transport the cons ole in its purpose built flight-case; whilst at the sa me time taking precautions to protect the co ntrol surf ace from any damage. Alway s make sure adequate manpower is available and correct lifting methods are taken when moving the console.

Read the following before using the equipment

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

,QVWUXFWLRQV

,QVWDOODWLRQ

&RYHUV

3RZHU

3RZHU#FRUG

:DUQLQJ

0RLVWXUH

9HQWLODWLRQ

Keep these instructions for future reference. Follow all warnings in this manual and those printed on the power supply units.

The console must be installed following the guide lines in this manual. Never connect power amplifier outputs directly to the console. Connectors and plugs must never be used for any other purpose than for what they are intended.

Never use the power supply units without covers fitted. All service work must be carried out by qualified personnel only.

The power supply units must always be connected to correctly r ated mains p ower as referred to in this manual and marked on the power supply units. The power supply units must, at all times, be connected to the local mains power supply using the supplied po w er c or d. In c ase s w her e th e supp l ie d p lu g d oes not fi t , a qu al if i ed elec tr ic ia n must be consulted.

The power cord must be routed in such a way that the risks of accidentally stepping on it, stretching it or it being pinched, are minimized.

THIS EQUIPMENT MUST BE EARTHED !

In order to minimize risks of fire hazards and/or electric shock , the power supply unit must ne v er be e x pos ed to moi st ur e or wa te r in any f orm; or b e us ed i n a damp or w et environment. Never place liquid c ontainers, such as for instance coffee/t ea mugs, on the power supply uni t, so as to avoid spillage into openings.

Ventilation slots on the power supply or the console must never be covered or in any other way obstructed. Air flow required for safe operation may otherwise be restricted. Where the console is to be operated in its flight-case, then this must be located in such a way that it allows for proper ventilation.

6HUYLFH

C-Type Revision C2005-2

Refer servicing to qualified technical personnel only.

vi General Precautions

Revision C2005-2 C-Type

Connecting the mixer systems 1-1

4 &RQQHFWLQJ#WKH#PL[HU#V\VWHPV

414 &RQVROH#PRGXODULW\

The C-Type features CADAC’s unique frame design which allow use rs to put any module in any position, thus configuring the console to suit the project in hand. Each module is fitted with XLR connectors and jack sockets on the rear vertical face, enabling the module to be moved quickly and easily .

The C-Type module’s design features a motherboard, with plug-in daughter boards fo r all audio and digital control functions. This ensures servicing simplicity and fast replacement of any faulty component. Each module may be plugged into any position in the console frame, by means of top quality two-part connector system, which is designed as a m ating pair to provide excellent mechanical and electrical reliability.

A rail system is used to guide each mod ule into its correct po sition. Also, the console design allows modules to be removed or inserted without powering down.

415 )UDPH#UHDU#FRQQHFWLRQV

HEADPHONES (PFL) NEXT FRAME

AUDIO BUS FRAME TO FRAME

FIG 1-1. Frame rear connections.

PSU 1

5 AMP FAN FUSE

PSU 2

GND - 0 - FRAME

AUDIO BUS FRAME TO FRAME

The connections on the C-Type console re ar frame include the following (from left to right):

Audio Bus - frame t o frame.

■■■■

PFL output to next frame.

■■■■

PSU1 co nnector

■■■■

PSU2 co nnector

■■■■

F rame, GND and 0 V-connections with grounding bar.

■■■■

Audio Bus - frame t o frame.

■■■■

The use of these connect ors is describe d in 1.3.3 Main and extension frame power

connections an d 1.4 Connecting the console frames.

Revision C2005-2 C-Type

1-2 Connecting the mixer systems

416 &RQQHFW#3RZHU#VXSSO\#V\VWHPV

41614 3RZHU#VXSSO\#V\VWHP#GHVFULSWLRQ

Cadac consoles are designed to al low the use of two independent power supplies in a redundant configu ration – “main” and “backup”. Both power supply units are used to power the consol e system so that under normal conditi ons, the ‘load’ is shared between the “main” and “backup” PSU’s. If a fault occurs in one of the power units (cau sing it to ‘shut-down’), the remaining power unit will power the console.

In situations where it is necessary to provide a separa te ‘feed’ to each PSU, make sure that the cable lengths are the same. This is to minimize any induced a.c. power input noise by ensuring that the “EARTH IMPEDANCE” is the same for both PSU systems.

$5($#%5$1&+#3$1(/

*1'#%$5

$5($#%5$1&+#3$1(/

*1'#%$5

FIG 1-2. AC mains grounding diagram (single phase 208-240V)

The a.c.-input connectors on each power supply unit have three conductors: ‘LIVE’ (brown), ‘NEUTRAL’ (blue) and ‘EARTH’ (yellow/green). For safety and electromagnetic compatibility considerations, it is essential that the ‘EAR TH’ conductor is connected on all PSUs

the a.c. supply has an ‘EARTH’ conduc tor that has a

and

continuous circuit to the “zero-signal reference potential” point in the building. The ZSRP po in t i n a b u ildi n g i s u sua ll y f o un d n ea r th e p la ce whe r e the a. c. ‘m ain s’ s up pl y enters the building (often referred to as the “MAIN GROUND REFERENCE EARTH ELECTRODE SYSTEM”). The basic concept for correct a.c. mains wiring distribution is shown in figure 1-1. If you need further information about this complex subject, please refer to “Grounding Systems and their Implementation” by Charles Atkinson and Philip Giddins published in the AES Journal Vol. 43, No. 6 – June 199 5.

/ 1

368#4

(

368#5

1 (

The g rounding schem e in CADAC consoles is designed to meet the rigorous EEC

Electromagnetic Compatibility

requirements (EMC Directive - 1996). Any RF noise induced in the console frame(s) is directed to the “local” ZSRP, which is the metalwork of the power supply u nits. In o rder to take full advantage of the “RF noise immunity” capability of the CADAC system, PSU a.c. mains cables and the a.c. mains supply EARTH conductor must be conn ected correctly.

C-Type Revision C2005-2

Connecting the mixer systems 1-3

41615 $&#SRZHU#UHTXLUHPHQWV

CADAC power supply units are designed to run from a minimum of 208V, 50/60Hz a.c. In many parts of the world where the single phase a.c. supply is 110/120V, the CADAC power supplies are adjusted to operate at this input voltage.

41616 0DLQ#DQG#H[WHQVLRQ#IUDPH#SRZHU#FRQQHFWLRQV

See fig 1-3 below for schematics of the frames power connections.

FIG 1-3. Power connections

368#4

1. Connect a PSU cable between the PSU 1 a nd the PSU connector on the MAIN FRAME.

2. Connect a PSU cable between the PSU 2 and the PSU 2 connector on the MAIN FRAME.

3. Repeat procedures 1 and 2 for EXTENSION FRAME 2 (a 3 frame console).

368#5

Revision C2005-2 C-Type

1-4 Connecting the mixer systems

417 &RQQHFWL QJ#WKH#FRQVROH#IUDPHV

41714 $XGLR#%XV#&RQQHFWLRQV

If the console is used in a multi-frame configur ation then th e busses need to be connected in a ‘daisy chain’ fashion.

Each end

(see fig 1-4). The bus cables are simply linked betwee n similar connectors on the

end of the nearest frame.

of a frame has six audio bus connectors

FIG 1-4. Audio/Data Bus connections.

Input channel mo dule 7911 2-1

5 ,QSXW#FKDQQHO#PRGXOH#:<44

The C- type input channel module is featured with microphone and line level inputs, controlled via a stepped gain control calibrated in dB. A three band equalizer with a HP-filter is provi ded as well as four mono auxiliary sends and a stereo fo ldback. Routing can be perf ormed to 16 groups a nd the module features a separate stereo mix. The direct output is controlled via a dedicated level control. An LED meter with a measuring range of 57 dB is positioned beside the channel fader and indicates the pre-fade r/direct ou tpu t si gnal level.

Following pages describes the 7911 module in detail.

Revision C2005-2 C-Type

2-2 Input ch annel modu le 7911

514 ,QSXW#&KDQQHO#:<44#0#IURQW#SDQHO

2.1.1 Input Gain

2.1.2 Input Trim

2.1.3 Input 2

2.1.5 Line-up tone

2.1.7 Phase reverse

51414 ,QSXW#*DLQ

Dual gang Input gain for microphone and Li ne level inputs, set on a stepped switch providing setting ranges of 50dB and 32dB respectively.

51415 ,QSXW#7ULP

2.1.4 Phantom power

2.1.6 M-S

2.1.8 LINE

2.1.9 Stereo

2.1.10 Groups

The input trim control provides a continuous +/- 6dB of change on the input gain.

51416 ,QSXW#5

Push-button to select the second input as the input source in place of I/P 1.

51417 3KDQWRP#3RZHU

Push-button to switch ON the 48V phantom power.

51418 /LQH0XS#WRQH

Press this button to apply a line-up tone to the input.

C-Type Revision C2005-2

Input channel mo dule 7911 2-3

51419 006

Press M-S when the channel is used for the side microphone in M-S applications. This function is only available when M-S safety (on the 8064) is selected ON.

5141: 3KDVH#UHYHUVH

Press this button to reverse the phase of the Mic and Line inputs.

5141; /,1(

Press this button to connect the second input to the Line Input amplifier, This function i s available ONLY when th e MASTER RE-MIX is ON.

5141< 6WHUHR

Press this button to route the channel output to the L and/or R stereo buss.

514143 *URXSV

Push-buttons f or r outi n g t he c hann el ou tp ut t o t he G roup ma ster s . When t h e ch anne l is used in surround mode the busses are pre-designated.

Revision C2005-2 C-Type

2-4 Input ch annel modu le 7911

,QSXW#&KDQQHO#:<44#0#IURQW#SDQHO

2.1.11 HF Q control

2.1.13 HF EQ Bell/Shelf switch

2.1.14 MF Q control

2.1.16 LF Q control

2.1.18 LF EQ Bell/Shel f sw itch

2.1.19 Equalizer In/Out

2.1.20 HP filter In/Out

2.1.22 Aux Sends Pre switches

2.1.12 HF Frequency, Boost/Cut control

2.1.15 MF Frequency, Boost/Cut control

2.1.17 LF Frequency, Boost/Cut control

2.1.21 H P Filter Frequency control

2.1.23 Aux Sends 1-4 level controls

2.1.24 Stereo foldback Pre switch

2.1.26 Direct O/P Pre switch

514144 +)#4#FRQWURO

The Q-control varies the bandwidth of the boost/cut at the frequency chosen (Q is only available at the default BELL response). A low Q-value gives a wide bandwidth. This means that a relatively large range of frequencies, either side of the centre frequency, have boost /cut applied. When the Q-value is high, the bandwidth is reduced so tha t a much smaller range of frequencies hav e boost/cut applied.

514145 #+)#)UHTXHQF\/#%RRVW2&XW#FRQWURO

Dual ganged control allow you to choose the “centre” frequency at which the boost/ cut is appli ed and to define the amount of boost or cut applied to the high frequency band.

2.1.25 Stereo foldback

2.1.27 Direct Output level

C-Type Revision C2005-2

Input channel mo dule 7911 2-5

514146 +)#(4#%HOO26KHOI#VZLWFK

Press this button to change the response of the equalizer from BELL (default response) to SHELF.

514147 0)#4#FRQWURO

The Q-control varie s the bandwidth of the boost/cut at the frequency chosen (Q is only available at the default BELL response). A low Q-value gives a wide bandwidth. This means that a relatively lar ge range of frequencies, eit her side of the centre frequency, have boost /cut applied. When the Q-value is high, the bandwidth is reduced so tha t a much smaller range of frequencies have boost /cut applied.

514148 0)#)UHTXHQF\/#%RRVW2&XW#FRQWURO

Dual ganged control allow you to choose the “centre” frequency at which the boost/ cut is appli ed and to define the amount of bo ost or cut applied to the mid frequency band.

514149 /)#4#FRQWURO

The Q-control varie s the bandwidth of the boost/cut at the frequency chosen (Q is only available at the default BELL response). A low Q-value gives a wide bandwidth. This means that a relatively lar ge range of frequencies, eit her side of the centre frequency, have boost /cut applied. When the Q-value is high, the bandwidth is reduced so tha t a much smaller range of frequencies have boost /cut applied.

51414: /)#)UHTXHQF\/#%RRVW2&XW#FRQWURO

Dual ganged control allow you to choose the “centre” frequency at which the boost/ cut is applied and to define the amount of boost or cut app lied to the high frequency band.

51414; /)#(4#%HOO26KHOI#VZLWFK

Press this button to change the response of the equalizer from BELL (default response) to SHELF.

51414< (TXDOL]HU#,Q22XW

Press the EQ IN button to put the equalizer in the channel signal chain.

514153 +3#)LOWHU#,Q22XW

Press the HPF button to switch the high-pass filter In/Out of circuit.

514154 +3#)LOWHU#)UHTXHQF\#FRQWURO

Variable frequency control for choosing the frequency at which the filter starts to “turn over” (also known as the knee or -3dB point for the filter). The “turn-over” frequency is continuously variable from 15 to 400 Hz and provides a cut of 12dB/oct.

Revision C2005-2 C-Type

2-6 Input ch annel modu le 7911

514155 $X[#6HQGV#3UH#VZLWFKHV

This switch functions in conjunction with the PRE selector switches on the rear panel to provide the option of sending from PRE/POST EQ or PRE/POST fader.

514156 $X[#6HQGV#407#OHYHO#FRQWUROV

Rotary control for setting the Aux Send level.

514157 6WHUHR#IROGEDFN#3UH#VZLWFK

This switch functions in conjunction with the PRE selector switches on the rear panel to provide the option of sending from PRE/POST EQ or PRE/POST fader.

514158 6WHUHR#IROGEDFN

Dual ganged control allow you to adjust stereo foldback Level and Pan.

514159 ' LUHFW#2XWSXW#3UH#VZLWFK

This s wit ch fu nc ti on s i n conj un ct io n wi th the P RE se lect o r s w itch on t he rear p anel to provide the option of sending from PRE/POST EQ or PRE/POST FADER.

51415: ' LUHFW#2XWSXW#OHYHO

Rotary co ntrol for adjusting the direct output level.

51415; 6XE0ZRRIHU#OHYHO

Rotary knob for adjusting the sub-woofer level.

51415< 814#(QDEOH

Pressing this switch enables Left-Centre-Right, Fr ont-Back and Sub woofer level. controls.

514163 713#(QDEOH

Pressing this switch enables Left-Right and Front-Back level.

514164 513#(QDEOH

Pressing this switch enables Left-Right panning on the ste reo bus.

514165 * URXS#(QDEOH

Pressing this switch enables Left-Right panning across the groups

C-Type Revision C2005-2

Input channel mo dule 7911 2-7

,QSXW#&KDQQHO#:<44#0#IURQW#SDQHO

2.1.28 Sub-woofer level

2.1.29 5.1 Enable

2.1.30 4.0 Enable

2.1.31 2.0 Enable

2.1.32 Group Enable

2.1.35 Insert Pre/Post EQ

2.1.37 SOLO

2.1.39 PF L

2.1.41 LED meter

2.1.33 Panning Front-Back

2.1.34 Panning Left-Right

2.1.36 Insert In/Out

2.1.38 Meter D-O

2.1.40 MUTE

2.1.42 Fader

514166 3DQQLQJ#)URQW0%DFN

Rotary control for Front-Back Panning.

514167 3DQQLQJ#/HIW05LJKW

Rotary control for Left-Right Panning.

Revision C2005-2 C-Type

2-8 Input ch annel modu le 7911

514168 ,QVHUW#3UH23RVW#(4

Press this switch to select Insert point PRE or POST Equalizer.

514169 ,QVHUW#,Q22XW

All input channels have a Send and Return break-jack facility. This is to allow the channel signal to be sent out to, and returned from an external processing unit. A relay is used to switch the insert function “in” and “out”. The relay is controlled by the insert (INS) switch.

51416: 6ROR

This b utt on p la ce s the p os t- f a de r s ig nal, pa nn ed 2.0, 4. 0 o r 5. 1 vi a the con t rol s in th e MONITOR module, to the monitor speakers. All other channels are muted.

51416; 0HWHU#'02

Pressing this button selects th e meter to read the level of the Direct Output in place of the pre-fader signal.

51416< 3)/

Pressing this button places the pr e-fader sign al into the MONITOR module where it can be checked on the monitor speakers, small L/S or headphones.

514173 087(

Pressing this button mutes all post fader signals leaving the input channel.

514174 /('#PHWHU

This 20-s eg men t LE D me te r indi ca te s t he ch an ne l l e v el i mme di atel y p re- f a der, or the direct output level.

514175 )DGHU

A 100m m fader contr olling the signal level to the stereo busses, Groups and all post fader send s.

C-Type Revision C2005-2

Input channel mo dule 7911 2-9

515 ,QSXW#&KDQQHO#:<44#0#UHDU#SDQHO

Inputs and Outputs are elect ronically ba l-

anced and connected via 3-pin XLRs and

follow the wiring convention:

PIN 1 = Screen

PIN 2 = In -phase signal (hot)

PIN 3 = Out-of-phase signal (cold)

The 0.25” TRS jack connectors use the

wiring convention:

TIP = In-phase signal (hot)

RING = Out-of-phase signal (cold)

SLEEVE = Screen

IMPORTANT NOTE: Pin 1 on XLR con-

nectors and the ‘sleeve’ connections on the jack sockets are connected to

the FRAME. This is to ensure that the

console can comply with the Electric

Compatibility (EMC) directive.

AUX AND FOLDBACK SWITCH DIRECT OUTPUT SWITCH

DIRECT OUTPUT

SEND

RETURN

LINE INPUT

MICROPHONE INPUT

Revision C2005-2 C-Type

2-10 Input ch annel modu le 7911

C-Type Revision C2005-2

Dual Mono Group & Playback Module 8063 3-1

6 'XDO#0RQR#*URXS#)#3OD\EDFN#

0RGXOH#;396

Each gr ou p o utpu t mo du le co ntai ns two ou tp ut gr ou ps wi th id en ti cal facilities and th e groups are individually metered on a 24-segment display. The main outputs may be used as sub-groups; each can be assigned to either the left or right stereo mixing busses. The module provides independent PAN or Left and Right signal to L and/or R mix busses. The insert point can be selected pre or post fader.

The following pages describes the Dual Mono Group & Playback module in detail.

Revision C2005-2 C-Type

3-2 Dual Mono Group & Playba ck Module 8063

614 'XDO#0RQR#*URXS#)#3OD\EDFN#PRGXOH#;396

61414 /('0PHWHUV

A pair of high accuracy 24-segment LED meters indicating the group output le vel. Rise t ime <2µS Fall back time is approximately 3 seconds. Accuracy at any step is ±0.1dB.

The LEDs are colour coded: Green -28dB to +4dB Amber +6 to +16dB Red +18dB

The +18dB sector has a 3 second ‘peak flash’ function to indicate that this level has been met or exceeded (user option).

61415 ,QSXW#7ULP

This centre detent potentiometer provides ±10dB adjustment for the track playback to the monitors.

61416 6XE0ZRRIHU#OHYHO

3.1.1 LED-meters

This potentiometer adjusts the output level from the group to the sub-woofer.

C-Type Revision C2005-2

Dual Mono Group & Playback Module 8063 3-3

61417 3DQQLQJ#)0%

This po tenti omete r adj usts the pan ning F ront to Ba ck (NO T E: The app ropria te f ormat must be sele cted with one of the Enable-buttons. If no form at is selected, panning does not operate).

61418 3DQQLQJ#50/

This potentiometer adjusts the panning Right to Left (NOTE: The appropriate format must be sele cted with one of the Enable-buttons. If no form at is selected, panning does not operate).

3.1.2 Input Trim

3.1.3 Sub-woofer level

3.1. 4 Panning F-B

3.1.5 Panning R- L

3.1.6 5.1 Enable

3.1.7 4.0 Enable

3.1.8 2.0 Enable

3.1.9 Track Playback Routing

61419 814#(QDEOH

Press this button to enable Left-Centre-Right, Front-Back and Sub-woofer level to monitors.

6141: 713#(QDEOH

Press this button to enable Left-Right and Front-Back panning to monitors.

Revision C2005-2 C-Type

3-4 Dual Mono Group & Playba ck Module 8063

6141; 513#(QDEOH

Press this button to enable Left-Right panning to the monitors.

6141< 7UDFN#3OD\EDFN#5R XWLQJ

Selector buttons for routing o f group to monit or module.

614143 * URXS#WR#6WHUHR

Rotary co ntrol adjusting panning to the left and right stereo recording busses.

614144 3DQQLQJ#,1

Press this button to activate the panning feature.

614145 3DQQLQJ#/HIW

Press this button to select Panning to the left recording bus.

614146 3DQQLQJ#5LJKW

Press this button to select panning to the right recording bus.

614147 3UH23RVW#IDGHU

This button is used to select insert point PRE or POST fader.

614148 ,QVHUW

Press this button to select Insert IN.

614149 3)/

This electronically la tching button is under control of the HOLD and CLEAR function on the Stereo Group module 8064 and allows pre-fader checking of the group signal.

61414: 087(

When pressed, the MUTE button breaks the post fader signal path.

61414; )DGHU

A 100mm conductive p lastic fader used t o control the Group recording level, providing 10dB gain when fully open.

C-Type Revision C2005-2

Dual Mono Group & Playback Module 8063 3-5

3.1.10 G roup to Stereo

3.1.11 Pann in g IN

3.1.12 Pann in g Le ft

3.1.13 Pann in g Right

3.1.14 Pre/Post fader

3.1.15 Ins ert

3.1.16 PF L

3.1.17 MU T E

3.1.18 Fader

. .

Revision C2005-2 C-Type

3-6 Dual Mono Group & Playba ck Module 8063

615 'XDO#0RQR#*URXS#)#3OD\EDFN#;396#0#UHDU#SDQHO

The SEND and RETURN insert points are electronically balanced and follow the wiring convention: TIP = In-phase signal (hot) RING = Out-of-phase signal (cold) SLEEVE = Screen

Output of the ‘ODD’ group.

Playback input to the ‘ODD’ group from recorder.

Inputs and Output s are electroni-

cally b alanced and conn ected

via 3-pin XLRs and follow the

wiring

convention:

PIN 1 = Screen

PIN 2 = In-phase signal (hot)

PIN 3 = Out-of-phase signal

(cold)

IMPORTANT NOTE: Pin 1 on

XLR connectors and the

‘sleeve’ connections on the

jack sockets are connected to

the FRAME. This is to ensure

that the console can comply

with the Electric Compatibility

(EMC) directive .

Group output to external meters (see chapter 8 for connection details)

The SEND and RETURN insert points are electronically balanced and follow the wiring convention: TIP = In-phase signal (hot) RING = Out-of-phase signal (cold) SLEEVE = Screen

Output of the ‘EVEN’ group.

Playback input to the ‘EVEN’ group.

C-Type Revision C2005-2

Stereo group & Playback Module 8064 4-1

7 6WHUHR#JURXS#)#3OD\EDFN#

0RGXOH#;397

The Stereo Group Output & Playback module 8064 has user selectable inputs to meters and input select for playback . Insert point can b e selected pre-fader and the module also features M-S safety check.

The following pages describes the Stereo Group and Playback module in detail.

Revision C2005-2 C-Type

4-2 Stereo group & Playback Module 8064

714 6WHUHR#*URXS#)#3OD\EDFN#PRGXOH#;397

71414 /('0PHWHUV

A pair of hi gh acc ur acy 24 -s eg ment LE D met e rs w ith a rise ti me to full sc al e o f <2µS. Fall back time is approximately 3 seconds. Accuracy at any step is ±0.1dB. The LEDs are colour coded:

Green -28dB to +4dB Amber +6dB to +16dB Red +18dB

The +18dB sector has a 3 second ‘peak flash’ function to indicate that this level has been met or exceeded (user option).

71415 &RQVROH#2XW

Press this button to select Consol e Out as the source of the Group and Stereo meters.

4.1.2 Console Out

4.1.3 Playback

4.1.4 Follow Monitors

4.1.1 LED-meters

C-Type Revision C2005-2

Stereo group & Playback Module 8064 4-3

71416 3OD\EDFN

Press this button to select Playback as the source of the Grou p and Stereo meters.

71417 ) ROOR Z#0RQLWRUV

Press this button to connect the monitor output signals to the group and stereo meters.

71418 006#6DIHW\

Press this master enable button to use any pair of channels in M-S (Master/Sides) mode.

71419 &KHFN#0XWH

If a channel is muted, pressing this button will have the effect that the channel goes unmuted but all the other channels are forced into mute. This allows the originally muted channel to have a ‘SOLO’ function. Note that this is not a true “solo function”, because if more than one channel is muted, then the operation of this switch will turn all the muted channels “on” again, as it forces all of the unmuted channels “off”.

4.1.10 Playback to TB

4.1.11 Playback to Monitor

4.1.5 M-S Safety

4.1.6 Check Mute

4.1.7 Remix

4.1.8 PFL & SOLO Clear

4.1.9 PFL & SOLO Hold

Revision C2005-2 C-Type

4-4 Stereo group & Playback Module 8064

7141: 5HPL[

Pressing this button changes the console from microphone inputs to line inputs. This means the console goes from record mode to playback the multi-track tape mode.

7141; 3)/#)#62/2#&OHDU

In norma l operatio n the PF L & SOLO bus se s function in ‘int e rc ancel mode ’ w he re each new selection cancels any active PFL or SOLO selections. The CLEAR button is illuminated if a PFL or SOLO is active and may be used to cancel the current selection.

7141< 3)/#)#62/2#+ROG

If the HOLD button is pressed, each new PFL or SOLO selection is mixed with the existing selection.

714143 3OD\EDFN#WR#7%

Pressing these buttons selects the STEREO returns from either recorder A or recorder B to the TalkBack system. The f eature is intended for enabling clic k track or tempo information to be heard via the TalkBack.

714144 3OD\EDFN#WR#0RQLWRU

Pressing these buttons selects the STEREO returns from either recorder A or B to the monitor system.

714145 3UH23RVW#IDGHU

This button is used to select the insert point PRE or POST fader.

714146 ,QVHUW

Press this button to select Insert IN.

714147 3)/

This electronically la tching button is under control of the HOLD and CLEAR function (see previous page) and allows pre-fader checking of the stereo channel.

C-Type Revision C2005-2

Stereo group & Playback Module 8064 4-5

714148 087(

When pressed, the MUTE button breaks the post fader signal path.

714149 )DGHU

A 100mm conductive plastic fader used to control the Stereo recording level, providing 10dB gain when fully open. .

4.1.12 Pre/Post fader

4.1.13 Insert IN

4.1.14 PFL

4.1.15 MUTE Left and Right

4.1.16 Fader

Revision C2005-2 C-Type

4-6 Stereo group & Playback Module 8064

715 6WHUHR#*URXS#)#3OD\EDFN#;397#0#UHDU#SDQHO

Stereo input (return) from recorder B.

Stereo input (return) from recorder A.

Inputs and Outputs are electron-

ically balanced and connected

via 3-pin XLRs and follow the

wiring

convention:

PIN 1 = Screen

PIN 2 = In-phase signal (hot)

PIN 3 = Out-of-phase signal

(cold)

IMPORTANT NOTE: Pin 1 on

XLR connectors and the

‘sleeve’ connections on the

jack sockets are connected to

the FRAME. This is to ensure

that the console can comply with the Electric Compatibil-

ity (E MC) directive.

Stereo Group output to external meters (see chapter 8 for connection details)

Left & Right channel send

Left & R ight channel r eturn

Output of Stereo LEFT.

Output of Stereo RIGHT

C-Type Revision C2005-2

Aux Groups Output Module 8065 5-1

8 $X[#*URXSV#2XWSXW#0RGXOH#

;398

The Auxiliary Group module 8065 has f our mono groups with independe nt controls fo r output level and PFL for each output. The module also comprises a Foldback output with pan and SOLO as wel l as independent meter select for each output.

The following pages describes the auxiliary group outputs module in detail.

Revision C2005-2 C-Type

5-2 Aux Groups Output Module 8065

814 $X[LOLDU\#*URXS#2XWSXWV#PRGXOH#;398

81414 /('#PHWHUV

Pair of high accuracy 24-segment LED meters that can be set to indicate the level of Aux 1 to 4 or Foldback. Rise time to full scale is <2µS and fallback time approximately 3 seconds. Accuracy at any step is ±0.1dB. The LEDs are colour coded: Green from -28 to +4, Amber from +6 to +16 and Red +18. The +18 sector has a 3 second ‘peak flash’ function to indicate that this level has been met or exceeded (user option).

81415 $X[#4#VHOHFW

Press this button to have the LED meters indicate the level of the Aux 1 group.

81416 $X[#5#VHOHFW

Press this button to have the LED meters indicate the level of the Aux 2 group.

81417 $X[#6#VHOHFW

Press this button to have the LED meters indicate the level of the Aux 3 group.

81418 $X[#7#VHOHFW

Press this button to have the LED meters indicate the level of the Aux 4 group.

81419 ) ROGEDFN#VHOHFW

Press this button to have the LED meters indicate the Foldback level.

C-Type Revision C2005-2

Aux Groups Output Module 8065 5-3

5.1.1 LED meters

5.1.4 Aux 3 select

5.1.2 Aux 1 select

5.1.5 Aux 4 select

5.1.3 Aux 2 select

5.1.6 Foldback select

Revision C2005-2 C-Type

5-4 Aux Groups Output Module 8065

5.1.7 PFL

5.1.8 MUTE

5.1.10 SOLO ON

5.1.11 MUTE

5.1.9 Aux grou p output level control

5.1.12 Foldback St ereo balance

5.1.13 Foldback output level control

8141: 3)/

Press this button to switch the Aux group output PFL feature ON.

8141; 087(

Press this button to mute the associated auxiliary group output.

8141< $X[#RXWSXW#OHYHO#FRQWURO

This rotary control sets the Aux group output level.

814143 62/2#21

Press this button to SOLO the output into the monitor speakers.

814144 087(

Press this button to mute the foldback output.

814145 )ROGEDFN#VWHUHR#EDODQFH

This c ontrol adjusts t he stereo balance of the fold back output.

814146 ) ROGEDFN#RXWSXW#OHYHO#FRQWURO

This control sets the foldback outp ut level.

C-Type Revision C2005-2

Aux Groups Output Module 8065 5-5

815 $X[#*URXSV#2XWSXW#PRGXOH#;398#0#UHDU#SDQHO

LEFT OUTPUT FOR FOLDBACK MONITORS

RIGHT OUTPUT FOR FOLDBACK MONITORS

Input s and Outputs are electronically

balanced and connected via 3-pin XLRs

and f ollow the wiring

convention:

PIN 1 = Screen

PIN 2 = In-phase signal (hot)

PIN 3 = Out-of-phase signal (cold)

IMPORTANT NOTE: Pin 1 on XLR con-

nectors and the ‘sleeve’ connections on the jack sockets are connected to

the FRAME. This is to ensure that the

console can comply with the Electric

Compatibility (EMC) directive.

AUXILIARY GROUP 4 OUTPUT

AUXILIARY GROUP 3 OUTPUT

AUXILIARY GROUP 2 OUTPUT

AUXILIARY GROUP 1 OUTPUT

Revision C2005-2 C-Type

5-6 Aux Groups Output Module 8065

C-Type Revision C2005-2

Monitoring Module 7912 6-1

9 0RQLWRULQJ#0RGXOH#:<45

The Monitoring module has several features including fully variab le SOLO level, fully variable BLEND into SOLO and full control over each surround monitor speaker. 5.1,

4.0 an d 2.0 formats can each be switched to MONO and the module also has inde-

pendent user controlled levels for both DIM and RTB dim.

The following pages describes the 7912 module in detail.

Revision C2005-2 C-Type

6-2 Monit oring Module 7912

914 0RQLWRULQJ #PRGXOH#:<45#0#IURQW#SDQHO

91414 62/2#OHYH O

This volume control sets the listening level of the ‘solo-in-place’ in the surround monitors. The control is a six-section potentiometer with matched tra cks that permit retention of the solo image location.

91415 %OHQG#LQWR#62/2

This control blends the listening level of the remaining soloed channels into the monitor speakers.

6.1.3 Blend into SOLO - ON

6.1.4 PFL - ext speaker

6.1.5 Reverse Talkback - ext speaker

6.1.7 PFL -headphones

6.1.8 Reverse Talkback - headphones

6.1.10 Shuffler

6.1.11 Output - Stereo monit ors ON

6.1.1 SOLO level

6.1.2 Blend into SOLO

6.1.6 Output level - ext speaker

6.1.9 Output level - headphones

6.1.12 O utput level - stereo monitors

6.1.13 MO NO

C-Type Revision C2005-2

Monitoring Module 7912 6-3

91416 %OHQG#LQWR#62/2#0#21

Press this button to switch the ‘Blend into solo’ - function ON.

91417 3)/#0#H[WHUQDO#VSHDNHU

Press this button to switch PFL to external speaker ON.

91418 5HYHU VH#7DONEDFN#0#H[WHUQDO#VSHDNHU

Press this button to switch Reverse Talkback listening to external speak er ON.

91419 2XWSXW#OHYHO#0#H[WHUQDO#VSHDNHU

This rotary control sets the output level to the external speaker.

9141: 3)/#0#+HDGSKRQHV

Press this button to switch PFL to headphones ON.

9141; 5HYHU VH#7DONEDFN#0#+HDGSKRQHV

Press this button to switch Reverse Talkback listening to headphones ON.

9141< 2XWSXW#OHYHO#0#+HDGSKRQHV

This rotary control sets the output level to the headphones.

914143 6KXIIOHU

Press this button to enhance the stereo image in the headphones to simulate loud speaker lis tening.

914144 2XWSXW#0#6WHUHR#0RQLWRUV#21

Press this button to switch ON the output from the stereo monitor bus to speakers located in th e recording studio. This function is disabled when the RED cue light is ON.

914145 2XWSXW#OHYHO#0#6WHUHR#0RQLWRUV

This rotary control sets the output level to the stereo monitors.

914146 0212

Pressing this button selects the various surround multi-channel formats and sums as mono to the monitors.

Revision C2005-2 C-Type

6-4 Monit oring Module 7912

914147 3KDVH#UHYHUVH#RI#PRQLWRU#VSHDNHUV

Press the required button to reverse the phase of any of the monitor speakers.

914148 0XWLQJ#RI#PRQLWRU#VSHDNHUV

Press the required button to mute any of the monitor speakers.

914149 /3 0ILOWHU#21

Press this button to switch the sub-woofer LP-filter ON.

91414: 6XE0ZRRIHU#WULP0SRW

Trim-pot for accurate adjustment of the sub-woofer level.

91414; &HQWUH#FKDQQHO#WULP0SRW

Trim -pot for accurat e adjustme nt of t he Ce nt r e ch an ne l level.

91414< /HIW#FKDQQHO#WULP0SRW

Trim-pot fo r accurate adjustmen t of th e level of the left channe l speaker .

6.1.14 Phase reverse of monitor speakers.

6.1.16 LP-filter ON

6.1.15 Muting of monitor speakers.

6.1.17 Sub-woofer trim-pot.

6.1.18 Centre channel trim-pot

6.1.19 Left channel trim-pot.

6.1.20 Left channel su rround trim-pot

C-Type Revision C2005-2

6.1.21 Right channel trim-pot.

6.1.22 Right channel surround trim-pot

Monitoring Module 7912 6-5

914153 /HIW#FKDQQHO#VXUURXQG#WULP0SRW

Trim-pot for accurate adjustment of the level of the left channel surround speaker.

914154 5LJKW#FKDQQHO#WULP0SRW

Trim-pot for accurate adjustment of the level of the rig ht channel speaker.

914155 5LJKW#FKDQQHO#VXUURXQG#WULP0SRW

Trim-pot for accurate adjustment of the right channel surround speaker.

914156 0RQLWRU#'LP#OHYHO#0#5H YHUVH#7 DONEDFN

Use this control to set the attenuation of the monitor speaker s when the reverse talkback featur e is en ga ged.

914157 0RQLWRU#'LP#OHYHO#0#',0#EXWWRQ

Use this control to set the attenuation of the monitor spe akers when the DIM-b utton is pressed.

6.1.23 Monitor Dim lev el - Rever s e T alkback

6.1.24 Monitor Dim level - DIM button

6.1.25 Monitor level

6.1.26 DIM-button

6.1.27 Monitor FROM

6.1.28 Monitor PLAYBACK

Revision C2005-2 C-Type

6-6 Monit oring Module 7912

914158 0RQLWRU#OHYHO

This s ix-section potentiometer with very closely mat ched tracks provi des accurate setting of the monitor speakers sound level.

914159 ',00EXWWRQ

When p ressed, this latching, illuminated button attenuates the monitor level to that set by the right hand monitor dim-level pot above.

91415: 0RQLWRU#)520

This latching, illuminated button selects whether the input to the monitor module, via the MONITOR PLA YBACK b utton (below) is multi-track (group) or stereo.

91415; 0RQLWRU#3/$<%$&.

This latching, illuminated button selects whether the monitor source is the recording outp ut from the cons ole or the playback returns into the console.

C-Type Revision C2005-2

Monitoring Module 7912 6-7

915 0RQLWRULQJ #PRGXOH#:<45#0#UHDU#SDQHO

OUTPUT TO EXTERNAL SPEAKER FOR MONITORING OR OF PFL OR RTB

LEFT OUTPUT - STUDIO MONITOR

RIGHT OUTPUT - STUDIO MONITOR

Input s an d outputs ar e ele ct r on ic al ly

balanced and connected via 3-pin

XLRs and follow the wiring conven-

tion:

PIN 1 = Screen

PIN 2 = In-phase signal (hot)

PIN 3 = Out-of-phase

signal (cold)

IMPORTANT NOTE: Pin 1 on XLR connectors and the ‘sleeve’ con-

nections on the jack sockets are

connected to the FRAME. This is

to ensure that the console can

comply with the Electric Comp ati -

bility (EMC) directive.

OUTPUT - RIGHT CHANNEL SURROUND

OUTPUT - LEFT CHANNEL SURROUND

OUTPUT - SUB-WOOFER

OUTPUT - CENTRE

OUTPUT - RIGHT

OUTPUT LEFT

Revision C2005-2 C-Type

6-8 Monit oring Module 7912

C-Type Revision C2005-2

OSC, PNG & Communications Module 7913 7-1

: 26&/#31*#)#&RPPXQLFDWLRQV#

0RGXOH#:<46

The OSC/PNG and Communications module 7913 has facilities for full power supply monitoring and comprises a Tone and Pink noise generator for line up of channels and surround monitor speakers. The module can facilitate a TB microphone and features c omp r eh ens iv e a nd in de pe nden t ta lk ba c k facilities for Producer, Music D ire ct or and spare. Talkback routing to all Auxiliary Groups, Studio, TB1 TB2 an d MD is included. Also, the module includes a Cue light control and a slate mark er for ‘audio inden t’ on a record track.

The following pages describes the module in detail.

Revision C2005-2 C-Type

7-2 OSC, PNG & Communications Module 7913

:14 26&231*#)#&RPPXQLFDWLRQV#PRGXOH#:<46#0#

IURQW#SDQHO

:1414 7;9#PRQLWRU

This LED provides monitoring indication of the 48V supply voltage.

:1415 .4;9#PRQLWRU

This LED provides monitoring indication of the +18V supply voltage.

:1416 04;9#PRQLWRU

This LED provides monitoring indication of the -18V supply voltage.

:1417 469#PRQLWRU

This LED provides monitoring indication of the 13V supply voltage.

:1418 ,QSXW#7%#PLFURSKRQH

This balanced XLR input is intended for an Engineer’s talkback microphone.

:1419 3KDQWRP#SRZHU#21

Press this button to switch ON the 48V phantom power.

7.1.1 48V monitor

7.1.2 +18V monitor

7.1.3 -18V monitor

7.1.4 13V monitor

7.1.5 Input TB micropho ne The wiring convention is:

PIN 1 = Screen

PIN 2 = + phase (hot)

PIN 3 = – ph ase (cold)

7.1.6 Phantom power ON

C-Type Revision C2005-2

OSC, PNG & Communications Module 7913 7-3

:141: 31*#WR#0RQLWRUV

Press this button to select the internal Pink Noise Generator to the Monitor output section of the 7912 Monitor module to enabl e accurate line-up of the surround speakers.

:141; 2VF#RU#31*#WR#&KDQQHOV

Press this button to route the selected output of the internal Oscillator o r PNG to the Channels-section of the console.

:141< 2VF#RU#31*#WR#*URXSV

Press this button to route the selected output of the internal Oscillator o r PNG to the Groups-section of the console.

7.1.7 PNG to Monitors

7.1.8 Osc or PNG to Channels

7.1.9 Osc or PNG to Groups

7.1.10 Osc or PNG to Stereo

7.1.11 PNG ON

7.1.12 Sine wave frequency select

7.1.13 Osc/PNG ON

7.1.14 P ro ducer TB Ph an tom power ON

7.1.19 LED meter

7.1.20 OSC/PNG Output

7.1.21 Producer Mic Gain

7.1.15 Reverse TB2 Phantom power ON

7.1.16 Reverse TB2 ON

7.1.17 MD Reverse TB Phantom power ON

7.1.18 MD Reverse TB ON

Revision C2005-2 C-Type

7.1.22 Reverse TB2 Mi c G ain

7.1.23 Reverse TB MD Mi c Gain

7-4 OSC, PNG & Communications Module 7913

:14143 2VF#RU#31*#WR#6WHUHR

Press this button to route the se lected output of the internal Oscillator or PNG to the Stereo-section of the console.

:14144 31*#21

When pressed, this button selects Pink Noise generator ON provided the Oscillator/ PNG ON-button has been pres sed.

:14145 6LQH#ZDYH#IUHTXHQF\#VHOHFW

When pressed, these four buttons selects pre-set sine wave frequency as indicated on the panel.

:14146 2VF231*#21

Press this button to switch the OSC/PNG ON.

:14147 3URGXFHU#7%#3KDQWRP#SRZHU#21

Press this butt on to switch the Phantom power for the Producer talkback microphone ON.

:14148 5HYHUVH#7%5#3KDQWRP#SRZHU#21

Press this button to switch the Phantom power for the TB2 input ON.

:14149 5HYHUVH#7%5#21

Press this button to switch the Reverse TB2 input ON. This input is a microphone le vel input and the microphone used should be equipped with a switch to short together two control wires in order to ‘open’ the microphone signal path in the desk.

See chapter 8 for co nnection details for the TB2 connector.

:1414: 0'#5H YHUVH#7%#3KDQWRP#SRZHU#21

Press this button to switch the Phantom power for the Music Directors talkback ON.

:1414; 0'#5H YHUVH#7%#21

Press this button to switch the input for the Music Directors talkback ON. This feature can be controlled via an external control box (option). It is enabled from this module.

:1414< /('#PHWHU

20-segment LED-meter indicating the output level from the OCS/PNG.

C-Type Revision C2005-2

OSC, PNG & Communications Module 7913 7-5

:14153 26&231*#2XWSXW

This rotary control is used to set the output level from the OSC/PNG.

:14154 3URGXFHU#0LFURSKRQH#*DLQ

The producer’s talkback operates via an external control box (option), this rotary control is used to set the gain.

:14155 5HYHUVH#7%5#0LFURSKRQH#*DLQ

This rotary control is used to set the gain for the Talkback 2 Microphone.

:14156 5HYHUVH#7%#0'#0LFURSKRQH#*DLQ

This rotary control is used to set the gain for the Music Director’s talkback microphone.

Revision C2005-2 C-Type

7-6 OSC, PNG & Communications Module 7913

:14157 /('0PHWHU

20-segment LED-meter indicating the Engineer’s Talkback output level.

:14158 (QJLQHHU·V#7DONEDFN#6HOHFW

The Engineer can talk to any or all of the various outputs of the console. Select the requ ired output with these push-buttons.

:14159 (QJLQHHU·V#0LF#*DLQ

This rotary control sets the gain for the microphone plugged into the XLR at the top of the module.

7.1.25 Engineer’s talkback select

7.1.24 LED-meter

7.1.26 Engineer’s Mic G ain

7.1.27 Cue lights

7.1.28 Slate

7.1.29 Engineer’s TB button

C-Type Revision C2005-2

OSC, PNG & Communications Module 7913 7-7

:1415: &XH#OLJKWV

Illuminated control buttons f or two Cue Lamp systems. When the RE D cue light is selected the STUDIO PLAYBAC K and the console OSC/PNG fun c tions are disabled.

:1415; 6ODWH

Pressi ng th is il lu mina te d co nt ro l b u tto n en ables the Engi ne er to make verbal cu es on the recording using the Talkback microphone.

:1415< (QJLQHHU·V#7%0EXWWRQ

This button switches the Engineer’s talkback function ON. In normal use, this button has a momentary action but, for ‘hands-free’ use it may be latched by pressing rapidly.

Revision C2005-2 C-Type

7-8 OSC, PNG & Communications Module 7913

:15 26&/#31*#)#&RPPV#0RGXOH#0#UHDU#S DQHO

The wir ing convention for the cue lights

output is :

PIN1 = GROUND

PIN2 = LINK OR SWITCH

CONTACTS

PIN3 = LINK OR SWITCH

CONTACTS

PIN4 = GREEN LAMP

PIN5 = RED LAMP

The wiring convention for the RTB I/P is:

PIN1 = SCREEN PIN2 = + PHASE PIN3 = – PHASE

PIN4 = LINK OR SWITCH

CONTACTS

PIN5= LINK OR SWITCH CONTACTS

Switched output for the CUE LIGHTS provide +12VDC at a maxi mum current of 100mA (internally fused). This o utput is intended for use with standard t riac controlled mains cue light.

The producers talkbac k control box (option) is conn ec te d vi a t hi s 25 - way Dtype connector (for connection details, see chapter 8).

The Music Directo r’ s ta lkba ck con trol bo x (option) is conn ec te d vi a t hi s 25 - way Dtype connector (for connection details, see chapter 8).

Microphone leve l input for Reverse Talkback 2. With switch contact for control lines.

Outputs for OSC, T/B O/ P2 and

T/B O/P1 are electronically bal-

anced and connected via 3-pin

XLRs and follow the wiring

convention:

PIN 1 = Screen

PIN 2 = In-phase signal (h ot)

PIN 3 = Out -of-phase signal

(col d)

Output from the internal sine wave oscillator/Pink Noise Generator.

TB O/P1 & O/P2 are balanced line level outputs from the desk talkback system.

IMPORTANT NOTE: Pin 1 on XLR connectors and the ‘sleeve’ connections on the jack sockets are connected to the FRAME. This is to ensure that the console can comply with the Electric Compatibility (EMC) directive.

C-Type Revision C2005-2

External connections 8-1

; ([WHUQDO#FRQQHFWLRQV

This section contains connection details for the ‘D’-type c onnectors used in the Group, Stereo and Communications modules.

;14 *URXS#WR#H[WHUQDO#PHWHU

7DEO H #4=# 480ZD\#µ'¶0W\SH#IHPDOH#FRQQHFWRU#RQ#UHDU#RI#³GXDO#JURXS´#PRGXOH1

PIN 1 ODD GROUP TAPE RETURN (–) PIN 9 ODD GROUP RETURN (+) PIN 2 EVEN GROUP TAPE RETURN (+) PIN 10 EVEN GROUP TAPE RETURN (–) PIN 3 ODD GROUP O/P TO RECORDER (+) PIN 11 ODD GROUP O/P TO RECORDER (–) PIN 4 EVEN GROUP O/P TO RECORDER (+) PIN 12 EVEN GROUP O/P TO RECORDER (–) PIN 5 0V PIN 13 0V

;15 6WHUHR#WR#H[WHUQDO#PHWHU

7DEOH#5=#480ZD\#µ'¶0W\SH#IHPDOH#FRQQHFWRU#RQ#UHDU#RI#³VWHUHR#JURXS´#

PRGXOH

PIN 1 TAPE RETURN A, LEFT (+) PIN 9 TAPE RETURN A, LEFT (–) PIN 2 TAPE RETURN A, RIGHT (+) PIN 10 TAPE RETURN A, RIGHT (–) PIN 3 TAPE RETURN B, LEFT (+) PIN 11 TAPE RETURN B, LEFT (–) PIN 4 TAPE RETURN B, RIGHT (+) PIN 12 TAPE RETURN B, RIGHT (–) PIN 5 O/P TO RECORDER, LEFT (+) PIN 13 O/P TO RECORDER, LEFT (–) PIN 6 O/P TO RECORDER, RIGHT (+) PIN 14 O/P TO RECORDER (–) PIN 7 0V PIN 15 0V PIN 8 0V

Revision C2005-2 C-Type

8-2 External connections

;16 0XVLFDO#'LUHFWRU·V#2XWSXW

7DEO H#6=#58#ZD\#µ'¶0W\SH#IHPDOH#FRQQHFWRU#RQ#UHDU#RI#³FRPPXQLFDWLRQV´#

PRGXOH

PIN 1 MD TO TALKBACK 1 SELECT * PIN 14 MD TO TALKBACK 2 SELECT * PIN 2 MD TO AUX 1 SELECT * PIN 15 MD TO AUX 2 SELECT * PIN 3 MD TO AUX 3 SELECT * PIN 16 MD TO AUX 4 SELECT * PIN 4 MD TO FOLDBACK SELECT * PIN 17 MD TO PLAYBACK SELECT * PIN 5 N/C PIN 18 RTB 1 CONTROL LIN E * PIN 6 MD O/P (+) PIN 19 MD O/P (–) PIN 7 MD O/P (+) PIN 20 MD O/P (–) PIN 8 GND PIN 21 GND PIN 9 0V PIN 22 0V PIN 10 MD MICROPHONE (+) PIN 23 MD MICROPHONE (–)

* Line requires connection to GND to select function

C-Type Revision C2005-2

External connections 8-3

;17 3URGXFHU·V #2XWSXW

7DEOH#7=#580ZD\#µ'¶0W\SH#IHPDOH#FRQQHFWRU#RQ#UHDU#RI#³FRPPXQLFDWLRQV´#

PRGXOH

PIN 1 PRODUCER TO TALKBACK 1 SELECT * PIN 14 PRODUCER TO TALKBACK 2 SELECT * PIN 2 PRODUCER TO AUX 1 SELECT * PIN 15 PRODUCER TO AUX 2 SELECT * PIN 3 PRODUCER TO AUX 3 SELECT * PIN 16 PRODUCER TO AUX 4 SELECT * PIN 4 PRODUCER TO FOLDBACK SELECT * PIN 17 PRODUCER TO PLAYBACK SELECT * PIN 5 PRODUCER TO MUSICAL DIRECTOR SELECT * PIN 18 PRODUCER’S CONTROL LINE * PIN 6 PRODUCER’S O/P, LEFT (+) PIN 19 PRODUCER’S O/P, LEFT (–) PIN 7 PRODUCER’S O/P, RIGHT (+) PIN 20 PRODUCER’S O/P, RIGHT (–) PIN 8 GND PIN 21 GND PIN 9 0V PIN 22 0V PIN 10 PRODUCER’S MICROPHONE (+) PIN 23 PRODUCER’S MICROPHONE (–)

* Line requires connection to GND to select function

Revision C2005-2 C-Type

8-4 External connections

C-Type Revision C2005-2

$SSHQGLFHV

$1##,PSRUWDQW#LQIRUPDWLRQ#UH JDUGLQJ#(0&#

On the 1st January 1996, new European legislation known as the EMC Directive came into force. The EMC D irective requires that all electronic e quipment manufactured or i mpo rted f o r sal e in th e EEC m ust no t e mit el ec tro ma gne t ic inte rf e r en ce tha t can impair the performance of other systems or sub-systems. Similarly, the product must also be immune to a wide range of natural and man-made electromagnetic inte rference in its operating environment. Many countries outside the EEC are also developing or have already put into place similar legislation. In order to conform to these rules, a number of changes were required to the basic design of our consoles and modules. One of the main changes is:

All cable ‘screen’ connections are bonded to the frame.

The figure below shows the required connection sc heme for XLR connectors.

Please note that in the case of ‘line’ or ‘free’ connectors (XLRs on cables), the 'pigtail ' formed from the cable screening braid should be as short as practical and soldered to the halfway between the The twisted pair should be left 'twisted' right up to the signal solder tags.

shell ground tag

. Pin 1 is then connected to the 'pigtail' approximately

shell g rou nd t ag

and th e s tart po i nt of t he ca bl e s cr ee ni ng br ai d.

APP-I

FIG 1-1. XLR connections.

M ETAL PAN EL

SHELL GROUND TAG

TW I STED PA IR WITH BRAIDED

SCREEN

STRAIN RELIEF

M ETAL SHELL

WITH CONDUCTIVE FINISH

PIGTAIL

XLR

TW I STED PAIR

LONG SO LDER TAG

SPIKY W ASHER

SHORT WIRE

TW I STED PAIR TO FILTER ON PCB

XLR CHASSIS CO N NEC TOR WITH CONDUCTIVE SURFACE AN D MULTI-PO INT BOND TO SHELL OF CABLE CONNECTOR

The cha s sis half of th e connector is bonded to the metalwork with the usual nuts, bolts and spiky washers. The solder tag should be as l ong as possible so that the length of the 'short wire' is a minimum. The twisted pair (from the signal pins - pin 2 & pin 3) are soldered onto the motherbo ard adjacent to the 'input RFI filt er' components.

Revision C2005-2 C-Type

APP-II

C-Type Revision C2005-2

,QGH [

a/c-input connectors 1-2 AC power requirements 1-3 Audio Bus / Data Bus Connections 1-4 Audio Bus Connections 1- 4 Aux Groups Output Modu le 8065 5- 1 Aux Groups Output module 8065 - rear panel 5-5

bus cables 1-4

Connect Power supply systems 1-2 Connecting the console frames 1-4 Connecting the mixer systems 1-1 Console modularity 1- 1

INDEX-I

Dual Mono Group & Playba ck 8063 - rear panel 3-6 Dual Mono Group & Playba ck Module 8063 3-1

(

Earth, 0V, GND and Fram e Connection s 1-4 elect romagnetic compatibility 1-2 EMC APP-I EXTERNAL CONNECTIONS 8-1 External connections 8-1

)

Frame rear connections 1-1

Group to external meter 8-1

Input Channel 7911 - rear panel 2-9 Input channel 7911 2-1

Main and extension frame power connect ions 1-3 Monit oring Module 7912 6-1 Monitoring module 7 912 - rear panel 6-7 Musica l Director’s Output 8-2

OSC, PNG & Comms Module - rear panel 7-8 OSC, PNG & Communiucations Module 7913 7-1

Revision C2005-2 C-Type

INDEX-II

PFL 1-4 Power supply system description 1-2 Producer’s Output 8-3

Remote start of 8400 PSU 1- 4

shorting-bar 1-4 Stereo Group & Playba ck 8064 - rear panel 4-6 Stereo group & Playback Module 8064 4-1 Stereo to external meter 8-1 Switching ON 1-7 System power-down procedure 1-7 System power-up procedure 1-7

;

XLR connections APP-I

C-Type Revision C2005-2

Cadac C-Type User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of conte nts iii

General Precautions v

Connecting the mixer systems 1-1

Input channel mo dule 7911 2-1

2.1.1 Input Gain

2.1.2 Input Trim

2.1.3 Input 2

2.1.5 Line-up tone

2.1.4 Phantom power

2.1.11 HF Q control

2.1.12 HF Frequency, Boost/Cut control

2.1.33 Panning Front-Back

2.1.34 Panning Left-Right

Dual Mono Group & Playback Module 8063 3-1

3-2 Dual Mono Group & Playba ck Module 8063

3.1.1 LED-meters

3.1. 4 Panning F-B

3.1.5 Panning R- L

3.1.6 5.1 Enable

3.1.7 4.0 Enable

Stereo group & Playback Module 8064 4-1

4-2 Stereo group & Playback Module 8064

4.1.2 Console Out

4.1.1 LED-meters

4.1.5 M-S Safety

4.1.6 Check Mute

4.1.16 Fader

Aux Groups Output Module 8065 5-1

5.1.7 PFL

5.1.8 MUTE

5.1.10 SOLO ON

5.1.11 MUTE

5.1.13 Foldback output level control

Monitoring Module 7912 6-1

6.1.1 SOLO level

6.1.2 Blend into SOLO

6.1.16 LP-filter ON

6.1.18 Centre channel trim-pot

6.1.23 Monitor Dim lev el - Rever s e T alkback

6.1.24 Monitor Dim level - DIM button

OSC, PNG & Communications Module 7913 7-1

7.1.1 48V monitor

7.1.2 +18V monitor

7.1.3 -18V monitor

7.1.4 13V monitor

7.1.5 Input TB micropho ne The wiring convention is:

7.1.6 Phantom power ON

7.1.7 PNG to Monitors

7.1.8 Osc or PNG to Channels

7.1.9 Osc or PNG to Groups

7.1.25 Engineer’s talkback select

7.1.24 LED-meter

7.1.26 Engineer’s Mic G ain

External connections 8-1
