Service Manual
Label Printer
EOS
Service Manual
2 2
for the following products
Description Type
Label Printer EOS1 / 200
EOS1 / 300
EOS1 / 200 C
EOS1 / 300 C
EOS4 / 200
EOS4 / 300
EOS4 / 200 C
EOS4 / 300 C
EOS4 / 200 P
EOS4 / 300 P
Edition: 11/2013 - Part. No. 9009226
Copyright
This documentation as well as translation hereof are property
of cab Produkttechnik GmbH & Co. KG.
The replication, conversion, duplication or divulgement of the
whole manual or parts of it for other intentions than its original
intended purpose - in particular the procurement of spare
parts for products sold by cab – demand the previous written
authorisation by cab.
Editor
Regarding questions or comments please contact cab Produkttechnik GmbH & Co. KG.
Topicality
Due to the constant further development of our products
discrepancies between documentation and product can occur.
Please check www.cab.de for the latest update.
Terms and conditions
Deliveries and performances are effected under the “General
conditions of sale of cab”
Germany
cab Produkttechnik
GmbH & Co KG
Postfach 1904
D-76007 Karlsruhe
Wilhelm-Schickard-Str. 14
D-76131 Karlsruhe
Telefon +49 721 6626-0
Telefax +49 721 6626-249
www.cab.de
info@cab.de
Representatives in other countries on request
France
cab technologies s.a.r.l.
F-67350 Niedermodern
Téléphone +33 388 722 501
www.cab.de/fr
info.fr@cab.de
USA
cab Technology Inc.
Tyngsboro MA, 01879
Phone +1 978 649 0293
www.cab.de/us
info.us@cab.de
South Africa
cab Technology (Pty.) Ltd.
2125 Randburg
Phone +27 11-886-3580
www.cab.de/za
info.za@cab.de
Asia
cab Technology Co., Ltd.
Junghe, Taipei, Taiwan
Phone +886 2 8227 3966
www.cab.de/tw
info.asia@cab.de
China
cab (Shanghai)Trading Co., Ltd.
Phone +86 21 6236-3161
www.cab.de/cn
info.cn@cab.de
Spare Parts - EOS1 Print Mechanics
3
No. Part No. Description PU Notes Serial No.
from to
1.1 5965403.001 Cover Plate 1
2 5902414.001 Screw EJOT-PT-K30x12 10
3.1 5965484.001 Cover 1
4 5550176.001 CPU X3 1
5.1 5551126.001 Power Supply 1 M
5.2 5966366.001 DC/DC Converter 1 B
6.1 5965498.001 Gear Motor 1
7 5965471.001 Cable Control Panel 1
8.1 5965474.001 Cable Sensors 1
9.1 5965473.001 Cable Printhead 1
10 5965530.001 Cable Power Supply 1
11 5965465.001 Stepper Motor 1
12.1 5965534.001 Cable Ground Connection 1 8963
12.3 5965384.001 Cable Ground Connection 1 8964
13.1 5965566.001 Shielding Plate 1 8963
14 5965359.001 Sensor 1
15 5966209.001 Spring 1
16.1 5965510.001 Control Panel 1
17 5965378.001 Cable Cutter Connection 1
18.1 5965435.001 Chassis 1
19.1 5965445.001 Tear-off Plate 1
20.1 5966207.001 Baseplate 1
No. Part No. Description PU Notes Serial No.
21 5540617.001 Foot 5
22 5965477.001 Belt Roller 1
23 5903004.001 Washer DIN125-A3.2 10
24 5966203.001 Ribbon Take-up Hub 1
25 5966205.001 Ribbon Supply Hub 1
26 5966214.001 Bushing 1
27 5965427.001 Spring 1
28.1 5965455.001 Media Hub 1
29.1 5965460.001 Margin Stop 1
30 5966354.001 Printhead Holder 1
31 5966323.001 Antistatic Brush 1
32 5906104.001 Spring 10
33.1 5966096.001 Printhead 200 1 200
33.2 5965580.001 Printhead 300 1 300
34 5902867.001 Screw DIN7984-M3x8 10
35 5965536.001 Gear Wheel Z31/19 1
36 5965415.001 Transport Module 1
37.1 5965488.001 Print Roller DR4 1
37.2 5966219.001 Print Roller DR4-50 1 O
37.3 5966218.001 Print Roller DR4-25 1 O
- 9109286.001 Packaging 1
Notes 200 EOS1 / 200, EOS1 / 200 C
300 EOS1 / 300, EOS1 / 300 C
M for mains operation 100-240 VAC
B for battery operation 24 VDC
O Option
from to
i
Spare Parts - Cutter EOS1 C
4 4
No. Part No. Description PU Notes Serial No.
Cutter
from to
38.1 5965987.001 Cover 1 917
38.2 5966331.001 Cover 1 918
39.1 5965529.001 Cutter Module 1 917
39.2 5966350.001 Cutter Module 1 918
40 5540637.001 Spring 1
41 5965501.001 Gear Wheel Z12 1
42 5541379.001 Gear Motor 1
No. Part No. Description PU Notes Serial No.
Cutter
from to
43 5965502.001 Shaft 1
44 5965524.001 Blade 1
45 5965528.001 Blade 1
46 5906221.001 Spring 1
47.1 5965507.001 Chassis 1 917
47.2 5966912.001 Chassis 1 918
Note!
To upgrade the EOS1 up to SN 14372 with the Cutter EOS1 C to an EOS1 / 200 C or EOS1 / 300 C the Cable
Cutter Connection (Art. No.: 5965378.001) must also be ordered .
Spare Parts - External Unwinder EOS1/205
No. Part No. Description PU Notes Serial No.
from to
2 5902414.001 Screw EJOT-PT-K30x12 10
48 5965349.001 Holder 1
No. Part No. Description PU Notes Serial No.
from to
49 5965504.001 Media Hub 1
50 5959588.001 Margin Stop 1
Spare Parts - EOS4 Print Mechanics
5
No. Part No. Description PU Notes Serial No.
from to
1.2 5965872.001 Cover Plate 1
2 5902414.001 Screw EJOT-PT-K30x12 10
3.2 5965877.001 Cover 1
4 5550176.001 CPU X3 1
5.1 5551126.001 Power Supply 1 M
5.2 5966366.001 DC/DC Converter 1 B
6.2 5965887.001 Gear Motor 1
7 5965471.001 Cable Control Panel 1
8.2 5965388.001 Cable Sensors 1
9.2 5965387.001 Cable Printhead 1
10 5965530.001 Cable Power Supply 1
11 5965465.001 Stepper Motor 1
12.2 5965392.001 Cable Ground Connection 1 8963
12.3 5965384.001 Cable Ground Connection 1 8964
13.2 5965857.001 Shielding Plate 1 8963
14 5965359.001 Sensor 1
15 5966209.001 Spring 1
16.2 5965880.001 Control Panel 1
17 5965378.001 Cable Cutter Connection 1
18.2 5965878.001 Chassis 1
19.2 5965879.001 Tear-off Plate 1
20.2 5965882.001 Baseplate 1
No. Part No. Description PU Notes Serial No.
21 5540617.001 Foot 5
22 5965477.001 Belt Roller 1
23 5903004.001 Washer DIN125-A3.2 10
24 5966203.001 Ribbon Take-up Hub 1
25 5966205.001 Ribbon Supply Hub 1
26 5966214.001 Bushing 1
27 5965427.001 Spring 1
28.2 5965886.001 Media Hub 1
29.2 5965885.001 Margin Stop 1
30 5966354.001 Printhead Holder 1
31 5966323.001 Antistatic Brush 1
32 5906104.001 Spring 10
33.1 5966096.001 Printhead 200 1 200
33.2 5965580.001 Printhead 300 1 300
34 5902867.001 Screw DIN7984-M3x8 10
35 5965536.001 Gear Wheel Z31/19 1
36 5965415.001 Transport Module 1
37.1 5965488.001 Print Roller DR4 1
37.2 5966219.001 Print Roller DR4-50 1 O
37.3 5966218.001 Print Roller DR4-25 1 O
- 9109287.001 Packaging 1
Notes 200 EOS4 / 200, EOS4 / 200 C, EOS4 / 200 P
300 EOS4 / 300, EOS4 / 300 C, EOS4 / 300 P
M for mains operation 100-240 VAC
B for battery operation 24 VDC
O Option
from to
