35 Industrial Way
Rochester, NH 03866
USA
(603) 332-9400
Part Number 04-0054-01 Rev. A
Order Number 9033003
Page 2
NOTICE
Cabletron Systems reserves the right to make changes in specifications and other information contained in this
document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any
such changes have been made. The hardware, firmware, and software described in this manual are subject to change
without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENT AL, INDIRECT, SPECIAL,
OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, BUT NOT LIMITED TO, LOST PROFITS)
ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF
CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE
POSSIBILITY OF SUCH DAMAGES.
Copyright 1997 - 99 by Cabletron Systems, Inc., P.O. Box 5005, Rochester, NH 03866-5005
All Rights Reserved
Printed in the United States of America
SmartSwitch ATM Switch Reference Manual
Part Number 04-0054-01 Rev. A
Order Number: 9033003
SmartSwitch, SPECTRUM, LANVIEW, MicroMMAC, and BRIM are registered trademarks and Element Manager,
EPIM, EPIMA, EPIM-F1, EPIM-F2, EPIM-F3, EPIM-T, EPIM-X, FOT-F, FOT-F3, HubSTACK, SEH, SEHI, and
TMS-3 are tradem arks of Cabletr on Systems, Inc . All other product names mentioned in this manual may be
trademarks or registered trademarks of their respective companies.
ii SmartSwitch ATM Switch Reference Manual
Page 3
FCC CLASS A NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NoteThis equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment uses, generates, and can
radiate radio frequency energy and if not installed in accordance with the
applicable SmartSwitch installation manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause interference in which case the user will be required to correct the
interference at his own expense.
Caution.Changes or modifications made to this device which are not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
DOC CLASS A NOTICE
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the
Radio Interference Regulations of the Canadian Department of Communications.
Le present appareil numerique n’emet pas de bruits radioelectriques depassant les limites applicables aux appareils
numeriques de la class A prescrites dans le Reglement sur le brou illage radioelectrique edicte par le ministere des
Communications du Canada.
SmartSwitch ATM Switch Reference Manual iii
Page 4
DECLARATION OF CONFORMITY
ADDENDUM
Application of Council Directive(s):
89/336/EEC
73/23/EEC
Manufacturer’s Name:
Manufacturer’s Address:
Product Name:
European Representative Name:
European Representative Address:
Conformance to Directive(s)/Product Standards:
Equipment Type/Environment:
Cabletron Systems, Inc.
35 Industrial Way
P. O. Box 5005
Rochester, NH 03866
SmartSwitch 2500 family and SmartSwitch 6500
Mr. J. Solari
Cabletron Systems, Limited
Nexus House, Newbury Business Park
London Road, Newbury
Berkshire RG13 2PZ, England
EC Directive 89/336/EEC
EC Directive 73/23/EEC
EN 55022
EN 50082-1
EN 60950
Networking Equipment, for use in a Commerci al or Light
Industrial Environment.
We the undersigned, hereby declare, under our sole respo nsi bility, that the equipment packa ged with this
notice conforms to the above directives.
Manufacturer:
Legal Repersentative in Europe:
iv SmartSwitch ATM Switch Reference Manual
Full Name:
Title:
Location:
Full Name:
Title:
Location:
Mr. Ronald Fotino
Principal Compliance Engineer
Rochester, NH. U.S.A.
Mr. J. Solari
Managing Director - E.M.E.A.
Newbury, Berkshire, England
Page 5
SAFETY INFORMATION
CLASS 1 LASER TRANSCEIVERS
The IOM-29-4, IOM-29-4-IR, IOM-29-4-LR, IOM-39 -1 and IOM-39-1-LR connectors use Class 1 Laser transceivers.
Read the following safety information before installing or operatin g one of these modules.
The Class 1 Laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop
eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow any user
adjustment. Class 1 Laser transceivers comply with the following safety standards:
•
21 CFR 1040.10 and 1040.11 U. S. Department of Health and Human Services (FDA).
•
IEC Publication 825 (International Electrotechnical Commission).
•
CENELEC EN 60825 (European Committee for Electrotechnical Standardization).
When operating within their performance limitations, laser transceiver output meets the Class 1 accessible emission
limit of all three standards. Class 1 levels of laser radiation are not considered hazardous.
LASER RADIATION AND CONNECTORS
When the connector is in place, all laser radiation remains within the fiber. The maximum amount of radiant power
exiting the fiber (under normal conditions) is -12.6dBm or 55x10
Removing the optical connector from the transceiver a llows laser r adiation to emit d irectly f rom the o ptical po rt. Th e
maximum radiance from the optical port (under worst case conditions) is 0.8 W cm
Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases
eye hazard. When viewing the output optical port, you must remove power from the network adapter.
-6
watts.
-2
or 8x103 W m-2 sr-1.
SmartSwitch ATM Switch Reference Manual v
Page 6
FIBER OPTIC PROTECTIVE CAPS
Warning.READ BEFORE REMOVING FIBER OPTIC PROTECTIVE CAPS.
Cable assemblies and MMF/SMF ports are shipped with protective caps to prevent contamination. To avoid
contamination, replace port caps on all fiber optic devices when not in use.
Cable assemblies and MMF/SMF ports that become contaminated may experience signal loss or difficulty inserting
and removing cable assemblies from MMF/SMF ports.
Contamination can be removed from cable assemblies by:
1.Blowing surfaces with canned duster (Chemtronics p/n ES1270 or equivalent).
2.Using a fiber port cleaning swab (Alcoa Fujikura LTS p/n ACT-01 or equivalent) saturated with
optical-grade isopropyl alcohol, gently wipe the end surface of ferrules first; then wipe down the
sides of both ferrules.
3.Blow ferrule surfaces dry with canned duster.
Contamination can be removed from MMF/SMF ports by:
1.Using the extension tube supplied with canned duster, blow into the optical port, being careful not
to allow the extension tube to touch the bottom of the optical port.
2.Reconnect cable and check for proper mating. If pr oblems remain, gently wipe out optical port with
a DRY fiber port cleaning swab and repeat step 1.
WarningT o avoid contamination, replace port caps on all fiber optic devices when not
in use.
vi SmartSwitch ATM Switch Reference Manual
Page 7
REGULATORY COMPLIANCE SUMMARY
SAFETY
The SmartSwitch 2500 family and SmartS witch 6500 meets the safet y requirements of UL 1950 , CSA C22.2 No. 950,
EN 60950, IEC 950, and 73/23/EEC.
EMC
The SmartSwitch 2500 fami ly and S martSwi tch 65 00 meets the EMC requ irements of FC C Part 15, EN 55 022, CS A
C108.8, VCCI V-3/93.01, EN 50082-1, and 89/336/EEC.
SmartSwitch ATM Switch Reference Manual vii
Page 8
REVISION HISTORY
Document Name:SmartSwitch ATM Switch Reference Manual
Document Part Number:04-0054-01 Rev. A
Document Order Number:9033003
Author: Robert de Peyster
Editor: Ayesha Maqsood
Illustrator: Mike Fornalski
This reference manual describes the console commands for the SmartSwitch 250 0 f amily and the Smar tSwitch 6 500 .
Unless otherwise noted, the information in this manual applies to both the SmartSwitch 2500 family and SmartSwitch
6500.
Audience and Scope
The manual is intended for network administrators and others responsible for maintaining the SmartSwitch 2500
family and the SmartSwitch 6500.
Definitions
The manual is organized alphabetically by switch attribute.
•
The definition of a switch attribute is a function that manipulates the switch in a specific way. For
example:
•
The definition of an operator is the active verb that makes the switch attribute perform a specific
task. For example:
•
The definition of a command is the combination of an operator plus a switch attribute. For example:
show buselan
buselan
show
NoteAsmall group of attributes does not require operators and can function as
standalone commands. Those attributes are:
shutdown.
exit, history, passwd, reboot and
Content
•
Chapter 2, "Console Commands," gives definitions, descriptions, and examples of all available
commands for the SmartSwitch 2500 family and SmartSwitch 6500.
•
Chapter 3, “Boot Load Commands” gives definitions, descriptions, and examples of the low-level
boot load commands.
•
Appendix A, “Acronyms,” spells out the ATM acronyms used in this manual as well as th ose found
in SmartSwitch user guides.
•
Appendix B, “Event/Alarm Messages,” describes the format of event and alarm messages that are
recorded to circular buffers and can be displayed on the console.
•
Appendix C, “Technical Support,” gives instructions for contacting Cabletron by telephone, fax,
electronic mail, and the World Wide Web.
SmartSwitch ATM Switch Reference Manual 1-1
Page 16
Additional Information Introduction
Additional Information
You will find a list of acronym s, details about technical support, and an index at the back of this manual. The index
contains page references for all switch attribute sections, command param eters, operators, co mmand descript ions and
command examples. There is also a table of commands at the end of this chapter. It lists all switch attributes by their
operators.
For details on how to use the SmartSwitch 2500 family or SmartSwitch 6500, see the SmartSwitch user guide that
applies. Each SmartSwitch user guide contains task-oriented information on switch configuration, maintenance, and
SNMP (simple network management protocol). Each also contains an overview of switch capabilities.
Conventions
This manual uses the following conventions for instructions and information:
•
Information you ente r (con sole commands and inpu t param eters) is shown in bold Courier 8 font
and requires a space between the operator and switch attribute.
•
Input and output parameters are shown in [Square Brackets].
•
Input definitions are shown in <anglebrackets>, as joined text and not case sensitive.
•
Filter flags </s> (summary) or </d> (detail) are available with certain show commands and apply
to different information viewing levels. Filter flags require a space between them and the full
command. The
details. For example:
/s option is the same as the standard default option; the /d option provides additiional
switch_prompt # show client /s
ClientNumber(ALL) :
Client Type IP Address Server Type Server Conn Status
==============================================================================
1 LANE 90.1.1.186 LECS Established Operational
3 IP/ATM 90.1.1.124 Local Established Operational
switch_prompt #
switch_prompt # show client /d
ClientNumber(ALL) :
LANE Client 1
==============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:00
LAN Name : elan1
LECS Addr Source : ILMI
LECS Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:01
LES Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:02
LAN Type : 802.3
MTU : 1516
IP Address : 90.1.1.186
IP NetMask : 255.255.255.0
IP/ATM Client 3
==============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:00:5A:01:01:7C:00
Server : is local
Server Connection : Established
MTU : 9180
IP Address : 90.1.1.124
1-2 SmartSwitch ATM Switch Reference Manual
Page 17
IntroductionAbbreviations
Abbreviations
Pay attention to how switch attributes appear in section headings of Chapter 2. Switch attributes are not case sensitive,
but you must spell them correctly. For example, if the heading states BUSStat, you must enter
busstats.
switch_prompt # show busstats
Command busstats not Valid for Action show
Type Help <command> for help
switch_prompt #
switch_prompt # show busstat
ELANNumber(ALL) :
BUS ELANs
============================================================================
ELAN ELAN000 Statistics
Out Octets : 0
Out Unicast : 0
switch_prompt #
You can, however, abbreviate the switch attribute to the extent it is unique. For example, instead of entering show
porttrafficcongestion
of entering
modify, you can enter mod. You should enter at least three characters for any operator. For example:
, you can just enter show portt. You can do the same with operators. For example, instead
switch_prompt # mod portm
PortNumber(ALL) :
PortMode(SONET) :
switch_prompt #
If you enter part of a command, and that part is not unique, the console displays a numbered list of possible matching
commands. For example, entering
show pnnin is ambiguous because there are several commands that start with
“pnnin.” In response, the console displays a list of possible commands:
switch_prompt # show pnnin
Objects beginning with pnnin for action show
0 : PnniNeighbor
1 : PnniNetworkLink
2 : PnniNetworkNode
3 : PnniNode
4 : PnniNodeTimer
(#)Command (Q)uit? :
SmartSwitch ATM Switch Reference Manual 1-3
Page 18
Help Options Introduction
Help Options
The console provides several levels of help for console commands. For example, to list the switch attributes that can
be used with a particular operator, enter the word
To get an explanation of a command and its parameters, enter the word help (or ?) before the command.
switch_prompt # ? add laneclient
Create LANE Client
==============================================================================
ClientNumber Local Client Number (0-127)
LanName Name of the ELAN to join
ServerType Type of LANE Server [LECS, LES]
ServerAddress ATM Address of the LANE Server
IPAddress IP Address of the Client
NetMask IP Netmask of the Client
MTU MTU for the Client [1516, 9234, NONE]
help (or ?) followed by the operator.
While entering a command, you can get help about an input parameter. To do so, enter a question mark (?) at the
parameter prompt.
switch_prompt # add atmroute
PortNumber(A1) : 1a3
AtmAddress() : 39:00:00:00:00:00:00:00:00:00:14:72:80
PrefixLength(104) :
Index(0) :
Type(Internal) : ?
The type of reachability. Use Internal, Exterior, or Reject.
Type(Internal) : exterior
Scope(0) :
MetricsTag(0) :
Switch 4 #
NotePress the Esc key to back out of any command before you enter the last value.
1-4 SmartSwitch ATM Switch Reference Manual
Page 19
IntroductionSwitch Attribute Entries
Switch Attribute Entries
Each switch attribute has an entry in Chapter 2. The entry starts with the attribute name and a brief explanation of the
attribute’s purpose.
NoteA few switch attributes apply to the SmartSwitch 6500 only. Those attributes are
indicated in Chapter 2 by the following notation after attribute name:
(SmartSwitch 6500 Only)
both to the SmartSwitch 2500 family and to the SmartSwitch 6500.
After the attribute name and explanation, each attribute entry in Chapter 2 has the following sections: Operators,
Parameters, Descriptions, and Examples.
Operators
If an attribute requires operators, they are listed under an “Operators” heading. Following is a list of all possible switch
operators. If an operator has an alias, it is shown in parenthesis.
. If that notation does not appear, the attribute applies
Table 1-1List of Operators
OperatorAction
add (create)Adds new object
activateActivates an existing but deactivated object
backupBacks up switch configuration
clearClears (initializes to 0) properties of an object
disableLowers privilege level
deactivateDeactivates an existing object
delete (remove)Deletes existing object
enableRaises privilege level
flushFlushes all entries
modify (set)Sets properties of an existing object
restartRestarts LANE clients
restoreRestores switch configuration
setupSets up switch
show (display)Shows properties of an object
startStarts an object
SmartSwitch ATM Switch Reference Manual 1-5
Page 20
Switch Attribute Entries Introduction
Table 1-1List of Operators (Continued)
OperatorAction
stopStops an object
updateUpgrades firmware
Parameters
Most switch attributes have input or output parameters (or both). If an attribute has parameters, they are listed in tables
under a “Parameters” heading. You enter input parameters at the console command line. You view output parameters
at the console screen after the com mand execut es. Som e inpu t parameter s have d efault v alues (s hown in p arenthesi s).
You do not need to type an entry if you accept the default.
Following is an example of the format of input and output parameter tables.
Input ParameterDescriptionValue/Field SizeDefault
[ATMAddress]ATM address assigned to the port.13-20 byte hex-based format
No default
separated by colons.
[ClientNumber]Number of the client. Each client on
0 to 127, or AllAll
the switch must have a unique client
number. Client numbers are shared
between LAN emulation (LANE) and
IP/ATM (IP over ATM) clients.
[InterfaceType]Interface type advertised by the port.Private, PublicPrivate
[SigRole]Signaling role of the port. Other is used
Network, Other, UserOther
only for autoConfig and pnni10.
In the output parameter table below,
display for these parameters, type
/d after the attribute in the command string (for example: operator attribute /d).
indicates parameters available only in detailed displ a y m ode . To view the
</d>
Output ParameterDescription
[Port ID]Same as the [PortNumber] input parameter.
[Intf Type]Same as the [InterfaceType] input parameter.
[Sig Role]
[Client Address]
1-6 SmartSwitch ATM Switch Reference Manual
</d>
</d>
Signaling role of the port.
ATM address of the client.
Page 21
IntroductionSwitch Attribute Entries
Descriptions
A “Descriptions” section follows parameters. The descriptions section shows command syntax (operator , attribute, and
input parameters). It also gives additional information on what the command does and how to use it. Finally, the
descriptions section indicates the privilege level required to use the command (Read Only, Administrator, or All).
Administrator privilege level is necessary for actions oth er than viewing output displays. All means any user has
complete access to command features.
OperatorParameters/PermissionsDescription
show
clientvc
[ClientNumber] <clientnumber>
All
Displays client ARP mapping details. In addition, it displays
VC details for local IP/ATM or LANE clients. For IP/ATM,
the associated IP address appears; for LANE, the associated
MAC address appears. (The associated address is what is
located at the other end of the VC.)
Examples
Examples are copied exactly from the switch console. They show how you enter console commands at the switch
prompt (for example:
in brackets immediately following each parameter field indicates the current default (for example:
NoteWith the exception of port numbering (1a1, 2b2.3, and so forth), most of the
modify buselan). The other bold text ( 1, 103, pvc, 802.5, 4544) is input parameter values. T ext
ELANType(802.3)).
console displays are identical for both the SmartSwitch 2500 family and the
SmartSwitch 6500. If the displays are not identical, the differences are noted in the
examples.
switch_prompt # show buselan
ELANNumber : 103
ELAN : elan103
ELAN Number : 103
ELAN Name : elan103
ATM Address : 39:00:00:00:00:00:00:00:20:D4:14:15:00:00:20:D4:14:15:66:02
Max Frame Size : 4544
Connection Method : PVC
Distribute VPI/VCI: 0/50
LAN Type : 802.5
Multipoint : YES
SmartSwitch ATM Switch Reference Manual 1-7
Page 22
Port Numbering Introduction
Port Numbering
Port numbering for t he SmartSwitch 6500 is d ifferent f rom that fo r the SmartSwitc h 2500 famil y . For the SmartSwitch
6500, physical port numbering uses the following format:
slot numberI/O module letterport number
For example, port 3 of I/O module A on the TSM in slot 5 is represented by:
5a3
For the SmartSwitch 2500 family, physical port numbering does not use slot numbers. Physical port numbering for
the SmartSwitch 2500 family uses the following format:
I/O module letterport number
For example, port 3 of module A is represented by: a3
Both the SmartSwitch 2500 family and SmartSwitch 6500 support virtual ports. Virtual ports are designated by a
period followed by the vi rt ual po rt nu mber (wh i ch both are appended to the phy si cal port number). For example, f or
the SmartSwitch 6500, virtual port 2 on physical port
7b1 is represented as: 7b1.3
For the SmartSwitch 2500 family, virtual port 2 on physical port c3 is represented as: c3.2
List of Operators and Switch Attributes
Following is a list of switch attributes used with operators. If an operator has an alias, it is shown in parenthesis.
NoteA small group of attributes does not require operators and can function as
standalone commands. Those attributes are:
shutdown. In addition, several attributes apply to the SmartSwitch 6500 only. In
the following lists, attributes that apply to the SmartSwitch 6 500 only are
indicated by an asterisk (*).
List of Operators and Switch Attributes Introduction
ConfigLESErrorLogLECSLNNIStatLESStat
PortStatsPVCPVP*
disable/enable
Privilege
execute
CpuSwitchover*CsmSwitchover*
flush
AliasConfigPVCP V P*
restart
Client
setup
Switch
start
LECSLESPing
stop
LECSLES
1-12 SmartSwitch ATM Switch Reference Manual
Page 27
IntroductionList of Operators and Switch Attributes
update
Firmware
SmartSwitch ATM Switch Reference Manual 1-13
Page 28
List of Operators and Switch Attributes Introduction
1-14 SmartSwitch ATM Switch Reference Manual
Page 29
2CONSOLE COMMANDS
NoteA few switch attributes apply to the SmartSwitch 6500 only. For those attributes,
the following appears below the attribute name:
notation does not appear, the attribute applies to both the SmartSwitch 2500
family and to the SmartSwitch 6500.
622LoopBack
Use 622LoopBack to set or display loopback on 622 Mbps (OC-12/STM-4) ports. ÊÊ
NoteA port in loopback mode does not pass normal traffic.
(SmartSwitch 6500 O nly)
. If this
Operators
modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[PortNumber]Port number on the switch.A1 to B4 (2500 family),
1A1 to 8B4 (6500),
or All
[Loopback]Loopback mode (see Table 2-1). None, Facility, Equipment, DiagNone
Output ParameterDescription
[PortNumber]Physical port number on the switch.
[Type]Type of port.
[Loopback]Loopback mode. Possible values are None, Facility, Equipment, or Diag (see Table 2-1).
No default
SmartSwitch ATM Switch Reference Manual 2-1
Page 30
622LoopBack Console Commands
Descriptions
OperatorParameters/PermissionsDescription
modify 622loopback
[Port] <port>
[Loopback] <loopback>
Sets loopback for 622 Mbps ports.
Administrator
show 622loopback
AdministratorShows loopback status for 622 Mbps ports.
Table 2-1OC-12/STM-4 Port Loopback Modes
ModeDescription
NoneLoopback is not enabled.
FacilityThe data stream is received from the network, has the overhead bits reinserted, and is retransmitted
back to the network.
EquipmentConnects the transmitter to the receiver. The data stream received from the line is retransmitted back
out the line. Cells generated by the switch to this port are not sent over the line.
DiagConnects the receiver to the transmitter . The data stream transmitted by the switch to a po rt is looped
back to the switch.
Examples
switch_1 # show 622loopback
Port(ALL) :
Port Type Loopback
==============================================================================
1A1 622 None
switch_1 # set 622loopback
Port() : 1a1
Loopback(None) : Facility
switch_1 # show 622loopback
Port(ALL) :
Port Type Loopback
==============================================================================
1A1 622 Facility
switch_1 #
2-2 SmartSwitch ATM Switch Reference Manual
Page 31
Console CommandsAlarmDisplay
AlarmDisplay
Use AlarmDisplay to enable/disable the display of alarm messages at the console.
NoteUse Alarms to display the alarms currently logged.
Operators
modify, show
Parameters
This attribute has no output parameters.
Input ParameterDescriptionValue/Field SizeDefault
[AlarmDisplay]Toggles the display On or Off.On, Off
Descriptions
OperatorParameters/PermissionsDescription
modify
alarmdisplay
show
alarmdisplay
[AlarmDisplay] <alarmdisplay>
Toggles display of alarm messages on the console screen.
Administrator
AdministratorDisplays status of alarms display.
Examples
switch_prompt # show alarmdisplay
Alarm Display is OFF
switch_prompt #
switch_prompt # modify alarmdisplay
AlarmDisplay[OFF] : on
switch_prompt #
switch_prompt # show alarmdisplay
Alarm Display is ON
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-3
Page 32
Alarms Console Commands
Alarms
Use Alarms to display or delete alarms currently logged.
Displays alarm(s) currently logged. Alarm information
includes message index number, alarm ID, message text,
severity, and a timestamp (time the alarm occurred, with
respect to switch up-time in hours, minutes, seconds, and
milliseconds).
Positive integer or AllAll
2-4 SmartSwitch ATM Switch Reference Manual
Page 33
Console CommandsAlarms
Examples
switch_prompt # show alarms
Index(ALL) :
0 33554652 000:00:32:238
Any valid combination of
operator and attribute (for
example,
show events). The
aliased string may not contain
another alias.
Output ParameterDescription
[Index]Sequence number assigned to alias by console.
[Alias Name]Same as the [AliasName] input parameter.
[Aliased Command]Same as the [AliasedString] input parameter.
Descriptions
OperatorParameters/PermissionsDescription
No default
No default
add alias [AliasName] <aliasname>
[AliasedString] <aliasedstring>
Administrator
2-6 SmartSwitch ATM Switch Reference Manual
Creates an alias. You can have up to 15 active
aliases (including
ping).
Page 35
Console CommandsAlias
OperatorParameters/PermissionsDescription
delete alias
[AliasName] <aliasname>
Deletes an alias.
Administrator
flush alias
modify alias[AliasName] <aliasname>
AdministratorDeletes all aliases (including ping).
Changes an alias.
[NewAliasedString] <newaliasedsring>
Administrator
show alias[AliasName] <aliasname>
Displays all aliases.
Administrator
Examples
switch_prompt # add alias
AliasName() : spnni
AliasedString() : show pnniinterface
switch_prompt #
switch prompt # delete alias
AliasName() : spnni
spnni -> show pnniinterface
Confirm(y/n)?:y
switch_prompt #
switch_prompt # flush alias
You are about to delete all aliases
Confirm(y/n)?:y
switch_prompt #
switch_prompt # modify alias
AliasName() : spnni
NewAliasedString() : sp
Modifying Alias "spnni -> show pnniinterface" to "spnni -> sp"
Confirm(y/n)?:y
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-7
Page 36
Alias Console Commands
switch_prompt # show alias
AliasName(ALL) :
Alias List
==============================================================================
Index Alias Name : Aliased Command
1 PING : Start Ping
2 sp : show pnninode
switch_prompt #
2-8 SmartSwitch ATM Switch Reference Manual
Page 37
Console CommandsAtmFilter
AtmFilter
Use AtmFilter to manage ATM filters on th e switch.
Use AtmFilterSet to manage an ATM filter set. An ATM filter set consists of one or more ATM filters. Each ATM
filter set is assigned to a pair of ports, having one incoming port and one outgoing port (alternately, you can assign a
filter set to all incoming or outgoing ports).
Operators
add, delete, modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[FilterName]Name of the filter to insert or
remove from the filter set (used with
modify atmfilterset
only).
[FilterSetName]Name of the filter set.
[Operation]Operation to perform on the filter set
(used with
modify atmfilterset
Insert, RemoveNo default
only).
In the Output Parameter tabl e below , (
(detailed) command or if you specify a specific [FilterSetName]. In both cases, you get information about specific
/d
) indicates parameters that are available only through the show atmfilter
</d>
filters in the filter set.
Output ParameterDescription
[FilterSetName]Name of the filter set.
[TotalAdmits]Total admits associated with the filter set.
[TotalDenies]Total d enies associated with the filter set.
[ReferenceCount]Reference count associated with the filter set.
[Priority]
</d>
Priority of a filter in the filter set. (Priority is assigned in the order in which
filters are added to the filter set; the first filter added becomes priority 1, the
second priority 2 and so forth. If a filter is removed from the set, each lower
priority filter has its prioiry adjusted upward one position. Filtering is done
in order of priority; the priority 1 filter is used, then priority 2 filter, and so
forth until all filters have been used.)
[FilterType]
</d>
Type of a filter in the filter set.
SmartSwitch ATM Switch Reference Manual 2-13
Page 42
AtmFilterSet Console Commands
Output ParameterDescription
(If /d or a specific [FilterSetName] is specified, you also get a breakdown of TotalAdmits, TotalDenies, and
ReferenceCount for each filter in the set.)
Filter Set Name : SET1
Total Admits : 0
Total Denies : 0
Reference Count : 0
================================================================================
Use ATMRoute to manage routes to reachable addresses from the switch.
NoteThe following applies to SmartSwitch 6500 only: You can hot-swap TSMs.
Hot-swapping is replacing a module when the chassis is powered up. If you
replace a TSM with another TSM of the same type (same I/O ports), existing
configuration of port parameters is not affected. This includes parameters set
using any of the following attributes: ATMRoute, CACServiceClassBw,
IlmiConfig, NetPrefix, Port, PortConfig, PVC, PVP, ServiceRegistry, SigTimer,
SigStatistics, SSCOPConfig, and SSCOPStatistics. If you replace a TSM with
another TSM of a different type, existing configuration of port parameters is
deleted. The deletion occurs when the new module is plu gge d into the chassis
backplane.
Operators
add, delete, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[Num]Index number of the route as assigned
by the console. Use the
atmroute all
index numbers.
[PortNumber]Port number on the switch. You can
specify a physical or virtual port.
[AtmAddr]Address prefix of the ATM end
system.
[PrefixLength]Length in bits to apply to the address
prefix.
command to get a list of
show
Positive integerAll
A1 to B4 (physical-2500 family),
A1.n to B4.n (virtual-2500 family),
1A1 to 8B4 (physical-6500),
1A1.n to 8B4.n (virtual-6500),
or All
All
No default
No default
[AddressIndex]Index into the set of listings of
connectivity to the address prefix.
[T ype]Type of reach ability from the switch to
the address prefix.
2-16 SmartSwitch ATM Switch Reference Manual
0
Exterior, Internal, RejectInternal
Page 45
Console CommandsATMRoute
Input ParameterDescriptionValue/Field SizeDefault
[Scope]PNNI scope of advertisement (level of
PNNI hierarchy) from the switch to the
address prefix.
[MetricsT ag]Index into listing of traffic parameters
that apply to connectivity from the
switch to the address prefix. If there
are no parameters associated with this
address prefix, then zero is used.
[Advertising]Whether or not the local switch should
advertise the address into the PNNI
domain. For example, use Yes for an
end station address and No for an IISP
route.
NoteIf you hot-swap a TSM with a TSM of a dif ferent type (different I/O ports), r outing
information associated with ports on the original TSM is deleted. Before you
insert a replacement TSM, you can display existing routing information using the
show operator with the /o option (for example: show atmroute /o).
Integers from 0-1040
0
Yes, NoNo
Output ParameterDescription
[Num]Index number of the route as assigned by the console.
[Port]Same as [PortNumber] input parameter.
[ATM Address]Same as [ATMAddr] input parameter.
[Protocol]Routing mechanism used to determine connectivity between the switch and the
reachable address prefix. Possible values are Other, Local, Mgmt, and PNNI.
[Advertising Node Id]Identifier of the node advertising reachability to the address prefix.
[Advertising Port Id]Iden tifier of the port used from the advertising node to reach the given address prefix.
[PNNI Scope] PNNI scope of advertisement (level of PNNI hierarchy) of reachability from the switch
to the address prefix.
[VP Capability]Ind icates whether or not VPCs can be established from the advertising node to the
reachable address prefix.
SmartSwitch ATM Switch Reference Manual 2-17
Page 46
ATMRoute Console Commands
Output ParameterDescription
[Metrics Tag] Index into the listing of traffic parameter values that apply for connectivity between the
switch and the reachable address prefix.
[Ptse Id]For reachable addresses learned through PNNI, this parameter contains the value of the
PTSE identifier for the P TSE that is originated by the originating node and contains the
information group(s) describing the reachable address. For reachable addr esses learned
by means other than PNNI, this parameter is set to zero.
[Advertising]Whether or not the local switch advertises the local address into the PNNI domain.
Possible values are: Yes and No.
[Oper Status]Whether or not the reachable address prefix is operationally valid and whether it is
advertised by this node. Possible values are: Advertised, Active, and Inactive.
Deletes a route to a reachable address from the switch.
Administrator
show atmroute
AllDisplays the configured routes from the switch.
Examples
switch_prompt # show atmroute
Num(ALL) :
Num Port Number ATM Address Type Proto
================================================================================
1 CPU 39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:00:1d:a3:87:0b I MGMT
2 CPU 39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:00:64:01:01:16 I MGMT
3 -- 39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:20:d4:28:c1:ff I MGMT
4 CPU 47:00:79:00:00:00:00:00:00:00:00:00:00:00:a0:3e:00:00:01 I MGMT
Num Port Number ATM Address Type Proto
================================================================================
1 7A3 20:01:02:03 I MGMT
2 CPU 39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:00:1d:a3:87:0b I MGMT
3 CPU 39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:00:64:01:01:16 I MGMT
4 -- 39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:20:d4:28:c1:ff I MGMT
5 CPU 47:00:79:00:00:00:00:00:00:00:00:00:00:00:a0:3e:00:00:01 I MGMT
Route Address Num 0
================================================================================
Node Index : 1
Port Number : 7A3
ATM Address : 20:01:02:03:00:00:00:00:00:00:00:00:00:00:00:00:00:00:00
Prefix Length : 32
Address Index : 0
Advertising Node: 50:a0:39:00:00:00:00:00:00:00:00:00:a3:87:0b:00:20:d4:28:c1:ff
:00
Advert Port Id : 29634560
Type : Internal
Protocol : MGMT
PNNI Scope : 0
VP Capability : False
Metrics Tag : 0
Ptse Id : 0
Advertising : No
Oper Status : Active
The ATM route was deleted successfully.
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-19
Page 48
BUSClient Console Commands
BUSClient
Use BUSClient to display or delete LANE clients connected to a BUS. Each LANE client is identified uniquely by its
LEC ID.
Operators
delete, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[ELANNumber]Number of the ELAN to which the BUS
0-1250
belongs.
[LECId]LEC ID of the specified client.1-652790
[ATMAddress]ATM address of the client.No default
Output ParameterDescription
[LECId]LEC identification number of the specified client.
[VPI/VCI]VPI/VCI (virtual path/channel identifier) values of control direct VCC (virtual channel
connection) or multicast send VCC.
[ATM Address]ATM address of the client.
Descriptions
OperatorParameters/PermissionsDescription
delete
busclient
[ELANNumber] <elannumber>
[LecID] <lecidvalue>
Administrator
show
busclient
2-20 SmartSwitch ATM Switch Reference Manual
[ELANNumber] <elannumber>
All
Removes a specified client from the BUS on the specified
ELAN.
Displays information about all clients that have joined the
BUS on the specified ELAN.
Use BUSErrorLog to display or clear the BUS error log associated with an ELAN.
NoteUse the add buselan or modify buselan commands to enable or disable the BUS
error log for a specified ELAN.
Operators
clear, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[ELANNumber]The number of the ELAN whose BUS errors are
to be shown or deleted.
Output ParameterDescription
[ATM Address]ATM address associated with the error.
[ErrorCode]Decimal code that shows why the error occurred (see Table 2-2).
[SysUpTime]Time the error occurred with respect to switch up-time in hours, minutes, and seconds.
0-125All
Descriptions
OperatorParameters/PermissionsDescription
delete buserrorlog
show buserrorlog
[ELANNumber] <elannumber>
Administrator
AdministratorDisplays the BUS error log.
Clears the BUS error log.
2-22 SmartSwitch ATM Switch Reference Manual
Page 51
Console CommandsBUSErrorLog
Table 2-2BUSErrorLog Error Codes
CodeNameMeaning
0SuccessSuccessful response.
1Insufficient resources to grant requestResponder is unable to grant request for reasons such as
insufficient table space or ability to establish VCCs.
2Bad control frameMalformed control frame or bad control request.
3Bad data frameMalformed data frame (too big or too small).
4OthersAll other events.
Examples
switch prompt # show buserrorlog
ELANNumber(ALL) : 1
switch prompt # show buserrorlog
ELANNumber(ALL) : 1
Error Log Entries for VLAN : 0
switch prompt #
SmartSwitch ATM Switch Reference Manual 2-23
Page 52
BUSELAN Console Commands
BUSELAN
Use BUSELAN to manage characteristics of a BUS for a specified ELAN. If an LES corresponding to the BUS exists,
the characteristics of the BUS should match those of the LES.
Operators
add, delete, modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[ELANNumber]Number of the ELAN to which the BUS
belongs.
[ELANName]Name of the ELAN to which the BUS belongs. Up to 32 characters
[ConnectMethod]Type of connection used.PVC, SVCSVC
[ELANType]Data-link type used by the ELAN.802.3 (Ethernet),
[Multipoint]Indicates whether control distribute VCC is
PMP (point-to-multipoint) or PTP
(point-to-point).
[MTU]Maximum transfer unit assigned for this client. 1516, 1580, 4544, or
[ErrorLogEnable]Whether or not BUS error log is enabled.Yes, NoNo
[MinimumTDEnable]Whether or not minimum acceptable traffic
descriptor negotiation is enabled .
[ForwardPeakCellRate]Minim um forward peak cell rate.Positive integer
0-125 or AllAll
802.3
802.5 (TokenRing)
Yes: VCC is PMP
No: VCC is PTP
9234
Yes, NoNo
Yes
1516
Output ParameterDescription
[ELAN Number]Number of the ELAN to which the BUS belongs.
[ELAN Name]Name of the ELAN to which the BUS belongs.
2-24 SmartSwitch ATM Switch Reference Manual
Page 53
Console CommandsBUSELAN
Output ParameterDescription
[ATM Address]AT M address of the ELAN.
[Max Frame Size]Maximum transfer unit assigned for this client. (Same as the [MTU] input parameter.)
[Connection Method]Type of connection used. (Same as the [ConnectMethod] input parameter.)
[Distribute VPI/VCI]VPI/VCI values of control direct VCC or multicast send VCC.
[ELAN Type]Data-link type used by the ELAN.
[Multipoint]Indicates whether control distribute VCC is PMP (point-to-multipoint) or PTP
(point-to-point).
[Error Logging]Whether or not BUS error log is enabled.
[Min TD Negotiation]Whether or not minimum TD negotiation is enabled.
Creates a BUS on a specified ELAN. If the
corresponding LESELAN exists, then the added
BUSELAN should have similar characteristics.
Removes the BUS from a specified ELAN and
drops clients connected to it.
Changes the behavior of th e BUS parameters for a
specified ELAN. The specified ELAN is then
deleted and recreated. If the corresponding
LESELAN exists, then the modified BUSELAN
should have the same characteristics as that
existing LESELAN because their parameters need
to match.
Administrator
SmartSwitch ATM Switch Reference Manual 2-25
Page 54
BUSELAN Console Commands
OperatorParameters/PermissionsDescription
show
buselan
[ELANNumber] <elannumber>
All
Displays the BUS parameters for the specified
ELAN. Enter
switch_prompt # delete buselan
ELANNumber(0) : 3
ELAN Number : 3
ELAN Name : ELAN003
ATM Address : 39:00:00:00:00:00:00:00:20:D4:14:15:00:00:20:D4:14:15:03:02
Confirm(y/n)? : y
switch_prompt #
2-26 SmartSwitch ATM Switch Reference Manual
Page 55
Console CommandsBUSELAN
The example below changes ELAN102 from an Ethernet BUSELAN to a T oken Ring BUSELAN, changing the MTU
to reflect the change in ELAN type. It assumes the LES has already been changed.
ELAN Number : 102
ELAN Name : ELAN102
ATM Address : 39:00:00:00:00:00:00:00:20:D4:14:15:00:00:20:D4:14:15:66:02
Max Frame Size : 4544
Connection Method : SVC
Distribute VPI/VCI : 0/2423
Sel.DistributeVPI/VCI: 0/2423
ELAN Type : 802.5
Multipoint : YES
Error Logging : NO
Min TD Negotiation : NO
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-27
Page 56
BUSLECStat Console Commands
BUSLECStat
Use BUSLECStat to display traffic statistics for clients connected to a BUS.
Operator
show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[ELANNumber]Number of the ELAN to which the BUS belongs.0-125 or AllAll
[LECId]LEC identification number of the specified client. 0-652790
Output ParameterDescription
[LECId]LEC identification number of the specified client.
[ATMAddress]ATM address of the client.
[Receives]Number of multicast and broadcast and unknown forward requests received by the
BUS from this LEC.
[Forwards]Number of requests forwarded by the BUS from this LEC.
[Discards]Number of requests discarded by the BUS from this LEC.
Descriptions
OperatorParameters/PermissionsDescription
show
buslecstat
[ELANNumber] <elannumber>
[LecId] <lecidvalue>
All
Displays statistical information about a sp ecific client or all
clients on that ELAN.
2-28 SmartSwitch ATM Switch Reference Manual
Page 57
Console CommandsBUSLECStat
Examples
switch_prompt # show buslecstat
ELANNumber(0) :
LECId(0) :
Use BUSStat to display or clear statistics of a BUS for an ELAN.
Operators
show, clear
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[ELANNumber]Number of the ELAN to which the BUS belongs. 0-125 or AllAll
Output ParameterDescription
[Out Octets]Number of octets (bytes) the BUS has sent since its initialization.
[Out Unicast]Number of unicast frames forwarded by the BUS.
[Out Multicast]Number of multicast frames forwarded by the BUS.
[In Octets]Number of octets (bytes) the BUS has received since its initialization.
[In Unicast]Number of unicast frames received by the BUS.
[In Multicast]Number of multicast frames received by the BUS.
[Frame Timeouts]Number of frames dropped by the BUS due to timeout.
[VCC Rejects]Number of frames rejected because VCC is not available.
Descriptions
OperatorParameters/PermissionsDescription
show
busstat
[ELANNumber] <elannumber>
All
Displays BUS statistics for the specified ELAN or for all ELANs.
clear
busstat
2-30 SmartSwitch ATM Switch Reference Manual
[ELANNumber] <elannumber>
Administrator
Clears BUS statistics for the specified ELAN or for all ELANs.
Page 59
Console CommandsBUSStat
Examples
switch_prompt # show busstat 3
ELAN ELAN003 Statistics
Out Octets : 450432
Out Unicast : 7030
Out Multicast : 3
In Octets : 450432
In Unicast : 7030
In Multicast : 3
Frame Timeouts : 0
VCC Rejects : 0
switch_prompt #
switch_prompt # clear busstat
ELANNumber(ALL):
Clearing ALL BUS ELAN Statistics
Confirm(y/n)?:y
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-31
Page 60
BUStype Console Commands
BUStype
Use BUStype to enable/disable intelligent B US mode.
NoteIf intelligent BUS mode is enabled, a unicast packet sent to the BUS is forwarded
only to the LANE client whose destination address is specified in the packet. If
intelligent BUS mode is not enabled, a unicast packet sent to the BUS is forwarded
to all LANE clients connected to the BUS.
Operators
modify
Parameters
This attribute has no output parameters.
Input ParameterDescriptionValue/Field SizeDefault
[IntelligentBUSMode]Enables/disables intelligent BUS mode.Off, OnOff
Descriptions
OperatorParameters/PermissionsDescription
modify bustype[IntelligentBUSMode]
<intelligentbusmode>
Sets intelligent BUS mode.
Administrator
Examples
switch_prompt # modify bustype
IntelligentBUSMode(OFF) : on
BUS Type Set to Intelligent Mode
switch_prompt #
2-32 SmartSwitch ATM Switch Reference Manual
Page 61
Console CommandsCACEqBwAllocScheme
CACEqBwAllocScheme
Use CACEqBwAllocScheme to set or display th e equivalent bandwidt h allocation scheme of switch ports.
Operators
modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[PortNumber]Port number on the switch.
You can specify a physical
or virtual port.
A1 to B4 (physical-2500 family),
A1.n to B4.n (virtual-2500 family),
1A1 to 8B4 (physical-6500),
All
1A1.n to 8B4.n (virtual-6500),
or All
[ServiceCategory]Service category.CBR, UBR, RTVBR, NRTVB R or
CBR
ABR
[AllocScheme]Allocation scheme for
connection admission.
CON (conservative), LIB (liberal),
MOD (moderate)
CON
Output ParameterDescription
[Port#]Port number on the switch. (Same as the [PortNumber] input parameter.)
[Alloc Scheme]Allocation scheme for connection admission for each service category.
switch_prompt # show caceqbwallocscheme
PortNumber(ALL) :
===========================================================
Port# Alloc Scheme
for
CBR RTVBR NRTVBR UBR ABR
===========================================================
7A1 CON CON CON LIB CON
7A1.1 CON CON CON LIB CON
7A2 CON CON CON LIB CON
7A3 CON CON CON LIB CON
7A4 CON CON CON LIB CON
7B1 CON CON CON LIB CON
7B2 CON CON CON LIB CON
7B3 CON CON CON LIB CON
CPU CON CON CON LIB CON
CPU.1 CON CON CON LIB CON
switch_prompt # show caceqbwallocscheme
PortNumber(ALL) :
===========================================================
Port# Alloc Scheme
for
CBR RTVBR NRTVBR UBR ABR
===========================================================
7A1 CON CON LIB LIB CON
7A1.1 CON CON CON LIB CON
7A2 CON CON CON LIB CON
7A3 CON CON CON LIB CON
7A4 CON CON CON LIB CON
7B1 CON CON CON LIB CON
7B2 CON CON CON LIB CON
7B3 CON CON CON LIB CON
CPU CON CON CON LIB CON
CPU.1 CON CON CON LIB CON
switch_prompt #
2-34 SmartSwitch ATM Switch Reference Manual
Page 63
Console CommandsCacInfo
CacInfo
Use CacInfo to display bandwidth allocated to switch ports per service category.
Operators
show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[PortNumber]Port number on the switch.
You can specify a physical
or virtual port.
[BandwidthUnit]Unit for specifying
bandwidth.
Output ParameterDescription
[Port#]Port number on the switch. (Same as the [PortNumber] input parameter.)
[Total BW]Available physical link bandwidth (in bandwidth units specified as input parameter).
[Total BW Allocated]Bandwidth allocated on this port.
[BwAlloc for
ServiceCategory]
Bandwidth allocated for each service category. Supported service categories are:
CBR (constant bit rate), UBR (unspecified bit rate), RTVBR (realtime variable bit
rate), NRTVBR (non-realtime variable bit rate), ABR (available bit rate).
A1 to B4 (physical-2500 family),
A1.n to B4.n (virtual-2500 family),
1A1 to 8B4 (physical-6500),
1A1.n to 8B4.n (virtual-6500),
or All
CPS (cells per second),
KBS (Kbits per second),
MBS (Mbits per second),
or PER (percentage)
Use CACServiceClassBw to set or display the bandwidth allocated to each service category.
NoteThe following applies to SmartSwitch 6500 only: You can hot-swap TSMs.
Hot-swapping is replacing a module when the chassis is powered up. If you
replace a TSM with another TSM of the same type (same I/O ports), existing
configuration of port parameters is not affected. This includes parameters set
using any of the following attributes: ATMRoute, CACServiceClassBw,
IlmiConfig, NetPrefix, Port, PortConfig, PVC, PVP, ServiceRegistry, SigTimer,
SigStatistics, SSCOPConfig, and SSCOPStatistics. If you replace a TSM with
another TSM of a different type, existing configuration of port parameters is
deleted. The deletion occurs when the new module is p lugged into the chassis
backplane.
Operators
modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[PortNumber]Port number on the switch.
You can specify a physical
or virtual port.
[ServiceCategory].iÀ܈ViÊV>Íi}œÀß°CBR, UBR, RTVBR, NRTVBR, ABR UBR
===========================================
Port# SC Max Bandwidth
In
Mbps Kbps Cps %
===========================================
1A1 CBR 1 1 1 1
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-41
Page 70
CACStatistics Console Commands
CACStatistics
Use CACStatistics to show CAC statistics fo r switch ports.
Operators
clear, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[PortNumber]Port number on the switch.
You can specify a physical
or virtual port.
A1 to B4 (physical-2500 family),
A1.n to B4.n (virtual-2500 family),
1A1 to 8B4 (physical-6500),
1A1.n to 8B4.n (virtual-6500),
or All
Output ParameterDescription
[Port Number]Physical or virtual port number on the switch.
[Global Statistics]Global CAC statistics (applies to all ports).
[Per Port Statistics]Statistics for a specific port.
Descriptions
OperatorParameters/PermissionsDescription
clear
cacstatistics
[PortNumber] <portnumber>
Administrator
Clears CAC statistics of a port or all ports.
All
show
cacstatistics
[PortNumber] <portnumber>
Administrator
Examples
2-42 SmartSwitch ATM Switch Reference Manual
Displays CAC statistics of a port or all ports.
Page 71
Console CommandsCACStatistics
switch_prompt # show cacstatistics
PortNumber() : 1a1
================================================================
CAC Statistics
================================================================
Global Statistics :
No of Rejections due to no memory :0
No of Rejections due to Invalid Physical port :0
No of Rejections due to Invalid logical port :0
No of Rejections due to Invalid VPI :0
No of Rejections due to Pre CAC no memory :0
Per Port Statistics :
Port Number :1A1
No of calls rejected due to User cell rate unavailable :0
No of calls rejected due to Sytem Low Memory :0
No of calls rejected due to Link Down :0
No of calls rejected due to VPCI/VCI unavailable :0
No of calls rejected due to Unsupported traffic params :0
No of CBR calls rejected :0
No of RT_VBR calls rejected :0
No of NRT_VBR calls rejected :0
No of UBR calls rejected :0
No of ABR calls rejected :0
No of CBR calls HIGH threshold exceeded :0
No of CBR calls LOW threshold exceeded :0
No of RT_VBR calls HIGH threshold exceeded :0
No of RT_VBR calls LOW threshold exceeded :0
No of NRT_VBR calls HIGH threshold exceeded :0
No of NRT_VBR calls LOW threshold exceeded :0
No of UBR calls HIGH threshold exceeded :0
No of UBR calls LOW threshold exceeded :0
No of ABR calls HIGH threshold exceeded :0
No of ABR calls LOW threshold exceeded :0
No of PNNI Updates sent :0
Total No of calls HIGH threshold exceeded :0
Total No of calls LOW threshold exceeded :0
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-43
Page 72
Client Console Commands
Client
Use Client to manage LANE and IP/ATM clients on the switch. Clients on the switch are called local clients.
NoteUse the LANEClient attribute to add or modify a LANE client. Use the
IPATMClient attribute to add or modify an IP/ATM client.
[ClientNumber]Number of the local client.0-125 or AllAll
(
In the Output Parameter table below,
client /d
(detailed) command.
)
appears next to parameters that are available only through the show
</d>
Output ParameterDescription
[Client]Number of the local client. (Same as the [ClientNumber] input parameter.)
[Type]Type of client.
[IP Address]IP address of client.
[Server Type]Specifies what server type the client is on.
[Server Conn]Status of connection the client has with the server. Possible values are:
Established and Shutdown.
[Status]Current status of the client.
[Client State]
</d>
[Client Address]
[LAN Name]
</d>
</d>
Status of where the client is in the process of making a connection.
ATM address of the client.
ELAN name for this client.
[LECS Addr Source]
2-44 SmartSwitch ATM Switch Reference Manual
</d>
ILMI, well-known address, or LECS address.
Page 73
Console CommandsClient
Output ParameterDescription
[LECS Address]
[LES Address]
[LAN Type]
[MTU]
[IP NetMask]
</d>
</d>
</d>
</d>
</d>
ATM address of the LECS.
ATM address of the LES.
Type of ELAN.
Maximum transfer unit assigned for this client.
IP netmask assigned to the client.
Descriptions
OperatorParameters/PermissionsDescription
activate
client
deactivate
client
delete
client
[ClientNumber] <clientnumber>
Administrator
[ClientNumber] <clientnumber>
Administrator
[ClientNumber] <clientnumber>
Administrator
Activates a client on the switch (same as the
command).
Deactivates a client on the switch.
Removes a client from the switch.
restart client
restart
client
show client
(/d)
[ClientNumber] <clientnumber>
Administrator
[ClientNumber] <clientnumber>
All
Restarts a client on the switch. If a client fails to successfully
join a VLAN, you can restart the client to retry. The switch
software, on a periodic basis, automatically tries to restart
clients that have not successfully joined. Enter
show client
to confirm that the client(s) have restarted.
Displays the details of a client on the switch. You can obtain
more details of all the clients on the switch by addin g
the end of the command. For example,
Client Type IP Address Server Type Server Conn Status
============================================================================
1 LANE 90.1.1.186 LECS Established Operational
3 IP/ATM 90.1.1.124 Local Established Operational
switch_prompt #
Client Type IP Address Server Type Server Conn Status
============================================================================
1 LANE 90.1.1.186 LECS Shutdown Initial
3 IP/ATM 90.1.1.124 Local Shutdown Initial
switch_prompt #
switch_prompt # show client /s
ClientNumber(ALL) :
Client Type IP Address Server Type Server Conn Status
============================================================================
1 LANE 90.1.1.186 LECS Established Operational
3 IP/ATM 90.1.1.124 Local Established Operational
switch_prompt #
2-46 SmartSwitch ATM Switch Reference Manual
Page 75
Console CommandsClient
With the following example (
), notice how you get the same amount of detail whether you specify the client or
</d>
accept the default (All):
switch_prompt # show client /d
ClientNumber(ALL) :
LANE Client 1
============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:00
LAN Name : elan1
LECS Addr Source: ILMI
LECS Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:01
LES Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:02
LAN Type : 802.3
MTU : 1516
IP Address : 90.1.1.186
IP NetMask : 255.255.255.0
IP/ATM Client 3
============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:00:5A:01:01:7C:00
Server : is local
Server Connection: Established
MTU : 9180
IP Address : 90.1.1.124
IP NetMask : 255.0.0.0
switch_prompt #
switch_prompt # show client 3 /d
IP/ATM Client 3
============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:00:5A:01:01:7C:00
Server : is local
Server Connection: Established
MTU : 9180
IP Address : 90.1.1.124
IP NetMask : 255.0.0.0
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-47
Page 76
ClientARP Console Commands
ClientARP
Use ClientARP to display the ARP table maintained by each LANE or IP/A TM client on the switch. For a LANE client,
the table contains mappings of MAC to A TM addresses for destination clients. The mappings are supplied by the ARP
server of each ELAN to which the LANE client connects. For an IP/ATM client, the table contains mappings of IP to
A TM addresses for destination clients. The map pings are supplied by the ARP server of each IP/ATM VLAN to which
the IP/ATM client connects. The LANE and IP/ATM clients cache the mappings to avoid repeated address resolution
requests to ARP servers.
NoteClients on the switch are called local clients.
Use ClientVC to display VCs associated with ARP mappings cached by LANE or IP/ATM clients on the switch.
ClientARP is similar to ClientVC but does not show the VPI/VCI corresponding to a route to a destination client.
NoteClients on the switch are called local clients.
[ClientNumber]Number of the local client.0-125 or AllAll
Output ParameterDescription
[MAC Address]MAC address of the LANE destination client.
[IP Address]IP address of the IP/ATM destination client.
[VPI/VCI]VPI/VCI values of control direct VCC or multicast Send VCC to the destination client.
[ATM Address]ATM address of the LANE or IP/ATM destination client.
Descriptions
OperatorParameters/PermissionsDescription
show
clientvc
[ClientNumber] <clientnumber>
All
Displays VC details for local IP/ATM or LANE clients in
addition to client ARP mapping details. For IP/ATM, the
destination IP address appears; for LANE, the destination
MAC address appears. The destination address is what is
located at the other end of the VC.
2-54 SmartSwitch ATM Switch Reference Manual
Page 83
Console CommandsClientVC
Examples
switch_prompt # show clientvc
ClientNumber(ALL) :
LANE Client 0 VC Table
MAC Address VPI/VCI
ATM Address
===========================================================================
00:02:D4:14:22:80 0/2453
39:00:00:00:00:00:00:00:20:D4:14:15:00:00:20:D4:14:22:80:00
IP/ATM Client 50 VC Table
IP Address VPI/VCI
ATM Address
============================================================================
Use Community to group NMS (network management system) hosts by privilege level. Hosts are collectively called
communities. Host privilege levels determine the type of information access permitted by the switch. The switch
provides access to the information only if the request comes from a community configured with the necessary
privileges.
Operators
add, delete, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[Name]SNMP community name. Needs to be
64 charactersNo default
defined on the switch to access SNMP.
[IPAddr]IP address of the host or hosts that can use
this community name. Entering 0.0.0.0
Dot decimal/
7-15 characters
No default
allows access by any host.
[Privilege]Privileges associated with this community. Read, Write, Read-write Read
Output ParameterDescription
[Community Name]SNMP community name. (Same as the [Name] input parameter.)
AdministratorDisplays all communities configured on the switch.
Removes a community from the switch.
Page 85
Console CommandsCommunity
Examples
switch_prompt # add community
Name() : boris
IpAddr() : 90.1.1.1
Priviledge(read) :
switch_prompt #
switch_prompt # show community
Community Name IP Address Privilege
===========================================================================
ILMI 0.0.0.0 READ
boris 90.1.1.1 READ
public 0.0.0.0 READ
zeitnet 0.0.0.0 WRITE
switch_prompt #
switch_prompt # delete community
Name() : boris
IpAddr() : 90.1.1.1
switch_prompt #
switch_prompt # show community
Community Name IP Address Privilege
===========================================================================
ILMI 0.0.0.0 READ
public 0.0.0.0 READ
zeitnet 0.0.0.0 WRITE
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-57
Page 86
Config Console Commands
Config
Use Config to erase the configuration information on the SmartSwitch 6500. Before using the clear config
command, you should back up the switch configuration using the
Operators
clear, flush
Parameters
This attribute has no input or output parameters. Just enter clear config at the switch prompt.
Descriptions
OperatorParameters/PermissionsDescription
backup switch command.
clear
config
AdministratorErases all switch configuration information, including
Ethernet interface address, IP/ATM VLAN and ELAN
configurations, signaling configuration, port configurations,
and so on.
Examples
switch_prompt # clear config
You should backup your configuration using the "backup switch" command, in case
you want to recover this configuration
Continuing will permanently erase the current switch configuration,
and requires a switch reboot.
Are you sure this is what you want to do?
Confirm(y/n)?:y
Configuration cleared.
Rebooting is required to ensure correct operation,
Do you want to reboot now?
Confirm(y/n)?:y
2-58 SmartSwitch ATM Switch Reference Manual
Page 87
Console CommandsConsoleTimeout
ConsoleTimeout
Use ConsoleTimeout to set or display the timeout for the console interface.
Operators
modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[ConsoleTimeout]Console timeout (in minutes).1-60 min. Setting console
timeout to 0 toggles console
timeout off.
Output ParameterDescription
[ConsoleTimeout]Console timeout (in minutes).
Descriptions
OperatorParameters/PermissionsDescription
modify
consoletimeout
show
consoletimeout
[ConsoleTimeout] <consoletimeout>
Sets console timeout.
Administrator
AdministratorDisplays current console timeout.
0 (Off)
Examples
switch_prompt # set consoletimeout
ConsoleTimeout(0) : 0
You are about to disable Console Timeout
Confirm (y/N)? : y
switch_prompt #
switch_prompt # show consoletimeout
Console Timeout in minutes
==============================================================================
ConsoleTimeout : OFF
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-59
Page 88
CoreDump Console Commands
CoreDump
Use CoreDump to dump the system CPU and/or common DRAM in the event of a system failure. The co re is dumped
to a file specified on a local Ethernet host. To use CoreDump, the Ethernet host must run TFTP server software, and
you must have write access to the TFTP directory.
Enables core dump. Once enabled, the core is
dumped to the file specified in the event o f a system
failure. The core dump takes about five minutes.
After the core dump, the switch is rebooted.
The core is dumped to two fi les, one containing CPU
memory (
core_cmn
(
core_cpu
), the other common memory
). You can send these files to Cabletron
customer support for analysis.
The
modify coredump command uses F TP to create
core_cpu
the
core_cmn
and
does not run FTP , cr eate these files manually bef ore
executing the modify coredump command. Ensure
the files have write access for everyone.
Note that each subsequent core dump overwrites
data from the previous core dump. If you want to
retain the previous core dump, rename the core
dump files or move them.
show coredumpAdministratorDisplays core dump status.
Use CpuSwitchover to manually switch roles of the redundant (slave) and master TSM/CPU modules (the slave
module becomes the master module and vice ve rsa). The
TSM/CPU module is present.
NoteCPU switchover occurs automatically if support for automatic TSM/C PU
redundancy has been activated and is operational. You activate automatic
TSM/CPU redundancy with the RedundancyOn attribute.
Operators
execute
execute cpuswitchover command is available only if a slave
Parameters
This attribute has no output parameters.
Input ParameterDescriptionValue/Field SizeDefault
[BackupConfig]Sets/unsets a flag to backup configuration.Y (Yes), N (No)Y
Descriptions
OperatorParameters/PermissionsDescription
execute
cpuswitchover
[BackupConfig] <backupconfig>
Administrator
Switches the slave TSM/CPU module to the master
TSM/CPU module and vice versa. The current
master configuration is backed up before the
switchover is made. After the switchover, the master
configuration is restored to the new master (the
module that was the slave before the switchover).
Backup the config and restore it on the redundant CPU when it boots up.
2-62 SmartSwitch ATM Switch Reference Manual
Page 91
Console CommandsCsmSwitchover
CsmSwitchover
(SmartSwitch 6500 Only)
Use CsmSwitchover to manually switch roles of the redundant (slave) and master CSM modules (the slave module
becomes the master module and vice versa). The
module is present.
NoteThe switch supports automatic CPU switchover but does not support automa tic
CSM switchover.
Operators
execute
Parameters
execute csmswitchover command is available only if a slave CSM
This attribute has no input or output parameters.
Descriptions
OperatorParameters/PermissionsDescription
execute
csmswitchover
AdministratorSwitches the slave CSM module to the master CSM
module and vice versa.
Examples
(Not available this draft.)
SmartSwitch ATM Switch Reference Manual 2-63
Page 92
DS3E3LoopBack Console Commands
DS3E3LoopBack
Use DS3E3LoopBack to set or display loopback at DS3 or E3 ports.
NoteA port in loopback mode does not pass normal traffic.
Operators
modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[PortNumber]Port number on the switch.A1 to B4 (2500 family),
1A1 to 8B4 (6500),
or All
[Loopback]Loopback mode (see Table 2-3).None, Cell, Payload,
Line, Diag
Output ParameterDescription
[Port]Port number on the switch.
[Type]Type of port.
[Loopback]Loopback mode specified (see Table 2-3).
Descriptions
OperatorParameters/PermissionsDescription
modify
ds3e3loopback
[Port] <port>
[Loopback] <loopback>
Administrator
Sets loopback status of DS3 and E3 ports.
All
None
show ds3e3loopbackAdministratorDisplays loopback status of DS3 and E3 ports.
2-64 SmartSwitch ATM Switch Reference Manual
Page 93
Console CommandsDS3E3LoopBack
Table 2-3DS3 and E3 Loopback Modes
ModeDescription
NoneLoopback is not enabled. The port passes normal traffic.
CellThe DS3 or E3 stream is received from the network, unframed into ATM cells, reframed, and then
retransmitted to the network.
PayloadThe DS3 or E3 stream is received from the network, has the DS3 or E3 overhead bits reinserted, and is
retransmitted to the network.
LineConnects the transmitter to the receiver. The DS3 or E3 stream received from the line is retransmitted
back out to the line. Cells generated by the switch to this po rt are not sent over the line.
DiagConnects the receiver to the transmitter. The DS3 or E3 stream transmitted by the switch to a port is
looped back to the switch. The DS3 or E3 stream is still trans mitted to the network, but the incoming
DS3 or E3 stream is ignored.
Examples
switch_prompt # show ds3e3loopback
Port(ALL) :
Port Type Loopback
==============================================================================
1D1 DS3 None
1D2 DS3 None
1D3 DS3 None
1D4 DS3 None
switch_prompt #
switch_1 # set ds3e3loopback
Port() : 1d3
Loopback(None) : Cell
NOTICE - 'tConsole' Port 1D3 (15) DOWN
switch_1 # show ds3e3loopback
Port(ALL) :
Port Type Loopback
==============================================================================
1D1 DS3 None
1D2 DS3 None
1D3 DS3 Cell
1D4 DS3 None
SmartSwitch ATM Switch Reference Manual 2-65
Page 94
ELAN Console Commands
ELAN
Use ELAN to create or delete ELANs on the switch. It is a means to manage ELAN servers with one command. To
manage ELAN servers individually, see the BUSELAN, LECSELAN, and LESELAN attributes.
NoteThe BUSELAN, LECSELAN, and LESELAN attributes manage, respectively,
the Broadcast and Unknown Se rver (BUS), LAN Emulation C onfiguration Serv er
(LECS), and the LAN Emulation Server (LES). The ELAN is served by a specific
BUS and LES (which sometimes are said to belong to the ELAN). The ELAN is
served by the network LECS.
[Distribute]Establi sh e s the nature of the control
All, ProxyProxy
distribute VCC. Possible values are: All or
Proxy. All establishes control distr ibut e
VCC to all clients. Proxy establishes
control distribute VCC onl y to proxy
clients.
Output Parameter Description
[ELAN Number]Number of the ELAN.
[LECS Address]ATM address of the LECS that serves the ELAN.
[LES Address]ATM address of the LES that serves the ELAN.
[ELAN Name]Name of the ELAN.
[ELAN Type]Type of the ELAN.
[MTU]Maximum tran sfer unit for the clien ts joining the ELAN.
[Connection Method]Type of connection used. (Same as the [ConnectMethod] input parameter.)
[Distribute VPI/VCI]VPI/VCI values of the control direct VCC or multicast send VCC.
[Distribute Method]Whether the control distribute VCC is established for all clients or only proxy clients.
[Multipoint]Indicates whether control distribute VCC is PMP (point-to-multipoint) or PTP
(point-to-point). Possible values are: Yes or No.
[Error Logging]Whether or not the BUS, LECS, and LES error logs are enabled.
[Min TD Negotiation]Whether or not minimum acceptable traffic descriptor negotiation is enabled.
Quickly configures an ELAN on the switch. It
adds an ELAN entry in the databases for the BUS,
LECS, and LES. It also activates the ELAN.
Quickly removes an ELAN config uration from the
switch. This command first checks that all servers
(LECS, LES, and BUS) exist before deleting any
of them.
switch_prompt # delete elan
ELANNumber(0): 11
Confirm(y/n)?: y
switch_prompt #
switch_prompt # show elan 0
ELAN 0
==============================================================================
ELAN Number : 0
LECS Address : 39:00:00:00:00:00:00:00:00:00:A3:87:0B:00:00:1D:A3:87:0B:01
LES Address : 39:00:00:00:00:00:00:00:00:00:A3:87:0B:00:00:1D:A3:87:0B:02
ELAN Name : ELAN000
ELAN Type : 802.3
MTU : 1516
Connection Method : SVC
Distribute VPI/VCI: 0/0
Distribute Method : PROXY
Multipoint : YES
Error Logging : NO
Min TD Negotiation : NO
switch_prompt #
SmartSwitch ATM Switch Reference Manual 2-69
Page 98
ElanMcast Console Commands
ElanMcast
Use ElanMcast to display multicast group MAC addresses served by an ELAN.
Operators
show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[ELANNumber]ELAN number associated with the multicast
0-125No default
group.
Output ParameterDescription
[Mcastid]BUS identification for the multicast group. Range is 2-64.
[Group MAC Address]Multicast group MAC address.
[Distribute VPI/VCI]Selective multicast forward VC established by the server.
Descriptions
OperatorParameters/PermissionsDescription
show elanmcast[ELANNumber] <elannumber>
Administrator
Displays multicast group MAC addresses served by
an ELAN.
Examples
switch_prompt # show elanmcast 0
MULTICAST ENTRIES for VLAN : 0
------------------------------------
McastId : 2
Group MAC Address : 01:80:C2:00:00:00
Distribute VPI/VCI : 0/62
switch_prompt #
2-70 SmartSwitch ATM Switch Reference Manual
Page 99
Console CommandsEventDisplay
EventDisplay
Use EventDisplay to enable/disable the display of event messages on the console screen.
NoteUse Events to display the events currently logged.
Operators
modify, show
Parameters
This attribute has no output parameters.
Input ParameterDescriptionValue/Field SizeDefault
[EventDisplay]Toggles the display On or Off.On, Off
Descriptions
OperatorParameters/PermissionsDescription
modify
eventdisplay
show
eventdisplay
[EventDisplay] <eventdisplay>
Administrator
AdministratorDisplays status of events display.
Toggles display of event messages on the console screen.
Examples
switch_1 # show eventdisplay
Event Display is ON
switch_1 #
switch_1 # modify eventdisplay
EventDisplay(ON) : off
switch_1 #
switch_1 # show eventdisplay
Event Display is OFF
switch_1 #
SmartSwitch ATM Switch Reference Manual 2-71
Page 100
Events Console Commands
Events
Use Events to display or delete events currently logged.
Displays event(s) currently logged. Event information
includes message index number, event ID, message text,
severity, and a timestamp (time the event occurred, with
respect to switch up-time in hours, minutes, seconds, and
milliseconds).
2-72 SmartSwitch ATM Switch Reference Manual
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
