Cabletron Systems KBU64 User Manual
KBU64 Rackmount
User Manual
Fivemere Ltd. Cabletron Systems Ltd.
Fivemere House Network House
161 High Street Newbury Business Park
Aldershot London Road, Newbury
Hampshire, England Berkshire, England
GU11 1TT RG13 2PZ
Telephone: [44] (0)1635 580000
Fax: [44] (0)1635 44578
KBU64 Rackmount
Publication — 80-10100001-09
Publication Notice:
This manual has been compiled and checked for accuracy. However the
information contained in this manual does not constitute a warranty of
performance. Cabletron Systems Ltd. reserves the right to revise this
publication from time to time without notice. Cabletron Systems Ltd.
assumes no liability for losses incurred as a result of out of date or incorrect
information contained in this manual.
Proprietary Notice:
© 1991-1997, Cabletron Systems Ltd., all rights reserved.
This document may not in whole or part be copi ed, phot ocopi ed, repr oduced,
translated, or reduced to any electronic medium or machine-readable f orm
without prior consent from Cabletron Systems Ltd.
Approval Notice:
This equipment is approved for connection to all United Kingdom
telecommunications services, including British Telecom PLC, Hull City
Council and Mercury Communications, and is subject to the conditions set
out in these instructions for use.
All users of this equipment in the UK, Europe and USA must make
themselves familiar with the statutory instructions contained in Section 7.
Pan European Approval:
Wher e the Pan European Approv al CE Mark ‘168X’ is appli ed to t he product ;
this approval is for connection of the ISDN and X.21 interfaces within the
European Community (EC).
Where an EC country requires approval for connection of the V35 or V24
Link ports to a PTO’s Digital Leased Circuit ( DLC) , this approval is necessary
in that country before connection to the DLC can be permitted.
Approv al in non EC count ries is subject to loc al regul ations in force, please
contact your Technical Support for information.
EMC Directive:
This product has been designed for use in Com mercial and Li ght Industrial
environments and tested to relevant EMC Standards as listed in the
European O.J. All testing was carried out using screened interconnection
cables. Should the equipment be used in a dif ferent env ironment the user
may need to take additional EMC precautions.
Acknowledgements: Kilostream™ is a trademark of British Telecom PLC.
Fivemere Ltd. is a subsidiary of Cabletron Systems Inc., USA.
User Manual
80-10100001-09ii
History Sheet
KBU64 Rackmount
User Manual
80-10100001-09 Issued separately for the R/M
due to USA requirements
21 January 1998
80-10100001-09 iii
KBU64 Rackmount
User Manual
TABLE OF CONTENTS
1 KBU 64 RACKMOUNT SPECIFICATION 1–1
NTRODUCTION
1.1 I
1–1
2 FRONT AND REAR PANELS AND INTERFACES 2–1
RONT PANEL
2.1 F
EAR INTERFACE CARDS
2.2 R
INK SETTINGS
2.2.1 L
2.2.2 C
2.2.3 V35 R
2.2.4 X21 R
2.2.5 V24 R
OMMAND PORT
EAR INTERFACE CARD
EAR INTERFACE CARD
EAR INTERFACE CARD
- KBU 64 R
EAR INTERFACE CARDS
2–1
2–1
2–3
2–4
2–5
2–6
2–6
3 MANAGER CARD 3–1
NTRODUCTION
3.1 I
3.2 F
3.3 R
RONT PANEL
EAR PANEL
3–1
3–3
3–3
4 CARD INSTALLATION 4–1
ANAGER CARD INSTALLATION
4.1 M
ONFIGURATION USING A MANAGER CARD
4.2 C
4–1
4–2
5 INSTALLATION AND POWER SUPPLY REQUIREMENTS 5–1
6 RACK SPECIFICATIONS 6–1
7 REGULATORY REQUIREMENTS 7–1
NITED KINGDOM AND EUROPE
7.1 U
7.2 A
DDITIONAL
EQUIREMENTS
UK R
7–1
7–1
80-10100001-09iv
KBU 64 Rackmount Specification
1 KBU 64 Rackmount Specification
1.1 Introduction
This manual describes the Rackmount version of the KBU64. The
standalone KBU 64 has its own manual , Publicat ion 80-10100000. For
information on the command menus and parameters in the rackmount
version, you will need to refer to the standalone KBU 64 manual.
The rackmount KBU 64 i s a dual channel rack m ountable car d that uses
the KBU 64 Card Fram e as a host for power and managem ent via t he
Management Card. The rackmounted KBU 64 consi sts of a K BU card
and a rear interface card (card 'pair'), both cards connecting to a
motherplane for power source and management. Rear interface cards
may be ordered as X.21, V.24, or V.35 variants.
Power supply is via two switching supplies, which normally load share
when both are fitted.
80-10100001-09 1–1
KBU64 Rackmount
User Manual
Fivemere
Figure 1.1 The KBU 64 Rackmount Version
Up to 13 KBU 64 card pairs m ay be fitt ed with either one or two power
supplies for resil ience. The 1st c ard slot is f or the Manager Card which
controls all cards within the rack via the KBU 64 polled management
system. If the Manager Card is not fi tt ed, m anagem ent of each c ard can
be perform ed by connecting a ter minal di rectly to t he command por t of
the rear int er face card. When fitted, the manager car d must be placed i n
slot 1, the left-hand most slot of the rack.
Fivemere
80-10100001-091–2
KBU 64 Rackmount Specification
The rackmount version of the KBU 64 is functionally the same as the
standalone in most respects, as it uses the same software. Theref ore
most of the sections of your KBU64 Manual manual (Publication 80-
10100000) relating to KBU 64's operation are relevant.
The rackmount card functionality differs in the following ways:-
• There is a single 15 way command port on each KBU 64 r ear card
for al l com mands and alar ms. T here is no separate alar m port or
alarm rel ay output on the cards. The com m and port has the sam e
function as the standalone 25 way command port.
• The Management Card (if fitted) provides a command port for
access to all KBU 64 cards in the rack.
• Standard physical interfaces are provided for X21 (15 way 'D'),
V35 (34 way MRAC), and V24 (25 way 'D'). Thi s means t hat the
V11/V28 selection links are not provided as they are no longer
necessary. A choice of 3 rear interface cards exist to provide
these interfaces.
• The interf ace LED's are as for the standalone ex cept that the Link
LED's have been omitted for front panel clarity.
• The ISDN cable is connected to the Rear I nterf ace Card by an RJ
45 style plug.
• Power indicati on f or each power supply i s present on the Manager
Card.
80-10100001-09 1–3
Front and Rear Panels and Interfaces
2 Front and Rear Panels and Interfaces
2.1 Front Panel
See the KBU64 standalone manual (Publication 80-10100000) for the
description of operation.
2.2 Rear Interface Cards
Wi th all 3 card types the USER ports are confi gured as physical DCEs,
the LINK ports as DTEs. The USER ports are fem ale and the LINK ar e
male for X21 and V24, both USER and LINK ports are female for V35.
All t hree card types use standard pin connection and so requi re 1 to 1
cables for connection to both user equipment and link equipment.
