CHAPTER 1

INTRODUCTION

Welcome to the Cabletron Systems

Switch Module Local Management Guide

to access and use Cabletron Systems Local Management for the ESXMIM products. Local Management provides monitoring and control capabilities for either ESXMIM model and its attached segments.

ESXMIM/ESXMIM-F2 Ethernet

. This manual explains how

1.1 USING THIS MANUAL

A general working knowledge of basic network operations and an understanding of management applications is helpful prior to using Cabletron Systems Local Management.

This manual describes how to

• access the Local Management application,

• identify and operate the types of ﬁelds used by Local Management,

• navigate through Local Management ﬁelds and menus,

• use Local Management screens to perform management operations.

1.1.1 Manual Organization

The following summarizes the organization of this manual. Chapter 1,

overview of Local Management, and e xplains how to use the management screens.

Chapter 2, requirements for accessing Local Management. It also explains how to conﬁgure a management terminal and connect it to the ESXMIM.

Chapter 3, Main Menu screen and navigate the Local Management screens.

Chapter 4, Level screen, its functions, and operations.

ESXMIM/ESXMIM-F2 Local Management Guide Page 1-1

Introduction

Local Management Requirements

Accessing Local Management

The System Level Screen

, outlines the contents of this manual, provides an

, describes how to access the

, describes how to use the System

, describes the setup

Chapter 1:

Introduction

Chapter 5,

The SNMP Community Names Screen

, explains how to

control access to the ESXMIM by assigning community names. Chapter 6,

The SNMP Traps Screen

, explains how to conﬁgure the ESXMIM to send SNMP trap messages to multiple network management stations.

Chapter 7,

The FLASH Download Screen

, describes how to download a

new ﬁrmware image to the ESXMIM’s FLASH EEPROM. Chapter 8,

The Bridge Setup Screen

, describes how to conﬁgure the ESXMIM for bridge functions.

Chapter 9,

The Module Specific Setup Screen

, describes how to

conﬁgure the ESXMIM interface 1 connection method. Chapter 10,

The Component Status Screen

, discusses how to view the

status of ESXMIM MIB components. Chapter 11,

The Interface Statistics Screen

, discusses how to conﬁgure

the ESXMIM to gather statistics for each interface. Chapter 12,

The MIB Navigator Screen

, describes how to access and use the MIB Navigator screen. This chapter also includes examples for MIB Navigator commands.

1.2 DOCUMENT CONVENTIONS

The following conventions are used throughout this document:

Note

NOTE

TIP

CAUTION

Page 1-2 ESXMIM/ESXMIM-F2 Local Management Guide

symbol. Calls the reader’s attention to any item of

information that may be of special importance.

Tip

symbol. Conveys helpful hints concerning procedures or

actions.

Caution

damage to the equipment.

symbol. Contains information essential to avoid

Getting Help

1.3 GETTING HELP

If you need additional support related to Local Management, or if you have any questions, comments, or suggestions concerning this manual, contact Cabletron Systems Technical Support:

By phone (603) 332-9400

A.M

Monday – Friday; 8 By CompuServe GO CTRON from any ! prompt By Internet mail support@ctron.com By FTP ctron.com (134.141.197.25)

anonymous

your email address

Before calling Cabletron Systems Technical Support, have the following information ready:

• A description of the failure

• A description of any action(s) already taken to resolve the problem

(e.g., changing mode switches, rebooting the unit, etc.)

• A description of your network environment (layout, cable type, etc.)

. – 8 P.M. Eastern Time

• Network load and frame size at the time of trouble (if known)

• The serial and revision numbers of all Cabletron Systems products in

the ESXMIM network

• The device history (i.e., have you returned the device before, is this a

recurring problem, etc.)

• Any previous Return Material Authorization (RMA) numbers

1.4 LOCAL MANAGEMENT OVERVIEW

Cabletron Systems Local Management is a management tool that allows a network manager to perform the following tasks:

• Conﬁgure the devices interconnected to form a network

• Monitor the network’s performance

• Control user access to the network and its components for the purpose

of security

ESXMIM/ESXMIM-F2 Local Management Guide Page 1-3

Chapter 1:

Introduction

1.4.1 The Management Agent

The management agent is a process within the ESXMIM which collects statistical information (e.g., frames received, errors detected) about the managed network’s operational performance. Local Management communicates with the management agent for the purpose of viewing statistics or issuing management commands.

1.4.2 In-Band vs. Out-of-Band

Network management systems are often classiﬁed as either in-band or out-of-band. In-band network management passes data along the same medium (cables, frequencies) used by all other stations on the network. An example of an in-band network management system is Cabletron Systems SPECTRUM.

Out-of-band network management passes data along a medium that is entirely separate from the network’s common data carrier, for example, a cable connection between a dumb terminal and the ESXMIM’s COM port. Cabletron Systems Local Management is an out-of-band network management system.

A device connected out-of-band to the management agent is not connected to the LAN. This type of connection allows you to communicate with a network device even when that device is unable to communicate through the network, for example, at the time of installation.

1.4.3 Local vs. Remote Management

Network management applications are usually described as either local or remote management applications. Local management applications reside within the management device’s management agent. Remote management applications run within the circuits of another device that provides management services. This allows you to perform network management from a remote location.

Page 1-4 ESXMIM/ESXMIM-F2 Local Management Guide

Local Management Requirements

1.5 LOCAL MANAGEMENT REQUIREMENTS

The ESXMIM provides two communication ports, labeled COM 1 and COM 2, that support a management terminal connection. To access Local Management, connect one of the following systems to either COM 1 or COM 2:

• Digital Equipment Corporation VT series terminal

• VT type terminal running emulation programs for the Digital

Equipment Corporation VT series

• IBM or compatible PC running a VT series emulation software

package

You can also access Local Management using a Telnet connection through one of the ESXMIM’s network ports.

ESXMIM/ESXMIM-F2 Local Management Guide Page 1-5

Chapter 1:

Introduction

1.6 LOCAL MANAGEMENT SCREEN ELEMENTS

Local Management screens consist of ﬁve basic elements, or ﬁelds. Figure 1-1 shows a Local Management screen and points out the various types of ﬁelds.

EVENT MESSAGE FIELD

DISPLAY FIELDS

SAVED OK

ESXMIM Local Management

System Date:

Host IP Address 000.000.000.000 Subnet Mask 255.255.0.0 Phys Address 00-00-1D-16-26-F8

COM 1 Application: COM 2 Application:

01/23/96

[NONE] [LM]

INPUT FIELDS

SYSTEM LEVEL

SELECTION FIELDS

Flash Image Version XX.XX.XX

System Time:

Out of Band IP Addr 0.0.0.0 Default Gateway NONE DEFINED Default Interface NONE DEFINED

14:23:00

SAVE RETURN

COMMAND FIELDS

Figure 1-1 Sample Local Management Screen

Page 1-6 ESXMIM/ESXMIM-F2 Local Management Guide

Local Management Screen Elements

The following list explains each of the Local Management ﬁelds:

Event Message Field

This ﬁeld brieﬂy displays messages that indicate if a Local Management procedure was executed correctly or incorrectly, that changes were saved or not saved to Non-Volatile Random Access Memory (NVRAM), or that a user did not have access privileges to an application.

Table 1-1 describes the most common event messages. Event messages related to speciﬁc Local Management applications are described with those applications throughout this manual.

Table 1-1 Event Messages

Message What it Means

SAVED OK

NOT SAVED?--PRESS SAVE TO KEEP CHANGES

NOTHING T O SAVE

Display Fields

One or more ﬁelds were modiﬁed, and saved to NVRAM.

Attempting to exit the LM screen after one or more ﬁelds were modiﬁed, but not saved to NVRAM.

The SAVE command was executed, but nothing was saved to NVRAM.

Display ﬁelds cannot be edited. These ﬁelds may display information that never changes, or information that may change as a result of Local Management operations, user selections, or network monitoring information.

Input Fields

Input Fields require the entry of keyboard characters. IP addresses, System Date, and System Time are examples of Input ﬁelds.

Selection Fields

Selection ﬁelds provide a series of possible values. Only applicable v alues appear in a selection ﬁeld.

ESXMIM/ESXMIM-F2 Local Management Guide Page 1-7

Chapter 1:

Introduction

Command Fields

Command ﬁelds are located at the bottom of Local Management screens. Command ﬁelds are used to exit Local Management screens and to save Local Management entries.

1.7 LOCAL MANAGEMENT KEYBOARD CONVENTIONS

All key names appear in this manual as capital letters. For example, the Enter key appears as ENTER, the Escape Key appears as ESC, and the Backspace Key appears as BACKSPACE. Table 1-2 explains the keyboard conventions used in this manual as well as the key functions.

Table 1-2 Keyboard Conventions

Key Function

ENTER and RETURN These are selection keys that perform

the same Local Management function. For example, “Press ENTER” means that you can press either ENTER or RETURN, unless this manual speciﬁcally instructs you otherwise.

ESC This key lets you escape from a Local

Management screen without saving your changes. For example, “Press ESC twice” means that you must quickly press the escape key two times to exit the Local Management screen.

SPACE bar and BACKSPACE These keys cycle through selections

in some Local Management ﬁelds. Use the SPACE bar to cycle forward through selections and use BACKSPACE to cycle backward through selections.

Page 1-8 ESXMIM/ESXMIM-F2 Local Management Guide

Navigating Local Management Screens

Table 1-2 Keyboard Conventions (Continued)

Arrows These are navigation keys. Use the

UP-ARROW, DOWN-ARRROW, LEFT-ARROW, and RIGHT-ARROW keys to move the screen cursor. For example, “Use the arrow keys” means to press whichever arrow key moves the cursor to the desired ﬁeld on the Local Management screen.

[+/=] This key increments values in some

Local Management selection ﬁelds. For example, “Press [ press the plus/equal key.

[–] This key decreases values from some

Local Management selection ﬁelds. For example, “Press [–]” means to press the minus key.

DEL The DEL (Delete) key removes

characters from a Local Management Selection ﬁeld. For example, “Press DEL” means to press the delete key.

+/=

]” means to

1.8 NAVIGATING LOCAL MANAGEMENT SCREENS

To navigate within a Local Management screen, use the arrow keys of the terminal or the workstation providing terminal emulation services. The Local Management screen cursor responds to the LEFT, RIGHT, UP, and DOWN arrow keys. Each time you press an arrow key, the Local Management screen cursor moves to the next available ﬁeld in the direction of the arrow key.

The Local Management screen cursor only moves to ﬁelds which can be selected or used for input. This means that the cursor jumps over display ﬁelds and empty lines on the Local Management screen.

The Local Management screen cursor provides wrap-around operation. This means that a cursor located at the edge of a screen, when moved in the direction of that edge, “wraps around” to the outermost selectable item on the opposite side of the screen which is on the same line or column.

ESXMIM/ESXMIM-F2 Local Management Guide Page 1-9

Chapter 1:

Introduction

Page 1-10 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 2

LOCAL MANAGEMENT REQUIREMENTS

This chapter describes how to attach a Local Management terminal to the Cabletron Systems host device, and lists the setup and conﬁguration requirements for the following equipment:

• Console/terminal

• Console cable

• Console cable connections

2.1 CONFIGURING A LOCAL MANAGEMENT TERMINAL

The following instructions explain how to conﬁgure your management terminal (console) to communicate with Local Management. Refer to your speciﬁc management terminal manual for more instructions if necessary.

To access Local Management, use one of the following systems:

• Digital Equipment Corporation VT series terminal

• VT type terminal running emulation programs for the Digital

Equipment Corporation VT series

• IBM or compatible PC running a VT series emulation software

package

ESXMIM/ESXMIM-F2 Local Management Guide Page 2-1

Chapter 2: Local Management Requirements

2.2 MANAGEMENT T ERMINAL SETUP REQUIREMENTS

Table 2-1 lists the setup parameters for the management terminal. If the management terminal is a Digital Equipment Corporation VT320 or VT220 terminal, press F3 to access the Setup Directory. If the management terminal uses terminal emulation of the VT320, refer to the equipment user manual for setup procedures.

Table 2-1 Terminal Setup Parameters

Menu Function Selection

Display Setup

General Setup

Communications Setup

Keyboard Setup

Columns 80 Columns Controls Interpret Controls Auto Wrap No Auto Wrap Test Cursor Cursor Mode 7 Bit Control Cursor Keys Normal Cursor Keys Transmit Transmit = 9600 Receive Receive = Transmit XOFF any option Bits, Parity 8 Bits, No Parity Stop Bit 1 Stop Bit Local Echo No Local Echo

Port Transmit any option

Auto Answerback No Auto Answerback Auto Repeat any option Keyclick any option Margin Bell Margin Bell Warning Bell Warning Bell Auto Answerback No Auto Answerback

DEC-423, Data Leads Only

Page 2-2 ESXMIM/ESXMIM-F2 Local Management Guide

Management Terminal Setup Requirements

2.2.1 Cable Conﬁguration for the Management T erminal

This section outlines the proper cable conﬁgurations to connect a management terminal to the ESXMIM.

You need an adapter kit containing the following items to connect a terminal to the ESXMIM:

• One RS232 cable

• One VT series adapter

• One device cable The adapter you use depends on whether you connect a VT320 or VT 220

terminal or a PC emulating a VT320 or VT220 to an ESXMIM COM port. Read the information included with the adapter kit to make sure that you are using the correct adapter.

To conﬁgure the cables, perform the following steps:

1. Plug a straight-through twisted pair cable (e.g., an RS232 cable) into the ESXMIM’s COM port.

2. Plug the other end of the RS232 cable into the adapter.

3. Connect the adapter into the device cable and plug the other end of the device cable into the terminal.

4. Power on the terminal. Access to Local Management is automatic. However, because of auto-baud detection, you may need to press ENTER.

ESXMIM/ESXMIM-F2 Local Management Guide Page 2-3

Chapter 2: Local Management Requirements

2.3 ESTABLISHING A TELNET CONNECTION

Once the ESXMIM has a valid IP address, you can establish a Telnet session with Local Management from any TCP/IP based node on the network. Telnet connections to the host device require the community name passwords assigned at the SNMP Community Names screen. Refer to Chapter 5, The SNMP Community Names Screen, for additional information about community names.

NOTE

See the instructions included with the Telnet application for information about establishing a Telnet session.

Page 2-4 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 3

ACCESSING LOCAL MANAGEMENT

This chapter explains how to access and use the Local Management menu screens. Menu screens provide a path to the setup screens, statistic screens, and status screens.

3.1 USING THE MENU SCREENS

Verify that your terminal has been properly connected to the ESXMIM before proceeding.

To access Local Management, perform the following steps:

1. Power on the terminal. The ESXMIM Password screen, Figure 3-1, appears.

ESXMIM Local Management

CABLETRON Systems, Incorporated

Rochester, NH 03867-5005 USA

Flash Image Version:

BOOTPROM Version:

Board Revision: X.X

Enter Password:

P.O. Box 5005

(603) 332-9400

XX.XX.XX XX.XX.XX

Figure 3-1 The ESXMIM Password Screen

ESXMIM/ESXMIM-F2 Local Management Guide Page 3-1

Chapter 3: Accessing Local Management

2. Enter your password and press ENTER. The default super-user access password is “public” or press ENTER.

NOTE

Your password is one of the community names speciﬁed in the SNMP Community Names screen. Access to certain Local Management capabilities depends on the degree of access accorded that community name. See Chapter 5, The SNMP Community Names Screen for more information on community names.

• If you enter an inv alid password, the cursor returns to the beginning of the password entry ﬁeld.

• If you enter a valid password, the associated access level displays at the bottom of the screen and the Main Menu screen, Figure 3-3, appears.

• If no activity occurs for sev eral minutes the Password screen reappears indicating that you must re-enter the password.

3.2 NAVIGATING LOCAL MANAGEMENT SCREENS

Local Management consists of a series of menu screens that provide a path to each of the Local Management function screens. You navigate through Local Management by selecting items from the menu screens. ESXMIM Local Management consists of the following menu screens:

• Main Menu screen

• Setup Menu screen

• Status Menu screen

• Statistics Menu screen

Figure 3-2 shows the hierarchy of Local Management screens.

Page 3-2 ESXMIM/ESXMIM-F2 Local Management Guide

Navigating Local Management Screens

System Level

Setup Menu

Main MenuPassword

Status Menu

SNMPCommunity Names SNMP Traps Flash Download Bridge Setup

Device Specific

Component Status

Statistics Menu

MIB Navigator

MIB-2 Statistics

Figure 3-2 Hierarchy of Local Management Screens

3.2.1 Selecting Local Management Menu Screen Items

To select items on a Local Management menu screen, perform the following steps:

1. Use the arrow keys to highlight a menu item.

2. Press ENTER. The selected Local Management menu screen appears.

ESXMIM/ESXMIM-F2 Local Management Guide Page 3-3

Chapter 3: Accessing Local Management

3.2.2 Exiting Local Management Screens

To exit any of the Local Management screens, perform the following steps:

1. Use the arrow keys to highlight the RETURN command at the bottom of the Local Management screen.

2. Press ENTER. The previous screen in the Local Management hierarchy appears.

NOTE

You can also exit Local Management screens by pressing ESC twice. This exit method does not warn you about unsaved changes and all unsaved changes will be lost.

3.2.3 Exiting the Local Management Session

To exit from ESXMIM Local Management, perform the following steps:

1. Use the arrow keys to highlight the RETURN command at the bottom of the Local Management screen.

2. Press ENTER. The previous screen in the Local Management hierarchy appears.

3. Repeat steps 1 and 2 until the Main Menu screen appears.

4. Use the arrow keys to highlight the EXIT command at the bottom of the Main Menu screen.

5. Press ENTER. The ESXMIM Local Management Password screen appears and the Local Management session ends.

Page 3-4 ESXMIM/ESXMIM-F2 Local Management Guide

The Main Menu Screen

3.3 THE MAIN MENU SCREEN

The Main Menu screen is the starting point from which all the Local Management screens are accessed. Figure 3-3 shows the Main Menu screen.

Event Message Line

ESXMIM Local Management

MAIN MENU

SETUP MENU

STATUS MENU

STATISTICS MENU

MIB NAVIGATOR

Flash Image Version: XX.XX.XX

EXIT

Figure 3-3 The Main Menu Screen

The Main Menu screen displays the following menu items:

• Setup Menu – The Setup Menu provides access to Local Management

screens that are used to conﬁgure the ESXMIM.

• Status Menu – The Status Menu provides access to the Component

Status screen which displays the operational and administrative status of ESXMIM MIB components.

• Statistics Menu – The Statistics Menu provides bridge statistics and

performance information for the switch interfaces of the ESXMIM.

ESXMIM/ESXMIM-F2 Local Management Guide Page 3-5

Chapter 3: Accessing Local Management

• MIB Navigator – The MIB Navigator is a Local Management utility which allows the user to access, monitor , and set speciﬁc Management Information Base (MIB) items within the ESXMIM.

3.4 THE SETUP MENU SCREEN

The Setup Menu provides access to Local Management screens that are used to conﬁgure or alter the conﬁguration of the ESXMIM. Examples of functions accessible through the Setup Menu include conﬁguring the host IP address and subnet mask, assigning SNMP community names, and conﬁguring SNMP trap notiﬁcation. Figure 3-4 shows the Setup Menu.

Event Message Line

ESXMIM Local Management

SETUP MENU

SYSTEM LEVEL

SNMP COMMUNITY NAMES

SNMP TRAPS

Flash Image Version XX.XX.XX

FLASH DOWNLOAD

BRIDGE SETUP

DEVICE SPECIFIC SETUP

RETURN

Figure 3-4 The Setup Menu Screen

Page 3-6 ESXMIM/ESXMIM-F2 Local Management Guide

The Setup Menu Screen

The Setup Menu displays the following menu items:

• System Level – The System Level Setup screen allows you to

conﬁgure basic operating parameters for the ESXMIM.

• SNMP Community Names – The SNMP Community Names Setup

screen allows you to change or review the community names used as access passwords for local management operation.

• SNMP Traps – The SNMP Traps Setup screen provides display and

conﬁguration access to the table of IP addresses used for trap destinations and associated community names.

• FLASH Download – The FLASH Download setup screen allo ws you

to conﬁgure the ESXMIM for a download of new ﬁrmware and perform the download operations.

• Bridge Setup – The Bridge setup screen allows you to select a

Spanning Tree method for the ESXMIM bridging operations and enable or disable individual bridge ports.

• Device Specific Setup – The Device Specific setup screen allows you

to set the connection method (backplane or front panel) used for interface 1 of the ESXMIM.

ESXMIM/ESXMIM-F2 Local Management Guide Page 3-7

Chapter 3: Accessing Local Management

3.5 THE STATUS MENU SCREEN

Figure 3-5 shows the Status Menu screen. The Status Menu screen provides access to the Chassis Status screen and Component Status screen.

NOTE

The ESXMIM does not use the Chassis Status screen.

Event Message Line

ESXMIM Local Management

Flash Image Version: XX.XX.XX

STATUS MENU

CHASSIS STATUS

COMPONENT STATUS

RETURN

Figure 3-5 The Status Menu Screen

Page 3-8 ESXMIM/ESXMIM-F2 Local Management Guide

The Statistics Menu Screen

3.6 THE STATISTICS MENU SCREEN

Figure 3-6 shows the Statistics Menu screen. The Statistics Menu screen provides access to the MIB-2 Statistics screen.

Event Message Line

ESXMIM Local Management

STATISTICS MENU

MIB-2 STATISTICS

Flash Image Version: XX.XX.XX

RETURN

Figure 3-6 The Statistics Menu Screen

ESXMIM/ESXMIM-F2 Local Management Guide Page 3-9

Chapter 3: Accessing Local Management

Page 3-10 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 4

THE SYSTEM LEVEL SCREEN

This chapter explains how to use the System Level screen to set the following parameters:

System Date System Time Host IP Address Subnet Mask Default Interface Default Gateway COM 1 Port Application COM 2 Port Application

4.1 SYSTEM LEVEL SCREEN FIELDS

Figure 4-1 shows the ESXMIM System Level screen.

Event Message Line

ESXMIM Local Management

SYSTEM LEVEL

Flash Image Version XX.XX.XX

System Date:

Host IP Address 000.000.000.000 Subnet Mask 255.255.0.0 Phys Address 00-00-1D-16-26-F8

COM 1 Application: COM 2 Application:

Field Sensitive Help Line

12/30/95

[NONE] [LM]

SAVE RETURN

Default Gateway NONE DEFINED Default Interface NONE DEFINED

14:23:00System Time:

Figure 4-1 The System Level Screen

ESXMIM/ESXMIM-F2 Local Management Guide Page 4-1

Chapter 4: The System Level Screen

The following deﬁnitions explain each System Level screen ﬁeld.

System Date

Use this ﬁeld to enter the system date.

System Time

Use this ﬁeld to enter the system time.

Host IP Address

Use this ﬁeld to enter the IP address of the ESXMIM.

Subnet Mask

Use this ﬁeld to enter the subnet mask for the ESXMIM. Subnets are logical divisions of the network that isolate groups of devices.

NOTE

Default Gateway

The subnet mask will default to a standard Class A, B, or C subnet mask depending upon the IP address Class of the entry in the Host IP Address ﬁeld. This default subnet mask may be modiﬁed if needed.

Use this ﬁeld to enter the default gateway for the ESXMIM. The default gateway is the IP address of the network device (gateway or router) used to forward SNMP traps to a management station. The default setting for this ﬁeld is NONE DEFINED.

Phys Address

This ﬁeld displays the physical MAC address of the ESXMIM. You cannot modify the physical address.

Default Interface

Use this ﬁeld to select the default interface for the ESXMIM’s default gateway. The default interface is the channel that is set up to handle message trafﬁc to the default gateway. The default setting for this ﬁeld is NONE DEFINED.

COM 1 Application

Use this ﬁeld to select the communication port’s application. The available setting for this ﬁeld is LM.

Page 4-2 ESXMIM/ESXMIM-F2 Local Management Guide

Setting the System Date

COM 2 Application

Use this ﬁeld to select the communication port’s application. The available setting for this ﬁeld is LM.

4.2 SETTING THE SYSTEM DATE

To set the system date, perform the following steps:

1. Use the arrow keys to highlight the System Date field.

2. Enter the date in a MM/DD/YY format.

NOTE

When entering the date in the system date ﬁeld, you do not need to add separators between month, day, and year numbers, as long as each entry uses two decimal numbers. For example, to set the date to 03/17/96, type “031796” in the System Date ﬁeld.

3. Press ENTER to set the system calendar.

4. Use the arrow keys to highlight the SAVE command field at the

bottom of the screen and press ENTER. If the date entered was a valid format, the Event Message field at the

top of the screen displays “SAVED OK”. If the entry was not valid, Local Management does not alter the current value and refreshes the System Date field with the previous value.

4.3 SETTING THE SYSTEM TIME

To set the system clock, perform the following steps:

1. Use the arrow keys to highlight the System Time field.

2. Enter the time in a 24-hour format, HH:MM:SS.

NOTE

When entering the time in the system time ﬁeld, you do not need to add separators between hours, minutes, and seconds , as long as each entry uses two decimal numbers. F or e xample , to set the time to 6:45 AM, type “064500” in the System Time ﬁeld.

ESXMIM/ESXMIM-F2 Local Management Guide Page 4-3

Chapter 4: The System Level Screen

3. Press ENTER to set the system clock.

4. Use the arrow keys to highlight the SAVE command field at the bottom of the screen and press ENTER.

If the time entered was a valid format, the Event Message field at the top of the screen displays “SAVED OK”. If the entry was not valid, Local Management does not alter the current value and refreshes the System Time field with the previous value.

4.4 SETTING THE HOST IP ADDRESS

To set the host IP address, perform the following steps:

1. Use the arrow keys to highlight the Host IP Address field.

2. Enter the IP address using Decimal Dotted Notation (DDN) format. For example: 134.141.25.17

3. Press ENTER. If the IP address entered was a valid format, the cursor returns to the beginning of the Host IP Address field. If the entry was not valid, the Event Message field displays “INVALID IP ADDRESS OR FORMAT ENTERED”. Local Management does not alter the current value and refreshes the Host IP Address field with the previous value.

4. Use the arrow keys to highlight the SAVE command field.

NOTE

Changing the ESXMIM IP address requires a reset of the module. LM will automatically reset the ESXMIM, which will go through startup operations before bridging will resume.

5. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”. This message flashes briefly, then the Event Message line will display “System Reboot in Progress...”. Local Management will be terminated and the screen will freeze while the ESXMIM resets.

Page 4-4 ESXMIM/ESXMIM-F2 Local Management Guide

Setting the Subnet Mask

NOTE

After the ESXMIM resets, the Password Screen appears and you must re-enter Local Management.

4.5 SETTING THE SUBNET MASK

Subnets are logical divisions of the network. To change the subnet mask from its default value, perform the following steps:

1. Use the arrow keys to highlight the Subnet Mask field.

2. Enter the subnet mask using DDN format. Values for each decimal

must range from 0-255. For example: 255.255.0.0

3. Press ENTER. If the subnet mask entered was a valid format, the

cursor returns to the beginning of the Subnet Mask field. If the entry was not valid, the Event Message field displays “INVALID SUBNET MASK OR FORMAT ENTERED”. Local Management does not alter the current value and refreshes the Subnet Mask field with the previous value.

4. Use the arrow keys to highlight the SAVE command field.

5. Press ENTER. The Event Message field at the top of the screen

displays “SAVED OK”.

ESXMIM/ESXMIM-F2 Local Management Guide Page 4-5

Chapter 4: The System Level Screen

4.6 SETTING THE DEFAULT GATEWAY

To set the default gateway, perform the following steps:

1. Use the arrow keys to highlight the Default Gateway field.

2. Enter the IP address of the default gateway using DDN format. For example: 134.141.79.121

3. Press ENTER. If the default gateway entered was a valid format, the cursor returns to the beginning of the Default Gateway field. If the entry was not valid, the Event Message field displays “INVALID DEFAULT GATEWAY OR FORMAT ENTERED”. Local Management does not alter the current value and refreshes the Default Gateway field with the previous value.

4. Use the arrow keys to highlight the SAVE command field.

5. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

4.7 SETTING THE DEFAULT INTERFACE

To set the default interface, perform the following steps:

NOTE

Before setting a default interface you need to assign a default gateway.

1. Use the arrow keys to highlight the Default Interface field.

2. Enter the interface number for the default gateway in this field.

3. Press ENTER. If the interface entered was a valid format, the cursor returns to the beginning of the Default Interface field. If the entry was not valid, the Event Message field displays “PERMISSIBLE RANGE:

1...1”. Local Management does not alter the current value and refreshes the Default Interface field with the previous value.

4. Use the arrow keys to highlight the SAVE command field.

5. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

Page 4-6 ESXMIM/ESXMIM-F2 Local Management Guide

COM Port Applications

4.8 COM PORT APPLICATIONS

The ESXMIM communication ports support the following application:

NOTE

Refer to the Release Notes included with the ESXMIM to verify which communication port applications are currently supported.

• Cabletron Systems Local Management connections

ESXMIM/ESXMIM-F2 Local Management Guide Page 4-7

Chapter 4: The System Level Screen

Page 4-8 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 5

THE SNMP COMMUNITY NAMES SCREEN

This chapter explains how to assign community names. Community names allow you to control Local Management access by establishing three passwords. Each password controls varying levels of access to ESXMIM Local Management. Figure 5-1 shows the SNMP Community Names screen.

Event Message Line

ESXMIM Local Management

SNMP COMMUNITY NAMES

Flash Image Version: XX.XX.XX

Community Name

public

public public

SAVE RETURN

Access Policy

read-only read-write super-user

Figure 5-1 The SNMP Community Names Screen

5.1 COMMUNITY NAME ACCESS POLICY

In order to perform any operations on the SNMP Community Names screen, you must have used the super-user community name at the User Password prompt when initiating the Local Management session. The default community name for each access level is public or press ENTER.

ESXMIM/ESXMIM-F2 Local Management Guide Page 5-1

Chapter 5: The SNMP Community Names Screen

The following deﬁnitions explain each of the three levels of access:

read-only

This access level allo ws reading of de vice parameters including read-only community names.

read-write

This access level allows the reading of parameters and the read-only and read-write community names. The read-write access level also allows the editing of some device parameters, not including community names.

super-user

This access level allows full management privileges.

5.2 SETTING SNMP COMMUNITY NAMES

To set a community name, perform the following steps:

1. Use the arrow keys to highlight the community name you want to change.

2. Type the new community name and press ENTER. The old community name text disappears and is replaced by the new community name.

3. Use the arrow keys to highlight the SAVE command field.

4. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

If you edit the super-user community name, be certain you do not forget it. If you do, you will be unable to perform Local

CAUTION

Page 5-2 ESXMIM/ESXMIM-F2 Local Management Guide

Management functions without returning the local management community names to their factory default conﬁgurations. This will require changing a mode switch setting and restarting the ESXMIM.

CHAPTER 6

THE SNMP TRAPS SCREEN

This chapter explains how to conﬁgure the SNMP Traps screen to allow the ESXMIM to send traps to as many as eight remote management workstations. SNMP traps are messages about network events and device operational statistics. The following sections explain SNMP Trap screen ﬁelds and instructions for conﬁguring them. Figure 6-1 shows the SNMP Traps screen.

Event Message Line

ESXMIM Local Management

0.0.0.0

SNMP TRAPS

Trap Community NameTrap Destination Enable Traps

public public public public public public public public

Flash Image Version: XX.XX.XX

[NO] [NO] [NO] [NO] [NO] [NO] [NO] [NO]

SAVE

RETURN

Figure 6-1 The SNMP Traps Screen

6.1 TRAP TABLE SCREEN FIELDS

The following deﬁnitions explain each of the SNMP Traps screen ﬁelds:

Trap Destination

Use this ﬁeld to enter the IP address of the management workstation designated to receive SNMP traps from the ESXMIM.

ESXMIM/ESXMIM-F2 Local Management Guide Page 6-1

Chapter 6: The SNMP Traps Screen

Trap Community Name

This ﬁeld allows you to enter the community name which provides the desired level of trap access for the management workstation in question. Some SNMP traps may not be available to stations which are given read-only or read-write access to the SNMP MIB.

Enable T raps

Use this ﬁeld to enable the transmission of SNMP traps to the management workstation.

6.2 SETTING THE SNMP TRAP DESTINATION

Each management workstation designated to receive SNMP traps from the ESXMIM must have a valid IP address and community name. To set and enable SNMP trap destination, perform the following steps:

1. Use the arrow keys to highlight the Trap Destination field you want to modify.

2. Type the IP address of the management workstation designated to receive SNMP traps from the ESXMIM. This address must be entered in DDN format.

For example: 134.141.25.17

3. Press ENTER.

4. Use the arrow keys to highlight the Trap Community Name field (on the same row as the Trap Destination field).

5. Type the community name to be used by the management workstation.

6. Press ENTER.

7. Use the arrow keys to highlight the Enable Traps field (on the same row as the Trap Destination and Trap Community Name you have just configured). The default setting for this field is NO.

8. Press SPACE bar or BACKSPACE to set the field to YES.

9. Use the arrow keys to highlight the SAVE command field.

10. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

Page 6-2 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 7

THE FLASH DOWNLOAD SCREEN

This chapter explains how to use the FLASH Download screen to download a ﬁrmware image from a TFTP server to the ESXMIM. Figure 7-1 shows the FLASH Download screen.

NOTE

Event Message Line

ESXMIM Local Management

download ﬁle and a properly conﬁgured download server.

Flash Image Version: XX.XX.XX

FLASH DOWNLOAD

Download Method:

Reboot After Download:

Last Image Server IP:

Last Image File Name:

Download Server IP:

Download File Name:

TFTP Gateway Server IP: 0.0.0.0

EXECUTE RETURN

This section appears only if BOOTPROM is selected as Download Method.

[RUNTIME]

[YES]

0.0.0.0

c:\tftpboot\f2_proxy.hex

0.0.0.0

c:\tftpboot\f2_proxy.hex

FLASH download operations require a properly named

Figure 7-1 The FLASH Download Screen

ESXMIM/ESXMIM-F2 Local Management Guide Page 7-1

Chapter 7: The FLASH Download Screen

7.1 SELECTING A FLASH DOWNLOAD METHOD

1. Use the arrow keys to highlight the Download Method field.

2. Press SPACE bar or BACKSPACE to select a flash download method.

• If you select RUNTIME, the Reboot After Download ﬁeld

appears.

• If you select BOOTPROM, the Commit to Flash ﬁeld and the

TFTP Gateway Server IP field appears.

7.1.1 BootPROM Download

If you select a BootPROM download, perform the following steps:

1. Use the arrow keys to highlight the Commit to Flash field.

2. Use the SPACE bar or BACKSPACE to select one of the following:

• YES, if you want the ESXMIM to copy the ﬁrmware image to

FLASH memory once the download has been completed.

• NO, if you want the ESXMIM to continue operating without

updating the ﬁrmware image currently stored in FLASH memory . If the ESXMIM is reset or restarted, it will start up from the previous ﬁrmware image which is contained in FLASH memory, discarding the downloaded ﬁrmware in LDRAM.

3. Use the arrow keys to highlight the DDN Format IP Address next to the TFTP Gateway Server IP field.

4. Enter the IP address of the TFTP gateway server.

Page 7-2 ESXMIM/ESXMIM-F2 Local Management Guide

Selecting a FLASH Download Server

7.1.2 Runtime Download

If you select Runtime download, perform the following steps:

1. Use the arrow keys to highlight the Reboot After Download field.

2. Use the SPACE bar or BACKSPACE to select one of the following:

• YES, if you want the ESXMIM to reboot and use the new

ﬁrmware image immediately.

• NO, if you want the ESXMIM to continue using the existing

ﬁrmware image without interrupting network operation. The ESXMIM stores the new ﬁrmware image in FLASH memory. When you reset the ESXMIM, it boots from FLASH memory using the new image.

7.2 SELECTING A FLASH DOWNLOAD SERVER

Directly below the Download Method and Reboot After Download/ Commit to Flash toggle ﬁelds are the Download Server and Download File display and input ﬁelds. The Download Server input ﬁeld contains

the IP address of the server that the ESXMIM will request a ﬁrmware image from. By default, the Download Server ﬁeld will display the last IP address used for a ﬁrmware download. If the same server is to be used to perform the current download, no changes need to be made to the Download Server input ﬁeld.

The Download File input ﬁeld contains the ﬁle name of the ﬁrmware image to be downloaded and the access path used to locate it on the server. By default, the Download File input ﬁeld will display the last ﬁrmware image ﬁlename and path used to perform a download to this ESXMIM. If there have been no changes to the server or the ﬁle name and path, these defaults can be used without changes being required.

ESXMIM/ESXMIM-F2 Local Management Guide Page 7-3

Chapter 7: The FLASH Download Screen

7.2.1 Changing the Download Server IP

To change the IP address of the FLASH Download server, perform the following steps:

1. Use the arrow keys to highlight the DOWNLOAD SERVER IP field.

2. Type the IP address of the server to be used for the download.

3. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

7.2.2 Changing the Download File Name

To change the name of the ﬁrmware image ﬁle that Local Management loads from the FLASH Download server, perform the following steps:

1. User the arrow keys to highlight the DOWNLOAD FILE NAME field.

2. Type the complete path and filename of the new image file to be downloaded. You must include all directories and subdirectories involved in accessing the file. Type the new entry over the previous entry.

3. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

7.3 PERFORMING A FLASH DOWNLOAD OPERATION

To perform a FLASH download using either method, perform the following steps:

1. Use the arrow keys to highlight the EXECUTE command field located at the bottom of the FLASH Download screen.

2. Press ENTER to begin the download. The ESXMIM attempts to download the file using the IP address, filename, and path provided. This file is assigned to the FLASH memory of the ESXMIM.

Page 7-4 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 8

THE BRIDGE SETUP SCREEN

This chapter explains how to use the Bridge Setup screen to select a Spanning Tree protocol and enable/disable bridge ports. Figure 8-1 shows the Bridge Setup screen.

Event Message Line

ESXMIM Local Management

BRIDGE SETUP

Flash Image Version: XX.XX.XX

SPANNING TREE PROTOCOL:

BRIDGE PORT ADMIN STATUS:

BRIDGE PORT PAIR ADMIN STATUS:

SAVE

Figure 8-1 The Bridge Setup Screen

[IEEE 802.1]

PORT XX --> ALL PORTS

PORT XX --> PORT [YY]

[BRIDGE_PORT XX] RETURN

[ENABLED]

ESXMIM/ESXMIM-F2 Local Management Guide Page 8-1

Chapter 8: The Bridge Setup Screen

8.1 BRIDGE SETUP SCREEN FIELDS

The following list describes each of the Bridge Setup screen ﬁelds:

Spanning T ree Protocol

Use this ﬁeld to select a spanning tree protocol. Possible selections for this ﬁeld are IEEE 802.1, DEC, or NONE.

Bridge Port Admin Status

Use this ﬁeld to enable or disable individual ESXMIM bridge ports. Possible selections for this ﬁeld are ENABLED or DISABLED.

Bridge Port Pair Admin Status

Use this ﬁeld to enable or disable bridging between bridge port pairs. For example, you can enable Port 1 to bridge trafﬁc to all ports except Port 2.

Bridge_Port

Use this command ﬁeld to select the ESXMIM bridge port you want to conﬁgure.

8.2 SELECTING A SPANNING TREE PROTOCOL

T o select the Spanning T ree protocol to be used by the bridge, perform the following steps:

1. Use the arrow keys to highlight the SPANNING TREE PROTOCOL field.

2. Press SPACE bar or BACKSPACE to select [IEEE 802.1], [DEC], or [NONE].

3. Use the arrow keys to highlight the SAVE command field.

4. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

Page 8-2 ESXMIM/ESXMIM-F2 Local Management Guide

Selecting the Port Administrative Status

8.3 SELECTING THE PORT ADMINISTRATIVE STATUS

To select the bridge port administrative status, perform the following steps:

1. Use the arrow keys to highlight the [BRIDGE_PORT X] field.

2. Press SPACE bar or BACKSPACE to select the bridge port you want

to configure. The selected bridge port appears in the Bridge Port Admin Status field.

3. Use the arrow keys to highlight the BRIDGE PORT ADMIN

STATUS: PORT XX - - > ALL PORTS [ENABLED] field.

4. Press SPACE bar or BACKSPACE to select ENABLE or DISABLE.

For example, the following bridge setup indicates that bridge port 01 is configured to bridge traffic to all ports:

BRIDGE PORT ADMIN STATUS: PORT 01 - - > ALL PORTS

[ENABLED]

5. Use the arrow keys to highlight the SAVE command field.

6. Press ENTER. The Event Message field at the top of the screen

displays “SAVED OK”.

ESXMIM/ESXMIM-F2 Local Management Guide Page 8-3

Chapter 8: The Bridge Setup Screen

8.4 SELECTING BRIDGE PORT PAIR

ADMINISTRATIVE STATUS

To select the bridge port pair administrative status, perform the following steps:

1. Use the arrow keys to highlight the [BRIDGE_PORT XX] field.

2. Press SPACE bar or BACKSPACE to select the bridge port you want to configure. The selected bridge port appears in the Bridge Port Pair Admin Status field.

3. Use the arrow keys to highlight the BRIDGE PORT PAIR ADMIN STATUS: PORT XX - -> PORT [YY] field.

4. Press SPACE bar or BACKSPACE to select the port you want to enable or disable bridge traffic.

5. Use the arrow keys to highlight the BRIDGE PORT PAIR ADMIN STATUS: PORT XX - -> PORT [YY] [ENABLED] field.

6. Press SPACE bar or BACKSPACE to select ENABLE or DISABLE. For example, the following bridge setup indicates that bridge port 01

is configured NOT to bridge traffic to bridge port 02: BRIDGE PORT PAIR ADMIN STATUS: PORT 01 - - > PORT [02]

[DISABLED]

7. Use the arrow keys to highlight the SAVE command field.

8. Press ENTER. The Event Message field at the top of the screen displays “SAVED OK”.

Page 8-4 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 9

THE MODULE SPECIFIC SETUP SCREEN

This chapter explains how to use the Module (Device) Speciﬁc Setup screen to modify the operation of the ESXMIM. The ESXMIM Module Speciﬁc Setup screen is shown in Figure 9-1.

Event Message Line

ESXMIM Local Management

MODULE SPECIFIC SETUP

Interface 1: MMAC CHANNEL A

Flash Image Version XX.XX.XX

Field Sensitive Help Line

RETURN

Figure 9-1 The Module Speciﬁc Setup Screen

ESXMIM/ESXMIM-F2 Local Management Guide Page 9-1

Chapter 9: The Module Speciﬁc Setup Screen

9.1 DEVICE SPECIFIC SETUP SCREEN FIELDS

The following list describes each of the Device Speciﬁc Setup screen ﬁelds:

Interface 1

This ﬁeld displays the current connection status of the ESXMIM Interface

1. Interface 1 may be assigned to either the MMAC backplane Ethernet

Channel A or to the front panel ESXMIM port 1.

9.2 SELECTING INTERFACE 1 CONNECTION STATUS

To select the connection method that will be used by ESXMIM interface 1, perform the following steps:

1. Use the arrow keys to highlight the selection field next to the Interface 1 display field. The default value for this field is MMAC CHANNEL A

2. Press ENTER to toggle between the two connection method options available for Interface 1; MMAC CHANNEL A or FRONT PANEL.

NOTE

The ESXMIM will only allow the default connection status to be altered if an Ethernet link is detected on front panel port 1.

3. The ESXMIM will immediately switch to the connection method displayed next to the Interface 1 field.

Page 9-2 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 10

THE COMPONENT STATUS SCREEN

Figure 10-1 shows the Component Status screen. The Component Status screen monitors the status of the MIB Components of the ESXMIM.

Event Message Line

ESXMIM Local Management

COMPONENT STATUS

Component Name Admin. Status

Flash Image Version: XX.XX.XX

ESXMIM Chassis MGR ESXMIM LIM ESXMIM Host Services ESXMIM IP Services ESXMIM Distributed LAN Monitor ESXMIM MIB Navigator ESXMIM RMON Default ESXMIM Transparent Bridge

enabled enabled enabled enabled enabled enabled disabled enabled

RETURN

Figure 10-1 The Component Status Screen

The Component Status table lists the administrative status (Admin. Status) of the ESXMIM’s MIB Components. The Admin. Status ﬁeld displays two states: Enabled and Disabled. Figure 10-1 shows the Component Status Screen.

ESXMIM/ESXMIM-F2 Local Management Guide Page 10-1

Chapter 10: The Component Status Screen

Page 10-2 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 11

THE INTERFACE STATISTICS SCREEN

Figure 11-1 shows the Interface (MIB-2) Statistics screen. The Interface Statistics screen displays error, collision, and traf ﬁc statistics for speciﬁed ESXMIM interfaces.

INTERFACE STATISTICS

IN OCTETS:

IN UNICAST PKTS:

IN NONUCAST PKTS:

IN DISCARDS:

IN ERRORS:

OUT OCTETS:

OUT UNICAST PKTS:

OUT NONUCAST PKTS:

OUT DISCARDS:

OUT ERRORS:

CLEAR COUNTERS

Figure 11-1 The Interface Statistics Screen

INTERFACE: 1 INTERFACE: 2 INTERFACE: 3

0 0 0 0 0

0 0 0

0 0

0 0 0 0 0

0 0 0

0 0

RETURNINTFACE 1 INTFACE 2 INTFACE 3UPDATE-FREQ 3 Sec

0 0 0 0 0

0 0 0

0 0

ESXMIM/ESXMIM-F2 Local Management Guide Page 11-1

Chapter 11: The Interface Statistics Screen

11.1 INTERFACE STATISTICS SCREEN FIELDS

The following list describes the Interface Statistics screen ﬁelds:

In Octets

This ﬁeld displays the number of octets (bytes) received by the interface.

In Unicast Pkts

This ﬁeld displays the number of unicast packets (packets destined for one speciﬁc address) received on the interface.

In Nonucast Pkts

This ﬁeld displays the number of non-unicast packets (multicast and broadcast packets; packets destined for more than one address) received by the interface.

In Discards

This ﬁeld displays the total number of packets discarded by the interface due to a lack of available resources.

NOTE

In Errors

For interface 7, the BRIM port, the In Discards ﬁeld displays the number of times the ESXMIM had to discard packets - any number of packets - received on the interface.

This ﬁeld displays the total number of errors received on the interface. The number displayed in the In Errors display ﬁeld can be composed of the following errors:

• Out Of W indow (OO W) collisions - Collisions caused by a station

on the network violating Carrier Sense and transmitting at will, a cable failure occurring during the transmission of a packet, or network propagation delay greater than 51.2 µs.

• Cyclical Redundancy Check (CRC) errors - Errors in the 4-byte

CRC ﬁeld of a packet which ensures that the data received by the ESXMIM is the same as the data transmitted by the originating device.

Page 11-2 ESXMIM/ESXMIM-F2 Local Management Guide

Interface Statistics Screen Fields

• Alignment Errors - Alignment errors are packets that are misaligned. A misaligned packet is one that contains a non-integral number of bytes.

• Runt Packets - Runt packets are packets smaller than the minimum Ethernet frame size of 64 bytes, not including preamble.

• Giant Packets - Giant packets are those whose size exceeds the maximum Ethernet frame size of 1,518 bytes, not including preamble.

NOTE

Out Octets

A complete breakdown of In Errors may be obtained from the ESXMIM RMON MIB. Refer to your remote management package documentation for instructions on how to obtain this breakdown.

This ﬁeld displays the number of octets (bytes) transmitted by the interface.

Out Unicast Pkts

This ﬁeld displays the number of unicast packets (packets destined for one speciﬁc address) transmitted by the interface.

Out Nonucast

This ﬁeld displays the number of non-unicast packets (multicast and broadcast packets – packets destined for more than one address) transmitted by the interface.

Out Discards

This ﬁeld displays the total number of packets discarded by the interface due to a lack of available resources.

Out Errors

This ﬁeld displays the total number of errors for a given interface.

Update-Freq

Use this ﬁeld to select the time interval between Network/Slot/Port counter updates. You can select update intervals in increments of 3 seconds, with the maximum interval being 99 seconds.

ESXMIM/ESXMIM-F2 Local Management Guide Page 11-3

Chapter 11: The Interface Statistics Screen

Interface

This command ﬁeld allows you to select the interface(s) you want to monitor.

11.2 SELECTING AN UPDATE-FREQ

The ESXMIM updates the Interface Statistics screen every three seconds by default. The UPDATE-FREQ command allows you to adjust the frequency in intervals of 3 seconds. The maximum update frequenc y is 99 seconds.

To adjust the UPDATE-FREQ, perform the following steps:

1. Use the arrow keys to highlight the UPDATE-FREQ command field.

2. Press [+/=] or [–] until the desired time/frequency appears (this number increments/decrements in 3-second intervals with a minimum of 3 seconds and a maximum of 99 seconds).

3. Press ENTER.

11.3 CLEARING STATISTICS COUNTERS

The ESXMIM provides a mechanism for resetting the statistics counter displays for all interfaces to zero. To clear counters, perform the following steps:

NOTE

Local Management does not ask for veriﬁcation bef ore clearing counters. Initiating this command will clear the counters immediately.

1. Use the arrow keys to highlight the CLEAR COUNTERS command field.

2. Press ENTER. All counters will be reset to zero and be updated after the current UPDATE-FREQ has passed.

Page 11-4 ESXMIM/ESXMIM-F2 Local Management Guide

Selecting an Interface

11.4 SELECTING AN INTERFACE

When the Interface Statistics Screen ﬁrst appears, statistics are displayed for Interface 1, Interface 2, and Interface 3. To view statistics for other interfaces, use the INTFACE X command ﬁelds at the bottom of the screen.

To select an interface to monitor, perform the following steps:

1. Use the arrow keys to highlight the INTFACE X command field.

2. Press [+/=] or [–] until the desired interface number appears.

3. Press ENTER. Statistics associated with the selected interface appear.

ESXMIM/ESXMIM-F2 Local Management Guide Page 11-5

Chapter 11: The Interface Statistics Screen

Page 11-6 ESXMIM/ESXMIM-F2 Local Management Guide

CHAPTER 12

THE MIB NAVIGATOR SCREEN

This chapter explains how to use the MIB Navigator utility. The MIB Navigator allows access to a command set from which you can conﬁgure and manage the ESXMIM. Figure 12-1 shows the MIB Navigator screen.

NOTE

Event Message Line

MIBNav-> help

MIBNav->

presented after the user entered the ‘help’ command.

Welcome to Cabletron ESXMIM Revision XX.XX.XX

Commands Available to the User:

arp ctron done help netstat pwd show snmpset traceroute

SPECIAL:

done, quit, or exit - Exit from the MIB Navigator. mib2 - Change MIB directory to MIB II (1.3.6.1.2.1). ctron - Change MIB directory to cabletron (1.3.6.1.4.1.52).

For help with a specific command, type 'help <command>'.

branch defroute exit ls next quit snmpbranch snmptree tree

cd dir get mib2 ping set snmpget su whoami

Figure 12-1 shows the MIB Navigator screen that would be

Figure 12-1 The MIB Navigator Screen

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-1

Chapter 12: The MIB Navigator Screen

12.1 MANAGING DEVICE MIBS

The MIB Navigator lets you manage objects in the ESXMIM’s Management Information Bases (MIBs). MIBs are databases of objects used for managing the device and determining the ESXMIM’s conﬁguration. The commands within the MIB Navigator allow you to view and modify a device’s objects.

The MIB Navigator views the MIB tree hierarchy as a directory. Figure 12-2 shows the MIB tree hierarchy. Each layer is numerically encoded, so that every branch group and leaf object in the MIB is identiﬁed by a corresponding number, known as an Object Identiﬁer (OID). This allows the MIB Navigator to navigate through the MIB and access the manageable leaf objects.

Object 1.1.1 Object 1.1.2

Object 1.2.1 Object 1.2.2

Object 1.3.1 Object 1.3.2

Root 1

Group 1.1 Group 1.2

Group 1.3

Figure 12-2 Hierarchical MIB Tree Structure

Often an ASCII name is assigned to a leaf object’s OID, making it more readable. To identify the value for the object “ip Forwarding” you would use the OID (/1/3/6/1/2/1/4/1), or its ASCII name (/iso/org/dod/internet/ mgmt/mib-2/ip/ipForwarding).

Page 12-2 ESXMIM/ESXMIM-F2 Local Management Guide

MIB Navigator Command Set Overview

12.2 MIB NAVIGATOR COMMAND SET OVERVIEW

The MIB Navigator command set provides the following commands:

Navigation Commands

Navigation commands allow you to access and manage the MIB for the device running the MIB Navigator. Some of these commands also provide user community-string information. The commands are as follows:

– branch – cd – ctron – dir – get – help – ls – mib2 – next – pwd – set – show – su – tree – whoami

Built-In Commands

Built-In commands allow you to access and manage network devices connected to the device running the MIB Navigator . The commands are as follows:

– arp – defroute – netstat – ping – snmpbranch – snmpget – snmpset – snmptree

– traceroute

Special Commands

Special Commands allow you to exit from the MIB Navigator. The commands are as follows:

– done – quit – exit

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-3

Chapter 12: The MIB Navigator Screen

12.2.1 Conventions for MIB Navigator Commands

This manual uses the following conventions for denoting commands:

• Information keyed by the user is shown in this helvetica font.

• Command arguments are indicated by two types of brackets:

- required arguments are enclosed by [ ].

- optional arguments are enclosed by < >.

MIB Navigator command conventions are as follows:

• To abort the output or interrupt a process the escape character is ^C (where ^ equals the Control key).

• A slash (/) proceeding an OID issues that command from the root directory regardless of where you are in the MIB. If no slash precedes the OID the command issues from your current MIB location.

• Dot notation (1.1.1.1) is equivalent to slash notation (1/1/1/1). Use slash notation with the navigational commands, and the dot notation with the built-in commands that are using SNMP to access and manage network devices.

MIB Navigation Commands are listed in the format shown below:

command:

Syntax: This entry provides the format that the MIB

Navigator command requires. It indicates where arguments, if any, must be speciﬁed.

Description: This entry brieﬂy describes the command and

its uses.

Options: This entry lists any additional ﬁelds which may

be added to the command and their format.

Example: This entry shows an example of the command.

Page 12-4 ESXMIM/ESXMIM-F2 Local Management Guide

MIB Navigator Command Set Overview

12.2.2 Navigation Commands

The following MIB Navigation commands allow you to move from MIB object to MIB object within the MIB tree.

branch:

Syntax: branch [path] Description: The branch command displays all of the leaves

in the MIB tree below a speciﬁed path. The information displayed includes the path name, the object ASCII name, the type of object (i.e., integer, counter , time tick, etc.), and the current value of each leaf object.

Options: Not Applicable Example:

MIBNav-> branch

# /1/3/6/1/2/1/7/1 # /1/3/6/1/2/1/7/2 # /1/3/6/1/2/1/7/3

udpInDatagrams udpNoPorts udpInErrors

COUNTER COUNTER COUNTER

38216 0 0

051456

cd:

Syntax: cd [path] or cd [option] Description: The cd command allows you to change

directories within a MIB subtree (branch). The path speciﬁed must be valid, or the MIB Navigator will not perform the cd operation.

Options: .. Moves you one subtree abov e the current one.

/ Moves you to the root.

Example:

MIBNav-> cd iso/org/dod/internet/mgmt

051457

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-5

Chapter 12: The MIB Navigator Screen

ctron:

Syntax: ctron Description: The ctron command allows you to change

directories to the Cabletron MIB (1.3.6.1.4.1.52) without keying in the entire path.

Options: Not Applicable Example:

MIBNav-> ctron

051458

help:

Syntax: help <COMMAND> Description: The help command provides general help on

how to use the MIB Navigator or how to use a particular MIB Navigator command.

Options: Not Applicable Example:

MIBNav-> help su

Command: Format: Allows user to change his/her community name, in order to allow different access to the MIB.

Page 12-6 ESXMIM/ESXMIM-F2 Local Management Guide

su su <Community Name>

051459

MIB Navigator Command Set Overview

mib2:

Syntax: mib2 Description: The mib2 command allows you to move

directly to the MIB II subtree (1.3.6.1.2.1) without entering the entire path.

Options: Not Applicable Example:

MIBNav-> mib2

051460

Syntax: next [path] Description: The next command enables you to determine

the next leaf in the speciﬁed path within the managed device’s MIB.

Options: Not Applicable Example:

MIBNav-> next /1/3/6/1/2/1

#/1/3/6/1/2/1/1/1 sysDescr String CtronRev.X.XX.XX

051461

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-7

Chapter 12: The MIB Navigator Screen

pwd:

Syntax: pwd Description: The pwd command displays the full path name

for the directory in which you are currently working. The directory is displayed in ASCII format.

Options: Not Applicable Example:

MIBNav-> pwd

# /iso/org/dod/internet/mgmt/mib-2

051462

Page 12-8 ESXMIM/ESXMIM-F2 Local Management Guide

MIB Navigator Command Set Overview

set:

Syntax: set <OID> <value> Description: The set command enables you to set the value

of a managed object. This command is valid only for leaf entries in the current MIB tree, or for managed objects in the MIB.

If the leaf speciﬁed does not exist for the given path, MIB Navigator asks for a value. The following lists possible value types:

(i)nteger - number (c)ounter - number (g)auge - number (t)ime ticks - number o(p)aque - “value” (with quotation marks) (s)tring - “value” (with quotation marks) (o)id - OID number with dotted punctuation (a)ddress - IP address in DDN format (m)ac - MAC address in hexadecimal format (n)ull - no type

Options: Not Applicable Example:

MIBNav-> set /1/3/6/1/4/1/52/1/6/4/7 122.1.1.1

Type: (i)nteger (a)ddress (c)ounter (g)auge (o)id:

051463

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-9

Chapter 12: The MIB Navigator Screen

su:

Syntax: su [community name] Description: The su command enables you to change your

community name to allow for different access to the MIB. The community name that you enter allows you either read only , read-write, or super-user access to that device’s MIBs, depending on the level of security access assigned the password through the SNMP Community Names screen. See Chapter 5 for more information about community names.

Options: Not Applicable Example:

MIBNav-> su public

051464

tree:

Syntax: tree Description: The tree command provides a display of the

entire MIB for the device. Leaves and associated values are displayed in columns.

Options: Not Applicable Example:

MIBNav-> tree

# /1/3/6/1/2/1/1/1 # /1/3/6/1/2/1/1/2 # /1/3/6/1/2/1/1/3 # /1/3/6/1/2/1/1/4

sysDescr sysObjectId sysUpTime sysContact

STRING OBJECT ID TIME TICKS STRING

Page 12-10 ESXMIM/ESXMIM-F2 Local Management Guide

EMRev X.X.X.X

1.3.6.1.4.1.52 8098654 AlZwie/MIS

051465

MIB Navigator Command Set Overview

whoami:

Syntax: whoami Description: The whoami command displays your

community string and access privileges to the MIB. When using the whoami command one of these three access levels appears: read-only, read-write, and super-user.

Options: Not Applicable Example:

MIBNav-> whoami

# Community Name # Access Level

: super : SuperUser

051466

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-11

Chapter 12: The MIB Navigator Screen

12.2.3 Built-In Commands

The built-in commands listed in this section activate functions on the LM managed device or devices being accessed through MIB Navigation.

arp:

Syntax: arp <options> Description: The arp command provides access to the ARP

(Address Resolution Protocol) cache, enabling you to view cache data, delete entries, or add a static route. Super-user access is required to delete an entry or add a static route.

Each ARP cache entry lists: the network interface that the device is connected to, the device’s network address or IP address, the device’s physical address or MA C address, and the media type of connection to the device. Media types are displayed as numbers, which stand for the following states: 1 - Other 2 - Inv alid entry (cannot ping device, timed out, etc.) 3 - Dynamic route entry 4 - Static route entry (not subject to change)

Options: -a View cache data

-d delete an IP address entry. Requires additional arguments: <Interface Number> <IP address>

-s Adds a static entry. Requires additional arguments: <Interface Number> <IP address> <MAC address>

Example:

MIBNav-> arp -d 1 122.144.52.68

# /1/3/6/1/2/1/7/1 # /1/3/6/1/2/1/7/2 # /1/3/6/1/2/1/7/3

Page 12-12 ESXMIM/ESXMIM-F2 Local Management Guide

udpInDatagrams udpNoPorts udpInErrors

COUNTER COUNTER COUNTER

38216 0 0

MIB Navigator Command Set Overview

defroute:

Syntax: defroute [interface number] [IP address] Description: The defroute command allows you to set the

default IP route to a managed device through the speciﬁed interface.

Options: Not Applicable Example:

MIBNav-> defroute 2 147.152.42.32

051469

netstat:

Syntax: netstat [option] Description: The netstat command provides a display of

general network statistics for the managed device. The netstat command must be used with one of the two display options.

Options: -i Displays status and capability information for

each interface

-r Displays routing information for each interface

Example:

MIBNav-> netstat -i Interface + Description

# 1 (ethernet - csmacd) # 2 (ethernet - csmacd) # 3 (ethernet - csmacd) # 4 (ethernet - csmacd)

MIBNav-> netstat -r Destination

# Default Route # 134.141.0.0 # 134.141.0.0

MTU 1514

1514 1514 1514

Next-hop DirectConnection

DirectConnection DirectConnection

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-13

Speed 10000000

10000000 10000000 10000000

Admin up

up up up

Interface 1

2 3

MAC Addr

Oper

0x00 0x00 0x1d 0x07 0x50 0x0e

0x00 0x00 0x1d 0x07 0x50 0x0f

0x00 0x00 0x1d 0x07 0x50 0x10

0x00 0x00 0x1d 0x07 0x50 0x11

051470

Chapter 12: The MIB Navigator Screen

ping:

Syntax: ping [IP address] Description: The ping command generates an outbound ping

request to check the status (alive/not ali ve) of a device at a speciﬁed IP address.

Options: Not Applicable Example:

MIBNav-> ping 122.144.40.10

122.144.40.10 is alive

051471

snmpbranch:

Syntax: snmpbranch [IP address] [community name]

[OID]

Description: The snmpbranch command enables you to

query another SNMP device. The command provides a display of objects that match the speciﬁed OID. If no match is made, no object is displayed.

Options: Not Applicable Example:

MIBNav-> snmpbranch 2.4.8.1 public 1.3.6.2.1.1

# /1/3/6/1/2/1/1/1 # /1/3/6/1/2/1/1/2 # /1/3/6/1/2/1/1/3 # /1/3/6/1/2/1/1/4

sysDescr sysObjectId sysUpTime sysContact

STRING OBJECT ID TIME TICKS STRING

Page 12-14 ESXMIM/ESXMIM-F2 Local Management Guide

EMRev X.X.X.X

1.3.6.1.4.1.52 8098654 AlZwie/MIS

051473

MIB Navigator Command Set Overview

snmpget:

Syntax: snmpget [IP address] [community name] [OID] Description: The snmpget command enables you to query

another SNMP device to obtain a value for a speciﬁed object. This command requires the appropriate community string and object id.

Options: Not Applicable Example:

MIBNav-> snmpget 22.44.61.22 public 1.3.6.1.2.1.1.1.0

# Cabletron ESXMIM Revision X.XX.XX

051474

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-15

Chapter 12: The MIB Navigator Screen

snmpset:

Syntax: snmpset [IP address] [community name] Description: The snmpset command enables you to set the

value of an object in other SNMP devices. This command requires the appropriate community string and OID.

When deﬁning a new leaf set, MIB Navigator asks for a value. The following lists possible value types:

Options: Not Applicable Example:

MIBNav-> snmpset 122.44.1.2 public

1.3.6.1.2.1.1.4.0 "Cyrus/MIS"

051475

Page 12-16 ESXMIM/ESXMIM-F2 Local Management Guide

MIB Navigator Command Set Overview

snmptree:

Syntax: snmptree [IP address] [community name] Description: The snmptree command provides a display of

all objects in the device and their corresponding values.

Options: Not Applicable Example:

MIBNav-> snmptree 122.144.89.10 public

# /1/3/6/1/2/1/1/1 # /1/3/6/1/2/1/1/2 # /1/3/6/1/2/1/1/3 # /1/3/6/1/2/1/1/4

sysDescr sysObjectId sysUpTime sysContact

STRING OBJECT ID TIME TICKS STRING

EMRev X.X.X.X

1.3.6.1.4.1.52 8098654 AlZwie/MIS

traceroute:

Syntax: traceroute [IP address] Description: The traceroute command generates a

TRACEROUTE request to a speciﬁed IP address and provides a display of all next-hop routers in the path to the device. If the device is not reached, the command displays all next-hop routers to the point of failure.

Options: Not Applicable Example:

MIBNav-> traceroute 122.144.11.52

# next-hop[1] 122.144.61.45 # next-hop[2] 122.144.8.113

051476

051477

ESXMIM/ESXMIM-F2 Local Management Guide Page 12-17

Chapter 12: The MIB Navigator Screen

12.2.4 Special Commands

done, quit, exit:

Syntax: done Description: These commands enable you to exit from the

MIB Navigator and return to the Main Menu screen.

Options: Not Applicable Example:

MIBNav-> done

Connection closed

051472

Page 12-18 ESXMIM/ESXMIM-F2 Local Management Guide

INDEX

Alignment errors 11-3 arp 12-12

Backplane connection 9-2 branch 12-5 Bridge Setup screen 8-1

port administrative status 8-3 Spanning Tree protocol 8-2

Caution 1-2 cd 12-5 COM port application 4-2 Command field 1-8 Community names 5-1

read-only 5-2 read-write 5-2 setting 5-2

super-user 5-2 Component Status screen 10-1 Configuration

terminal 2-1 Conventions 1-2 CRC errors 11-2 ctron 12-6

Date and time 4-3 Default gateway 4-2, 4-6 Default interface 4-2, 4-6 defroute 12-13 Device Specific screen - See Module

Speciﬁc screen

Display field 1-7 done 12-18

Event message field 1-7 exit 12-18

Fields

command 1-8 display 1-7 event message 1-7 input 1-7 selection 1-7 types 1-7

FLASH Download screen 7-1

bootPROM download 7-2 download file name 7-4 runtime download 7-3 selecting server 7-3 server IP 7-4

Giants 11-3

Help (getting) 1-3 help (MIB Navigator

command) 12-6 Hierarchy of screens 3-2 Host IP address 4-2, 4-4

ESXMIM/ESXMIM-F2 Local Management Guide Index-1

Index

Input field 1-7 Interface 1

assigning 9-2

Interface Statistics screen 11-1

clearing counters 11-4 discards 11-2, 11-3 errors 11-2, 11-3 interface 11-4 nonucast 11-2, 11-3 octets 11-2, 11-3 screen fields 11-2 selecting interface 11-5 selecting update-freq 11-4 unicast 11-2, 11-3 update-freq 11-3

Keyboard conventions 1-8

Local Management

access levels 5-2 exiting screens 3-4 navigating menu screens 3-2 overview 1-3 requirements 1-5 screen elements 1-6 selecting menu screen items 3-3

Main Menu screen 3-5 Management agent 1-4 Management terminal

cable configuration 2-3 setup requirements 2-2

Menu screens

main menu 3-5 setup menu 3-6 statistics menu 3-9 status menu 3-8

MIB

components 10-1 description 12-2 tree hierarchy 12-2

MIB Navigator

built-in commands 12-3 commands 12-4 to 12-18 navigation commands 12-3

special commands 12-3 mib2 12-7 MIB-2 Statistics screen - see Interface

Statistics screen

Module Specific screen 9-1

interface 1 connection 9-2 Moving the cursor 1-9

netstat 12-13 Network management

in-band 1-4

local 1-4

out-of-band 1-4

remote 1-4 next 12-7 Note 1-2

OOW collision 11-2 Organization 1-1

Index-2 ESXMIM/ESXMIM-F2 Local Management Guide

Index

Password screen 3-1 Passwords - see Community names Physical (MAC) address 4-2 ping 12-14 pwd 12-8

quit 12-18 Quitting 3-4

Runts 11-3

Screen fields

command fields 1-8 display fields 1-7 event message field 1-7 input fields 1-7 selection fields 1-7

Screens

Bridge Setup 8-1 Component Status screen 10-1 FLASH Download screen 7-1 Interface Statistics screen 11-1 password 3-1 SNMP community names 5-1 SNMP Traps screen 6-1

system level 4-1 Selection field 1-7 set 12-9 Setup Menu screen 3-6 SNMP Community Names

screen 5-1

setting community names 5-2 SNMP Traps screen 6-1

fields 6-1

setting destination 6-2 snmpbranch 12-14 snmpget 12-15 snmpset 12-16 snmptree 12-17

Spanning Tree

selecting method 8-2 Statistics Menu screen 3-9 Status Menu screen 3-8 su 12-10 Subnet mask 4-2, 4-5 System date 4-2, 4-3 System Level screen 4-1

COM port operations 4-7 to ??

default gateway 4-6

default interface 4-6

fields 4-1

IP address 4-4

subnet mask 4-5

system date 4-3

system time 4-3 System time 4-2, 4-3

Technical Support 1-3 Telnet 2-4 Tip 1-2 traceroute 12-17 tree 12-10

VT setup 2-2

whoami 12-11

ESXMIM/ESXMIM-F2 Local Management Guide Index-3

Index
