CSX200 CyberSWITCH

Installation Guide

9032753

Notice

Cabletron Systems reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR

CONSEQUENTIAL DAMA GES WHATSOEVER (INCLUDING BUT NOT LIMITED T O LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.



Part Number: 9032753 August 1998

Cabletron Systems, LANVIEW, QuickSET,

are trademarks of Cabletron Systems, Inc. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies.

FCC Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment uses, generates, and can radiate radio frequency energy and if not installed in accordance with the operator’s manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense.

WARNING:

could void the user’s authority to operate the equipment.

Changes or modiﬁcations made to this device which are not expressly approved by the party responsible for compliance

and

SPECTRUM

are registered trademarks, and

QuickSTART

, and

CyberSWITCH

Industry Canada Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.

CSX200 Installation Guide i

Notice

VCCI Notice

This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.

Cabletron Systems, Inc. Program License Agreement

IMPORTANT:

This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (the “Program”) contained in this package. The Program may be contained in ﬁrmware, chips or other media. BY UTILIZING THE ENCLOSED PRODUCT, YOU ARE AGREEING TO BECOME BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND THE LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND.

Before utilizing this product, carefully read this License Agreement.

Cabletron Software Program License

1. LICENSE. You have the right to use only the one (1) copy of the Program provided in this package subject to the terms and

conditions of this License Agreement. You may not copy , reproduce or transmit an y part of the Program except as permitted by the Cop yright Act of the United States or

as authorized in writing by Cabletron.

2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or disassemble the Program.

3. APPLICABLE LA W. This License Agreement shall be interpreted and governed under the laws and in the state and federal courts

of New Hampshire. You accept the personal jurisdiction and venue of the New Hampshire courts.

ii CSX200 Installation Guide

Exclusion of Warranty and Disclaimer of Liability

Notice

1. EXCLUSION OF

expressed or implied, concerning the Program (including its documentation and media). CABLETRON DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE SUPPLIED TO YOU BY CABLETRON IN

WRITING, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THE PROGRAM, THE ACCOMP ANYING WRITTEN MA TERIALS, AND ANY A CCOMP ANYING HARDWARE.

2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL CABLETRON OR ITS SUPPLIERS BE

LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS, PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS) ARISING OUT OF THE USE OR INABILITY TO USE THIS CABLETRON PRODUCT, EVEN IF CABLETRON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR ON THE DURATION OR LIMITATION OF IMPLIED WARRANTIES, IN SOME INSTANCES THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU.

WARRANTY. Except as may be specifically provided by Cabletron in writing, Cabletron makes no warranty,

United States Government Restricted Rights

The enclosed product (a) was developed solely at priv ate e xpense; (b) contains “restricted computer software” submitted with restricted rights in accordance with Section 52227-19 (a) through (d) of the Commercial Computer Software - Restricted Rights Clause and its successors, and (c) in all respects is proprietary data belonging to Cabletron and/or its suppliers.

For Department of Defense units, the product is licensed with “Restricted Rights” as deﬁned in the DoD Supplement to the Federal Acquisition Regulations, Section 52.227-7013 (c) (1) (ii) and its successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at

252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505.

CSX200 Installation Guide iii

Notice

Declaration of Conformity

Application of Council Directive(s):

Manufacturer’s Name:

Manufacturer’s Address:

European Representative Name:

European Representative Address:

Conformance to Directive(s)/Product Standards:

Equipment T ype/Environment:

W e the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives.

89/336/EEC 73/23/EEC 91/263/EEC

Cabletron Systems, Inc. 35 Industrial Way

PO Box 5005 Rochester, NH 03867

Mr. J. Solari Cabletron Systems Limited

Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England

EC Directive 89/336/EEC EC Directive 73/23/EEC EC Directive 91/263/EEC EN 55022 EN 50082-1 EN 60950

Networking Equipment, for use in a Commercial or Light Industrial Environment.

Manufacturer Legal Representative in Europe Mr. Ronald Fotino Mr. J. Solari

___________________________________ ___________________________________

Full Name Full Name Principal Compliance Engineer Managing Director - E.M.E.A.

___________________________________ ___________________________________

Title Title Rochester, NH, USA Newbury, Berkshire, England

___________________________________ ___________________________________

Location Location

iv CSX200 Installation Guide

CHAPTER 1 INTRODUCTION

Related Documentation ...................................................................................1-1

How to Use This Guide ....................................................................................1-1

Document Conventions...................................................................................1-3

Getting Help......................................................................................................1-4

CHAPTER 2 ABOUT THE CSX200

CSX200 Hardware.............................................................................................2-1

WAN Connection........................................................................................2-1

Ethernet LAN Connection .........................................................................2-2

Remote Management Capabilities..................................................................2-3

Optional Features.............................................................................................2-3

CSX200 Firmware Support ..............................................................................2-4

IEEE 802.3 Ethernet ...................................................................................2-4

WAN Protocols...........................................................................................2-4

Firmware Data Compression ....................................................................2-5

HDLC...........................................................................................................2-5

DHCP and NAT...........................................................................................2-5

Frame Relay Protocol................................................................................2-6

Point-to-Point Protocol (PPP)...................................................................2-7

PAP and CHAP Security............................................................................2-7

LQM.............................................................................................................2-8

Multilink Protocol.......................................................................................2-8

ISDN ............................................................................................................2-8

HDSL ...........................................................................................................2-9

Bridging and Routing ................................................................................2-9

Bridging and Routing Protocol Filtering................................................2-11

System Passwords ..................................................................................2-12

Simple Network Management Protocol (SNMP)....................................2-12

Software and Firmware Upgrades..........................................................2-15

CSX200 Installation Guide v

Contents

CHAPTER 3 10BASE-T LAN REQUIREMENTS

Network Requirements ....................................................................................3-1

10BASE-T Twisted Pair Network ..............................................................3-1

Port Descriptions..............................................................................................3-2

10BASE-T LAN Configuration .........................................................................3-3

Connecting UTP Cables to Ports 1 Through 12......................................3-3

CHAPTER 4 INSTALLATION

Unpacking the CSX200 ....................................................................................4-1

Installation Guidelines .....................................................................................4-1

Removing the CSX200 Cover....................................................................4-2

Installing a WPIM........................................................................................4-3

COMP/ENCR Module Installation....................................................................4-5

Installing the CSX200.......................................................................................4-6

Tabletop and Shelf Installations...............................................................4-6

Rackmount Installation....................................................................................4-7

Attaching the Strain-Relief Bracket..........................................................4-8

Attaching the Rackmount Brackets .........................................................4-9

Installing the CSX200 in a 19-Inch Rack................................................4-10

Powering the CSX200.....................................................................................4-10

CHAPTER 5 TROUBLESHOOTING

Troubleshooting CSX200 Hardware ...............................................................5-4

Power (PWR) LED is OFF..........................................................................5-4

Processor (CPU) LED is OFF....................................................................5-4

Processor (CPU) LED is RED....................................................................5-4

Troubleshooting the LAN ................................................................................5-4

Collision (CLN) LED is RED ......................................................................5-4

Link (LNK) LED is OFF...............................................................................5-4

Troubleshooting the WAN ...............................................................................5-5

Link (LNK) LED is OFF...............................................................................5-5

Link (LNK) LED is RED..............................................................................5-5

Link (LNK) LED is AMBER.........................................................................5-5

Status 1 (STS1) LED is OFF ......................................................................5-5

Status 1 (STS1) LED is RED......................................................................5-6

vi CSX200 Installation Guide

Status 1 (STS1) LED is AMBER ................................................................5-7

Status 1 (STS1) LED is GREEN.................................................................5-7

Status 2 (STS2) LED is OFF ......................................................................5-8

Status 2 (STS 2) LED is RED WPIM-HDSL Installed in CSX200.............5-8

Status 2 (STS2) LED is AMBER ................................................................5-9

Status 2 (STS2) LED is GREEN.................................................................5-9

Test (TST) LED is AMBER (blinking)......................................................5-10

Investigating Software Configuration Problems .........................................5-10

Connection to Device Fails During Software Configuration................5-10

User Cannot Communicate with Remote Network Station..................5-10

APPENDIX A WPIM CABLE SPECIFICATIONS

WPIM-T1 ...........................................................................................................A-1

WPIM-SY...........................................................................................................A-3

EIA-449....................................................................................................... A-4

V.35.............................................................................................................A-5

EIA-232....................................................................................................... A-7

X.21.............................................................................................................A-8

EIA-530, EIA-530 ALT A, EIA-530 A, and EIA-530 A ALT A.................... A-9

WPIM-DDS...................................................................................................... A-11

WPIM-E1 ......................................................................................................... A-12

WPIM-DI.......................................................................................................... A-14

WPIM-HDSL....................................................................................................A-15

Contents

APPENDIX B SPECIFICATIONS AND STANDARDS COMPLIANCE

CSX200 Regulatory Compliance.................................................................... B-2

Individual WPIM Regulatory Compliance......................................................B-2

WPIM-T1..................................................................................................... B-2

WPIM-SY ....................................................................................................B-3

WPIM-DDS..................................................................................................B-3

WPIM-E1.....................................................................................................B-4

WPIM-DI......................................................................................................B-4

WPIM-HDSL ...............................................................................................B-4

CSX200 Installation Guide vii

Contents

APPENDIX C FCC PART 68 - USER’S INFORMATION FOR CSX200

APPENDIX D GLOSSARY

INDEX

viii CSX200 Installation Guide

Introduction

Welcome to the Cabletron Systems provides conﬁguration information, hardware speciﬁcations and troubleshooting tips for the CSX200 CyberSWITCH. This guide also provides background information about 10BASE-T Ethernet Local Area Networks (LANs) and guidelines for routing and bridging over Wide Area Networks (WANs).

CSX200 CyberSWITCH Installation Guide

. This guide

How to Use This Guide

The

READ ME FIRST!

provide all the information you need to install the CSX200. Read all of these documents before installing the CSX200.

document, the

CSX200 QuickSTART Guide,

and this installation guide,

This guide consists of the following sections:

Chapter 1, Introduction Chapter 2, About the CSX200,

protocols employed by this device.

Chapter 3, 10BASE-T LAN Requirements

Local Area Network (LAN).

Chapter 4, Installation

CSX200 Installation Guide 1-1

, details document conventions and provides

describes the hardware components and features, and software

, describes the cabling requirements for an Ethernet

, shows how to install your CSX200 and connect it to a network.

Getting Help

information.

Chapter 1:

Introduction

Chapter 5, Troubleshooting

, shows how to use the LANVIEW LEDs on the CSX200 for

network troubleshooting.

Appendix A, WPIM Cable Specifications

, provides part numbers and connector information for

WPIMs (Wide Area Port Interface Modules).

Appendix B, Specifications and Standards Compliance

, contains hardware speciﬁcations and

safety and compliance standards for the CSX200.

Appendix C, FCC Part 68 - User’s Information for CSX200

requirements for FCC Rules, Part 68.

Appendix D, Glossary

, deﬁnes commonly used networking terms.

, provides compliance

1-2 CSX200 Installation Guide

Document Conventions

The following conventions are used throughout this guide:

Note

NOTE

TIP

symbol. Calls the reader’s attention to any item of information that may be of

special importance.

Tip

symbol. Conveys helpful hints concerning procedures or actions.

Document Conventions

CAUTION

WARNING

Caution

Warning

electrical shock hazard.

Warning

symbol. Contains information essential to avoid damage to the equipment.

symbol. Warns against an action that could result in the presence of an

symbol. Warns against an action that could result in personal injury or death.

CSX200 Installation Guide 1-3

Chapter 1:

Introduction

Getting Help

If you need additional support related to this device, or if you have any questions, comments, or suggestions concerning this manual, contact the Cabletron Systems Global Call Center:

Phone (603) 332-9400 Internet mail support@ctron.com FTP ctron.com (134.141.197.25)

BBS (603) 335-3358

Modem setting 8N1: 8 data bits, No parity, 1 stop bit

For additional information about Cabletron Systems or our products, visit our World Wide Web site: For technical support, select

Before calling the Cabletron Systems Global Call Center, have the following information ready:

• Your Cabletron Systems service contract number

• A description of the failure

anonymous your email address

http://www.cabletron.com/

Service and Support

• A description of any action(s) already taken to resolve the problem (e.g., changing mode switches, rebooting the unit, etc.)

• The serial and revision numbers of all involved Cabletron Systems products in the network

• A description of your network environment (layout, cable type, etc.)

• Network load and frame size at the time of trouble (if known)

• The device history (i.e., have you returned the device before, is this a recurring problem, etc.)

• Any previous Return Material Authorization (RMA) numbers

1-4 CSX200 Installation Guide

About the CSX200

The CSX200 CyberSWITCH ( Network (LAN) connectivity (via twelve RJ45 ports) for the small ofﬁce, and offers high-speed Wide Area Network (WAN) access to a remote site, such as the Internet or an enterprise network. The CSX200 supports IEEE 802.1d transparent bridging, IP, and IPX routing, ISDN, Dynamic Host Conﬁguration Protocol (DHCP), and Network Address Translation (NAT) routing between Ethernet LANs across a WAN.

Figure 2-1

Figure 2-1 The CSX200 CyberSWITCH

) is an access device that provides Ethernet Local Area

STS 1 STS 2

CSX200 Hardware

This section details hardware features of the CSX200 CyberSWITCH.

WAN Connection

The CSX200 supports Point-to-Point Protocol (PPP) including: Link Control Protocol (LCP), BNCP, IPCP, IPXCP, LQM, Multilink Protocol (MP), Frame Relay, and CHAP and PAP security protocols, through one of the following WAN port interface modules (WPIMs):

•

The WPIM-T1 provides a T1 interface through a front panel RJ45 port and includes a built-in Channel Service Unit/Digital Service Unit (CSU/DSU) for direct connection to a T1 line. The WPIM-T1 provides both Full T1 (twenty-four time slots) or Fractional T1 (less than twenty-four time slots) using 56 Kbps-, or 64Kbps per time slot. The total throughput of the CSX200 is 1.544 Mbps.

CSX200 Installation Guide 2-1

Chapter 2:

•

The WPIM-SY provides a synchronous serial connection of up to 2.048 Mbps to external

About the CSX200

communications equipment (e.g., a multiplexer or CSU/DSU). The WPIM-Sync uses a subminiature 26-pin connector that supports the electrical signal interfaces listed below.

Appendix A, WPIM Cable Specifications

, provides complete part number and cable pin assignment information for the following electrical signal interfaces: EIA-RS449, V.35, EIA-RS232D, X.21, EIA-RS530, EIA-530A, RS530 ALT A, and RS530A ALT A

•

The WPIM-DDS provides a 56 Kbps or 64 Kbps Digital Data Service (DDS) connection. The WPIM-DDS supports remote CSU diagnostic, or 64 Kbps clear channel loopback and non-latching remote DSU diagnostic loopback.

•

The WPIM-E1 provides an E1 interface through a front panel RJ45 port and includes a built-in CSU/DSU for direct connection to an E1 line. The WPIM-E1 provides both Full E1(32 time slots) or Fractional E1 (less than 32 time slots) using 56Kbps, or 64 Kbps per time slot with a total throughput of up to 2.048 Mbps.

•

The WPIM-DI provides a T1 interface through a front panel RJ45 port and includes a built-in CSU/DSU for direct connection to a T1 line. The WPIM-DI provides both Full T1 (24 time slots) or Fractional T1 (less than 24 time slots) using 56Kbps-, or 64 Kbps per time slot. The WPIM-D1 also provides a second Drop-and-Insert interface, which allows more than one device, such as a PBX, to share a single T1 connection.

• The WPIM-S/T provides an Integrated Services Digital Netw ork (ISDN) 128 Kbps Basic Rate

Interface for the CSX200. An NT-1 adapter is necessary for this interface in the United States.

• The WPIM-HDSL provides a 1.544 Mbps connection for: users in a campus environment, or

for access to local subscriber loops. The WPIM-HDSL uses existing telephone lines between ﬂoors, buildings, or other physical structures. HDSL supports line lengths of up to 3, 657 meters (12,000 feet) over 24 AWG Unshielded Twisted Pair cabling.

Ethernet LAN Connection

The CSX200 provides 10 Mbps Ethernet/IEEE 802.3 support through twelve (11 if Call Backup is enabled) 8-pin RJ45 10BASE-T ports on the front of the unit (see Figure 2-1).

Repeater Functionality — The CSX200 fully conforms to the IEEE 802.3 Repeater, AUI, and

10BASE-T speciﬁcations, and provides the ﬂexibility to connect networks using IEEE 802.3, Ethernet Version 1 or Version 2 equipment. The CSX200 transmits retimed data packets, regenerates the preamble, extends fragments, and arbitrates collisions. The CSX200 automatically partitions problem segments, and reconnects repaired segments to the network. This feature minimizes the impact on network operation resulting from a problem on one segment by isolating the problem segment. Only devices on the problem segment are affected. When the problem is solved, the CSX200 automatically reconnects the isolated segment to the network.

2-2 CSX200 Installation Guide

Remote Management Capabilities

Polarity Detection and Correction — Each twisted pair port on the CSX200 incorporates a

Polarity Detection and Correction feature that allows the CSX200 to pass data regardless of the polarity of the twisted pair segment’s receive link. We do not recommend operating in this condition. When this condition is detected, remove the segment from the network and wire it correctly to reduce the potential for problems if equipment changes are made.

Flash EEPROMs — The CSX200 uses a Flash Electrically Erasable Programmable Read-Only

Memory (EEPROM) that allows the downloading of new and updated ﬁrmware in conjunction with QuickSET or any device utilizing BootP or TFTP protocols.

LANVIEW LEDs — LANVIEW Status Monitoring and Diagnostics System is a troubleshooting

tool that helps in diagnosing power failures, collisions, cable faults, and link problems. The LANVIEW LEDs are conveniently located on the CSX200 front panel.

RESET Button — The front panel RESET button reboots the CSX200 and initializes the

processor. The RESET button is also used (with the mode switches) to clear NVRAM.

Remote Management Capabilities

The CSX200 can be managed remotely with any SNMP (Simple Network Management Protocol) compliant network management system.

Optional Features

Rack Mounting Capabilities — The CSX200 can be installed in a 19-inch rack with an

accessory package that includes the rackmount brackets, a strain-relief bracket for cable management, and mounting screws. See Chapter 4, Installation, for complete rack mounting instructions.

Hardware Data Compression Module — The same industry standard STAC Electronics

Stacker LZS Compression algorithm supported by CSX200 software is made available by an optional hardware data compression module that accelerates data compression for the CSX200 over PPP and Frame Relay. Depending on the packet type and size, hardware data compression provides a minimum of 2:1 data compression, giving (effectively) 3 Mbps throughput on a T-1 WPIM interface. To use the hardware data compression module, compatible equipment (that conforms to the applicable standards), must be in use at both ends of the WAN link. When the hardware data compression module is installed on the board, it automatically assumes the compression task from software. There is no conﬁguration necessary to prioritize hardware over software compression.

CSX200 Installation Guide 2-3

Chapter 2: About the CSX200

CSX200 Firmware Support

The CSX200 ﬁrmware supports IEEE 802.1d bridging, and IP and IPX routing,. Wide Area Networking includes Point-to-Point Pr otocol (PPP), and Frame Relay . Remote access is via Full or Fractional T1, E1, Synchronous, Digital Data Service, ISDN, or HDSL connections.

This device supports industry-standard protocols, security features, compression algorithms and network management tools to ensure interoperability with equipment from other vendors.

IEEE 802.3 Ethernet

The CSX200 provides a standard 802.3 Media Access Control (MAC) layer for Ethernet communications. All bridging and routing protocols are supported across the Ethernet link.

WAN Protocols

This device supports the following WAN protocols over the WAN port:

• Point-to-Point Compression Control Protocol (CCP) as deﬁned by RFC 1962

• Dynamic Host Conﬁguration Protocol (DHCP) as deﬁned by RFC 1541

• Network Address Translation (NAT) routing as deﬁned by RFC 1631

• Point-to-Point Protocol (LCP) as deﬁned by RFC 1661

• Point-to-Point Protocol (BNCP) as deﬁned by RFC 1638

• Point-to-Point Protocol (IPCP) as deﬁned by RFC 1332

• Point-to-Point Protocol (IPXCP) as deﬁned by RFC 1552

• Password Authentication Protocol (PAP) and Challenge Handshake Authentication Protocol

(CHAP) under PPP as deﬁned by RFC 1994

• Point-to-Point Protocol Link Quality Monitoring (LQM) as deﬁned by RFC 1333

• Point-to-Point Protocol Multilink Protocol (MP) as deﬁned by RFC 1717

• Frame Relay Link Management Interface (LMI) as deﬁned by ANSI T1.617 Annex D and ITU

Q.933 Annex A

• Frame Relay Data Encapsulation as deﬁned by RFC 1490

• Frame Relay Data Compression Protocol (DCP) as deﬁned by FRF.9

2-4 CSX200 Installation Guide

CSX200 Firmware Support

Firmware Data Compression

The STAC Electronics Stacker LZS Compression algorithm provides a minimum of 2:1 ﬁrmware data compression for the CSX200 over PPP and Frame Relay. Firmware data compression is supported in software on each WAN interface for line speeds of up to 256 Kbps per WPIM, which is equivalent to four DS0 channels. To use data compression, compatible equipment (which conforms to the applicable standards), must be in use at both ends of the WAN link. This method of data compression is used as the default, if the hardware compression module is not installed.

HDLC

High-level Data Link Control (HDLC) protocol is used in conjunction with the WPIM-HDSL to conserve WAN bandwidth between two compatible devices, over a point-to-point connection. The HDLC (RAW) protocol reduces the amount of overhead information that needs to be contained within each data packet to direct it to its destination. This decreased packet overhead provides more available bandwidth to transfer data.

DHCP and NAT

The Dynamic Host Conﬁguration Protocol (DHCP) and Network Address Translation (NAT) schemes eliminate the expense of purchasing limited public IP addresses for each client on a local network, and the need to re-conﬁgure a client if it is moved to a different network.

The CSX200 acts as a DHCP server that lets individual clients (PCs, network equipment) take turns using a range of private IP addresses (often referred to as local IP addresses), and provides optional secondary setup features for these clients on a per-port basis. A pri v ate or “local” netw ork is referred to as a sub network that is using private or “local” IP addresses. An “outside” network refers to a Wide Area Network (WAN) commonly known as an Internet. An Intranet is an “Internet” in use on a facility or campus where registered public IP addresses are required.

The CSX200 distributes these addresses on a ﬁrst-come-ﬁrst-served basis, dynamically assigning a local IP address to an individual client (from 253 av ailable addresses). This local IP address is then “leased” for a predetermined amount of time, conﬁgured for a particular port. Each Ethernet port provides DHCP services for one Class C subnet and secondary setup features for individual clients that support the use of a default gateway, domain name and WINs server. On the Wide Area Network (WAN) side, the Network Address Translation (NAT) routing scheme lets clients with local IP addresses use the public IP address(es) of the CSX200 WAN interface(s) to access the WAN.

NAT lets several DHCP clients on a sub network connect to WAN clients by letting the DHCP clients share a single public IP address. The NAT scheme modiﬁes the IP headers and addresses, and the selected ﬁelds in upper layer protocol headers.

CSX200 Installation Guide 2-5

Chapter 2: About the CSX200

This is done to replace the hidden local IP addresses from the sub network with one or more public InterNic assigned IP addresses that can be sent over the outside network on the WAN interfaces. Once the CSX200 is assigned at least one public IP address, over 250 IP clients can share this address simultaneously using NAT. This public IP address is assigned statically by the Internet Service Provider (ISP).

Frame Relay Protocol

Frame Relay can be deﬁned as a “packet mode” service, organizing data into individually addressed units known as “frames”. Frame Relay eliminates Layer 3 processing. Only a few Layer 2 functions are used, such as checking for a valid, error free frame, but not requesting retransmission if an error is found. Frame Relay uses a variable length framing structure, which, depending on user data, can range from a few to more than a thousand characters.

A Frame Relay Network will often be depicted as a cloud, because the Frame Relay Network is not a single physical connection between one endpoint and another. Frame Relay Protocol is based on the concept of “virtual circuits” (VCs). VCs are two-way, software deﬁned data paths between two ports that take the place of private lines in the network. There are two types of Frame Relay connections; Switched Virtual Circuits (SVCs), and Permanent Virtual Circuits (PVCs).

Permanent Virtual Circuits, or PVCs, are set up via a network management system, and initially deﬁned as a connection between two sites, or endpoints. PVCs may be added as the demand arises for more bandwidth, alternate routing, or more sites, or endpoints. PVCs are ﬁxed paths, not available on demand, or on a call-by-call basis. Although the actual path through the network may change from time to time, such as when automatic rerouting takes place, the beginning and end of the circuit will not change.

Switched Virtual Circuits, or SVCs, are available on a call-by-call basis using the SVC signaling protocol (Q.933). The network must quickly establish the connection, and allocate bandwidth based on the user’s request.

In a Frame Relay frame, user data packets are not changed in any way. A two-byte header is appended to the frame. Contained in this header is a 10-bit number called the Data Link Connection Identiﬁer (DLCI). The DLCI is the “virtual circuit” number which corresponds to a particular destination. The DLCI allows data coming into a Frame Relay switch to be sent across the network using a three-step process: check the integrity of the frame and discard it if it is in error, look up the DLCI in a table and if not intended for this link, discard the frame. If the frame passes the previous tests, relay the frame toward its destination out the port speciﬁed in the table. If the frame passes the previous tests, relay the frame toward its destination out the port speciﬁed in the table.

2-6 CSX200 Installation Guide

CSX200 Firmware Support

The ANSI standard deﬁnes a mechanism for the network to signal the existence of congestion, called Explicit Congestion Notiﬁcation (ECN) bits. Frame Relay uses FECN (Forward ECN) and BECN (Backward ECN) bits to notify end user devices about network congestion. Although the Frame Relay Protocol does not respond to congestion, some higher layer protocols for end-user devices may respond to ECNs by recognizing that delays have increased, or that frames have been dropped.

Point-to-Point Protocol (PPP)

PPP is a data link layer industry standard WAN protocol for transferring multi-protocol data trafﬁc over point-to-point connections. With this protocol, options such as security, data compression, and network protocols can be negotiated over the connection. Data compression allows Frame Relay to negotiate compression over Frame Relay permanent virtual circuits (PVCs). Frame Relay is a packet-switching data communications protocol that statistically multiplexes many data conversations over a single transmission link.

The CSX200 supports synchronous PPP over an ISDN WAN port (WPIM-S/T). In Single Link Mode, PPP uses one ISDN B channel for data transmission. PPP runs over each ISDN B channel for two separate conversations (split B channel). In Multi-Link Protocol mode, PPP simultaneously sends and receives data over two ISDN B channels on the same connection to optimize bandwidth usage. The STAC Electronics Stacker LZS Compression Protocol is supported over PPP, providing up to 4:1 data compression.

PAP and CHAP Security

The CSX200 supports the Password Authentication Protocol (PAP) and Challenge Handshake Authentication Protocol (CHAP) under PPP.

PAP provides veriﬁcation of passwords between devices using a two-way handshake. One device (peer) sends the system name and password to the other device (authenticator). Then the authenticator checks the peer’s password against the conﬁgured remote peer’s password and returns acknowledgment.

CHAP is more secure than PAP as unencrypted passwords are not sent across the network. CHAP uses a 3-way handshake and supports full or half-duplex operation. In half-duplex operation, the authenticator device challenges the peer device by generating a CHAP challenge. The challenge contains an MD5 algorithm with a random number that your encrypted password and system name. The peer device then applies a one-way hash algorithm to the random number and returns this encrypted information along with the system name in the CHAP response. The authenticator then runs the same algorithm and compares the result with the expected value. This authentication method depends upon a password or secret, known only to both ends locally.

CSX200 Installation Guide 2-7

Chapter 2: About the CSX200

Full-duplex operation places an additional step to half-duplex operation that mirrors the operation for a peer to validate the authenticator. The peer device challenges the authenticator by generating a CHAP challenge, and the authenticator returns a CHAP response.

The peer device challenges the authenticator device by generating a CHAP challenge, and the challenge contains your encrypted password and system name. The authenticator device then applies a one-way hash algorithm to the random number and returns this encrypted information along with the system name in the CHAP response. The peer device then runs the same algorithm and compares the result with the expected value. This authentication method depends upon a password or secret, known only to both ends locally.

LQM

Link Quality Monitoring (LQM) is a link control mechanism used with PPP to determine when, and how often, a link is dropping data in units of packets and octets. Link Quality Monitoring accomplishes this by providing Link-Quality-Reports to determine if the quality of the link is adequate for operation. Link Quality Monitoring provides separate measurements for both incoming and outgoing packets that are communicated to both ends of the link.

The PPP LQM mechanism carefully deﬁnes the Link-Quality-Report packet formats, and speciﬁes reference points for all data transmission and reception measurements. The LQM implementation maintains successfully received packet and octet counts, and periodically transmits this information to its peer using Link-Quality-Report packets.

Multilink Protocol

Multilink Protocol (MP) is an extension of PPP that controls the way frames are transferred across several links whenever a single link is not sufﬁcient to meet requirements of your present trafﬁc load. Multilink Protocol establishes several simultaneous links between two end points over switched circuits (dial-up lines) in an ISDN network, and dynamically adjusts the bandwidth demands between available links to maintain an effective data transfer.

ISDN

ISDN provides an inexpensive switched digital access to remote sites. The ISDN BRI (Basic Rate Interface) standard provides for two high speed 64 Kbps bearer (B) channels used for voice or data connections and one 16 Kbps signaling data (D) channel used for call setup, signaling, and other information. ISDN allows all types of information to be transferred including voice, data, fax, and video. Multiple devices can be linked to a single ISDN connection, each having their own telephone number. Two or more channels can be combined into a single larger transmission pipe offering variable transmission speeds.

2-8 CSX200 Installation Guide

CSX200 Firmware Support

The CSX200 supports one ISDN BRI line and either or both of the B channels for transferring data. If the two B channels are used for separate connections, each provides up to 64 Kbps transfer rate. Both channels can be used together to provide uncompressed data transfer at up to 128 Kbps. The CSX200 can also transfer compressed data at up to 512 Kbps (after decompression).

A network terminator device (NT-1) provides the interface between ISDN terminal (router) equipment and the ISDN service provider. The CSX200 supports the WPIM-S/T by providing an S/T interface that requires an external NT-1.

The following telephone switch types are supported within the U.S.:

• NET3 (European ISDN)

• NET3SW (European Swiss Variant)

• NTT (Nippon Telephone and Telegraph)

• KDD (Kokusai Denshin Denwa Co. Ltd.)

• French Delta (VN4) switches

HDSL

High data rate Digital Subscriber Line (HDSL) technology uses existing copper twisted pair cables designed for conventional analog voice transmission from a telephone carrier servicing area as low-cost alternative to ﬁber optic cables. HDSL provides high-speed full-duplex digital transmission links of up to 1.544 Mbps.

HDSL is a direct connection technology that allows connections to be made for distances of up to 12,000 feet over 24 American Wire Gauge (AWG) unconditioned twisted pair wire. To obtain the Full T1 line Rate of 1.544 Mbps, two wire pairs are necessary (four wires). If one pair of wires is used, the data rate is772 Kbps, equivalent to one-half of a T1 line.

Bridging and Routing

Bridging — Bridging connects two or more separate networks together. The bridge examines a

portion of each network frame called the header. This header contains control information for the frame. The bridge compares the destination address of the frame to a table of source addresses (bridges dynamically learn the physical location of devices by logging the source addresses of each frame and the bridge port the frame was received on in the source address table).

CSX200 Installation Guide 2-9

Chapter 2: About the CSX200

In transparent bridging, the decision to forward the frame is based on this comparison. If the address indicates that the sending station and the destination station are on the same side of the bridge, the frame is not forwarded across the bridge. If the addresses do not indicate that, the bridge forwards the broadcast frame across the bridge to the other network(s).

Bridging allows frames to be sent to all destinations regardless of the network protocols used. It also allows protocols that cannot be routed (such as NETBIOS) to be forwarded, and optimizes internetwork capacity by localizing trafﬁc on LAN segments. A bridge extends the physical reach of networks beyond the limits of each LAN segment. Filters can be used to increase network security in bridged networks, and restrict message forwarding by using user-built address tables (non-transparent bridging).

Routing — Routing provides a way to transfer user data from source to destination over dif ferent

LAN and WAN links using one or more network protocol formats. Routing relies on routing address tables to determine the best path for each packet. Routing tables can be seeded (i.e., addresses for remote destinations are placed in the table along with network address masks and a metric for path latency). Routing tables are also built dynamically (i.e., the location of remote stations, hosts and networks are updated through inter-router protocols). Routing helps to increase network capacity by localizing trafﬁc on LAN segments and broadcasts that would result from bridged trafﬁc. It also provides security by isolating trafﬁc on segmented LANs. Routing extends the world-wide reach of networks.

CSX200 Bridging and Routing — The CSX200 can operate as a bridge, a router, or both. The

CSX200 operates as a router for network protocols that are supported when routing is enabled and operates as a bridge when bridging is enabled. When both bridging and routing are enabled, routing takes precedence over bridging; i.e., the CSX200 uses the protocol address information of the packet to route the packet to the correct destination. However, if the protocol is not supported, the CSX200 operates as a bridge and uses the MAC address information to send the packet.

Operation of the CSX200 is inﬂuenced by routing and bridging controls and ﬁlters set during CSX200 conﬁguration. General IP routing, and routing or bridging from speciﬁc remote routers are controls set during the conﬁguration process.

IEEE 802.1d Bridging — The CSX200 supports the IEEE 802.1d standard for LAN to LAN

bridging. Bridging is provided over PPP and Frame Relay as well as adjacent LAN ports. Bridging uses the MAC (Machine Address and Control layer) address unique to each device. When conﬁgured as a bridge, the CSX200 bridges data packets to the destination, regardless of the network protocols used.

2-10 CSX200 Installation Guide

CSX200 Firmware Support

The CSX200 uses the Spanning Tree Algorithm to prevent data loops and duplicate data. This is a self-learning bridge, i.e., the bridge builds and updates an address table with each MAC source address and associated information when the packets are received.

IP Routing — IP routing support provides the ability to process TCP/IP frames at the network

layer for routing. IP routing support includes the Routing Information Protocol (RIP) that allows the exchange of routing information on a TCP/IP network. The CSX200 recei v es and rebroadcasts RIP messages to and from adjacent routers and workstations.

IPX Routing — Internet Packet Exchange (IPX) routing support provides the ability to process

Novell proprietary frames at the network layer for routing. IPX routing support includes both Routing Information Protocol (RIP), and Service Advertising Protocol (SAP). These protocols allow the exchange of routing information on a Novell NetWare network. The SAP protocol provides a means for routers and workstations to advertise their class of services (ﬁle, print, etc.) to adjacent routers and workstations.

Bridging and Routing Protocol Filtering

Filtering is used to allow efﬁcient usage of network resources and provide security for your network and hosts.

IP Internet Firewall — The CSX200 supports IP Internet Firewall ﬁltering to prevent

unauthorized access to your system and network resources from the Internet or a corporate Intranet. Security can be conﬁgured to permit or deny IP trafﬁc. The security is established by conﬁguring IP access ﬁlters, which are based on source IP address, source mask, destination IP address, destination mask, protocol type, and application port identiﬁers for both Transmission Control Protocol (TCP) and User Datagram Protocol (UDP).

IP access ﬁlters allow individual IP source and destination pair ﬁltering as well as IP address ranges and wild carding to match any IP address. Firewall ﬁlters can be deﬁned to allow inbound only, outbound only, or bi-directional IP communication up to the UDP and TCP application port level. The CSX200 supports the IP Access Control (from the ctip-mib) Internet Firewall Filter.

Bridge Filtering — Bridge ﬁltering lets a network administrator control the ﬂow of packets

across the CSX200. Bridge ﬁltering is used to “deny” or “allow” packets based on a “matched pattern” using a speciﬁed position and hexadecimal content within the packet. This enables restricting or forwarding of messages based on address, protocol, or data content. Common uses include preventing access to remote networks, controlling unauthorized access to the local network, and limiting unnecessary trafﬁc.

CSX200 Installation Guide 2-11

Chapter 2: About the CSX200

System Passwords

You can control access to the CSX200 by the use of three passwords. Each password provides a different level of access to the CSX200. The default password for each access level is pre-set to public. The following deﬁnitions explain the levels of access:

read-only — allows reading of device parameters not including system passwords. read-write — Allows editing of some device conﬁguration parameters not including changing

system passwords.

super-user — Allows full management privileges. You must access the CSX200 at this level to

run QuickSET.

Simple Network Management Protocol (SNMP)

The CSX200 provides SNMP agent support for standard, and Enterprise-Speciﬁc Management Information Bases (MIBs), and support for standard, and Enterprise-Speciﬁc SNMP Traps. SNMP is also used internally for conﬁguration of the CSX200. The active SNMP agent within the CSX200 accepts SNMP requests for status, statistics, and conﬁguration updates. Communication with the SNMP agent occurs over the LAN or WAN connection. Any management application using SNMP over UDP/IP has access to the local SNMP agent.

SNMP MIB Support

SNMP MIBs (Management Information Bases) are databases of objects used for managing and determining the status and conﬁguration of an SNMP-compliant device.

The CSX200 supports the following SNMP MIBs:

• MIB II RFC1213

• RMON MIB RFC1271

• DS1 and E1 MIB RFC1406 (Digital Signal Level 1 [T1/E1 interface types])

• IETF Bridge MIB RFC1493

• IP Forwarding MIB RFC1354

• PPP LCP MIB RFC1471 (Point-to-Point Protocol, Link Control Protocol)

• PPP IPCP MIB RFC1473 (IP Control Protocol)

• PPP BNCP MIB RFC1474 (Bridge Network Control Protocol)

• IPXCP MIB RFC1552

2-12 CSX200 Installation Guide

CSX200 Firmware Support

• Frame Relay DTE MIB RFC1490

• Security MIB RFC1472 (CCP, PAP, and CHAP)

• RS-232 MIB RFC1317

• LQM MIB RFC1989

• PPP MP MIB RFC1990

• Frame Relay Multi Protocol Encapsulation MIB RFC1490

SNMP T rap Support

SNMP Traps are notiﬁcations of network events sent by an SNMP-compliant device to an SNMP management station.

TheCSX200 supports the following SNMP IETF Standard Traps:

• Warm Start Trap Type Code #1 RFC1214

• Bridge New Root Trap Type Code #1 RFC1493

• Bridge Topology Change Trap Type Code #2 RFC1493

Cabletron Enterprise Traps include:

• Port Segmented Trap Type Code #257(0x101) rrev4-mib

• Port Operational Trap Type Code #258(0x102) rrev4-mib

• Port Link Up Trap Type Code #259(0x103) rrev4-mib

• Port Link Down Trap Type Code #260(0x106) rrev4-mib

• Environmental Temperature Hot Trap Type Code #282(0x11A) rrev4-mib

• Environmental Temperature Normal Trap Type Code #284(0x11C) rrev4-mib

• IP Event Log Change Trap Type Code #1280(0x500) ctip-mib

The following is a list of IP Events that are logged, and that create the IP Event Log Change Trap.

• IP Routing has been disabled on interface #

• IP Routing has been enabled on interface #

• IP Forwarding has been enabled on interface #

• IP MTU size has been changed on interface #

• IP Framing Type has been changed on interface #

CSX200 Installation Guide 2-13

Chapter 2: About the CSX200

IP Events, continued:

• IP has detected Link UP on interface #

• IP has detected Link DOWN on interface #

• IP Primary address has been changed on interface #

• IP Secondary address has been changed on interface #

• IP Access Control Lists have been enabled on interface #

• IP Access Control Lists have been disabled on interface #

• IP has detected Port UP (WAN devices only)

• IP has detected Port DOWN (WAN devices only)

• IP Proxy ARP has been disabled on interface #

• IP Proxy ARP has been enabled on interface #

• IP RIP has been enabled on interface #

• IP RIP has been disabled on interface #

• IPX Event Log Change Trap Type Code #1281(0x501) ctipx-mib

The following is a list of IPX Events that are logged, and that create the IPX Event Log Change Trap.

• IPX Routing has been disabled on interface #

• IPX Routing has been enabled on interface #

• IPX Forwarding has been enabled on interface #

• IPX MTU size has been changed on interface #

• IPX Framing Type has been changed on interface #

• IPX has detected Link UP on interface #

• IPX has detected Link DOWN on interface #

• IPX Primary address has been changed on interface #

• IPX Access Control Lists have been enabled on interface #

• IPX Access Control Lists have been disabled on interface #

2-14 CSX200 Installation Guide

CSX200 Firmware Support

• IPX has detected Port UP (WAN devices only)

• IPX has detected Port DOWN (WAN devices only)

• IPX RIP has been enabled on interface #

• IPX RIP has been disabled on interface #

• IPX SAP has been enabled on interface #

• IPX SAP has been disabled on interface #

Software and Firmware Upgrades

Software and Firmware upgrades can be performed remotely through the Windows-based QuickSET utility application. Refer to The QuickSET Conﬁguration Guide for QuickSET instructions. QuickSET allows you to retrieve or upgrade the ﬁrmware, software, and conﬁguration ﬁles from its Firmware U access a TFTP (Trivial File Transfer Protocol) server.

pgrade menu by selecting the TFTP/BootP Services to

CSX200 Installation Guide 2-15

Chapter 2: About the CSX200

2-16 CSX200 Installation Guide

This chapter contains general networking guidelines for setting up a 10BASE-T Local Area Network using ports 1 through 12 on the CSX200. Review the requirements and speciﬁcations outlined in this chapter before attempting to install the CSX200.

10BASE-T LAN Requirements

Network Requirements

Take care in planning and preparing the cabling and connections for your network. The quality of the connections, the length of cables, and other conditions of the installation play critical roles in determining the reliability of your network.

10BASE-T Twisted Pair Network

When connecting a 10BASE-T twisted pair segment to any of the CSX200 ports (Interfaces 1 through 12), ensure the network meets the following requirements:

Length — The IEEE 802.3 standard for 10BASE-T requires that 10BASE-T devices transmit

over a 100 meter (328 foot) link on 22–24 AWG Unshielded Twisted Pair (UTP) wire. However, cable quality largely determines maximum link length. Lengths of up to 200 meters may be achieved if high quality, low attenuation cable is used. Cable delay limits the maximum link length to 200 meters.

Losses introduced by connections at punch-down blocks and other equipment reduce

NOTE

Impedance — Cabletron Systems 10BASE-T twisted pair products use twisted pair cable with

75 to 165 ohms impedance. UTP cable typically has an impedance from 85 to 110 ohms. Shielded twisted pair cable, such as IBM Type 1 cable with an impedance of 150 ohms can also be used.

CSX200 Installation Guide 3-1

total segment length. For each connector or patch panel in the link, subtract 12 meters from the total length of the cable.

Chapter 3: 10BASE-T LAN Requirements

Temperature — Multi-pair PVC 24 AWG telephone cable typically has an attenuation of

approximately 8–10 dB/100 m at 20°C (68°F). The attenuation of PVC insulated cable varies with temperature. At temperatures greater than 40°C (104°F), use plenum-rated cable to ensure that attenuation remains within speciﬁcation.

Port Descriptions

Table 3-1 deﬁnes the pinout for the Ethernet twisted pair ports 1 through 12.

Table 3-1 Ethernet Twisted Pair Ports (1-12)

Pin Number Signal Name

4 Ground 5 Ground

7 Ground 8 Ground

Twisted Pair Transmit +

Twisted Pair Transmit -

Twisted Pair Receive +

Twisted Pair Receive -

3-2 CSX200 Installation Guide

10BASE-T LAN Configuration

10BASE-T LAN Conﬁguration

This section contains the procedures for connecting a UTP segment from the 10BASE-T network or other devices to the CSX200. Ports 1 through 12 on the CSX200 have RJ45 connectors for UTP connections.

Connecting UTP Cables to Ports 1 Through 12

Before connecting a segment to the CSX200, check each end of the segment to verify wire crossover.

To establish a link, you must have an odd number of crossovers (preferably one)

CAUTION

Connect a twisted pair segment to the CSX200 as follows:

1. Ensure that the device at the other end of the segment is connected to the segment and is

powered ON.

between 10BASE-T devices of the same type (i.e., from repeater to repeater or transceiver to transceiver).

2. Refer to Figure 3-1. Connect the twisted pair segment to the CSX200 by inserting the RJ45

connector on the twisted pair segment into the desired RJ45 port (ports 1 through 12).

2012_11

Figure 3-1 CSX200 Twisted Pair Connection

CSX200 Installation Guide 3-3

Chapter 3: 10BASE-T LAN Requirements

3. Verify that a Link exists by checking that the receive port (RCV) LED is on (flashing green or

amber or on solid green). If the RCV LED is off, perform the following steps until it is on:

a. Check that the 10BASE-T device at the other end of the twisted pair segment is ON and

connected to the segment.

b. Verify that the RJ45 connectors on the twisted pair segment have the proper pinouts

(Figure 3-2) and check the cable for continuity.

1 2

3 6

RX+ RX–

TX+ TX–

2012_13

NOTE: RX+/RX– and TX+/TX– must share a common color pair.

CyberSWITCH RJ45 Port

RX+

RX– 2

TX+

TX–

10BASE-T Device Port

RJ45 to RJ45

Figure 3-2 Cable Pinouts - (RJ45) Crossover Cable

c. Check that the twisted pair connection meets the dB loss and cable specifications outlined

in 10BASE-T LAN Requirements. If a link is not established, contact Cabletron Systems Technical Support. Refer to Getting

Help in Chapter 1, Introduction, for details.

4. Repeat step 2, above, until all connections have been made.

3-4 CSX200 Installation Guide

This chapter shows you how to connect your CSX200 to the network. Ensure that the network meets the guidelines and requirements outlined in Chapter 3, 10BASE-T LAN Requirements, before installing your CSX200.

Installation

Unpacking the CSX200

Remove the shipping material from the box and carefully remove the CSX200. Visually inspect the CSX200. If there are any signs of damage, contact Cabletron Systems (see the Getting Help section) immediately. Read the CSX200 Release Notes included in the shipping box.

Installation Guidelines

Installation sites must meet the requirements listed below:

• A properly grounded power receptacle must be within seven feet of the location.

• In a shelf installation, the shelf must be able to support 13.6 kg (30 lb) of static weight for each

device on the shelf.

• You must maintain a temperature of between 5°C (41°F) and 40°C (104°F) at the installation

site with ﬂuctuations of less than 10°C (50°F) per hour.

• There must be a two-inch clearance for each side and the back of the device for adequate

ventilation.

• Install Cabletron Systems WAN Port Interface Modules (WPIMs) and the CSX-COMP/ENCR

modules (when necessary) into the CSX200 before proceeding with the installation of your CSX200. Refer to the Installing a WPIM and COMP/ENCR Module Installation sections within this chapter for installation instructions.

The WPIM, CSX200-COMP/ENCR, and the CSX200 are sensitive to static

CAUTION

CSX200 Installation Guide 4-1

discharges. Use a grounding strap and observe all static precautions during installation. Failure to do so could result in damage to the WPIM, CSX200-COMP/ ENCR and the CSX200.

Chapter 4: Installation

NOTE

The CSX200 must have a WPIM installed before you can begin conﬁguring the device.

Removing the CSX200 Cover

The cover must be removed to install a WAN Port Interface Module.

DO NOT REMOVE THE COVER FROM THE CSX200 WHILE POWER IS APPLIED

CAUTION

To remove the chassis cover, proceed as follows:

TO THE UNIT . DO NOT PO WER UP THE DEVICE AGAIN UNTIL THE COVER AND SCREWS ARE

IN PLACE. DECKEL VON DAS CSX200 NICHT ABZIEHEN UNTER SPANNUNG. CSX200 NICHEINSCHALTEN SO LANG DER DECKEL UND SCHRAUBEN NICHT

EINGEBAUT SIND. NO DEBE DE REMOVER LA TAPA DURENTE QUE ESTE CONELTADO A LA

CORRIENTE. NO ENCHUFE A LA CORRIENTE HASTA QUE LA TAPA Y LOS TORNILLOS ESTEN

EN SU LUGAR.

• If the CSX200 is installed, unplug the power cord from the rear of the CSX200 chassis.

Before disconnecting any network cables, mark them according to their associated port

TIP

numbers. This will make reinstallation easier.

• Disconnect all network cables attached to the CSX200.

• Use a ﬂat-blade screwdriver to remove the cover screw attaching the cover to the CSX200

chassis (refer to Figure 4-1) and save the screw.

• Remove the cover by sliding it back until it clears the front of the chassis and then lifting it

straight up and off the chassis.

4-2 CSX200 Installation Guide

Chassis Cover

Installation Guidelines

Cover Screw (1)

Chassis

Figure 4-1 Removing the Plastic Chassis Cover

Installing a WPIM

Before performing installation procedures, ensure that the requirements outlined in the section, Tabletop and Shelf Installations on page 4-6, are met.

CAUTION

When removing an existing WPIM, make sure to pull the module straight out to avoid

CAUTION

To install a WPIM into the CSX200, refer to Figure 4-2 on the following page.

damaging the connector.

979-01

CSX200 Installation Guide 4-3

Chapter 4: Installation

WPIM

WPIM Screws

WPIM Connector

WPIM Connector Pins

Standoffs

Figure 4-2 Installing WPIMs

To install a WPIM, follow these instructions:

• Attach the disposable grounding strap to your wrist (refer to the instructions outlined on the

disposable grounding strap package).

• Remove the CSX200 cover (see Removing the CSX200 Cover on page 4-2).

• Remove the blank faceplate from the appropriate WPIM slot.

• Orient the WPIM as shown in Figure 4-2, above, and carefully insert the WPIM connector into

the WPIM connector pins on the CSX200.

• Press down ﬁrmly on the WPIM until the pins slide all the w ay into the connector. Ensure that

the WPIM seats ﬂush on the standoffs.

• Secure the WPIM to the three standoffs using the screws supplied.

• Replace the CSX200 cover.

4-4 CSX200 Installation Guide

COMP/ENCR Module Installation

To install the CSX200-COMP/ENCR into the CSX200 chassis, perform the following procedure:

• Attach one end of the antistatic wrist strap to your wrist and the other end to an approved

electrical ground.

• Unpack the CSX200-COMP/ENCR by carefully removing it from the shipping box and then

from the protective plastic bag. Do not cut the bag as the de vice could be damaged. If there are any signs of damage, contact the Cabletron Systems Global Call Center . See the Getting Help section of this document.

The CSX200-COMP/ENCR comes with a pre-attached metal cage. Do not remove

CAUTION

• Remove all power from the CSX200.

• You must remove the chassis cover of the CSX200 to install the CSX200-COMP/ENCR (refer

to Removing the CSX200 Cover on page 4-2).

• Locate the D-Type connector and the standoffs on the chassis (refer to Figure 4-3 on the

following page).

this cage.

• The D-Type connector pins of the CSX200-COMP/ENCR only ﬁt one way onto the CSX200

D-Type connector . Lo wer the CSX200-COMP/ENCR module onto the standoffs and align the connector with the connector pins. Carefully insert the connector pins of the CSX200-COMP/ENCR module into the CSX200 D-type connector.

• Press down ﬁrmly on the CSX200 COMP/ENCR module until the pins ﬁt all the way into the

connector.

• Secure the CSX200-COMP/ENCR with the standoff screws supplied with the

CSX200-COMP/ENCR module.

• Replace the CSX200 chassis cover and reconnect power.

• The CSX200-COMP/ENCR installation is complete.

CSX200 Installation Guide 4-5

Chapter 4: Installation

Standoff Screws

D-Type Connector Pins

D-Type Connector

CSX-COMP/ENCR

Standoff

2204N01

Figure 4-3 CSX200-COMP/ENCR Module Installation

Installing the CSX200

The CSX200 may be installed on a tabletop, on a shelf, or in a 19-inch rack.

Detail

Tabletop and Shelf Installations

The following two subsections provide guidelines for installation on a tabletop or shelf.

Before performing tabletop or shelf installation procedures , ensure that the requirements outlined in the section, Installation Guidelines on page 4-1, are met.

CAUTION

To install the CSX200 on a tabletop or shelf, perform the following procedure:

• Locate the CSX200 within seven feet of its po wer source with an unrestricted free surface area

as shown in Figure 4-4, on the following page.

• Locate the six round rubber feet included with your CSX200, and peel the paper backing off

the round rubber feet. Place one rubber foot near each of the four corners of the CSX200, and evenly space the remaining two near the center.

• Complete the installation by connecting power as described in Powering the CSX200.

4-6 CSX200 Installation Guide

Rackmount Installation

18 IN.

6 IN.

Figure 4-4 Tabletop or Shelf Installation

21 IN.

7 FT.

2012_07

Rackmount Installation

Cabletron Systems offers an accessory kit that includes rackmount brackets, mounting screws, and a strain-relief bracket for cable management. The accessory kit is not included with the CSX200, but can be purchased separately from Cabletron Systems as part number CSX200-ACCY-KIT.

Before installing the CSX200 into a rack, ensure that the rack supports the device(s)

WARNING

without compromising the stability of the rack. Otherwise, personal injury and/or equipment damage may result.

Rack mounting the CSX200 requires the following steps:

• Attaching the strain-relief bracket

• Attaching the rackmount brackets

• Installing the CSX200 in a 19-inch rack

• Connecting the CSX200 to a power source

Tools Required

• Phillips screwdriver

CSX200 Installation Guide 4-7

Chapter 4: Installation

Materials Required

The following parts are included in the CSX200-ACCY-KIT.

• Strain-relief bracket (shown in Figure 4-6, on the following page)

• Left and right rackmount brackets (shown in Figure 4-7, on the following page)

• 8-32 x 1/4-inch, pan-head screws (4)

• 8-32 x 3/8-inch, pan-head screws (4)

Do not use any screws other than those supplied with the CSX200-ACCY-KIT to perf orm the following procedures.

CAUTION

Rackmount

Brackets (2)

Strain-Relief Bracket

Figure 4-5 CSX200 Rackmount Hardware

2012_12

Attaching the Strain-Relief Bracket

Attach the strain-relief bracket to the front of the CSX200 as follows:

• Locate the strain-relief bracket and four 8-32 x 3/8-inch, pan-head screws provided in the

CSX200-ACCY-KIT.

• Using the four 8-32 x 3/8-inch, pan-head screws, attach the strain-relief bracket to the bottom

of the CSX200 as shown in Figure 4-6, on the following page.

4-8 CSX200 Installation Guide

Rackmount Installation

2012_08

Figure 4-6 Attaching the Strain-Relief Bracket

Attaching the Rackmount Brackets

Refer to Figure 4-7, below, and proceed as follows to attach the rackmount brackets:

• Locate the four 8-32 x 1/4-inch screws and the two rackmount brackets in the

CSX200-ACCY-KIT package.

• Using the four 8-32 x 1/4-inch screws, attach the rackmount brackets to the bottom of the

CSX200 as shown in Figure 4-7, below.

Rackmount

Brackets (2)

Screws (4)

Figure 4-7 Installing the Rackmount Brackets

2012_09

CSX200 Installation Guide 4-9

Chapter 4: Installation

Installing the CSX200 in a 19-Inch Rack

Install the CSX200 in a 19-inch rack as follows:

• Position the CSX200 between the vertical frame members of the 19-inch rack.

• Fasten the CSX200 with mounting screws as shown in Figure 4-8, below.

19-Inch Rack

Screws (4)

2012_10

Figure 4-8 Installing the CSX200 in the Rack

• Complete the installation by connecting power as described in Powering the CSX200, below.

Powering the CSX200

NOTE

To connect the CSX200 to the power source, perform the following steps:

1. Plug the power cord into the back panel of the CSX200.

2. Plug the other end of the power cord into a grounded wall outlet.

3. Verify that the PWR LED is on, indicating that the CSX200 is receiving power. After the

4-10 CSX200 Installation Guide

The CSX200 has a universal power supply. This allows you to connect the CSX200 to power sources of 100–125VAC 50/60 Hz, or 200–240 Vac, 50/60 Hz.

CSX200 runs a self test, the CPU LED blinks green indicating normal operation. If the LED remains red, the processor is faulty; contact Cabletron Systems (refer to Getting Help).

Troubleshooting

Use this chapter in conjunction with the LANVIEW status monitoring and diagnostic LEDs on the CSX200 to diagnose power failures, collisions, cable faults and link problems. Figure 5-1 shows the front panel LEDs. Table 5-1, Table 5-2, Table 5-3, Table 5-4, and Table 5-5 describe LED states.

If you are having difﬁculty installing and conﬁguring the CSX200, take the following steps:

• Review your CSX200 QuickSTART Guide to insure proper installation.

• Check that all cables and connectors have been attached properly.

• Verify that power has been attached.

STS 1

Power

CPU

Collision

Receive Link

Transmit

Receive

Link

STS 2

Status 1 Status 2 Test

2012_06

Figure 5-1 CSX200 Front Panel LEDs

Table 5-1 CSX200 Hardware LED States

LED Color State

Power (PWR)

Processor (CPU)

OFF Power Off GREEN Power is on OFF Power Off RED Fault condition detected GREEN (blinking) NORMAL

CSX200 Installation Guide 5-1

Chapter 5: Troubleshooting

LED Color State

Table 5-2 CSX200 LAN LED States

Receive (RCV)

Link (LNK)

LED Color State

Transmit (XMT)

Receive (RCV)

Link (LNK)

Test

OFF Not receiving trafﬁc AMBER (ﬂashing) Receiving trafﬁc OFF Link does not exist GREEN NORMAL, link exists

Table 5-3 CSX200 WAN LED States

OFF Not transmitting trafﬁc GREEN (ﬂashing) Transmitting trafﬁc OFF Not receiving trafﬁc AMBER (ﬂashing) Receiving trafﬁc OFF WPIM not conﬁgured GREEN NORMAL, link exists AMBER Link exists in STANDBY RED WPIM conﬁgured, link does not exist OFF NORMAL

AMBER (ﬂashing)

Power-up diagnostics Loopback testing

5-2 CSX200 Installation Guide

Table 5-4 CSX200 WAN LED States for STS 1

WPIM Color State

Troubleshooting

T1, DI, and E1

DDS

SYNC

HDSL

WPIM Color State

T1, DI, and E1

DDS OFF Normal or port disabled

SYNC

HDSL

OFF Normal or port disabled RED Red alarm OFF Normal or port disabled AMBER Out of service (OOS) OFF Inactive or disabled GREEN Request to send (RTS) OFF Port disabled or in loopback mode

RED GREEN Loop 1 synchronized

Table 5-5 CSX200 WAN LED States for STS 2

OFF Normal or port disabled AMBER Yellow alarm

OFF Inactive or disabled GREEN Clear to send (CTS)

OFF RED Loop 2 not synchronized (T1 mode only)

GREEN Loop 2 synchronized (T1 mode only)

Loop 1 not synchronized, in T1 and Fractional T1 mode

Port disabled, in Loopback mode, or Fractional T1 mode

CSX200 Installation Guide 5-3

Chapter 5: Troubleshooting

Troubleshooting CSX200 Hardware

Power (PWR) LED is OFF

• Check that the power connection is ﬁrmly attached to the back panel of the CSX200, and the

other end to an active power source.

Processor (CPU) LED is OFF

If the CPU stays OFF for an extended amount of time, and the power (PWR) light remains on, the CPU is in an unknown state.

• Contact Cabletron Systems Global Call Center for technical support (refer to Getting Help in

Chapter 1, Introduction).

Processor (CPU) LED is RED

The processor has detected a fault condition.

• Contact Cabletron Systems Technical Support (refer to Getting Help in Chapter 1,

Introduction).

Troubleshooting the LAN

Collision (CLN) LED is RED

Collisions are normal in an Ethernet network, however, increased collisions may indicate that the network is out of speciﬁcation (the propagation delay between two nodes on the network exceeds

25.6 µs).

Link (LNK) LED is OFF

• Check that the CSX200 and the device at the other end of the segment are powered up.

• Verify that the RJ45 connectors on the twisted pair segment have the correct pinouts.

• Check the cable for continuity.

• Check that the cable meets the speciﬁcations for dB loss.

5-4 CSX200 Installation Guide

Troubleshooting the WAN

Link (LNK) LED is OFF

The WAN interface is not conﬁgured for operation.

• Use QuickSET or Local Management to make sure that the WAN interface is conﬁgured

correctly.

Link (LNK) LED is RED

The WAN interface is conﬁgured, but there is no signal indicating that a v alid connection is present on the WAN interface.

• Check that the CSX200 and the device at the other end of the segment are powered up.

• Use QuickSET or Local Management to make sure that both WAN interfaces, local and remote,

are conﬁgured correctly.

• Check to ensure that the correct cable is being used.

• Check to ensure that the cable has continuity and is fully installed.

• Check with the WAN Service Provider to ensure that the circuit has been conﬁgured by them

and is active.

Link (LNK) LED is AMBER

The port is in Standby mode.

• Check with the Network Administrator to see if management placed the port in Standby mode.

• Ensure that the protocol that you want to run has been properly selected at both ends and the

time slots have been allocated if applicable.

Status 1 (STS1) LED is OFF

WPIM-T1, WPIM-E1, WPIM-DI, or WPIM-DDS Installed in CSX200

The port is operating normally. If it is not, and this LED is OFF the port may be disabled.

• Use QuickSET or Local Management to make sure that the WAN interface on the Local device

is conﬁgured correctly.

CSX200 Installation Guide 5-5

Chapter 5: Troubleshooting

WPIM-SYNC Installed in CSX200

The port is operating normally. If it is not, and this LED is OFF the port may be disabled or RTS may be inactive.

• Use QuickSET or Local Management to make sure that the WAN interface on the Local device

is conﬁgured correctly.

WPIM-HDSL Installed in CSX200

The port is disabled or has been placed into Loopback Test mode.

• Use QuickSET or Local Management to make sure that the WAN interface on the Local device

is conﬁgured correctly.

• Use QuickSET or Local Management to make sure that the WAN interface on the Remote

device is conﬁgured correctly.

Status 1 (STS1) LED is RED

WPIM-T1, WPIM-E1, or WPIM-DI Installed in CSX200 is in RED Alarm Mode

A RED alarm indicates that the WAN connection is not receiving proper framing or has lost framing.

• Verify the use of proper cabling on the WAN connection.

• Check Frame Type selection on the WAN Physical Conﬁguration and line coding.

• Possible bad cabling between Telco and CSX200.

5-6 CSX200 Installation Guide

Troubleshooting the WAN

WPIM-HDSL Installed in CSX200

WPIM-HDSL is conﬁgured for either Full or Fractional T1 and the WPIM is not able to establish synchronization on Loop 1 with the remote HDSL circuit.

• Verify using QuickSET of Local Management that one of the WPIM-HDSL is involved in the

connection is set to Master (Local) Timing and that the other one is set to Sla ve (Loop) T iming.

• Verify the use of proper cabling for the HDSL connections. Category 3 or Category 5

Unshielded Twisted Pair copper wiring is required. One pair (2 wires) for Fractional T1, two pair (4 wires) for Full T1. The presence of bridged taps and multiple wire segments connected together to form the loop may reduce the maximum distance usable between the Remote and Local devices. Wire gauge has an impact on the distance which can be supported as well. The maximum distance is 12,000 feet using 24 AWG wiring.

• Verify the gauge and condition of the wire. A trained line technician may be necessary to

determine this.

• Verify that the distance between the Remote and Local units is less than 12,000 Feet.

Status 1 (STS1) LED is AMBER

WPIM-DDS Installed in CSX200

The DDS circuit is Out of Service (OOS).

• Contact your WAN DDS Service Provider and have them test the operation of your DDS circuit.

Status 1 (STS1) LED is GREEN

WPIM-SYNC Installed in CSX200

The Port is operating normally. Request to Send (RTS) has been activated by your WAN device.

• Use QuickSET or Local Management to make sure that the WAN interface on the local device

is conﬁgured properly.

• Verify the cabling being used between the CSX200 and the CSU/DSU.

CSX200 Installation Guide 5-7

Chapter 5: Troubleshooting

WPIM-HDSL is installed in CSX200

The Port is operating normally, Loop 1 has synchronized with the HDSL circuit at the remote end.

Status 2 (STS2) LED is OFF

WPIM-T1, WPIM-E1, WPIM-DI, or WPIM-DDS Installed in CSX200

The port is operating normally. If it is not, and this LED is OFF the port may be disabled.

• Use QuickSET or Local Management to make sure that the WAN interface on the Local device

is conﬁgured correctly.

WPIM-SYNC Installed in CSX200

The port is operating normally. If it is not, and this LED is OFF the port may be disabled or CTS may be inactive from the CSU/DSU connected to the CSX200.

• Use QuickSET or Local Management to make sure that the WAN interface on the Local device

is conﬁgured correctly.

WPIM-HDSL Installed in CSX200

The port is in Fractional T1 mode and is operating normally. If it is not, the port is disabled or has been placed into Loopback Test mode.

• Use QuickSET or Local Management to make sure that the WAN interface on the Local device

is conﬁgured correctly.

• Use QuickSET or Local Management to make sure that the WAN interface on the Remote

device is conﬁgured correctly.

Status 2 (STS 2) LED is RED WPIM-HDSL Installed in CSX200

WPIM-HDSL is conﬁgured for either Full T1 and the WPIM is not able to establish synchronization on Loop 2 with the remote HDSL circuit.

• Verify using QuickSET of Local Management that one of the WPIM-HDSL is involved in the

connection is set to Master (Local) Timing and that the other one is set to Sla ve (Loop) T iming.

5-8 CSX200 Installation Guide

Troubleshooting the WAN

• Verify the use of proper cabling for the HDSL connections. Category 3 or Category 5

• Verify the gauge and condition of the wire. A trained line technician may be necessary to

determine this.

• Verify that the distance between the Remote and Local units is less than 12,000 Feet.

Status 2 (STS2) LED is AMBER

WPIM-T1, WPIM-E1, or WPIM-DI Installed in CSX200

The device is in Yellow alarm mode. A Yellow alarm indicates that the CSX200 is receiving proper framing from the Telco, but the Telco is not receiving proper framing.

• Check for faulty or incorrect cabling between Telco and CSX200.

• Request that the Telco verify the conﬁguration and operation of the circuit.

Status 2 (STS2) LED is GREEN

WPIM-SYNC Installed in CSX200

The Port is operating normally, Clear to Send (CTS) has been received by your WAN device.

• If it is not, check STS 1 to determine if the Port is Sending a Request to Send (RTS) to the CSU/

DSU it is connected to.

• Verify the cabling being used between the CSX200 and the CSU/DSU.

• Check the CSU/DSU for proper operation.

WPIM-HDSL Installed in CSX200

The port is operating normally, Loop 2 has synchronized with the HDSL circuit at the remote end (Full T1 mode only).

CSX200 Installation Guide 5-9

Chapter 5: Troubleshooting

Test (TST) LED is AMBER (blinking)

The device is in test mode.

• The CSX200 is running its Power-up Diagnostic Tests.

• Loopback Testing is underway on a WAN circuit.

Investigating Software Conﬁguration Problems

Software problems usually occur when your software conﬁguration contains incomplete or incorrect information.

Connection to Device Fails During Software Conﬁguration

• For a LAN connection, verify that the IP address matches the IP address previously stored into

the conﬁguration of the router. You must have previously (through QuickSET) set the Ethernet LAN IP address and Subnet Mask, enabled IP routing, saved the Ethernet conﬁguration changes and rebooted the router for the new IP address to take effect.

• Check that your LAN cable is wired correctly and each end securely plugged in.

• Make sure that an IP route exists between your local PC and the CSX200. The PC and CSX200

must be on the same IP subnetwork or the CSX200 must be reachable through a router on your LAN.

• Check Network TCP/IP properties under Windows 95 or Windows NT, as described in the

Read Me First! document.

User Cannot Communicate with Remote Network Station

If Bridging,

• Check that the Bridging Default Destination is set.

• Check that bridging to/from the remote router is set on.

• Be sure to reboot if you have made any bridging destination or control changes.

5-10 CSX200 Installation Guide

Investigating Software Configuration Problems

If TCP/IP Routing,

• Check that TCP/IP Routing is set on and is enabled at the remote end.

• Check that the IP address of the LAN beyond the remote router is correct, as well as the

associated Subnet Mask.

• If the remote router WAN IP address and Subnet Mask are required, check that they have been

speciﬁed correctly.

• Check that, if required, the source and remote WAN IP addresses are on the subnetwork.

• Check that you have seeded the routing table, if RIP is not allowed to ﬂow on the WAN link.

• Be sure to reboot if you have made any IP address, control or protocol option changes.

CSX200 Installation Guide 5-11

Chapter 5: Troubleshooting

5-12 CSX200 Installation Guide

WPIM Cable Speciﬁcations

NOTE

For all WPIM cables, there is part number information for ordering a standard 20-foot cable or a speciﬁed length of cable. The number 20 followed by the part number denotes the standard 20-foot cable. The letter “L” denotes the speciﬁed length required in feet or meters. For example: 9372095-3 denotes a 3 foot cable; 9372095-3M denotes a 3-meter cable.

WPIM-T1

This section provides the Cabletron Systems part number and connector speciﬁcations for WPIM-T1 interface cables.

T able A-1 provides connector type and part number information.

Table A-1 T-1 Interface Cable Part Numbers

Connector Type Part Number

RJ48C 9372094

T able A-2 provides RJ48 connector pin assignments.

Table A-2 T-1 Connector Pin Assignments

Pin Signal

1 Receive Ring 2 Receive Tip 3 Not Used 4 Transmit Ring 5 T r ansmit Tip 6 Not Used 7 Shield Ground 8 Shield Ground

CSX200 Installation Guide A-1

Appendix A: WPIM Cable Specifications

T able A-3 provides RJ48 DTE pin assignments.

Table A-3 DTE Pin Assignments

Pin Signal

1 Receive Ring 2 Receive Tip 3 Not Used 4 Transmit Ring 5 T r ansmit Tip 6 Not Used 7 Shield Ground 8 Shield Ground

T able A-4 provides RJ48 network pin assignments.

Table A-4 Network Pin Assignments

Pin Signal

1 Receive Ring 2 Receive Tip 3 Not Used 4 Transmit Ring 5 Transmit Tip 6 Not Used 7 Not Used 8 Not Used

A-2 CSX200 Installation Guide

WPIM-SY

This section provides the Cabletron Systems part number and connector speciﬁcations for the WPIM-SY interface cables.

T able A-5 provides the cable and interface types, electrical types, and part numbers for the

WPIM-SY.

Table A-5 WPIM-SY Interface Cables

Cable and Interface Type Electrical Type Part Number

RS449 RS422 9380120 V.35 V.35 9380121 RS232 RS232 9380122 X.21 X.21 9380123 RS530 RS422 9380124 RS530 ALT A RS422 9380125 RS530A RS422 9380126 RS530A ALT A RS422 9380127

CSX200 Installation Guide A-3

Appendix A: WPIM Cable Specifications

EIA-449

T able A-6 shows the connector number, cable assembly description, and connector type.

Table A-6 EIA-449 Interface

Connector Number Cable Assembly Description Connector Type

EIA-530A ALT A to EIA-449

2 DB-37 pin male connector

Sub DB 26-pin male connector

T able A-7 provides pin assignments for the EIA-449 interface cable.

Table A-7 EIA-449 Interface Cable Pin Assignment

MNEMONIC

BA DCE

CA DCE

DA DCE

Connector 1 EIA-530A ALT A

DIRECT

DTE

Transmit Signal Timing A 15 Transmit Signal Timing B 12 23 Send Timing B

Receive Signal Timing A 17

Receive Signal Timing B 9 26 Receive Timing B Transmit Signal Timing A 24 Transmit Signal Timing B 11 35 Terminal Timing B

NAME PIN PIN NAME

Transmit Data A 2 Transmit Data B 14 22 Send Data B

Receive Data A 3

Receive Data B 16 24 Receive Data B Clear to Send A 5 Clear to Send B 13 27 Clear to Send B

Request to Send A 4 Request to Send B 19 25 Request to Send B

PAIR

4 Send Data A

6 Receive Data A

9 Clear to Send A

7 Request to Send A

5 Send Timing A

8 Receive Timing A

17 T erminal Timing A

Connector 2 EIA-449

DIRECT

DCE SD

DTE

DCE RS

DTE

DCE TT

MNEMONIC

A-4 CSX200 Installation Guide

Table A-7 EIA-449 Interface Cable Pin Assignment (Continued)

WPIM-SY

Connector 1 EIA-530A ALT A

MNEMONIC

CE TM Test Mode 25 18 Test Mode TM CC DCE Ready 6 11 Data Mode DM CD DCE DTE Ready 20 12 Terminal Ready DCE TR

AC Signal Common 23 20 Receive Common RC

AB Signal Common 7

DIRECT

DTE

NAME PIN PIN NAME

Ring Indicator 22 15 Incoming Call

SHIELD 1

PAIR

19 30 37

Connector 2 EIA-449

DIRECT

DTE

Send Common

Terminal Ready B

Signal Ground

V.35

T able A-8 shows the connector number, cable assembly description, and connector type.

Table A-8 V.35 Interface

Connector Number Cable Assembly Description Connector Type

EIA-530A ALT A to V.35

2 M Series 34-pin male

Sub DB 26-pin male

MNEMONIC

TR_B

T able A-9 provides pin assignments for the V.35 interface cable.

Table A-9 V.35 Interface Cable Pin Assignment

Connector 1 EIA-530A ALT A

MNEMONIC

BA DCE

BB CB Clear to Send A 5 C D Ready to Send A 106

CA DCE Request to Send A 4 D C Request to Send A DCE 105

DIRECT

DTE

NAME PIN PIN NAME

Transmit Data A 2 Transmit Data B 14 S Transmit Data B Receive Data A 3 Receive Data B 16 T Receive Data B

PAIR

P Transmit Data A

R Receive Data A

CSX200 Installation Guide A-5

Connector 2 V.35

DIRECT

DCE 103

DTE

MNEMONIC

104

Appendix A: WPIM Cable Specifications

Table A-9 V.35 Interface Cable Pin Assignment (Continued)

Connector 1 EIA-530A ALT A

MNEMONIC

DA DCE

CE TM Test Mode 25 NN Test Indicator 142 CC DCE Ready 6 E Data Set Ready 107

RL Remote Loopback 21 N

LL Local Loopback 18 L Local Loopback 141

AC Signal Common 23 B Signal Common 102 AB Signal Common 7 B Signal Common 102

DIRECT

DTE

DCE

NAME PIN PIN NAME

Transmit Signal

Timing A

Transmit Signal

Timing B

Receive Signal

Timing A

Receive Signal

Timing B

Transmit Signal

Timing A

Transmit Signal

Timing B

Ring Indicator 22 J Calling Indicator

DTE Ready 20 H

SHIELD 1 DRAIN

PAIR

12 AA

11 W

Transmitter Signal

Receiver Signal

Transmitter Signal

Connector 2 V.35

Timing A

Timing B

Timing A

Timing B

Timing A

Timing B

Data T erminal

Ready

Loopback

Maintenance

DIRECT

DTE

DCE 113

DTE

DCE

MNEMONIC

114

115

125

108

140

A-6 CSX200 Installation Guide

WPIM-SY

EIA-232

T able A-10 shows the connector number, cable assembly description, and connector type.

Table A-10 EIA-232 Interface

Connector Number Cable Assembly Description Connector Type

EIA-530A ALT A to EIA-232

2 DB-25 pin male

Sub DB 26-pin male

T able A-11 provides pin assignments for the EIA-232 interface cable.

Table A-11 EIA-232 Interface Cable Pin Assignment

Connector 1 EIA-530A ALT A Connector 2 EIA-232

MNEMONIC

BA DCE Transmit Data 2 2 Transmit Data DCE BA BB CB Clear to Send 5 5 Clear to Send CB CA DCE Request to Send 4 4 Request to Send DCE CA

DD Receive Signal Timing 17 17

DA DCE Transmit Signal Timing 24 24 CE DTE Ring Indicator 22 22 Ring Indicator DTE CE RL

LL Local Loopback 18 18 Local Loopback LL TM CC DCE Ready 6 6 DCE Ready CC CD DCE DTE Ready 20 20 DTE Ready DCE CD

AC Signal Common 23 7 Signal Common AB AB Signal Common 7 7 Signal Common AB

DIRECT

DTE

DCE

DTE

NAME PIN PIN NAME

Receive Data 3 3 Receive Data

Transmit Signal Timing 15 15

Remote Loopback 21 21

Test Mode 25 25 Test Indicator

SHIELD 1

Transmitter Signal

Receiver Signal

Transmitter Signal

Loopback

Maintenance

Timing

DIRECT

DTE

DCE DA

DCE

DTE

MNEMONIC

CSX200 Installation Guide A-7

Appendix A: WPIM Cable Specifications

X.21

T able A-12 shows the connector number, cable assembly description, and connector type.

Table A-12 X.21 Interface

Connector Number Cable Assembly Description Connector Type

1 2 DB-15 pin male

EIA-530A ALT A to X.21

T able A-13 provides pin assignments for the X.21 interface cable.

Table A-13 X.21 Interface Cable Pin Assignment

Connector 1 EIA-530A ALT A

17 15

PAIR

2 Transmit A

4 Receive A

5 Indication A

3 Control A

Signal Element

8 Signal Ground G

Timing A

Signal Element

Timing B

MNEMONIC

BA DCE

BB DTE

CB DTE

CA DCE

DB DTE

AC DTE Common 7 AB DCE Common 23

DIRECT

NAME PIN PIN NAME

Transmit Data A 2 Transmit Data B 14 9 Transmit B

Receive Data A 3

Receive Data B 16 11 Receive B Clear to Send A 5 Clear to Send B 13 12 Indication B

Request to Send A 4 Request to Send B 19 10 Control B

T ransmit Signal Timing A

Receive Signal Timing A

T ransmit Signal Timing B

Receive Signal Timing B9 12

SHIELD 1 DRAIN

Sub DB 26-pin male

Connector 2 X.21

DIRECT

DCE T

DTE R

DTE I

DCE C

DTE S

MNEMONIC

A-8 CSX200 Installation Guide

WPIM-SY

EIA-530, EIA-530 ALT A, EIA-530 A, and EIA-530 A ALT A

T able A-14 shows the connector number, cable assembly description, and connector type for the

EIA-530, EIA-530 ALT A, EIA-530A, and EIA-530A ALT A, interface cables.

Table A-14 EIA-530, EIA-530 ALT A, EIA-530A, and EIA-530A ALT A Interfaces

Connector Number Cable Assembly Description Connector Type

EIA-530A ALT A to EIA-530

2 DB 25-pin male 1

EIA-530A ALT A to EIA-530 ALT A

2 Sub DB26-pin male 1

EIA-530A ALT A to EIA-530A

2 DB 25-pin male 1

EIA-530A ALT A to EIA -530A ALT A

2 Sub DB 26-pin male

Sub DB 26-pin male

T able A-15 provides the cable pin assignments for the EIA-530, EIA-530 ALT A, EIA-530A, and

EIA-530A AL T A, interface cables.

Table A-15 EIA-530, EIA-530 ALT A, EIA-530A, and EIA-530A ALT A Interface Cable Pin Assignments

MNEMONIC

BA DCE

CA DCE

Connector 1 EIA-530A ALT A

DIRECT

DTE

NAME PIN PIN NAME

Transmit Data A 2 Transmit Data B 14 14 Transmit Data B

Receive Data A 3

Receive Data B 16 16 Receive Data B Clear to Send A 5 Clear to Send B 13 13 Clear to Send B

Request to Send A 4 Request to Send B 19 19 Request to Send B

PAIR

2 Transmit Data A

3 Receive Data A

5 Clear to Send A

4 Request to Send A

Connector 2 EIA-530

DIRECT

DCE BA

DTE

DCE CA

MNEMONIC

CSX200 Installation Guide A-9

Appendix A: WPIM Cable Specifications

Table A-15 EIA-530, EIA-530 ALT A, EIA-530A, and EIA-530A ALT A Interface Cable Pin Assignments

Connector 1 EIA-530A ALT A

MNEMONIC

RL Remote Loopback 21 21 Remote Loopback RL

LL Local Loopback 18 18 Local Loopback LL TM CC DCE Ready 6 6 DCE Ready CC CD DCE DTE Ready 20 20 DTE Ready DCE CD

AC Signal Common 23 7 Signal Common AC

AC Signal Common 23 23 Signal Common AC AB Signal Common 7 7 Signal Common AB

CE DTE Ring Indicator 22 22 Ring Indicator DTE CE

DIRECT

Transmit Signal Timing A 15

Transmit Signal Timing B 12 12

DTE

Receive Signal Timing A 17

Receive Signal Timing B 9 9

Transmit Signal Timing A 24

DCE

DTE

Transmit Signal Timing B 11 11

SHIELD 1 DRAIN

NAME PIN PIN NAME

Test Mode 25 25 Test Mode

PAIR

Connector 2 EIA-530

Transmit Signal

Timing A

Transmit Signal

Timing B

Receive Signal

Timing A

Receive Signal

Timing B

Transmit Signal

Timing A

Transmit Signal

Timing B

DIRECT

DTE

DCE

DTE

MNEMONIC

a. This pin assignment only applies to the EIA-530A ALT A interface cable. b. This pin assignment only applies to the EIA-530A and EIA-530A ALT A interface cables.

A-10 CSX200 Installation Guide

WPIM-DDS

This section provides Cabletron Systems part number and connector speciﬁcations for the WPIM-DDS interface cable. The WPIM-DDS has one RJ45 port for a direct connection to a single Digital Data Service (DDS) circuit.

T able A-16 provides cable and interface type, and part number information for the WPIM-DDS

interface cable, and T able A-17 provides network Pin Assignment information for the DDS interface cable.

Table A-16 DDS Interface Cable Part Number

Cable and Interface Type Part Number

DDS 9360119

Table A-17 Network Pinout Assignments

PIN SIGNAL

1 Transmit Ring 2 Transmit Tip 3 Not Used 4 Not Used 5 Not Used 6 Not Used 7 Receive Tip 8 Receive Ring

CSX200 Installation Guide A-11

Appendix A: WPIM Cable Specifications

WPIM-E1

This section provides the Cabletron Systems part number and connector speciﬁcations for the WPIM-E1 interface cable.

T able A-18 shows the WPIM-E1 connector number, cable and interface type, connector type and

part number information.

Table A-18 WPIM-E1 Connector Information

Connector Number Cable and Interface Type Connector Type Part Number

1 2

E1 RJ45 9372095

T able A-19 provides WPIM-E1 network interface cable pin assignments.

Table A-19 Network Interface

Pin Signal

1 Receive Ring 2 Receiv e Tip 3 Shield Ground 4 Transmit Ring 5 Transmit Tip 6 Shield Ground 7 Not Used 8 Not Used

A-12 CSX200 Installation Guide

T able A-20 provides WPIM-E1 DTE interface cable pin assignments.

Table A-20 DTE Interface

Pin Signal

1 Receive Ring 2 Receive Tip 3 Shield Ground 4 Transmit Ring 5 Transmit Tip 6 Shield Ground 7 Not Used 8 Not Used

T able A-21 provides WPIM-E1 RJ45 network interface cable pin assignments.

Table A-21 Network Interface

WPIM-E1

Pin Signal

1 Receive Ring 2 Receive Tip 3 Not Used 4 Transmit Ring 5 Transmit Tip 6 Not Used 7 Not Used 8 Not Used

CSX200 Installation Guide A-13

Appendix A: WPIM Cable Specifications

WPIM-DI

This section provides Cabletron Systems part number and connector speciﬁcations for the WPIM-DI interface cables.

T able A-22 shows the connector number, cable assembly description, cable and interface type,

connector type and part number information for the WPIM-DI interface.

Table A-22 WPIM-DI Connector Information

Connector

Number

1 Network 2 Drop and Insert

Cable Assembly Description

Cable and Interface Type

DI RJ48 9372094

Connector Type

T able A-23 provides the WPIM-DI network interface cable pin assignments.

Table A-23 WPIM-DI Network

Pin Signal

1 Receive Ring 2 Receiv e Tip 3 AC Coupled Ground 4 Transmit Ring 5 Transmit Tip 6 AC Coupled Ground 7 AC Coupled Ground 8 AC Coupled Ground

Part Number

A-14 CSX200 Installation Guide

T able A-24 provides the WPIM-DI drop and insert interface cable pin assignments.

Table A-24 WPIM-DI Drop and Insert

Pin Signal

1 Transmit Ring 2 T r ansmit Tip 3 AC Coupled Ground 4 Receive Ring 5 Receive Tip 6 AC Coupled Ground 7 AC Coupled Ground 8 AC Coupled Ground

WPIM-HDSL

This section provides connector speciﬁcations for the WPIM-HDSL interface cables. Table A-25 provides pin assignments for the RJ-45 network interface connector.

Table A-25 WPIM-HDSL Network Interface Cable Pin Assignments

Pin Signal

1 HDSL Loop 1 (Ring1) 2 HDSL Loop 1 (Tip1) 3 Not Used 4 HDSL Loop 2 (Ring2) 5 HDSL Loop 2 (Tip2) 6 Not Used 7 Not Used 8 Chassis Ground

CSX200 Installation Guide A-15

Appendix A: WPIM Cable Specifications

A-16 CSX200 Installation Guide

Speciﬁcations and Standards Compliance

This chapter contains hardware speciﬁcations, and safety and compliance standards for the CSX200, and for the individual WPIMs that can be conﬁgured with this device.

Table B-1 Hardware Specifications

CSX200 - One WPIM interface (WPIM not included)

WAN Interface

LAN Interface 12 Ethernet ports, 10BASE-T (Type RJ45) Other Interfaces AC Power Connector Processor Intel i960 Width 17 in (43.6 cm) Height 2.8 in (7.2 cm) Depth 8.5 in (21.6 cm) Weight 4.8 lbs (10.56 kg)

CSX201 - One T-1 Interface CSX202 - One Synchronous Interface CSX203 - One DDS Interface

Power Supply Built-in power supply Voltage 100–125 Vac ~ 1.0 A, 200–240 Vac ~ 0.5 A Frequency 50/60 Hz Power Consumption 70 Watts maximum Operating Temperature 5° to 40°C (41° to 104°F) Storage Temperature -30° to 73°C (-22° to 164°F) Humidity 5% to 90% RH, non-condensing

CSX200 Installation Guide B-1

Appendix B: Specifications and Standards Compliance

CSX200 Regulatory Compliance

Safety — This unit meets the safety requirements of UL 1950, CSA C22.2 No. 950 and

EN 60950, IEC 950, and 73/23/EEC.

Electromagnetic Compatibility (EMC) — This unit meets the EMC requirements of FCC Part

15, EN 55022, EN 50082-1, 89/336/EEC, AS/NZS 3548, CSA C108.8, and VCCI V-3.

Individual WPIM Regulatory Compliance

The following sections provide regulatory compliance standards for the WPIM-TI, WPIM-SY, WPIM-DDS, WPIM-E1, WPIM-DI, WPIM-S/T , and the WPIM-HDSL. Cabletron Systems reserves the right to change these speciﬁcations at any time without notice.

WPIM-T1

This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-T1.

Safety — This unit meets the safety requirements of UL 1950, and CSA C22.2 No. 950. Electromagnetic Compatibility (EMC) — This unit meets the EMC requirements of FCC Part

15, VCCI V -3, and CSA108.8.

NEBS — This unit meets a minimum of Level 1 NEBS requirements in accordance with Bellcore

SR 3580.

TELECOM — FCC Part 68, CS-03.

B-2 CSX200 Installation Guide

Individual WPIM Regulatory Compliance

WPIM-SY

This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-SY.

Safety — This unit meets the safety requirements of UL1950, CSA C22.2 No. 950, EN 60950,

IEC 950, and 73/23/EEC.

EMI — This unit meets the EMI requirements of FCC Part 15, EN 55022, EN 50082-1,

AS/NZS 3548, 89/336/EEC, CSA108.8, and VCCI V-3.

TELECOM — 91/263/EEC, and NET 2.

WPIM-DDS

This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-DDS.

Safety — This unit meets the safety requirements of UL1950, and CSA C22.2 No. 950. (EMC) — This unit meets the EMC requirements of FCC Part 15, CSA108.8, and VCCI V-3. NEBS — This unit meets a minimum of Level 1 NEBS requirements in accordance with Bellcore

SR 3580.

TELECOM — FCC Part 68, CS-03.

CSX200 Installation Guide B-3

Appendix B: Specifications and Standards Compliance

WPIM-E1

This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-E1.

Safety — This unit meets the safety requirements of EN 60950, IEC 950, 73/23/EEC and

AS/NZS 3260.

Electromagnetic Compatibility (EMC) — This unit meets the EMI requirements of EN 55022,

EN 50082-1, AS/NZS 3548, and 89/336/EEC.

TELECOM — 91/263/EEC, CTR 12, TS 001, and TS 016.

WPIM-DI

This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-DI.

Safety — This unit meets the safety requirements of UL1950, and CSA C22.2 No. 950. Electromagnetic Compatibility (EMC) — This unit meets the EMI requirements of FCC Part

15, VCCI V -3, and CSA108.8.

TELECOM — The WPIM-DI meets FCC Part 68 and CS-03.

WPIM-HDSL

This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-HDSL.

Safety — This unit meets the safety requirements of UC1950, CSA 22.2 No. 950, EN 60950,

IEC 950 73/23/EEC.

Electromagnetic Compatibility (EMC) — This unit meets the EMC requirements of FCC

Part 15, EN 55022, VCCI V-3, CSA/08.8 EN 50082-1, AS/NZS 3548, 89/336/EEC.

NEBS — This unit meets a minimum of Level 1 NEBS requirements in accordance with Bellcore

GR 1089.

B-4 CSX200 Installation Guide

FCC Part 68 - User’s Information for CSX200

The following instructions are to ensure compliance with the Federal Communications Commission (FCC) Rules, Part 68:

1. All connections to the WPIM-T1, WPIM-DI and WPIM-DDS must be made using standard

plugs and jacks.

2. Before connecting your unit, you must inform the local telephone company of the following

information:

Table C-1 WPIM-DI and WPIM-T1

Port ID REN/SOC FIC USOC

04DU9-BN

WPIM-DI WPIM-T1

04DU9-DN

6.0N

Table C-2 WPIM-DDS (Only)

04DU9-1KN 04DU9-1SN 04DU9-1ZN

RJ48C RJ48X

Port ID REN/SOC FIC USOC

WPIM-DDS 6.0N

04DU5-56 04DU5-64

RJ48S

3. If the unit appears to be malfunctioning, it should be disconnected from the telephone lines until

you learn if your equipment or the telephone line is the source of the trouble. If your equipment needs repair, it should not be reconnected until it is repaired.

4. The CSU/DSU has been designed to prevent harm to the T1 and DDS network. If the telephone

company finds that the equipment is exceeding tolerable parameters, the telephone company can temporarily disconnect service, although they will attempt to give advance notice if possible.

5. Under the FCC Rules, no customer is authorized to repair this equipment. This restriction

applies regardless of whether the equipment is in or out of warranty.

CSX200 Installation Guide C-1

Appendix C: FCC Part 68 - User’s Information for CSX200

6. If the telephone company alters their equipment in a manner that will affect use of this device,

they must give you advance warning so as to give you the opportunity for uninterrupted service. You will be advised of your right to file a complaint with the FCC.

7. See the attached Affidavit on the following page. The Affidavit must be completed by the

installer.

8. In the event of equipment malfunction, all repairs should be performed by our Company or an

authorized agent. It is the responsibility of the users requiring service to report the need for service to our Company or to one of our authorized agents. Refer to the Getting Help section of Chapter 1, Introduction, for more information on how to get service and support.

C-2 CSX200 Installation Guide

FCC Part 68 - User’s Information for CSX200

AFFIDAVIT FOR THE CONNECTION OFCUSTOMER EQUIPMENT

TO 1.544 MBPS AND/OR SUBRATE DIGITAL SERVICES

For the work to be performed in the certiﬁed territory of

Telco’s name:

State of:

Country of:

I, , of

(Name of Authorized Representative) (Customer Name)

(Customer’s Address) (Telephone Number)

being duly sworn, state:

I have responsibility for the operation and maintenance of the terminal equipment to be connected to

1.544 Mbps and/or Subrate digital services. The terminal equipment to be connected complies with Part 68 of the Commission’s rules except for the encoded analog content and billing protection speciﬁcations. With respect to encoded analog content and billing protection:

• I attest that all operations associated with the establishment, maintenance and adjustment of the digital CPE with respect to encoded analog content and encoded billing information continuously complies with Part 68 of the FCC’s Rules and Regulations.

• The digital CPE does not transmit digital signals containing encoded analog or billing information which is intended to be decoded within the telecommunications network.

• The encoded analog and billing protection is factory set and is not under the control of the customer.

CSX200 Installation Guide C-3

Appendix C: FCC Part 68 - User’s Information for CSX200

I attest that the operator(s) maintainer(s) of the digital CPE responsible for the establishment, maintenance and adjustment of the encoded analog content and billing information has (have) been trained to perform these functions by successfully completing one of the following: Check appropriate one(s).

a. A training course provided by the manufacturer/grantee of the equipment used to encode

analog signals; or

b. A training course provided by the customer or authorized representative, using training

materials and instructions provided by the manufacturer/grantee of the equipment used to encode analog signals; or

c. An independent training course (e.g. trade school or technical institution) recognized by the

manufacturer/grantee of the equipment used to encode analog signals; or

d. In lieu of the proceeding training requirements, the operator(s) maintainer(s) is (are) under

the control of a supervisor trained in accordance with

above.

I agree to provide

(Telco’s Name)

with proper documentation

to demonstrate compliance with the information as provided in the proceeding paragraph, if so requested.

Subscribed and sworn to me this

(Signature)

(Title)

(Date)

day of , 19 .

(Notary Public)

My commission expires:

C-4 CSX200 Installation Guide

10BASE-T — IEEE 802.3 standard for the use of Ethernet LAN technology over Unshielded

Twisted Pair wiring, running at 10 Mbps.

ARP — Address Resolution Protocol. An Internet protocol used to bind an IP address to Ethernet/

802.3 addresses.

ASCII — American Standard Code for Information Interchange. It is an 8-bit code for character

representation.

AUI — Attachment Unit Interface. An IEEE 802.3 transceiver cable connecting the network

device (such as a router) to the MAU (media access unit).

Bandwidth on Demand — Feature providing the capability of adjusting the bandwidth (opening

or closing multiple B channels) when the load in trafﬁc increases or decreases.

Bridge — A device that segments network trafﬁc. A bridge maintains a list of each node on the

segment and only trafﬁc destined for a node on the adjacent segment is passed across the bridge. A bridge operates at Layer 2 of the OSI reference model.

B Channel — In ISDN, a full-duplex, 64 Kbps channel used for sending user data.

Glossary

BRI — Basic Rate Interface. The ISDN interface providing two 64 Kbps B channels for voice,

data and video transmission and one 16 Kbps D channel for signaling and data transmission.

CHAP — Challenge Handshake Authentication Protocol. A security protocol supported under

point-to-point protocol (PPP) used to prevent unauthorized access to de vices and remote networks. Uses encryption of password, device names and random number generation.

DCE — Data Communications Equipment. Equipment used within a network to transfer data

from source to destination such as modems.

D Channel — In ISDN, a full-duplex 16 Kbps channel used for link setup. Data Compression — Techniques used to reduce the number of bits transferred across the

communication links that represent the actual data bits. Compression is used to optimize use of WAN links and speed data transmission.

CSX200 Installation Guide D-1

Appendix D: Glossary

DHCP — Dynamic Host Conﬁguration Protocol is a protocol for automatic TCP/IP conﬁguration

that provides static and dynamic address allocation and management.

Dial on Demand — Dial up WAN resources are accessed only when remote access is required

and released as soon as the resource is no longer needed.

DTE — Data Terminating Equipment. DTE refers to equipment used in a network as the data

source and/or destination, such as computers.

DTMF — Dual Tone Multi-Frequency. TOUCHTONE as opposed to Dial Pulse (DP). DTR — Data Terminal Ready. RS232 signal used for indicating to the DCE the readiness to

transmit and receive data.

EtherTalk — AppleTalk protocols running on Ethernet. Filter — Feature to control the ﬂow of data based on protocol or bridge information. Filters can

be speciﬁc to allow data through or prevent transmission.

Firewall — A combination of techniques used to protect one network from unknown networks

and users on the outside. Firewalls can ﬁlter or block trafﬁc and act as a management and netw ork security point where all trafﬁc can be scrutinized.

Frame — A group of data generated by Data Link Layer operation. HDSL — High bit rate Digital Subscriber Line. A technology to put two-way T1 on a normal

unshielded, bridged (but not loaded) twisted pair without using repeaters.

In-Band Signaling — Transmission within the frequency range used for data transmission; i.e.,

results in use of bandwidth normally reserved for data.

IP — Internet protocol. A network layer protocol which allows a packet to traverse multiple

networks on the way to its ﬁnal destination.

IP Address — Internet address. A 32-bit address assigned to devices that participate in a netw ork

using TCP/IP. An IP address consists of four octets separated with periods deﬁning network, optional subnet and host sections.

IPX (Internet Packet Exchange) — A proprietary Network layer protocol developed by Novell

and used in NetWare networks.

D-2 CSX200 Installation Guide

Glossary

ISDN — Integrated Services Digital Network. Digital transmission standard deﬁning

communication protocols permitting telephone networks to carry data, voice, fax and other streams.

Leased Line — A telecommunications line between two service points leased from a

communications carrier for private use, usually incurring a monthly service rate.

LEDs (Light Emitting Diodes) — Type of indicator lights on the panel of a device. Local Area Network (LAN) — A network connecting computers over a relatively small

geographic area (usually within a single campus or building).

MAC Layer/Address — Media Access Control layer/address deﬁned by the IEEE 802.3

speciﬁcation which deﬁnes media access including framing and error detection. Part of the OSI reference model Data Link layer.

Metric — An algorithm used by routers to determine the best path for transmitting packets to a

remote destination based on considerations such as time, delay, cost, etc.

Modem — Modulator/Demodulator. A device that converts digital signals to/from analog signals

for transmission over analog communications lines.

Multi-Link Protocol — A protocol, deﬁned in RFC 1717, that deﬁnes a way to perform inverse

multiplexing on the TCP/IP point-to-point protocol (PPP); i.e., the ability to use multiple serial WAN channels for transferring one datastream. With MLP, a user can send and receive data over both B channels in an ISDN basic-rate interface connection

NAT — Network Address Translation uses a unique IP address for a WAN interface. This IP

Address is negotiated through PPP or assigned statically by the Internet Service Provider (ISP). NAT reduces the number of unique IP addresses for all clients using a particular WAN interface to one.

NetWare — A Network Operating System developed by Novell, Inc. providing shared access to

ﬁles and other network services.

Network Layer — Layer 3 of the OSI reference model that provides the protocol routing

function.

Node — Refers to a termination point for communication links; entity that can access a network.

CSX200 Installation Guide D-3

Appendix D: Glossary

OSI — Open System Interconnection. An international standard developed by ITU (formally

CCITT) and ISO (International Organization for Standardization) to facilitate data networking multi-vendor interoperability. The OSI Reference Model deﬁnes seven layers, each providing speciﬁc network functions.

Packet — A group of data that includes a header and usually user data for transmission through a

network.

Ping (Packet Internet Groper) — An echo message, available within the TCP/IP protocol suite,

sent to a remote node and returned; used to test the accessibility of the remote node.

PPP (Point-to-Point Protocol) — A Data Link layer protocol that provides asynchronous and

synchronous connectivity between computer/network nodes. Includes standardization for security and compression negotiation.

Q.921 — ISDN Data Link layer speciﬁcation for the user-to-network interface. Q.931 — ISDN speciﬁcation for call set-up and signaling on ISDN connections. RFC — Request for Comment. Documentation describing Internet communications

speciﬁcations (e.g., Telnet, TFTP). Often these RFCs are used to achieve multi-vendor interoperability during implementation.

RJ11 — Standard 4-wire connectors for telephone lines. RJ45 — Standard 8-wire connectors used for ISDN lines and 10 BASE-T connections. RIP (Routing Information Protocol) — Protocols used in IP and IPX for broadcasting open path

information between routers to keep routing tables current.

Routing — A Network layer function that determines the path for transmitting packets through a

network from source to destination.

RS-232 — EIA standard specifying the physical layer interface used to connect a device to

communications media.

Serialization Frames — Frames sent out by servers under IPX to check whether illegal copies of

NetWare are in use on the network.

Service Advertising Protocol — Protocol used in IPX for broadcasting information about

services available on the network, such as ﬁle servers, CD-ROM drives and modem pools.

D-4 CSX200 Installation Guide

Glossary

SNMP — Simple Network Management Protocol. A widely implemented Internet network

management protocol that allows status monitoring, getting/setting of parameters for conﬁguration and control of network devices, such as routers and bridges.

Split B Channels — Each 64 Kbps ISDN B-channel can be used individually for a separate data

connection.

Spooﬁng — Spooﬁng is a technique used to remove poll and update service frames from WAN

links while ensuring that the network continues to operate normally. Spooﬁng is employed to minimize dial-up line connection time.

Subnet Address — An extension of the Internet 32-bit addressing scheme that allows the

separation of physical or logical networks within the single network number assigned to an organization. TCP/IP entities outside this organization have no knowledge of the internal “subnetting.”

Subnet Mask — A 32-bit internet protocol address mask used to identify a particular

subnetwork.

TCP/IP — Transmission Control Protocol/Internet Protocol. Refers to a set of internetworking

protocols developed by the U.S. Department of Defense that deﬁne a two level layered approach for interoperability. TCP provides a connection-oriented Transport layer ensuring end-to-end reliability in data transmission. IP provides for Network layer connectivity using connectionless datagrams.

Telco Cloud — The “cloud” of switched virtual connections over a Wide Area Network (WAN). TELNET — Internet standard protocol for remote terminal emulation that allows a user to

remotely log in to another device and appear as if directly connected.

TFTP — Trivial File Transfer Protocol. A simpliﬁed version of the File Transfer Protocol (FTP)

allowing for ﬁle transfer between computers over a network.

Transparent Bridging — Bridging technique used in Ethernet networks that allows transfer of

frames across intermediate nodes using tables associating end nodes with bridging addresses. Bridges are unknown to the end nodes.

UDP — User Datagram Protocol. A connectionless protocol used to pass packets across an

internet network, requiring no handshaking between source and destination.

CSX200 Installation Guide D-5

Appendix D: Glossary

Watchdog Frames — Frames sent out by servers to clients, under IPX, to verify that clients are

still logged on.

Wide Area Network — A communications network that is geographically dispersed thus

requiring links provided by communications carriers.

Workstation — Computer or terminal used by the systems administration or user.

D-6 CSX200 Installation Guide

Index

Numerics

10BASE-T

connection 3-3 impedance 3-1 length 3-1 requirements 3-1 temperature 3-2

Bridge ﬁltering 2-11 Bridging 2-9 Bridging and routing 2-10

Cable speciﬁcations

10BASE-T UTP 3-1

Challenge Handshake Authentication Protocol

(CHAP) 2-7

COMP/ENCR installation 4-5

Daughter Board 2-3 Dynamic Host Conﬁguration Protocol

(DHCP) 2-5

Hardware specs B-1 HDLC 2-5 Help 1-3

related manuals 1-3

High-bit rate Digital Subscriber Line

(HDSL) 2-9

IEEE 802.1d bridging 2-10 IEEE 802.3 Ethernet 2-4 IP

about IP routing 2-11 internet firewall 2-11

IPX

about IPX routing 2-11

ISDN 2-9

LAN support 2-2 Link Quality Monitoring (LQM) 2-8

MIB support 2-12

EMC B-2, B-3, B-4 EMI B-3, B-4

Firmware Data Compression 2-5 Flash EEPROMs 2-3

Network Address Translator (NA T) 2-5 Network information worksheets A-1

Password Authentication Protocol (PAP) 2-7 Point-to-Point Protocol (PPP) 2-7 PPP 2-4

Getting help 1-4

CSX200 Installation Guide Index-1

Index

Rack Mounting

accessory kit 2-3 Remote Network Management 2-3 Routing 2-10

Safety Requirements B-3 SNMP 2-12 SNMP Community Names

read-only 2-12

read-write 2-12

super-user 2-12 Software and ﬁrmware upgrades 2-15

technical support 1-3 Troubleshooting 5-1

bridging 5-10

power 5-4
