2M46-04R

2M46-04R/2M46-04RDC

SmartSwitch 2000

User’s Guide

PWR

RESET

CPU

COM

HSIM 1HSIM 2

9032363-02

Only qualiﬁed personnel should perform installation procedures.

NOTICE

Cabletron Systems reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL,

INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.



Order Number: 9032363-02 September 1998

Cabletron Systems, SPECTRUM, LANVIEW, QuickSET

trademarks and All other product names mentioned in this manual may be trademarks or registered trademarks of

their respective companies.

SmartSwitch

is a trademark of Cabletron Systems, Inc.

, and

SecureFast are registered

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment uses, generates, and can radiate radio frequency energy and if not installed in accordance with the operator’s manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense.

WARNING:

party responsible for compliance could void the user’s authority to operate the equipment.

Changes or modiﬁcations made to this device which are not expressly approved by the

2M46-04R/2M46-04RDC User’s Guide i

Notice

INDUSTRY CANADA NOTICE

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada.

VCCI NOTICE

This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.

CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT

IMPORTANT:

This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (the “Program”) contained in this package. The Program may be contained in ﬁrmware, chips or other media. BY UTILIZING THE ENCLOSED PRODUCT, YOU ARE AGREEING TO BECOME BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND THE LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND.

Before utilizing this product, carefully read this License Agreement.

ii 2M46-04R/2M46-04RDC User’s Guide

Notice

CABLETRON SOFTWARE PROGRAM LICENSE

1. LICENSE

package subject to the terms and conditions of this License Agreement. You may not copy, reproduce or transmit any part of the Program except as permitted by the

2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or disassemble the

Program.

3. APPLICABLE LA W. This License Agreement shall be interpreted and governed under the laws

and in the state and federal courts of New Hampshire. You accept the personal jurisdiction and venue of the New Hampshire courts.

. You have the right to use only the one (1) copy of the Program provided in this

EXCLUSION OF WARRANTY AND DISCLAIMER OF LIABILITY

1. EXCLUSION OF

writing, Cabletron makes no warranty, expressed or implied, concerning the Program (including its documentation and media).

CABLETRON DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE SUPPLIED TO YOU BY CABLETRON IN WRITING, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THE PROGRAM, THE ACCOMP ANYING WRITTEN MA TERIALS, AND ANY A CCOMP ANYING HARDWARE.

2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL

CABLETRON OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS, PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS) ARISING OUT OF THE USE OR INABILITY TO USE THIS CABLETRON PRODUCT, EVEN IF CABLETRON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR ON THE DURATION OR LIMITATION OF IMPLIED WARRANTIES, IN SOME INSTANCES THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU.

WARRANTY. Except as may be specifically provided by Cabletron in

UNITED STATES GOVERNMENT RESTRICTED RIGHTS

The enclosed product (a) was developed solely at private expense; (b) contains “restricted computer software” submitted with restricted rights in accordance with Section 52227-19 (a) through (d) of the Commercial Computer Software - Restricted Rights Clause and its successors, and (c) in all respects is proprietary data belonging to Cabletron and/or its suppliers.

For Department of Defense units, the product is licensed with “Restricted Rights” as deﬁned in the DoD Supplement to the Federal Acquisition Regulations, Section 52.227-7013 (c) (1) (ii) and its successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at

252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505.

2M46-04R/2M46-04RDC User’s Guide iii

Notice

SAFETY INFORMATION

CLASS 1 LASER TRANSCEIVERS

THE FE-100F3 FAST ETHERNET INTERFACE MODULE, FPIM-05 AND

FPIM-07 FDDI PORT INTERFACE MODULES, AND APIM-29 ATM

PORT INTERFACE MODULE USE CLASS 1 LASER TRANSCEIVERS.

READ THE FOLLOWING SAFETY INFORMATION BEFORE

INSTALLING OR OPERATING THESE MODULES.

The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow any user adjustment. Class 1 Laser transceivers comply with the following safety standards:

• 21 CFR 1040.10 and 1040.11 U.S. Department of Health and Human Services (FDA).

• IEC Publication 825 (International Electrotechnical Commission).

• CENELEC EN 60825 (European Committee for Electrotechnical Standardization). When operating within their performance limitations, laser transceiver output meets the Class 1

accessible emission limit of all three standards. Class 1 levels of laser radiation are not considered hazardous.

SAFETY INFORMATION

CLASS 1 LASER TRANSCEIVERS

LASER RADIATION AND CONNECTORS

When the connector is in place, all laser radiation remains within the ﬁber. The maximum amount of radiant power exiting the ﬁber (under normal conditions) is -12.6 dBm or 55 x 10-6 watts.

Removing the optical connector from the transceiver allows laser radiation to emit directly from the optical port. The maximum radiance from the optical port (under worst case conditions) is

0.8 W cm-2 or 8 x 103 W m2 sr-1.

Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter.

iv 2M46-04R/2M46-04RDC User’s Guide

DECLARATION OF CONFORMITY

Notice

Application of Council Directive(s):

Manufacturer’s Name:

Manufacturer’s Address:

European Representative Name:

European Representative Address:

Conformance to Directive(s)/Product Standards:

Equipment T ype/Environment:

W e the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives.

Manufacturer Legal Representative in Europe

89/336/EEC 73/23/EEC

Cabletron Systems, Inc. 35 Industrial Way

PO Box 5005 Rochester, NH 03867

Mr. J. Solari Cabletron Systems Limited

Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England

EC Directive 89/336/EEC EC Directive 73/23/EEC EN 55022 EN 50082-1 EN 60950

Networking Equipment, for use in a Commercial or Light Environment.

Industrial

Mr. Ronald Fotino Mr. J. Solari

___________________________________ ___________________________________

Full Name Full Name Principal Compliance Engineer Managing Director - E.M.E.A.

___________________________________ ___________________________________

Title Title Rochester, NH, USA Newbury, Berkshire, England

___________________________________ ___________________________________

Location Location

2M46-04R/2M46-04RDC User’s Guide v

Notice

vi 2M46-04R/2M46-04RDC User’s Guide

CHAPTER 1 INTRODUCTION

1.1 Using This Guide.........................................................................1-1

1.2 Structure of This Guide................................................................1-1

1.3 2M46-04R Overview....................................................................1-2

1.3.1 Connectivity ....................................................................1-3

1.3.2 Full Duplex Switched Ethernet........................................ 1-3

1.3.3 Auto-Negotiation.............................................................1-4

1.3.4 SmartTrunk.....................................................................1-4

1.3.5 Runtime IP Address Discovery.......................................1-5

1.3.6 Management...................................................................1-5

1.3.7 Switching ........................................................................1-6

1.3.8 Standards Compatibility..................................................1-6

1.3.9 Year 2000 Compliance ...................................................1-6

1.3.10 LANVIEW Diagnostic LEDs............................................ 1-6

1.3.11 Optional Features ...........................................................1-7

1.4 Document Conventions...............................................................1-8

1.5 Getting Help.................................................................................1-9

1.6 Related Manuals........................................................................1-10

CHAPTER 2 NETWORK REQUIREMENTS

2.1 SmartTrunk..................................................................................2-1

2.2 100BASE-TX Network.................................................................2-1

2.3 100BASE-FX Fiber Optic Network .............................................. 2-2

CHAPTER 3 INSTALLATION

3.1 Unpacking the 2M46-04R............................................................3-1

3.2 Installing Options.........................................................................3-2

3.3 Installing the 2M46-04R...............................................................3-2

3.3.1 Tabletop or Shelf Installation ..........................................3-2

3.3.2 2M46-04R and 2M46-04RDC Rackmount Installation.... 3-4

3.4 Connecting Power.......................................................................3-8

3.4.1 Connecting Power to the 2M46-04R............................... 3-8

3.4.2 Connecting Power to the 2M46-04RDC .........................3-9

3.5 Connecting to the Network........................................................3-11

3.5.1 Connecting a UTP Segment to the FE-100TX.............. 3-11

3.5.2 Connecting a Fiber Optic Segment to the

FE-100FX and FE-100F3 .............................................3-13

3.6 Completing the Installation........................................................3-15

2M46-04R/2M46-04RDC User’s Guide vii

CONTENTS

CHAPTER 4 TROUBLESHOOTING

4.1 Using LANVIEW...........................................................................4-1

4.2 FE-100TX LED.............................................................................4-4

4.3 Troubleshooting Checklist............................................................4-6

4.4 Using the RESET Button .............................................................4-7

CHAPTER 5 LOCAL MANAGEMENT

5.1 Overview......................................................................................5-1

5.2 Local Management Keyboard Conventions.................................5-2

5.3 Management Terminal Setup.......................................................5-3

5.3.1 Console Cable Connection..............................................5-3

5.3.2 Management Terminal Setup Parameters ......................5-5

5.3.3 Telnet Connections .........................................................5-6

5.3.4 Connecting an Uninterruptible Power Supply..................5-6

5.4 Accessing Local Management.....................................................5-8

5.4.1 Navigating Local Management Screens..........................5-9

5.4.2 Selecting Local Management Menu Screen Items........5-11

5.4.3 Exiting Local Management Screens..............................5-11

5.5 Device Menu Screen..................................................................5-12

5.6 Device Configuration Menu Screen ...........................................5-14

5.7 General Configuration Screen ...................................................5-16

5.7.1 Setting the IP Address...................................................5-19

5.7.2 Setting the Subnet Mask...............................................5-20

5.7.3 Setting the Default Gateway..........................................5-21

5.7.4 Setting the TFTP Gateway IP Address .........................5-21

5.7.5 Setting the Device Date.................................................5-22

5.7.6 Setting the Device Time................................................5-23

5.7.7 Entering a New Screen Refresh Time...........................5-23

5.7.8 Setting the Screen Lockout Time..................................5-24

5.7.9 Setting the Operational Mode........................................5-24

5.7.10 Configuring the COM Port.............................................5-25

5.7.10.1 Changing the COM Port Application.............5-26

5.7.11 Clearing NVRAM...........................................................5-28

5.7.12 Enabling/Disabling IP Fragmentation............................5-29

5.8 SNMP Community Names Screen.............................................5-29

5.8.1 Establishing Community Names ...................................5-31

5.9 SNMP Traps Screen..................................................................5-32

5.9.1 Configuring the Trap Table............................................5-33

5.10 Switch Configuration Screen......................................................5-34

5.10.1 Setting the STA.............................................................5-36

5.10.2 Setting the Age Time Field............................................5-36

5.10.3 Setting (Enabling or Disabling) the Port Status.............5-37

viii 2M46-04R/2M46-04RDC User’s Guide

CONTENTS

5.11 Device Specific Configuration Menu Screen.............................5-37

5.12 System Resources Screen........................................................5-39

5.12.1 Setting the Reset Peak Switch Utilization.....................5-41

5.13 High Speed Interface Configuration Menu Screen....................5-42

5.14 High Speed Interface Configuration Screen..............................5-44

5.14.1 Configuring an FE-100FX or FE-100F3

in Port 1 or 2 .................................................................5-46

5.14.2 Setting the FE-100FX or FE-100F3

Desired Operational Mode............................................5-47

5.14.3 Configuring an FE-100TX in Port 1 or 2 .......................5-47

5.14.4 Setting the FE-100TX Desired Operational Mode ........5-47

5.14.5 Setting the FE-100TX Advertised Ability....................... 5-48

5.15 Flash Download Screen ............................................................ 5-48

5.15.1 Image File Download Using BootP...............................5-50

5.15.2 Image File Download Using TFTP................................5-51

5.15.3 Image File Download Using Runtime ...........................5-52

5.16 Port Redirect Function Screen .................................................. 5-53

5.16.1 Displaying the Source and Destination Entries............. 5-54

5.16.2 Changing Source and Destination Ports....................... 5-55

5.17 Broadcast Suppression Screen.................................................5-56

5.17.1 Setting the Threshold.................................................... 5-57

5.17.2 Setting the Reset Peak Rate ........................................5-58

5.18 Device Statistics Menu Screen..................................................5-58

5.19 Switch Statistics Screen............................................................5-60

5.19.1 Using the Clear Counters Command............................5-61

5.20 Interface Statistics Screen.........................................................5-62

5.20.1 Displaying Interface Statistics.......................................5-65

5.20.2 Using the Clear Counters Command............................5-66

5.21 RMON Statistics Screen............................................................5-66

5.21.1 Displaying RMON Statistics..........................................5-70

5.21.2 Using the Clear Counters Command............................5-70

5.22 Network Tools............................................................................5-70

5.22.1 Built-in Commands .......................................................5-72

5.22.2 Special Commands....................................................... 5-80

APPENDIX A SPECIFICATIONS

A.1 Device Specifications ..................................................................A-1

A.2 Physical Properties......................................................................A-1

A.3 Electrical Specifications...............................................................A-1

A.4 Environmental Requirements......................................................A-2

A.5 Input/Output Ports .......................................................................A-2

A.6 COM Port/Pin Assignments.........................................................A-3

A.7 Regulatory Compliance...............................................................A-3

2M46-04R/2M46-04RDC User’s Guide ix

CONTENTS

APPENDIX B FE-100TX, FE-100FX, AND FE-100F3

SPECIFICATIONS

B.1 FE-100TX.................................................................................... B-1

B.2 FE-100FX.................................................................................... B-2

B.3 FE-100F3.................................................................................... B-3

APPENDIX C OPTIONAL INSTALLATIONS AND

MODE SWITCH BANK SETTINGS

C.1 Required Tools............................................................................C-1

C.2 Removing the Chassis Cover .....................................................C-2

C.2.1 Setting the Mode Switch.................................................C-3

C.3 Installing Optional Fast Ethernet Interface Modules...................C-6

INDEX

x 2M46-04R/2M46-04RDC User’s Guide

CHAPTER 1

INTRODUCTION

Welcome to the

2M46-04R/04RDC SmartSwitch 2000 User’s Guide.

This guide describes the 2M46-04R and 2M46-04RDC SmartSwitch 2000 devices and provides information concerning network requirements, installation, troubleshooting, and the use of Local Management.

NOTE

The 2M46-04R and 2M46-04RDC have identical features and functions with the exception of their power source connection. The 2M46-04R connects to an ac power source and the 2M46-04RDC connects to a dc power source. Both the 2M46-04R and 2M46-04RDC are referred to as the 2M46-04R unless otherwise speciﬁed in this guide.

1.1 USING THIS GUIDE

Read through this guide completely to understand the 2M46-04R features, capabilities, and Local Management functions.

1.2 STRUCTURE OF THIS GUIDE

This guide is organized as follows:

Chapter 1,

describes the 2M46-04R features. Directions about how to obtain additional help and a list of related manuals are also included.

Introduction

, outlines the contents of this manual and brieﬂy

Chapter 2,

Network Requirements

, explains the network requirements

to consider before installing the 2M46-04R.

Chapter 3,

Installation

, provides instructions on how to install the

2M46-04R and connect segments to the device.

Chapter 4,

Troubleshooting

, describes the function of the LANVIEW

LEDs, which can help to quickly diagnose network/operational problems.

Chapter 5,

Local Management

, describes how to access Local Management and use the Local Management screens to manage the 2M46-04R.

2M46-04R/2M46-04RDC User’s Guide 1-1

Chapter 1:

Introduction

Appendix A,

Speciﬁcations

, contains information on functionality and operating speciﬁcations, connector pinouts, environmental requirements, and physical properties.

Appendix B,

FE-100TX, FE-100FX, and FE-100F3 Speciﬁcations

, contains information about FE-100TX pinouts and information concerning cable types used with the FE-100FX and FE-100F3.

Appendix C,

Optional Installations and Mode Switch Bank Settings

, describes how to install optional Fast Ethernet Interface Modules and ho w to set the Mode Switch.

1.3 2M46-04R OVERVIEW

The 2M46-04R, shown in Figure 1-1, is a 4-port high-speed network switching device that supports traditional switching (bridging), IEEE

802.1Q switching (port based VLANs), and Cabletron Systems SecureFast Switching Virtual Network technology. The 2M46-04R also has redundant power supplies.

Ports 1 and 2 on the 2M46-04R support optional Fast Ethernet Interface Modules and can provide uplinks to 100BASE-TX or 100BASE-FX Fast Ethernet networks. There are also two HSIM slots that support optional High Speed Interface Modules (HSIMs) that provide additional connectivity to various networking technologies such as Asynchronous Transfer Mode (ATM), Wide Area Networks (WANs), and Fiber Distribution Data Interface (FDDI).

Optional HSIM Slots

HSIM 2

Port Status LEDs

HSIM 1

Optional Fast Ethernet Interface Module Ports 1 and 2

2314_01

RESET

2M46-04R

COM

2M46-04R

RESET Button

PWR CPU

System LEDs

COM Port

Figure 1-1 The 2M46-04R

1-2 2M46-04R/2M46-04RDC User’s Guide

2M46-04R Overview

The 2M46-04R is a tabletop unit that can be installed in a standard 19-inch rack using the supplied rack mounting hardware.

The 2M46-04R has two ac power supplies. The po wer supplies load share 50% (+/-5%) of the power required by the device. If one power supply fails, the remaining power supply assumes the entire load of the device without interruption to network trafﬁc. Each power supply module supports its own ac input connection, which allows the user to connect each power supply to a different ac power circuit.

The 2M46-04RDC operates from two dc voltage power sources. The power supplies load share 50% (+/-5%) of the power required by the device. If one power supply fails, the remaining power supply assumes the entire load of the device without interruption to network trafﬁc. Each power supply module supports its own dc input connection, which allows the user to connect each power supply to a different dc power source.

1.3.1 Connectivity

The 2M46-04R has two front panel slots (ports 1 and 2) for optional Fast Ethernet Interface Modules to support an uplink to 100 Mbps Fast Ethernet backbones or a high speed connection to a local server . There are also two HSIM slots for optional HSIMs to provide additional connectivity to various networking technologies.

1.3.2 Full Duplex Switched Ethernet

The optional Fast Ethernet Interface Modules can be conﬁgured to operate in Full Duplex Switched Ethernet (FDSE) mode which provides up to 200 Mbps of throughput per interface.

2M46-04R/2M46-04RDC User’s Guide 1-3

Chapter 1:

Introduction

1.3.3 Auto-Negotiation

The optional FE-100TX Fast Ethernet Interface Module can auto-negotiate the type of connection required to provide a link to another device. During Auto-Negotiation, two devices automatically exchange information “telling” each other what their operating capabilities are. The Auto-Negotiation feature targets the maximum capabilities that can be reached between the two devices. For example, a 2M46-04R FE-100TX Fast Ethernet Interface Module adjusts to 100 Mbps when the device on the other end of the connection can also adjust to 100 Mbps. If the device on the other end of the connection can only operate at 10 Mbps, then the 2M46-04R Fast Ethernet Interface Module simply adjusts to 10 Mbps.

When Auto-Negotiation is supported at both ends of a link, the two devices dynamically adjust to full or half duplex operation based on the maximum capability that can be reached between the two devices. If the device connected to the 2M46-04R cannot auto-negotiate, the 2M46-04R Fast Ethernet Interface Module operates according to the capabilities of the other device.

1.3.4 SmartTrunk

SmartTrunk, also referred to as SmartTrunking, is Cabletron Systems’ terminology for load balancing or load sharing. SmartTrunk technology provides an easy-to-implement mechanism to group, or aggregate, multiple physical links together to scale the backbone bandwidth beyond the limitations of a single link. All links are user-conﬁgurable so administrators can scale the backbone bandwidth by adding SmartTrunk links. The SmartTrunk beneﬁts are as follows:

•

All purchased bandwidth is used.

•

Distributed, resilient links increase reliability and performance.

•

Multiple technologies are supported within a single trunk for maximum ﬂexibility.

For more information about SmartTrunk, refer to the Cabletron Systems

SmartTrunk User’s Guide

1-4 2M46-04R/2M46-04RDC User’s Guide

2M46-04R Overview

1.3.5 Runtime IP Address Discovery

This feature enables the 2M46-04R to automatically accept an IP address from a BootP server on the network into NVRAM without requiring the user to enter an IP address through Local Management.

When the 2M46-04R is connected to the network and powered up, Runtime IP Address Discovery (RAD) checks the 2M46-04R for an IP address. If one has not yet been assigned, RAD checks to see if any of the 2M46-04R interfaces have a link. If so, RAD sends out Reverse Address Resolution Protocol (RARP) and BootP requests to obtain an IP address from a BootP server on the network.

The RAD requests start out at an interval of 1 second, then the interval doubles after every transmission until an interval of 300 seconds is reached. At this point, the interval remains at 300 seconds. The RAD requests continue until an IP address is received from a BootP server, or an IP address is entered using Local Management.

1.3.6 Management

Management of the 2M46-04R is accomplished using Local Management tools or remote SNMP management stations. Local Management is accessible through the RS232 COM port on the front panel using a local VT100 terminal, or a remote VT100 terminal via a modem connection, and in-band via a Telnet connection. In-band remote management is possible through any SNMP compliant Network Management Software.

Local Management provides the ability to manage the 2M46-04R and any of the optional Fast Ethernet Interface Modules installed in ports 1 and 2 and the optional High Speed Interface Modules (HSIMs).

The associated High Speed Interface Module user’s guide provides detailed information about Local Management of the HSIM.

Information about how to access and use Local Management is contained in Chapter 5.

2M46-04R/2M46-04RDC User’s Guide 1-5

Chapter 1:

Introduction

1.3.7 Switching

The 2M46-04R provides traditional switching (802.1D), IEEE 802.1Q switching, or SecureFast Switching (SFS) Virtual Network Services between all of the optional Fast Ethernet Interface Modules and High Speed Interface Modules (HSIMs). SFS and 802.1Q switching allow for migration to Virtual Network technologies without requiring the replacement of existing equipment.

1.3.8 Standards Compatibility

The optional Fast Ethernet Interface Modules are fully compliant with the IEEE 802.3u standard.The 2M46-04R provides IEEE 802.1D Spanning Tree Algorithm (STA) support or DEC spanning tree support to enhance the overall reliability of the network and protect against “loop” conditions. The 2M46-04R supports a wide variety of industry standard MIBs including RFC 1213 (MIB II), RFC 1271 (RMON), RFC 1317 (RS232 MIB), RFC 1493 (Bridge MIB), RFC 1573 (Evolution of MIB II Interfaces), and RFC 1354 (FIB MIB). A full suite of Cabletron Systems Enterprise MIBs provide a wide array of statistical information to enhance troubleshooting.

1.3.9 Year 2000 Compliance

The 2M46-04R has an internal clock that can maintain the time and date beyond the year 1999.

1.3.10 LANVIEW Diagnostic LEDs

LANVIEW diagnostic LEDs serve as an important troubleshooting aid by providing an easy way to observe the status of indi vidual ports and overall network operations. Chapter 4 provides details about the 2M46-04R LANVIEW LEDs.

1-6 2M46-04R/2M46-04RDC User’s Guide

2M46-04R Overview

1.3.11 Optional Features

Options for the 2M46-04R include Fast Ethernet Interface Modules and High Speed Interface Modules to add uplink capability. Cabletron Systems provides Fast Ethernet Interface Modules to support uplinks to 100 Mbps Ethernet backbones or high speed connections to local servers. The Fast Ethernet Interface Modules are listed in Table 1-1.

P/N Description Application

FE-100TX

FE-100FX

FE-100F3

Table 1-1 Fast Ethernet Interface Modules

Uses RJ45 connector

Uses SC connector

Supports Category 5 Unshielded Twisted Pair (UTP) with impedance of 85 to 111 ohms.

Supports multimode ﬁber optic cabling.

Supports single mode ﬁber optic cabling.

Other Fast Ethernet Interface Modules ma y be available for the

NOTE

2M46-04R. Check the Release Notes included with the 2M46-04R.

High Speed Interface Modules (HSIMs) are available from Cabletron Systems for additional connectivity to various networking technologies. The HSIMs available for the 2M46-04R are listed in the Release Notes.

2M46-04R/2M46-04RDC User’s Guide 1-7

Chapter 1:

Introduction

1.4 DOCUMENT CONVENTIONS

The following conventions are used throughout this document:

Note

NOTE

TIP

symbol. Calls the reader’s attention to any item of

information that may be of special importance.

Tip

symbol. Conveys helpful hints concerning procedures or

actions.

CAUTION

WARNING

Caution

damage to the equipment.

Electrical Hazard Warning

that could result in personal injury or death due to an electrical hazard.

Warning

personal injury or death.

symbol. Contains information essential to avoid

symbol. Warns against an action

symbol. Warns against an action that could result in

1-8 2M46-04R/2M46-04RDC User’s Guide

Getting Help

1.5 GETTING HELP

For additional support related to this device or document, contact the Cabletron Systems Global Call Center:

World Wide Web http://www.cab letron.com/ Phone (603) 332-9400 Internet mail support@cabletron.com FTP ftp://ftp.cabletron.com/

To send comments or suggestions concerning this document, contact the Cabletron Systems Technical Writing Department via the following email address: TechWriting@cabletron.com

Make sure to include the document Part Number in the email message.

Before calling the Cabletron Systems Global Call Center, have the following information ready:

•

Your Cabletron Systems service contract number

•

A description of the failure

anonymous your email address

•

A description of any action(s) already taken to resolve the problem (e.g., changing mode switches, rebooting the unit, etc.)

•

The serial and revision numbers of all involved Cabletron Systems products in the network

• A description of your network environment (layout, cable type, etc.)

• Network load and frame size at the time of trouble (if known)

• The device history (i.e., have you returned the device before, is this a

recurring problem, etc.)

• Any previous Return Material Authorization (RMA) numbers

2M46-04R/2M46-04RDC User’s Guide 1-9

Chapter 1: Introduction

1.6 RELATED MANUALS

The following manuals may help to set up, control, and manage the 2M46-04R using SNMP network management systems:

Cabletron Systems ATM Technology Guide Cabletron Systems FDDI Technology Guide Cabletron Systems HSIM-A6DP User’s Guide Cabletron Systems HSIM-F6 User’s Guide Cabletron Systems HSIM-FE6 User’s Guide Cabletron Systems HSIM-W6 Installation Guide Cabletron Systems HSIM-W84 Installation Guide Cabletron Systems Local Management for CSX200, CSX400,

CSX400-DC, HSIM-W6, and HSIM-W84

Cabletron Systems HSIM-W87 User’s Guide Cabletron Systems HSIM-G01/G09 User’s Guide Cabletron Systems Ethernet Technology Guide Cabletron Systems Cabling Guide Cabletron Systems Port Based VLAN User’s Guide Cabletron Systems SmartTrunk User’s Guide These manuals can be obtained from the World Wide Web in Adobe

Acrobat Portable Document Format (PDF) at the following site:

http://www.cabletron.com/

NOTE

1-10 2M46-04R/2M46-04RDC User’s Guide

All documentation for Cabletron Systems SecureFast VLAN Manager software can be found on the VLAN Manager CD-ROM.

The documentation for the HSIM-W6 and HSIM-W84 is on the QuickSET CD-ROM.

CHAPTER 2

NETWORK REQUIREMENTS

Before installing the 2M46-04R or Fast Ethernet Interface Module, review the requirements and speciﬁcations referred to in this chapter.

The network installation must meet the guidelines to ensure satisfactory performance of this equipment. Failure to follow the guidelines may produce poor network performance.

NOTE

The Cabletron Systems

Guide

, referred to in the follo wing sections, can be f ound on the Cabletron Systems World Wide Web site: http://www.cabletron.com/

Cabling Guide and SmartTrunk User’s

2.1 SmartTrunk

To connect the 2M46-04R to a network so it can take advantage of the SmartTrunk feature, there are certain rules concerning port connections and conﬁgurations that must be followed for proper operation. Refer to the Cabletron Systems SmartTrunk User’s Guide for additional information.

2.2 100BASE-TX NETWORK

The 2M46-04R, with an FE-100TX installed in ports 1 or 2, provides an RJ45 connection that supports Category 5 unshielded twisted pair (UTP) cabling, with an impedance between 85 and 111 ohms. The device at the other end of the twisted pair segment must support IEEE 802.3u 100BASE-TX Fast Ethernet operations. The cabling between the devices must meet the test criteria for a 100BASE-TX link for the devices to operate at 100 Mbps. Refer to the Cabletron Systems Cabling Guide for details.

NOTE

2M46-04R/2M46-04RDC User’s Guide 2-1

The 2M46-04R with an FE-100TX installed is capable of operating at either 10 or 100 Mbps. The FE-100TX can automatically sense the speed of the other device and adjust its speed accordingly.

Chapter 2: Network Requirements

2.3 100BASE-FX FIBER OPTIC NETWORK

Ports 1 and 2 of the 2M46-04R support the Cabletron Systems FE-100FX and FE-100F3 ﬁber optic interface modules. The device at the other end of the ﬁber optic segment must support the 100BASE-FX Fast Ethernet operations. The cabling between the devices must meet the test criteria for a 100BASE-FX link for the devices to operate at 100 Mbps. Refer to the Cabletron Systems Cabling Guide for details.

Multimode Mode Fiber Optic Cable

The test characteristics of a 100BASE-FX segment is covered in the Cabletron Systems Cabling Guide.

Single Mode Fiber Cable

The test characteristics of a single mode ﬁber optic link are similar to those for a multimode ﬁber optic 100BASE-FX link, with the following exceptions:

• Cable type - 8.3/125 µM

• Maximum Length - no more than 5 km from Data T erminal Equipment

(DTE) to DTE in half duplex mode, or 20 km from DTE to DTE in full duplex mode.

2-2 2M46-04R/2M46-04RDC User’s Guide

CHAPTER 3

INSTALLATION

Only qualiﬁed personnel should install the 2M46-04R.

This chapter provides all instructions required to install the 2M46-04R. A Phillips screwdriver is required to install the device.

3.1 UNPACKING THE 2M46-04R

Unpack the 2M46-04R as follows:

1. Open the box and remove the packing material protecting the

2M46-04R.

2. Verify the contents of the carton as listed in Table 3-1.

Table 3-1 Contents of 2M46-04R Carton

Item Quantity

2M46-04R 1 Antistatic Wrist Strap 1 Console Cable Kit 1 Rackmount Kit 1 Strain-Relief Bracket 1 Power Cords (2M46-04R only) 2 Release Notes 1

3. Remove the black and amber tape seal on the non-conductive bag to

remove the 2M46-04R.

4. Perform a visual inspection of the device. If there are any signs of

physical damage, contact the Cabletron Systems Global Call Center.

2M46-04R/2M46-04RDC User’s Guide 3-1

Chapter 3: Installation

3.2 INSTALLING OPTIONS

NOTE

Install any optional equipment before proceeding to

Section 3.3.

If the 2M46-04R is to be installed with an optional Fast Ethernet Interface Module, refer to Appendix C for installation instructions. The installation instructions for the HSIMs are in the associated HSIM user’s guide.

3.3 INSTALLING THE 2M46-04R

The 2M46-04R may be installed on a tabletop, shelf, or in a 19-inch rack.

Section 3.3.1 describes a tabletop or shelf installation and Section 3.3.2

describes the rackmount installation.

To prevent possible damage to the unit, do NOT connect power to the 2M46-04R until instructed to do so.

3.3.1 Tabletop or Shelf Installation

Tabletop and shelf installations must be within reach of the network cabling and meet the requirements listed below:

• Locate the 2M46-04R within seven feet of an appropriately grounded

power receptacle that meets the power supply requirements listed in

Appendix A, Speciﬁcations. (This requirement does not apply to the

2M46-04RDC.)

• In a shelf installation, the shelf must support 13.6 kg (30 lb) of static

weight for all devices.

• Maintain a temperature of between 5°C (41°F) and 40°C (104°F) at

the installation site with ﬂuctuations of less than 10°C (18°F) per hour.

Maintain a 2-inch clearance from the left, right, and rear sides of the device to provide adequate ventilation and prevent

CAUTION

3-2 2M46-04R/2M46-04RDC User’s Guide

overheating.

Installing the 2M46-04R

Locate the 2M46-04R on an unrestricted free surface area as shown in

Figure 3-1. Proceed to Section 3.4.1 for 2M46-04R power connection

instructions and to Section 3.4.2 for 2M46-04RDC power connection instructions.

A = 15 cm (6 in) B = 57 cm (22.5 in) C = 53 cm (21 in) D = 213 cm (7 ft)

HSIM 1HSIM 2

2M46-04R

PWR CPU

RESET

COM

Figure 3-1 Tabletop or Shelf Installation

2314-0

2M46-04R/2M46-04RDC User’s Guide 3-3

Chapter 3: Installation

3.3.2 2M46-04R and 2M46-04RDC Rackmount Installation

Before installing the 2M46-04R/04RDC into a rack, ensure that

WARNING

Guidelines for the Rackmount Installation

The installation site must be within reach of the network cabling and meet the requirements listed below:

• An appropriate grounded power receptacle must be located within

• Maintain a temperature of between 5°C (41°F) and 40°C (104°F) at

CAUTION

the rack supports the device(s) without compromising the stability of the rack. Otherwise, personal injury and/or equipment damage may result.

seven feet of the device. (This requirement does not apply to the 2M46-04RDC.)

the installation site with ﬂuctuations of less than 10°C (18°F) per hour.

To ensure proper ventilation and prevent overheating, leave a minimum clearance space of 5.1 cm (2.0 in) at the left, right,

and rear of the 2M46-04R.

To install the 2M46-04R/04RDC in a 19-inch rack, Cabletron Systems includes an accessory kit containing the rackmount brackets, mounting screws, and a strain-relief bracket for cable management.

Attaching the Strain-Relief Bracket

Attach the strain-relief bracket to the front of the 2M46-04R/04RDC as follows:

1. Locate the strain-relief bracket and four 8-32 x 3/8-inch pan-head

screws in the rackmount kit.

Do not attempt to attach the strain-relief bracket with screws other than the 8-32 x 3/8-inch screws included with the

CAUTION

2M46-04R/04RDC. Use of longer screws may damage the unit.

2. Place the 2M46-04R/04RDC upside down (as shown in Figure 3-2) on

a clean flat surface. Then attach the strain-relief bracket to the bottom of the 2M46-04R/04RDC using the four 8-32 x 3/8-inch pan-head screws.

3-4 2M46-04R/2M46-04RDC User’s Guide

Screws (4)

Strain-Relief Bracket

Installing the 2M46-04R

HSIM 1HSIM 2

CPU PWR

2M46-04R

RESET

COM

2314-47

Figure 3-2 Attaching the Strain-Relief Bracket

There are two methods for attaching the rackmount brackets for the 2M46-04R and 2M46-04RDC. Proceed to the section entitled

Rackmounting the 2M46-04R for instructions on installing the

2M46-04R, or the section entitled Bonding the Rackmount Brackets to

the 2M46-04RDC, which discusses the GR-1089-CORE Section 9

bonding requirements for the 2M46-04RDC when installing rackmount brackets.

Rackmounting the 2M46-04R

Proceed as follows to install the 2M46-04R into a 19-inch rack.

1. Remove and discard the four cover screws (two from each side)

located along the front edges of each side of the 2M46-04R.

2. Locate the four 6-32 x 3/8-inch flat head cover replacement screws in

the rackmount kit. Use these screws to attach the rackmount brackets to the 2M46-04R as shown in Figure 3-3.

2M46-04R/2M46-04RDC User’s Guide 3-5

Chapter 3: Installation

Rackmount Brackets (2)

HSIM 1HSIM 2

2314-04

2M46-04R

PWR CPU

RESET

COM

Screws (4)

Figure 3-3 Installing the Rackmount Brackets

3. With the mounting brackets installed, position the 2M46-04R between

the vertical frame members of the 19-inch rack and fasten it securely with mounting screws as shown in Figure 3-4.

19-Inch Rack

PWR CPU

RESET

2M46-04R

COM

Screws (4)

Figure 3-4 Installing the 2M46-04R in a Rack

HSIM 1HSIM 2

2314-03

Bonding the Rackmount Brackets to the 2M46-04RDC

If the 2M46-04RDC is going to be mounted in a rack and needs to meet the GR-1089-CORE Section 9 bonding requirements, use the following instructions to install the 2M46-04RDC into a 19-inch rack.

1. Remove and discard the four cover screws (two from each side)

located along the front edges of each side of the 2M46-04RDC.

2. Remove the paint from around the area near the mounting holes on the

left and right side of the cover of the 2M46-04RDC. See Figure 3-5.

3. Apply a thin layer of anti-oxidant to the surface where the paint was

removed.

3-6 2M46-04R/2M46-04RDC User’s Guide

Installing the 2M46-04R

4. Locate the four 6-32 x 3/8-inch flathead cover replacement screws in

the rackmount kit. Use these screws to attach the rackmount brackets to the 2M46-04RDC as shown in Figure 3-5.

Rackmount Brackets (2)

HSIM 1HSIM 2

PWR

RESET

2M46-04RDC

CPU

COM

Remove Paint

Screws (4)

2272-04

Figure 3-5 Installing the 2M46-04RDC Rackmount Brackets

5. With the mounting brackets installed, position the 2M46-04RDC

between the vertical frame members of the 19-inch rack and fasten it securely with thread-forming mounting screws (user supplied) as shown in Figure 3-6.

19-Inch Rack

HSIM 1HSIM 2

PWR

RESET

2M46-04RDC

CPU

COM

Screws (4)

2272_05

Figure 3-6 Installing the 2M46-04RDC in a Rack

2M46-04R/2M46-04RDC User’s Guide 3-7

Chapter 3: Installation

3.4 CONNECTING POWER

The 2M46-04R connects to an ac power source and the 2M46-04RDC connects to a dc power source. If you are connecting power to a 2M46-04R, proceed to section 3.4.1. If you are connecting power to a 2M46-04RDC, proceed to section 3.4.2.

3.4.1 Connecting Power to the 2M46-04R

NOTE

The 2M46-04R has two power supplies with automatic voltage sensing that allow connection to power sources ranging from 100–125 Vac or 200–250 Vac, 50/60 Hz.

To connect the 2M46-04R to the power sources, proceed as follows:

1. Insert the connector of each power cord into the two power supplies

and insert the plug of each power cord into a grounded wall outlet (see

Figure 3-7). To take advantage of the load sharing and redundancy

capabilities, each power cord must be plugged into a dedicated ac outlet. The POWER LED turns ON (green) and the CPU LED turns ON (green) briefly.

Power Supplies

2363-62

Figure 3-7 2M46-04R Rear View

NOTE

It takes approximately one minute for the 2M46-04R to boot up.

3-8 2M46-04R/2M46-04RDC User’s Guide

Connecting Power

2. Observe the LANVIEW LEDs. After a successful boot, the CPU LED

turns ON (green). If the PWR LED turns amber, there is no power redundancy. Check the power cord connections and the power source. If there are no problems with the power cord connections or power source and the PWR LED is still not green, contact the Cabletron Systems Global Call Center. Refer to Section 1.5 for details.

3.4.2 Connecting Power to the 2M46-04RDC

ONLY QUALIFIED PERSONNEL SHOULD PERFORM THESE INSTALLATION PROCEDURES.

TO REDUCE THE RISK OF ELECTRIC SHOCK OR ENERGY HAZARDS:

• CONNECT TO A RELIABLY GROUNDED 48/60 VDC SELV SOURCE.

• THE BRANCH CIRCUIT OVERCURRENT PROTECTION MUST BE RATED AT 15 A.

• USE 12 OR 14 AWG CONDUCTORS ONLY.

• A READILY ACCESSIBLE DISCONNECT DEVICE THAT IS SUITABLY APPROVED AND RATED, SHALL BE INCORPORATED IN THE FIELD WIRING.

TO BE INSTALLED IN A RESTRICTED ACCESS AREA IN ACCORDANCE WITH THE NEC OR THE AUTHORITY HAVING JURISDICTION.

The 2M46-04RDC has two dc power supplies with their own on/off switch and input power strip, and are each rated at 100 watts. Each dc power supply input requires either a 48 Vdc or 60 Vdc power source,

4.0 A (maximum), supplied by three 12 or 14 AWG (American Wire Gauge) copper wires. These wires must be terminated with either ring or spade terminals that accept a #6 screw.

2M46-04R/2M46-04RDC User’s Guide 3-9

Chapter 3: Installation

To connect the 2M46-04RDC to a 48/60 Vdc power source, f ace the back of the device, then refer to Figure 3-8 and proceed as follows:

DC Input Power Strip

ON/OFF

Earth Ground

48 or 60 Vdc

Power Source

2363-02

Figure 3-8 Connecting to a 48/60 Vdc Power Supply

To prevent injury or damage to the equipment, remove power from a 48/60 Vdc power source before proceeding with the following steps.

1. Connect the ground terminal of the dc input power strip to an

appropriate earth ground.

2. Refer to Figure 3-8 for the proper connections to a 48/60 Vdc power

source. Then connect the output leads from the 48/60 Vdc power source being used to the negative (-) and positive (+) terminals on the dc input power strip.

3. Repeat steps 1 and 2 to connect a 48/60 Vdc power source to the other

dc input power strip on the 2M46-04RDC.

4. Restore power to the 48/60 Vdc power sources.

5. Press the power switches to on.

3-10 2M46-04R/2M46-04RDC User’s Guide

Connecting to the Network

NOTE

The 2M46-04RDC sounds an audible alarm if there is a polarity reversal. If the alarm sounds, turn off the 48/60 Vdc power source to that power supply. Then reverse the positive and negative leads to the dc input power strip of that power supply. Restore power from the 48/60 Vdc power source. Press the on/off switch to on. If the alarm sounds again, press the power switch to off and contact the Cabletron Systems Global Call Center. Refer to Section 1.5.

3.5 CONNECTING TO THE NETWORK

This section provides the procedures for connecting UTP and ﬁber optic segments from the network or other devices to the 2M46-04R.

NOTE

Ports 1 and 2 support FE-100TX, FE-100FX, or FE-100F3 Fast Ethernet Interface Modules. Refer to Section 3.5.1 to make a UTP cable connection to an optional FE-100TX in port slot 1 or 2. Refer to

Section 3.5.2 to make an SC ﬁber optic cable connection to an optional

FE-100FX or FE-100F3 in port slot 1 or 2.

If the 2M46-04R is being installed in a network using SmartTrunking, there are rules concerning the network cable and port conﬁgurations that must be followed for SmartTrunking to operate properly. Before connecting the cables, refer to the Cabletron Systems

Guide

for the conﬁguration information.

SmartTrunk User’s

Refer to the associated High Speed Interface Module user’ s guide to make connections to an optional High Speed Interface Module installed in the HSIM slots.

3.5.1 Connecting a UTP Segment to the FE-100TX

An FE-100TX installed in port slot 1 and/or 2 has an internal crossover . If you need a crossover, set the Fast Ethernet Interface Module crossover switch shown in Figure 3-9 to the crossed over position marked with an X. If you do not need a crossover, set the Fast Ethernet Interface Module crossover switch shown in Figure 3-9 to the straight-through (not crossed over) position, marked with an =.

2M46-04R/2M46-04RDC User’s Guide 3-11

Chapter 3: Installation

Position X (crossed over)

1. RX+

2. RX-

3. TX+

4. NC

5. NC

6. TX-

7. NC

8. NC

FE-100TX

Position = (not crossed over)

1. TX+

2. TX-

100

3. RX+

4. NC

Figure 3-9 FE-100TX Crossover Switch

A schematic of a crossover cable is shown in Figure 3-10.

NOTE: RX+/RX– and TX+/TX– must share a common color pair.

Figure 3-10 Schematic of Crossover Cable

RJ45 Port RX+ RX– 2

TX+ TX–

3 6

RJ45 to RJ45

10BASE-T Device Port

5. NC

6. RX-

7. NC

8. NC

1 2

3 6

16651_05

RX+ RX–

TX+ TX–

2251-31

Connect an FE-100TX to a twisted pair segment as follows:

1. Ensure that the device connected to the other end of the segment is

powered ON.

2. Connect the twisted pair segment to the module by inserting the RJ45

connector on the twisted pair segment into the RJ45 port on the module shown in Figure 3-9.

3. Verify that a link exists by checking that the port RX LED is ON

(flashing amber, blinking green, or solid green). If the RX LED is OFF and the TX LED is not blinking amber, perform the following steps until it is on:

a. Verify that the 100BASE-TX de vice at the other end of the twisted

pair segment is powered up.

3-12 2M46-04R/2M46-04RDC User’s Guide

Connecting to the Network

b. Verify that the RJ45 connector on the twisted pair segment has the

proper pinouts.

c. Check the cable for continuity. d. Make sure that the twisted pair connection meets the cable

specifications outlined in the Cabletron Systems Cabling Guide.

e. Confirm that the crossover switch is in the correct position.

If a link is not established, see Chapter 4, Troubleshooting, before contacting the Cabletron Systems Global Call Center (refer to Section 1.5 for details).

3.5.2 Connecting a Fiber Optic Segment to the FE-100FX and FE-100F3

The FE-100FX and FE-100F3 have SC style network ports (see

Figure 3-11).

NOTES

Fiber Optic Network Connection

An odd number of crossovers (preferably one) must be maintained between like devices so that the transmit port of one device is connected to the receive port of the other device and vice versa.

If the ﬁber optic cable being used has SC style connectors that do not resemble MIC style connectors, or has SC connectors on one end and a different type on the other, such as ST connectors, ensure that the proper crossing over occurs.

1. Remove the protective rubber covers from the fiber optic ports on the

applicable port on the module and from the ends of the connectors.

The FE-100F3 uses Class 1 lasers. Do not use optical instruments to view the laser output. The use of optical

CAUTION

instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter.

2M46-04R/2M46-04RDC User’s Guide 3-13

Chapter 3: Installation

Do not touch the ends of the ﬁber optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants.

CAUTION

Contamination of the ends causes problems in data transmissions. If the ends become contaminated, blow the surfaces with a canned duster. A ﬁber port cleaning swab saturated with optical-grade isopropyl alcohol ma y also be used to clean the ends.

2. Insert one end of the SC connector into the FE-100FX or FE-100F3

installed in the 2M46-04R. See Figure 3-11.

3. At the other end of the fiber optic cable, attach the SC connector to the

other device.

HSIM 1

RX LED

1960-34

Figure 3-11 FE-100FX and FE-100F3 Ports

3-14 2M46-04R/2M46-04RDC User’s Guide

Completing the Installation

4. Verify that a link exists by checking that the port RX LED is ON

(flashing amber, blinking green, or solid green). If the RX LED is OFF and the TX LED is not blinking amber, perform the following steps until it is on:

a. Check that the po wer is turned on for the device at the other end of

the ﬁber optic cable.

b. Verify proper crossover of fiber strands between the applicable

port on the 2M46-04R and the fiber optic device at the other end of the fiber optic cable.

c. Verify that the fiber connection meets the dB loss specifications

outlined in the Cabletron Systems Cabling Guide.

If a link is not established, see Chapter 4, Troubleshooting, before contacting the Cabletron Systems Global Call Center (refer to

Section 1.5, for details).

3.6 COMPLETING THE INSTALLATION

After installing the 2M46-04R and any optional Fast Ethernet Interface Modules and HSIMs as appropriate, and making the connections to the network, proceed as follows:

1. Secure the cables by running the cables along the strain-relief bracket

and tying them to the strain-relief bracket using cable ties.

2. The 2M46-04R is now ready to be set up through Local Management.

Refer to Chapter 5, Local Management, for information on how to access and use Local Management to configure the 2M46-04R.

2M46-04R/2M46-04RDC User’s Guide 3-15

Chapter 3: Installation

3-16 2M46-04R/2M46-04RDC User’s Guide

CHAPTER 4

TROUBLESHOOTING

This chapter provides information concerning the following:

• Using the LANVIEW diagnostic and status monitoring system

• Troubleshooting network and 2M46-04R operational problems

• Using the RESET button

4.1 USING LANVIEW

The 2M46-04R uses the Cabletron Systems built-in visual diagnostic and status monitoring system called LANVIEW. The LANVIEW LEDs (Figure 4-1) allow quick observation of the network status to aid in diagnosing network problems. Refer to Table 4-1 for a description of the LEDs.

For a functional description of the LANVIEW LED on the optional Fast Ethernet Interface Module (FE-100TX), refer to Section 4.2.

All LEDs for the High Speed Interface Module (HSIM) are located on the HSIM and are described in the associated HSIM user’s guide.

PWR

HSIM-ASDP

HSIM 1

PWR CPU

2M46-04R

COM

RESET

CPU

TXRX

2314-36

Figure 4-1 LANVIEW LEDs

2M46-04R/2M46-04RDC User’s Guide 4-1

Chapter 4: Troubleshooting

NOTE

tables indicate the following:

Flashing indicates an irregular LED pulse. Blinking indicates a steady LED pulse (50% on, 50% off). Solid indicates a steady LED light. No pulsing.

Table 4-1 LANVIEW LEDs

LED Color State Recommended Action

The terms flashing, blinking, and solid used in the following

PWR Green Functional. Power

supply(ies) operating normally.

Amber This indication only

applies when there are two power supplies. Indicates loss of power supply redundancy.

CPU Off Power off. Power up device.

Red Blinking. Hardware

failure has occurred. Solid. Resetting,

normal power up reset.

Amber Blinking. Crippled. Contact the Cabletron

Solid. Testing. None. Green Solid. Functional. None. Amber

and Green

Booting. Alternately

blinks amber and

green while booting.

None.

1. Ensure that the power cords are plugged in correctly and that there is power at the power source.

2. Contact the Cabletron Systems Global Call Center (GCC).

Contact the Cabletron Systems GCC.

None.

Systems GCC.

None.

4-2 2M46-04R/2M46-04RDC User’s Guide

Using LANVIEW

Table 4-1 LANVIEW LEDs (Continued)

LED Color State Recommended Action

RX (Receive)

TX (Transmit)

Off No link. No activity.

Port enabled or disabled.

Green Solid. Port enabled,

link, no activity. Blinking. Port

disabled, link.

Amber Flashing. Port

enabled, link, activity.

Red Diagnostic failure. Contact the Cabletron

Off Port enabled, and no

activity.Should ﬂash green every two seconds indicating BPDUs being sent if STA is enabled and there is a valid link.

Green Flashing. Indicates

activity. Rate indicates data rate.

Green Blinking. Port

disabled, link.

Amber Blinking. Port in

standby. Port may be disabled due to Spanning T ree .

Red Flashing. Indicates

collision rate. Solid. Diagnostic

failure.

None.

Systems GCC.

1. Ensure that the STA is enabled and that there is a valid link.

2. Contact the Cabletron Systems GCC.

None unless a high rate of collisions exist. If so, check network conﬁguration.

None.

1. Ensure that the port is not disabled.

2. Contact the Cabletron Systems GCC.

None.

Contact the Cabletron Systems GCC.

2M46-04R/2M46-04RDC User’s Guide 4-3

Chapter 4: Troubleshooting

4.2 FE-100TX LED

The optional FE-100TX has one LED labeled 10/100. The 10/100 LED together with the receive LED allo ws the user to determine the link status and the operating speed of the Fast Ethernet Interface Module. The 10/100 LED and the Receive (RX) LED are shown in Figure 4-2.

Table 4-2 and Table 4-3 provide a functional description of the 10/100

LED when the RX LED is on or off, respectively.

LED

100

Receive (RX) LED

FE-100TX

Figure 4-2 FE-100TX LED

HSIM 1

100

1960-41

NOTE

LED Color Indication

10/100

on.

Table 4-2 10/100 LED Indications When RX LED Is On

Off FE-100TX is operating at 10 Mbps. Green FE-100TX is operating at 100 Mbps.

4-4 2M46-04R/2M46-04RDC User’s Guide

A link exists if the associated port (1 or 2) RX (Receive) LED is

FE-100TX LED

NOTE

LED Color Indication

10/100

is off.

Table 4-3 10/100 LED Indications When RX LED Is Off

No link or no cable attached. FE-100TX

Off

Green

forced to 10 Mbps operation, or is manually set to “auto-negotiate” mode.

No link or no cable attached. FE-100TX is forced to 100 Mbps operation.

No link exists if the associated port (1 or 2) RX (Receive) LED

2M46-04R/2M46-04RDC User’s Guide 4-5

Chapter 4: Troubleshooting

4.3 TROUBLESHOOTING CHECKLIST

If the 2M46-04R is not working properly , refer to Table 4-4 for a checklist of possible problems, causes, and recommended actions to resolve the problem.

Table 4-4 Troubleshooting Checklist

Problem Possible Cause Recommended Action

All LEDs are OFF. Loss of power. Check for proper connection

of the power cable and its access to a live outlet.

Installed improperly. Check the installation.

No Local Management Password screen.

Cannot contact the device from in-band management.

Port(s) goes into standby for no apparent reason.

User parameters (IP address, Device and Module name, etc.) were lost when the 2M46-04R power was cycled or the front panel RESET button was pressed.

Autobaud is enabled. Press ENTER (RETURN)

(may take up to four times).

Terminal setup is not correct.

Improper console cable used.

Improper Community Names T ab le.

IP address not assigned. Refer to Chapter 5 for IP

Port is disabled. Enable port. No link to device. Check link to device. Loop condition detected. Review network design and

Mode switch (7), NVRAM Reset, was changed sometime before either cycling power or pressing the RESET button causing the user-entered parameters to reset to factory default settings.

Refer to Chapter 5 for proper setup procedures.

Refer to Appendix A for proper console port pinouts.

Refer to Chapter 5 for Community Names Table setup.

address assignment procedure.

delete unnecessary loops. Call the Cabletron Systems Global Call Center if the problem continues.

Reenter the lost parameters as necessary. Call the Cabletron Systems Global Call Center if problem continues.

4-6 2M46-04R/2M46-04RDC User’s Guide

Using the RESET Button

4.4 USING THE RESET BUTTON

The RESET button shown in Figure 4-3 resets the 2M46-04R processor without affecting the NVRAM.

NOTE

CAUTION

Clearing NVRAM may be performed via Local Management.

Section 5.7.11 describes this procedure. Additionally, NVRAM

may be cleared by changing the position of mode switch 7 (Clear NVRAM) as described in Appendix C. It is only necessary to use this method when it is not possible to access Local Management.

Pressing the RESET button resets the device and all current switching being performed by the device is halted. The

2M46-04R will be unavailable for up to two minutes as it boots up.

PWR CPU

COM

2M46-04R

RESET

2314-37

RESET Button

Figure 4-3 RESET Button

To reset the 2M46-04R processor, use a non-conductive tool to press and release the RESET button. The 2M46-04R goes through the reset process and then reenters the network.

2M46-04R/2M46-04RDC User’s Guide 4-7

Chapter 4: Troubleshooting

4-8 2M46-04R/2M46-04RDC User’s Guide

CHAPTER 5

LOCAL MANAGEMENT

This chapter explains how to set up a management terminal to access Local Management. It also explains how to use the Local Management screens and commands.

5.1 OVERVIEW

Local Management for the 2M46-04R consists of a series of screens that allow the management of the 2M46-04R. The screens allo w the user to do the following tasks:

• Assign IP address and subnet mask

• Select a default gateway

• Control access by establishing community names

• Download a new operation software image

• Designate which Network Management Workstations receive SNMP

traps from the device

• View statistics

• Conﬁgure ports

• Control the number of receive broadcasts that are switched out to the

other interfaces

There are three ways to access Local Management:

• Locally using a VT type terminal connected to the COM port

• Remotely using a VT type terminal connected through a modem

• In-band through a Telnet connection

NOTE

2M46-04R/2M46-04RDC User’s Guide 5-1

If you have an HSIM-W6 or HSIM-W84 installed in your 2M46-04R, their Local Management screens can only be accessed via their respective ASYNC ports. See the associated HSIM user’s guides for more details.

Chapter 5: Local Management

5.2 LOCAL MANAGEMENT KEYBOARD CONVENTIONS

All key names appear as capital letters in this manual. Table 5-1 explains the keyboard conventions and the key functions that are used.

Table 5-1 Keyboard Conventions

Key Function

These are selection keys that perform the same

ENTER Key RETURN Key

ESCAPE (ESC) Key

SPACE Bar BACKSPACE Key

Local Management function. For example, “Press ENTER” means that you can press either ENTER or RETURN, unless this manual speciﬁcally instructs you otherwise.

This key allows an escape from a Local Management screen without saving changes. For example, “Press ESC twice” means the ESC key must be pressed quickly two times.

These keys cycle through selections in some Local Management ﬁelds. Use the SPACE bar to cycle forward through selections and use BACKSPACE to cycle backward through selections.

These are navigation keys. Use the UP-ARROW, DOWN-ARROW, LEFT-ARROW, and

Arrow Keys

[–] Key

DEL Key

RIGHT-ARROW keys to move the screen cursor. For example , “Use the arrow keys” means to press whichever arrow key moves the cursor to the desired ﬁeld on the Local Management screen.

This key decreases values from a Local Management increment ﬁeld. For example, “Press [–]” means to press the minus sign key.

The DEL (Delete) key removes characters from a Local Management ﬁeld. F or e xample, “Press DEL” means to press the Delete key.

5-2 2M46-04R/2M46-04RDC User’s Guide

Management Terminal Setup

5.3 MANAGEMENT TERMINAL SETUP

Use one of the following systems to access Local Management:

• An IBM or compatible PC running a VT series emulation software

package

• A Digital Equipment Corporation VT100 type terminal

• A VT type terminal running emulation programs for the Digital

Equipment Corporation VT100 series

• A remote VT100 type terminal via a modem connection

• In-Band via a Telnet connection

5.3.1 Console Cable Connection

Use the Console Cable Kit provided with the 2M46-04R to attach the management terminal to the 2M46-04R COM port as shown in

Figure 5-1.

Connect an IBM PC or compatible device, running the VT terminal emulation, to the 2M46-04R as follows:

1. Connect the RJ45 connector at one end of the cable (supplied in the

kit) to the COM port on the 2M46-04R.

2. Plug the RJ45 connector at the other end of the cable into the

RJ45-to-DB9 adapter (supplied in the kit).

NOTE

If using a DEC VT style terminal for Local Management, use the DB25 adapter for this device instead of the DB9 adapter.

3. Connect the RJ45-to-DB9 adapter to the communications port on

the PC.

2M46-04R/2M46-04RDC User’s Guide 5-3

Chapter 5: Local Management

RJ45 COM Port

HSIM 1HSIM 2

2M46-04R

RESET

COM

PWR CPU

RJ45-to-DB9

PC Adapter

UTP Cable

with RJ45 Connectors

Figure 5-1 Management Terminal Connection

2314-50

5-4 2M46-04R/2M46-04RDC User’s Guide

Management Terminal Setup

5.3.2 Management Terminal Setup Parameters

Table 5-2 lists the setup parameters for the local management terminal.

Table 5-2 VT Terminal Setup

Display Setup Menu

Columns -> Controls -> Auto Wrap -> Scroll -> Text Cursor -> Cursor Style ->

General Setup Menu

Mode -> ID number -> Cursor Keys -> Power Supply ->

Communications Setup Menu

Transmit -> Receive -> XOFF -> Bits -> Parity -> Stop Bit -> Local Echo -> Port -> Transmit -> Auto Answerback ->

Keyboard Setup Menu

Keys -> Auto Repeat -> Keyclick -> Margin Bell -> Warning Bell ->

80 Columns Interpret Controls No Auto Wrap Jump Scroll Cursor Underline Cursor Style

VT100, 7 Bit Controls VT100ID Normal Cursor Keys UPSS DEC Supplemental

2400, 4800, 9600, 19200 Receive=Transmit XOFF at 64 8 bits No Parity 1 Stop Bit No Local Echo DEC-423, Data Leads Only Limited T r ansmit No Auto Answerback

Typewriter Keys any option any option Margin Bell Warning Bell

2M46-04R/2M46-04RDC User’s Guide 5-5

Chapter 5: Local Management

5.3.3 Telnet Connections

Once the 2M46-04R has a valid IP address, a Telnet session with Local Management can be established from any TCP/IP based station on the network. Telnet connections to the 2M46-04R require the passwords assigned at the SNMP Community Names screen. For additional information about these passwords, refer to Section 5.8. Refer to the instructions included with the Telnet application for information about establishing a Telnet session.

5.3.4 Connecting an Uninterruptible Power Supply

If the 2M46-04R is connected to an American Power Conversion (APC) Uninterruptible (UPS) device for power, a connection from the 2M46-04R COM port to the UPS can be made to monitor the power status of the UPS. To use the COM port for this purpose, it must be reconﬁgured to support the UPS connection using the local management screen, General Conﬁguration, as described in Section 5.7.10. Refer to the UPS documentation for details on how to access the status information.

Use the Console Cable Kit provided with the 2M46-04R to attach the UPS to the 2M46-04R COM port as shown in Figure 5-2.

Connect the UPS device to the COM port of the 2M46-04R as follows:

1. Connect the RJ45 connector at one end of the cable to the COM port

on the 2M46-04R.

2. Plug the RJ45 connector at the other end of the cable into the

RJ45-to-DB9 male (UPS) adapter.

3. Connect the RJ45-to-DB9 male (UPS) adapter to the female DB9 port

on the rear of the UPS device (see the particular UPS device’s user instructions for more speciﬁc information about the monitoring connection).

5-6 2M46-04R/2M46-04RDC User’s Guide

DB9 Port

2M46-04R

Management Terminal Setup

HSIM 1HSIM 2

PWR CPU

RESET

COM

RJ45 COM Port

UPS Device

RJ45-to-DB9 UPS Adapter

UTP Cable

with RJ45 Connectors

Figure 5-2 Uninterruptible Power Supply (UPS) Connection

2314_51

2M46-04R/2M46-04RDC User’s Guide 5-7

Chapter 5: Local Management

5.4 ACCESSING LOCAL MANAGEMENT

Access to Local Management is controlled through the Password screen shown in Figure 5-3. Whenever a connection is made to the 2M46-04R the Password screen displays. Before continuing, the user must enter a password (community name) which is compared to the previously stored passwords. The lev el of access allo wed the user depends on the password. To set or change passwords refer to Section 5.8. The following steps describe the procedure to access Local Management.

1. Turn on the terminal. Press ENTER (up to four times) until the

2M46-04R Local Management Password screen displays (Figure 5-3).

2M46-04R LOCAL MANAGEMENT

CABLETRON Systems, Incorporated

Device Serial Number: XXXXXXXXX Device Hardware Revision: XX Device Firmware Revision: X.XX.XX Device BOOTPROM Revision: X.XX.XX

P.O.Box 5005

Rochester, NH 03866-5005 USA

(603) 332-9400

Enter Password:

Event Message Line

2314-12

Figure 5-3 Local Management Password Screen

2. Enter the Password and press ENTER. The default super-user access

password is “public” or press ENTER.

NOTE

5-8 2M46-04R/2M46-04RDC User’s Guide

The user’s password is one of the community names speciﬁed in the SNMP Community Names screen. Access to certain Local Management capabilities depends on the degree of access accorded that community name. Refer to Section 5.8.

Accessing Local Management

• If an invalid password is entered, the terminal beeps and the cursor

returns to the beginning of the password entry ﬁeld.

• Entering a valid password causes the associated access lev el to display

at the bottom of the screen and the Device Menu screen to appear.

• If no activity occurs for several minutes, the Password screen

redisplays and the password has to be reentered.

5.4.1 Navigating Local Management Screens

The 2M46-04R Local Management consists of a series of menu screens. Navigate through Local Management by selecting items from the menu screens.

The 2M46-04R supports three modes of switch operation. The switching modes are as follows:

• 802.1D Switching (traditional switching)

• 802.1Q Switching (port based switching)

• SecureFast VLAN (Cabletron Systems SecureFast switching)

NOTE

Refer to the Release Notes shipped with the product to verify which screens are supported in each of the three available switching modes.

Depending on the Operational Mode set for the device, the hierarchy of the Local Management screens differ as shown in Figure 5-4, Figure 5-5, and Figure 5-6. Refer to the appropriate ﬁgure that relates to the Operational Mode set for the device to see the applicable Local Management screen hierarchy.

2M46-04R/2M46-04RDC User’s Guide 5-9

Chapter 5: Local Management

Password

Device Configuration Menu

General Configuration SNMP Community Names SNMP Traps Switch Configuration SmartTrunk

Configuration

System Resources

High Speed Interface Configuration

Device Menu

Device Specific Configuration Menu

Flash Download

Device Statistics Menu

Switch Statistics Interface Statistics RMON Statistics

Port Redirect Function

Broadcast Suppression

Network Tools

Figure 5-4 802.1D Switching Mode, LM Screen Hierarchy

Device

Device Menu

Configuration Menu

Device Statistics Menu

Network Tools

General Configuration SNMP Community Names

SNMP Traps Switch Configuration SmartTrunk

Configuration Device Specific

Configuration Menu

Switch Statistics Interface Statistics

RMON Statistics

System Resources

Flash Download High Speed

Interface Configuration

Broadcast Suppression

802.1Q VLAN Configuration

2363_100

Fast Ethernet Interface

HSIM

2314-43

Fast Ethernet Interfaces

HSIM

Figure 5-5 802.1Q Switching Mode, LM Screen Hierarchy

5-10 2M46-04R/2M46-04RDC User’s Guide

Accessing Local Management

Password

Device Menu

Device Configuration Menu

Device Statistics Menu

Network Tools

General Configuration SNMP Community Names SNMP Traps

Device Specific Configuration Menu

Interface Statistics RMON Statistics

System Resources

Flash Download

High Speed Interface Configuration

Fast Ethernet Interfaces

HSIM

2363_101

Figure 5-6 SecureFast VLAN Mode, LM Screen Hierarchy

5.4.2 Selecting Local Management Menu Screen Items

Select items on a menu screen by performing the following steps:

1. Use the arrow keys to highlight a menu item.

2. Press ENTER. The selected menu item displays on the screen.

5.4.3 Exiting Local Management Screens

There are two ways to exit the Local Management (LM) screens.

Using the Exit Command

To exit LM using the EXIT screen command, proceed as follows:

1. Use the arrow keys to highlight the EXIT command at the bottom of

the Local Management screen.

2. Press ENTER. The Password screen displays and the session ends.

Using the RETURN Command

To exit LM using the RETURN command, proceed as follows:

1. Use the arrow keys to highlight the RETURN command at the bottom

of the Local Management screen.

2. Press ENTER. The previous screen in the Local Management

hierarchy displays.

2M46-04R/2M46-04RDC User’s Guide 5-11

Chapter 5: Local Management

NOTE

ESC twice. This exit method does not warn about unsaved changes and all unsaved changes will be lost.

3. Exit from 2M46-04R Local Management by repeating steps 1 and 2

until the Device Menu screen displays.

4. To end the LM session, use the arrow keys to highlight the RETURN

command at the bottom of the Device Menu screen.

5. Press ENTER. The Password screen displays and the session ends.

5.5 DEVICE MENU SCREEN

The Device Menu screen is the access point for all Local Management screens. Figure 5-7 shows the Device Menu screen.

2M46-04R LOCAL MANAGEMENT

Device Menu

The user can also exit Local Management screens by pressing

Device Type: 2M46-04R

DEVICE CONFIGURATION

DEVICE STATISTICS NETWORK TOOLS

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

EXIT

RETURN

2314-13

Figure 5-7 Device Menu Screen

5-12 2M46-04R/2M46-04RDC User’s Guide

Device Menu Screen

NOTE

If the terminal is idle for a modiﬁable period of time, the Password screen redisplays and the session ends.

The following explains each Device Menu screen ﬁeld as shown in

Figure 5-7:

DEVICE CONFIGURATION

The Device Conﬁguration screen provides access to the Local Management screens that are used to conﬁgure the 2M46-04R and also to the Device Speciﬁc Conﬁguration menu screen. The Device Speciﬁc Conﬁguration menu screen provides access to the screens that allow the user to check the 2M46-04R resources and set operating parameters speciﬁc to each port. For details about the Device Conﬁguration Menu screen, refer to Section 5.6. For details about the Device Speciﬁc Conﬁguration menu screen, refer to Section 5.11.

DEVICE STATISTICS

The Device Statistics screen provides statistics and performance information for the 2M46-04R. For details about this screen, refer to

Section 5.18.

NETWORK TOOLS

The Network Tools function resides on the 2M46-04R and consists of a series of commands that allow the user to access and manage network devices. Section 5.22 explains how to use the Network Tools utility.

2M46-04R/2M46-04RDC User’s Guide 5-13

Chapter 5: Local Management

5.6 DEVICE CONFIGURATION MENU SCREEN

The Device Conﬁguration Menu screen, Figure 5-8, provides access to Local Management screens that allow you to conﬁgure and monitor operating parameters, modify SNMP community names, set SNMP traps, conﬁgure switch parameters, and conﬁgure 2M46-04R ports.

To access the Device Conﬁguration Menu screen from the Device Menu screen, use the arrow keys to highlight the DEVICE CONFIGURATION menu item and press ENTER. The Device Conﬁguration Menu screen displays.

NOTE

Device Type: 2M46-04R

The Switch Conﬁguration menu will only display if the operational mode of the device has been set to 802.1D SWITCHING or 802.1Q SWITCHING. Refer to Section 5.7.9 for instructions on conﬁguring the device to operate in this mode.

2M46-04R LOCAL MANAGEMENT

Device Configuration Menu

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

GENERAL CONFIGURATION

SNMP COMMUNITY NAMES SNMP TRAPS SWITCH CONFIGURATION SMARTTRUNK CONFIGURATION DEVICE SPECIFIC CONFIGURATION

EXIT

RETURN

2314_66

Figure 5-8 Device Conﬁguration Menu Screen

5-14 2M46-04R/2M46-04RDC User’s Guide

Device Conﬁguration Menu Screen

The following brieﬂy explains each screen accessible from the Device Conﬁguration Menu screen:

GENERAL CONFIGURATION

The General Conﬁguration screen allows the user to monitor and conﬁgure operating parameters for the 2M46-04R. For details, refer to

Section 5.7.

SNMP COMMUNITY NAMES

The SNMP Community Names screen allows the user to enter new, change, or review the community names used as access passwords for device management operation. Access is limited based on the password level of the user. For details, refer to Section 5.8.

SNMP TRAPS

The SNMP Traps screen provides display and conﬁguration access to the table of IP addresses used for trap destinations and associated community names. For details, refer to Section 5.9.

SWITCH CONFIGURATION

The Switch Conﬁguration screen provides the basic setup options for customizing switch operations. For details, refer to Section 5.10.

SMARTTRUNK CONFIGURATION

The SmartTrunk Conﬁguration screen allows the user to logically group interfaces together to aggregate high speed uplinks. Refer to the Cabletron Systems SmartTrunk User’s Guide for additional information.

DEVICE SPECIFIC CONFIGURATION

The Device Speciﬁc Conﬁguration menu screen allows the user to select screens to conﬁgure ports or check system resources speciﬁc to the 2M46-04R. For details, refer to Section 5.11.

2M46-04R/2M46-04RDC User’s Guide 5-15

Chapter 5: Local Management

5.7 GENERAL CONFIGURATION SCREEN

The General Conﬁguration screen, Figure 5-9, allows the user to, among other things, set the system date and time, IP address and subnet mask, the default gateway, the TFTP gateway IP address, the operational mode, and the COM port conﬁguration.

To access the General Conﬁguration screen from the Device Conﬁguration Menu screen, use the arrow keys to highlight the GENERAL CONFIGURATION menu item and press ENTER. The General Conﬁguration screen displays.

Event Message Line

Device Type: 2M46-04R

MAC Address: IP Address: Subnet Mask: Default Gateway: TFTP Gateway IP Addr:

Operational Mode: [802.1D SWITCHING]

Com 1: [ENABLED] Application: [LM] Clear NVRAM: [NO] IP Fragmentation [ENABLED ]

2M46-04R LOCAL MANAGEMENT

General Configuration

00-00-ID-00-00-00

0.0.0.0

0.0.0.0 NONE DEFINED

0.0.0.0

EXIT

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

Device Date: Device Time: Screen Refresh Time: Screen Lockout Time: Device Uptime XX D XX H XX M

11/29/97 14:23:00 03 sec. 15 min.

RETURNSAVE

2314-15

Figure 5-9 General Conﬁguration Screen

The following brieﬂy explains each General Conﬁguration screen ﬁeld:

MAC Address (Read-Only)

Displays the base physical address of the 2M46-04R.

IP Address (Modiﬁable)

Displays and allows the user to set the IP address for the 2M46-04R. To set the IP address, refer to Section 5.7.1. The IP address can also be set through Runtime IP Address Discovery as previously described in

Section 1.3.5.

5-16 2M46-04R/2M46-04RDC User’s Guide

General Conﬁguration Screen

Subnet Mask (Modiﬁable)

Displays the subnet mask for the 2M46-04R. A subnet mask “masks out” the network bits of the IP address by setting the bits in the mask to 1 when the network treats the corresponding bits in the IP address as part of the network or subnetwork address, or to 0 if the corresponding bit identiﬁes the host. For details about how to change the subnet mask from its default value, refer to Section 5.7.2.

Default Gateway (Modiﬁable)

Displays the default gateway for the 2M46-04R. This ﬁeld is not deﬁned until an appropriate value is entered. For details about why and ho w to set the default gateway, refer to Section 5.7.3.

TFTP Gateway IP Addr (Modiﬁable)

Displays and allows the user to set the TFTP gateway IP address for the 2M46-04R. To set the TFTP gateway IP address, refer to Section 5.7.4.

Device Date (Modiﬁable)

Contains a value that the device recognizes as the current date. To set a new device date, refer to Section 5.7.5.

Device Time (Modiﬁable)

Contains a value that the device recognizes as the current time. To enter a new time, refer to Section 5.7.6.

Screen Refresh Time (Modiﬁable)

Contains the rate at which the screens are updated. This setting determines how frequently (in seconds) information is updated on the screen. To enter a new update time, refer to Section 5.7.7.

Screen Lockout Time (Modiﬁable)

Contains the maximum number of minutes that the Local Management application displays a module’s screen while awaiting input or action from a user. For example, if the number 5 is entered in this ﬁeld, the user has up to ﬁve minutes to respond to each of the speciﬁed module’s Local Management screens.

In this example, after ﬁve minutes of “idleness” (no input or action), the terminal “beeps” ﬁve times, the Local Management application terminates the session, and the display returns to the Password screen. To enter a new lockout time, refer to Section 5.7.8.

2M46-04R/2M46-04RDC User’s Guide 5-17

Chapter 5: Local Management

Device Uptime (Read-Only)

Displays the total time that the device has been operating.

Operational Mode (Modiﬁable)

This ﬁeld allows the user to set the 2M46-04R to operate as a traditional switch (802.1D SWITCHING), an IEEE 802.1Q switch (802.1Q SWITCHING), or as a Cabletron Systems SecureFast switch (SECURE F AST VLAN).

In 802.1D SWITCHING mode, the Fast Ethernet Interface Module(s), and HSIM port(s) are bridged to each other.

In 802.1Q SWITCHING mode, the 2M46-04R acts as a IEEE 802.1Q switch which allows the creation of port-based VLANs.

When the operational mode is set to SECURE FAST VLAN, the 2M46-04R acts as a SecureFast switch. The 2M46-04R is able to increase its switching functionality by creating and maintaining Virtual LANs (VLANs).

For details on how to select the Operational Mode, refer to Section 5.7.9.

Com 1 (Toggle)

This ﬁeld allows the user to enable or disable the COM port. The selection toggles between ENABLED and DISABLED. The default is ENABLED. For details about setting up the COM port, refer to

Section 5.7.10.

Application (Toggle)

Displays the application set for the COM port. This ﬁeld allows the user to set the application that the COM port supports. The ﬁeld toggles between LM (Local Management) and UPS (Uninterruptible Power Supply).

The UPS setting allows the COM port to be used to monitor an American Power Conversion Smart Uninterruptible Power Supply (UPS).

The baud rate setting for LM is automatically sensed. For UPS connections, the baud rate is automatically set to 2400.

The default setting is LM. For details about how to conﬁgure the COM port for various applications, refer to Section 5.7.10.

5-18 2M46-04R/2M46-04RDC User’s Guide

General Conﬁguration Screen

Clear NVRAM (Toggle)

This allows the user to reset NVRAM to the factory default settings. All user-entered parameters, such as IP address and community names, are then replaced with 2M46-04R default conﬁguration settings. For details, refer to Section 5.7.11.

IP Fragmentation (Toggle)

This ﬁeld, which only displays if an HSIM-F6 is installed in the 2M46-04R, allows the user to enable or disable IP Fragmentation. The default setting for this is ﬁeld is ENABLED. If traf ﬁc from the 2M46-04R is to be bridged to an FDDI ring, IP Fragmentation should be enabled. If IP Fragmentation is disabled, all FDDI frames that exceed the maximum Ethernet frame size will be discarded. For details on enabling IP Fragmentation, refer to Section 5.7.12.

5.7.1 Setting the IP Address

To set the IP address, perform the following steps:

1. Use the arrow keys to highlight the IP Address field.

2. Enter the IP address into this field using Dotted Decimal Notation

(DDN) format. For example: 134.141.79.120

3. Press ENTER. If the IP address is a valid format, the cursor returns to

the beginning of the IP address field. If the entry is not valid, the Event Message Line displays “INVALID IP ADDRESS OR FORMAT ENTERED”. Local Management does not alter the current value and refreshes the IP address field with the previous value.

4. Use the arrow keys to highlight the SAVE command, then press

ENTER. The warning screen shown in Figure 5-10 displays.

2M46-04R/2M46-04RDC User’s Guide 5-19

Chapter 5: Local Management

Event Message Line

WARNING!

YOU HAVE ELECTED TO SAVE ONE OR MORE CONFIGURATION ITEMS THAT REQUIRE RESETTING THIS DEVICE.

ARE YOU SURE YOU WANT TO CONTINUE?

YES

Figure 5-10 Conﬁguration Warning Screen

confgwarn

5. Use the arrow keys to highlight the YES command and press ENTER.

The changes are saved and the device reboots.

5.7.2 Setting the Subnet Mask

If the management workstation that is to receive SNMP traps from the 2M46-04R is located on a separate subnet, the subnet mask for the 2M46-04R may need to be changed from its default.

To change the subnet mask from its default, perform the following steps:

1. Use the arrow keys to highlight the Subnet Mask field.

2. Enter the subnet mask into this field using Dotted Decimal Notation

(DDN) format. For example: 255.255.0.0

3. Press ENTER. If the subnet mask is valid, the cursor returns to the

beginning of the Subnet Mask field. If the entry is not valid, the Event Message Line displays “INVALID SUBNET MASK OR FORMAT ENTERED”. Local Management does not alter the current value, but it does refresh the Subnet Mask field with the previous value.

5-20 2M46-04R/2M46-04RDC User’s Guide

General Conﬁguration Screen

4. Use the arrow keys to highlight the SAVE command, then press

ENTER. The warning screen shown back in Figure 5-10 displays.

5. Use the arrow keys to highlight the YES command and press ENTER.

The changes are saved and the device reboots.

5.7.3 Setting the Default Gateway

If the SNMP management station is located on a different IP subnet than the 2M46-04R, a default gateway must be speciﬁed. When an SNMP T rap is generated, the 2M46-04R sends the trap to the default gateway. To set the default gateway, perform the following steps:

1. Use the arrow keys to highlight the Default Gateway field.

2. Enter the IP address of the default gateway using the DDN format.

For example: 134.141.79.121

3. Press ENTER. If the default gateway entered is a valid format, the

cursor returns to the beginning of the Default Gateway field. If the entry is not valid, the Event Message Line displays “INVALID DEFAULT GATEWAY OR FORMAT ENTERED”. Local Management does not alter the current value, but it does refresh the Default Gateway field with the previous value.

4. Use the arrow keys to highlight the SAVE command.

5. Press ENTER. The Event Message Line at the top of the screen

displays “SAVED OK”.

5.7.4 Setting the TFTP Gateway IP Address

If the network TFTP server is located on a different IP subnet than the 2M46-04R, a gateway IP address should be speciﬁed. To set the TFTP gateway IP address, perform the following steps:

1. Use the arrow keys to highlight the TFTP Gateway IP Addr field.

2. Enter the IP address of the TFTP gateway using the DDN format.

For example: 134.141.80.122

2M46-04R/2M46-04RDC User’s Guide 5-21

Chapter 5: Local Management

3. Press ENTER. If the TFTP gateway IP address entered is a valid

format, the cursor returns to the beginning of the TFTP Gateway IP Address field. If the entry is not valid, the Event Message Line displays “INVALID TFTP GATEWAY IP ADDRESS OR FORMAT ENTERED”. Local Management does not alter the current value, but it does refresh the TFTP Gateway IP Address field with the previous value.

4. Use the arrow keys to highlight the SAVE command.

5. Press ENTER. The Event Message Line at the top of the screen

displays “SAVED OK”.

5.7.5 Setting the Device Date

The 2M46-04R is year 2000 compliant so that the Device Date ﬁeld can be set beyond the year 1999. To set the system date, perform the following steps:

1. Use the arrow keys to highlight the Device Date field.

2. Enter the date in this format: MM/DD/YYYY

NOTE

It is not necessary to add separators between month, day, and year numbers, as long as each entry uses two numeric characters. For example, to set the date to 08/29/1997, type “08291997” in the Device Date ﬁeld.

3. Press ENTER to set the Device Date to the date in the input field.

4. Use the arrow keys to highlight the SAVE command at the bottom of

the screen and press ENTER.

If the date entered is a valid format, the Event Message Line at the top of the screen displays “SAVED OK”. If the entry is not valid, Local Management does not alter the current value, but it does refresh the Device Date ﬁeld with the previous value.

5-22 2M46-04R/2M46-04RDC User’s Guide

General Conﬁguration Screen

5.7.6 Setting the Device Time

To set the device time, perform the following steps:

1. Use the arrow keys to highlight the Device Time field.

2. Enter the time in this 24-hour format: HH:MM:SS

NOTE

When entering the time in the system time ﬁeld, separators between hours, minutes, and seconds are not needed as long as each entry uses two numeric characters. F or e xample, to set the time to 6:45 A.M., type “064500” in the Device Time ﬁeld.

3. Press ENTER to set the Device Time to the time in the input field.

4. Use the arrow keys to highlight the SAVE command at the bottom of

the screen and press ENTER.

If the time entered is a valid format, the Event Message Line at the top of the screen displays “SAVED OK”. If the entry is not valid, Local Management does not alter the current value and refreshes the Device Time ﬁeld with the previous value.

5.7.7 Entering a New Screen Refresh Time

The screen refresh time is set from 3 to 99 seconds with a default of 3 seconds. To set a new screen refresh time, perform the following steps:

1. Use the arrow keys to highlight the Screen Refresh Time field.

2. Enter a number from 3 to 99.

3. Press ENTER to set the refresh time to the time entered in the input

field.

4. Use the arrow keys to highlight the SAVE command at the bottom of

the screen and press ENTER.

If the time entered is within the 3 to 99 seconds range, the Event Message Line at the top of the screen displays “SAVED OK”. If the entry is not valid, Local Management does not alter the current setting, but it does refresh the Screen Refresh Time ﬁeld with the previous value.

2M46-04R/2M46-04RDC User’s Guide 5-23

Chapter 5: Local Management

5.7.8 Setting the Screen Lockout Time

The screen lockout time can be set from 1 to 30 minutes with a default of 15 minutes. To set a new lockout time, perform the following steps:

1. Use the arrow keys to highlight the Screen Lockout Time field.

2. Enter a number from 1 to 30.

3. Press ENTER to set the lockout time in the input field.

4. Use the arrow keys to highlight the SAVE command at the bottom of

the screen and press ENTER.

If the time entered is within the 1 to 30 minutes range, the Event Message Line at the top of the screen displays “SAVED OK”. If the entry is not valid, Local Management does not alter the current setting, but it does refresh the Screen Lockout Time ﬁeld with the previous value.

5.7.9 Setting the Operational Mode

NOTE

If the device is to be conﬁgured to operate as a SecureFast switch, the device must be assigned an IP address that has been saved (i.e., the device has rebooted and the new IP address is active).

To set the Operational Mode, proceed as follows:

1. Use arrow keys to highlight the Operational Mode field.

2. Press the SPACE bar to step to the appropriate operation mode

(802.1D SWITCHING, 802.1Q SWITCHING or SECURE FAST VLAN).

3. Use the arrow keys to highlight the SAVE command at the bottom of

the screen, then press ENTER. The warning screen shown back in

Figure 5-10 displays.

4. Use the arrow keys to highlight the YES command and press ENTER.

The changes are saved and the device reboots.

NOTES

If the 2M46-04R has been set to SECURE F AST VLAN, ref er to your SecureFast documentation set to conﬁgure the device for this type of operation.

If the 2M46-04R has been set to 802.1Q SWITCHING, refer to the Cabletron Systems

Port Based VLAN User’s Guide

5-24 2M46-04R/2M46-04RDC User’s Guide

General Conﬁguration Screen

5.7.10 Conﬁguring the COM Port

Upon power up, the COM port is conﬁgured to the default settings of ENABLED and LM.

Before altering the COM port settings, ensure that a valid IP address is set. Refer to Section 5.7.1. Read this entire COM

CAUTION

The 2M46-04R COM port supports the following applications:

• Local Management connections

• American Power Conversion Uninterruptible Power Supply (UPS)

To conﬁgure the COM port, proceed as follows:

1. Use the arrow keys to highlight the Com 1 field.

CAUTION

port conﬁguration section before altering the COM port settings.

connections

Do NOT disable or alter the settings of the COM port while operating the current Local Management connection through a

terminal. Altering the COM port settings disconnects the Local Management terminal from the port, and ends the Local Management session. If the 2M46-04R was previously assigned a valid IP address, reenter Local Management by establishing a Telnet connection to the device. If the device does not have a valid IP address and the COM port has been disabled or the settings changed, reset NVRAM on the 2M46-04R (refer to Appendix C) to reestablish COM port communications.

2. Press the SPACE bar to choose either ENABLED or DISABLED.

ENABLED allows the COM port to be connected to the terminal and

used for a particular application. DISABLED disables the COM port connection to the terminal.

If the COM port is conﬁgured without a valid IP address, the screen shown in Figure 5-11 displays.

CAUTION

2M46-04R/2M46-04RDC User’s Guide 5-25

Do not continue unless the outcome of the action is fully understood. If the Warning screen displays, continue on to step 3, otherwise, proceed to step 4.

Chapter 5: Local Management

WARNING

THE COM PORT HAS BEEN RECONFIGURED AND THERE IS NO IP ADDRESS SET FOR THIS DEVICE. YOU WILL NO LONGER BE ABLE TO MANAGE THIS BOARD. DO YOU STILL WISH TO RECONFIGURE THIS COM PORT?

YES

Figure 5-11 COM Port Warning Screen

174252

3. Use the arrow keys to highlight YES. Press ENTER.

4. If you ENABLED the port, proceed to step 5. If you DISABLED the

port, use the arrow keys to highlight SAVE at the bottom of the screen, then press ENTER.

5. When the message “SAVED OK” appears, the edits you made are

saved.

Exiting without saving causes the message “NOT SAVED -PRESS SA VE TO KEEP CHANGES” to appear. Exiting without

CAUTION

saving causes all edits to be lost.

5.7.10.1 Changing the COM Port Application

After enabling the COM port as described in Section 5.7.10, you can select one of the applications supported by the COM port: LM or UPS. The default application is LM.

To change the COM port application:

1. Use the arrows keys to highlight the Application field.

5-26 2M46-04R/2M46-04RDC User’s Guide

General Conﬁguration Screen

2. Use the SPACE bar or BACKSPACE to step through the available

settings until the operation you require displays. Table 5-3 lists the available settings and their corresponding applications.

Table 5-3 COM Port Application Settings

Setting Application LM Local Management Session

UPS APC Power Supply SNMP Proxy

3. Press ENTER to accept the application.

When the COM port is conﬁgured to perform the UPS application, all future LM connections must be made by a Telnet

CAUTION

connection. Ensure that the device has a valid IP address before saving changes to the COM port application. If the device does not have a valid IP address and the changes are saved, refer to Appendix C for instructions on clearing NVRAM in order to reestablish COM port communications.

4. Use the arrow keys to highlight SAVE at the bottom of the screen, then

press the ENTER key. When the message “SAVED OK” displays, the edits are saved.

When the COM port is conﬁgured to perform the UPS application, all future Local Management connections must be

CAUTION

2M46-04R/2M46-04RDC User’s Guide 5-27

made by establishing a Telnet connection to the device. Ensure that the device has a valid IP address bef ore sa ving changes to the COM port application. If the device does not ha v e a v alid IP address and the changes are saved, refer to Appendix C for instructions on clearing NVRAM in order to reestablish COM port communications.

Chapter 5: Local Management

5.7.11 Clearing NVRAM

Clearing NVRAM will result in the loss of all user-entered parameters. Do not proceed unless this procedure is

CAUTION

Clearing NVRAM allows the user to clear all user-entered parameters, such as, the IP address and Community Names from NVRAM.

Clear NVRAM as follows:

1. Use the arrow keys to highlight the Clear NVRAM field.

2. Use the SPACE bar to toggle the field to YES.

3. Use the arrow keys to highlight SAVE at the bottom of the screen.

4. Press ENTER. The warning shown in Figure 5-12 displays.

5. Use the arrow keys to highlight YES and press ENTER.The message

completely understood.

“CLEARING NVRAM. REBOOT IN PROGRESS...” displays. The 2M46-04R clears NVRAM and reboots. All user-entered parameters default to factory default settings.

WARNING

YOU HAVE ELECTED TO CLEAR NVRAM. THIS WILL CLEAR ALL SYSTEM DEFAULTS INCLUDING BUT NOT LIMITED TO IP ADDRESS, INTERFACE CONFIGURATION, AND COM PORT CONFIGURA TION, THEN REBOOT THIS DEVICE. ARE YOU SURE YOU WANT TO CLEAR NVRAM?

YES

Figure 5-12 Clear NVRAM Warning Screen

5-28 2M46-04R/2M46-04RDC User’s Guide

174251

SNMP Community Names Screen

5.7.12 Enabling/Disabling IP Fragmentation

To enable or disable IP fragmentation, proceed as follows:

1. Use the arrow keys to highlight the IP Fragmentation field.

2. Press the SPACE bar to choose either ENABLED or DISABLED.

3. Use the arrow keys to highlight the SAVE command.

4. Press ENTER. “SAVED OK” displays in the Event Message Line at

the top of the screen.

If the 2M46-04R is being bridged to an FDDI ring via an optional HSIM-F6, IP Fragmentation should be enabled. If IP

CAUTION

Fragmentation is disabled, all FDDI frames that exceed the maximum Ethernet frame size will be discarded.

5.8 SNMP COMMUNITY NAMES SCREEN

The SNMP Community Names option allows the user to set SNMP Management community names. Community names act as passwords to Local/Remote Management and are agents of security access to the 2M46-04R. Access to the 2M46-04R is controlled by enacting any of three different levels of security authorization (read-only, read-write, and super-user).

NOTE

Super-user access gives the user full management privileges, allows existing passwords to be changed, and all modiﬁable MIB objects for the Cabletron Container MIB and Internet MIB-II to be edited.

To access the SNMP Community Names screen from the Device Conﬁguration Menu screen, use the arrow keys to highlight the SNMP COMMUNITY NAMES menu item and press ENTER. The SNMP Community Names screen displays.

2M46-04R/2M46-04RDC User’s Guide 5-29

Chapter 5: Local Management

Event Message Line

Device Type: 2M46-04R

2M46-04R LOCAL MANAGEMENT

SNMP Community Names

Community Name

public

public public

EXIT

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

Access Policy read-only read-write super-user

RETURNSAVE

2314-16

Figure 5-13 SNMP Community Names Screen

The following explains each SNMP Community Names screen ﬁeld:

Community Name (Modiﬁable)

Displays the user-deﬁned name through which a user accesses the 2M46-04R SNMP Management. Any community name assigned here acts as a password to Local/Remote Management.

Access Policy (Read-Only)

Indicates the access accorded each community name. Possible selections are as follows:

read-only This community name gives the user read-only

access to the 2M46-04R MIB objects, and excludes access to security-protected ﬁelds of read-write or super-user authorization.

read-write This community name gives the user read-write

access to the 2M46-04R MIB objects, excluding security protected ﬁelds for super-user access only.

5-30 2M46-04R/2M46-04RDC User’s Guide

SNMP Community Names Screen

super-user This community name gi ves the user read-write

access to the 2M46-04R

MIB objects and

allows the user to change all modiﬁable parameters including community names, IP addresses, traps, and SNMP objects.

5.8.1 Establishing Community Names

The password used to access Local Management at the Password Screen must have super-user access to view and edit the SNMP Community Names screen. Using a password with read-only or read-write access does not allow the user to view or edit the SNMP Community Names screen.

NOTE

Any community name assigned in the SNMP Community Names screen is a password to its corresponding level of access to Local/Remote Management. The community name assigned super-user access is the only one that gives the user complete access to Local/Remote Management.

To establish community names, proceed as follows:

1. Use the arrow keys to highlight the Community Name field adjacent

to the selected access level.

2. Enter the password in the field (maximum 31 characters).

3. Press ENTER.

4. Repeat steps 1 through 3 to modify the other community names.

5. Use the arrow keys to highlight SAVE at the bottom of the screen and

press ENTER. The message “SAVED OK” displays. The community names are saved to memory and their access modes implemented.

NOTE

Exiting without saving causes a “NOT SAVED?” message to display abov e the SAVE command. Edits will be lost if they are not saved before exiting.

2M46-04R/2M46-04RDC User’s Guide 5-31

Chapter 5: Local Management

5.9 SNMP TRAPS SCREEN

Since the 2M46-04R is an SNMP compliant device, it can send messages to multiple Network Management Stations to alert users of status changes. The SNMP Traps screen is shown in Figure 5-14.

To access the SNMP Traps screen from the Device Conﬁguration Menu screen, use the arrow keys to highlight the SNMP TRAPS menu item and press ENTER. The SNMP Traps screen displays.

Event Message Line

Device Type: 2M46-04R

Trap Destination

0.0.0.0

2M46-04R LOCAL MANAGEMENT

SNMP Traps

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

Trap Community Name

public public public public public public public public

EXIT

Enable Traps

[NO] [NO] [NO] [NO] [NO] [NO] [NO] [NO]

RETURNSAVE

2314-17

Figure 5-14 SNMP Traps Screen

The following explains each ﬁeld of the SNMP Traps screen:

Trap Destination (Modiﬁable)

Indicates the IP address of the workstation to receive trap alarms. Up to eight different destinations can be deﬁned.

Trap Community Name (Modiﬁable)

Displays the community name included in the trap message sent to the Network Management Station with the associated IP address.

Enable Traps (Toggle)

Enables transmission of the traps to the network management station with the associated IP address. This ﬁeld toggles between YES and NO.

5-32 2M46-04R/2M46-04RDC User’s Guide

SNMP T raps Screen

5.9.1 Conﬁguring the Trap Table

To conﬁgure the Trap table, proceed as follows:

1. Use the arrow keys to highlight the appropriate Trap Destination

field.

2. Enter the IP address of the workstation that is to receive traps. IP

address entries must follow the DDN format. For example: 134.141.79.121

3. Press ENTER. If an invalid value is entered “INVALID IP

ENTERED” is displayed in the Event Message Line.

4. Use the arrow keys to highlight the Trap Community Name field.

Enter the community name.

5. Press ENTER.

6. Use the arrow keys to highlight the Enable Traps field. Press the

SPACE bar to choose either YES (send alarms from the 2M46-04R to the workstation), or NO (prevent alarms from being sent).

7. Use the arrow keys to highlight the SAVE command and press

ENTER. The message “SAVED OK” displays on the screen.

8. To exit the screen, use the arrow keys to highlight RETURN and press

ENTER.

NOTE

Link traps may be disabled by using Network Tools. See Section 5.22 for more details.

The designated workstations now receive traps from the 2M46-04R.

2M46-04R/2M46-04RDC User’s Guide 5-33

Chapter 5: Local Management

5.10 SWITCH CONFIGURATION SCREEN

NOTE

operational mode of the device has been set to 802.1D SWITCHING or 802.1Q SWITCHING. Refer to Section 5.7.9 for instructions on conﬁguring the device to operate in this mode.

The Switch Conﬁguration screen, Figure 5-15, provides the basic setup options to make a switch operational in your network.

T o access the Switch Conﬁguration screen from the De vice Conﬁguration Menu screen, use the arrow keys to highlight the SWITCH CONFIGURATION menu item and press ENTER. The Switch Conﬁguration screen displays.

The Switch Conﬁguration screen will only display if the

NOTE

Ports 1 and 2 of the Switch Conﬁguration screen correspond to the Fast Ethernet slots and ports 3 and 4 correspond to the HSIM slots.

Event Message Line

Device Type: 2M46-04R

2M46-04R LOCAL MANAGEMENT

Switch Configuration

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

Switch Address: 00-00-1D-00-00-00 Number of Ports: 4

Port #

1 2 3 4

MAC Address

00-00-1D-00-00-00 00-00-1D-00-00-01 00-00-1D-00-00-02

Type of STA: Age Time (sec): 300

State

learning listening blocking disabled

EXIT

[IEEE]

Status

[ENABLED] [ENABLED] [ENABLED] [DISABLED]

RETURNSAVE

14-1

Figure 5-15 Switch Conﬁguration Screen

5-34 2M46-04R/2M46-04RDC User’s Guide

Switch Conﬁguration Screen

The following describes each ﬁeld of the Switch Conﬁguration screen:

Switch Address (Read-Only)

Displays the base MAC address of the switch.

Number of Ports (Read-Only)

Displays the total number of switched ports on the 2M46-04R.

Type of STA (Modiﬁable)

Allows the user to set the method that switches use to decide which switch is the controlling (Root) switch when two or more switches exist in parallel (Spanning Tree Algorithm). Valid entries include IEEE, DEC, and NONE. To set the STA, refer to Section 5.10.1.

Age Time (Modiﬁable)

Allows the user to set the amount of time (in seconds) that the 2M46-04R keeps an address in its switch table before discarding it. An address is automatically discarded when a valid packet is not received from that address within the time speciﬁed in the Age T ime ﬁeld. To change the Age Time ﬁeld from the default value of 300 seconds, refer to Section 5.10.2.

Port # (Read-Only)

Lists each switched port on the device.

MAC Address (Read-Only)

Displays the hardware address assigned to each listed port.

State (Read-Only)

Disabled: Management disabled this interface. No trafﬁc is received or forwarded while the interface is disabled.

Learning: The switch is learning the addresses on this interface. The switch enters the learning state when the Transparent Database is created (during start-up or after being deleted), or when the Spanning Tree Algorithm detects a network topology change.

Listening: The switch is not adding information to the Transparent Database. The switch is monitoring BPDU trafﬁc while preparing to move from the learning to the forwarding state.

Forwarding: The switch is operating and this interface is forwarding trafﬁc.

Blocking: This interface will not forward any trafﬁc through the switch because a loop condition has been detected by the STA.

2M46-04R/2M46-04RDC User’s Guide 5-35

Chapter 5: Local Management

Status (Toggle)

Allows the user to disable or enable a port by setting the status of the listed interface to either ENABLED or DISABLED. To set the port status, refer to Section 5.10.3.

5.10.1 Setting the STA

The Spanning Tree Algorithm (STA) setting allows the user to set the method that the switches use to decide which is the controller (Root) switch when two or more switches are in parallel. The av ailable selections are IEEE, DEC, and NONE.

To set the STA, proceed as follows:

1. Use the arrow keys to highlight the Type of STA field.

2. Use the SPACE bar to step to the appropriate setting (IEEE, DEC, or

NONE).

3. Use the arrow keys to highlight the SAVE command at the bottom of

the screen.

4. Press ENTER. The message “SAVED OK” is displayed.

5.10.2 Setting the Age Time Field

To set the Age Time, proceed as follows:

1. Use the arrow keys to highlight the Age Time (sec) field.

2. Type in the desired Age Time in increments of 10. The available Age

Time range is 10 to 1,000,000 seconds with the default value being 300 seconds.

3. Use the arrow keys to highlight the SAVE command at the bottom of

the screen.

4. Press ENTER. The message “SAVED OK” is displayed.

5-36 2M46-04R/2M46-04RDC User’s Guide

Device Speciﬁc Conﬁguration Menu Screen

5.10.3 Setting (Enabling or Disabling) the Port Status

To set the status of an interface (port), proceed as follows:

1. Use the arrow keys to highlight the Status field of the port.

2. Use the SPACE bar to toggle to either ENABLED or DISABLED.

3. Use the arrow keys to highlight the SAVE command at the bottom of

the screen.

4. Press ENTER. The message “SAVED OK” is displayed.

5.11 DEVICE SPECIFIC CONFIGURATION MENU

SCREEN

The Device Speciﬁc Conﬁguration menu screen, Figure 5-16, allows the user to select one of several screens to conﬁgure ports or check system resources speciﬁc to the 2M46-04R.

NOTE

The PORT REDIRECT FUNCTION menu item on the Device Speciﬁc Conﬁguration Menu screen does not display if the operational mode of the device is set to 802.1Q SWITCHING.

The PORT REDIRECT FUNCTION and BROADCAST SUPPRESSION menu items do not display if the operational mode is set to SECURE FAST VLAN.

Section 5.7.9 provides instructions on setting the operational

mode.

T o access the De vice Speciﬁc Conﬁguration menu screen from the Device Conﬁguration menu screen, use the arrow keys to highlight the DEVICE SPECIFIC CONFIGURATION menu item and press ENTER. The Device Speciﬁc Conﬁguration menu screen displays.

2M46-04R/2M46-04RDC User’s Guide 5-37

Chapter 5: Local Management

2M46-04R LOCAL MANAGEMENT

Device Specific Configuration

Device Type: 2M46-04R

SYSTEM RESOURCES HIGH SPEED INTERFACE CONFIGURATION FLASH DOWNLOAD PORT REDIRECT FUNCTION BROADCAST SUPPRESSION

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

SAVE

EXIT

RETURN

2314-20

Figure 5-16 Device Speciﬁc Conﬁguration Menu Screen

The following explains each selectable item in the Device Speciﬁc Conﬁguration Menu screen:

SYSTEM RESOURCES

The System Resources screen displays the amount of FLASH memory, DRAM and NVRAM installed, indicates the amount of available memory and provides information on 2M46-04R operation. For details, refer to

Section 5.12.

HIGH SPEED INTERFACE CONFIGURATION

The High Speed Interface Conﬁguration screen provides access to the Fast Ethernet Interfaces screen and the HSIM screens. For details, refer to

Section 5.13.

FLASH DOWNLOAD

The FLASH Download screen allows the user to download a new ﬁrmware image to FLASH memory on the 2M46-04R. For details, refer to Section 5.15.

5-38 2M46-04R/2M46-04RDC User’s Guide

System Resources Screen

PORT REDIRECT FUNCTION

The Port Redirect Function screen allows the user to redirect trafﬁc from one or multiple ports to a speciﬁc destination port. For details, refer to

Section 5.16.

BROADCAST SUPPRESSION

The Broadcast Suppression screen allows the user to set a desired limit of received broadcast frames that will be forwarded per port per second. F or details, refer to Section 5.17.

802.1Q VLAN CONFIGURA TION

This menu item will only display if the 2M46-04R has been conﬁgured to operate as an IEEE 802.1Q switch (Section 5.7.9, describes how to conﬁgure the 2M46-04R to function as an 802.1Q switch). When selected, this menu item opens the VLAN Main Menu screen. For details on the VLAN Main Menu screen, refer to the Cabletron Systems Port Based VLAN User’s Guide.

5.12 SYSTEM RESOURCES SCREEN

The System Resources screen, Figure 5-17, provides information concerning the processor used in the 2M46-04R and the amount of FLASH memory , DRAM, and NVRAM that is installed and how much of that memory is available. This screen also allows the user to monitor the current processor (switch) utilization and the peak switch utilization.

To access the System Resources screen from the Device Speciﬁc Conﬁguration Menu screen, use the arrow keys to highlight the SYSTEM RESOURCES menu item and press ENTER. The System Resources screen displays.

2M46-04R/2M46-04RDC User’s Guide 5-39

Chapter 5: Local Management

Event Message Line

Device Type: 2M46-04R

Flash Memory Installed : XX MB

DRAM Installed: XX MB

NVRAM Installed: XX KB

SAVE

2M46-04R LOCAL MANAGEMENT

System Resources

CPU Type: i960 HT 25 Mhz

Available: XXXXX Bytes

Current Switch Utilization: 66% Peak Switch Utilization: 75%

Reset Peak Switch Utilization: [NO]

EXIT

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

RETURN RETURN

2314-23

Figure 5-17 System Resources Screen

The following brieﬂy explains each ﬁeld of the System Resources screen:

CPU Type (Read-only)

Indicates the microprocessor used in the 2M46-04R.

Flash Memory Installed (Read-only)

Indicates the amount of FLASH memory installed in the 2M46-04R and how much is currently available.

DRAM Installed (Read-only)

Indicates the amount of DRAM installed in the 2M46-04R and how much of it is currently available.

NVRAM Installed (Read-only)

Indicates the amount of NVRAM installed in the 2M46-04R and how much of it is currently available.

Current Switch Utilization (Read-only)

Shows how much (percentage of switch capacity) of the 2M46-04R is currently being used.

5-40 2M46-04R/2M46-04RDC User’s Guide

System Resources Screen

Peak Switch Utilization (Read-only)

Shows the peak percentage of maximum switching capacity, since last reset.

Reset Peak Switch Utilization (Toggle)

Allows the user to reset the Peak Switch Utilization ﬁeld. The switch may be set to either YES or NO. YES resets the Peak Switch Utilization ﬁeld to zero.

5.12.1 Setting the Reset Peak Switch Utilization

To reset the Peak Switch Utilization ﬁeld to zero, proceed as follows:

1. Use the arrow keys to highlight the Reset Peak Switch Utilization

field.

2. Press the SPACE bar to select YES.

3. Use the arrows keys to highlight the SAVE command at the bottom of

the screen.

4. Press ENTER. The message “SAVED OK” displays.

2M46-04R/2M46-04RDC User’s Guide 5-41

Chapter 5: Local Management

5.13 HIGH SPEED INTERFACE CONFIGURATION

MENU SCREEN

NOTE

Interface Modules AND an HSIM are installed. This screen will also not display if the HSIM that is installed is

an HSIM-W6 or an HSIM-W84. Access to their Local Management screens is via their respective ASYNC ports. Refer to the associated HSIM user’s guides for more details.

If only Fast Ethernet Interface Modules or an HSIM is installed, then the respective Fast Ethernet Interfaces screen or the HSIM Setup screen displays instead of the High Speed Interface Conﬁguration Menu screen.

To access the High Speed Interface Conﬁguration Menu screen,

Figure 5-18, from the Device Speciﬁc Conﬁguration Menu screen, use the

arrow keys to highlight the HIGH SPEED INTERFACE CONFIGURATION menu item and press ENTER. The High Speed Interface Conﬁguration Menu screen displays.

2M46-04R LOCAL MANAGEMENT

High Speed Interface Configuration Menu

This screen does not display unless one, or both, F ast Ethernet

Device Type: 2M46-04R

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

FAST ETHERNET INTERFACES HSIMS

EXIT

RETURN

2314-53

Figure 5-18 High Speed Interface Conﬁguration Menu Screen

5-42 2M46-04R/2M46-04RDC User’s Guide

High Speed Interface Conﬁguration Menu Screen

The following brieﬂy explains each screen accessible from the High Speed Interface Conﬁguration Menu screen:

FAST ETHERNET INTERFACES

Displays a screen named High Speed Interface Conﬁguration which shows the types of Fast Ethernet Interface Modules installed in ports 1 and 2, their current operating mode, and indicates if the ports are linked. This screen also allows the user to enable or disable Auto-Negotiation and set the Advertised Ability. For details, refer to Section 5.14.

HSIMS

Displays the types of interfaces installed in the High Speed Interface Module (HSIM) slots. The HSIM screens are depicted in their respective user’s guides.

2M46-04R/2M46-04RDC User’s Guide 5-43

Chapter 5: Local Management

5.14 HIGH SPEED INTERFACE CONFIGURATION

SCREEN

The High Speed Interface Conﬁguration screen, Figure 5-19, applies only to Fast Ethernet Interface Module ports 1 and 2. This screen supports the FE-100TX, FE-100FX, and FE-100F3 Fast Ethernet Interface Modules that operate at 10 or 100 Mbps.

If you are conﬁguring an HSIM which is installed in the 2M46-04R, use the arrow keys to highlight the HSIMS menu item and press ENTER. Then refer to the applicable HSIM User’s Guide for further information.

The High Speed Interface Conﬁguration screen displays the types of interfaces installed in ports 1 and 2, their current operating mode, and indicates if the ports are linked. This screen also allows the user to enable or disable Auto-Negotiation and set the Advertised Ability.

To access the High Speed Interface Conﬁguration screen from the High Speed Interface Conﬁguration Menu screen, use the arrow keys to highlight the FAST ETHERNET INTERFACES menu item and press ENTER. The High Speed Interface Conﬁguration screen displays.

Event Message Line

Device Type: 2M46-04R

Port Type Link Status Current Oper. Mode Desired Oper. Mode Advertised Ability

SAVE

2M46-04R LOCAL MANAGEMENT

High Speed Interface Configuration

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

Port 1 FE-100TX Link 100Base-TXFD

[Auto-Negotiation] [100Base-TXFD] [Disabled]

EXIT

Port 2 Unknown N/A [N/A] [N/A] [N/A]

RETURN

2314-24

Figure 5-19 High Speed Interface Conﬁguration Screen

5-44 2M46-04R/2M46-04RDC User’s Guide

High Speed Interface Conﬁguration Screen

The following brieﬂy explains each ﬁeld of the High Speed Interface Conﬁguration screen:

Port Type (Read-only)

Displays the type of interface (FE-100FX, FE-100TX, FE-100F3, or Unknown) installed in ports 1 and 2. Figure 5-19 shows that there is an FE-100TX interface installed in port 1 and no interface, indicated by Unknown, in port 2.

Link Status (Read-only)

Indicates whether or not there is a physical connection from this port to another 10BASE-T or 100BASE-TX/FX device. One of the following values displays:

• Link – There is a link signal present and a valid physical connection to

another device.

• No Link – There is no link signal present and no valid physical

connection to another device.

Current Oper. Mode (Read-only)

This ﬁeld displays the current operating mode of ports 1 and 2. Depending on whether a 100BASE-FX, or 100B ASE-TX is installed, this ﬁeld displays the following:

• With a 100BASE-FX interface: 100Base-FX, 100Base-FXFD (full

duplex), or N/A when port is empty.

• With a 100BASE-TX interface: Unknown, 10Base-T, 10Base-TFD

(full duplex), 100Base-TX, 100Base-TXFD (full duplex) or N/A when port is empty.

Desired Oper. Mode (Selectable)

This ﬁeld allows the user to select the desired operational mode for an interface in port 1 or 2. The ﬁeld toggles between 100Base-FX and 100Base-FXFD (full duplex) when an FE-100FX or FE-100F3 is installed. Section 5.14.1 describes how to conﬁgure a port with an FE-100FX or FE-100F3.

2M46-04R/2M46-04RDC User’s Guide 5-45

Chapter 5: Local Management

NOTE

In normal operation, the port with an FE-100TX installed automatically establishes a link with the device at the other end of the segment without requiring user setup. However, Local Management provides the user with the option of manually conﬁguring that port.

If an FE-100TX is installed, the ﬁeld steps to Auto-Negotiation, 10Base-T, 10Base-TFD (full duplex), 100Base-TX, and 100Base-TXFD (full duplex). In normal operation, the port with an FE-100TX installed is capable of auto-negotiating the operational mode and no further user setup is required. Section 5.14.3 describes how to manually conﬁgure an FE-100TX.

In Auto-Negotiation, the FE-100TX negotiates to the highest common denominator of the two interfaces. The order of priority of negotiation is 100BASE-TXFD, 100BASE-TX, 10BASE-TFD, and 10BASE-T.

Advertised Ability (Selectable)

During auto-negotiation, the FE-100TX “tells” the device at the other end of the segment about its capabilities. The capabilities of a port (1 or 2) with an FE-100TX installed are 10BASE-T, 10BASE-TFD (full duplex mode), 100BASE-TX and 100BASE-TXFD (full duplex mode). In normal operation, with all capabilities enabled, the FE-100TX “advertises” that it has the ability to operate in any mode. The Network Manager may choose to set up the port so that only a portion of the available capabilities are advertised and the others are disabled. For example, only 100BASE-TX and 100BASE-TXFD might be enabled so that only devices that operate at 100 Mbps can communicate with that port. Section 5.14.5 describes how to enable or disable advertised modes.

5.14.1 Conﬁguring an FE-100FX or FE-100F3

in Port 1 or 2

When an FE-100FX or FE-100F3 is installed in port 1 or 2, it must be manually set to operate in the same technology as the device at the other end of the connected segment. Section 5.14.2 provides instructions for manually conﬁguring the port with an FE-100FX or FE-100F3 interface.

5-46 2M46-04R/2M46-04RDC User’s Guide

High Speed Interface Conﬁguration Screen

5.14.2 Setting the FE-100FX or FE-100F3

Desired Operational Mode

Use this ﬁeld to set the active technology. This ﬁeld toggles between 100Base-FX and 100Base-FXFD (full duplex). To set the active technology through Local Management, proceed as follows:

1. Use the arrow keys to highlight the Desired Oper. Mode field.

2. Use the SPACE bar to select 100Base-FX or 100Base-FXFD (full

duplex).

3. Press ENTER. The port now operates in the chosen mode.

4. Use the arrow keys to highlight the SAVE command. Press ENTER.

The message “SAVED OK” displays and Local Management saves the changes to memory.

5.14.3 Conﬁguring an FE-100TX in Port 1 or 2

In normal operation, a port (1 or 2) with an FE-100TX interface automatically establishes a link with the device at the other end of the segment and no user setup is required. Section 5.14.4 and Section 5.14.5 provide instructions for manually conﬁguring the port with an FE-100TX installed.

5.14.4 Setting the FE-100TX Desired Operational Mode

Use this ﬁeld to set the active technology. This ﬁeld steps between Auto-Negotiation, 10Base-T, 10Base-TFD (full duplex), 100Base-TX, and 100Base-TXFD (full duplex). If Auto-Negotiation is selected, the FE-100TX automatically sets the active technology. To manually set the active technology through Local Management, proceed as follows:

1. Use the arrow keys to highlight the Desired Oper. Mode field.

2. Use the SPACE bar to select the desired mode. Press ENTER. If any

mode other than Auto-Negotiation is selected, the port only operates in the chosen mode and Auto-Negotiation is disabled.

3. Use the arrow keys to highlight the SAVE command. Press ENTER.

The message “SAVED OK” displays and Local Management saves the changes to memory. The selected mode is displayed in both the Desired Operational Mode field and the Current Operational Mode field.

2M46-04R/2M46-04RDC User’s Guide 5-47

Chapter 5: Local Management

5.14.5 Setting the FE-100TX Advertised Ability

In normal operation, a port (1 or 2) with an FE-100TX auto-negotiates to the highest speed possible. Under some circumstances, the Network Administrator may want the port to advertise only some of the available modes and not advertise in other modes. This ﬁeld steps to 10Base-T, 10Base-TFD (full duplex), 100Base-TX, and 100Base-TXFD (full duplex). To set the advertised ability, proceed as follows:

1. Use the arrow keys to highlight the Advertised Ability field.

2. Use the SPACE bar to select the desired mode.

3. Use the arrow keys to move to the Enabled/Disabled field to the right

of the desired mode and use the SPACE bar to select Enabled or Disabled. Press ENTER.

4. Repeat steps 1 to 3 until you have completed enabling or disabling the

desired advertised modes.

5. Use the arrow keys to highlight the SAVE command. Press ENTER.

The message “SAVED OK” displays and Local Management saves the changes to memory.

5.15 FLASH DOWNLOAD SCREEN

The Flash Download screen, shown in Figure 5-20, allows the user to clear the information stored in the 2M46-04R FLASH memory and download a new image ﬁle from a TFTP server. Before downloading an image to the device, load the image onto the network TFTP server.

NOTES

5-48 2M46-04R/2M46-04RDC User’s Guide

The user may also force the do wnload of an image by changing the position of Switch 6 located inside the device. Refer to

Section C.2.1, Setting the Mode Switch, for details. If Switch 6

is toggled, the TFTP server must be located on a Fast Ethernet port.

For information on how to set up a workstation as a TFTP server, refer to the speciﬁc workstation documentation.

Boot PROM downloads (.hex) cannot be done through HSIM ports. If downloading through an HSIM, runtime download MUST be used. Firmware based downloads (.ﬂs) can be done through any port.

Flash Download Screen

To access the Flash Download screen from the Device Speciﬁc Conﬁguration Menu screen, use the arrow keys to highlight the FLASH DOWNLOAD menu item and press ENTER. The Flash Download screen displays.

TFTP DOWNLOAD. WILL COMMIT TO FLASH. REBOOT IN PROGRESS...

Device Type: 2M46-04R

EXECUTE

2M46-04R LOCAL MANAGEMENT

Flash Download

Download Method: Reboot After Download: TFTP Gateway IP Addr:

Last Image Server IP:

Last Image File Name:

Download Server IP:

Download File Name:

EXIT

[TFTP] [YES]

134.141.79.123

134.141.79.121 /tftpboot/2M46.hex

Figure 5-20 Flash Download Screen

Download Server IP and Download File Name are displayed

NOTE

only when TFTP or RUNTIME is selected in Download Method.

Firmware Revision: XX.XX.XX BOOTPROM Revision: XX.XX.XX

RETURN

2314-49

The following brieﬂy explains each ﬁeld of the Flash Download screen:

Download Method (Selectable)

This ﬁeld toggles between BOOTP, TFTP, and RUNTIME. If set for BootP, the device sends out a BootP request to determine the IP address of the TFTP server and the ﬁle name of the image to be downloaded. If set for TFTP or RUNTIME, the 2M46-04R attempts a TFTP do wnload based on the IP address and ﬁle name entered in the ﬁelds at the bottom of the Flash Download screen. Section 5.15.1 describes how to download using BootP. Section 5.15.2 describes how to download using TFTP.

Section 5.15.3 describes how to download using Runtime.

2M46-04R/2M46-04RDC User’s Guide 5-49

Chapter 5: Local Management

Reboot After Download (Modiﬁable when RUNTIME is chosen only)

This ﬁeld notiﬁes the user that the 2M46-04R will reboot after the download is complete. If a Runtime Download is performed, this ﬁeld toggles between YES and NO. If YES is selected, the device reboots after the download is completed. If NO is selected, the device continues using the existing ﬁrmware image and stores the new ﬁrmware image in FLASH memory. When the device is reset or during the next power-up, the device will boot from FLASH memory using the new image.

TFTP Gateway IP Addr (Selectable)

This ﬁeld shows the IP address of the TFTP gateway deﬁned in the General Conﬁguration screen in Section 5.7.4.

Last Image Server IP (Read-only)

This ﬁeld shows the IP address of the server used for the pre vious FLASH Download.

Last Image File Name (Read-only)

This ﬁeld shows the complete path and ﬁle name of the last image downloaded to FLASH.

If TFTP or RUNTIME is selected as the download method (Figure 5-20), the following two additional ﬁelds appear:

Download Server IP (Modiﬁable)

The IP address of the TFTP server to be used for the FLASH download is entered in this ﬁeld.

Download File Name (Modiﬁable)

The complete TFTP Server path and ﬁle name of the new image is entered in this ﬁeld.

5.15.1 Image File Download Using BootP

To download a ﬁrmware image into FLASH using BootP, proceed as follows:

1. Use the arrow keys to highlight the Download Method field.

2. Use the SPACE bar to select BOOTP.

3. Use the arrow keys to highlight the TFTP Gateway IP Addr field.

5-50 2M46-04R/2M46-04RDC User’s Guide

Flash Download Screen

4. Set the IP address of the TFTP gateway server (this defaults to the

same IP address set in the TFTP Gateway IP Addr ﬁeld in the General Configuration screen).

5. Use the arrow keys to highlight EXECUTE at the bottom of the screen

and press ENTER. The message “BOOTP DOWNLOAD. WILL COMMIT TO FLASH. REBOOT IN PROGRESS...” displays in the event message line at the top of the screen and the new image is downloaded into FLASH memory.

5.15.2 Image File Download Using TFTP

To download a ﬁrmware image into FLASH using TFTP, proceed as follows:

1. Use the arrow keys to highlight the Download Method field.

2. Use the SPACE bar to select TFTP.

3. Use the arrow keys to highlight the TFTP Gateway IP Addr field.

4. Set the IP address of the TFTP gateway server (this defaults to the

same IP address as that set in the TFTP Gateway IP Addr field on the General Configuration screen).

5. Use the arrow keys to highlight the Download Server IP field.

6. Enter the IP address of the TFTP server using the DDN format.

For example: 134.141.79.121

7. Use the arrow keys to highlight the Download File Name field.

8. Enter the complete path and file name of the image stored on the

download server. For example: /tftpboot/2M46.hex

9. Use the arrow keys to highlight EXECUTE at the bottom of the screen

and press ENTER. The message “TFTP DOWNLOAD. WILL COMMIT TO FLASH. REBOOT IN PROGRESS...” displays in the event message line at the top of the screen and the new image is downloaded into FLASH memory.

2M46-04R/2M46-04RDC User’s Guide 5-51

Chapter 5: Local Management

5.15.3 Image File Download Using Runtime

To download a new ﬁrmware image into FLASH using Runtime, proceed as follows:

1. Use the arrow keys to highlight the Download Method field.

2. Use the SPACE bar to select RUNTIME.

3. Use the arrow keys to highlight the Reboot After Download field.

4. Use the SPACE bar to select either YES or NO. Select YES if you

want the device to reboot after the download is completed. Select NO if you want the device to store the new image in FLASH memory until the device is reset or during the next power-up.

5. Use the arrow keys to highlight the TFTP Gateway IP Addr field.

6. Set the IP address of the TFTP gateway server (this defaults to the

same IP address as that set in the TFTP Gateway IP Addr field on the General Configuration screen).

7. Use the arrow keys to highlight the Download Server IP field.

8. Enter the IP address of the TFTP server using the DDN format.

For example: 134.141.79.121

9. Use the arrow keys to highlight the Download File Name field.

10. Enter the complete path and file name of the image stored on the

download server. For example: /tftpboot/2M46.ﬂs

11. Use the arrow keys to highlight EXECUTE at the bottom of the screen

and press ENTER. The message “RUNTIME DOWNLOAD. WILL COMMIT TO FLASH. REBOOT IN PROGRESS...” displays in the event message line at the top of the screen and the new image is downloaded into FLASH memory.

5-52 2M46-04R/2M46-04RDC User’s Guide

Cabletron Systems 2M46-04R User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

NOTICE

CONTENTS

INTRODUCTION
