RapidRun® Optical Runner Cable
OFNP (plenum) rated for in-wall installation—optimized for extremely high bandwidth and data speeds over a single fiber runner cable!
OVERVIEW
RapidRun Optical is our leanest-longest, fastest-strongest RapidRun product yet! Designed to be the standard for in-wall audio/video installations, it boasts
distances of up to 1000 feet, an 18Gbps bandwidth, and a diameter of just a half inch. Using pre-terminated break-away flying leads and wall plates with
an in-wall runner ensures flexible, efficient, high quality connections for all types of equipment, with no field terminations.
Utilize this OFNP (plenum) rated fiber runner cable for in-wall installations that require the highest in-wall ratings. Supports up to a 4k resolution at up to
1000 feet, while providing enough bandwidth to serve the audio/video needs of commercial applications from classrooms to lecture halls and auditoriums
to boardrooms for years to come.
Please note: Each complete RapidRun Optical solution requires a break-away flying lead or wall plate to terminate each end of the runner cable. Each runner
requires (2) break-away flying leads, (2) wall plates, OR (1) break-away flying lead and (1) wall plate.
Note:
– RapidRun Optical Runners are directional cables that require the TX to be installed at the source side and the RX to be installed at the display side.
– RapidRun Optical Fiber Pulling Eye sold separately. (60155)
FEATURES
– Supports full 1080p, 4k, 3D HDMI features up to 1000ft
– Utilizes fiber cabling, so it is resistant to EMI/RFI interference
– Powered with USB at the display side (RX)
APPLICATIONS
– In-wall rated HDMI signal extension
– Long distance HDMI signal extension
Page 2
TECHNICAL
MARKETING
DOCUMENT
ELECTRICAL CHARACTERISTICS:
Resolutions Supported: 4k x 2k 60Hz, 4k x 2k 30Hz, 1080p, 720p, 480p
HDMI Features Supported: Ethernet Return Channel, HDMI High Speed, HDCP, EDID, CEC,
Audio Return Channel
Data Rate Supported: 18Gbps
PHYSICAL CHARACTERISTICS:
Jacket Rating: OFNP (Plenum)
Temperature Rating: 0°C ~ 70°C
Humidity: 0% ~ 90% RH
Cable Pull Strength: 30lbs
Bend Radius: 5mm
Compliance: UL/CSA, OFNP, CE, FCC, RoHS2
SPECIFICATIONS:
RapidRun Optical Runner Cables
ITEM DESCRIPTION
60118 35ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60119 50ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60120 65ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60121 80ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60122 100ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60123 125ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60124 150ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60125 175ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60126 200ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60127 500ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60128 750ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
60129 1000ft RapidRun Optical Runner Cable – Plenum, OFNP-Rated
© 2014 Legrand All Rights Reserved rev.06/14 TMD–11848_05.14_PDF
Cables To Go
3555 Kettering Blvd.
Moraine, OH 45439
Phone: 800.287.2843
www.c2g.com
