cable matters cDock USB-C Docking Station User Manual
email: support@cablematters.com
c
Dock
USB-C™ Smartphone Docking Station
with PD
www.cablematters.com
cDock USB-C Smartphone Dock
1
Table of Contents
1. INTRODUCTION……………………… .......... ………………….…...2
1.1 Introduction
1.2 Copyright and Trademarks
1.3 FCC Compliance Statement
2. PRODUCT OVERVIEW
2.1 Package Contents
2.2 Product Description
2.3 Product Features ..................................................................................... 3
2.4 Smartphone Requirements
3. CONNECTION AND OPERATING INSTRUCTIONS …….. ............ .4
3.1 Preparing the Dock
3.2 Connecting a Display with HDMI…………..… .................. …………...….5
3.3 Connecting a 3.5mm Headset or Microphone
3.4 Connecting USB-A Peripheral Devices………… ……………...………....6
3.5 Connecting a USB-C Peripheral Device
3.6 Connecting to an Ethernet Network
3.7 RF Remote with Keyboard………………………………………… ..... …...7
3.8 Charging the Remote………………………………………… ............. …...8
3.9 Troubleshooting………………………………………… ...................... …...9
4. TECHNICAL SPECIFICATIONS……… .......... ………..…….…………....10
5. WARRANTY AND SUPPORT
5.1 Customer Support and Contact Information
5.2 Warranty Information
5.3 Limitations of Liability
www.cablematters.com
2
cDock USB-C Smartphone Dock
1. INTRODUCTION
1.1 Introduction
Thank you for your purchase from Cable Matters® Inc., the ‘Reliable Connectivity’ com-
pany. This User Manual provides an overview of the features and installation of your new
cDock USB-C Smartphone Docking Station
Please read these instructions carefully before connecting, operating or configuring this
product. Please keep this manual for future reference.
Contact support@cablematters.com for questions or product support.
1.2 Copyright and Trademarks
Specifications are subject to change without notice. Cable Matters is a registered trademark or trade-
mark of Cable Matters Inc. All rights reserved. All other trademarks are the property of their respective
owners.
USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum
1.3 FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device must not cause harmful interference, and 2) this device must accept any interference
received, including interference that may cause undesired operation.
2. PRODUCT OVERVIEW
2.1 Package Contents
Please check that the following items are contained in the package:
• cDock Smartphone Docking Station
• RF Remote with Keyboard
• USB Charging Cable for RF Remote
• 4K-Rated HDMI Cable
• 12V 2A AC Power Adapter
• User Manual (available in a PDF from cablematters.com)
www.cablematters.com
cDock USB-C Smartphone Dock
3
2.2 Product Description
The Cable Matters® cDock USB-C Docking Station unleashes all the
features of a USB-C smartphone while charging at the same time. Stream
audio and video, connect USB peripheral devices, and add a wired
Ethernet network over a single USB-C phone port. Watch movies from
your phone on a 4K TV with the included RF remote. Connect a keyboard
and mouse to the Dock for editing documents for school or work.
2.3 Product Features
• Transform a single USB-C phone port into a docking station
• Power and charge a smartphone while in use
• Connect to a wired Ethernet network
• Stream 4K@60Hz video and audio to a display with HDMI
• Control the display with an RF Remote
• Connect USB-A and USB-C peripheral devices
• Connect a headset, external speaker or microphone
2.4 Smartphone Requirements
Check kb.cablematters.com for a list of compatible smartphones
• Smartphone with Android 7.0 or higher
• Video mirroring requires DisplayPort Alternate Mode to view video over USB-C
• Fast-charging a smartphone requires Power Delivery over USB-C
• Connecting a USB flash drive requires Mass Storage Device support
• Audio over USB-C must be supported by the phone to use the 3.5mm port
