C2G VGA W-AUDIO OVER CAT5 EXTENDER User Manual

SER GUIDE

U

VGA W/AUDIO OVER CAT5 EXTENDER

Model: 39984(1 port base unit)

1

TABLE OF CONTENTS

Introduction................................................................................................................................................2

Features.....................................................................................................................................................3

System Requirements .........................................................................................................................4

Package Contents......................................................................................................................................5

Device Overview.........................................................................................................................................6

Device Installation ......................................................................................................................................7

Troubleshooting..........................................................................................................................................10

Technical Specifications..........................................................................................................................11

Cables To Go One Year Warranty............................................................................................................12

Important Safety Information.....................................................................................................................13

1

INTRODUCTION

Thank you for purchasing the TruLink™ 1 Port VGA w/Audio over Cat5 Extender Base Unit. The Extender
Base Unit when paired with the Extender Remote Unit is a robust solution that allows you to extend your
VGA and audio signal up to 300 meters (1000 feet) over a Cat5E Unshielded Twisted Pair (UTP) cable.
This solution is ideal for applications where your VGA monitor needs to be placed further than the average
100 foot VGA cable limitation. Driving VGA and audio signals over Cat5E allows you to take advantage of
your UTP cable infrastructure already installed for a cost-effective and reliable installation. With the TruLink
VGA w/Audio over Cat5 Extender, you can place your display across the room, on another floor, or in
another building while your computer remains in a convenient location. It is recommended that you read
this guide thoroughly before use, and retain for future reference.

2

FEATURES

 Extend your analog video and audio signals up to 300 meters (1000 feet)
 Cat5E UTP cabling enables easy and cost effective in-wall installation
 Supports the following resolutions using Cat5E* cabling:

100M 1280x1024
180M 1024x768
200M 800x600
300M 640x480

3

SYSTEM REQUIREMENTS

 Remote Unit- Part #39986 (sold separately)
 Cat5E UTP Cable
 HD15 and 3.5mm Audio connections on computer
 HD15 and 3.5mm Audio connections on monitor, projector, or other display device
 HD 15 male to male cables for display device connected and 3.5mm cables for speaker, projector, etc.

connected
