BW Technologies M5-XW0Y-R-P-D-Y-N-00, M5-XWAY-R-P-D-Y-N-00, M5-XW0Y-A-P-D-Y-N-00, M5-XWSY-R-P-D-Y-N-00, M5-XWAY-R-D-D-Y-N-00 User manual
...
www.GlobalTestSupply.com
1, 2, 3, 4, and 5-Gas Detector
User Manual
Limited Warranty and Limitation Liability
BW Technologies LP (BW) warrants the product to be free from defects in material and workmanship under normal use and service for a period of two years, beginning on the date of
shipment to the buyer. Thi s warranty extends only to t he sale of new and u nused product s to t he original buyer. BW’s warranty obligation is limited, at BW’s option, to refu nd of the pur chase
price, repair or replacement of a defective product that is returned to a BW authorized service center within the warranty period. In no event shall BW’s liability hereunder exceed the
purchase price actually paid by the buyer for the Product.
This warranty does not include:
a) fuses, disposable batteries or the routine replacement of parts due to the normal wear and tear of the product arising fro m use;
b) any product which in BW’s opinion, has been misused, altered, neglected or damaged, by accident or abnormal conditions of operation, handling or use;
c) any damage or defects attributable to repair of the product by any person other than an authorized dealer, or the installation of unapproved parts on the product; or
The obligations set forth in this warranty are conditional on:
a) proper storage, installation, calibration, use, ma intenance and compliance with the product manual instructions and any other applicable recommendations of BW;
b) the buyer promptly notifying BW of any defect and, if required, promptly making the product available for correction. No goods shall be returned to BW until receipt by the buyer of
shipping instructions from BW; and
www.GlobalTestSupply.com
c) the right of BW to require that the buyer provide proof of purchase such as the original invoice, bill of sale or packing slip to establish that the product is within the warranty period.
THE BUYER AGREES THAT THIS WARRANTY IS THE BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. BW SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR BASED ON CONTRACT, TORT OR RELIANCE
OR ANY OTHER THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limit ation of incidental or consequential damages, the limitations and exclusions of
this warranty may not apply to every buyer. If any provision of this warr anty is held invalid or unenforceable by a court of competent jurisdiction, such holding will not affect the validity or
enforceability of any other provision.
Table of Contents
Title Page
Limited Warranty and Limitation Liability ........................................................................................................................ 0
www.GlobalTestSupply.com
Contacting BW Technologies by Honeywell.................................................................................................................... 1
Introduction......................................................................................................................................................................... 1
Gases Monitored ..................................................... .... ... ... ... ... .... ... ................................................................................. 2
Safety Information - Read First.......................................................................................................................................... 2
aCautions .......................................................................................................................................................................... 3
Sensor Poisons and Contaminants .................................................................................................................................. 6
Getting Started.................................................................................................................................................................... 8
Parts of the GasAlertMicro 5/PID/IR.................................................................................................................................. 9
Screen Elements...... ... ... ... .... ... ................................................... .... ... ... ............................................................................ 10
Pushbuttons...................................................................................................................................................................... 11
Activating the Detector..................................................................................................................................................... 12
Self-Tests....................................................................................................................................................................... 12
Battery Test .............................................................................................................................................................. 12
Datalogging (Optional).............................................................................................................................................. 13
Pump Test ................................................................................................................................................................ 15
Due-Lock Enabled.................................................................................................................................................... 16
Force Calibration Enabled........................................................................................................................................ 17
Bump Daily Enabled................................................................................................................................................. 17
Self-Test Pass ................................................... ... .................................................... ... ... ............................................... 19
Self Test Fail.................................................................................................................................................................. 19
Battery Test ...................................................................................................................................................................19
Datalogger Operation (Optional).................................................................................................................................... 19
i
GasAlertMicro 5/PID/IR
User Manual
Title Page
Deactivating the Detector.................................................................................................................................................20
User Options Menu ........................................................................................................................................................... 20
Exit User Options Menu.................................................................................................................................................21
Options Menu.... .... ... ... .................................................... ... ... ... ......................................................................................21
Backlight ................................................................................................................................................................... 22
www.GlobalTestSupply.com
Confidence Beep ......................................................................................................................................................22
Due-Lock ..................................................................................................................................................................22
Latched Alarms.........................................................................................................................................................22
Passcode Protect......................................................................................................................................................23
Safe Display.............................................................................................................................................................. 23
Sensor Configuration .....................................................................................................................................................24
Sensor Enable/Disable .............................................................................................................................................25
Span Gas Value........ .................................................... ... ... .... ..................................................................................26
STEL Period ............................................................................................................................................................. 26
TWA Method.............................................................................................................................................................27
Resolution.................................................................................................................................................................27
%Vol CO
%Vol CH
(CO2 Sensors Only)..................................... .................................................... ... ... ... ...............................28
2
(LEL Sensors Only)..................................................................................................................................28
4
Correction Factor (CF)..............................................................................................................................................28
Automatic Oxygen (O
) Calibration..................................... .................................................... ... .... ... ........................30
2
Logger Option ................................................................................................................................................................30
Clock Option ..................................................................................................................................................................31
Language Selection ........... ... ................................................... .... ... ... ............................................................................32
Tech Mode.....................................................................................................................................................................32
Sensors..................................................................................................................................................................... 33
Initialize.....................................................................................................................................................................34
Force Calibration ...................................................................................................................................................... 35
ii
GasAlertMicro 5/PID/IR
User Manual
Title Page
Bump Daily ................................................... ... ... .... ................................................... ... ............................................35
Stealth Mode.............................................................................................................................................................36
Sleep Mode......... ... .................................................... ... ... ... ......................................................................................36
Alarms................................................................................................................................................................................37
Gas Exposures Computed.............................................................................................................................................40
www.GlobalTestSupply.com
Viewing Gas Exposures.................................................................................................................................................40
Clearing Gas Exposures................................................................................................................................................41
Gas Alarm Setpoints......................................................................................................................................................41
Viewing the Alarm Setpoints..........................................................................................................................................41
Resetting Gas Alarm Setpoints......................................................................................................................................42
Stopping a Gas Alarm....................................................................................................................................................43
Sensor Alarm .................................................................................................................................................................43
Pump Alarm ............. .................................................... ... ... ... .........................................................................................43
Low Battery Alarm.......................................................................................................................................................... 44
Automatic Deactivation Alarm........................................................................................................................................44
Calibration and Setting Alarm Setpoints ........................................................................................................................ 44
Guidelines......................................................................................................................................................................44
Diagnostics Testing............................................... ... .... ................................................... ...............................................45
Applying Gas to the Sensors ................................................... .... ... ... ... .... ... ... ............................................................... 46
Single Gas Calibration Cap ......................................................................................................................................46
Calibration Procedure ........... ... ... ... .................................................... ... .... ... ..................................................................47
Start Calibration........................................................................................................................................................48
Auto Zero and Oxygen (O
Zero CO
(GasAlertMicro 5 IR only) ......................................................................................................................... 48
2
) Sensor Calibration ..... ... ................................................... .... ... ... ..................................48
2
Passcode Protect Activated......................................................................................................................................49
Auto Span.................................................................................................................................................................50
Successful Span.......................................................................................................................................................52
iii
GasAlertMicro 5/PID/IR
User Manual
Title Page
Setting the Calibration Due Date .............................................................................................................................. 52
Alarm Setpoints ............................................ ... ... .... ... ................................................... ............................................54
Setting the Remaining Alarm Setpoints....................................................................................................................56
Finish Calibration......................................................................................................................................................56
Verification................................................................................................................................................................56
www.GlobalTestSupply.com
Unsuccessful Span...................................................................................................................................................57
Attaching the Accessories... ... ... ... ... .... ... ... ... .... ...............................................................................................................59
Installing the Pump Module............................................................................................................................................59
Replacing the Pump Filter..............................................................................................................................................60
Replacing the Pump Nozzle...........................................................................................................................................61
Attaching the Auxiliary Filter ..........................................................................................................................................61
Attaching the Sample Probe ..........................................................................................................................................63
Datalogger .........................................................................................................................................................................64
MMC/SD Card Compatibility.............................................................................................................................................64
Inserting the MMC/SD Card...........................................................................................................................................64
MMC/SD Card Troubleshooting.......................................................................................................................................65
Restoring Datalog Files..................................................................................................................................................66
Reformatting the MMC/SD Card.................................................................................................................................... 67
Import Datalogs to Fleet Manager II ....................................................... .... ... ... ...............................................................68
Minimum PC Requirements........................................................................................................................................... 68
Importing from MicroDock II to Fleet Manager II............................................................................................................68
Import to Fleet Manager II Using a Card Reader...........................................................................................................68
View Datalog Files in Spreadsheets................................................................................................................................69
Example of a Datalog Spreadsheet..........................................................................................................................70
Maintenance ......................................................................................................................................................................73
Battery Cautions ............................................... ... ... .... ................................................... ...............................................73
Charging the Battery......................................................................................................................................................73
iv
GasAlertMicro 5/PID/IR
User Manual
Title Page
Replacing the Alkaline Batteries ....................................................................................................................................74
Replacing the Lithium Battery Pack...............................................................................................................................75
Replacing a Sensor or Sensor Filter..............................................................................................................................75
Photoionization Detector (PID) ............................................. ... .... ... ... ... .... .....................................................................77
Clean or Replace the Lamp.................................... ... ... ... ... .... ... ... ............................................................................77
www.GlobalTestSupply.com
Replace the Lamp.. .................................................... ... ... ... ......................................................................................78
Replace the Electrode Stack ........................................ ... ... .... ..................................................................................78
Troubleshooting................................................................................................................................................................79
Replacement Parts and Accessories ..............................................................................................................................85
Specifications....................................................................................................................................................................87
General Specifications for Datalogger Units..................................................................................................................90
GasAlertMicro 5/PID/IR Downloadable Datalogger ....................................................................................................... 90
PID Correction Factor (CF) Library..................................................................................................................................91
v
List of Figures
Figure Title Page
1. Parts of the GasAlertMicro 5/PID/IR...................................................................................................................... 9
www.GlobalTestSupply.com
2. Screen Elements................................................................................................................................................. 10
3. Applying Gas to the Sensors...............................................................................................................................46
4. Single Gas Calibration Cap................................................................................................................................. 47
5. Removing the Single Gas Calibration Cap.......................................................................................................... 47
6. Installing the Pump Module................................................................................................................................. 59
7. Replacing the Pump Filter................................................................................................................................... 60
8. Replacing the Pump Nozzle................................................................................................................................ 61
9. Attaching the Auxiliary Filter...............................................................................................................................61
10. Attaching the Filter Cord..................................................................................................................................... 62
11. Attaching the Sample Probe................................................................................................................................ 63
12. Inserting/Removing the MMC/SD Card............................................................................................................... 65
13. Replacing the Alkaline Batteries..........................................................................................................................74
14. Replacing the Lithium Battery Pack ............................................... ... ... ...............................................................75
15. Replacing a Sensor or Sensor Filter ................................................................................................................... 76
16. Parts of the PID...................................................................................................................................................77
vii
List of Tables
Table Title Page
1. Gases Monitored........................................... .... ................................................... ... .... ... ....................................... 2
www.GlobalTestSupply.com
2. Sensor Poisons and Contaminants....................................................................................................................... 6
3. International Symbols.............................. ..............................................................................................................7
4. Parts of the GasAlertMicro 5/PID/IR...................................................................................................................... 9
5. Screen Elements................................................................................................................................................. 10
6. Pushbutton .......................................................................................................................................................... 11
7. Alarms ................................................................................................................................................................. 37
8. Computed Gas Exposures ............ ....... ... ... ... ...................................................................................................... 40
9. Gas Alarm Setpoints ..................................................... .... ... ... ... ......................................................................... 41
10. OSHA Sample Factory Alarm Setpoints.............................................................................................................. 42
11. Applying Gas to the Sensors............................................................................................................................... 46
12. Single Gas Calibration Cap................................................................................................................................. 47
13. Time Required to Span ....................................................................................................................................... 51
14. Installing the Pump Module................................................................................................................................. 59
15. Datalog Spreadsheet Example............................................................................................................................ 70
16. Datalog Status Codes ......................................................................................................................................... 71
17. Datalog Gas and Correction Factor Sensor Codes............................................................................................. 72
18. Replacing the Alkaline Batteries..........................................................................................................................74
19. Replacing a Sensor or Sensor Filter .................................................................................................................. 76
20. Parts of the PID sensor ....................................................................................................................................... 77
21. Troubleshooting................................................................................................................................................... 79
22. Replacement Parts and Accessories .................................................................................................................. 85
23. PID Corrections Factor (CF) Library.................................................................................................................... 91
ix
GasAlertMicro 5/PID/IR
www.GlobalTestSupply.com
Introduction
a Warning
To ensure personal safety, read the Safety Information -
Read First and Cautions before using the detector.
The GasAlertMicro 5, GasAlertMicro 5 PID, and GasAlertMicro 5 IR
gas detectors (“the detector”) warn of hazardous gas at levels above
user-defined alarm setpoints.
The detector is a personal safety device. It is your responsibility to
respond properly to the alarm.
Note
Unless reference is made to a specific detecto r model, the
GasAlertMicro 5, GasAlertMicro 5 PID, and GasAlertMicro 5 IR
detectors are referred to as GasAlertMicro 5/PID/IR.
Refer to Gases Monitored
prior to operating the detector.
1
GasAlertMicro 5/PID/IR
User Manual
Gases Monitored
The following table lists the gases that are monitored by the detector.
Table 1. Gases Monitored
Gas Detected Unit of Measure
www.GlobalTestSupply.com
Oxygen (O2)
Combustible gases (LEL)
Carbon monoxide (CO) parts per million (ppm)
Hydrogen sulfide (H
Phosphine (PH
Sulfur oxide (SO
Chlorine (Cl
)
2
Ammonia (NH
Nitrogen dioxide (NO
S)
2
)
3
)
2
)
3
)
2
Hydrogen cyanide (HCN) parts per million (ppm)
Chlorine dioxide (ClO
Ozone (O
)
3
)
2
Volatile orga nic compounds
(VOC)
Carbon dioxide (CO
) parts per million or %vol CO
2
% volume
a) percent of lower explosi
l
imit (%LEL)
b) percent by volu
me
thane 0-5.0% v/v
me
parts per million (ppm)
parts per million (ppm)
parts per million (ppm)
parts per million (ppm)
parts per million (ppm)
parts per million (ppm)
parts per million (ppm)
parts per million (ppm)
parts per million (ppm)
ve
CAUTION: FOR SAFETY REASONS, THIS EQUIPMENT MUST BE
OPERATED AND SERVICED BY QUALIFIED PERSONNEL ONLY.
READ AND UNDERSTAND THIS USER MANUAL COMPLETELY
BEFORE OPERATING AND SERVICING.
Safety Information - Read First
Use the detector only as specified in this user manual, otherwise the
protection provided by the detector may be impaired.
International symbols used on the detector and in this user manual are
defined in Table 3.
.
Read the Cautions on the following pages before using the dete ctor.
ec Warning
This instrument contains batteries. Do not mix with the
solid waste stream. Spent batteries must be disposed of
by a qualified recycler or hazardous materials handler.
Dispose of lithium cells immediately. Do not
disassemble and do not dispose of in fire. Do not mix
with the solid waste stream. Spent batteries must be
disposed of by a qualified recycler or hazar dous
materials handler.
2
2
GasAlertMicro 5/PID/IR
a
Cautions
aCautions
• Warning: Substitution of components may impair Intrinsic Safety.
• Caution: For safety reasons, this equipment must be operated and serviced by qualified person nel only . Read and understand
this user manual completely before operating or servicing.
www.GlobalTestSupply.com
• Do not use the detector if it is damaged. Inspect the detector before using. Look for cracks and/or missing parts.
• If the detector is damaged or parts are missing, contact BW Technologies by Honeywell
• Use only sensor(s) that are specifically designed for the GasAlertMicro 5/PID/IR detectors. Refer to Replacement Part
Accessories.
• Calibrate the detector before first-time use and then on a regular schedule, depending on use and sensor exposure to poisons
and contaminants. Sensors must be calibrated regularly and at least once every 180 days (6 months).
• BW recommends to bump test the sensors, before each day’s use, to confirm their ability to respond to gas by exposing the
detector to
Calibrate if the readings are not within the specified limits.
• BW recommends the combustible sensor be checked with a known concentration of calibration gas af ter any known exposure
catalyst contaminants/poisons (sulfur c ompounds, silicon vapors, halogenated compounds, etc).
• The combustible sensor is factory calibrated to 50 % LEL methane. If monitoring a different combustible gas in the % LEL range,
calibrate the sensor using the appropriate gas.
• Warning: High off-scale LEL readings may indicate an explosive concentration.
• Only the combustible gas detection portion of this instrument has been assessed for performance by CSA International.
• Protect the combustible sensor from exposure to lead compounds, silicones, and chlorinated hydrocarbons. Although certain
organic vapors (such as leaded gasoli ne and halogenated hydrocarbons) may temporarily inhibit sensor performance, in most
cases, the sensor will recover after calibration.
• Before using common products around sensors, refer to Sensor Poisons and Contaminants
a gas concentration that exceeds the alarm setpoints. Manually verify that the audible and visual alarms are activated.
immediately.
s and
.
to
3
GasAlertMicro 5/PID/IR
User Manual
aCautions
• Any rapid up-scaling reading followed by a declining or erratic reading may indicate a gas concentration beyond upper scale
li
mit, which may be hazardous.
• Calibrate only in a safe area that is free of hazardous gas, in an atmosphere of 20.9% oxygen.
www.GlobalTestSupply.com
• Use only BW approved batteries for the GasAlertMicro 5/PID/IR detectors. Refer to Replacement Parts and Accessories
• Charge the detector before first-time use. BW recommends the detector be charged after every workday.
• Charge the battery pack immediately when a low battery alarm occ urs.
• Read and adhere to the battery cautions provided in Battery Cautions
• Charge the GasAlertMicro 5/PID/IR batteries using the recommended charging adapter only. Do not use any other charging
a
dapter. Failure to adhere to this caution can lead to fire and/or explosion.
• Read and adhere to all instructions in the charger user manual. Failure to do so can result in fire, electrical shock, persona
njury, and/or property damage.
i
• Extended exposure of the GasAlertMicro 5/PID/IR detectors to certain concentrations of combustible gases and air may stress
detector el
rec
• Protect the PID sensor from exposure to silicone vapors.
• When calibrating O
to ensure accurate calibration. For more information, refer to Single Gas Calibration Cap
• Replace the CO
• The optional pump (M5-PUMP) is certified for use with the GasAlertMicro 5/PID/IR detectors only.
• Do not immerse the detector in liquids.
ement, which can seriously affect its performance. If an alarm occurs due to high concentration of combusti ble gases
alibration should be performed, or if needed, the sensor replaced.
and ClO2 sensors that are located in the Toxic 2 sensor position, a single gas calibration cap must be used
3
sensor only in a safe area that is free of hazardous gas.
2
.
.
.
l
a
,
4
• Do not test the combustible sensor’s response with a butane cigarette lighter; doing so will damage the sensor.
• Do not expose the detector to electrical shock or severe continuous mechanical shock.
• Do not attempt to disassemble, adjust, or service the detector unless instructions for that procedure are provided in the user
www.GlobalTestSupply.com
manual and/or that part is listed as a replacement part. Use only BW Technologies by Honeywell Replacement Parts and
Accessories.
• The detector warranty is void if customer, personnel, or third parties damage the detector during repair attempts. Repair
attempts made by non-BW Technologies by Honeywell repair/service personnel voids this warranty.
Lithium Battery Packs
• Warning: The lithium battery (M5-BAT08) may present a risk of fire or chemical burn hazard if misused. Do not disassemble,
heat above 212°F (100°C), or incinerate.
aCautions
GasAlertMicro 5/PID/IR
a
Cautions
• Do not use any other lithium batteries with the GasAlertMicro 5/PID/IR detectors. Use of any other cell can cause fire and/
plosion. To order and replace the M5-BAT08 battery, refer to Replacement Parts and Accessories.
ex
• Warning: Lithium polymer cells exposed to heat at 266°F (130°C) for 10 minutes can cause fire and/or explosion.
• Dispose of used lithium cells immediately. Do not disassemble and do not dispose of in fire. Do not mix with the solid waste
stream. Spent batteries must be disposed of by a qualified recycler or hazardous materials handler.
• Keep lithium cells away from children.
or
5
GasAlertMicro 5/PID/IR
User Manual
Sensor Poisons and Contaminants
Several cleaners, solvents, and lubricants can contaminate and cause
permanent damage to sensors. Before using cleaners, solvents, and
lubricants in close proximity to the detector sensors, read and adhere
to the following caution and table.
www.GlobalTestSupply.com
Use only the following BW Technologies by Honeywell
recommended products and pr ocedures:
• Use water based cleaners.
• Use non-alcohol based cleaners.
• Clean the exterior with a soft, damp cloth.
• Do not use soaps, polishes, or solvents.
a Caution
The following table lists common products to avoid using around
sensors.
Table 2. Sensor Poisons and Contaminants
Cleaners and
Lubricants
Brake cleaners Silicone cleaners
Lubricants Silicone based
Rust inhibitors Hand/body and
Window and glass
cleaners
Dishsoaps Mold releasing
Citrus based cleaners Polishes
Alcohol based
cleaners
Hand sanitizers
Anionic detergents
Methanol
(fuels and antifreezes)
Silicones Aerosols
Bug repellents
and protectants
adhesives, sealants, and gels
medicinal creams
that contain silicone
Tissues containing
silicone
agents
and sprays
Lubricants
Rust inhibitors
Window and
glass cleaners
6
Table 3. International Symbols
Symbol Description
GasAlertMicro 5/PID/IR
Sensor Poisons and Contaminants
n
www.GlobalTestSupply.com
g
X
ATEX
IECEx
Approved to both U.S. and Canadian Standards by CSA International
European Explosives Protection
Conforms to European Union Directives
Conforms to European ATEX Directives
International Electrotechnical Commission Scheme for Certification to Standards for Electrical Equipment for
Explosive Atmospheres
7
GasAlertMicro 5/PID/IR
User Manual
Getting Started
The list below provides the standard ite ms included with the detector.
If the detector is damaged or parts are missing, contact the place of
purchase immediately.
• Batteries: Three replaceable alkaline cells with battery pack,
on
www.GlobalTestSupply.com
To order parts, refer to Replacement Parts and Accessories
e rechargeable lithium battery pack
• Sensors: O
PID, or CO
• Calibration cap and hose
• Single gas calibration cap
• Screwdriver
• Quick reference guide
• Quick reference card
• User manual and training on CD-ROM
• Fleet Manager II (if applicable)
, combustible (LEL), toxic, H2S/CO (TwinTox sensor),
2
2
.
The detector is shipped with the sensors, and battery packs installed.
To replace sensors, the pump, or the battery pack, refer to Replacement
Parts and Accessories.
To become oriented with the features and functions of the detector, refer
or
to the following figures and tables:
• Fi
• Fi
• T
and Table 4. describe the detector’s components.
gure 1.
gure 2.
and Table 5. describe the detector’s screen elements.
able 6.
describes the detector’s pushbutton.
8
GasAlertMicro 5/PID/IR
Parts of the GasAlertMicro 5/PID/IR
Parts of the GasAlertMicro 5/PID/IR
www.GlobalTestSupply.com
Figure 1. Parts of the GasAlertMicro 5/PID/IR
Table 4. Parts of the GasAlert Micro 5/PID/IR
Item Description
1 Liquid crystal display (LCD)
2 Pushbuttons
3 Audible alarms
4 Toxic 2 sensor
Toxic 1/PID sensor (Micro 5 PID)
5
6 Visual alarm indicators (LEDs)
7 LEL sensor
8 Oxygen sensor
9 Pushbuttons
10 Battery pack
11 Alligator clip
or
Toxic 1/IR (CO
) sensor (Micro 5 IR)
2
9
GasAlertMicro 5/PID/IR
User Manual
Screen Elements
www.GlobalTestSupply.com
If enabled, the backlight automatically activates for 8 seconds
when there is an alarm condition and whenever there is
insufficient light to view the LCD. Any pushbutton reactivates
the backlight in low light conditions.
Figure 2. Screen Elements
Note
Table 5. Screen Elements
Item Description
1 Alarm condition
2 Automatically span sensor
3 Gas cylinder
4Gas type
5 Battery life indicator
6 Passcode lock
7 Data transmission
8Clock
9 Stealth mode
10 Pump indicator (optional)
11 MMC indicator (optional )
Alarm condition (low, high, TWA,
12
13 Automatically zero sensor
STEL, or multi alarm) or view TWA,
STEL and peak (MAX) gas exposures
10
Pushbuttons
Table 6. Pushbutton
Pushbutton Description
GasAlertMicro 5/PID/IR
Pushbuttons
www.GlobalTestSupply.com
A
G
H
• To activate the detector press A.
• To deactivate the detector, press and hold A until the countdown is complete.
• To increment the displayed value or scroll up, press G.
• To enter the user options menu, press and hold G and H simultaneously until the countdown is complete.
• To clear the TWA, STEL, and peak (MAX) gas exposure readings, press and hold C and G simultaneously
until the countdown is complete.
• To view the date and time, alarm setpoints (TWA, STEL, low, high) of all sensors, and the LEL/PID correction fact
applicable) press G.
(if
• To decrement the displayed value or scroll down, press H.
• To initiate calibration and to define alarm setpoints, press and hold C and H simultaneously until the countdown
is complete.
• To view the TWA, STEL, and peak (MAX) gas exposure readings, press C.
or
C
• To acknowledge latched alarms, press C.
11
GasAlertMicro 5/PID/IR
User Manual
Activating the Detector
If using the pump module, attach it and the pump accessories prior to
activating the detector.
For illustrations and procedures, refer to the following:
• Installing the Pump Module
www.GlobalTestSupply.com
• Attaching the Sample Probe
• Replacing the Pump Filter
• Replacing the Pump Nozzle
• Attaching the Auxiliary Filter
Only activate the detector in a safe atmosphere that is free of
hazardous gas in an atmosphere of 20.9% oxygen.
To activate the de tecto r, press A.
Self-Tests
When the detector is activated, it performs several self-tests. Conf irm
the following tests occur.
If an error message displays during the self-test, refer to
Troubleshooting
.
.
Note
Note
Battery Test
The detector performs a battery test during startup. I f the battery has
insufficient power to operate, the following screen di splays before
deactivating.
Replace the batteries and reactivate the detector.
1. All of the LCD elements display simultaneously as the detector beeps, flashes, vibrates, and briefly activates the backlight.
12
GasAlertMicro 5/PID/IR
Activating the Detector
2. The version and serial number of the detector displays.
www.GlobalTestSupply.com
3. The date and time displays.
Datalogging (Optional)
4. If the detect or is a datalogging unit, it determines if
• a MultiMediaCard (MMC) or Secure Digital (SD) card
nserted,
i
• the detector can communicate with the card,
• the detector supports the size of the card, and
• the card requires formatting.
Note
If there is a problem with the MMC/SD card, Datalogger
disabled displays. The detector then automatical ly continues
with the self-test.
If the card requires formatting, the following screen
displays as the card is automatically formatted.
5. The detector then runs a self-test to verify the sensors and
power supply are operating correctly.
is
13
GasAlertMicro 5/PID/IR
User Manual
Self-test Successful: If successful, the following screen displays.
www.GlobalTestSupply.com
Self-test Unsuccessful: If a sensor fails the self-test, a warning
displays indicating which sensor(s) has failed.
6. If correction factors are set in the user options, the LEL or PI
tom) correction factors display.
(cus
7. The TWA, STEL, low, and high alarm setpoints then
display in the following order (left to right).
TWA STEL
Low High
D
The alarm setpoints may vary by region. Refer to Resetting
Gas Alarm Setpoints.
Note
14
GasAlertMicro 5/PID/IR
Activating the Detector
Pump Test
8. If the pump module is attached to the detector, the following
reens display.
sc
www.GlobalTestSupply.com
When the following screen displays, block the pump inlet.
If the pump inlet is not blocked within 10 seconds or the pump
test fails, the following screens display.
If C is not pressed or the pump is not removed within
25 seconds, the detector performs the pump test again.
Note
The pump may require a new filter. Refer to Replacing the
Pump Filter.
If the pump alarm persists, remove the battery pack to deactivate the detector and then refer to the “Pump Operation” section of Troubleshooting
If the pump test is successful, the following screen
displays and the self-test continues.
.
15
GasAlertMicro 5/PID/IR
User Manual
9. Unless disa ble d in user op ti ons, the ox ygen (O2) sensor is cali-
brated automatically.
www.GlobalTestSupply.com
If the calibration is successful, the detector beeps twice.
Note
If the automatic O
Automatic O
10. The number of days remaini ng before calibration is due dis-
plays for all sensors.
calibration feature has been disabled,
2
span disabled displays.
2
If any sensor is over due for calibration, the LCD displays the
name of the sensor and the number of days past due.
Due-Lock Enabled
The Due-lock option ensures that a passcode must be entered when
calibration is past due, otherwise the detector automatically deactivates.
11. If Due-Lock is enabled in the user options, the followi
scree
n displays.
Enter the correct passcode and press C to confirm.
ng
16
Note
If any sensor is overdue, Y displays continually until calibra tion
is performed.
If no passcode is entered, or it is entered inc orrect ly, the following screen displays.
www.GlobalTestSupply.com
To enable/disable this option, refer to Due-Lock
options menu. Also refer to Passcode Protect
.
Force Calibration Enabled
12. If Force cal (force calibration) is enabled in tech mode, calibra-
tion is mandatory before the detector enters normal operation.
Refer to Force Calibration
refer to Calibration Procedure
in Tech Mode to enable/disable, and
to calibrate.
in the user
GasAlertMicro 5/PID/IR
Activating the Detector
Bump Daily Enabled
a Caution
BW recommends that a bump test to all sensors be
performed every 24 hours prior to the beginning of the
work shift.
13. If Bmp Daily (bump daily) is enabled in tech mode, the follow-
ing screens display.
If C is not pressed to start calibration , the f ollowin g scre en d isplays and the detector deactivates.
If a bump test of the LEL and O
detector will deactivate.
Apply the LEL gas and then apply the O
percentage than the default 20.9%, such as 18 % O
sensor is not performed, the
2
(a higher or lower
2
).
2
17
GasAlertMicro 5/PID/IR
User Manual
Successful Bump Tes t: If the bump test passes, the following screens
display.
www.GlobalTestSupply.com
The detector waits for the sensor(s) to clear (30 seconds) and then
enters normal operation.
Unsuccessful Bump Tes t: If the bump test is unsucce ssful or the bump
test is not performed, the following screen displays and the detector
deactivates.
If additional sensors require a bump test but are not mandatory, the
following screens display.
Press C Yes to accept and proceed to normal operation.
Or
If A No is pressed, or no buttons are pressed, the sensor(s) that is
past due displays as FAIL when the detector enters normal operation.
In the following screen example, only the SO
operational.
The self-test is now complete.
, CO, and O2 sensors are
2
18
GasAlertMicro 5/PID/IR
Activating the Detector
Self-Test Pass
If the detector passes the self-test, it enters normal operation and
displays the ambient gas readings.
www.GlobalTestSupply.com
The detector begins recording the peak (MAX) gas exposure and calculating the short-term exposure level (STEL) and time-weighted average
(TWA) exposures.
Self Test Fail
If a sensor fails, FAIL flashes above that sensor on the normal operation
screen. For possible problems and solutions, refer to Troubleshooting
Battery Test
The batteries are tested when the detector is activated and continuously
thereafter. The battery power icon displays continually during normal
operation. If battery power is low, flashes.
Datalogger Operation (Optional)
a Caution
Do not remove the battery pack while the detector is
activated. Doing so will prevent the datalogger from
logging correctly.
Datalogger operation is automatic and requires no settings. During
normal operation the card is tested every 20 seconds.
Note
The MMC/SD card icon (S) displays continuously on the LCD
when the card is inserted. The card is not required for opera-
.
tion; however, if the card is not inserted the detector will not
record data.
19
GasAlertMicro 5/PID/IR
User Manual
Deactivating the Detector
To deactivate the detector, press and hold A while it beeps and flashes
to the corresponding countdown.
www.GlobalTestSupply.com
At the end of the countdown, the detector emits an extended beep and
flash then displays 0 before deactivating.
Note
If A is not held down for the complete count down, the detec tor
remains activated.
User Options Menu
If the detector is passcode protected, a passcode must be entered to
access the user options menu. For more information, refer to Passcode
Protect.
The available user options are as follows:
1. Exit
2. Options: Backlight, confidence beep, due-lock, latch, passcode, and safe mode.
3. Sensors: Sensor enable /disable, span gas, STEL period, TW A
method, resolution, % vol CH
cal
ibration, and % vol CO
4. Logger
5. Clock
6. Language: English, French, German, Spanish, a
Portug
uese.
7. Tech mode: Sensors, initialize, forced calibration, daily bump
test, stealth, and zero level (CO
Tech mode is not visible in the user options menu. To access
this option, refer to Tech Mode
, correction factor, automatic O
4
, (CO2 sensor only)
2
nd
sensor only).
2
Note
.
2
20
GasAlertMicro 5/PID/IR
User Options Menu
1. To enter the user options menu, press and hold G and H
simultaneously as the detector beeps and fl ashes to the corresponding countdown.
www.GlobalTestSupply.com
H must be held down for the entire countdown to
G and
access the user options menu.
When the countdown is complete, the revision/serial number
screen displays followed by the options menu.
2. To scroll through the options, press H or G. When the cursor
displays beside the desired option, press C
To return to the previous menu, scroll to Back and press C
3.
pre
ss A.
.
or
Note
If no pushbuttons are pressed within 20 seconds, the detector
returns to normal operation.
Exit User Options Menu
To exit the user options menu and return to normal operation, scroll to
Exit and press C. The following screen displays.
The user options menu can also be exited by repeatedly pressing A
until the detector returns to normal operation.
Options Menu
Each feature within the Options menu is enabled/disabled by pressing
C to toggle between the checkboxes.
Enabled
Disabled
21
GasAlertMicro 5/PID/IR
User Manual
Backlight
The Backlght (backlight) option enables
the LCD backlight to activate automatically
in low-light conditions.
If disabled, the backlight activates only
when the detector is in alarm mode.
www.GlobalTestSupply.com
Note
In stealth mode, the backlight does
not activate.
The detector is shipped with the Backlght
option enabled.
Confidence Beep
The Confibeep (confidence beep) option
provides continuous confirmation that the
detector is operating properly. When confidence beep is enabled, the audible alarm
beeps once every 10 seconds.
Note
Confidence beep is automatically
disabled during a low battery alarm.
The detector is shipped with the
Confibeep option disabled.
Due-Lock
If the Due-lock (calibration user lockout)
option is enabled and a sensor is overdue
for calibration upon startup, the passcode
must be entered to access normal operation.
Note
If the correct passcode is not
entered, the detector deactivates.
The detector is shipped with the Due-lock
option disabled.
Latched Alarms
If enabled, the Latch (latched alarms)
option causes the low and high gas alarms
(audible, visual, and vibrator) to persist
until they are acknowledged. Press C to
acknowledge the alarm.
After the alarm is acknowledged, it reactivates every 30 seconds until the gas
concentration is below the setpoint.
The detector is shipped with the Latch
option disabled.
22
Passcode Protect Safe Display
The Passcode option prevents unauthorized
access to the user options menu, the calibration function, and to adjusting the alarm
setpoints.
www.GlobalTestSupply.com
The passcode is provided separate ly.
If passcode protect is enabled and the Enter
passcode: 1000 screen displays, press G or
H to scroll to the correct passcode and then
press C to confirm.
The detector is shipped with the Passcode
option disabled.
If an incorrect passcode is entered or C is not
pressed within 5 seconds to confirm the correct
passcode, Passcode incorrect displays. The
alarm beeps three times and the detector
either
• resumes normal operation
or user options), or
(f
• deactivates
(for calibration if Due Lock is enabled).
Note
When enabled, the Safe option confirms that
conditions are normal and there are no gas
hazards present. When all gas levels are
normal or below the alarm setpoints, Safe
displays continually on the LCD.
The detector is shipped with the Safe option
disabled.
GasAlertMicro 5/PID/IR
User Options Menu
23
GasAlertMicro 5/PID/IR
User Manual
Sensor Configuration
The Sensor option provides access to additional options and functions
for each sensor.
Depending upon the sensor that is selected, some or all of the following
options are available for configuration:
• Enabling/disabling a sensor
www.GlobalTestSupply.com
• Setting the span gas value
• Adjusting the STEL period (not applicable to LEL and O
• Selecting the TWA method (not applicable to LEL and O
• Resolution setting (not applicable to CO, LEL, O
2
sensors)
•% vol CO
•% vol CH
(CO2 sensor only)
2
(LEL sensor only)
4
• Selecting the correction factor (LEL and PID sensors only)
• Automatic calibration (O
sensor only)
2
2
2
, and CO
sensors)
sensors)
1. From the option menu screen, scroll to Sensors and press
C to access the following screen.
2. Press G or H to scroll to the desired sensor. Press C to con-
2
firm and to access the menu options specific to the select
sor.
sen
For all sensor options, if a value is changed but no
con
firmed within 5 seconds, the detector emit
s an
ed
t
audible alarm and displays the following error message.
The detector retains the previous setting and returns to the
user options menu.
24
GasAlertMicro 5/PID/IR
User Options Menu
Sensor Enable/Disable
a Warning
Disabling a sensor should only be performed with
extreme caution. The disabled sensor cannot measure
and alarm against the applicable gas.
If a sensor fails, disabling the sensor deactivates the fail alarm. The
www.GlobalTestSupply.com
sensor should be replaced and enabled as soon as possible. The
detector will function normally with the remaining enabled sensors.
Note
Detectors that are configured for a 1, 2, 3, or 4 gases may contain a dummy sensor in one of the four sensor locations.
After selecting the desired sensor, the following screen displays.
Press C to toggle between enable/disable (sensor can be enabled at
any time).
Enabled
Disabled
If disabled, the readings and the gas type for the sensor do not display
when in normal operation.
If a sensor is enabled but it is not installed in the detector, FAIL flashes
above the gas type of the missing sensor.
Disabled Enabled/not installed
If all the sensors are disabled, the following screens display.
Enable one or more sensors to exit and access normal operation.
25
GasAlertMicro 5/PID/IR
User Manual Span Gas Value STEL Period
The Span gas option increases or
decreases the gas concentration for
calibration (must match the gas
concentration listed on the gas cylinder).
www.GlobalTestSupply.com
After selecting the sensor, press H to
scroll to Span gas and press C within
20 seconds to confirm.
Depending upon the sensor selected, a
screen similar to A or B displays. Press
G or H to scroll to the desired value and
press C within 5 seconds to confirm.
If C is not pressed within 5 seconds to
confirm the new value, the detector
retains the previous value and returns to
the user options menu.
Note
BW recommends that span concentration
values be set between specific ranges.
Refer to the Resetting Gas Alarm
Setpoints.
The short-term exposure limit (STEL period) option provides
protection for workers from over exposure to high concentrations
of gas, and is based on 5-15 minute intervals.
The STEL period option is available for
every toxic sensor.
After selecting the desired sensor, press
A
B
H to scroll to STEL period and press C
within 20 seconds to confirm.
The STEL period can be set from 5 to
15 minutes. Press G or H to scroll to the
required value, and then press C within
5 seconds to confirm.
If C is not pressed within 5 seconds to
confirm the new value, the detector
retains the previous value and returns to
the user options menu.
The detector is shipped with the STEL
period set to 15 minutes.
26
GasAlertMicro 5/PID/IR
User Options Menu
TWA Method
The TWA method (time-weighted average)
option is a safety measure used to calculate
accumulated averages of gases to notify the
user when the maximum average is
accumulated. The options are the OSHA or
www.GlobalTestSupply.com
ACGIH calculating method.
OSHA Method: 8 hour moving average – oldest value (first hour) is
replaced by the newest value (ninth hour).
ACGIH Method: Infinite accumulated average to 8 hours – total
accumulation, whether it is 2 hours or 8 hours.
After selecting the desired sensor, press H to scroll to TWA method.
Press C within 20 seconds to confirm.
A check displays in the checkbox of the
currently selected method. To select the
other method, press H to move the check
to the other method. Press C to confirm the
selection.
The detector is shipped with the OSHA
method enabled.
Note
If the TWA method has been changed, the TWA, STEL, and
MAX values must be reset to ensure the TWA is calculated
correctly. Refer to Clearing Gas Exposures
.
Resolution
The Resolution option displays the gas
measurement using Regular or Extra
resolution.
Regular: Displays gas measurement in
1 ppm increments.
Extra: Displays the gas measurement in
0.1 ppm increments.
Note
Regular resolution for O
extra resolution is 0.01 ppm.
The Resolution option is not available for CO, O
and CO
After selecting the desired sensor, press H to scroll to Resolution.
Press C within 20 seconds to confirm.
A check displays in the checkbox of the
currently selected resolution. To select th e
other resolution, press H to move the
check to other resolution. Press C to
confirm the selection.
The detector is shipped with Regular
resolution enabled for applicable sensors.
sensors.
2
and ClO2 sensors is 0.1 ppm, while
3
, LEL, PID,
2
27
GasAlertMicro 5/PID/IR
User Manual
%Vol CO2 (CO2 Sensors Only)
If the %vol CO
displays the carbon dioxide (CO
readings as %vol (0.0).
From the Sensors option menu, select
www.GlobalTestSupply.com
CO
.
2
Press H to scroll to %vol CO
to toggle between enable and disable.
Confirmation is not required. If no bu ttons
are pushed, after 20 seconds the detector
returns to the sensor selection screen.
The change is saved automatically.
The detector is shipped with %vol CO
disabled.
Correction factors are not applicable to the CO
is enabled, the detector
2
2
)
2
. Press C
2
Note
Enable
Disable
sensor.
2
%Vol CH4 (LEL Sensors Only)
If %vol CH4 is enabled, any currently
enabled correction factor is ignored and
the detector operates assuming a
methane (CH
) calibration.
4
From the Sensors menu, select LEL and
press C to confirm.
Next, press H to scroll to %vol CH
and
4
press C within 20 seconds to confirm.
Press C to toggle between enable and
disable.
Confirmation is not required. If no buttons
are pushed within 20 seconds, the
detector returns to the sensor selection
screen. The change is saved
automatically.
The detector is shipped with %vol CH
4
Enable
Disable
disabled.
Correction Factor (CF)
Depending upon the selected sensor, refer to the following sections
LEL Sensor
or PID Sensor for more information.
Note
Corrections factors are not applicable to CO
sensors.
2
28
GasAlertMicro 5/PID/IR
User Options Menu
LEL Sensor
This option is used to enter compensation
factors for hydrocarbons other than
methane. The factor can only be applied if
the LEL sensor has been calibrated with
methane.
www.GlobalTestSupply.com
After selecting the LEL sensor, press H
to scroll to Correction. Press C within
20 seconds to confirm and access the LEL
correction library.
Scroll to the required gas type and
press C. A check displays in the
corresponding checkbox. The detector
automatically applies the correction factor.
To disable the Correction option, press H
to scroll to None or to Methane. A check
displays in the corresponding checkbox. If
required, select a differen t g as ty p e
correction factor.
Custom: To enter a correction factor that
is not listed in the library, press H to scroll
to Custom and press C within 5 seconds
to confirm.
The Custom LEL correction screen displays. Press G or H to select the
required value, and press C with in 5 seco n ds to confir m .
PID Sensor
This option is used to enter compensation
factors for selected gas types. The factor
can only be applied if the PID sensor has
been calibrated with isobutylene.
After selecting the PID sensor, press H
to scroll to Correction. Press C within
20 seconds to confirm and access the
PID correction library.
Scroll to the required gas type and
press C. A check displays in the
corresponding checkbox. The detector
automatically applies the correction factor.
To disable the Correction option,
press H to scroll to None or to Isobutyl.
A check displays. If required, select a
different gas type correction factor.
Custom: To enter a correction factor for
a custom PID sensor, scroll to Custom
and press C. Press G or H to scroll to
the required value, and press C within
5 seconds to confirm. Refer to the PID
Correction Factor PID Correction Factor
(CF) Library Library for gas types and
corresponding correction factor values.
29
GasAlertMicro 5/PID/IR
User Manual Automatic Oxygen (O2) Calibration Logger Option
When the Autocal option is enabled, it
forces the detector to automatically
calibrate the oxygen sensor during
startup.
www.GlobalTestSupply.com
If the Autocal option is enabled, ensure
the detector is activated in a safe area
that is free of hazardous gas in an
atmosphere of 20.9% oxygen.
From the Sensor menu, press H to scroll
to O
and press C within 20 seconds to
2
confirm.
Press H to scroll to Autocal. Press C
to toggle between enable/disable.
The detector is shipped with the Autocal
option enabled.
The Logger option is used to define how often the detector records a
datalog sample (once every 1 to 127 seconds).
From the user options menu, press H to scroll to Logger. Press C
within 20 seconds to confirm.
Press G or H to change the current logger rate. When the desired
value displays, press C within 5 seconds to confirm the new value.
30
GasAlertMicro 5/PID/IR
User Options Menu
If C is not pressed within 5 seconds, the following screen displays.
www.GlobalTestSupply.com
The detector is shipped with the datalog sample time set to 5 seconds.
Clock Option
The Clock option is used to change the date and time.
From the user options menu, press H to scroll to Clock. Press C
within 20 seconds to confirm.
The screen displays showing the month highlighted indicating it is
selected to set.
Press G or H to scroll to the desired month and press C within
20 seconds to confirm. To bypass and retain the current setting, press
C. Continue setting/bypassing the remaining options.
The date/time options are set in the following order:
•month
•day
•year
•hour
• minutes
When the settings have been set or bypassed, the detector beeps twice
and returns to the user options menu.
Note
The detector is shipped with the date and time set to Moun t ai n
Standard Time (MST).
31
GasAlertMicro 5/PID/IR
User Manual
Language Selection
The detector is shipped with English selected as the default language.
The available languages are as follows:
• Français (French)
• Deutsch (German)
www.GlobalTestSupply.com
• Español (Spanish)
• Prtuguês (Portuguese)
Press H to scroll to Language and press C within 20 seconds to
confirm.
Press G or H to scroll to the desired language and press C. A check
displays in the checkbox of the selected language.
Wait for 20 seconds until the detect or returns to the user options menu,
or press G to scroll to Back (English), Retour (French), Zurück
(German), Regreso (Spanish), or Retornar (Portuguese).
All screens now display in the selected language.
Tech Mode
a Warning
Tech mode should only be accessed by authorized
personnel.
Tech mode can only be accessed from the Language option. Press H
to scroll to Language. Do not press C until instructed.
32
GasAlertMicro 5/PID/IR
User Options Menu
In the following order, press and continue to hold each button until
Tech mode displays below the Language option.
1. Press and hold H with the right index finger.
2. Press and hold G with the right middle finger.
3. Press and hold C with the left thumb.
www.GlobalTestSupply.com
4. Press C to enter Tech mode. The options are as
follows:
• Sensors
• Initialize
• Force Calibration (Force calibration)
• Bump Daily
• Stealth Mode
• Sleep Mode
(Bump test daily)
Sensors
a Caution
To reconfigure the sensor type, physically change the
sensor prior to entering Tech mode.
When a toxic sensor is physically removed and replaced by anot her toxic
sensor, the detector must be reconfigured to recognize the change.
Note
If a sensor is replaced, the detector will classify the sensor as
overdue for calibration. Calibrate the new sensor immediately.
1. Press H to scroll to Sensors. Press
C within 20 seconds to confirm and
access the toxic sensor menu.
2. Press G or H to scroll to Toxic 1
or Toxic 2 and press C within
20 seconds to confirm.
33
GasAlertMicro 5/PID/IR
User Manual
A corresponding list of toxic sensors
displays. A checkbox displays beside
the current toxic sensor.
Note
Toxic 1: List includes the PID and CO
sensors.
www.GlobalTestSupply.com
Toxic 2: List includes the H
sensor.
3. Press G or H to scroll to the new
sensor and press C to confirm. A
checkbox displays beside the n
nsor. To reconfigure, exit the us
se
tions menu.
op
The following screen displays.
de
tector deactivates and immediate
reactivates. It performs the
reconfiguration during the startup.
The new sensor must be calibrated
il the new sensor is calibrated, t
Unt
du
e date displays as OL (over limit)
when in normal operation.
4. Calibrate the new sensor
immediately.
2
2
S/CO COSH
ew
er
The
he
Initialize
The Initialize option restores the original factory default settings of the dete ctor.
1. Press H to scroll to Initialize an
pres
s C within 20 seconds to
confirm.
2. From the Initialize? scree
pe
rform one of the following options
within 5 seconds.
• Press A No to exit, or
• Press C Yes to initialize.
ly
If No is selected, the following screen
.
displays and the detector exits t he initia lize option.
d
n
34
GasAlertMicro 5/PID/IR
User Options Menu
If Yes is selected, the following screen
displays while performing the initializing
process.
www.GlobalTestSupply.com
When initializing is complete, the
following screen displays.
The detector deactivates and then
immediately reactivates. The detector
then reconfigures to the default settings
while it performs the self-test.
Verify all settings and alarm setpoints,
and then calibrate the sensors.
Force Calibration
If enabled, the Force cal option
automatically forces the detector to enter
calibration if a sensor is overdue upon
startup. Press H to scroll to Force cal.
Press C to toggle between enable and
disable.
Bump Daily
If enabled, the Bmp daily option forces the
detector to perform a daily bump test to
ensure that it is responding to the test gas.
Press H to scroll to Bmp daily. Press C
to toggle between enable/disable.
When enabled, the following screen
displays during the startup self-test.
The bump test must be performed for the
LEL and O
detector will deactivate. Refer to Bump
Daily Enabled for procedures.
The detector is shipped with the Bmp
daily option disabled.
If Bmp daily is enabled, the O
bump tests whenever the detector is activated (or reactivated)
following 00:00 hours (midnight).
sensors, otherwise the
2
Note
and LEL sensors require daily
2
The detector is shipped with the Force cal option disabled.
35
GasAlertMicro 5/PID/IR
User Manual
Stealth Mode
The Stealth option disables the backlight,
visual alarms, and audible alarms when
concealment is required.
Only the vibrator and the LCD activate
www.GlobalTestSupply.com
during an alarm condition.
Press H to scroll to Stealth. Press C to
toggle between enable and disable.
The detector is shipped with the Stealth option disabled.
Sleep Mode
Note
BW recommends the Sleep option be enabled when using
rechargeable battery packs.
If Sleep is enabled, sensor circuits remain
active after the detector is deactivated and
inserted into the charging cradle.
Press H to scroll to Sleep. Press C to
toggle between enable/disable.
Note
Enabling the Sleep option may
require the battery be charged more
frequently.
The detector is shipped with the Sleep
option disabled.
36
Alarms
The following table describes the detector alarms and corresponding screens.
• During an alarm condition, the detector activates the backlight and displays the current ambient gas readi ng.
• If more than one type or level of alarm exists simultaneously, a multi alarm results.
• To change the factory-set alarm setpoints, refer to Calibration and Setting Alarm Setpoints
www.GlobalTestSupply.com
Table 7. Alarms
Alarms Screen` Alarms Screen
.
GasAlertMicro 5/PID/IR
Alarms
Low Alarm
• Fast beep
•Slow flash
•
L and gas type flash
• Vibrator alarm activates
High Alarm
• Constant beep
• Fast flash
•
L and gas type flash
• Vibrator alarm activates
TWA Alarm
• Fast beep
•Slow flash
• L and gas type flash
• Vibrator alarm activates
STEL Alarm
• Constant beep
• Fast flash
• L and gas type flash
• Vibrator alarm activates
37
GasAlertMicro 5/PID/IR
User Manual
Alarms Screen Alarms Screen
Table 7. Alarms
Multi Alarm
www.GlobalTestSupply.com
• Alternating low and high alar
beep
and flash
•
L and gas types flash
• Vibrator alarm activates
Sensor Alarm
• One beep every 15 seconds
• FAIL flashes above the failed
or
sens
Low Battery Alarm
• One beep and two flashes
every 25 sec
• flash
onds
es
m
Over Limit (OL) Exposure
Alarm
• Fast beep and flash
L and gas type flash
•
• Vibrator alarm activates
Automatic Deactivation Alarm
• Eight beeps and flashes
• displays
• Vibrator alarm temporar
act
ivates
Normal
Deactivation
• Three beeps and flashes
ily
38
GasAlertMicro 5/PID/IR
Table 7. Alarms
Alarms Screen Alarms Screen
Alarms
Confidence Beep
www.GlobalTestSupply.com
• One beep, one flash, and one
vibrate every 10 seconds
MMC/SD Fail Alarm
• One beep every 5 seconds
• S flashes
Alarms Screen
Pump Alarm
• Two fast beeps and alternating flashes
• Vibrator alarm activates
•
L and J flash
Note
If the Latch (latched alarms) option is activated, the audible, visual, and vibrator alarms persist until the alarm condition is acknowledged.
To acknowledge a latched alarm, press C. The alarms cannot be deactivated if an alarm condition exists.
If the Stealth option is enabled, the detector only vibrates during an alarm; the audible and visual alarms are disabled.
a Caution: If the detector emits a low battery alarm, charge the lithium battery pack immediately.
39
GasAlertMicro 5/PID/IR
User Manual
Gas Exposures Computed
a Warning
To avoid possible personal injury, do not deactivate
the detector during a work shift. TW A and STEL readings
reset if the detector is deactivated for more than
www.GlobalTestSupply.com
5 minutes.
Table 8. Computed Gas Exposures
Gas Exposure Description
Time-weighted average
(TWA) based on accumulated
TWA (toxic only)
STEL (toxic only)
*Peak (MAX)
exposure to toxic gases averaged over a work day according to OSHA or ACGIH
method.
Short-term exposure limit
(STEL) to gas based on a
5-15 minute user selectabl
period.
Peak (MAX) concentration
exposure during work shift.
*For oxygen, it is the highest or the lowest concentration
countered.
en
Viewing Gas Exposures
Press and hold C until the
peak (MAX) gas exposures
displays.
The TWA gas exposures
display next.
e
The STEL gas exposures
display last.
40
GasAlertMicro 5/PID/IR
Alarms
Clearing Gas Exposures
The exposures automatically clear after 5 minutes when the detector
is deactivated.
To clear the MAX, TWA, and STEL exposure readings immediately,
press and hold C and G simultaneously. The detector displays the
following screen during the countdown.
www.GlobalTestSupply.com
Note
Hold C and G for the entire countdown, otherwise the MAX,
TWA, and STEL exposure readings will not clear.
Gas Alarm Setpoints
The gas alarm setpoints trigger the gas alarms and are described in
.
Table 9.
Table 9. Gas Alarm Setpoints
Alarm Condition
Low alarm Toxics and combustibles: Ambient
gas level above low alarm setpoint.
Oxygen: Ambient gas level may be
set above or below 20.9%.
High alarm Toxics and combustibles: Ambient
gas level above high alarm setpoint.
Oxygen: Ambient gas level may be
set above or below 20.9%.
TWA alarm Toxic only: Accumulated value above
the TWA alarm setpoint.
STEL alarm Toxic only: Accumulated val ue above
the STEL alarm setpoint.
Downscale alarm Toxic: If sensor reading is negative
(half of the TWA setpoint).
LEL: If sensor reading is negative
(half of the low alarm setpoint).
Multi alarm Two or more gas alarm conditions.
Viewing the Alarm Setpoints
To view the current alarm setpoints for all of the sensors, press G
during normal operation.
41
GasAlertMicro 5/PID/IR
User Manual
The time/date, TWA, STEL, l ow , and high alarm setp oint screens displ ay
in the following order left to right:.
www.GlobalTestSupply.com
If a correction factor has been applied to a sensor, one of the following
screens display indicating the sensor and gas type.
Resetting Gas Alarm Setpoints
Note
Standard factory alarm setpoints may vary by region.
The following table lists the factory alarm setpoints according to the
Occupational Safety and Health Association (OSHA) settings.
Table 10. OSHA Sample Factory Alarm Setpoints
Gas TWA STEL Low High
O
2
LEL N/A N/A 10% LEL 20% LEL
CO 35 ppm 50 ppm 35 ppm 200 ppm
H
2
PH
SO
Cl
2
NH
NO
HCN 4.7 ppm 10.0 ppm 4.7 ppm 10.0 ppm
ClO
O
3
VOC 50 ppm 100 ppm 50 ppm 100 ppm
CO
N/A N/A 19.5% vol. 23.5% vol.
S
10 ppm 15 ppm 10 ppm 15 ppm
0.3 ppm 1.0 ppm 0.3 ppm 1.0 ppm
3
2 ppm 5 ppm 2 ppm 5 ppm
2
0.5 ppm 1.0 ppm 0.5 ppm 1.0 ppm
25 ppm 35 ppm 25 ppm 50 ppm
3
2.0 ppm 5.0 ppm 2.0 ppm 5.0 ppm
2
0.1 ppm 0.3 ppm 0.1 ppm 0.3 ppm
2
0.1 ppm 0.1 ppm 0.1 ppm 0.1 ppm
5,000
2
ppm
30,000
ppm
5,000
ppm
30,000
ppm
42
GasAlertMicro 5/PID/IR
Alarms
To change the factory-set alarm setpoints, refer to Calibration and Set-
ting Alarm Setpoints.
Note
To disable an alarm, set the alarm setpoint to 0 (zero).
Stopping a Gas Alarm
www.GlobalTestSupply.com
The low and high alarms stop when the ambient gas level returns to
below the low alarm setpoint.
Note
If alarms are set to latch, press C to reset the alarms.
a Caution
Follow all safety procedures as define d by your
employer. Confirm with your supervisor before clearing
TWA and STEL alarms.
The TWA and STEL alarms can be stopped either by
• clearing the MAX, TWA, and STEL exposures (refer to
Gas Exposures), or
• deactivating the detector for 5 minutes (minimum) and then
reactivating it again.
Clearing
Sensor Alarm
The detector tests for missing or defective sensors during the activation
self-test. If a sensor fails the self-test, FAIL flashes on the LCD above
the failed sensor. Refer to Troubleshooting
.
Pump Alarm
The external pump draws air over the sensors continually. If the pump
stops operating or becomes blocked, the detector activates the pump
alarm. The following screens display.
The pump alarm continues until the blockage is cleared or it is
acknowledged by pressing C. If C is pressed, the detector automati cally launches a pump test to reset the pump module.
43
GasAlertMicro 5/PID/IR
User Manual
Refer to Pump Test for more information. If the pump test is successful,
the detector returns to normal operation, otherwise the pump alarm continues. If the pump alarm persists, refer to the Pump Operatio n section in
Troubleshooting
.
Low Battery Alarm
www.GlobalTestSupply.com
The detector tests the batteries upon activation and continuously
thereafter. Battery power is continually displayed during normal
operation. If the battery voltage is low, the detector activates the
low battery alarm.
The low battery alarm continues until the batteries are replaced/c harged,
or until the battery power is almost depleted. If the battery voltage
becomes too low, the detector deactivates.
Note
Typ ically, the low battery alarm continues for 30 minutes before
the detector automatically deactivates.
Automatic Deactivation Alarm
If the battery voltage is in immediate danger of falling below the minimum
operating voltage, the audible alarm beeps eight times and the visual
alarm flashes eight times. After 3 seconds, the LCD dims and the
detector deactivates.
To replace or charge the batteries, refer to the following sections:
• Replacing the Alkaline Batteries
• Replacing the Lithium Battery Pack
Calibration and Setting Alarm Setpoints
Guidelines
When calibrating the detector, adhere to the following guidelines:
Recommended gas mixture:
CO: 50 to 500 ppm balance N
H
S: 10 to 100 ppm balance N
2
PH3: 1 to 5 ppm balance N
SO2: 10 to 50 ppm balance N
Cl2: 3 to 25 ppm balance N
NH3: 20 to 100 ppm balance N
NO2: 5 to 50 ppm balance N
HCN: 5 to 20 ppm balance N
ClO2: 0.1 to 1.0 ppm balance N
O3: 0.1 to 1.0 ppm balance N
VOC:100 ppm isobutylene
LEL: 50% LEL or 2.5% by vol. methane balance air
: 5000 ppm balance air
CO
2
O
: 18.0%
2
• To ensure accurate calibration, use a premium-grade calibration
gas. Gases approved by the National Institute of Stand
T
echnology (NIST) improves the validity of the calibration.
• Do not use a gas cylinder beyond its expiration date.
2
2
2
2
2
2
2
2
2
2
ards and
44
GasAlertMicro 5/PID/IR
Calibration and Setting Alarm Setpoints
• Calibrate a new sensor before use. Install the sensor, activate
the detector, and allow the sensor to stabilize before starting
calibration.
Used sensor: 60 seconds / New sensor: 5 minutes
• Calibrate the detect or at least once every 180 days (every 90 days
for HCN sensors) depending upon use and sensor exposure to
isons and contaminants. For a list of common pro ducts that can
www.GlobalTestSupply.com
po
damage sensors, refer to Sensor Poisons and Contaminants
• Calibrate the detector if the ambient gas varies during startup.
• Calibrate the sens or before changing the alarm setpoints.
• Calibrate only in a safe area that is free of hazardous gas i
at
mosphere of 20.9% oxygen.
• To disable an alarm, set the alarm setpoint to 0 (zero).
• If the Auto cal option i s enabled, the oxygen (O
automatically every time the detector is activated. Activate the
detector in a safe area that is free of hazardous ga
at
mosphere of 20.9% oxygen.
• After acti vating t he detecto r, allow it to stabilize for 1 minute bef
pe
rforming a calibration or bump test.
• If a certified calibration is required, contact BW Technologi
Honeywell.
Note
A generator must be used for O
and ClO2 sensors.
3
) sensor calibrates
2
s in an
.
n an
es by
Diagnostics Testing
The detector tests the ambient air (auto zero) and the test gas that is
applied (auto span) to ensure it meets expected values. Auto zero sets
the zero-gas level of the sensor. If ambient gas is present, the zero
level will be incorrect.
If excessive target gas is present, the detector displays an error
message and lists the affected sensor.
In auto span, if the target gas is not d ete cted or does no t mee t exp ected
values, a message displays that the detector is exiting calibrat io n mode.
The detector retains the previous set values.
ore
45
GasAlertMicro 5/PID/IR
User Manual
Applying Gas to the Sensors
The calibration cap, single gas calibration cap, and hose are shipped
with the detector. Refer to Figure 3.
The calibration cap and single gas calibration cap must only be
www.GlobalTestSupply.com
used during the calibration span process.
Figure 3. Applying Gas to the Sensors
and Table 11. for installation.
Note
Table 11. Applying Gas to the Sensors
Item Description
1
2
3
4
5
Detector with calibration cap
Calibration hose
Regulator and gas cylinder
Toxic 2 sensor position
Single gas calibration cap
Single Gas Calibration Cap
a Caution
If an O3 or ClO2 sensor is located in the Toxic 2 position
(refer to Figure 3.
cap must be used to ensure accurate calibration.
To calibrate O
refer to Figure 4.
1. Insert the cap int o the Toxic 2 sensor position on the de tect
2. Connect the cal ibration hose to the gas cylinder and to t
3. Proceed to Calibration Procedure
and ClO2 sensors using the single gas calibration cap,
3
(refer to Fi
ntake inlet on the cap.
i
and Table 11.), a single gas calibration
, Table 12., and complete the following procedures.
gure 3.
). Press firmly until the release tabs click.
.
or
he
46
GasAlertMicro 5/PID/IR
Calibration and Setting Alarm Setpoints
Table 12. Single Gas Calibration Cap
Item Description
1
2
3
www.GlobalTestSupply.com
4
Intake inlet
Calibration hose
Gas flow direction arrow
Output outlet
Removing the Single Gas Calibration Cap
Using the thumb, push forward against both the inlet and the outlet
simultaneously to remove the cap from the detector.
Figure 5. Removing the Single Gas Calibration Cap
Calibration Procedure
Figure 4. Single Gas Calibration Cap
Note
The arrow on the cap indicates the direction of gas flow from
intake to outtake.
To calibrate the detector and set the alarm setpoints, perform the
following procedure.
Note
To bypass a step during the calibration process (after auto
zero), press A.
47
GasAlertMicro 5/PID/IR
User Manual
Start Calibration
Note
Verify that the calibration gas being used matches the span
concentration value(s) that are set for the detector. Refer to
Span Gas Value
www.GlobalTestSupply.com
bration. Correction factors that were set prior to calibration are
restored when the detector returns to normal operation.
. Correction factors are not applied during cali-
a Caution
Calibrate only in a safe area that is free of hazardous gas
in an atmosphere of 20.9% oxygen.
1. To enter calibration, press and hold C and H simultane-
ously as the detector beeps, flashes, and vibrates to the
corresponding countdown.
Auto Zero and Oxygen (O2) Sensor Calibration
2. flashes while the detector automatically zeroes the
toxic and combustible sensors, and calibrates the O
Depending upon the detector being calibrated, the auto zero
screens display differently.
sensor.
2
GasAlertMicro 5/PID GasAlertMicro 5 IR
Note
Do not apply calibration gas during this p rocess, otherwise the
auto zero step will fail.
Zero CO2 (GasAlertMicro 5 IR only)
If calibrating using the GasAlertMicro 5 or the GasAlertMicro PID, proceed to Auto Span
ceed to Passcode Protect
3. For GasAlertMi cro 5 IR models, there is a second aut
hat is performed for the CO
t
Wh
scree
step #5. If the detector is passcode protected, pro-
step #4.
o zero
sensor.
2
en auto zero for the other sensors is comple te, the followin
n displays.
g
48
GasAlertMicro 5/PID/IR
Calibration and Setting Alarm Setpoints
Press C Yes to zero the CO2 sensor.
Or
Press A No to bypass the CO
step #5. If the detector is passcode protected, refer to Pass-
code Protect Activated step #4.
www.GlobalTestSupply.com
If C Yes is pressed, the following screen displays.
zero and proceed to Auto Sp an
2
a Warning
Use nitrogen (N2) to zero the CO2 sensor.
Apply N
displays.
to zero the CO2 sensor. The following screen
2
sensor (approximately 30 seconds).
Passcode Protect Activated
4. When auto zero is c omplete and if the p assco de pro tect option
is enabled, the following screen displays.
The passcode must be entered to proceed.
Press G or H to scroll to the correct passcode and then press
C within 5 seconds to confirm. If entered correctly, the detector beeps twice and proceeds to Auto Span
Incorrect Passcode: If the passcode is incorrect or is not confirmed
within 5 seconds by pressing C, the following screens display.
flashes whiles the detector zeros the CO
step #5.
2
The detector saves the calibration and returns to normal operation.
49
GasAlertMicro 5/PID/IR
User Manual
Auto Span
5. When auto zero is complete, the following screens display.
GasAlertMicro 5 and PID
www.GlobalTestSupply.com
GasAlertMicro 5 IR
.Note
Span sensors in the following order:
• Exotics (NH
• Single gas
• Quad gas (H
•PID
, ClO2, O3, Cl2, and CO2)
3
S, CO, LEL, and O2)
2
Note
A generator must be used for O
and ClO2 sensors.
3
To ensure accurate calibration, a single gas calibration cap
must be used to calibrate O
• ClO
: Use a Tedlar bag as a buffer between the generator
2
and ClO2 sensors.
3
and the detector (using the single gas calibration cap) to
regulate the flow rate to ensure accurate readings.
• Allow the Tedlar bag to fill for several minutes before
initiating calibration.
• O
: Calibrate using the generator and the single gas
3
calibration cap. Do not use a Tedlar bag.
• Set the generator to 0.5 ppm at a flow rate of 0.5 l/min.
Depending upon the gas cylinder being used, one or all four sensors
can be calibrated at one time.
Apply Span Gas Now
Attach the calibration cap (or single gas calibration cap fo r O
and ClO
to Figure 3.
) and apply gas to the sensor(s). To attach caps, refer
2
.
Refer to the following flow rates:
• 1000 ml/min. for NH
• 500 ml/min. for CO
and Cl
3
2
2
• 250-500 ml/min. (all other sensors)
3
50
GasAlertMicro 5/PID/IR
Calibration and Setting Alarm Setpoints
K flashes as the detector initially detects the calibration gas.
GasAlertMicro 5 and PID GasAlertMicro 5 IR
While the detector is spanning the sensor(s), a countdown of
time remaining displays in the lower left of the screen.
GasAlertMicro 5 and PID GasAlertMicro 5 IR
www.GlobalTestSupply.com
After 30 seconds the detector beeps and K stops flashing.
flashes while spanning the sensors until the detec tor
has attained a sufficient l evel of the expected gas.
Refer to Table 13.
for times required to span.
When the span is complete, the following screen
displays.
Table 13. Time Required to Span
Gas Type Time Required to Span
Most toxic gases and CO
Exotic toxic gases 5 minutes
LEL (combustibles) 30 seconds
PID gases 2 minutes
2
2 minutes
Successful Span: Proceed to Successful Span
step #6.
Unsuccessful Span: Refer to Unsuccessful Span for possible solutions.
Insufficient Level: If a sensor does not attain a sufficient level
of expected gas, it is cleared from the L CD and i s n ot spanned.
51
GasAlertMicro 5/PID/IR
User Manual
Successful Span
6. If the sensor(s) has spanned successfully, the audible alarm
beeps three times and the following screens display.
www.GlobalTestSupply.com
If there are more sensors to span, remove the current cylinder
and connect the next gas cylinder.
Press G and apply gas to span the other sensor(s).
Or
Press H to end the span and proceed to Setting the Calibra-
tion Due Date step #7.
When all sensors have spanned, the following screen displays.
If a sensor fails to span, refer to Unsuccessful Span at the end of the
calibration section for possible solutions.
52
Setting the Calibration Due Date
7. When the sp an is complete, th e calibration due date can be set
for each sensor that has spanned successfully. The following
screen displays.
Press C to set the calibration due dates.
Or
Press A to bypass and proceed to Alarm Setpoints
Note
If a new due date is not entered, the detector automatically
resets to the previously entered number of days.
step #8.
GasAlertMicro 5/PID/IR
Calibration and Setting Alarm Setpoints
The calibration due dates are set in the following order:
•Toxic 1
•Toxic 2
•LEL
•O
www.GlobalTestSupply.com
2
If the due date of an unsuccessfully spanned sensor is
changed, the following screens display.
The detector then automatically proceeds to the next sensor.
To change the calibration due date (1-365 days), press H or
G until the new value displays. Press C within 5 seconds to
confirm.
Or
Press A to bypass a sensor and proceed to the next sensor.
If a value is changed but C is not pressed within 5 seconds to
confirm, the following screen displays.
The previous value is automatically retained. The detector
proceeds to the next sensor due date.
Repeat step #7 to set the calibration due dates for the remaining sensors.
When all of the due dates are entered, press C to proceed to
Alarm Setpoints
Or
Press A to bypass setting the alarm setpoints and proceed to
Finish Calibration
step #8.
step #10.
Note
53
GasAlertMicro 5/PID/IR
User Manual
Alarm Setpoints
8. When all of the sensor due dates have been set or bypassed,
the alarm setpoints need to be set or bypassed. The following
screen displays.
www.GlobalTestSupply.com
Factory alarm setpoints may vary by region. Refer to Resetting
Gas Alarm Setpoints for an example.
Alarms can be set to any value within the detection range of
the selected sensor. Refer to “Detection Range” in Specifica-
tions.
Note
To disable an alarm setpoint, set it to 0 (zero).
If a new setpoint is entered but not confirmed within 5 seconds
by pressing C, the following screen displays.
The previous setpoint is retained and the detector
proceeds to the next setpoint.
The setpoints are set in the following order:
• TWA (if applicable)
• STEL (if applicable)
•low
•high
To bypass a setpoint, press C to save the current value and
proceed to the next setpoint.
54
GasAlertMicro 5/PID/IR
Calibration and Setting Alarm Setpoints
Setting the TWA Alarm Setpoint
The current TWA alarm setpoint displays for the selected sensor
(if applicable).
www.GlobalTestSupply.com
Press H or G to change the value for the TWA alarm setpoint. When
the required value displays, press C to confirm.
Setting the STEL Alarm Setpoint
The current STEL alarm setpoint displays for the selected sensor
(if applicable).
Press H or G to change the value for the STEL alarm setpoint. When
the required value displays, press C to confirm.
Setting the Low Alarm Setpoint
The current low alarm setpoint displays for the selected sensor.
Press H or G to change the value for the low alarm setpoint. When the
required value displays, press C to confirm.
Setting the High Alarm Setpoi nt
The current high alarm setpoint displays for the selected sensor.
Press H or G to change the value f or the high alarm se tpoint. When t he
required value displays, press C to confirm.
Proceed to step #9 Setting the Remaining Alarm Setpoints
.
55
GasAlertMicro 5/PID/IR
User Manual
Setting the Remaining Alarm Setpoints
9. Repeat step #8 to set the alarm setpoints for the remaining
sensors. When complete, the detector emits two quick beeps
and proceeds to Finish Calibration
.
Finish Calibration
10. The detector displays the following screen to indicate that
www.GlobalTestSupply.com
calibration is complete.
Verification
1. Aft er calibration is complete and the detector returns
to normal operation, verify the calibration by using a
gas cylinder other than the one used for calibration.
2. The gas concentration should not exceed the sensor's detection range. Confirm that the LCD displays the expected concentration values.
3. To ensure t he reading is accurate, apply the verificat ion gas for
the same amount of time as was applied to the sensor when it
was calibrated.
Example: SO
verification gas for 2 minutes.
span time 2 minutes therefore, apply
2
56
GasAlertMicro 5/PID/IR
Calibration and Setting Alarm Setpoints
Unsuccessful Span
If the sensor(s) did not span successfully, refer to the following sections
for possible solutions:
• Failed Span
• No Gas Detected
www.GlobalTestSupply.com
• Did Not Reach Target Span
• Large Span
Failed Span
If a sensor fails the span, the following error message displ ays.
If the sensor is not calibrated, it displays as FAIL in normal operation the
next time the detector is activated.
If all sensors fail the span, the following sc reen displays.
1. Ensure the regulator valve is open and that the gas cylinder
is not past the expiration date. Replace the gas cylinder and/
or regulator if required.
2. Replace the sensor(s) and sensor filter if required.
3. Press A to exit and then calibrate again in a safe area that
is free of hazardous gas in an atmosphere of 20.9% oxygen.
4. If the span fails a second time, reactivate the detector to test
the sensors.
If all sensors fail the span, the calibration due dates canno t be reset. The
following screens display.
57
GasAlertMicro 5/PID/IR
User Manual
No Gas Detected
If the detector does not detect any gas within 30 seconds, the following
screens display.
www.GlobalTestSupply.com
1. Ensure the regulato r valve is open and the calibration hose is
free of debris.
2. Replace the gas cylinder and/or regulator if required.
3. Replace the sensor(s) and sensor filter if required.
4. Press G to reapply gas or press H to end the span.
Did Not Reach Target Span
If the target span was not achieved, as defined in the Span Gas Value
option, the following screens display.
58
Not reaching the target span can result from
• a problem with the span gas,
• the gas cylinder being past the expiry date, or
• a problem with the sensor.
Accept Current Span: If the gas cylinder, regulator, and sensor
rating correctly, press C to accept the current span.
are ope
Reject Current Span: Press A to reject. Verify the gas cylinder,
detector settings, and sensor are operating correctly. Calibrate t
sen
sor again.
Large Span
If the span adjustment is unusually large (more than 15%), the following
screens display.
Ensure the correct gas cylinder being used and that the span concentration value(s) of the detector matches the span concentration value(s) of
the gas cylinder. Refer to Spa n Gas Value
Adjustment Expected: If the calibration adjustment is expected,
press C to accept the span.
Adjustment Not Expected: If the calibration adjustment is not
expected or the span gas value does not match the gas cylinder,
press A to reject the span and calibrate that sensor again.
.
he
GasAlertMicro 5/PID/IR
Attaching the Accessories
Attaching the Accessories
Installing the Pump Module
The pump module can be used independently to measure gas or it can
be used with the sample probe to test for gases in confined spaces. To
measure gas using the sample probe, refer to Attaching the Sample
www.GlobalTestSupply.com
Probe.
Ta ble 14. Installing the Pump Module
Item Description
1 Pump module
2 Sensor filter
3Detector
4 Machine screws (2)
To install the pump module, refer to Figure 6., Table 14., and the
following procedures.
1. Deactivate the detector.
2. Remove the two machine screws and the sensor cover.
Remove the sensor filter from the sensor cover and insert it
into the pump module.
3. Attach the pump module to the detector and replace the two
machine screws.
4. If samplin g in a confined sp ace, attach the sample probe. Refer
to Attaching the Sample Probe
If using an auxiliary filter as an additional filtrat ion system, refer
to Attaching the Auxiliary Filter
5. Activate th e detector. The detector performs a pump test dur-
ing the startup self-tests. Refer to Pump Test
.
.
.
Figure 6. Installing the Pump Module
59
GasAlertMicro 5/PID/IR
User Manual
Replacing the Pump Filter
To replace the pump filter, refer to Figure 7. and the following steps 1-8.
Note
If using the auxiliary filter on an older model pump module or
as an additional filtration system on the new pump module,
www.GlobalTestSupply.com
refer to Attaching the Auxiliary Filter
Figure 7. Replacing the Pump Filter
.
1. Deactivate the detector.
2. Remove the filter window screw.
3. Remove the filter window.
4. Remove the old filter from the filter window.
Important! Ensure the filter cavity and filter window are clean
and free of debris.
5. Insert a new filter.
6. Replace the fi lter window and screw.
7. Activate th e detector. The detector performs a pump test dur-
ing the startup self-tests to veri fy the pump module i s operating
correctly.
8. To order additional filters, refer to Replacement Parts and
Accessories.
a Caution
Filters may need to be replaced more frequently in high
particulate areas. BW Technologies by Honeywell
recommends that the auxiliary filter be used as a
additional filtration in high particulate areas.
60
GasAlertMicro 5/PID/IR
Attaching the Accessories
Replacing the Pump Nozzle
To replace the pump nozzle, refer to Figure 8. and step 1-4.
www.GlobalTestSupply.com
Figure 8. Replacing the Pump Nozzle
Note
If the nozzle is damaged, replace it immediately to ensure
accurate pump flow . To order additional pump nozzles, refer to
Replacement Parts and Accessories
1. Deactivate the detector.
2. Gently insert a medium-sized flathead screwdriver into the
nozzle slot. Twist the screwdriver slightly to lift and remove the
damaged nozzle.
.
3. Insert the new nozzle. Ensure the nozzle post inserts correctly
into the nozzle gasket.
4. Activate th e detector. The detector performs a pump test during the startup self-tests to veri fy the pump module i s operating
correctly.
Attaching the Auxiliary Filter
The Pump Module Auxiliary Filter (“the filter”) is used to filter out
particulates that can decrease t he life span of the pump.
Figure 9. Attaching the Auxiliary Filter
61
GasAlertMicro 5/PID/IR
User Manual
a Caution
The filter is designed to protect the pump. For older
model pumps, the filter must be connected when the
pump is activated. Only remove the filter to perform
calibrations, bump tests, and when using the sample
probe.
www.GlobalTestSupply.com
For new model pumps, the a uxiliary fi lter can be used as
an additional filtration system in high particulate areas.
To ins e rt th e a uxiliary filter, complete the following:
1. Loop the filter cord through the ring on the alligator clip and
pull the filter through the loop of the filter cord.
Note
Attaching the filter cord to the alligator clip ensures the filter
remains with the detector when not in use.
2. Pull the filter cord tight. Ensure the loop knot is secure.
3. Align the pump quick connector with the filter quick connector
and turn clockwise. Ensure the connection is secure.
4. Change the filter as required. Environments with heavy airborne particulates require the filter to be changed
frequently.
To order additional filters, refer to Replacement Parts and
Accessories.
62
Figure 10. Attaching the Filter Cord
GasAlertMicro 5/PID/IR
Attaching the Accessories
Attaching the Sample Probe
The sample probe is used to safely test for gas in confined spaces
before entering.
a Warning
To measure hazardous gas in a confined space, the
www.GlobalTestSupply.com
sample probe must be used with the pump module.
a Caution
To prevent the Teflon lining inside the T ygon tubing from
causing a blockage when connecting it to the sample
probe, the end of the tubing must be f lared. Refer to
steps 3 and 4.
1. Deactivate the detector.
2. Att ach the pump connector end of the t eflon-lined Tygon tubing
to the nozzle on the pump module.
3. Gently inse rt need le nose pli ers into the ot her end of th e teflonlined Tygon tub ing. Using a ci rcular moti on, flare th e end of the
tubing.
4. Connect the fl ared end of the tubing to the sample probe.
Ensure the teflon lining does not separate from the Tygon tubing, as it will block the tube and generate a pump alarm.
5. Activate the det ector . Ensure all co nnections are secure before
sampling.
6. Insert the sample probe into the confined space.
a Warning
Depending upon the length of the tub ing and the type
of gas in the confined space, allow a minimum of
3 seconds per ft. of tubin g to ensure the readings
stabilize before entering the area.
Example: 50 ft. = 2.5 minutes
Figure 11. Atta ching the Sample Probe
63
GasAlertMicro 5/PID/IR
User Manual
Datalogger
Detectors equipped with the datalogger option record information that
can be compiled to create a report. To set how often the detect or records
a sample (1-127 seconds), refer to Logger Option
menu.
The following information is recorded in a datalog:
www.GlobalTestSupply.com
• Date and time
• Serial number of the detector
• Type of gas the detector monitors
• Gas reading(s) that display
• STEL and TWA readings
• Sensor status
• Detector status
• Passcode protect enabled/disabled
• STEL period setting
• Confidence beep enabled/disabled
• Automatic backlight enabled/disabled
• Stealth mode is enabled/disabled
• Latching alarm enabled/disabled
• Calibration past due option enabled/disabled
• Language the detector is set to display
in the user options
MMC/SD Card Compatibility
a Caution
To ensure the Intrinsic Safety rating of the detector, use
only the following certified Multi MediaCards (MMC) and
Secure Digital (SD) cards.
The following MMCs and SD cards are approved for use with the
GasAlertMicro 5 and GasAlertMicro 5 PID detectors:.
• 128 MB Delkin SD card
• 64 MB Unigen SD card
The following MMCs and SD cards are approved for use with the
GasAlertMicro 5 and GasAlertMicro 5 PID detectors:.
• 128 MB Delkin MMC
• 128 MB Delkin SD card
• 128 MB Transcend MMC
• 64 MB Unigen SD card
To purchase additional MMC or SD cards, refer to Specifications
Inserting the MMC/SD Card
To insert the MMC/SD card into the detector, refer to the following steps
1-5 and Figure 12.
1. Deactivate the detector.
2. Release the latch and remove the battery pack.
3. Insert the MMC/SD card (pins face down).
4. Replace the battery pack and secure the latch.
.
.
64
GasAlertMicro 5/PID/IR
MMC/SD Card Troubleshooting
5. Activate the detector. The MMC/SD card is automatically formatted during the startup self-test.
www.GlobalTestSupply.com
Figure 12. Inserting/Removing the MMC/SD Card
MMC/SD Card Troubleshooting
The MMC/SD card is not required for operation in detectors equipped
with datalogging. However, the following two screens display if the card
is not inserted during startup.
A new MMC/SD card is automatically formatted when i t is in serted i n the
detector. When the detector is activated, it begins the self-test and then
displays the following screen.
65
GasAlertMicro 5/PID/IR
User Manual
Restoring Datalog Files
If the MMC/SD card has been accidentally reformatted or erased by the
computer application, the following screens display when the card is
inserted into the detector.
www.GlobalTestSupply.com
a Caution
Only erased data files can be restored using the detector.
Computer applications sometimes write data over erased
files, and that erased data cannot be restored by the detector.
Always create back up files on the computer.
To restore the logfile, complete the following:
1. From the detector, press H to restore the logfile. The
following screen displays.
If the detector successfully restores the logfile, the
following screen displays and the startup tests continue.
2. From the computer, verify that the logfile has been restored.
When the normal operation screen displays, deactivate the
detector.
3. Remove the MMC/SD card and insert it into the card reader.
4. From the computer desktop, double-click My Computer to
view the list of drives.
5. Double-click the Removable Disk drive to access
LOGFILE0.csv. Open the logfile and verify that the data has
been restored.
If LOGFILE0.csv does not display, ensure that the MMC/SD
card is inserted in the card reader correctly and that all conn ections are secure.
6. Aft er verifying that the logfile has been restored, re-insert the
MMC/SD card into the detector.
66
GasAlertMicro 5/PID/IR
MMC/SD Card Troubleshooting
Reformatting the MMC/SD Card
To reform a t th e M MC /S D ca rd , comp l ete the follo wing:
1. Insert the MMC/SD card into the card reader.
2. From the computer desktop, double-click My Computer to
view the list of drives.
www.GlobalTestSupply.com
3. Double-click the Removable Disk drive to acce
LOGFILE0.csv.
4. Select LOGFILE0.csv and delete.
5. Insert the MMC/SD card into the detector.
6. Activate the detector. The startup self-test begins and the following screens display.
ss
7. Press G to format the MMC/SD card. The following screen dis-
plays.
For any additional MMC/SD card errors, refer to
Troubleshooting
.
67
GasAlertMicro 5/PID/IR
User Manual
Import Datalogs to Fleet Manager II
Note
Refer to the following minimum requirements before importing
datalogs to Fleet Manager II.
Minimum PC Requirements
www.GlobalTestSupply.com
• 500 MHz Pentium (or equivalent)
• 100 MB free hard disk space
•Windows XP or Vista
• USB port
Importing from MicroDock II to Fleet Manager II
If the detector is used with the MicroDock II Station to import datalogs to
Fleet Manager II, refer to the MicroDock II User Manual for complete
instructions.
Import to Fleet Manager II Using a Card Reader
To import a datalog file from the detector to Fleet Manager II, complete
the following:
1. Deactivate the detector
2.
Release the latch and remove the battery pack.
3. Remove the MMC/SD card from the detector. Refer to Fi
12. and 1.
4. Connect the card reader to the USB port on the computer.
5. Insert the MMC/SD card into the card reader (ensure the pi
ace down).
f
6. Open Fleet Manager II. Click Start > All Programs > BW
Technologies > Fleet Manager II > BW Technologies Fl
Manage
7. From the top task bar, click Help > User Manual.
8. Refer to section “Importing Data into Fleet Manager II”.
r II.
.
gure
ns
eet
68
View Datalog Files in Spreadsheets
The datalog files can be downloaded from the MMC/SD card into most
spreadsheet applications using a card reader.
Compatible software applications ar e
• Microsoft® Excel 98 or higher,
www.GlobalTestSupply.com
• Quattro Pro,
• Lotus 1-2-3,
• Microsoft® Access, and
• Microsoft® Word.
To view a datalog file in a software spreadsheet, complete the following:
1. Deactivat e the det ector and re move th e MMC/SD ca rd (ref er
Figure 12.
to
2. Insert the MMC/SD card into the card reader.
3. From the computer desktop, double-click My Computer to
view the list of drives.
4. Double-click Removable Disk drive.
5. Double-click LOGFILE0.csv.
6. Refer to Table 15.
The Unit Config column (far right) in Table 15.
codes. Refer to Table 16.
des.
co
).
for an example of the datalog spreadsheet.
contains letter
and Table 17. for definitions of the
GasAlertMicro 5/PID/IR
View Datalog Files in Spreadsheets
69
GasAlertMicro 5/PID/IR
User Manual
Example of a Datalog Spreadsheet
When datalog information is imported into most spreadsheet software, it appears similar to the example below.
a Warning: Some compatible software packages have an internal file size limit and may not load the entire file. Check the software limit.
Note
www.GlobalTestSupply.com
Not all columns are included in this example. Additional Toxic TWA and Toxic STEL display on a normal spreadsheet.
Table 15. Datalog Spreadsheet Example
Date
dd-mm-yy
23-12-05 #4 9:54:25 5 10 35 -- -- 33------ S104-000001
23-12-05 #4 9:54:30 10 15 50 -- -- 44------ S104-000001
23-12-05 #4 9:54:35 5 10 35 10 19.5 -- -- 1111---- S104-000001
23-12-05 #4 9:54:40 10 15 200 20 23.5 -- -- 2222---- S104-000001
23-12-05 #4 9:54:45 0 0 0 24 20.9 -- -- -D-E---D S104-000001 FCEKNL
23-12-05 #4 9:54:50 0 0 0 24 20.9 0 0 -------- S104-000001 FCEKNL
23-12-05 #4 9:54:55 0 0 0 24 20.9 0 0 --L----L S104-000001 FCEKNL
23-12-05 #4 9:55:00 0 0 0 24 20.9 0 0 LLH----M S104-000001 FCEKNL
23-12-05 #4 9:55:05 5 10 35 0 0 LLH----M S104-000001
23-12-05 #4 9:55:10 10 15 50 0 0 LLL----M S104-000001
23-12-05 #4 9:55:15 5 10 35 10 19.5 0 0 -L-----L S104-000001
23-12-05 #4 9:55:20 10 15 200 20 23.5 0 0 -------- S104-000001
23-12-05 #4 9:55:25 0 0 0 24 20.9 0 0 -------B- S104-000001 FCEKNL
23-12-05 #4 9:55:30 0 0 0 24 20.9 0 0 ------B- S104-000001 FCEKNL
Day
Mon=1
Time
hh:mm:ss
Toxic1
ppm
Toxic2
ppm
Toxic3
ppm
LEL
%CH4
%LEL
O2%Toxic 1
TWA ppm
Toxic 1
STEL ppm
Status
Codes
Serial
Number
70
Unit
Config
GasAlertMicro 5/PID/IR
View Datalog Files in Spreadsheets
Table 16. Datalog Status Codes
Status Codes
Normal operation
⎯
Low alarm
L
High alarm
www.GlobalTestSupply.com
H
TWA alarm
T
TWA and low alarm (dual alarms)
U
TWA and high alarm (dual alarms)
V
STEL alarm
s
STEL and low alarm (dual alarms)
u
Fresh air delay
f
Zero CO
@
Plugged (blocked) - pump alarm
P
Batteries OK
⎯
Low alarm
L
High alarm
H
TWA alarm
T
2
Backlight is on
G
STEL and high alarm (dual alarms)
v
TWA and STEL alarm (dual alarms)
w
TWA, STEL, and low (triple alarms)
x
TWA, STEL, and high (triple alarms)
y
Overload / sensor is over-ranged
O
Calibrating
C
Failure - sensor failure
F
Time set
I
Pump Codes
Failure / pump failure
F
Battery Status Codes
Low battery alarm
B
Alarm Status Codes
Multi alarm
M
Calibration
C
Off / quit / manual deactivation
Q
Alarm setpoint 1 (low alarm)
1
Alarm setpoint 2 (high alarm)
2
Alarm setpoint 3 (TWA alarm)
3
Alarm setpoint 4 (STEL alarm)
4
Calibration due date (days)
D
Elapsed / last calibration (days)
E
Auto zeroing
Z
Testing
t
Confidence beep is active
C
Automatic shutdown
S
Failure / self-test fail
F
RTCC / real-time clock failure
R
Note: TWA readings greater than 99 are recorded as OL.
71
GasAlertMicro 5/PID/IR
User Manual
No sensor B H2S C H2S COSH D CO E CO COSH
A
SO
F
NH
www.GlobalTestSupply.com
K
IR
Q
Acetaldhyde B Acetone C Ammonia D Benzene E Butadiene
A
Diesel G Ethanol H Ethylene I Gasoline J Hexane
F
Isobtyln L JP8 M Kerosene N MEK O Naptha
K
Styrene Q Toluene R Turpentine S Vinyl_Cl T Xylene
P
Custom
U
Acetone B Benzene C Butane D Cyclohexane E Ethanol
A
Ethyl_Ace G Gasoline H Heptane I Hexane J Hydrogen
F
Isobutylene L Isopropanol M MEK N Methane O Methanol
K
Octane Q Pentane R Propane S Toluene T Turpentine
P
Custom
U
LEL in % by Vol CH
V
Table 17. Datalog Gas and Correction Factor Sensor Codes
Gas Sensor Codes
2
3
G PH
L ClO
3
2
H NO
M O
2
3
I HCN J Cl
O LEL P PID
2
Correction Factor Codes for PID (if applicable)
Correction Factor Codes for LEL
LEL Unit Codes
4
L LEL in % LEL
72
GasAlertMicro 5/PID/IR
Maintenance
Maintenance
To maintain the detector in good operating condition, perform the
following basic maintenance as required.
• Calibrate, bump test, and inspect the detector at regular intervals.
• Maintain an operations log of all maintenance, calibrations, bump
www.GlobalTestSupply.com
tests, and alarm events.
• Clean the exterior with a soft damp cloth. Do not use solvents,
soaps, or polishes. Refer to Sensor Poisons and Contaminants
• Do not immerse the detector in liquids.
Battery Cautions
a Warning
To avoid personal injury and/or pr operty damage, adh ere
to the following:
• Replace the batteries immediately when the detector emits a
low battery alarm.
• Use only batteries that are recommended by BW Technologies
by Honeywell. Refer to Specifications
• Ensure the alkaline batteries are properly installed in the
detector battery pack.
• Charge batteries using only a recommended BW charger. Do
not use any other charger. Failure to adhere to this caution
can cause fire and/or explosion.
.
• Do not calibrate the detector during or immediately after
charging.
• Both the rechargeable lithium battery pack and the alkaline
battery pack are user-changeable in hazardous locations, but
the alkaline battery cells inside the pack can onl y be replaced in
a safe area that is free of hazardous gas.
• Warning: The battery pack (M5-BAT08) that is equipped with a
lithium polymer cell may present a risk of fire or chemical burn
.
hazard if misused. Do not recharge, disassemble, heat above
212ºF (100ºC), or incinerate.
• Warning: Do not use any other lithium batteries with the Micro5/
PID/IR detectors. Use of any other cell can cause fire and/or
explosion. To order a replacement lithium battery pack (M5BAT08), refer to Re placement Parts and Accessories
• Warning: Lithium Polymer cells exposed to heat at 266ºF
(130ºC) for 10 minutes can cause fire and/or explosion.
• Dispose of used lithium cells immediately. Do not disassemble
and do not dispose of in fire. Do not mix with the solid waste
stream. Spent batteries must be disposed of by a qualified
recycler or hazardous materials handler.
• Keep lithium cells away from children.
Charging the Battery
To charge the battery, refer to the GasAlertMicro 5/PID/IR Charger
Instruction Sheet.
.
• The detector must be deactivated to charge the battery.
73
GasAlertMicro 5/PID/IR
User Manual
Replacing the Alkaline Batteries
To replace the alkaline batteries, refer to Figure 13., Table 18., and the
following steps 1-6.
www.GlobalTestSupply.com
Figure 13. Replacing the Alkaline Batteries
Table 18. Replacing the Alkaline Batteries
Item Description
1 Detector
2 Latch
3 Battery pack
4 Battery tray
5 Captive screws (2)
6 Alkaline batteries (3)
7 Battery shell
1. Open the latch on the bottom of the detector.
2. Remove the battery p ack by lif ting the bottom of th e pack away
from the detector.
3. On the battery pack, remove the two captive screws. Remove
the battery shell from the battery tray.
4. Replace the three alkaline batteries.
5. Replace the battery pack and the captive screws.
6. Reinsert the battery pack and secure the latch.
74
GasAlertMicro 5/PID/IR
Maintenance
Replacing the Lithium Battery Pack
To replace the lithium battery pack, refer to Figure 14. and the following
steps 1-4.
www.GlobalTestSupply.com
Figure 14. Replacing the Lithium Battery Pack
1. Open the latch on the bottom of the detector.
2. Remove the battery pack by lifting the bottom of the pack
upward from the detector.
a Warning
Do not disassemble lithium battery packs. Read and
adhere to the cautions in Battery Cautions
3. Replace the battery pack with a fully charged lithium
battery pack.
4. Close the latch.
.
Replacing a Sensor or Sensor Filter
a Warning
To avoid personal injury, only use sensors that are
specifically designed for the detector. Refe r to
Specifications
Each sensor has a high degree of resistance to common vapors and
gases. To clear a sensor, place the detector in a clean environment
and wait 10 to 30 minutes.
Do not expose a sensor to vapors from organic solvents such as pain t
thinners and acetone. For a list of common products that can damage
sensors, refer to Sensor Poisons and Contaminants
For sensor problems, refer to Troubleshooting
.
.
.
75
GasAlertMicro 5/PID/IR
User Manual
To replace a sensor or sensor filter, refer to Figure 15., Table 19., and
the following procedures 1-7.
www.GlobalTestSupply.com
Figure 15. Replacing a Sensor or Sensor Filte r
Note
Detectors that are configured for 1, 2, 3, or 4 gases may
contain a dummy sensor in one of the four sensor locations.
Table 19. Replacing a Sensor or Sensor Filter
Item Description
1 Sensor cover
2 Sensor filter
3 Sensors
4 Detector
5
1. Deactivate the detector.
2. Remove the two machine screws on the rear shell and then
remove the sensor cover or pump module.
3. Remove the sensor filter and/or the sensor(s).
4. Insert the new filter and/or sensor. Ensure the sensor posts are
aligned correctly.
5. Re-assemble the detector.
6. If the senso r is changed, such as SO
must be reconfigured. Refer to Sensors
option.
7. A sensor that has been replaced must be calibrated immediately. Refer to Calibration and Setting Alarm Setpoints
Machine screws (2)
to an H2S, the detector
2
in the Tech Mode
.
76
Photoionization Detector (PID)
Clean or Replace the Lamp
The PID lamp must be cleaned regularly. Use only the cleaning kit
that is supplied by BW Technologies by Honeywell.
To clean the PID lamp, refer to the illustrations and procedures that
www.GlobalTestSupply.com
are provided with the PID Lamp Cleaning Kit. To order the kit, refer
to Replacement Parts and Accessories
a Caution
To ensure proper maintenance and continued accurate
readings from the sensor, use only the PID Lamp
Cleaning Kit that is supplied by BW Technologies by
Honeywell.
Table 20. Parts of the PID sensor
Item Description
1 PID sensor
2 Diffusion barrier
3 Sensor cover
4 Electrode stack
5
Lamp
.
GasAlertMicro 5/PID/IR
Maintenance
Figure 16. Parts of the PID
77
GasAlertMicro 5/PID/IR
User Manual
Replace the Lamp
Replace the lamp when it falls below the acceptable l evel. Possible
indicators that the lamp requires replacement are as follows:
• The detector will not cali brate.
• The startup self-te st fails.
www.GlobalTestSupply.com
• The ppm levels are incorrect.
To replace the lamp, refer to the illustrations and procedures in the
PID Lamp Cleaning Kit.
If required, contact BW Technologies by Honeywell
for more information.
Replace the Electrode Stack
Replace the electrode stack when it is contaminated. To replace
the electrode stack, refer to Table 20.
procedures. 1-4.
Ensure your fingers do not make contact with the
diffusion barrier or the electrodes on the underside of
the stack.
1. Remove the sensor cover.
2. Remove the old ele ctrode stack.
3. Insert the new electrode stack.
4. Replace the sens or cover.
, Figure 16., and the following
a Caution
78
Troubleshooting
If a problem occurs, refer to the solutions provided in Table 21.. If the problem persists, contact BW Technologies by Honeywell.
Table 21. Troubleshooting
Problem Possible Cause Solution
www.GlobalTestSupply.com
Startup Troubleshooting
The detector does not
activate.
The detector immediately
enters alarm mode when
activated.
The startup self-test fails.
No batteries Refer to Replacing the Alkaline Batte ries
Pack.
Depleted batteries Refer to Replacing the Alkaline Batteries
Pack.
Damaged or defective detector Contact BW Technologies by Honeywell
Sensor needs to stabilize Used sensor: wait 60 seconds.
New sensor: wait 5 minutes.
Low battery alarm Refer to Battery Cautions
Lithium Battery Pack.
Sensor alarm Refer to Replacing a Sensor or Sensor Filter
Pump alarm If the sampling hose is attached, det ermine if it is obstructed. If not, clean
or replace the pump filter. If the pump alarm persists, refer to the “Pump
Operation” section in Troubleshooting.
General fault Ensure that the sensors and battery pack are installed correctly and then
reactivate the detector.
If the fault persists, record the error message and contact BW Technologies
by Honeywell.
, Replacing the Alkaline Batteries, Replacing the
or Replacing the Lithium Battery
, or Replacing the Lithium Battery
.
.
GasAlertMicro 5/PID/IR
Troubleshooting
79
GasAlertMicro 5/PID/IR
User Manual
Problem Possible Cause Solution
Detector Operation Troubleshooting
Detector does not display
normal ambient gas
www.GlobalTestSupply.com
readings after startup
self-test.
Detector does not respond
to pushbuttons.
Detector does not
accurately measure gas.
Table 21. Troubleshooting
Sensor not stabilized Used sensor: wait 60 seconds
New sensor: wait 5 minutes
Detector requires calibration Calibrate the sensors. Refer to Calibration and Setting Alarm Setpoints
Target gas is present Detector is operating properly. Use caution in suspect areas.
Batteries are depleted Refer to Replacing the Alkaline Batteries
Pack.
Detector is performing
operations that do not require
user input
Detector requires calibration Calibrate the sensors. Refer to Calibration and Setting Alarm Setpoints
Detector is colder/hotter than
ambient gas
Sensor filter is blocked Clean the sensor filter. Refer to Replacing a Sensor or Sensor Filter
Pushbutton function restores automatically when the operation ends.
Allow the detector to adjust to am b ie n t te m p era ture before using.
or Replacing the Lithium Battery
.
.
.
80
Table 21. Troubleshooting
Problem Possible Cause Solution
MMC/SD Card Troubleshooting
GasAlertMicro 5/PID/IR
Troubleshooting
www.GlobalTestSupply.com
The MMC/SD card is not
inserted.
The MMC/SD card that is
inserted in the detector has a
storage size that is not
supported by the detector.
The detector has lost
communication with the MMC/
SD card.
Insert the MMC/SD card. Refer to Inserting the MMC/SD Card
Insert an approved MMC/SD card:
• 128 MB Delkin MMC
• 128 MB Delkin SD card
• 128 MB Transcend SD card
• 64 MB Unigen SD card
Retry communication
Insert a new approved MMC or SD card. Refer to Inserting the MMC/SD
Card.
Reformat the MMC or SD card in windows and then reinsert into the
detector.
Contact BW Technologies by Honeywell
.
.
81
GasAlertMicro 5/PID/IR
User Manual
Problem Possible Cause Solution
Alarms Troubleshooting
Detector does not enter
alarm mode.
www.GlobalTestSupply.com
Detector intermittently
enters alarm without any
apparent reason.
Detector enters alarm with
LEL reading displaying as
OL (over limit).
Table 21. Troubleshooting
Alarm setpoint(s) are set
incorrectly.
Alarm setpoint(s) are set to
zero.
Detector requires calibration. Calibrate the sensors. Refer to Calibration and Setting Alarm Setpoints
Ambient gas levels are near
alarm setpoint or the sensor is
exposed to a puff of the target
gas.
Alarms setpoints are set
incorrectly.
Missing or faulty sensor. Refer to Replacing a Sensor or Sensor Filter
Pump flow rate is set too high. Refer to the last solution in Pump Operation troubleshooting on the
Reset alarm setpoints. Refer to Calibration and Setting Alarm Setpoints
Reset alarm setpoints. Refer to Calibration and Setting Alarm Setpoints
Detector is operating normally. Use caution in suspect areas. Check MAX
gas exposure reading.
Reset alarm setpoints. Refer to Calibration and Setting Alarm Setpoints
.
following page.
.
.
.
.
Automatic Deactivation Troubleshooting
Detector automatically
deactivates.
Automatic shutdown activated
because of weak batteries.
Calibration is overdue and the
Due-lock (calibration user
lock-out) option is enabled.
82
Refer to Charging the Battery
Enter the password to enter calibration. Calibrate the sensor(s). Refer to
Calibration Procedure
.
.
Problem Possible Cause Solution
Pump Operation Troubleshooting
GasAlertMicro 5/PID/IR
Troubleshooting
Table 21. Troubleshooting
www.GlobalTestSupply.com
Detector enters alarm with
LEL reading displaying as
over limit (OL).
There is an obstruction in the
tubing.
Filter needs to be cleaned or
replaced.
Pump is drawing too much air
over the sensors.
Pump flow rate is set too high. 1. From Tech Mode
If using tubing that is attached to the sample probe, determine if it is
obstructed. If not, clean or replace the pump filter. Re fer to Replacing the
Pump Filter.
Clean or replace the pump filter. Refer to Replacing the Pump Filter
For newer model pump modules, the pump may be drawing too much air
over the sensors. Attach the auxiliary filter to reduce the flow. Refer to
Attaching the Auxiliary Filter
2. From the Pump Speed screen, press H to decrease the speed to 150.
3. Exit user options. The detector automatically initiates a pump test.
4. If the pump alarm persists, contact BW Technologies by Ho ne y w e ll
.
.
, scroll to the Pump option and press C.
.
83
GasAlertMicro 5/PID/IR
User Manual
Table 21. Troubleshooting
Problem Possible Cause Solution
Clock Errors Troubleshooting
Clock icon is flashing. The clock has failed. Contact BW Technologies by Honeywell
www.GlobalTestSupply.com
The detector displays a
clock error message using
last recorded time.
There is communication failure. Contact BW Technologies by Honeywell
General fault. Reactivate the detector. If the same error message displays, reset the clock
in the user options menu. Reactivate the detector.
If the error message still displays, contact BW Technologies by Honeywell
84
.
.
.
Replacement Parts and Accessories
a Warning
To avoid personal injury and/or damage to the detector,
use only the specified replacement parts.
To order parts or accessories, contact BW Technologies by Honeywell.
www.GlobalTestSupply.com
T able 22. Replacement Parts and Accessories
Model No. Description Qty
Sensors
S4-W04 Combustible (LEL) sensor
S4-W04-UF
SR-X10 Oxygen (O
PS-RM04 Carbon monoxide (CO) sensor 1
PS-RH04S Hydrogen sulfide (H
SR-P04 Phosphine (PH
PS-RS04 Sulfur dioxide (SO
PS-RC10 Chlorine (Cl
SR-A04 Ammonia (NH
PS-RD04 Nitrogen dioxide (NO
PS-RZ10 Hydrogen cyanide (HCN) sensor 1
SR-V04 Chlorine dioxide (ClO
SR-G04
D4-RHM04
(with silicone protection filter)
Combustible (LEL) sensor
(no silicone protection filter)
) sensor
2
S) sensor
2
) sensor
3
) sensor
2
) sensor
2
) sensor
3
) sensor
2
) sensor
2
Ozone (O
TwinTox CO/H
) sensor
3
S sensor
2
GasAlertMicro 5/PID/IR
Replacement Parts and Accessories
SR-Q07 PID sensor 1
SR-B04
SR-DUMM1
Carbon dioxide (CO
Dummy sensor 3-pin O
SR-DUMM2 Dummy sensor for LEL location 1
Sensor Replacement Parts and Accessories
RL-PID10.6 Lamp for PID sensor 1
M5PID-ES-1 Electrode stack for PID sensor 2
M5PID-CLN-K1 Cleaning kit for PID sensor lamp 1
1
1
M5-SS Sensor filters (quad) kit of 2 2
Gas Cylinders
Quad calibration gas, CH
1
CG-Q58-4
18.0%, H
bal. N
1
1
CG-Q34-4
1
1
1
1
1
1
1
CG-T34
CG2-S-25-58
CG-BUMP-S25
CG-BUMP1
REG-0.5 Regulator (0.5 l/min) 1
G0042-H25
Quad calibration gas, CH
18.0%, H
bal. N
Two gas calibration cylinder, 50% LEL
(CH
Calibration gas, SO
SO
Bump alarm gas aerosol (CH
O
Calibration gas, H
S-25 ppm, CO-100 ppm,
2
(58 l)
2
S-25 ppm, CO-100 ppm,
2
(34 l)
2
-2.5%) O2-20.9%, bal. N2 (34 l)
4
bump test gas
2
-10%, H2S-40 ppm, CO-200 ppm)
2
) sensor
2
or TwinTox
2
-2.5%, O2-
4
-2.5%, O2-
4
25 ppm (58 l)
2
-2.5%,
4
S 25 ppm (58 l)
2
1
1
1
1
1
1
1
1
1
85
GasAlertMicro 5/PID/IR
User Manual
CG2-M-200-103 Calibration gas, CO 200 ppm (103 l) 1
CG2-S-25-58
CG2-C-5-58
CG2-Z-10-58 Calibration gas, HCN 10 ppm (58 l) 1
www.GlobalTestSupply.com
CG2-D-10-58
CG2-P-1-58
CK-Q34-4
CK-Q58-4
Micro 5/PID/IR Alkaline Battery Packs
M5-BAT0501 Alkaline battery pack 1
M5-BAT0502 Alkaline battery pack with European
Micro 5/PID/IR Lithium Battery Packs
M5-BAT08 Lithium rechargeable battery pack 1
M5-BAT08B Lithium rechargeable battery pack
Micro 5/PID/IR Chargers and Kits
M5-CO1* GasAlertMicro 5 battery charger 1
M5-CO1-BAT08*
GA-V-CHRG4 Vehicle GasAlertMicro 5 battery charger 1
M5-BL-1 Battery latch replacement 1
Calibration gas, SO
Calibration gas, Cl
Calibration gas, NO
Calibration gas, PH
Quad calibration kit with regulator, quad
gas cylinder (CG-Q34-4), hose and
carrying case
Quad calibration kit with regulator, quad
gas cylinder (CG-Q58-4), hose and
carrying case
screw
(black)
GasAlertMicro 5 Lithium battery charger
and battery pack kit
25 ppm (58 l)
2
5 ppm (58 l)
2
10 ppm (58 l)
2
1 ppm (58 l)
3
Datalogger Accessories
1
1
1
1
1
1
1
CR-MMC-USB1 USB memory card reader 1
MMC128-D 128 MB Delkin MMC 1
MMC128-D 128 MB Delkin SD card 1
MMC128-D 128 MB Transcend SD card 1
M5-MMC 64 MB Unigen SD card 1
Accessories
M5-PUMP Motorized Pump Module Kit 1
M5-TC-1 Calibration cap and hose 1
GA-AG-2 Alligator clip (stainless steel) 1
GA-CH-2 Chest harness 1
GA-ES-1 Extension strap 1
GA-ARM-1 Arm band 1
GA-HM5 Belt holster 1
Replacement Parts
Pump replacement filters (kit of 2) 1
Pump replacement filters (kit of 5) 1
Pump replacement nozzle (kit of 2) 1
* Add suffix (-UK) for United Kingdom mains plug, (-EU) for European
mains plug, (-AU) for Australian mains plug.
1
86
Specifications
Instrument dimensions: 14.5 x 7.4 x 3.8 cm (5.7 x 2.9 x 1.5 in.)
Weight: 370 g (13.1 oz.)
Operating and storage conditions
Temperature:
VOC: -10°C to +40°C (-14°F to +104°F)
www.GlobalTestSupply.com
Other gases: -20°C to +50°C (-4°F to +122°F)
Combustible gas sensor: Certified by CSA International to ±3% LEL
accuracy from -10°C to +40°C (4°F to 104°F)
Humidity:
: 0% to 99% relative humidity (non-condensing)
O
2
VOC and CO
Combustibles: 5% to 95% relative humidity (non-condensing)
Cl
: 10% to 95% relative humidity (non-condensing)
2
HCN, ClO
Other gases: 15% to 90% relative humidity (non-condensing)
Pressure: 95 to 110 kPa
Alarm setpoints: May vary by region and are user-defined
Detection range:
O
: 0 – 30.0% vol. (0.1% vol. increments)
2
CO: 0 – 999 ppm (1 ppm increments)
CO (TwinTox sensor): 0 – 500 ppm (1 ppm increments)
H
S: 0 – 500 ppm (1 ppm increments)
2
H
S (TwinTox sensor): 0 – 500 ppm (1 ppm increments)
2
Combustible (LEL): 0 - 100% LEL (1% LEL increments) or 0 - 5.0% v/v
methane; certified by CSA International to C22.2 No. 152 and ISA
12.13.01 within 0 - 60% or 3.0% v/v methane
IR: 0% to 95% relative humidity (non-condensing)
2
: 15% to 95% relative humidity (non-condensing)
2
GasAlertMicro 5/PID/IR
Specifications
PH
: 0 – 5.0 ppm (0.1 ppm increments)
3
SO
: 0 – 150 ppm (1 ppm increments)
2
Cl
: 0 – 50.0 ppm (0.1 ppm increments)
2
NH
: 0 – 100 ppm (1 ppm increments)
3
NO
: 0 – 99.9 ppm (0.1 ppm increments)
2
HCN: 0 – 30.0 ppm (0.1 ppm increments)
ClO
: 0 – 1.00 ppm (0.01 ppm increments)
2
O
: 0 – 100 ppm (0.01 ppm increments)
3
VOC: 0 – 1000 ppm (1.0 ppm increments)
CO
IR: 0-50,000 ppm (50 ppm increments) or 0-5.0% v/v CO
2
(Sensors not available for use with the Micro 5 IR: ClO2, HCN, NO2,
PH
, and Cl2)
3
Sensor type:
H
S/CO: Twin plug-in electrochemical cell
2
Combustibles: Plug-in catalytic bead
VOC: Photoionization detector (PID)
CO
: IR detector
2
Other gases: Single plug-in electrochemical cell
O
measuring principle: Capillary controlled concentration sensor
2
Alarm conditions: TWA alarm, STEL alarm, low alarm, high alarm,
multi alarm, over limit alarm, sensor alarm, pump alarm,
MMC/SD card fail alarm, low battery alarm, confidence beep,
automatic deactivation alarm
Audible alarm: 95 dB at 0.3 m (1 ft.) variable pulsed dual beepers
Visual alarm: Dual red light-emitting diodes (LED)
Display: Alphanumeric liquid crystal display (LCD)
2
87
GasAlertMicro 5/PID/IR
User Manual
Backlight: Automatically activates during an alarm condition and when
there is insufficient light to view the LCD (if enabled in user options)
Self-test: Initiated during activation
Calibration: Automatic zero and automatic span
Oxygen sensor: Automatic span upon activat ion (en able/dis able op tion)
www.GlobalTestSupply.com
User options: Confidence beep, latching alarms, passcode protection,
enable/disable safe display mode, combustible sensor measurement,
sensor disable, TWA and STEL, language selection, enable/disable
automatic oxygen calibration, define sp an concentration values, define
STEL calculation period, define TWA method, gas measurement resolution, enable/disable automatic backlight, adjust clock calendar, and
define logging rate (datalogger models only), CO
sensor measurement
2
Approved MMC and SD cards for GasAlertMicro 5 and
GasAlertMicro 5 PID: 128 MB Delkin SD card and 64 MB Unigen SD
card
Approved MMC and SD cards for GasAlertMicro 5 IR: 128 MB Delkin
MMC, 128 MB Delkin SD card, 128 MB Transcend MMC, and 64 MB
Unigen SD card
Battery operating time:
Toxic, O
, and LEL sensors: Three alkaline cells or one lithium battery
2
pack at 20°C provides 20 hours operating runtime
Toxic, O
, LEL, and PID sensors: Three alkaline cells or one lithium
2
battery pack at 20°C provides 15 hours operating runtime
Toxic, O
, LEL, and CO2 sensors: Three alkaline cells or one lithium
2
battery pack at 20°C provides 15 hours operating runtime
Year of manufacture: The detector’s year of manufact ure is determined
from the serial number . The second and t hird number af ter t he first let ter
determines the year of manufacture.
E.g., H309
-Y000001 = 2009 year of manufacture
Approved batteries for GasAlertMicro 5/PID/IR models:
Alkaline (M5-BAT02) and lithium-ion polymer (M5-BAT08), as per
standards EN 60079-11, EN 60079-0, UL913, CSA C22.2 No.157
Alkaline: Temperature Code
Duracell MN1500
-20°
C ≤ Ta ≤ +50°
C
T4 (129.9°C)
Energizer E91VP -20°C ≤ Ta ≤ +50°C T3C (135.3°C)
Lithium rechargeable:
M5-BAT08
20°C ≤ Ta ≤ 50°C T4
-
Battery charger: GasAlertMicro 5/PID/IR battery charger
First-time charge: 6 hours for lithium battery pack
Normal charge: 6 hours for lithium battery pack
Warranty: 2 years including sensors
(1 year for NH
sensor and PID lamp)
3
88
GasAlertMicro 5/PID/IR
Specifications
Approvals:
GasAlertMicro 5 and GasAlertMicro 5 PID (Zone 0)
Approved by CSA to both U.S. and Canadian Standards
Standards: CAN/CSA C22.2 No. 157 and C22.2 No.152
ANSI/UL – 913 and ANSI/ISA – S12.13 Part 1
CSA Class I, Division 1, Group A, B, C, and D
www.GlobalTestSupply.com
ATEX CE 0539
IECEx Ga Ex ia IIC IECEx CSA 06.0011X
ABS Type Approved: VA-348169-X
GasAlertMicro 5 IR (Zone 1):
Approved by CSA to both U.S. and Canadian Standards
Standards: CAN/CSA C22.2 No. 157 and C22.2 No.152
ANSI/UL – 913 and ANSI/ISA – S12.13 Part 1
CSA Class I, Division 1, Group A, B, C, and D
ATEX CE 0539
IECEx Ex d ia IIC IECEx CSA 06.0011X
Class 1, Zone 0, Group IIC
g II 1 G Ga Ex ia IIC T4
KEMA 06 ATEX 0206X
EN 60079-0, EN 60079-11, EN 60079-26
IEC 60079-0, IEC 60079-11, IEC 60079-26
Class 1, Zone 1, Group IIC
g II 2 G Ex d ia IIC
KEMA 06 ATEX 02 06X
EN 60079-0, EN 60079-1, EN 60079-11
IEC 60079-0, IEC 60079-1, IEC 60079-11
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules and
ICES-003 Canadian EMI requirements. These limits are designed to
provide reasonable protection against harmful interference in a resi dential installation. This equipment gen erates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determin ed by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one of more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equip ment into an out let on a circuit diff erent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
89
GasAlertMicro 5/PID/IR
User Manual
General Specifications for Datalogger Units
Media type: MultiMediaCard (MMC) or Secure Digital (SD) card
Approved MMC and SD cards for GasAlertMicro 5 and
GasAlertMicro 5 PID: 128 MB Delkin SD card and 64 MB Unigen SD
card
Approved MMC and SD cards for GasAlertMicro 5 IR: 128 MB Delkin
www.GlobalTestSupply.com
MMC, 128 MB Delkin SD card, 128 MB Transcend MMC, and 64 MB
Unigen SD card
Storage: 500,000 lines of data available; 4.4 months at 5 second
intervals (based on a normal work week)
Memory type: Wrap-around memory ensures most recent data is
always saved
Sample rate: One reading every 5 seconds (standard)
Data recorded: All sensor readings, all alarm conditions, calibrations,
event flags, battery status, pump status, sensor status, confidence beep
activation, and detector status that includes the date, time and detector
serial number for each reading
MMC/SD card test: Automatically during activation
GasAlertMicro 5/PID/IR Downloadable Datalogger
Operation: Requires no user intervention (automatic)
Indicators: Icon indicates datalogger is operating normally, MMC/SD
card missing/malfunction
Compatibility: Desktop PC or laptop
Operating system: Windows 95 or higher and Macintosh OS 8.6 or
higher
Download via: MMC/SD reader
Software required: Spreadsheet or database compatible with
comma-separated-value (CSV) text files
Card alarm: Card fail or missing
Support:
Fleet Manager II: Reports are generated using the detector datalogs
and the Fleet Manager II application. Filters can be defined using
Fleet Manager II, or data can be exported to Excel for custom reports.
Software Requirements to generate reports:
• Windows XP or Vista
• Fleet Manager II
• Excel (optional)
90
PID Correction Factor (CF) Library
Table 23. PID Corrections Factor (CF) Library
GasAlertMicro 5/PID/IR
PID Correction Factor (CF) Library
Gas # Gas Type LCD Gas Type Abbreviation
1 No PID correction factor N/A N/A
www.GlobalTestSupply.com
2 Acetaldehyde Acetdhd 4.6’
3 Acetone Acetone 1.2’
4 Ammonia Ammonia 10.6’
5 Benzene Benzene 0.5’
6 Butadiene Butadien 0.9’
7 Diesel Diesel 0.9’
8 Ethanol Ethanol 13.3’
9 Ethylene Ethylene 9.1’
10 Gasoline Gasoline 0.7’
11 Hexane Hexane 4.6’
12 Isobtyln Isobtyln 1.0’
13 JP8 JP-8 0.5’
14 Kerosene Kerosene 1.1’
15 MEK MEK 0.9’
16 Naptha Naptha 1.0’
17 Styrene Styrene 0.5’
18 Toluene Toluene 0.5’
19 Turpentine Turpentine 0.5’
20 Vinyl Chloride Vinyl Chloride 2.2’
21 Xylene Xylene 0.5’
22 Custom Custom 0.1’ to 15.0’
Correction Factor Value
(CF values subject to change)
91
Loading...
