Bussmann HV Series Data Sheet
12-21-98
SB98107
Rev. A
Buss High Voltage Fuses HV
1000 - 10,000 Volts
Series
Form No. HV Series
Page 1 of 2
BIF Doc #6003
Bussmann
®
13/32” and 13/16” x Length
(10.3mm and 20.6mm x Length)
For High Voltage Circuits
• Non-Time Delay fuses for high voltage instruments and circuits.
• Physical size varies with electical rating of fuse to prevent
over-fusing.
• Use HVA, HVB, HVJ an d HVL for circuits up to 20kw dc or
30 KVAac. For higher interrupting capacity, use HVR, HVT,
HVU, HVW and HVX.
CATALOG SYMBOL: HVA, HVB, HVJ, HVL, HVR, HVT, HVU,
HVW, AND HVX
NON-TIME DELAY
1000 TO 10,000 VOLTS
HVA(1000 Volts)
Length *Wt./100
Amps Dia. In. mm Lbs. Kg
1/16 3/4
1/8 1
1/4 1-1/2
1/10 2 0.41” 3” 76.1 2 0.91
2/10 3
3/10 4
3/8 6
1/2 10
HVB (2500 Volts)
1/2 1-1/2
3/4 2 0.41” 4.5” 114.2 3 1.36
13
HVJ (5000 Volts)
1/16 1-1/2
1/8 2
1/4 4 0.81” 5” 126.9 9 4.08
1/2 6
3/4 10
1—
HVL (10,000 Volts)
1/16 1
1/8 1-1/2
1/4 2
0.81” 10” 253.8 15 6.80
1/2 3
HVR (1000 Volts) (max. S.C. KVA-500)
1/2 3
14 0.41” 3” 76.1 3 1.36
25
HVT (2500 Volts) (max. S.C. KVA-1250)
1/2 3
15 0.41” 4.5” 114.2 4 1.81
2—
HVU (5000 Volts) (max. S.C. KVA-2500)
1/2 3
14 0.81” 5” 126.9 19 8.62
25
HVW (1200 Volts) (max. S.C. KVA-5000)
1/2 3
14 0.41” 2.25” 57.1 2 0.91
25
8
HVX (10,000 Volts) (max. S.C. KVA-12,000)
1/2 3
15
0.41” 10.0” 253.8 36 16.33
*Shipping.
Carton quantity: 10.
Test Spectifications
Catalog
Number Load Opening Time
HVA
HVB 110% 4 Hours (min.)
HVJ 135% 1 Hour (max.)
HVL
HVR
HVT
100% 4 Hours (min.)
HVU
150% 1 Hour (max.)
HVW
HVX
}
}
12-21-98
SB98107
Rev. A
Buss High Voltage Fuses HV
1000 - 10,000 Volts
Series
Bussmann
®
Form No. HV Series
Page 2 of 2
BIF Doc #6003
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this BIF document are by definition uncontrolled. This bulletin is intended to
clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any
products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
CATALOG SYMBOL: 4528, 4529, 4530, AND 2960
FUSE BLOCKS
For BUSS High Voltage Fuses
(1000 to 10,000 Volts)
• Bakelite base.
• Alloy plated terminals.
*Dimensions
For Bock Inches/(mm’s)
Fuse Cat. Base
Sym. No. A B C Width
HVA
4528
3.75” 1.125” 0.38” 1.0”
HVR (95.3) (28.6) (9.5) (25.4)
HVB
4529
5.25” 1.125” 0.38” 1.0”
HVT (133.4) (28.6) (9.5) (25.4)
HVJ
4530
6.5” 1.66” 0.5” 1.38”
HVU (165.1) (42.1) (12.7) (34.9)
HVL
2960
11.44” 1.45” 0.75” 1.38”
HVX (290.5) (48.4) (19.1) (34.9)
*Two mounting holes:
Use #8 screws on blocks 4528 and 4529.
Use #10 screws on blocks 4530 and 2960.
C
A
B
Dimensional Data
CURRENT IN AMPERES
TIME IN SECONDS
.02
.1
1
10
20
300
100
10
1
.1
.01
AMPERE
RATING
1/16
1/4
1/2
3/4
1
2
3
Time-Current Characteristic Curves—Average Melt
