Bushnell 360200 User Manual

GPS

MADE SIMPLE!

N E V E R G E T L O S T A G A I N

Model #: 360200

Quick Start Guide

Lit# 98-1586/04-10

Full Instruction Manual available online at:

www.bushnell.com/manuals/gps

Control & Display Guide

POWER Button

Battery Indicator

MARK Button

Local Time

DOWN Button

Location Memory Icon

(1 of 5 shown)

Satellite Locked Icon

Direction to Location

UP Button

Distance to Location

Note: Control Buttons are located on the sides of the BackTrack

Lock Position

1. Open the battery cover and insert two AAA batteries.

Hold POWER Button

Unlock Position

GPS Satellite

Reception Icon

Take the

BackTrack

Outdoors

2. Hold POWER button (until the display appears) to turn on the BackTrack. When satellite icon stops blinking, it is ready to use (be sure you are outdoors with a clear view of the sky).

Icons indicate button functions in Setup mode

Time Set

Temp Units

Press UP

Settings Mode

3. The Location screen will display when ﬁrst turned on. The time is displayed but may need to be adjusted for your time zone. Go to Settings Mode to change the time (as well as other units of measurement). Press UP button on right side of unit to access Settings Mode.

Press MARK

DOWN

Time Set Screen

4. Press the MARK button to go to the Time Set screen. Press the UP or DOWN button to set the correct hour. The minutes are automatically set via GPS satellite data. After you’ve set the hour, press MARK to conﬁrm the setting.

Hour Format Distance Units

Press the UP/DOWN buttons to set the hour, then press MARK to conﬁrm and return to Settings Mode
