BOOM MOWER

HYDRAULIC BOOM CUTTER

Published 04/11

PARTS MANUAL

SECTION 93

PARTS ORDERING GUIDE

The following instructions are offered to help eliminate needless delay and error in pro­cessing purchase orders for the equipment in this section.

1. The Parts Section is prepared in logical sequence and grouping of parts that belong
to the basic machine featured in this manual. Part Numbers and Descriptions are given
to help locate the parts and quantities required.

2. The Purchase Order must include the name and address of the person or organiza­tion ordering the parts, who should be charged, and if possible, the serial number of the
machine for which the parts are ordered.

3. The Purchase Order must clearly list the quantity of each part, the complete and correct
part number (be sure to include all periods), and the basic name of the part.

4. The Manufacturer reserves the right to substitute parts where applicable.

5. Some parts are unlisted items which are special production items not normally stocked
and are subject to special handling. Request a quotation for such parts before sending
a Purchase Order.

6. The Manufacturer reserves the right to change prices without prior notice.
For maximum safety and to guarantee optimum product reliability, always

use genuine BUSH HOG Parts. The use of inferior replacement parts may
causepremature or catastrophic failure which could result in serious injury
or death.Direct any questions regarding parts to:

BUSH HOG

2501 Griffin Ave.
Selma, AL 36703
www.bushhog.com
Contact Us
800-304-2836

©2009 Alamo Group Inc.

To the Owner/Operator/Dealer

All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded
operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has
designed this implement to be used with all its safety equipment properly attached to minimize the chance of
accidents.

BEFORE YOU STAR T! Read the safety messages on the impl ement and shown in your manual. Observe the rules
of safety and common sense!

WARRANTY INFORMATION:
Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty RegistrationForm in
full and return it to within 30 Days. Make certain the Serial Number of the Machine is recorded on theWa rranty Card and
on the Warranty Form that you retain.

LIMITED WARRANTY

2222222222222222222222222222222

Bush Hog warrants to the original purchaser of any new Bush Hog equipme nt, purchas ed from an au thorized Bush
Hog dealer, that the equipment be free from defects in material and workmanship for a period of one (1) year for
non-commercial, state and municipalities’ use and ninety (90) days for commercial use from date of retail sale. The
obligation of Bush Hog to the purchaser under this warranty is limited to the repair or replacement of defective
parts.

Replacement or repair parts installed in the equipment covered by this limited warranty are warranted for ninety
(90) days from the date of purchase of such part or to the expiration of the applicable new equipment warranty
period, whichever occurs later . Warranted parts shall be provided at no cost to the user at an authorized Bush Hog
dealer during regular working hours. Bush Hog reserves the right to inspect any equipment or parts which are
claimed to have been defective in material or workmanship.

DISCLAIMER OF IMPLIED WARRANTIES & CONSEQUENTIAL DAMAGES

Bush Hog’s obligation under this limited warranty, to the extent allowed by law , is in lieu of all warranties, implied or
expressed, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE and any liability for incidental and consequential damages with respect to the sale or
use of the items warranted. Such incidental and consequential damages shall include but not be limited to:
transportation charges other than normal freight charges; cost of installation other than cost approved by Bush
Hog; duty; taxes; charges for normal service or adjustment; loss of crops or any other loss of income; rental of
substitute equipment, expenses due to loss, damage, detention or delay in the delivery of equipment or parts
resulting from acts beyond the control of Bush Hog.

THIS LIMITED WARRANTY SHALL NOT APPLY:

1. To vendor items which carry their own warranties, such as engines, tires, and tubes.

2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident.

3. If parts not made or supplied by Bush Hog h ave been us ed in connection with the unit, if, in the sole judgement
of Bush Hog such use affects its performance, stability or reliability.

4. If the unit has been altered or repaired outside o f an authorized Bush Hog de alership in a man ner which, in the
sole judgement of Bush Hog, affects its performance, stability or reliability.

5. To normal maintenance service and normal replacement items such as gearbox lubricant, hydraulic fluid, worn
blades, or to normal deterioration of such things as belts and exterior finish due to use or exposure.

6. To expendable or wear items such as teeth, chains, sprockets, belts, springs and any other items that in the
company’s sole judgement is a wear item.

NO EMPLOYEE OR REPRESENTATIVE OF BUSH HOG IS AUTHORIZED TO CHANGE THIS LIMITED
WARRANTY IN ANY WAY OR GRANT ANY OTHER WARRANTY UNLESS SUCH CHANGE IS MADE IN
WRITING AND SIGNED BY BUSH HOG’S SERVICE MANAGER, 2501 GRIFFIN AVE., SELMA, ALABAMA

36703.

2222222222222222222222222222222

Record the model number, serial number and date
purchased. This information will be helpful to your
dealer if parts or service are required.

MODEL NUMBER ________________________________
SERIAL NUMBER ________________________________
DATE OF RETAIL SALE ___________________________

MAKE CERTAIN THE WARRANTY
HAS BEEN FILED WITH BUSH HOG
SELMA, ALABAMA

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

APRIL, 2011

ALPHABETICAL INDEX

RMB11865 / 1865E BOOM MOWER

ITEM PAGE NUMBER

100 LPM DRIVE MODULE - SUPERCUT AND MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-44

CAB CONTROL MOUNT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-38

CABLE ACV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-36

CABLE RCV ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-34

CASING - SUPERCUT FLAILHEAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1- 43

DIPPER ARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-5

FILTER AND DIFUSER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-16

FLAIL HEAD - MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-50

FLAILHEAD - SUPERCUT (47” WIDE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-42

FRONT FLAP KIT, SUPERCUT AND MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-48

GEARBOX ASSEMBLY - PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-26

GUARD KIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-39

HEAD, ANGLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-6

HOSE KIT RMB1865 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-29

HOSE KIT RMB1865E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93-1-30

HYDRAULIC CYLINDER - ANGLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-23

HYDRAULIC CYLINDER - LIFT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-22

HYDRAULIC CYLINDER - REACH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-21

HYDRAULIC CYLINDER - SLEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93-1-20

HYDRAULIC HOSES AND FITTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93-1-18

HYDRAULIC TANK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-14

LIFT FLOAT KIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93-1-56

LIGHT KIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-58

MAIN ARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-4

MAIN FRAME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-10

MOTOR COVER - MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-54

MOTOR COVER 1.2M SUPERCUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-46

PILLAR, RH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-8

PUMP AND GEARBOX ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-24

PUMP ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-28

QUAD DRIVE MODULE - MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-53

ROLLER 1.2 SUPERCUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-47

ROLLER ASSEMBLY - MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-52

ROTOR MODULE - MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-51

ROTOR MODULE - SUPERCUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-45

SAFETY DECALS (BOOM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-1

SAFETY DECALS (CUTTER HEAD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-2

SHEARTRIM SICKLEBAR (59” WIDE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-40

SHIELDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-12

SKID KIT - MULTICUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-55

SKID KIT, SUPERCUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1- 49

STABILIZER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-1-3

SWITCHBOX ASSY. RMB1865E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93-1-33

VALVE ASSEMBLY RMB1865E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93-1-32

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-1

APRIL, 2011

SAFETY DECALS (BOOM)

REF. PART

NO. NO.

DESCRIPTION QTY.

1 D433 Decal, Multi Hazard 1
2 D388 Decal, Driveline Hazard 1
3 D355 Decal, Important Check Chains 1
4 02962764 Decal, Warning Pinch Point 6
5 02962765 Decal, Danger Crushing Hazard 1
6 02965262 Decal, Warning Oil Leak 1
7 D354 Decal, Danger Crushing Hazard 1
8 50065309 Decal, Bush Hog Logo 14.85” 1

9 50068739 Decal, Model No. 1865 2
10 50061049 Decal, Bush Hog Logo (22”) 1
11 D524 Booklet, Safety 1
12 83380 Reflector, Smv Triangle 1
13 D569 Decal, Warning Oper. Only Wit Cab Tractor 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-2

APRIL, 2011

SAFETY DECALS (CUTTER HEAD)

REF. PART

NO. NO.

DESCRIPTION QTY.

1 50061049 Decal, Bush Hog Logo (22”) 1
2 24028 Decal, Deflector Warning 1
3 02965141 Decal, Warning Thrown Objects 1
4 1290738 Decal, Instruction 1
5 09.821.35 Decal, Instruction Multi 1
6 1458392 Reflector, Red 2
7 1458393 Reflector, Yellow 2
8 09.810.01 Decal, Instruction Grease 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-3

APRIL, 2011

STABILIZER

REF. PART

NO. NO.

DESCRIPTION QTY.

1 431217 Linch Pin, Med.7/16 2
2 21160.03 Pto Hook Support-Plated 1
3 21370.07 Top Link Assy - 357 To 517mm 1
4 21388.01 Plastic Insert 45mm Dia 4
5 21883.01 Sleeve Hfs Tube 38.6 X 6.3 Wal 1
6 22072.01 Quadrant Pin-Stabilizer 1
7 41205.13 Narrow Nose Stabilizer W.A. 1
8 45999.04 Spacer 55 X 40.5 X 9 2

9 45999.05 Spacer Sleeve 2
10 7196045 Hose Tie- 350.0lg 1
11 7499506c Stabilizer Tongue Cat.3-Cast 1
12 7560144 Pin-Top Link 2
13 9100108 Flatwasher M20 2
14 9100109 Flatwasher M24 Bzp 2
15 9163008 Nyloc Nut M20 2
16 9163009 Nyloc Nut M24 2
17 9213228 Bolt 2
18 9213309 Capscrew M24 X 150 2
19 0425540 Roll Pin M5 X 40 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-4

APRIL, 2011

MAIN ARM

REF. PART

NO. NO.

DESCRIPTION QTY.

1 0901121 Grease Nipple,1/8 2
2 22522.01 Hose Guard W/A Black 1
3 45202.06 Lift Base Pin W/Assy 2
4 45318.05 Main Arm RMB1865/RMB1865E 1
5 06.430.18 Clamp,Lower Hose 2
6 7115208 Bushing 40 X 44 X 40 4
7 7193063 1"Bsp Pair Hose Clamps 2
8 9100105 Flatwasher 10.5 X 23.5 X 2.0 2

9 9100404 Washer, M8 External Shakeproof 2
10 9163005 Nut M10 Nyloc 4
11 9213205 Capscrew M10 X 100 2
12 9313055 Capscrew M10 -1.5 X 25 2
13 9343184 Capscrew M8 X 90 Bzp 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-5

APRIL, 2011

DIPPER ARM

REF. PART

NO. NO.

DESCRIPTION QTY.

1 08.297.04 Bushing 37 X 30 X 30 2
2 0901121 Grease Nipple,1/8 5
3 22522.04 Hose Guard W/A Black 1
4 42684.07 Pin W/A Dipper Ram 1
5 45063.14 RH Dipper Arm W.A. 1
6 45202.01 Pin W/A - T/Link Outer 1
7 45264.03 Main Pivot Pin 1
8 45630.01 Clamp,Hose 4

9 7136035 Bushing,Flail Head 2
10 9100105 Flatwasher, 10.5 X 23.5 X 2.0 2
11 9100206 Lockwasher 12mm 1
12 9100404 Washer, M8 External Shakeproof 2
13 9163005 Nut M10 Nyloc 4
14 9213136 Capscrew M 12-P1.75 X 65mm 1
15 9213205 Capscrew M10 X 100 2
16 9243154 Capscrew M8 X 75 Lg Bzp 2
17 9313055 Capscrew M 10-P1.50 X 25mm 5 2
18 41741.16 Edging Strip - 160mm Lg 1
19 8629218 Seal,Lip 30 X 40 X 4 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-6

APRIL, 2011

HEAD, ANGLING

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-7

APRIL, 2011

HEAD, ANGLING

REF. PART
NO. NO. DESCRIPTION QTY.

1 0423556 Spring Dowel 5/8in X 3-1/2in 1
2 05.281.18 Flat Washer 30mm - Plated 2
3 08.297.04 Bushing 37 X 30 X 30 4
4 0901121 Grease Nipple,1/8 2
5 42646.03 Radius Arm 1
6 42646.04 Radius Arm 1
7 21801.01 Slave Link Casting 1
8 42648.01c Jaw Plt Cast 30.0 Pivots 1

9 42649.01 Pivot Tube 1
10 42684.01 Pin 1
11 42684.05 Pin - 30mm X 116 Lg 1
12 43055.09 Hose Brkt 1.5/16 Jic 1
13 7198333 Hose Tray 1
14 9100028 Nut 2
15 9100105 Flatwasher 10.5 X 23.5 X 2.0 4
16 9163005 Nut M10 Nyloc 6
17 9200023 Bolt Ht M16 X 1.5p X 55lg 1
18 9200028 Bolt 1
19 9213205 Bolt M10 X 100 1
20 9313065 Capscrew M 10-P1.5 X 30mm Pl5 4
21 9313075 Capscrew M 10-P1.50 X 35mm 5 1
22 0425540 Roll Pin M5 X 40 2
23 02971717 Roll Pin M6 X 50 1
24 8629218 Seal, 30 X 40 X 4 4

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-8

APRIL, 2011

PILLAR, RH

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-9

APRIL, 2011

PILLAR, RH

REF. PART

NO. NO. DESCRIPTION QTY.

1 0901121 Grease Nipple, 1/8 6
2 45192.10 RH Pillar 1
3 45202.04 Pin W/A - Slew Rod 1
4 45202.07 Pin W/A - Left Ram Base 1
5 45264.03 Main Pivot Pin 1
6 45271.01 Pivot Pin 2
7 45298.01 Thrust Washer 75 X 41 X 5 1
8 45416.01 Screw, Special M12 X 40 Drilled 1

9 9100206 Lockwasher, 12mm 1
10 9163005 Nut M10 Nyloc 2
11 9163006 Nut Nyloc M12 2
12 9213136 Capscrew M 12-P1.75- 65mm 1
13 9313075 Capscrew M 10-P1.50- 35mm 2
14 9313076 Capscrew M 12-P1.75- 35mm 1
15 9501255 Cotter Pin 4mm X 25mm 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-10

APRIL, 2011

MAINFRAME

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-11

APRIL, 2011

MAINFRAME

REF. PART
NO. NO. DESCRIPTION QTY.

1 0431105 Pin, Cotter 2
2 0431217 Linch Pin, Med.7/16 2
3 0901121 Grease Nipple, 1/8 1
4 41559.01 Linkage Pin Cat 2 2
5 43332.01 Spacer, 15 Lg. 2
6 43332.02 Spacer, 10 Lg. 2
7 45193.10 RH Mainframe 1
8 45202.05 Pin 1

9 45210.01 Plug, Plastic, Square 6
10 45293.01 Stand Leg Lh 1
11 45293.02 Stand Leg Rh 1
12 45297.01 Leg Pin 2
13 7115208 Bushing 40 X 44 X 40 Glacier 2
14 7136330 Driveline, 27 Pin Ctrs 1
15 9113008 Nut M 20 - P2.5 1
16 9163005 Nut M10 Nyloc 1
17 9313075 Capscrew M10-P1.50- 35mm 1
18 9313118 Capscrew M20 X 55 (Coarse) H.T. 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-12

APRIL, 2011

SHIELDING

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-13

APRIL, 2011

SHIELDING

REF. PART

NO. NO. DESCRIPTION QTY.

1 21612.01 Pop Rivet Dia 4.8 X 16 Lg 4
2 21726.31 Sponge Pad 2
3 22472.02 RH Cover & Valve Mtg 1
4 22476.04 RH Rear Cover W.A. 1
5 22477.03 Tank Top Cover 1
6 22513.02 RH Valve Cover 1
7 22531.01 Blanking Plate-Rear Cover 1
8 43449.02 Overcentre Fastener 1

9 46007.01 Hook-Small 1
10 9100105 Flatwasher, 10.5 X 23.5 X 2.0 4
11 9100205 Lockwasher- 10mm Dia. Bzp 4
12 9300164 Taptite M6 X 12 4
13 9313035 Capscrew M 10-P1.50- 16mm 4
14 21726.34 Foam Strip 275mm Lg 1
15 21726.35 Foam Strip 410mm Lg 1
16 22549.01 Short Nose,Slotted Head Size 8, 4
17 22549.02 Fast Turn Size 8 Slip On 4
18 22549.03 Fast Turn Plastic Retainer 4

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-14

APRIL, 2011

HYDRAULIC TANK

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-15

APRIL, 2011

HYDRAULIC TANK

REF. PART

NO. NO. DESCRIPTION QTY.

1 05.131.01 Adaptor 1" X 1.1/4" Bsp 1
2 21612.02 Pop Rivet Dia 4.8 X 16 Lg 3
3 22470.04 Tank W.A.-RH Pa47,Pa50 & Eco 1
4 22530.01 Rivet Washer-For 4.8 Dia Rivet 3
5 46505.01 Plastic Manual Holder Us 1
6 8401048 Gauge,Level 1
7 8401050 Asy, Filler Breather Ucp Ab 13 1
8 8401088 Filter Assy Incl Diffuser 1

9 8401097 Suction Stranier 125 Micron 1
10 8581260 Adp.Hyd. 1-1/4bsp X 1-1/2bsp 1
11 8650109 1-1/4 bsp Bonded Seal 1
12 9100204 Spring Washer 8mm 2
13 9163007 M16 Nyloc Nut 3
14 9313064 Capscrew M8 X 30 (Coarse) 2
15 9313097 Capscrew M16 X 45 Coarse H.T. 3
16 8700784 O Ring 202-784-4480 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-16

APRIL, 2011

FILTER AND DIFUSER ASSEMBLY

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-17

APRIL, 2011

FILTER AND DIFUSER ASSEMBLY

REF. PART

NO. NO. DESCRIPTION QTY.

1 8401089 Filter Element 1
2 8401092 Filter Lid Spring 1
3 8401093 Fitler Housing Seal 1
4 8700235 O-Ring 200-235-4480 1
5 8700092 O-Ring 204-192-4480 1
6 212.013.04 Filler Cap 1
7 8401103 Moulded Seal For 8401088 1
8 8401104 Plastic Filter Housing 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-18

APRIL, 2011

HYDRAULIC HOSES AND FITTINGS

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-19

APRIL, 2011

HYDRAULIC HOSES AND FITTINGS

REF. PART

NO. NO. DESCRIPTION QTY.

1 45288.10 Hydraulic Cylinder Assy -Slew 1
2 45288.09 Hydraulic Cylinder Assy -Reach 1
3 45895.10 Hydraulic Cylinder Assy - Lift 1
4 43317.10 Hydraulic Cylinder Assy - Angle 1
5 08.955.45 Adapter Mm 1 5/16"-12 Jic 2
6 0904107 Hose Clips 40-55 Mm *Bi* 4
7 22590.19 Hose Sleeving FC425-59 950 Lg 1
8 22590.20 Hose Sleeving FC425-59 1000 Lg 1

9 22591.03 Hose Sleeving FC425-40 150 Lg 1
10 8501470 Bore Suction Hose 1 1/2" - 470 Mm Long 1
11 8581264 Elbow 1" Bsp M-Fln 90 Swept 1
12 05.433.17 Blanking Cap 1 5/16" Jic 2
13 8581233 Swivel Adp. 1bsp-F X1-5/16-M 1

7135084 Hose Tie 180.0 Lg (Not Shown) 3
7196045 Hose Tie- 350.0lg (Not Shown) 4

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-20

APRIL, 2011

HYDRAULIC CYLINDER - SLEW

REF. PART

NO. NO. DESCRIPTION QTY.

1 45288.05p Slew Ram Assy-Painted 1

8699525 Kit, Seal, Slew Ram 1
2 08.297.05 Bushing,Plastic 42 X 35 X 30 4
3 8650103 Seal,3/8bsp Bonded 4
4 08.955.06 Adaptor 1
5 8124121 Restrictor 3/8 Bsp-9/16 Jic 1
6 08.200.01 Valve, Ball 1
7 6000113 3/8 Bsp Double Male 1
8 8581178 Union,Swivel 3/8bsp M-F 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-21

APRIL, 2011

HYDRAULIC CYLINDER - REACH

REF. PART

NO. NO. DESCRIPTION QTY.

1 45288.04p Hydraulic Cylinder Assy-Painted 1

8699258 Kit, Seal 1
2 08.297.05 Bushing, Plastic 42 X 35 X 30 4
3 08.955.06 Adaptor 2
4 8650103 Seal, 3/8 Bsp Bonded 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-22

APRIL, 2011

HYDRAULIC CYLINDER - LIFT

REF. PART

NO. NO. DESCRIPTION QTY.

1 45895.04p Hydraulic Cylinder Assy - Lift 1

43315.01 Kit, Seal, Lift Cylinder 1
2 08.297.05 Bushing,Plastic 42 X 35 X 30 5
3 6000113 Adapter Double Male 3/8 Bsp 1
4 08.955.06 Adaptor 2
5 8650103 Seal, 3/8 Bsp Bonded 4
6 8581178 Union,Swivel 3/8 Bsp M-F 1
7 08.200.01 Valve, Ball 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-23

APRIL, 2011

HYDRAULIC CYLINDER - ANGLE

REF. PART

NO. NO. DESCRIPTION QTY.

1 43317.02p Hydraulic Cylinder Assy - Angle 1

43317.01 Kit, Seal, Angle Ram 1
2 08.955.06 Adaptor 2
3 8650103 Seal, 3/8 bsp Bonded 2
4 08.297.04 Bushing 37 X 30 X 30 4
5 0901121 Grease Nipple, 1/8 2
6 8629218 Seal,Lip 30 X 40 X 4 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-24

APRIL, 2011

PUMP AND GEARBOX ASSEMBLY

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-25

APRIL, 2011

PUMP AND GEARBOX ASSEMBLY

REF. PART

NO. NO. DESCRIPTION QTY.

1 21931.01 Gearbox 4.25:1 13t 1
2 8201700 Pump,Tandem Iron 1
3 8005052 Pressure Connection Kit 1
4 42029.01 Flange-Pump Port 1/2" Bsp 1
5 9313085 Capscrew M10 X 40 (Coarse) H.T. 4
6 9300147 Socket Capscrew M8 X 20 4
7 8600304 O-Ring 2 Idx2-1/4 Od 1
8 8600405 O-Ring 1-1/16 Id X 1-1/4 Od 1

9 9100205 Lockwasher - 10mm Dia. 4
10 9100105 Flatwasher, 10.5 X 23.5 X 2.0 4
11 9243126 Capscrew M12 X 60 Skt. 3
12 8650104 Seal, 1/2bsp Bonded 1
13 8650106 Seal, 3/4bsp Bonded 1
14 42142.02 Block Suction Taper 1
15 8581367 Adaptor 1-1/4" Bspt X 1-1/2" L.P 1
16 8120003 Adapter St 3/4 Jic-M X 1/2 Bsp-M 1
17 8581192 Adapter 16 M Jic - 12 M Bspp 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-26

APRIL, 2011

GEARBOX ASSEMBLY - PARTS

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-27

APRIL, 2011

GEARBOX ASSEMBLY - PARTS

REF. PART

NO. NO. DESCRIPTION QTY.

1 8013530 Cap-80mm Dia 1

2 8013529 Internal Circlip 80mm Dia 2

3 8013528 Bearing 2

4 8013585 Gearbox Casting 1

5 8013533 Drain Plug 2

6 8013575 Shaft 1

7 8013586 Driveshaft Key 1

8 8013526 Shaft Seal 1

9 8013525 Internal Circlip 90mm Dia 2

10 8013524 Bearing Larger 2
11 8013522 Input Shaft 1
12 8013587 Primary Gear 1
13 8013534 Level Plug 2
14 8013589 Gearbox Cover 1
15 9313033 Setscrew 6
16 8013590 Breather 1/2" Bsp 1
17 8013591 Sealing Washer 5
18 8013592 Oil Plug 1
19 8013576 Ring 1
20 8013593 Oil Plug 1
21 8013527 Cap-90mm Dia 1
22 8013594 Oil Plug 1
23 8699264 Gearbox Seal 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-28

APRIL, 2011

PUMP ASSEMBLY

PART DESCRIPTION QTY.

NO.

8201700 Tandem Pump Assy 1
8201165 Pump (Front Half Of 8201685) 1
8699234 Seal Kit For Pump 8201685 1
8201728 Rear Pump For 8201700 For Unts 1
8201729 Parker Male Male Coupling For 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-29

APRIL, 2011

HOSE KIT - RMB1865

REF. PART

NO. NO. DESCRIPTION QTY.

1 08.961.01 Hose 1bore X 500 Jic 90 xst 1
2 08.961.02 Hose 1 5/16"JIC Fs/F 90 550 mm Lg 1
3 41677.08 Hose 1.5/16" JIC Fs/F 135 1900 Lg Hos 2
4 08.961.48 Hose 1 Bore X 3700mm 2
5 08.958.06 Hose 3/4" JIC Fs/F90 X 400 1
6 41671.11 Hose 7/8"JIC Fs/F90 550 MM Lg 1
7 41721.31 Hose 9/16" JIC Fs/Fs 2100 MM Lg 1
8 08.957.36 Hose 9/16” JIC FS/F90 2800MM Lg 1

9 08.957.55 Hose 9/16” JIC FS/F90 4700MM Lg 2
10 08.957.20 Hose 1/4 Bore X 1200 MM 1
11 41721.22 Hose 9/16" Fs/Fs 1200 Lg 1
12 08.957.16 Hose 9/16" Jic Fs/F90 900 Lg 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-30

APRIL, 2011

HOSE KIT - RMB1865E

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-31

APRIL, 2011

HOSE KIT - RMB1865E

REF. PART QTY.

NO. NO. DESCRIPTION REQ’D.

1 08.961.01 Hose,1bore X 500 Jic 90xst 1
2 08.961.02 1 5/16"Jic Fs/F90 550mm Lg 1
3 41677.08 1.5/16" Jic Fs/F135 1900lg Hos 2
4 08.961.48 1 5/16" Jic Fs/F90 3700 Lg 2
5 08.958.08 Hose 3/8 Bore X 500mm 1
6 41671.14 Hose 1
7 41721.29 Hose 9/16" Jic Fs/Fs 1900 Lg 1
8 08.957.34 Hose,1/4bore X 6500 Stx 90 Jic 1

9 08.957.53 Hose 1
10 08.957.18 Hose 1
11 41721.20 Hose 1
12 08.957.12 1/4 Bore Hose 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-32

APRIL, 2011

VALVE ASSEMBLY - RMB1865E

REF. PART QTY.

NO. NO. DESCRIPTION REQ’D.

1 22516.01 Valve Mtg Plate 1
2 22523.12 Manifold Assy 1
3 22524.47 Adaptor Kit 1
4 22525.20 Solenoid Kit 1
5 8130092 Valve 1
6 9100105 Flatwasher,10.5 X 23.5 X 2.0 6
7 9100205 Lockwasher - 10mm Dia. 2
8 9163005 Nyloc Nut M10 4
9 9313065 Capscrew M10 - P1.5 - 30mm 6

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-33

APRIL, 2011

SWITCH - RMB1865E

REF. PART QTY.

NO. NO. DESCRIPTION REQ’D.

1 22698.13 XTC Control Module 1
2 1290717 Decal 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-34

APRIL, 2011

CABLE RCV ASSEMBLY

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-35

APRIL, 2011

CABLE RCV ASSEMBLY

REF. PART

NO. NO. DESCRIPTION QTY.

1 8125356 Valve,Rotor Control (190 Bar) 1

2 8650106 Seal,3/4bsp Bonded 6

3 9213085 Capscrew M 10-P1.5 - 40mm Pl 2

4 9163005 Nut M10 Nyloc 2

5 8017052 Control Hd/Cable Assy-3.5m 1

6 8581224 Extension Adapter 3/4"Bsp M-F 1

7 9213113 Capscrew M6 X 55 (Coarse) H.T. 3

8 9163003 Nut M6 Nyloc 3

9 7650282 Control Cable Brkt 1
10 9313034 Capscrew M 8-P1.25 X 16mm 2
11 9113004 Nut 8mm-P1.25 Pl 2
12 8581271 Adapter 3/4 M Bsp-7/8 M Jic 1
13 8581192 Adapter 16 M Jic - 12 M Bspp 4

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-36

APRIL, 2011

CABLE ACV

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-37

APRIL, 2011

CABLE ACV

REF. PART

NO. NO. DESCRIPTION QTY.

1 8130466 Control Valve 4 Spool 1
2 8130124 Relief Valve Cartridge 1
3 8116011 Spring .275x23 Swgx5/8 Lg 2
4 8130156 Relief Valve Housing 1
5 8130083 Body, Relief Valve 1
6 8650103 Seal, 3/8 Bsp Bonded 11
7 8650104 Seal, 1/2 Bsp Bonded 1
8 8017050 Control Hd/Cable Assy-3.5m 4

9 8650102 Seal, 1/4 Bsp Bonded 3
10 8130067 Restrictor 1/4-3/8 Bsp 1
11 6000113 Adaptor 3/8 Bsp M/M 1
12 05.123.01 Adaptor 1/2 X 3/8 Bsp M/M 1
13 8581115 Adaptor, 1/4 X 3/8 Bsp Male 1
14 8581254 Tee Adaptor 1/4 Bsp M-F-M 1
15 04.282.71 Stud M6 X 233 Plated 3
16 7650307 Arm Rest Brkt W/A 1
17 1290368 Decal, Control 1
18 1290541 Decal-Slew Sma1046 1
19 8581209 Union 3/8 Bspm X 3/8 Bspm 1
20 8581214 Restrictor Adaptor 1/4" Bsp 1
21 8123044 Restrictor Disc, 1.8mm Orifice 1
22 9343022 Shcs Metric 5-P0.8 - 12mm Pl9 8
23 9213134 Bolt 3
24 9163004 Nut Nyloc M8 3
25 9313034 Capscrew M 8-P1.25- 16mm 2
26 9113004 Nut 8mm-P1.25 Pl 2
27 04.056.25 Tee 1/2 - 1/2 - 1/4 Fmm 1
28 8581117 Connector,3/8 Bsp 90deg. 1
29 9163003 Nut M6 Nyloc 6
30 1290338 Decal,Rotor Control Valve 1
31 8124120 Restrictor 3/8bsp-9/16jic 1
32 8124121 Restrictor 3/8 Bsp-9/16 Jic 2
33 8124118 Restrictor 3/8bsp-9/16jic 1
34 8124125 Restrictor 3/8" Bsp-9/16 Jic 1
35 05.835.11 Adaptor,Swivel 90-1/4 X 9/16 Jic 3
36 8581341 Adaptor 1/4 Bspfx 9/16 Jicm 2
37 8581220 Adaptor 1/2 Bspf-7/8jic M 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-38

APRIL, 2011

CAB CONTROL MOUNT

REF. PART

NO. NO.

DESCRIPTION QTY.

1 42491.01 Mount Plate 1
2 9100104 Flatwasher 8mm 2
3 9100204 Lockwasher 8mm 2
4 9193004 Wing Nut 2
5 9313054 Capscrew M8 x 25 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-39

APRIL, 2011

GUARD KIT

REF. PART

NO. NO.

DESCRIPTION QTY.

1 7313049 Guard Panel, Large Self Color 1
2 7313050 Guard Panel, Small- Self Color 1
3 6001064 Guard Spring 2
4 6001065 Guard Hook 6
5 41587.01 Guard Hook 6
6 41745.01 Hook,Plastic 8

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-40

APRIL, 2011

SHEARTRIM SICKLEBAR (59” WIDE)

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-41

APRIL, 2011

SHEARTRIM SICKLEBAR (59” WIDE)

REF. PART

NO. NO. DESCRIPTION QTY.

1 42018.05 Cutter Bar 1
2 42019.12 Cutterbar Brkt 80 Box Rh 1
3 08.961.02 1 5/16"Jic Fs/F90 550mm Lg 2
4 42844.01 Flow Control Valve 1
5 8581192 Adp Hyd Stght 16mj - 12mbspp 2
6 8650106 Seal, 3/4 bsp Bonded 3
7 T7560 Adaptor Tee 1"Bsp Fff 1
8 8002086 Adaptor 3/4" X 1" Bsp Mm 1

9 8581110 Male Union, 1/2 X 1/2 Bsp 2
10 8650104 Seal,1/2bsp Bonded 2
11 8581129 Adaptor 1"Bsp X 1/2" Bsp Mm 1
12 10.006.10 Hose 1/2bsp Stx90 S.Seal 500 2
13 06.282.03 Check Valve 1"Bsp Ff 1
14 46043.05 W/Assy-180 Deg Elbow 1
15 8650108 1bsp Bonded Seal 2
16 8581130 Adaptor 3/4 Bsp X 1/2 Bsp 1
17 G5200331 Adaptor-1/2"Bsp Mf Elbow Short 1
18 9213155 Capscrew M10 X 75 4
19 9143005 Use 00765676 4
20 09.821.35 Combined Decal 1
21 3688303 Decal, Danger Severed Fingers 1
22 1458392 Decal, Red Reflector 1
23 1458393 Decal, Yellow Reflector 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-42

APRIL, 2011

FLAILHEAD - SUPERCUT (47” WIDE)

REF. PART

NO. NO. DESCRIPTION QTY.

1 22494.11 1.2m Supercut Casing Module 1
2 22495.21 100lpm Drive Module 54hp 1.2m 1
3 22497.33 1.2m Rotor Assy S-Cut F91 Comp 1
4 22496.08 1.2m S/Cut Motor Cover Module 1
5 7193063 Pipe Clamp 91 Pair0 .38" Dia. 1
6 9213155 Capscrew M10 X 75 1
7 21917.02 Head Decal 1
8 22808.01 Roller Assy-1.2m Supercut 1

9 21978.10 Head Decal Kit Multicut 1
10 06.418.05 Clamp Plate - Pipe Clamp 1
11 50068703 Flap Kit, Front 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1- 43

APRIL, 2011

CASING - SUPERCUT FLAILHEAD

REF. PART

NO. NO. DESCRIPTION QTY.

1 7198327 Casing - 1.2m Supercut 1
2 7191352 Front Hood 1
3 7191116 Hood Pivot Pin 1
4 7191361 Flap,Rear 1
5 7198330 Clamp Plate 1
6 7198332 Clamp 2
7 7191362 Clamp Strip-Rear Flap 1
8 9313055 Hexb Metric 10-P1.50- 25mm 5 10

9 00765676 Nut, M10 - 1.5 10
10 0311106 Set Screw Hex Head 5/8 UNF 1-1/4 HT 2
11 00749136 Locknut 5/6-Nf Toplock 10
12 0425540 Roll Pin M5 X 40 1
13 0211226 Capscrew 5/8 In X 2 3/4 In Unf 4
14 0211246 Capscrew 5/8 In X 3 In Unf 4

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-44

APRIL, 2011

100 LPM DRIVE MODULE - SUPERCUT AND MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 8301302 Motor 1
2 7190015 Motor Locating Washer 1
3 7190584 Coupling 27 Spline 1
4 8650106 Seal,3/4bsp Bonded 2
5 8581567 Adaptor 3/4 X 1.5/16" Jic Mm 2
6 41677.08 Hydraulic Hose 1.5/16" Jic Fs/F135 1900lg 2
7 05.433.14 Plug 1.5/16" JIC 2
8 9300144 Capscrew,Wedglok 4

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-45

APRIL, 2011

ROTOR MODULE - SUPERCUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 7191382 Weldmt, Rotor 1.2m W/A 12 Row 1
2 7190261 Housing Bearing 2
3 7191109 Flail Bolt 24
4 9100205 Washer, Spring- 10mm Dia. Bzp 4
5 7191054 Spacer, Cast Flail 24
6 7198390 Single Edge Flail Knife 24
7 9313045 Capscrew M10-P1.5 - 20mm 5 4
8 0901125 Grease Fitting 1/8 4

9 7191098 Shim, 1.5 Thick 3
10 7191099 Shim, 2.5 Thick 3
11 8121043 Spacer, Thin- Ref. 96-033 5
12 8121044 Spacer Thick 5
13 0600018 Bearing 55x120x29mm 1r.15 2
14 7190022 120 Internal Circlip D1300-12 2
15 7190444 Plate,Cover 1
16 02716500 Locknut, Toplock 1/2" - 20 24
17 0100305 Washer, Serrated Int.1/2 Dia. 48
18 0311146 Hhss 5/8UNF 1-3/4ht 1
19 0311126 Hhss 5/8UNF X 1-1/2grs 5
20 00749136 Locknut, Toplock 5/8" UNF 6

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-46

APRIL, 2011

MOTOR COVER 1.2M SUPERCUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 7191393 Motor Cover 1
2 0311126 Capscrew 5/8” X 1/2” Unf 4
3 00749136 Locknut, Toplock 5/8" Unf 3
4 41740.01 Hose Retainer 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-47

APRIL, 2011

ROLLER 1.2 SUPERCUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 22808.02 Roller Tube 1
2 22808.05 Roller Shaft 1
3 22808.03 Roller Bracket Lh 1
4 22808.04 Roller Bracket Rh 1
5 22808.06 Seal Carrier 2
6 0600111 Deep Groove Ball Brg 30x62x17 2
7 8629215 Seal 2
8 8600422 O Ring 200-138-4490 2
9 0411262 Internal Circlip 62mm Dia 2

10 0412120 1-1/4 Internal Spirolox Ring 2
11 0901121 Grease Nipple,1/8 Straight 2
12 9213117 Bolt M16 X 55 2
13 9313097 M16 X 45 Coarse H.T. 2
14 9143007 Top Lock Nut 16mm-P2.0 Zp 4
15 42257.03 Shim-1.2mm 2
16 42257.04 Shim - 2.0mm 2
17 8629181 Seal,Rotary Shaft Dia 35 2
18 21395.03 Tab Washer-M24 Special 2
19 9100035 Nut M24 Lh Plated 30af 1
20 9100036 Nut M24 Rh Plated 30af 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-48

APRIL, 2011

FRONT FLAP KIT, SUPERCUT AND MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 7290053 Front Flap 8
2 7190304 Frontflap Strip 1
3 9293054 Carriage Bolt M8 X 25 (Plated) 16
4 70093C Locknut, Toplock M8 x P1.25 16
5 9100104 Flatwasher M8 16

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1- 49

APRIL, 2011

SKID KIT, SUPERCUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 7198368 Skid W/Assy-Left Hand 1
2 7198369 Skid W/Assy-Right Hand 1
3 7290391 Wear Strip 2
4 6012034 Bolt, Tine 7/16 UNC x 1-3/8 6
5 0100104 Washer 6
6 0311106 Capscrew 5/8unf 1-1/4ht 2
7 0311126 Capscrew5/8 UNF X 1-1/2grs 4
8 00749136 Locknut, 5/8 X P1.25 6
9 0141004 Locknut 7/16 Unf Standard 6

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-50

APRIL, 2011

FLAIL HEAD - MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 22494.05 1.2 M Dd F.Head Casing Module 1
2 21523.08 1.2 DMS Roller 1
3 50068703 Flap Kit, Front 1
4 22497.02 1.2 M Rotor Module F10s.E Cast 1
5 22498.03 Multicut Quad Drive Module 1
6 22496.04 RH 52-65hp Motor Cover Module 1
7 22495.21 100 lpm Drive Module 54hp 1.2m 1
8 21978.10 Head Decal Kit Multicut 1
9 22906.01 Shipping Stand, Flail Head 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-51

APRIL, 2011

ROTOR MODULE - MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 22269.01 Rotor 1.2m Quad Drive 1
2 9353097 M16x45 Skt.Csk.Screw Bzp. 4
3 7390276 Flail, Single Edge 24
4 0901161 Grease Nipple M6 X 1 Straight 1
5 7314223 Bushing, Flail Pivot 24
6 9143007 Top Lock Nut 16mm-P2.0 Zp 4
7 7314201 Capscrew 5/8 Nf 3-1/4 24
8 0100206 Lockwasher 5/8 Dia. 48
9 00749136 Locknut, Toplock 5/8" 24

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-52

APRIL, 2011

ROLLER ASSEMBLY - MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 21394.03 1.2m Roller W.Assy 1
2 21394.32 Roller End Cap 2
3 21524.12 Roller Bracket 1
4 21524.13 Roller Bracket 1
5 0600111 Deep Groove Ball Brg 30x62x17 4
6 21523.31 Bearing Spacer 2
7 0402240 1.687" Int.Spirolox Ring 2
8 9343105 M10 X 50 Skt Capscrew Bzp 6

9 9200031 M16 X 1.5 Grade 8.8 Bolt 60 Lg 4
10 9100024 Nut 4
11 0901121 Grease Nipple,1/8bsp-Straight 2
12 0401230 Circlip, External 30mm Dia. 2
13 8629239 Shaft Seal 40x50x7.0 Deep 2
14 42257.10 Shim 1.2m Dms Quad Drive 2

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-53

APRIL, 2011

QUAD DRIVE MODULE - MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 7190261 Housing Bearing 2
2 9100024 Nut 6
3 9200031 Capscrew M16 - 1.5 X 60 Grade 8.8 6
4 0901121 Grease Nipple,1/8bsp-Straight 2
5 0901125 Grease Fitting 1/8bspx45deg 2
6 9300144 Capscrew,Wedglok 4
7 7190292 Plate, Cover 1
8 9100205 Lockwasher 10mm Dia. Bzp 4

9 9313045 Capscrew M10-P1.5 X 20mm 4
10 0600018 Bearing 55x120x29mm 1r.15 2
11 22269.02 Drive Hub Quad Drive 1
12 7190022 120 Internal Circlip D1300-12 1
13 8121043 Spacer, Thin- Ref. 96-033 5
14 8121044 Spacer Thick 5

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-54

APRIL, 2011

MOTOR COVER - MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 42282.04 Motor Cover Rh 1
2 30.073.25 Capscrew M16 - 1.5p X 40 Lg 4
3 9100024 Locknut, Flanged M16-1.5p 5
4 9200034 Capscrew M 16 - 1.5p X 180 Lg 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-55

APRIL, 2011

SKID KIT - MULTICUT

REF. PART

NO. NO. DESCRIPTION QTY.

1 7290389 Skid R/H 1
2 7290390 Skid L/H 1
3 7290391 Wear Strip 2
4 6012034 Bolt, Tine 7/16 UNC x 1-3/8 6
5 0100104 Washer 6
6 0141004 7/16 Unf Standard 6
7 9313066 Hexb Metric 12-P1.75- 30mm Pl5 6
8 9100106 Washer, 12m Form A.Bzp 6
9 9143006 Nut Metric 12mm-P1.75 Pl 6

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-56

APRIL, 2011

LIFT FLOAT KIT

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-57

APRIL, 2011

LIFT FLOAT KIT

REF. PART

NO. NO. DESCRIPTION QTY.

1 8126044 Accumulator 1l 25 Bar Pc 1
2 8126318 Bracket Float Kit 1
3 G2410380 Adaptor 3/8 Bsp X M22 M-M 1
4 8650322 M22 Bonded Seal 1
5 8650103 Seal,3/8bsp Bonded 4
6 08.200.01 Valve, Ball 1
7 8581209 Union 3/8 Bspm X 3/8 Bspm 1
8 8123041 Disc, Restrictor-1.5mm Orifice 1

9 8116011 Spring .275x23 Swgx5/8 Lg 1
10 8581346 Adaptor Rest. Body 3/8mm 1
11 08.958.18 Hose 3/4" Jic Fs/F90 1000 1
12 11.068.69 Adaptor-Tee 3/8f-3/8m+3/8m 1
13 9163006 Nyloc Nut M12 2
14 9313056 Capscrew M12-P1.75- 25mm Pl5 2
15 8581221 Adaptor 3/8"Bsp F X 3/4" Jic M 2
16 8581117 Connector, 3/8 Bsp 90deg. 1

BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL

93-1-58

APRIL, 2011

LIGHT KIT

REF. PART

NO. NO. DESCRIPTION QTY.

1 21678.07 7 Pin Socket Plastic 12v 1
2 22342.01 Cable Tie-4.8 Wide X 120 Lg 12
3 22484.02 Light Guard & Mtg - Rear Cover 1
4 22487.01 Light Mounting Bracket 1
5 22488.01 Ns Light Guard & Mounting 1
6 45900.07 Lighting Kit 1
7 9100105 Flatwasher,10.5 X 23.5 X 2.0 2
8 05.287.09 Nyloc Nut M5 3

9 9163005 Nyloc Nut M10 2
10 9163006 Nyloc Nut M12 2
11 9313055 Capscrew M10-P1.50- 25mm 5 2
12 9213246 Capscrew M12 X 120 2
13 9243062 CapscrewM5 X 30 Socket 3
14 9300164 M6 X 12 Taptite 4

2501 Griffin Ave.• Selma, AL 36703

[phone] • [phone]

Parts Ordering 1-800-304-2836

Fax [phone]

www.bushhog.com
