Bush IDLCD2205HDV Instruction Manual

22

INSTRUCTION MANUAL

IDLCD2205HDV

The Gold Technical Support Line: 1902 215 259

Personal Product Support

(Charges will apply at $2.95 per minute)

INTRODUCTION

Thank you for buying this Bush product, which is designed to give you many years of
trouble-free service.

You may already be familiar with using a similar unit, but please take time to read
these instructions. They are designed to familiarise you with the unit s many features
and to ensure you get the very best from your purchase.

Safety is important

Your safety and the safety of others is important. Therefore, please ensure you read
the Safety Instructions before you operate this unit.

Warranty

In the unlikely event that your product fails to work normally, please call the below
Bush warranty number to discuss the problem with one of our qualified service
engineers.

Australia
Bush Warranty: 1800 509 394

New Zealand
Bush Warranty: 0800 450 259

-1-

CONTENTS

1. INTRODUCTION........................................................................1

2. SAFETY INSTRUCTIONS...........................................................3

3. INSTALLATION..........................................................................4

WALL MOUNTING INSTALLATION GUIDLINES............................ .4

ACCESSORIES...........................................................................5

FRONT PANEL............................................................................5

KEY BOARD................................................................................6

REAR PANEL..............................................................................6

ANTENNA CONNECTION.............................................................7

CONNECTING TO PC..................................................................8

PC PRESET................................................................................9

CONNECTING TO AV EQUIPMENTS...........................................10

4. REMOTE CONTROL................................................................. 11

BATTERY INSTALLATION......................................................... . .

KEYS FUNCTION.......................................................................

11

12

5. OPERATION..........................................................................

BASIC OPERATION...................................................................13

TELETEXT.................................................................................14

EPG..........................................................................................15

MENU OPERATION....................................................................16

...

13

6. DVD OPERATION ....................................................................20-27

7. TROUBLESHOOTING...............................................................28-29

8. TECHNICAL SPECIFICATION....................................................30

9. WARRANTY.............................................................................31

-2-

SAFETY INSTRUCTIONS

1. Do not use this apparatus near water.

2. Clean only with dry cloth.

3. Do not block any ventilation openings. Install in accordance with the manufacturers
instructions.

4. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.

5. Protect the power cord from being walked on or pinched particularly at plugs
convenience receptacles, and the point where they exit from the apparatus.

6. Only use attachments/accessories specified by the manufacturer.

7. Unplug this apparatus during lightning storms or when unused for long periods of

time.

8. Refer all servicing to a qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.

9. The apparatus should not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, should be placed on the apparatus.

10. If the television is to be built into a compartment or similar enclosed, the minimum

distances must be maintained. Heat build-up can reduce the service life of your
television, and can also be dangerous.

ADDITIONAL SAFETY NOTES

Never tamper with any components inside the TV, or any other adjustment controls not
mentioned in this manual.

All LCD-TVs are high voltage instruments. When you clean up dust or water drops on
the LCD PANEL or CABINET, the power cord should be pulled out from the receptacle,
then wipe the TV with a dry soft cloth.

During thunder and lighting, unplug the power cord and antenna cord to prevent
damage to your TV.

All repairs to this TV should only be performed by qualified TV service personnel.

-3-

INSTALLATION

INSTALLATION NOTES

This TV can b e connected t o AC 100-240 Volts. 50/60 Hz. Never connect toaDC
supply o r any other power supply.

Locate the TV i n the room where light does not strike the screen . Total darkness o r a
reflection o n the picture screen can cause eyestrain. Soft and indirect lighting i s
recommended for comfortable viewing.

Allow enough space between the T V and the wall to permit ventilation.

Avoid excessively warm locations to prevent possible damage to the cabinet or
premature component failure.

Do not cover the ventilation openings when using the TV.

WALL MOUNTING INSTALLATION GUIDELINES

This television can be wall mounted as follows:

1.Place the LCD Television ontoasolid surface. Please place some soft material t o
over the front of the screen to avoid any damage.

2.Remove the screws from the lower part of the television, where the base joins to the
TV, and take away the stand (put the stand somewhere safe for future use).

3.Use the four screws provided to fix the TV ontoawall mounting bracket via the 4
VESA standard holes on the back o f th e television.

100 mm

001 mm

-4-

ACCESSORIES

INTSTALLATION

AC Power Cord.........................

Infrared Remote Control............

User s Manual ........................

Battery(AAA)........................... 2

FRONT PANEL

1

1

1

3

4

30 30

POWER

1

4 5 6

7 8 9 0

TVMENU INPUT

DVBMENU

+

VOL

_

SLEEP ASPECT

INFO FAV EPG

REVEAL

HOLD LIST

SUBPAGE SIZE AUDIOSUBTITLE

2

1

1: Remote control sensor.

MUTE

NICAM

2 3

RECALL

ENTER

EXIT

SOUND

+

CH

PIC

_

TEXTDISPLAYSOURCE

INDEX

2: Indicator LED: GREEN POWER ON.

RED STANDBY.
3: Key board(see next page).
4: Power: Press this button to the status

of , the unit will turn ON. Press
this button to the status of , the
unit will turn OFF.

-5-

INSTALLATION

KEY BOARD

SOURCE

SOURCE

MENU

MENU

CH+

CH+

CH-

CH-

VOL+

VOL+

VOL-

VOL-

1.SOURCE
To display the input source menu.

2.MENU
To display main MENU.

3.CH+/CH­In TV mode to change the channel up
and down.
In MENU mode, to select the menu items .
In standby mode, it can turn on the TV.

4.VOL+/VOL­To adjust sound level.

In MENU mode,to select the menu items.

REAR PANEL

DVD SIDE PANEL

OPEN/CLOSE

PLAY/PAUSE

STOP

PREV
NEXT

USB

USB

In DVD mode, press DVD/USB button
on the Remote control, insert a USB
or a Mp3 player with USB interface to
play the Mp3, JPEG and Mp4 files.

Caution:

When using USB function, please do
not insert in the wrong direction, or else
it will damage the unit.

LRAV

Pr

AC-INPUT

100-240V~ 50/60Hz

HDMI

S-VIDEO

AUDIO

VGAINPUT

VGAINPUT

Y

YPbPr

AUDIO

INPUT

INPUT

Pb

SPDIFOUTPUT

ANT

All the terminals are(from left to right):
AC POWER SOCKET, HDMI input,VGA ,PC AUDIO input,AV ,S-VIDEO,Rear Audio input,
YPbPr input, ANTENNA SOCKET,

Coaxial SPDIF OUTPUT,

Note: 1.AV,S-VIDEO and YPbPr share the Rear Audio input channel.

2. When HDMI port get DVI signal,the PC Audio channel will change to receive the audio

from HDMI port.

-6-

ANTENNA CONNECTION

INSTALLATION

Note:
Aerial connections:IEC(female).
Input impendance:75 unbalanced.

-7-

CONNECTING TO PC

STEPS:

Be sure both the TV and computer are set to Power off.

1.Connect VGA and audio cable.

2.Connect the power cord.

3.Power on the TV, switch the input source to VGAmode.

4.Power on the PC.

This sequence is very important.

LRAV

Pr

Y

YPbPr

AC-INPUT

100-240V~ 50/60Hz

AUDIO

AUDIO

VGAINPUT

VGAINPUT

HDMI

INPUT

S-VIDEO

INPUT

SPDIFOUTPUT

ANT

Pb

VGA cable

INSTALLATION

Power cord

PC Audio

-8-

PC PRESET

PRESET MODE(recommended resolution is 1024*768@60Hz)

INSTALLATION

RESOLUTION

1

2

3

4

5

6

7

8

9

720*400

640*480

800*600

800*600

800*600

800*600

1024*768

1024*768

1024*768

V.Freq.(Hz) H.Freq.(KHz)

70

60

56

60

75

72

60

70

75

31.47

31.47

35.156

37.88

46.88

48.08

48.36

56.48

60.02

-9-
