Bush DW9SLSAEINTW, DW9SLINTWE1 User guide

Instruction manual

Dishwasher

DW9SLSAEINTW - DW9SLINTWE1

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

You’ll soon be enjoying your new
DW9SLSAEINTW - DW9SLINTWE1 Dishwasher.

It all begins here, with your instructions. Don’t worry,
there’s nothing too technical coming up. Just
simple, step-by-step guidance to get you up and
running quickly. Sound good? Then let’s get started.

Help and Guidance

We’re here to help you get the most from your DW9SLSAEINTW - DW9SLINTWE1.
Should you require any guidance, a simple solution can often be found online at:

www.bush-support.com

If you still require further assistance, call one of our experts on 0345 257 7271.

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

Contents

Safety information

1

Safety information

Getting to know your

2

Dishwasher

Ready? Let’s begin

Accessories

Installing your Dishwasher

3

Installation requirements

Unpacking

Connections (electrical, water, gas)

Functions

4

Functions

10

13

16

16

17

20

Product support

7

6

Troubleshooting

Help and assistance

Declaration of conformance to product
standards

Disposal

Guarantee

33

36

37

37

38

Using your Dishwasher

5

First use of DW9SLSAEINTW - DW9SLINTWE1

Standard and advanced functions/use

Care and Maintenance

6

Cleaning

Maintenance actions

Technical specifications

24

25

28

28

29

3

1

Safety information

Icon Type Meaning

WARNING

RISK OF ELECTRIC SHOCK

FIRE

CAUTION

IMPORTANT / NOTE

Serious injury or death risk

Dangerous voltage risk

Fire risk

Injury or property damage risk

Operating the system correctly

Safety information

Safety information

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Important - Please read these instructions fully before

installing or operating. Keep this manual
for future reference.

1.1 General Safety Warnings

Please check the packaging of your
machine before installation and the outer surface of
the machine once the packaging has been
removed. Do not operate the machine if it appears
damaged or if the packaging has been opened.

• Packaging materials protect your machine
from any damage that might occur during
transportation. The packaging materials are
environmentally friendly as they are
recyclable. Use of recycled material reduces
raw material consumption and decreases
waste production.

This appliance can be used by children
aged from 8 years and above, and by persons with
reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been
given supervision or instruction concerning the use
of the appliance in a safe way and understand
hazards involved. Children should not be allowed to
play with the appliance.

Check that the indoor electrical fuse system is

connected in line with safety regulations.

All electrical connections must match the

values on the plate.

Ensure the machine does not stand on the

electrical supply cable.

Never use an extension cord or a multiple

socket connection.

The plug should be accessible after the

machine is installed.

After installation, run your machine unloaded for the
first time.

The machine must not be plugged in during

positioning.

Always use the coated plug supplied with your

machine.

If the electrical cable is damaged, it should only

be replaced by a qualified electrician.

Remove packaging and keep it out of reach
of children.

Keep children away from detergents and
rinse aids.

There may be some residue left in the
machine after washing. Keep children away from
the machine when it is open.

1.2 Installation Warnings

• Choose a suitable and safe place to install
your machine.

• Only original spare parts should be used with
the machine.

Unplug the machine before installation.

Your machine must only be installed by an
authorised service agent. Installation by anyone
other than an authorised agent may cause your
warranty to be void.

1.3 During Use

This machine is for domestic use only; do not use it for
other purposes. Commercial use will void the
guarantee.

Do not stand, sit or place loads on the open

door of the dishwasher.

Only use detergents and rinse aids produced
specifically for dishwashers. Our company is not
responsible for any damage that may occur due to
misuse.

Do not drink water from the machine.

Due to the danger of explosion, do not place
any chemical dissolving agents into the machine’s
washing section.

Check the heat-resistance of plastic items before
washing them in the machine.

Only put items in the machine which are
suitable for dishwashing and take care not to overfill the
baskets.

6

Safety information

Safety information

Important - Please read these instructions fully before

installing or operating. Keep this manual
for future reference.

Do not open the door while the machine is in
operation, hot water may spill out. Safety devices
ensure the machine stops if the door is opened.

The machine door should not be left open. It
may cause accidents.

Place knives and other sharp objects in the
cutlery basket in a blade-down position.

For models with the automatic door-opening
system, when the EnergySave option is active, the
door will open at the end of a program. To prevent
damage to your dishwasher, do not attempt to close
the door for one minute after it has opened. For
effective drying, keep the door open for 30 minutes
after a programme has ended. Do not stand in front of
the door after the auto-open signal sounds.

In the case of a malfunction, repair should
only be performed by an authorised service company,
otherwise the warranty will be void.

Before repair work, the machine should be
disconnected from the mains. Do not pull the cable to
unplug the machine. Switch off the water tap.

Operation at a low voltage will cause a
decline in performance levels.

For safety, disconnect the plug once a
program has finished.

To avoid an electric shock, do not unplug the
machine with wet hands.

Pull the plug to disconnect the machine from
the mains, never pull on the cord.

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

7

Getting to know your

Dishwasher

2

Getting to know your Dishwasher

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Getting to know your Dishwasher

You’ll be up and running in no time

Ready? Let’s begin...

Please read these instructions carefully. They contain
important information which will help you get the best
from your DW9SLSAEINTW - DW9SLINTWE1 and ensure safe and
correct installation and operation.

If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.

10

Getting to know your Dishwasher

You’ll be up and running in no time

Getting to know your Dishwasher

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

11

10

9

8

1

2

3

4

5

6

7

12

1. Upper basket with racks

2. Upper spray arm

3. Lower basket

4. Lower spray arm

5. Filters

6. Rating plate

7. Control panel

8. Detergent and rinse-aid dispenser

9. Cutlery basket

10. Salt dispenser

11. Upper basket track latch

12. Mini Active Drying Unit: This system provides better drying

performance for your dishes.

11

Getting to know your Dishwasher

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Getting to know your Dishwasher

You’ll be up and running in no time

Technical Specifications

10 place

Capacity

settings

Dimensions Height
Width Depth

820-870 (mm)
450 (mm)
570 (mm)

Net weight 32 kg

Operating
voltage /

220-240V 50 (Hz)

frequency

Total

10(A)

current

Total power 1900(W)

Maximum: 1

Water

supply

(Mpa) Minimum:

0.03 (Mpa)

pressure

12

Getting to know your Dishwasher

You’ll be up and running in no time

Getting to know your Dishwasher

Capacity

DW9SLSAEINTW - DW9SLINTWE1

Acce

This machine includes the below accessories, please
install these parts before operating.

• Water Inlet Hose x1

• Drain Hose x1

ssories

10 Place Settings 1900W A++ A

Power Energy Class Drying Class

13

Installing your Dishwasher

3

Installing your Dishwasher

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Installing your Dishwasher

Bringing it all together

3.1 Positioning your Machine

When positioning the machine, place it in an area
where dishes can be easily loaded and unloaded. Do
not put the machine in an area where the ambient
temperature falls below 0°C.

Read all warnings located on the packaging before
removing the packaging and positioning the machine.
Place the machine close to a water tap and drain. Take
into consideration that the connections will not be
altered once the machine is in position.

Do not hold the machine by its door or panel.

Leave an adequate distance around the machine to
allow ease of movement when cleaning.

Ensure the water inlet and outlet hoses are not
squeezed or trapped and that the machine does not
stand on the electrical cable while positioning.

Adjust the feet so the machine is level and balanced.
The machine should be placed on flat ground
otherwise it will be unstable and the door of the
machine will not close properly.

3.2 Water Connection

3.3 Water inlet hose

WARNING: Use the new water inlet hose
supplied with your machine, do not use an old
machine’s hose.

WARNING: Run water through the new hose
before connecting.

WARNING: Connect the hose directly to the
water inlet tap. The pressure supplied by the tap
should be a minimum of 0.03 MPa and a maximum of
1 MPa. If the pressure exceeds 1 MPa, a pressure relief
valve must be fitted between the connection.

WARNING: After the connections are made,
turn the tap on fully and check for water leaks. Always
turn off the water inlet tap after a wash program has
finished.

We recommend fitting a filter to your water inlet supply
in order to prevent damage to your machine due to
contamination (sand, rust, etc.) from indoor plumbing.
This will also help prevent yellowing and deposit
formation after washing.

Note printing on the water inlet hose!
If models are marked with 25°, the water temperature
may be max. 25 °C (cold water).
For all other models:
Cold water preferred; hot water max.
temperature 60 °C.

An Aquastop water spout is available with

some models. Do not damage it or allow it to
become kinked or twisted.

16

Installing your Dishwasher

Bringing it all together

Installing your Dishwasher

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION:

TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION:

TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

3.4 Water drain hose

Connect water drain hose directly to water drain hole
or to the sink outlet spigot. This connection should be
minimum 50 cm and maximum 110 cm from floor
plane.

IMPORTANT: Items will not wash properly if a

drain hose longer than 4 m is used.

3.5 Electrical Connection

WARNING: Your machine is set to operate
at 220-240 V. If the mains voltage supply to your
machine is 110 V, connect a transformer of 110/220
V and 3000 W between the electrical connection.

e productConnect th to agrounded outlet
protected by a fuse complying with the values in
the "Technical Specifications" table".

The earthed plug of the machine must be
connected to an earthed outlet supplied by
suitable voltage and current.

In the absence of earthing installation, an
authorised electrician should carry out an earthing
installation. In the case of use without earthing
installed, we will not be responsible for any loss of
use that may occur.

The plug on this appliance may
incorporate 13A fuse depending on the target
country. (For Example UK, Saudi Arabia)

17

Functions

4

Functions

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Functions

Simple everyday use

The Control Panel

i

1

ii

2 3 4

iii vi

iv

v

1. On/Off button

2. Programme Selection Button

i. Programme Leds

3. Half Load Button
ii. Half Load Led

4. Delay Button
iii. Delay Leds

iv. Salt Indicator
v. Rinse Aid Indicator
vi. End of Programme Indicator

1. On/Off Button

Switch the machine on by pressing On/Off
button. When machine is on, the End Of
Programme Indicator (vi) will illuminate.

2. Programme Selection
Button

Select a suitable programme for your
dishes by pressing Programme

Selection button. The Programme Led (i)
corresponding to the selected programme
will illuminate and the End Of Programme
Indicator (vi) will switch off. The programme
will start automatically when the door is
closed.

3. Half Load Button

Press the Half Load button to reduce the
duration of the selected programme, and
therefore decrease your energy and water
consumption. When Half Load option is
selected, Half Load led (ii) will illuminate.

remaining delay duration (3h, 6h, 9h) will
be on. If you switch off the machine after
activating the delay time, the delayed time is
cancelled.

NOTE: If you decide not to start the
selected programme, please see the
"Changing a Programme" and "Cancelling a
Programme" sections.

NOTE: When there is insucient
softening salt, the Salt Lack Warning
Indicator (iv) will illuminate to indicate the
salt chamber needs filling.

NOTE: When there is insucient rinse
aid, the Rinse Aid Lack Warning Indicator
(v) will illuminate to indicate the rinse aid

chamber needs filling.

Changing a Programme

Follow the steps below to change a
programme while in operation.

Open the door and select a new

programme using the Programme

Selection button.

After closing the door, the new

programme will resume the course

of the old programme.

NOTE: Open the door slightly at first to
stop a programme before it is complete in
order to avoid water spillage.

20

4. Delay Button

Press the Dela
time of a programme for 3, 6 or 9 hours.
Pressing once will delay the start time for 3
hours, pressing twice for 6 hours, and three
times for 9 hours. Press the Delay Timer
button to change or cancel the delayed start
time. The Delay led (iii) corresponding to the

y button to delay the start

Functions

Simple everyday use

Cancelling a Programme

Follow the steps below to cancel a
programme while in operation.

When the door of your machine

is opened, the light corresponding

to the most recently selected

programme will illuminate.

3. To decrease sound level press
Programme (2) button. To increase
sound level, press Half Load (3) button.

4. When voice level is changed,
corresponding leds shown below table
illuminate.

Voice
Levels

S0 X

S1 X X

S2 X X X

S3 X X X X

1/2 3h 6h 9h

Leds

Press and hold the Programme Selection

button for 3 seconds. The End Of

Programme Indicator will flash and the

programme light will switch off.

5. To save the selected sound level, turn

o

the machine.
’’S0’’ level means all voices are o.

The water discharge process will start after

the door of the machine is closed and
will continue for 30 seconds. A buzzer

will sound 5 times when a programme

is cancelled and the End Of Programme

Indicator will illuminate.

Factory setting is “S3.

Save Power Mode

To activate or deactivate save power
mode,

Switching the Machine Off

follow the below steps:

1. Open the door and press Half Load
(3) and Delay (4) buttons simultaneously
for 3 seconds.

2. After 3 seconds, the machine will

The End Of Programme Indicator will
illuminate when a programme is complete.
A signal will also sound 5 times. You can
then switch your machine off using the
Power On/Off button.

Disconnect the plug and turn off the

water tap.

display last setting.

3. When Save Power Mode is activated,
P1, P2, 1/2 leds illuminate. On this
mode, interior lights will turn off 4
minutes after the door is opened,
and the machine will turn off after 15
minutes of no activity in order to save

energy.

4. When Save Power Mode is

NOTE: Do not open the door before

the programme is complete.

deactivated P1, P2 leds illuminate. If
Save Power Mode is deactive, interior
lights will be on as long as the door is

NOTE: If the door of the machine

is opened or the power is cut off while

open, and the machine will always be
on unless it is turned off by user.

a programme is in operation, the
programme will continue when the
door is closed or the power returns.

5. To save the selected setting, turn o

the machine.
In factory setting, Save Power Mode is

NOTE: If the power is cut or the

active.
machine door is opened during the
drying process, the programme will
terminate. Your machine will now be
ready for a new programme selection.

Buzzer Sound Control

To change the buzzer sound level,
follow the below steps:

1. Open the door and press
Programme (2) and Half Load (3)
buttons simultaneously for 3 seconds.

2. When sound setting is recognized,

Infoled 2.1 (Model Dependent)

LED Indicator State of the Machine

Red, continuous

Red, flashing A program is cancelled.

Red, flashing
rapidly

Green, continuous A program is finished.

buzzer gives a long sound and
machine will
display last set level, from “S0” to “S3”.

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

The machine is running a
program.

The machine has a fault. Refer
to section "Automatic fault
warnings and what to do".

Functions

21

Functions

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

Functions

Simple everyday use

Programme Table

P1 P2 P3

Program

Name:

Type of Soil:

Level of Soil: Medium Heavy Heavy Medium

Amount of
Detergent:

A: 25 cm3

B: 15 cm3”

Program
Duration

(h:min)

Electiricity

consumption

(kWh/cycle)

Water

consumption

(l/cycle)

Eco Intensive 65°C Auto Super 50’ 65°C

Standard

program for

normally

soiled daily

using dishes

with reduced

energy

and water

consumptions..

A A A A

03:42 02:15 01:50 - 02:15 00:50

0.755 1.550 1.150 - 1.550 0.950

11.0 17.6 11.2 - 17.6 11.2

Suitable for

heavily soiled

dishes

Auto program

for heavily

soiled dishes..

normally soiled

Suitable for

daily dishes

with faster

program.

• The program duration may change according to the amount of dishes, the water
temperature, the ambient temperature and selected additional functions.

• Values given for programmes other than the eco programme are indicative only

• If your model has turbidity sensor, it has Auto program instead of Intensive program.

• Eco programme is suitable to clean normally soiled tableware, that for this use, it is the
most efficient programme in terms of its combined energy and water consumption,
and that it is used to assess compliance with the EU ecodesign legislation.

• Washing tableware in a household dishwasher usually consumes less energy and
water in the use phase than hand dishwashing when the household dishwasher is used
according to the manufacturer’s instructions.

• Only use powder detergent for short programs.

• Short programs do not include drying.

• To assist drying, we recommend slightly opening the door after a cycle is complete.

• You can access the product database where the model information is stored by reading
the QR code on the energy label.

NOTE: According to regulations 1016/2010 and 1059/2010, Eco program energy
consumption values may differ. This table is in line with regulations 2019/2022 and
2017/2022.

2

2

Using your Dishwasher

5

Using your Dishwasher

Getting the most from your appliance

Using your Dishwasher

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

5.1. Preparing your
dishwasher for first use

••Make sure the electricity and supply
water specifications match the
values indicated in the installation
instructions for the machine.

Remove all packaging material
inside the machine.

• Set the water softener level.

• Fill the rinse aid compartment..

5.2 Salt usage (IF AVAILABLE)

For a good washing function, the
dishwasher needs soft, i.e. less calcareous
water. Otherwise, White lime residues will
remain on the dishes and the interior
equipment. This will negatively affect your
machine’s washing, drying and shining
performance. When water flows through
the softener system, the ions forming the
hardness are removed from the water and
the water reaches the softness required to
obtain the best washing result. Depending
on the level of hardness of the inflowing
water, these ions that harden the water
accumulate rapidly inside the softener
system. Therefore, the softener system has
to be refreshed so that it operates with the
same performance also during the next
wash. For this purpose, dishwasher salt is
used.

1 2

3 4

SALT

Only add water to the salt
compartment on first use.

Use softener salt specifically produced
for use in dishwashers.

When you start your dishwasher, the
salt compartment is filled with water,
therefore put the softener salt in prior
to starting your machine.

If the softener salt has overflowed
and you do not start the machine
immediately, run a short washing
program to protect your machine
against corrosion.

Machine can only be used by special
dishwasher salt to soften the water. Do not
use any small grained or powdered type of
salts which can easily soluble. Using any
other type of salt can damage your
machine.

5.3. Fill the salt (IF AVAILABLE)

To add softener salt, open the salt
compartment cap by turning it counter
clockwise. (1) (2) At first use, fill the
compartment with 1 kg salt and water (3)3)
til it is almost overflowing. If available, using
a funnel (4) will make filling easier. Replace
the cap and close it. After every 20-30
Cycles add salt into your machine until it
fills up
(approx. 1 kg).

25

Using your Dishwasher

Getting the most from your appliance

Using your DIshwasher

Using your Dishwasher

Ge

tting the most from your appliance

5.4. Test Strip

Run water through

the tap (1min.)

1

munite

NOTE: The factory hardness level setting is “3”. If the water is well water or has a
hardness level above 90 dF, we recommend that you use filter and refinement
devices.

5.5. Water Hardness Table

Level

2 6-11 10-20 7-14 P2-9h LEDs are on.

German dHFrench

1 0-5 0-9 0-6 P1-9h LEDs are on.

Keep the strip in
the water (1sec)

1

second

dF

Shake the strip. Wait (1min.)

British dE Indicator

1

munite

Set the hardness level of

your machine.

1
2
3
4
5
6

3 12-17 21-30 15-21 1/2-9h LEDs are on.

4 18-22 31-40 22-28 3h-9h LEDs are on.

5 23-31 41-55 29-39 6h-9h LEDs are on.

6 32-50 56-90 40-63 P1-6h-9h LEDs are on.

5.6. Water Softener System

The dishwasher is equipped with a water softener which reduces the hardness in
the mains water supply. To find out the hardness level of your tap water, contact
your water company or use a test strip (if available).

5.7. Setting

In order to change the salt level, follow the below steps:

• Open the door of the machine.

• Turn on the machine, and press the Programme button as soon as the

machine is turned on.

• Hold down the Programme button until all leds blink once.

• The machine will display the last setting.

• Set the level by pressing the Programme button.

• Switch off the machine to save the setting.

5.8. Detergent usage

Only use detergents specifically designed for domestic dishwashers. Keep your
detergents in cool, dry places out of reach of children.

Add the proper detergent for the selected program to ensure the best

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

26

Using your Dishwasher

Getting the most from your appliance

Using your Dishwasher

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

performance. The amount of detergent
needed depends on the cycle, load
size, and soil level of dishes.

Do not fill detergent into the detergent
compartment more than required;
otherwise you can see whitish streaks
or bluish layers on glass and dishes and
may cause glass corrosion. Continued
use of too much detergent may cause
machine damage.

Using little detergent can result in
poor cleaning and you can see whitish
streaksin hard water. See the detergent
manufacturer’s instructions for a
further information.

4.9. Filling the detergent

Push the latch to open the dispenser
and pour in the detergent. Close the
lid and press it until it locks in place.
The dispenser should be refilled just
before the start of each programme.
If the dishes are heavily soiled, place
additional detergent in the pre-wash

detergent chamber.

DETERGENT

4.10. Using combined
detergents

These products should be used
according to the manufacturer’s
instructions.

Never put combined detergents into
the interior section or the cutlery
basket.

Combined detergents contain not only
the detergent but also rinse-aid, salt
replacement substances and additional
components depending on the
combination.

We recommend you do not use
combined detergents in short
programmes. Please use powder
detergents in such programmes.

If you encounter problems when using
combined detergents, please contact
the detergent manufacturer.

When you stop using combined
detergents, make sure that water
hardness and rinse aid settings are set
to the correct level.

4.11. Rinse-aid usage

The rinse aid helps to dry the dishes
without streaks and stains. Rinse-aid is
required for stain-free utensils and
clear glasses. The rinse aid is
automatically released during the hot
rinse phase. If rinse aid dosage setting
set too low, whitish stains remains on
dishes and dishes do not dry and
washed clean. If rinse aid dosage
setting set too height, you can see
bluish layers on glass and dishes.

4.12. Filling the rinse ­aid and setting

To fill the rinse aid compartment, open
the rinse-aid compartment cap. Fill the
compartment with rinse aid to
the MAX level and then close the cap.
Be careful not to overfill the rinse aid
compartment and wipe up any spills.

In order to change the rinse aid level,
follow the below steps:

• Open the door of the machine.

• Turn on the machine, and press
the Programme button as soon
as the machine is turned on.

• Hold down the Programme
button until all leds blink twice.
Rinse aid setting follows water
hardness setting.

• The machine will display the last
setting.

• Change the level by pressing the
programme button.

• Switch off the machine to save
the setting.

The factory rinse aid level setting is “4”.
If the dishes are not drying properly or are
spotted, increase the level. If blue stains
form on your dishes, decrease the level.

Level Brightener

Dose

1 Rinse-aid not

dispensed

2 1 dose is

dispensed

3 2 doses are

dispensed

4 3 doses are

dispensed

5 4 doses are

dispensed

Indicator

r1 is shown on

the display.

r2 is shown on

the display.

r3 is shown on

the display.

r4 is shown on

the display.

r5 is shown on

the display.

27

Using your Dishwasher

Getting the most from your appliance

Using your Dishwasher

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

LOADING YOUR DISHWASHER

For best results, follow these loading
guidelines.

Loading the household dishwasher up to
the capacity indicated by the manufacturer
will contribute to energy and water savings.

Manual pre-rinsing of tableware items leads
to increased water and energy consumption
and is not recommended You can place
cups, glasses, stemware, small plates, bowls,
etc. in upper basket. Do not lean long
glasses against one another or they cannot
remain steady and may receive damage.
When placing long stem glasses and
goblets, lean them against the basket edge
or rack and not against other items.

Place all containers such as cups, glasses
and pots into the dishwasher with the
opening facing downwards otherwise water
can collect on items.

If there is cutlery basket in machine, you
are recommended to use the cutlery grid in
order to obtain the best result. Place all large
(pots, pans, lids, plates, bowls etc.) and very
dirty items in the lower rack.

Dishes and cutlery should not be placed
above each other.

WARNING: Take care not to obstruct

the rotation of spray arms.

Upper Basket
Height adjustment
Turn the Rail Stop Clips, at the ends of the rails, to the sides to
open them (as shown in the image below), then pull out and
remove the basket. Change the position of the wheels, then
reinstall the basket to the rail, making sure to close the Rail Stop
Clips. When the upper basket is in the higher position, large
items such as pans can be
placed on the lower basket.

WARNING:Make sure after loading
the dishes do not prevent opening the
detergent dispenser.

Recommendations

Remove any coarse residue on dishes
before placing the dishes in the machine.
Start the machine with full load.

Do not overload the drawers or place

dishes in the wrong basket.

WARNING: To avoid any possible
injuries, place long-handle and sharp­pointed knives with their sharp points facing
down or horizontally on the baskets.

Top basket Fixed Rack

Upper basket racks have two positions: open (a) and
closed (b). You can place cups on the racks to be
washed. You can also place long forks, knives and
spoons on the racks laterally.

b

a

28

Using your Dishwasher

Getting the most from your appliance

Using your Dishwasher

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Alternative Basket Loads

Lower Basket

Top Basket

Important Note for Test Laboratories

For detailed information required for tests
according to EN normatives and a softcopy of the
manual, please send the model name and serial
number to the following address:

[email protected]

Incorrect Loads

Incorrect loading can cause poor
washing and drying performance. Please
follow the manufacturer’s
recommendations for a good
performans result.

29

Care and maintenance

6

Care and maintenance

Care and maintenance

Looking after your appliance

Cleaning

Cleaning your dishwasher is important
to maintain the machine’s service life
Make sure that the water softening
setting (If available) is done correctly
and correct amount of detergent
is used to prevent limescale
accumulation. Refill the salt
compartment when the salt sensor
light comes on.

Oil and limescale may build up in your
Dishwasher over time. If this occurs:

• Fill the detergent compartment
but do not load any dishes.
Select a programme which runs
at high temperature and run the
Dishwasher empty. If this does not
clean your Dishwasher sufficiently,
use a cleaning agent designed for
use with dishwashers.

• To extend the life of your
dishwasher, clean the appliance
regularly on each month

• Wipe the door seals regularly
with a damp cloth to remove any
accumulated residue or foreign

objects.

• Never use your dishwasher without
a filter.

• Incorrect fitting of the filter will
reduce the washing effectiveness.

• Clean filters are necessary for
proper running of the machine.

6.2. Spray arms

Make sure that the spray holes are not
clogged and that no food waste or
foreign object is stuck to the spray
arms. If there is any clogging,remove
the spray arms and clean them under
water. To remove the upper spray arm
undo the nut holding it in position by
turning it clockwise and pulling it
downwards. Make sure that the nut is
properly tightened when refitting the
upper spray arm.

6.1. Filters

Clean the filters and spray arms at least
once a week. If any food waste remains
or foreign objects on the coarse and
fine filters, remove them and clean
them thoroughly with water.

a) Micro Filter b) Coarse Filter
c) Metal Filter

1 2

b

a

3 4

c

To remove and clean the filter
combination, turn it counter clockwise
and remove it by lifting it upwards (1).
Pull the coarse filter out of the micro
filter (2).Then pull and remove the
metal filter (3).Rinse the filter with
lots of water until it is free of residue.
Reassemble the filters. Replace the

filter insert, and rotate it clockwise (4).

6.3. Drain Pump

Large food residues or foreign objects
which were not captured by the filters
may block the waste water pump. The
rinsing water will then be above the
filter.

Warning Risk of cuts!

When cleaning the waste water pump,
ensure that you do not injure yourself
on pieces of broken glass or pointed
implements.

In this case:

1. First always disconnect the appliance

from the power supply.

2. Take out baskets.

3. Remove the filters.

4. Scoop out water, use a sponge if
required.

5.Check the area and remove any
foreign objects.

6. Install filters.

7. Re-insert baskets.

31

Product support

7

Product support

Help is always at hand

Troubleshooting

FAULT POSSIBLE CAUSE TROUBLESHOOTING

Your Dishwasher is not plugged in. Plug your Dishwasher in.

The programme does not

Water remains inside the

Shaking and hitting noises are

heard during a wash operation.

start.

machine.

Machine stops during

washing.

Your Dishwasher is not switched on.

Fuse blown. Check your indoor fuses.

Water inlet tap is closed. Turn on the water inlet tap.

Your Dishwasher door is open. Close the Dishwasher door.

Water inlet hose and machine filters are

Water drain hose is clogged or twisted. Check the drain hose, then either clean or untwist it.

The filters are clogged. Clean the filters.

The programme is not finished yet. Wait until the programme is finished.

The spray arm is hitting the dishes in the lower

clogged.

Power failure. Check mains power.

Water inlet failure. Check water tap.

basket.

Switch your Dishwasher on by pressing the On/Off

Check the water inlet hose and machine filters and

make sure they are not clogged.

Move or remove items blocking the spray arm.

button.

33

Dishes placed incorrectly, sprayed water not

Partial food wastes remain

on the dishes.

Wrong wash programme selected.

Spray arms clogged with food waste.

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

reaching affected dishes.

Dishes leaning each another.

Not enough detergent used.

Filters or water drain pump clogged or filter

misplaced.

Place dishes as instructed in the section on loading your

Use the information in the programme table to select the

Do not overload baskets.

dishwasher.

Use the correct amount of detergent, as instructed in

Clean the holes in the spray arms with thin objects.

Check the drain hose and filters are correctly

the programme table.

most appropriate programme.

fitted.

Product support

Product support

Help is always at hand

FAULT POSSIBLE CAUSE TROUBLESHOOTING

Whitish stains remains on

dishes.

Dishes do not dry.

Rust stains form on the

dishes.

Not enough detergent used.

Rinse aid dosage and/or water softener

Salt compartment cap not closed properly. Check that the salt compartment cap is closed

Rinse aid dosage set too low. Increase rinse aid dosage setting.

High level of salt in wash water.

Salt compartment cap not closed properly. Check that the salt compartment cap is closed

Too much salt spilled in the Dishwasher

setting set too low.

High water hardness level. Increase water softerner level and add salt.

Drying option is not selected. Select a programme with a drying option.

Stainless-steel quality of the dishes is

insufficient.

while filling it with salt.

Use the correct amount of detergent, as instructed

Increase rinse aid and/or water softener level.

Adjust the water hardness level using water hardness

in the programme table.

properly.

Use only dishwasher-proof sets.

table.

properly.

Use funnel while filling salt to the

compartment to avoid spillage.

Detergent remains in the

detergent compartment.

A poor mains grounding. Consult a qualified electrician immediately.

Detergent was added when the detergent

compartment was wet.

Make sure detergent compartment is dry before use.

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

34

Product Support

Product support

Help is always at hand

AUTOMATIC FAULT WARNINGS AND WHAT TO DO

TROUBLE CODE POSSIBLE FAULT WHAT TO DO

P1 P2 1/2 3h 6h

Make sure the water inlet tap is

open and water is flowing.

Water inlet system

failure

Pressure system

failure

Continuous water

input

Inability to discharge

water

Faulty heater Contact for service.

Overflow

Separate the inlet hose from the

tap and clean the filter of the hose.

Contact for service if the error

Close the tap and contact for

Water discharge hose and filters

If the error continues, contact for

Unplug the machine and close the

continues.

Contact for service.

service.

may be clogged.

Cancel the programme.

service.

Contact for service.

tap.

Contact for service.

Faulty electronic

card

Overheating Contact for service.

Faulty heater sensor Contact for service.

Hihg voltage failure Contact for service.

Low voltage failure Contact for service.

The installation and repairing procedures should always carried out by the Authorised Service Agent in order to avoid
possible risks. The manufacturer shall not be held liable for damages that may arise from procedures carried out by
unauthorised persons. Repairs may be carried out by technicians only. If a component has to be replaced, ensure that
only original spare parts are used.Improper repairs or use of non-original spare parts may cause considerable damage
and put the user at considerable risk. Contact information for your customer service can be found on the back of this
document. Function-relevant genuine spare parts according to the corresponding Ecodesign order can be obtained
from Customer Service for a period of at least 10 years from the date on which your appliance was placed on the
market within the European Economic Area.

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

35

Product support

Contact for service.

Product support

Help is always at hand

Product support

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

Help and assistance

If you require any technical guidance or find that your <enter product name> is not operating as intended, a simple
solution can often be found in the Troubleshooting section of these instructions or online at

www.bush-support.com

If you still require further assistance, call one of our experts on xxxx xxx xxx*. To help give us give you a fast and
efficient service please have the following information ready:

Model Ref.

Serial number

Date of purchase

Local call rates applies*

You can find these on
the rating plate - a small
information panel (usually
a sticker or metal plate) on
the rear of your appliance

This will be shown on
your receipt

Lines open 8am-7pm Monday to Saturday and 10am-4pm Sunday.

*Calls to Bush enquiry lines may attract a charge and set up fee from residential lines depending on your call plan/tari. Mobile and other
providers costs may vary, see www.bt.com/pricing for details.

For Security and training purposes, telephone calls to and from customer service centres maybe recorded and monitored. Calls from
Republic of Ireland will attract international call charges.

36

Declaration of conformance to
product standards

We declare that our products meet the applicable
European Directives, Decisions and Regulations and
the requirements listed in the standards referenced.

Packaging and the Environment

Packaging materials protect your machine from
damage that may occur during transportation. The
packaging materials are environmentally friendly as
they are recyclable. The use of recycled material
reduces raw material consumption and therefore
decreases waste production.

Recycling

• Some machine components and packaging
consist of recyclable materials.

• Plastics are marked with the international
abbreviations:(>PE<, >PP<, etc. )

Disposal

The symbol on the product or on its
packaging indicates that this product may not
be treated as household waste. Instead, it
shall be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local city office,
your household waste disposal service or the
shop where the product was purchased.

• The cardboard parts consist of recycled paper.
They can be put into waste paper containers for
recycling.

• Material unsuitable for domestic waste must be
disposed of at recycling centres.

• Contact a relevant recycling centre to obtain
information about disposal of different materials.

37

Product support

Help is always at hand

Product support

or online at www.bush-support.com If you still require further assistance, call one of our experts on 0345 257 7271.

Call us now and activate your 12 month guarantee

Thank you for choosing Bush. Your new product is guaranteed against faults and
breakdowns for 12 months. Don’t forget to register it with us today so we can provide you
with our best possible after-sales service and useful updates.

Lines are open 8am - 8pm, 365 days a year. *Calls may be recorded and monitored.

www.bushregistration.co.uk

FREEPHONE*

0800 597 8548

Your Bush Guarantee

This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to
faulty materials or workmanship will be repaired free of charge (or if applicable the product will be replaced or the
purchase price refunded) where possible during this period by the dealer from who your purchased the unit.

The guarantee is subject to the following provisions:

• The guarantee does not cover accidental damage,
misuse, cabinet parts, knobs or consumable items.

• The product must be correctly installed and
operated in accordance with the instructions
contained in the manual.

• It must be used solely for domestic purposes. The
guarantee will be rendered invalid if the product is

re-sold or has been damaged by inexpert repair.

• Specifications are subject to change without notice.

• Bush disclaim any liability for loss or damage arising
from the breakdown of the product.

• This guarantee is in addition to and does not
diminish your statutory or legal rights.

Important Data Protection Information

To find out how we and Domestic & General Insurance Plc use your data please refer to the guarantee registration
material or visit www.bushregistrations.co.uk.

Guarantor: Argos Limited - 489 - 499 Avebury Blvd. - Milton Keynes - MK9 2NW

38

Contact:

www.bush-support.com

Helpline: 0345 257 7271

52257989 R36
