Instruction manual
40/133F
40/133FDVD
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 1User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 1 04/12/2015 13:06:0504/12/2015 13:06:05
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 2User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 2 04/12/2015 13:06:0704/12/2015 13:06:07
___________________________________________
____________________________________________
___________________________________________
Important Guarantee Information
Congratulations on purchasing this television. We hope you have many years of trouble free enjoyment from
your purchase.
Your product is covered under the manufacturers guarantee for 12 months from the date of purchase.
If you experience any difficulties with your TV, please refer to the ‘Frequently asked questions’ section
in this user guide.
If you are still unable to remedy the issue, try resetting the TV to factory settings. (Details in the ‘Settings menu’
section of this user guide). Alternatively you can contact the helpline on the number below.
In the event that a fault is diagnosed, the helpline will arrange to collect the TV from your home
or work address, return it to our service centre, repair the item and then return it to you.
If we believe we cannot offer a permanent repair, we will replace the item.
Helpline Information
Telephone UK 0330 024 0805, ROI 01443 3940
Web support: www.umc-uk.co.uk
The telephone opening hours are Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm. (Calls are charged
at the standard rate of your network provider.)
You must retain all packaging materials, in addition to your proof of purchase/receipt, as you will need these in the
event of warranty/service support.
This guarantee is in addition to and does not affect your statutory rights.
If you need to call the helpline, you will need the following information.
1) Model Ref
2) Date of purchase
3) Serial Number
___________________________________________ (You can find this on the rear of the TV)
____________________________________________ (You can find this on your sales receipt)
___________________________________________
(You can find this on the rear of the TV)
EXAMPLE OF LABEL ON REAR OF TV
Model Ref
Serial No.
This TV is for domestic use only
3
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 3User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 3 04/12/2015 13:06:0704/12/2015 13:06:07
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
4
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 4User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 4 04/12/2015 13:06:0704/12/2015 13:06:07
Contents
Safety information
1
Safety information 8-10
Getting to know your TV
2
Accessories 14
Stand installation 15
Detaching the stand 16
Securing the TV with anti-tip straps 16
Wall mounting 17
TV buttons 18
Remote control 19
Connections
3
TV buttons and input source 22
TV connections 23-24
Advanced features
5
Network configuration 36
DVD setup 37
7 day TV guide 38
USB media player 39
Product support
6
Connecting a sky digital set top box 42-43
Frequently asked questions 44-45
Technical specification 46-47
Bush warranty information 48
Standard features
4
How to navigate the menus 28
Channel menu 29
Picture menu 30
Sound menu 31
Time menu 31
Setup menu 32
Lock menu 33
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the
Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruSurround is a trademark of DTS,
Inc. © DTS, Inc. All Rights Reserved.
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
5
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 5User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 5 04/12/2015 13:06:0704/12/2015 13:06:07
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 6User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 6 04/12/2015 13:06:0704/12/2015 13:06:07
1Safety information 1
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 7User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 7 04/12/2015 13:06:0704/12/2015 13:06:07
Safety information
Important - Please read these instructions fully before
installing or operating
WARNING - Never place a television set on an unstable
location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to
children, can be avoided by taking simple precautions
such as:
Warnings
• Television sets which weigh 20kg or more must be
lifted and carried by at least 2 people.
• This television does not contain any parts that are
serviceable by the user. In case of a fault, contact
the manufacturer or authorised service department.
Exposing the internal parts inside the TV may
endanger your life. The manufacturers guarantee
does not extend to faults caused by repairs carried
out by unauthorised third parties.
To prevent the spread of fi re, keep
candles or other open fl ames away
from this product at all times
• To reduce the risk of fire, electric shock or damage
to the TV, do not expose it to dust, rain or moisture.
Never expose the TV to dripping or splashing and
do not place objects filled with liquids on or near
the TV.
• Do not connect any external devices (DVD player,
games console etc) when the TV is switched on.
Disconnect both the TV and device from the mains
before connecting. Only switch appliances on
when the connection process
is complete.
• Do not place the television in a confined space and
do not obstruct the ventilation openings at the rear
of the television.
• When installing on a wall, ensure the TV is at
least 5cm from the wall for ventilation.
• Always ensure that the TV’s ventilation openings
are not covered with items such as newspapers,
table-cloths, curtains, etc.
• Ensure this TV is used in moderate climates only.
• Use cabinets or stands recommended by the
manufacturer of the television set.
• Only use furniture that can safely support the
television set.
• Ensure the television set is not overhanging the
edge of the supporting furniture.
• Do not place the television set on tall furniture
(for example, cupboards or bookcases) without
anchoring both the furniture and the television
set to a suitable support.
• Do not place the television set on cloth or other
materials that may be located between the
television set and supporting furniture.
• Please educate children about the dangers of
climbing on furniture to reach the television set or
its controls.
• If your existing television set is being retained and
relocated, the same considerations as above should
be applied.
Safety
• Dispose of this television and any components
including batteries in an environmentally friendly
manner. If in doubt, please contact your local
authority for details of recycling.
• For your safety, this appliance is fitted with a fused
3 pin mains plug. Should the fuse need to be
replaced, ensure that any replacement is of the
same amperage and approved with the
BSI mark.
• Never try and replace the mains plug unless
you have adequate qualifications and are legally
authorised to do so. In the event that a replacement
mains cable is required, contact the manufacturer
for a suitable replacement.
• Never use the television if it is damaged in
any way.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Safety information8
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 8User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 8 04/12/2015 13:06:0704/12/2015 13:06:07
Safety information
Important - Please read these instructions fully before
installing or operating
• Always place the television on a flat level surface
avoiding anywhere which may be subject to
strong vibration.
• The ideal distance to watch the television is
approximately five times the length of the diagonal
measurements of the TV screen. Ensure the
television is not placed on top of the power cable as
the weight of the television may damage the cable
and cause a safety hazard.
• Never place mobile phones, speakers or any
other device which may cause magnetic or radio
interference, near the television. If interference is
apparent, move the device causing the interference
away from the television.
• To Isolate the TV from the mains power, please use
the power switch located on the side, underside or
rear of the TV set.
• Ensure that the power switch on the unit and the
mains plug are always easily accessible.
WARNING: Excessive noise when using earphones and
headphones can cause loss of hearing.
Packaging
• The safest way to transport your item is in the
original box/packaging - please save your packaging
for this.
• You will need the original box/packaging in the
event of warranty/service repair or support. We
are unable to carry out warranty/service if you are
unable to package the item correctly.
IMPORTANT: Information regarding use of video
games, computers, captions or other fixed image
displays
The extended use of fixed image program material can
cause a permanent “shadow image” on the LCD/LED
panel, also known as “screen burn”.
This “shadow image” can appear in the background
during normal viewing. This type of irreversible LCD/
LED panel deterioration can be limited by observing the
following steps:
1. Reduce the brightness/contrast setting to a
minimum suitable viewing level.
• To clean your TV, wipe with a soft, dry cloth. If
the surfaces are extremely dirty, use a soft cloth
dipped in a soap and water solution or a weak
detergent solution.
• Never use alcohol, paint thinner or benzene to
clean this unit.
• Before using a chemically treated cloth, read the
instructions that came with the cloth carefully.
CAUTION: If water or other liquid enters the
television through the display panel surface, a
malfunction may occur.
2. Do not display the fixed image for extended periods
of time.
3. Turn the power off when not in use.
Examples of images that are more likely to
cause “screen burn” are as follows:
• TV channel logos: e.g. shopping channel logos and
pricing displays - especially if they are bright and
stationary. Moving or low-contrast graphics are less
likely to cause ageing of the screen.
• Teletext: Do not view a stationary page for a long
period of time
• Time displays.
• TV/DVD menus: e.g. listings of DVD disc content.
• Pause mode: Do not leave the TV in pause mode
for long periods of time, e.g. when watching DVDs
or videos.
IMPORTANT: Once ‘shadow image/screen burn’
occurs, it will never disappear and is not repairable
under warranty.
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Safety information 9
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 9User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 9 04/12/2015 13:06:0704/12/2015 13:06:07
Safety information
Important - Please read these instructions fully before
installing or operating
Disposal
UK: Waste electrical products should not
be disposed of with household waste. Please dispose
of the product at a designated collection point for
recycling of WEEE. For your nearest facilities, please see
www.recycle-more.co.uk or in store for details.
ROI: Waste electrical products should not be disposed
of with household waste. Separate disposal facilities
exist. Check with your local authority or retailer for
recycling advice.
Batteries
• Do not expose batteries to high temperatures,
excessive heat, prolonged sunshine or fire as this
may cause leakage, explosion or ignition.
Observe the correct polarity when inserting
batteries.
• Do not use different types of batteries together or
mix old and new batteries.
• Dispose of batteries in an environmentally
friendly way.
• Certain regions may regulate the disposal of
batteries. Please consult your local authority.
• HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
• The “HD TV” Logo is a trademark of
DIGITALEUROPE.
• The “HD TV 1080p” Logo is a trademark of
DIGITALEUROPE.
• The DVB logo is the registered trademark of the
Digital Video Broadcasting - DVB – project.
• Manufactured under license from Dolby
Laboratories. Dolby, Dolby Audio, and the double-D
symbol are trademarks of Dolby Laboratories.
• Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S.
and worldwide patents issued & pending. DTS,
the Symbol, & DTS and the Symbol together are
registered trademarks & DTS 2.0+Digital Out is a
trademark of DTS, Inc. Product includes software. ©
DTS, Inc. All
Rights Reserved.
• FREEVIEW HD
The FREEVIEW HD words and logos are trade marks
of DTV Services LTD. © DTV Services Ltd.
TV Models with built in DVD players
CAUTION:
CLASS 1
LASER PRODUCT
This unit is a class 1 laser product. This unit uses a visible laser beam which could cause hazardous radiation
exposure if directed. Be sure to operate the player correctly as instructed.
When this unit is plugged into the wall outlet, do not place your eyes close to the openings to look into the
inside of this unit.
Use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
Do not open covers and do not repair yourself. refer servicing to qualified personnel.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Safety information10
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 10User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 10 04/12/2015 13:06:0704/12/2015 13:06:07
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Safety information 11
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 11User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 11 04/12/2015 13:06:0704/12/2015 13:06:07
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 12User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 12 04/12/2015 13:06:0704/12/2015 13:06:07
Getting to know your TV
2
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 13User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 13 04/12/2015 13:06:0704/12/2015 13:06:07
Getting to know your TV
You’ll be up and running in no time
Accessories
1 x User guide 1 x Remote control
User Guide
1 x Quick start guide
QSG
1 x TV
1 x RF cable
2 x AAA batteries
1 x Mini Component / YPbPr Cable
1 x Standard installation pack
4 x
1 x L (left)
1 x R (right)
Note: Please save your box/packaging as you will need this in the event of warranty/service repair or support.
We are unable to carry out warranty/service if you are unable to package it correctly. The safest way to package
your item in the event of warranty/service repair is in it’s original box/packaging.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
14
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 14User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 14 04/12/2015 13:06:0704/12/2015 13:06:07
Getting to know your TV
Getting to know your TV
You’ll be up and running in no time
Stand installation
To complete the stand installation you will require a cross head screw driver.
The stand installation pack comes with 4 screws and 2 x stand feet.
4 x
1
Back/Shortest
Front/Longest
1 x L (left)
1 x R (right)
fig 1) Place the TV set on a flat and clean surface with
the panel facing downwards to avoid damage, then
fix the stand feet shown.
fig.2) When the stand feet are installed correctly the
stand feet will be longest at the front of the TV and
shortest at the back with the feet pointing away from
each other.
2
3
4
fig 3) When the stand feet are in the correct position,
secure the stand feet to the underside of the TV set
1
2
3
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 15User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 15 04/12/2015 13:06:0904/12/2015 13:06:09
4 x
using the 4 screws provided.
Getting to know your TV
15
Getting to know your TV
You’ll be up and running in no time
Detaching the stand
To detach the stand please remove the 4 screws highlighted then remove the stand feet from the rear of
the TV set.
3
4
1
2
4 x
Securing the TV using anti-tip straps
For maximum security in the home, when using a TV with its stand, anti-tip straps should be fitted. These are
available from supermarket websites and other websites and are an easy, inexpensive and effective way of ensuring
your TV stays safely upright. Straps are designed to be attached to the rear of the TV and then tethered to the wall
or the furniture the TV is stood on, these are fitted as follows.
NOTE: Please ensure that children do not climb on the TV set.
A) Using one or both of the top wall-mounting holes and screws fasten one end of the fastening cord/s to the TV.
(the screws are already supplied in the wall mounting holes)
B) Secure the other end of the fastening cord/s to your wall. (you will need screws/fixings suitable for your wall
type - available separately from most DIY stores.
The Royal Society for the Prevention of Accidents is urging people to take care with flat-screen televisions.
RoSPA stated in 2010 that “Toddlers are particularly at risk of pulling flat-screen televisions on to themselves.
They are unsteady on their feet and are attracted by colourful television images.”
The risk is increased as televisions become lighter.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
16
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 16User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 16 04/12/2015 13:06:0904/12/2015 13:06:09
Getting to know your TV
Getting to know your TV
You’ll be up and running in no time
Wall mounting
IMPORTANT: Before drilling any holes in the wall ensure you are not drilling where there could be any electric
wires, water or gas pipes.
1) Remove the four screws located at the back of the TV set.
2) The wall mount can now be easily attached to the
mounting holes, located on the back of the TV, using the
same four screws removed.
IMPORTANT : If wall mounting this TV, only use the screws already provided in the wall mounting holes. Using
other screws which are longer could cause irreparable damage to internal parts.
For optimum viewing, if wall mounting the TV higher than eye level, the TV should be tilted downwards so that the
TV’s screen is ‘face on’. See fig 1 and 2 below.
fi g 1
INCORRECT
Viewing angle
TV
CORRECT
fi g 2
Viewing angle
TV
For VESA wall mounting information please refer to the Technical Specification page.
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Getting to know your TV
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 17User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 17 04/12/2015 13:06:0904/12/2015 13:06:09
17
Getting to know your TV
You’ll be up and running in no time
TV buttons and input source
STANDBY
1
1) Standby Power On/Off
2) Displays the input source menu
3) Displays Menu/OSD
4) Programme/Channel down and menu down
5) Programme/Channel up and menu up
6) Volume down and menu left
7) Volume up and menu right
2
Choosing mode and input/source
To switch between the different input/connections.
A) Using the buttons on the remote control:
1) Press [SOURCE] - The source menu will appear.
2) Press [\/] or [/\] to select the input you require.
3) Press [OK].
B) Using the buttons on the Television:
1) Press [SOURCE].
2) Scroll up / down using CH+/ CH- buttons to the
input/source you require.
3) Press Vol+ to change input/source to the one
selected.
For further information on input/connections please
view ‘Connections’ pages.
Freeview TV
Analogue TV
Composite/AV
Component / YPbPr
VGA/PC
For models with built in DVD player
23344556677
1
1) Stop/Eject DVD
2) Play/Pause DVD
3) Volume up and menu right
4) Volume down and menu left
5) Programme/Channel up and menu up
6) Programme/Channel down and menu down
7) Displays Menu/OSD
8) Displays the input source menu
9) Standby Power On/Off
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
18
Getting to know your TV
USB Media
STANDBY
Example of Source menu depending on the TV model
8
9
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 18User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 18 04/12/2015 13:06:0904/12/2015 13:06:09
Getting to know your TV
You’ll be up and running in no time
Remote control functions
For Models with Integrated DVD players
For Models with PVR Function
For Models with USB Playback
For Models with 3D Feature
1) STANDBY
2) MUTE
3) DTV
4) RADIO
5) DVD
6) USB
7) NUMBER BUTTONS
8) TV GUIDE
9)
- To return to the previous channel viewed
10) P.MODE - Scrolls through picture mode options
11) VOL
12) CH
13) S.MODE - Scrolls through sound mode options
14) FAV - To display favourites menu
15) MENU
16) EXIT
17)
menus and adjust the system settings to your preference
18) SOURCE/AV
19) INFO - Press once for now/next channel
information. Press twice for programme information
about current programme
20) ASPECT
21) SLEEP
22) SUBTITLE
23) AUDIO
24) TEXT
25) TEXT HOLD
26) DISPLAY
27) TEXT ZOOM/DVD ZOOM
28) DVD Menu/Record:
- To restart the current chapter
- To advance forward to the next chapter
- To stop/eject Disc (hold for 4 seconds to eject disc)
- To play in fast rewind mode
- To play in fast forward mode
- To play/pause
29) REC LIST
30) GOTO
31) A-B
32) REPEAT
33) ANGLE/
- Allows you to navigate the on-screen
3D - Change to 3D mode
12
53
4
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 22
21 23
24
26
25 27
28
29
30
32
31
33
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Getting to know your TV
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 19User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 19 04/12/2015 13:06:1004/12/2015 13:06:10
19
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 20User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 20 04/12/2015 13:06:1104/12/2015 13:06:11
Connections
3
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 21User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 21 04/12/2015 13:06:1104/12/2015 13:06:11
Connections
Bringing it all together
Connections
EARPHONE Earphone socket
1
LAN* Network connection
2
Video Video input
3
L/R L/R audio input
4
COMPONENT (HD) Component input (YPbPr)
5
HDMI 1 HDMI input
6
HDMI 2 (ARC) HDMI input
7
VGA/PC VGA/PC input
8
VGA/PC AUDIO IN 3.5mm PC audio input
9
RF IN RF / TV aerial input
10
Digital audio Digital optical audio output
11
HDMI 3 HDMI input
12
USB x2 USB input
13
CI CARD IN Common Interface module
14
1
EARPHONE
*The Ethernet port is used only for Freeview HD services only.
2
3
VIDEO
4
L
567 8 91011
R
Y Pb Pr
VGA/PC IN
VG A/PC (Audio in)
Digital Audio
Output
12 13 14
USB
CI CARD IN
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Connections22
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 22User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 22 04/12/2015 13:06:1104/12/2015 13:06:11
Connections
Bringing it all together
Connections
Connecting a camcorder, camera or games console.
The TV source should be set to composite/AV.
L (white)
R (red)
Video
(yellow)
Connecting a DVD player/recorder, video recorder or cable/satellite box.
AV
out
Source should be set to composite/video.
L (white)
R (red)
Video
(yellow)
Scart
Connecting a High Definition (HD) Device Option 1 - via HDMI to HDMI cable
A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio with
minimal loss of quality.
TVs Source should be set to the corresponding HDMI Port (HDMI 1, HDMI 2, etc).
HDMI HDMI
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Connections 23
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 23User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 23 04/12/2015 13:06:1104/12/2015 13:06:11
Connections
Connecting a High Definition (HD) Device Option 2 - via Component cable
If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors you must
connect via Component (for picture) and by phono cable (for sound).
TV Source should be set to Component/YPbPr.
Y (green)
Mini
YPbPr
PB (blue)
PR (red)
L (white)
R (red)
L (white)
R (red)
Connecting to a device with VGA/PC output (Laptop or Desktop Computer)
Source should be set to VGA/PC
VGA/PC
in
VGA/PC
(audio
in)
VGA/PC
out
Audio
out
Connecting to an external audio device (Amplifiers, Surround Sound, Sound Bars etc)
When connecting via the TV’s 3.5mm Earphone output, this will disable the TV speakers.
There are two options when connecting a device via the 3.5mm Earphone Output and the Digital Optical Audio
Output
3.5mm
earphone
Digital
audio
out
(optical)
OPTION 1 for 3.5mm EARPHONE Output
OPTION 2 for Digital Optical Audio Output
Connecting an Ethernet/Network cable
The Ethernet port is used only for Freeview HD services only.
Ethernet
port
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
3.5mm
Ethernet
port
audio
in
Digital
audio
in
(optical)
Connections24
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 24User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 24 04/12/2015 13:06:1104/12/2015 13:06:11
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 25User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 25 04/12/2015 13:06:1104/12/2015 13:06:11
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 26User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 26 04/12/2015 13:06:1104/12/2015 13:06:11
Standard features
4
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 27User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 27 04/12/2015 13:06:1104/12/2015 13:06:11
Standard features
Standard features
Simple everyday use
Simple everyday use
How to navigate the menus
To access this menu, press [MENU] button on the
remote control. To enter a menu press [OK]
If you wish to make changes to any of the default
settings, use the scroll
any settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
buttons. To confirm
Tip: If you do not press any buttons for 30 seconds,
the menu will automatically exit. You can change the
length of time before the menu exits automatically -
see ‘OSD Timer’ in the Time Menu.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Standard features28
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 28User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 28 04/12/2015 13:06:1104/12/2015 13:06:11
Standard features
Simple everyday use
Channel menu
Auto Tuning - Allows you to retune the television
for all digital channels, digital radio stations and
analogue channels.
Freeview Manual Tuning - Allows you to manually
tune your digital signal
Analogue Manual Tuning - Allows you to manually
tune your analogue signal
Channel Edit - Allows you to delete, move, skip and
add favourite channels.
Signal Information - Displays signal strength
information
CI Information - Pay per view services require a
“smartcard” to be inserted into the TV. If you subscribe
to a pay per view service the provider will issue you
with a ‘CAM’ and a “smartcard”. The CAM can then
be inserted into the COMMON INTERFACE PORT
(CI Card In).
Schedule List - Lists your programme reminders
Software Update (OAD) - Switch on/off OAD updates
Tip: If you do not press any buttons for 30 seconds,
the menu will automatically exit. You can change the
length of time before the menu exits automatically -
see ‘OSD Timer’ in the Time Menu.
Important: To receive Freeview channels, in
particular Freeview HD channels, you will need a
Digital TV aerial and be in a good Freeview coverage
area. You can check coverage for your postcode at
www.freeview.co.uk
Please note that any Freeview HD channels
found during tuning will be placed in channel
positions above 100. For example, 101 (BBC1 HD)
102 (BBC2 HD) etc.
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Standard features 29
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 29User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 29 04/12/2015 13:06:1204/12/2015 13:06:12
Standard features
Simple everyday use
Picture menu
Dynamic - Recommended settings for fast
moving pictures.
Standard - Default settings.
Mild - Set to be lighter in colour and less bright.
Personal - Lets you manually alter all the settings.
Economy - Power saving mode which reduces the
energy used by up to 25% (by reducing the power to
the LED/LCD panel). In Economy mode, the TV will
switch itself to Standby mode after 3-5 hours in the
event that the TV buttons or remote control buttons
are not pressed (change the picture mode to another
setting to de-activate this function).
Aspect Ratio - Within the UK the picture format varies
depending on the channel/broadcast. There are a
number of different options to best meet your needs.
• Point2Point - Will display the picture in its original
resolution without any change. Only available
when the TV source is set to HDMI.
• Auto - Automatically displays the best
picture format. So the picture is in the correct
position. May have black lines at the top/bottom
and/or sides.
• 4:3 - Displays the 4:3 picture in its original size.
Side bars are shown to fill the 16:9 screen.
• 16:9 - Fills the screen with a regular 16:9 signal and
4:3 will stretch to fill the screen.
Contrast - Switch the balance between black and
white.
Brightness - Increase or decrease the brightness of
the picture.
Colour - Increases the colour from black and white.
Tint - Lets you increase or decrease the level of tint
within the picture (only available in VGA/PC source
mode).
Sharpness - Increase or decrease the sharpness of
the picture.
Colour Temperature
• Normal - Default settings.
• Warm - Increases red within the picture.
• Cool - Increases blue within the picture.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Standard features30
• Zoom1 and Zoom 2 - The picture is the correct
proportion but zoomed in to fill the screen.
Noise Reduction
• Off - Turns noise reduction off.
• Low - Minor system adjustment.
• Middle - Medium system adjustments.
• High - Maximum system adjustments.
Screen - Allows you to adjust screen settings
when the TV is used a PC monitor and the .TV is set
to VGA/PC source.
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 30User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 30 04/12/2015 13:06:1204/12/2015 13:06:12
Standard features
Simple everyday use
Sound menu
Sound Mode
Standard - Default settings.
Music - Emphasises music over voices.
Movie - Provides live and full sound for movies.
Sports - Emphasises sound for sports.
Personal - Selects your personal sound settings.
Audio Description - This allows the user to increase
and decrease the AD (Audio Description) volume
level. (Audio Description is a service available on
certain programmes. It provides a description of what
is happening during the selected programme for a
person who is visually impaired).
Digital Output
• Off - Off.
• Auto - Selects the best settings automatically.
• PCM - Select this option if you are connecting
to a Stereo Hi-fi via coax cable (Pulse-code
modulation (PCM) is a digital representation of
an analogue signal).
Audio Delay - Enables the user to adjust setting to sync
picture and audio.
Tip: Treble and bass levels can only be adjusted
when the sound mode ‘personal’ is selected.
Balance - To switch the so und between the left and
right speakers.
Auto Volume Level (AVL) - When ‘on’ is selected,
the volume will stay at a constant level regardless of
input/source.
Surround Sound
• Off - Off.
• TruSurround HD - TruSurround HD™ creates an
immersive, feature-rich surround sound experience
from two speakers, complete with rich bass, high
frequency detail and clear dialog.
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the
Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruSurround is a trademark of DTS,
Inc. © DTS, Inc. All Rights Reserved.
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Standard features 31
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 31User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 31 04/12/2015 13:06:1204/12/2015 13:06:12
Standard features
Simple everyday use
Time menu
Clock - Shows the date and time.
Time Zone - Change your current time zone.
Sleep Timer - Lets you set the sleep timer so the
television automatically switches off after a set amount
of time. Off -> 10min -> 20min -> 30min -> 60min ->
90min -> 120min -> 180min -> 240min.
OSD Timer - Lets you adjust the amount of time
the On Screen Menu stays on the screen before
disappearing.
Auto standby - Set Auto standby between 3 hours, 4
hours and 5 hours ( to turn off this function you must
exit Home Mode in the Picture Menu).
Setup menu
Audio language - Allows the user to change the audio
language.
Subtitle Language - Allows the user to change the
subtitle language.
Hearing Impaired - This allows the user to turn on
the Hearing Impaired function, this produces subtitles
on the screen which provide a description of what is
happening during the selected program.
PVR File System - Allows you to view the format and
performance of a USB key.
Blue Screen - Changes the background when there is
no input between clear and a blue background (Only
available on some sources).
Network Configuration - Allows you to manually set
your network settings on the TV (for more information
please see ‘Network Configuration’ page.
First Time Installation - Allows you to retune the
television for all digital channels, digital radio stations
and analogue channels.
HDMI CEC (Consumer Electronic Control) - Allows
HDMI devices to control each other and allows the
user to operate multiple devices with one remote
control. (only available with compatible devices)
Software Update (USB) - This menu lets you install
the new software/firmware onto the television.
Further details of how to do this will be issued with the
firmware. Contact the helpline or refer to the ‘product
support’ section of the website.
Reset TV - This resets the menus to factory settings
and will erase all TV channels stored on the television.
Language - Allows you to change the language of the
menu.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Standard features32
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 32User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 32 04/12/2015 13:06:1204/12/2015 13:06:12
Standard features
Simple everyday use
Lock menu
System/Hotel Lock - Allows you to lock or unlock the
menu. You will be asked to enter a 4 digit password use
the button to quit the password input. Use the
button to clear. Default password is 0000
Change Password - Allows you to change the
password
Channel Lock - Allows you to lock certain channels
manually
Parental Guidance - Allows you to set the rating to
block certain content based on age information
TV Button Lock - Allows you to lock the buttons on
the side of the TV set
Default Source - Allows the user to set the default
source. The default source is the source the TV starts
on when first switched on
Default Channel - Allows the user to set a channel as
the default channel on the Digital source. The default
channel is the channel the TV starts on when first
switched on
Max Volume - Allows you to adjust and set the
maximum volume
Source Lock - Allows you to lock the source menu
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Standard features 33
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 33User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 33 04/12/2015 13:06:1204/12/2015 13:06:12
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 34User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 34 04/12/2015 13:06:1204/12/2015 13:06:12
Advanced features
5
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 35User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 35 04/12/2015 13:06:1204/12/2015 13:06:12
Advanced features
Getting the most from your TV
Network confi guration
For the network configuration to work the TV will need to be connected to your home network via an Ethernet
cable, with these requirements in place the TV will connect to the network automatically.
If you are looking to change the configuration to a static IP address this can be done by following the instructions
below.
1)
1) In the Setup Menu you will need to highlight and select Network Configuration.
2) When the Network menu appears highlight and select Wired Network.
3) Next the Wired Network menu will appear please highlight and select Configuration.
4) 5) 6)
2)
3)
4) The Network Configuration menu allows you to choose between DHCP and Static.
DHCP - will automatically connect the TV to your home network (this is the default setting and is highly
recommended).
Static - is an advanced option and allows you to manually change the IP, Netmask, Gateway and DNS information.
5) If the static option is chosen you will able to scroll down and manually change the IP, Netmask, Gateway and
DNS information.
6) When the connection process is completed with either DHCP or Static option the Success screen will appear.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Advanced features36
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 36User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 36 04/12/2015 13:06:1204/12/2015 13:06:12
Advanced features
Getting the most from your TV
DVD setup
Applies to TV models with built in DVD players only.
TV Display - Choose from the following options
4:3 Pan Scan PS Traditional picture format, often used on old fi lm
4:3 Letter Box LB Traditional picture which has been adapted for widescreen
Wide 16:9 Widescreen picture format
Speaker Setup - Choose from the following options
LT/RT Converts from multi-channel sound to mono
Stereo Converts from multi-channel sound to Stereo
Dual Mono - Choose from the following options
Stereo Outputs 2 channels of sound both left and right
Mono L Outputs left side sound
Mono R Outputs right side sound
Mix Mono Outputs a single channel of sound but mix between right and left
Dynamic Range - This is the difference between the quietest and loudest sounds. This setting works only with DVD discs
recorded in Dolby digital.
Full Set this to listen with the range recorded on the disc
3/4 Set this to listen with a range equivalent to a normal television
1/2 Set this to listen with a smaller di erence between the maximum and minimum volume
1/4 Set this to listen with a smaller di erence between the maximum and minimum volume
O Set dynamic range to o
TV Type - Choose from the following options
PAL For discs from UK/Europe, Asia, Australia etc
Multi For both NTSC and PAL
NTSC For discs from North America, Japan etc
Default - Choose from the following options
Reset Resets all options in the ‘DVD setup’ menu back to the default settings
Tip: This TV/DVD player is pre-set to play Region 2 DVDs. In the event you wish to use the TV/DVD in
another country that uses different region discs, please visit www.umc-uk.co.uk. Select ‘Product Support’,
‘Changing Region’.
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Advanced features 37
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 37User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 37 04/12/2015 13:06:1204/12/2015 13:06:12
Advanced features
Getting the most from your TV
7 day TV guide and channel list
TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported
by the freeview channel). You can view the start and end time of all programmes and on all channels for the next 7
days and set reminders.
1) Press [TV GUIDE]. The following 7 Day TV Guide will appear.
7 Day TV GUIDE
1 BBC ONE Oxford
12:15 - 13:00 11 Dec 2014
Norfolk: Tim wonnacott and the teams are in Norfolk in search of great buys to take to auction.
Expertise comes from Catherine Southon and Jonathan Pratt, and Tim visits Ham House.
CHANNEL
1 BBC ONE Oxford
2 BBC TWO
3 ITV
4 Channel 4
5 Channel 5
6 ITV2
7 BBC THREE
9 BBC FOUR
Record
Move
12:00
Bargain Hunt
Daily Politics The Blue Planet
Let’s Do Christmas with Gino and Mel
Come Dine with Me
Three Wise Women
Prev. Day
Info. Exit.
Info
13:00 13:30Now
BBC News at One South...
Jame...
Coronation Street
This is BBC Three
This is BBC Four
Next Day
EXIT
11 Dec 2014 12: 58
Come Dine with Me
5..
You’ve Been Framed! Royal...
2) Navigate through the menu using
You can now:
View a previous day by pressing GREEN,
View the next day by pressing YELLOW
Set a reminder by pressing BLUE
3) Press [EXIT] to exit the 7 day TV Guide.
Lifestyle
Doctors
ITV News & Weather
Come Dine...
Home and Away
Remind
OK
OK
Channel list
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
To view the channel list, please ensure that the TV is set to either the analogue
or digital source and no menus or TV notifications are displayed.
1) Press [OK] on the remote control and the
channel list menu will appear.
2) Scroll through the channel list by using
buttons then
press [OK] to view the channel that is currently highlighted.
You can also:
View Freeview HD channels by pressing RED
View standard definition Freeview channels by pressing GREEN
View radio channels by pressing YELLOW
View all channels by pressing BLUE
3) Press [EXIT] to exit the channel list.
Advanced features38
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 38User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 38 04/12/2015 13:06:1204/12/2015 13:06:12
Advanced features
Getting the most from your TV
USB media player
USB mode offers playback of various different types
of content that you have saved on your USB Memory
Stick.
On switching to USB source the menu screen will
appear. The content will be divided into Photo, Music,
Movie and Text based on file type.
1) You can navigate through the menus using the scroll
buttons. To confirm the item you wish to play/
view press [OK] button.
2) Select the drive you require.(If your drive only has 1
partition you will only see 1 item).
3) You can now access the item. Press OK to view.
4) While viewing you control the item using (Fig A).
or by pressing ( i ) and using
Tip: If you experience a playback issue, please
ensure the files being used are the correct format
(example - the picture plays but no sound)
and (OK).
1)
2)
3)
For the best performance, do not use USB
extension cable. See technical specifi cation page
for compatible fi le types.
4)
Fig A
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Advanced features 39
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 39User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 39 04/12/2015 13:06:1204/12/2015 13:06:12
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 40User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 40 04/12/2015 13:06:1304/12/2015 13:06:13
Product support
6
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 41User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 41 04/12/2015 13:06:1304/12/2015 13:06:13
Product support
Help is always at hand
Connecting a sky digital set top box
Using a Sky Remote or a Universal Remote to operate your TV
Sky Remote Control - If you wish to use your Sky remote to operate the basic functions of your TV, you need to
program a 4 digit code into it. Please note - you will need a Sky Revision 9 remote control (or later). If you wish to
upgrade/replace your existing Sky remote control to the latest version, you can do so on our website.
Universal Remote Control - If you wish to use a Universal remote control to operate your TV, please refer to the
website for a full list of codes. (Please note we only have codes for One for All branded remote controls, if you
have an alternative brand of Universal remote, please refer to the manufacturer for the code).
Connecting your TV to your Sky box (when both the TV and Sky Box are located in the same room)
Option 1)
Depending on your Sky Box & TV model, connect either by SCART or HDMI cables (available separately).
If connecting by SCART, select the ‘Input source’ on the TV as SCART. If your TV model does not have SCART,
please refer to the ‘Connections’ pages in this user guide for alternative ways to connect.
If connecting by HDMI, select the ‘Input source’ on the TV as HDMI (if the TV has more than 1 HDMI port, ensure
you select the input source to match the HDMI numbered port on the rear of the TV).
If you wish to use your Sky remote to operate the TV’s functions, you will need a Sky remote control (Revision 9 or
later) and you will need to program a 4 digit code into it.
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Product support42
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 42User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 42 04/12/2015 13:06:1304/12/2015 13:06:13
Product support
Help is always at hand
Connecting your TV to your Sky box (when your Sky box is located in a different room to the TV)
Option 2)
Please note, if you are adding a ‘Magic Eye/TV Link’ to your system so that you can use your Sky remote control to
change the Sky channel in the room where the 2nd TV is located, please refer to the instructions included with the
TV link/magic eye in order to ensure the RF or RF2 output on your Sky box is powered on. (The red LED light on
the TV link/magic eye will light up if the RF/RF2 output is correctly set up) If you do not have the instructions that
came with the TV link/magic eye, instructions on how to do it can be found on our website.
1) To tune the TV to the Sky box, on the 2nd TV, select the ‘Analogue’ input source.
2) Select the channel that you wish to store the Sky box/channel on. (If you do not use channels 1-5 because you
no longer have analogue terrestrial channels after digital switchover, you may choose to select channel 1 to store
the Sky box/channel, if you still have and use analogue channels 1-5, you may for example decide that channel 6 is
the best option for you)
3) Press the corresponding number on the remote control to select the desired analogue channel chosen as per
point 2 above.
4) On the TV remote control, press Menu. Now navigate through the menus to select Manual Tuning or Analogue
Manual Tuning (refer to the Tuning/Channel menu section of this user guide if necessary)
5) Manually tune in the channel (usually, the Sky box is at a frequency between 800Mhz and 850Mhz) once the Sky
box/channel is found, press ‘OK’ to store it. If you wish to use your Sky remote to operate the TV’s functions, you
will need a Sky remote control (Revision 9 or later) and you will need to program a 4 digit code into it.
If you wish to use your Sky remote to operate the TV’s functions, you will need a Sky remote control
(Revision 9 or later) and you will need to programme a 4 digit code into it.
2nd TV in
another room
Connect to the
SCART
or HDMI
cable
RF/COAX cable from
Sky Box to 2nd TV
Aerial/RF input
on the 2nd TV
Sky Box
Connect to RF
or RF2 output
on the Sky box
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
TV Link/Magic Eye
(optional)
Product support 43
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 43User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 43 04/12/2015 13:06:1304/12/2015 13:06:13
Other information
Helpful technical information
Frequently asked questions
General I would like to have
louder sound by
connecting additional
speakers.
General Why are some
options in the menu
unavailable and greyed
out.
General Can I stop my TV
automatically turning
o after 4hrs?
TV I have tuned in Digital
TV but I am not
receiving any or all of
the channels and/or
the channels I receive
are breaking up.
1) Use the 3.5mm headphone output and a 3.5mm to phono cable (available
separately) to connect to an amplifi er/surround sound system. Please note
this will deactivate the TV’s built in speakers.
2) Connect a COAX cable from the TV’s COAX output to your amplifi er/
surround systems COAX input.
Some options are only available in certain sources, i.e. HDMI. They are
unavailable in the other sources where they have no a ect.
Yes, in the ‘Time’ menu settings, scroll down to Auto standby and select OFF.
1) Check you are in an area that can receive Freeview/Saorview, visit www.
freeview.co.uk or www.saorview.ie
2) Check you are using an aerial that is able to receive a good digital signal.
In most cases, you will need an outdoor digital hi-gain/wideband aerial.
In areas that have excellent digital coverage, you may be able to use a loft
type aerial but it is highly likely that you will also need to connect a booster
between the back of the TV and the TV aerial wall socket. Unfortunately,
to receive a good enough digital signal, it is not possible to use a portable/
indoor type aerial.
TV I have re-tuned my
television but when
I switch it o it is not
storing the channels.
VCR/DVD
Recorder
Game
Consoles
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
I have connected the
TV to my VCR or DVD
Recorder via SCART but
it is not recording.
I have connected my
Playstation/Xbox to
the TV via HDMI, but I
am not receiving any
pictures or sound on
my Television.
If the TV does not save the channels when you power it o , it’s likely the
channel database has become corrupt.
1) Turn o the TV.
2) Remove the RF/Aerial cable from the rear of the TV and then turn the TV
back on again.
3) Using the remote control, press Menu followed by 8-8-8-8 to enter the
initial setup/fi rst time installation menu.
4) Press OK (let the TV run the full tuning process).
5) Once completed, turn o the TV, reconnect the RF/Aerial cable then turn
the TV back on again.
6) Repeat steps 3 & 4.
In addition to connecting via SCART, you should connect the aerial cable
from the wall socket to your VCR/DVD Recorder and another aerial cable
from the VCR/DVD Recorder to the TV.
1) Ensure the TVs’ source is set to HDMI.
2) Check your settings on your Playstation/Xbox are as per the Playstation/
Xbox instruction manual.
Other information44
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 44User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 44 04/12/2015 13:06:1304/12/2015 13:06:13
Product support
Help is always at hand
Frequently asked questions
Game
Consoles
System Lock I have changed the
USB Mode I have inserted a USB
USB Mode Using a USB portable
DVD (For TV
models with
DVD only)
I have connected my
Playstation/Xbox to
the TV via Component
cables (red, green &
blue) but I am not
receiving any sound.
password on the
television and now
forgotten it.
Memory Key, but the
TV does not recognise
it.
hard drive / larger than
32GB.
I have inserted a disc
but it is not playing.
Component cables only provide HD pictures. For the sound you will need
to connect the red & white audio cables on the Playstation/Xbox to the red
& white phono inputs (or mini AV input where fi tted) on the rear of the TV.
Please refer to the ‘Connections’ pages.
There is a master password of 4711, to gain access to the TV menu and reset
the normal password.
Ensure the USB Memory Key is formatted to type FAT32.
If you wish to use a portable hard drive larger than 32GB, please note that
it must be formatted to the FAT32 fi le system in order to operate on this TV.
Windows XP/Vista computers are only capable of formatting up to 32GB,
therefore, you will need a software programme/utility to format larger hard
drives.
Please refer to the website, www.umc-uk.co.uk, for more information.
1) Ensure you have inserted the disc facing the correct way.
2) Ensure the disc is clean and is not scratched.
3) Some copied discs will not play.
4) Check the DVD is a region 2 disc – to change the region of the DVD
player, refer to www.umc-uk.co.uk, select ‘Changing DVD Region’ in the
‘Product Support’ section
DVD (For TV
models with
DVD only)
Freeview HD I cannot access all
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
I have pressed the eject
button but the disc is
not coming out.
Freeview channels
To eject the disc hold the stop/eject button for 4 seconds.
Some data channels for Freeview can only be obtained when the TV
receives an internet connection.
Product support 45
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 45User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 45 04/12/2015 13:06:1304/12/2015 13:06:13
Product support
Help is always at hand
Technical specifi cation
Product fiche
Trademark
Model ID
Energy effi ciency class A +
Visible screen size (diagonal) 102 cm / 40 inches
On mode power consumption 48.0 W
Annual energy consumption *1 70 kWh
Standby power consumption *2 <0.50 W
Off mode power consumption 0 W
Screen resolution 1920 (H) x 1080 (V)
*1: Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4 hours per day for 365 days. The actual energy
consumption will depend on how the television is used.
*2: When the TV is turned off with the remote control/standby button and no function is active.
Additional Technical Information
RF
Video Inputs 3 x HDMI, 2 x USB, 1 x Composite/Video,
Sound Inputs
Sound Outputs 1 x Digital Optical Audio output, 1 x 3.5mm Headphone
Speaker / Amplifi er Watts (RMS) 2 x 10W / 2 x 8W
Dimensions including stand (mm)
Net weight
Energy Consumption Info
Voltage and power consumption
48 / 75 / 90W (ecomode/standard/max)
Wallmounting VESA
40/133F 40/133FDVD
75 ohm Antenna / Analog / DVB
1 x Mini Component/YPbPr, 1 x VGA/PC,
1 x shared audio for Composite/Video & Component/YPbPr,
1 x 3.5mm jack for PC audio input
8.1 kgs 8.4 kgs
110-240v 50 / 60Hz
EEI - A+ (Energy Rating)
Bush
929 W x 600 H x 200 D
110-240v 50 / 60Hz
48 / 75 / 100W ((ecomode/standard/max)
EEI - A+ (Energy Rating)
200 x 200 (mm)
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Product support46
Product support46
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 46User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 46 04/12/2015 13:06:1304/12/2015 13:06:13
Product support
Help is always at hand
Technical specifi cation
Compatible files in USB Mode
Media File Ext.
.mpg/.mpeg
/.dat
.ts/.trp/.tp/.
m2ts
.vob MPEG-2
.mp4
.rm/.rmvb Rm codec
Movie
Music
.mkv
.avi
Motion JPEG JPEG
.asf,wmv VC1
.flv/.swf
.mp3 --
.wma/.asf --
.ogg -- OGG Sample Rate: ~48KHz
.m4a/.aac -- AAC HEAAC
.jpg/
.jpeg
.bmp BMP
.png
Video Decoder
Video Audio
MPEG-1, MPEG-2
MPEG-2, H.264,VC1,AVS
MPEG-4, Xvid, H.264
MPEG-1, MPEG-2, MPEG-4,
H.264
MPEG-2, MPEG-4,
Xvid, H.264
H.264, AVC, Sorenson
H.263
Progressive JPEG Max Resolution: 1024×768
Baseline JPEG
Non-Interlaced
Interlaced Max Resolution: 1200×800
MP3, WMA,AAC,
LPCM,DTS(DMP)，
IMA-aDPCM/MS-A
AAC, LPCM
DPCM,LBR(cook),
G711A/mu-law
MPEG1/2 (Layer1，
Layer2，Layer3)
WMA
WMA pro
MP3, WMA,
Remark
Max Solution: 1920×1080
Max Data Rate: 40 Mbps
Max Solution: 640×480
Max Data Rate: 10 Mbps
Max Solution: 1920×1080
Max Data Rate: 40 Mbps
Sample
Rate: 16KHz~48KHz
BitRate: 32K~448Kbps
BitRate: 128Kbps~320Kbps
Sampling rate : 8KHz-48KHz
BitRate: <768Kbps
Sampling rate : ~96KHz
Sample Rate: 8K~48KHz
Bit Rate: 24K~384Kbps
Max Resolution:
1920×8×1088×8
Max Resolution:
9600×6400
Max Resolution:
9600×6400
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0330 024 0805. (Calls are charged at the standard rate of your network provider).
Product support 47
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 47User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 47 04/12/2015 13:06:1304/12/2015 13:06:13
Product support
Help is always at hand
Call us now and activate your 12 month guarantee
Thank you for choosing Bush. Your new product is guaranteed against faults and
breakdowns for 12 months. Don’t forget to register it with us today so we can provide you
with our best possible after-sales service and useful updates.
www.bushregistration.co.uk
FREEPHONE*
0800 597 8548
Lines are open 8am - 8pm, 365 days a year. *Calls may be recorded and monitored.
Your Bush Guarantee
This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to
faulty materials or workmanship will be repaired free of charge (or if applicable the product will be replaced or the
purchase price refunded) where possible during this period by the dealer from who your purchased the unit.
The guarantee is subject to the following provisions:
• The guarantee does not cover accidental damage,
misuse, cabinet parts, knobs or consumable items.
• The product must be correctly installed and
operated in accordance with the instructions
contained in the manual.
• It must be used solely for domestic purposes. The
guarantee will be rendered invalid if the product is
re-sold or has been damaged by inexpert repair.
• Specifications are subject to change without notice.
• Bush disclaim any liability for loss or damage arising
from the breakdown of the product.
• This guarantee is in addition to and does not
diminish your statutory or legal rights.
Important Data Protection Information
If you provide us with information about another
person, you confirm that they have appointed you
to act for them, to consent to the processing of their
personal data including sensitive personal data and
that you have informed them of our identity and the
purposes (as set out in the Important Data Privacy
notice displayed overleaf) for which their personal data
will be processed.
You are entitled to ask for a copy of the information
we hold about you (for which we may charge a small
fee) and to have any inaccuracies in your information
corrected.
For quality control and training purposes, we may
monitor or record your communications with us.
If your personal details change, if you change your
mind about any of your marketing preferences or if you
have any queries about how we use your information,
please let us know by contacting our Data Protection
Officer, Domestic & General, Leicester House
17 Leicester Street, Bedworth, Warwickshire
CV12 8JP.
Guarantor: Argos Limited - 489 - 499 Avebury Blvd. - Milton Keynes - MK9 2NW
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 48User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 48 04/12/2015 13:06:1304/12/2015 13:06:13
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 49User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 49 04/12/2015 13:06:1304/12/2015 13:06:13
Contact:
www.umc-uk.co.uk
Helpline: 0330 024 0805
BUS/MAN/0026
User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 50User Guide - BUS-MAN-0026 BUSH 40-133F -40-133Z-WB-11B-FGKUS-UK.indd 50 04/12/2015 13:06:1304/12/2015 13:06:13
Loading...
