1473-1 -7925 │ Rev. 01 │ 17.12.2012
Dimmer
6519 U
6513 U
6513
Operating Instructions
Busch-Dimmer®
Pos: 2 /#N eustr uk tur #/Onl ine- Dok umen ta tion ( +KN X) /Tit elbl ät ter/D i mmer /Tit elbl att - 65 13/6 519 @ 21\ mod_1331117836768_15.docx @ 201733 @ @ 1
-500
-102-500
-102-500
=== Ende der Li st e für Te xtm arke Cov er == =
Operating Instructions
Busch-Dimmer®
Operating Instructions | 1473-1-7925
— 2 —
Pos: 4 /#N eustr uk tur #/Onl ine- Dok umen ta tion ( +KN X) /In halt sver zei chni s ( --> Für all e D oku ment e <--) /Inhal tsver zeich nis @ 19 \mod_1320649044386_15.docx @ 109653 @ @ 1
Safety ....................................................................................................................................................................... 3
1
2 Intended use ............................................................................................................................................................ 3
3 Environment ............................................................................................................................................................. 3
4 Technical data .......................................................................................................................................................... 4
5 Setup and function ................................................................................................................................................... 5
5.1 Features of function and equipment ........................................................................................................ 5
5.2 Possible combinations ............................................................................................................................ 6
6 Reduction of the connection load (derating)............................................................................................................. 7
7 Installation and electrical connection ....................................................................................................................... 8
7.1 Requirements for the electrician ............................................................................................................. 8
7.2 Mounting ................................................................................................................................................. 9
7.3 Electrical connection ............................................................................................................................. 10
7.4 Inserting the glow lamp ......................................................................................................................... 11
=== Ende der Li st e für Te xtm arke TOC == =
Operating Instructions
Busch-Dimmer®
Safety
Operating Instructions | 1473-1-7925
— 3 —
Warning
Consider the protection of the environment!
device at the appropriate collecting depot.
Pos: 6 /#N eustr uk tur #/Onl ine- Dok umen ta tion ( +KN X) /Ü bersc hri fte n (-- > Für all e D oku ment e <--)/1. Ebene/S - T/Sicherhei t @ 18\mod_1302612791790_15.docx @ 103357 @ 1 @ 1
1 Safety
Pos: 7 /#N eustr uk tur #/Onl ine- Dok umen ta tion ( +KN X) /Si cher hei tshi nw eis e un d Hi nweis e ( --> F ür all e D o kume nte < --)/W arn hinw eis e/Sic herh eit - 230 V @ 18\mod_1302606816750_15.docx @ 103308 @ @ 1
Electric voltage!
Risk of death and fire due to electrical voltage of 230 V.
– Work on the 230V supply system may only be performed by authorised electricians!
– Disconnect the mains power supply prior to installation and/or disassembly!
Pos: 8 /#N eustr uk tur #/Onl ine- Dok umen ta tion ( +KN X) /Ü bersc hri fte n (--> Für alle Do ku ment e <--)/1. Ebene/A - F/Bestimmu ngsg emäßer Gebra uch @ 18\ mod_1302763321316_15.docx @ 103483 @ 1 @ 1
2 Intended use
Pos: 9 /#N eustr uk tur #/Onl ine- Dokumentation (+KNX)/Bestimmungsgemäßer Gebrauch (--> Für alle Dokumente <--)/Busch-Di mmer /B esti mm ungsg em äßer Gebr a uch @ 2 3\mod_1335350449857_15.docx @ 208763 @ @ 1
The device is to be used exclusively with the components that are supplied and licensed as described in chapter
"Setup and function".
Pos: 10 /#N eustr u ktur #/O nline-Do ku ment ati on (+ KN X)/Ü ber sc hrift en ( --> F ür all e D ok ume nte < --)/1. E bene/U - Z/U mwel t @ 18\mod_1302614158967_15.docx @ 103383 @ 1 @ 1
3 Environment
Pos: 11 /#N eustr u ktur #/O nlin e-Dokumentation (+KNX)/Sicherheitshinweise und Hinweise (--> Für alle Dokumente <--)/Hinweise - Umwelt/Hinweis - Umwelt - Hinweis Elektrogeräte @ 18\mod_1302763973434_15.docx @ 103500 @ @ 1
Used electric and electronic devices must not be disposed of with domestic waste.
– The device contains valuable raw materials which can be recycled. Therefore, dispose of the
Pos: 12 /#N eustr u ktur #/O nlin e-Dokumentation (+KNX)/Sicherheitshinweise und Hinweise (--> Für alle Dokumente <--)/Hinweise - Umwelt/Hinweis - Umwelt - Entsorgung Elektrogeräte @ 20\mod_1325760695972_15.docx @ 136583 @ @ 1
All packaging materials and devices bear the markings and test seals for proper disposal. Always dispose of the
packaging material and electric devices and their components via the authorized collecting depots and disposal
companies.
The products meet the legal requirements, in particular the laws governing electronic and electrical devices and
the REACH ordinance.
(EU Directive 2002/96/EC WEEE and 2002/95/EC RoHS)
(EU REACH ordinance and law for the implementation of the ordinance (EC) No.1907/2006)
Pos: 13 /#N eustr u ktur #/O nlin e-Do ku ment ati on (+ KN X)/S teuer m odul e - Online-Dokumentation (--> Für alle Dokumente <--)/++++++++++++ Seitenumbruch ++++++++++++ @ 9\mod_1268898668093_0.docx @ 52149 @ @ 1
Operating Instructions
Busch-Dimmer® Technical data
Operating Instructions | 1473-1-7925
— 4 —
General
Nominal voltage
230 V AC ± 10 %, 50 Hz
Nominal power
(depending
power loss of 5% in case of electronic
transformers needs to be considered)
Minimum load
40 W / VA
Module width
3 MW (1 MW = 18 mm) applies only to Modular DIN Rail Component (MDRC)
Short-circuit protection
Electronic
Overload protection
Electronic
Radio interference suppression
According to EN 55015
Total ambient temperature range
0 ...70 °C
Connected load
- Ambient temperature range
0 ...35°C connected load 100 %
- Ambient temperature range
35 ... 70°C reduced connected load (Derating)
Terminal 4
Nominal voltage
230 V AC ± 10 %, 50 / 60 Hz
Nominal current
100 mA
Series circuit-breaker
0,5 A
Note
Pos: 14 /#N eustr u ktur #/O nlin e-Do ku ment ati on (+ KN X)/Ü ber sc hrift en ( --> F ür all e D ok ume nte < --)/1. Ebene/S - T/Technische Daten @ 11\mod_1279185386320_15.docx @ 83019 @ 1 @ 1
4 Technical data
Pos: 15 /#N eustr u ktur #/O nlin e-Dokumentation (+KNX)/Technische Daten/Dimmer/Technische Daten - 6513/6519 @ 21\mod_1331118004651_15.docx @ 201747 @ @ 1
on the ambient temperature, a
Terminal 4 is intended for operation with voltage sensors, see Fig. 4.
Pos: 16 /#N eustr u ktur #/O nlin e-Do ku ment ati on (+ KN X)/S teuer m odul e - Online-Dokumentation (--> Für alle Dokumente <--)/++++++++++++ Seitenumbruch ++++++++++++ @ 9\mod_1268898668093_0.docx @ 52149 @ @ 1
6513 … :
6519 U … :
420 W / VA
550 W / VA
