BURNDY®EC&M Tooling
158
Tooling BURNDY
®
EC&M
INSTALLATION TOOLING SYSTEM
Installation Tooling System
Lugs & Splices
One & Two T&B Taps Taps Taps
Hole Index* Thin-Wall C-Taps Heavy Duty C-Taps H-Taps
Conductor Run=Tap Code Run=Tap, AWG Only Run=Tap Run=Tap
AWG Flex Die Color Index (Flex) Die Color Index Die Color Index Die Color Index
8/6 W8CVT
sol.
8
U8CRT
Red 49 21 W4CVT Gray 8 U240 Red 240 U11T-1 Green 11
W5CVT
66
U5CRT
Blue 7 24 W2CVT Brown 10 UC Brown C UBGRT Orange BG
W4CVT
44
U4CRT
Gray 8 29 W25VT Pink 12 UC Brown C UC Brown C
3/2 W3CRT
sol. U3CRT
White 9 W26VT Black 13 UC Brown C UC Brown C
W2CVT
22
U2CRT
Brown 10 33 W27VT Orange 14 UC Brown C UC Brown C
W1CVT
11
U1CRT-1
Green 11 W28VT Purple 15 U997 Orange 997 U654 Purple 654
W25VT 42
1/0 1/0
U25RT
Pink 12
(45)
W29VT Yellow 16 U997 Orange 997 U654 Purple 654
W26VT 45 Refer to
2/0 2/0
U26RT
Black 13
(50) Catalog
U997 Orange 997 U654 Purple 654
W27VT
3/0 3/0
U27RT
Orange 14 U997 Orange 997 U654 Purple 654
W28VT 54
4/0 4/0
U28RT
Purple 15
(62)
— — — U997 Orange 997 U654 Purple 654
4/0/250
250 class
W29VT
Yellow 16 — — — U997 Orange 997 U654 Purple 654
G & H
U29RT
262/250
300 class
W30VT
White 17 — — — U1104 Brown 1104 U1104 Brown 1104
I, K & M
U30RT
W31VT
350 313
U31RT
Red 18 71 — — — U1104 Brown 1104 U1104 Brown 1104
350/ W32VT
373 U32RT
Blue 19 — — — U1104 Brown 1104 U1104 Brown 1104
W34VT
500 444
U34RT
Brown 20 87 — — — U1104 Brown 1104 U1104 Brown 1104
500/
535
U38XRT Pink L99 — — — P1103 Blue 1103 PYFR Yellow KR
600 U36RT Green 22 (99) — — — P1103 Blue 1103 PYFR Yellow KR
700 U38RT Pink 400 — — — P1103 Blue 1103 PYFR Yellow KR
750 646 U39RT Black 24 106 — — — P1103 Blue 1103 PYFR Yellow KR
750/
777
U44XRT Yellow L115
800 P40RT Orange 25 (115) — — — P1102 White 1102 PYFR Yellow KR
1000 P44RT White 27 — — — P1102 White 1102 PYFR Yellow KR
*Die sets with a dash CK are not UL Listed. Please consult factory for further information.
Bolt Equivalent
Unified Inch Metric
Hole Size Equivalent
1/4 M6
5/16 M8
3/8 M10
1/2 M12
5/8 M16
YF-TOOL
Installation Ratchet Tool
for Bare and Insulated Ferrules
For Use On Copper Ferrules
These tools have been specifically designed
to work with ferrule types.
YF2610TOOL,
YF2210TOOL, and
YF1006TOOL have multiple
grooves for range capacity.
YF2214TOOL has one
groove to accept 22-14
AWG range.
YF4/0250TOOL
Catalog Number Capacity
YF3206TOOL 32-6 AWG
YF2610TOOL 26-10 AWG
YF2214TOOL 22-14 AWG
YF2210TOOL 22-10 AWG
YF1006TOOL 10-6 AWG
YF0801TOOL 8-1 AWG
YF0401TOOL 4-1 AWG
YF/03/0TOOL 1/0-3/0 kcmil
YF4/0250TOOL 4/0-250 kcmil
Y10D
Plier Type HYTOOL™
Combination Crimping and Cutting Tool
Features and Benefits
• Two tools in one, both a crimper and a cutter
• Saves time and money with only one tool needed
to install both nylon insulated and bare connectors
• Installs 22 - 10 AWG nylon and bare terminals and
splices
• Heavy-duty forged steel for durability and long life
• Recommended BURNDY®terminals and splices
are UL Listed and CSA Certified when installed
using the Y10D
• 5-year limited warranty
Specifications
• Weight: 13.5 oz.
• Length: 9-3/4
• Conductor Range: 22-10 AWG
