P R O D U C T S P E C I F I C A T I O N
Resilient BurkeTurf Rubber Flooring
1. PROPRIETARY PRODUCT/MANUFACTURER
1.1 Proprietary Product: Resilient BurkeTurf Rubber
Flooring - A.D.A. Compliant – FloorScore Certified
1.2 Manufacturer:
Burke Flooring
2250 South Tenth Street
San Jose, California 95112
Phone: (800) 447-8442
(352) 357-4119
Fax: (352) 357-9660
Samples: Ext 1031
Web: www.burkeflooring.com
1.3 Proprietary Product Description:
1.3.1 Construction: BurkeTurf Rubber Flooring is
manufactured from recycled truck tire strips adhered with hotmelt adhesive to a reinforced nylon scrim backing. This
rugged, carpet-like tile is highly resistant and spike-proof. Its
non-skid surface is ideal for ramps, concourses, golf pro
shops, entrances, skating rinks, schools, and other sports areas.
BurkeTurf Rubber Flooring is designed for both interior and
exterior applications, but not recommended for commercial
kitchen environments.
1.3.2 Physical Characteristics:
Thickness: 5/16" (7.94 mm)
Tile Size: 12" (30.48 cm) x 12" (30.48 cm)
Roll Size: 12" (30.48 cm) x 25 ft. (7.62 m) coils
Packaging - 25 tiles or 1 coil per carton.
2. PRODUCT PERFORMANCE AND TECHNICAL
DATA
2.1 Hardness - ASTM D 2240: ≥ 85 Shore A
2.2 Abrasion Resistance - ASTM D 3389: 0.22 mg/cycle
2.3 Slip Resistance - ASTM D 2047: COF ≥ 0.5
2.4 Flammability - ASTM D-2859 (Pill Test) - Passed;
Char Diameter = .672
3. INSTALLATION
The installation of BurkeTurf Rubber Flooring should not
begin until the work of all other trades has been completed,
especially overhead trades. Areas to receive BurkeTurf shall
be clean and maintained at a uniform temperature of at
least 70° F for 24 hours before, during, and after the
installation is completed. The BurkeTurf and adhesives shall
be conditioned in the same manner. Surfaces shall be smooth,
flat, permanently dry, clean and free of all foreign material,
such as dust, paint, grease, oils, solvents, curing and hardening
compounds, sealers, asphalt, and old adhesive residue.
BurkeTurf may be installed on any smooth, dry interior or
exterior surface. If installing on an exterior surface, do not
allow the product to be exposed to water or moisture for a
period of 96 hours after the installation to permit proper
adhesive curing. After adhesive application and
installation, the floor tiles shall be rolled with a 100 lb. 3section roller to ensure proper bonding.
3.1 Adhesives:
Burke #BR-710 One-Part Urethane Adhesive.
Trowel: 1/16" V-notched trowel
(Approximately 80 - 90 sq. ft/gal)
Burke #BR-725 Two-Part Urethane Adhesive:
Trowel: 1/16" square-notched trowel
(Approximately 125 - 150 sq. ft/gal)
4. INSTALLATION MANUAL
Refer to BurkeTurf Rubber Flooring installation instructions
for complete installation details.
5. AVAILABILITY AND COST
Available through authorized Burke distributors nationwide.
6. WARRANTY
Limited 10 year wear warranty available.
For complete details, contact Burke or an authorized Burke
distributor.
7. MAINTENANCE
Refer to BurkeTurf Rubber Flooring Installation Instructions
for complete maintenance details.
Page 2
Revision 1 - Released March, 2011 © Burke Flooring, A Division of Burke Industries
8. TECHNICAL SERVICES
Samples: Submittal samples for verification and approval
available upon request from Burke. Samples shall be
submitted in compliance with the requirements of the
Contract Documents. Accepted and approved samples shall
constitute the standard materials which represent materials
installed on the project.
For current Installation and Maintenance Instructions, Product
Specifications, and other technical data, visit us on the web at
www.BurkeFlooring.com or contact Burke at 1-800-447-8442.
