Bunn-O-Matic G9-2T HD, G9-2T DBC General Manual
INTERNATIONAL
ITE M#
Portion Control Grinders
with 2 Hoppers
Features
Portion Control Grinder
• Two hoppers hold 6 lbs. (2.7 kg) each of regular, decaf or specialty beans.
• Selected models interface to compatible BUNN brewers.
• Portion controlled for the right amount of coffee every time.
• Precision burrs for consistent, commercial-quality grind.
• The G92T HD accommodates larger brew funnels.
G9-2T HD
(funnel sold separately)
Dimensions: 24.6”H x 8.3”W x 17.6”D
(62.5cm H x 21.1cm W x 44.7cm D)
BrewWISE
• Two hoppers hold 6 lbs. (2.7 kg) each of regular, decaf or specialty beans.
• Stores individual coffee grind profiles.
• Operate any combination of equipment error-free with wireless brewergrinder interface via Smart Funnel™ and any BrewWISE
• Portion controlled for the right amount of coffee every time with 3 batch
sizes per hopper.
®
DBC Portion Control Grinder
PROJECT
DATE
®
brewer.
G9-2T DBC
(funnel sold separately)
Dimensions: 27.1”H x 8.3”W x 17.8”D
(68.8cm H x 21.1cm W x 44.7cm D)
For current specification sheets and other information, go to www.bunn.com.
Related Products
Precision Burrs
All BUNN grinders use precision burrs to
cut (not crush) the coffee beans and deliver
consistent grind distribution. BUNN burrs
are rated at a Rockwell hardness of 66C,
resulting in an exceptionally long burr life.
International models may vary in appearance.
Patents Apply
12/06
C1.2
Dimensions & Specifications
Model Product # Volts Amps Capacity Shipping Cord Agency
Weight Attached
G9-2TA HD 24250.0022 230 4.5 6 lbs. per hopper 71 lbs. Yes
(2.72 kg per hopper) (32 kg)
G9-2TA DBC* 33700.0005 230 4.5 6 lbs. per hopper 67 lbs. Yes
SST
(2.72 kg per hopper) (30 kg)
G9-2TA DBC* 33700.0009 230 4.5 6 lbs. per hopper 67 lbs. Yes
Black
(2.72 kg per hopper) (30 kg)
G9-2TB DBC 33700.0007 100 9.4 6 lbs. per hopper 67 lbs. No
(2.72 kg per hopper) (30 kg)
G9-2TB DBC 33700.0010 100 9.4 6 lbs. per hopper 67 lbs. No
Multi-BrewWISE
(2.72 kg per hopper) (30 kg)
G9-2TA DBC 33700.0012 230 4.5 6 lbs. per hopper 67 lbs. Yes
Multi-BrewWISE
(2.72 kg per hopper) (30 kg)
Note: Models accept large brew funnels for Single, Dual and other large BUNN® Brewers. Models also interface with BUNN brewers.
*Wireless interface. Funnels sold separately.
Electrical: 230 volt models require 2-wires plus ground service rated 220-240V, single phase, 50 Hz., circuit required,
3
⁄
HP motor.
4
100 volt models require 2-wire plus ground service, single phase, 50 Hz., 3/4 HP motor.
G9-2T DBC Panel
Bunn-O-Matic® Corporation - 1400 Stevenson Drive Springfield, Illinois 62703 • USA • +1-217-529-6601 • Fax +1-217-529-2827 • www.bunn.com
BUNN® practices continuous product research and improvement. We reserve the right to change specifications and product design without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
All dimensions shown in centimeters. Bunn-O-Matic Corporation owns all copyrights relating to materials in this publication. Please contact BUNN to request permission to reproduce any portion of this publication.
