Bunn-O-Matic 387000013 Specifications
Adjusts automatically to varying water pressure
AXIOM-TWIN-APS
23.5" x 17.7" x 16.0"
(59.7cm x 45.0cm x 40.6cm)
Electronic diagnostics and built-in tank drain make service easier
For high lime areas, BrewLOGIC® technology calculates flow rate
and adjusts brew time to maintain consistent pot levels
Large 200oz. (5.9L) tank provides back-to-back brewing capacity
Ensure coffee quality with programming for brew level, cold brew
lock- out and tank temperature, set easily from the front of the
machine
Coffee extraction controlled with programmable pre-infusion, pulse
brew and digital temperature precision
Brews directly into 1.9 to 3L airpots
Energy-saver mode reduces tank temperature during idle periods
Hot water faucet
SplashGard® funnels deflect hot liquids away from the hand
Twin brew head system
Agency:
Servers and airpots sold separately
Specifications Additional Features
38700.0013Product #: DBC
PlumbedWater Access:
Finish:
Stainless
Stainless SteelFunnel:
UpperFaucet:
Electrical & Capacity
Volts Amps Watts
120/240
26 6100 No - 240
Cord
Attached
Plug Type
8oz cups/hr
236ml cups/hr
Input H²O
Temp.
60°F (15.5°C)
Phase
1 3 60
# Wires
plus Ground
Hertz
Plumbing Requirements CAD Drawings
PSI kPa
20-90 138-621
Fitting Supplied
3/8" Male Flare Fitting
BUNN® reserves the right to change specifications and product design without notice. Such revisions do not entitle
the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
For most current specifications and other info visit bunn.com.
Water Flow Required (GPM)
-
2D
Revit
•
KLC
Created on:
11/16/2016
Unit Shipping
Width Height
Depth
Width Height
Depth
Weight
Volume
English 16.0 in. 23.5 in. 17.7 in. - - - 52.950 lbs 5.440 ft³
Metric 40.6 cm 59.7 cm 45.0 cm - - - 24.018 kgs 0.154 m³
BUNN® reserves the right to change specifications and product design without notice. Such revisions do not entitle
the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
For most current specifications and other info visit bunn.com.
Created on:
11/16/2016
