Bunn Coffee Maker CWT-APS Parts List

CWT, CWTF,

CWT-APS, CWTF-APS

Dual-Voltage Models

ILLUSTRATED PARTS CATALOG

Designs, materials, weights, specifications, and dimensions for equipment or replacement parts

are subject to change without notice.

BUNN-O-MATIC CORPORATION

POST OFFICE BOX 3227

SPRINGFIELD, ILLINOIS 62708-3227

PHONE: [phone] FAX: [phone]

10789.0002 10/03 ©2003 Bunn-O-Matic Corporation

www.bunnomatic.com

BUNN-O-MATIC COMMERCIAL PRODUCT WARRANTY

Bunn-O-Matic Corp. (“BUNN”) warrants equipment manufactured by it as follows:

1) All equipment other than as specified below: 2 years parts and 1 year labor.

2) Electronic circuit and/or control boards: parts and labor for 3 years.

3) Compressors on refrigeration equipment: 5 years parts and 1 year labor.

4) Grinding burrs on coffee grinding equipment to grind coffee to meet original factory screen sieve analysis:
parts and labor for 3 years or 30,000 pounds of coffee, whichever comes first.

These warranty periods run from the date of installation BUNN warrants that the equipment manufactured by it
will be commercially free of defects in material and workmanship existing at the time of manufacture and appearing
within the applicable warranty period. This warranty does not apply to any equipment, component or part that
was not manufactured by BUNN or that, in BUNN’s judgment, has been affected by misuse, neglect, alteration,
improper installation or operation, improper maintenance or repair, damage or casualty. This warranty is conditioned
on the Buyer 1) giving BUNN prompt notice of any claim to be made under this warranty by telephone at (217)
529-6601 or by writing to Post Office Box 3227, Springfield, Illinois 62708-3227; 2) if requested by BUNN,
shipping the defective equipment prepaid to an authorized BUNN service location; and 3) receiving prior
authorization from BUNN that the defective equipment is under warranty.

THE FOREGOING WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTY, WRITTEN OR ORAL,
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF EITHER
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. The agents, dealers or employees of BUNN

are not authorized to make modifications to this warranty or to make additional warranties that are binding on
BUNN. Accordingly, statements by such individuals, whether oral or written, do not constitute warranties and
should not be relied upon.

If BUNN determines in its sole discretion that the equipment does not conform to the warranty, BUNN, at its
exclusive option while the equipment is under warranty, shall either 1) provide at no charge replacement parts
and/or labor (during the applicable parts and labor warranty periods specified above) to repair the defective
components, provided that this repair is done by a BUNN Authorized Service Representative; or 2) shall replace
the equipment or refund the purchase price for the equipment.

THE BUYER’S REMEDY AGAINST BUNN FOR THE BREACH OF ANY OBLIGATION ARISING OUT OF THE SALE
OF THIS EQUIPMENT, WHETHER DERIVED FROM WARRANTY OR OTHERWISE, SHALL BE LIMITED, AT BUNN’S
SOLE OPTION AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND.

In no event shall BUNN be liable for any other damage or loss, including, but not limited to, lost profits, lost sales,
loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute
equipment, facilities or services, or any other special, incidental or consequential damages.

2

10789.2 090203

TABLE OF CONTENTS

Electrical and Operating Controls ..............................................................................................................................................26

External Strainer, Flow Control, Solenoid and Lines.................................................................................................................. 22

Faucet and Tubing .................................................................................................................................................................... 24

Fill Basin ................................................................................................................................................................................... 16

Funnels and Filter Basket .......................................................................................................................................................... 32

Hood and Top Covers ............................................................................................................................................................... 14

Numerical Index ........................................................................................................................................................................34

Tank and Components W/Out Faucet ........................................................................................................................................18

Tank and Components W/Faucet...............................................................................................................................................20

Trunks and Panels - APS Models ................................................................................................................................................4

Trunks and Panels - SST and Black CWT Models W/One Warmer Base ..................................................................................... 6

Trunks and Panels - One Lower and Two Upper Warmers .......................................................................................................... 8

Trunks and Panels - SST and Black CWT Models W/One Lower and One Upper Warmer ......................................................... 10

Trunk and Panels - CWT & CWTF Three or More Warmers ...................................................................................................... 12

Warmer Assemblies ..................................................................................................................................................................30

Model Designation :

CWT...................................................................................................................................................................Non Faucet Models

CWTF ........................................................................................................................................................................ Faucet Models

DV .............................................................................................................................................................................. Dual-Voltage

APS ...................................................................................................................................................................................... Air Pot

3

10789.2 090203

BUNN

®

TRUNKS AND PANELS - APS MODELS

CWT, CWTF-DV

CWT, CWTF APS-DV

1

2

02374.0000

00462.0001

6

13350.0006 (W/ STD FUNNEL)

13350.0011 (W/ WIDE FUNNEL)

17

3

4

5

7

2

1

O
M

O
C

FUN
A

: 658

PN

2

/

0

BUNN

L
E
D

E
R
E
V

EL C
N
RE

FA

Optional Field Wiring

1

1

,

V

3

0

,

4

H

2

-

P

8

1

0

D

E
R
U

T

G

C

N

I

A

R

F

P

U

S

N
A
M

A
S
T
L

O

V

E

M
S

A

R

H

O

P

E
N

O
R
E
D

N
U
D

HE
T
O

E
R
O

M

R
O
E

N
O

C

!

T

EN
NT
O

T

HO

CO

TO

ILURE

W

0

0

1

3

-

0

4

3

2

,

A

Z

1

.

H

3

0

1

-

6

4

,

.

e

r

i

W

-

N
O

I
T
A

R

O
P
R

O

C
C
I

.

T

A

A

.

S

M

.

­U

O

,

-

N

IS

N

O

U

N
I

B

L

Y

L

S

I

B

T

,

T

D

A

L

/N

E

W

I

S

Z

F

T

:

R

S

E

T

H

N
E
T

P

A

M

P

A

G

N
I
E

R

W

I
O

W

L

L
O
F

.
C
.

HE
T
F

O
E

G

R

N
I

O

D
N

E
P
E

B
Y

A
M
S

T
N

E
T
A

P
R

ER

T

N

O

CAN

I

T

D DE

U

R

A

DISCA

IF:

D

E

D

Y

K

T

E

C

P

H

A

C

M

R

Y

E

T

E

C

R

A

M

.

N

D

R

A

C

E

I

L

C

D

H

R

F

S

E

T

.

W

L

H

I

C

D

G

O

E

I

E

L

B

H

T

.

E

A

N

D

E

O

E

H

D

S

.

E

O

S

P

U

X

S

.

Y

E

T
N

R

E

O

.

M

JUR

E

L

S

IN

ATION

E

S

RPOR

ISK

LY R
MP

5 BUNN-O-MATIC CO
98
1

00658.0000

10693.0000

16

15

13

14

18

12

11

10

8

9

P2734.40

4

10789.2 090203

TRUNKS AND PANELS - APS MODELS

ITEM PART NO. QTY. DESCRIPTION

1 34070.0003 1 Cover, Top

01303.0000 1 Screw, Pan Head #4-40 x .50"

00912.0000 1 Fastener, "J" Type #8-32

2 13350.0000 1 Housing, Hood

13350.0006 1 Housing, Hood (CWT Models)

02308.0000 6 Screw, Pan Head #8-32 x .375"

3 34081.1000 1 Trunk W/Decals, (Includes items 4, 5 & 6)

02308.0000 6 Screw, Pan Head #8-32 x .375"

4 00656.0000 1 Decal, Compliance To Plumbing Code

5 00831.0000 1 Decal, Warning-Electrical

6 00669.0003 2 Plug, Hole .437" Dia

7 27929.0000 2 Bracket, Mounting

02308.0000 4 Screw, Pan Head #8-32 x .375"

8 22999.0000 1 Plate, Base

02332.0002 8 Screw, Hex-Crimptite #6-32 x .375"

9 25137.0001 4 Foot, Rubber

10 22306.0000 1 Decal, Red Decorative Stripe

11 23321.0000 1 Housing, Base W/Decals (Includes item 10)

12 00754.0001 2 Locator

13 22730.1025 1 Panel, Trunk W/Decals (Includes items 14, 15, 16 & 18)

01382.0000 6 Screw, Truss Head #6-32 x .375"

00988.0000 6 Fastener, "U" Type #6-32

14 00658.0000 1 Decal, Warning Decal/Funnel

15 10836.0010 1 Schematic, Electrical

16 34955.0000 1 Decal, Optional Field Wiring

17 26225.0000 1 Decal, Flow Control/Strainer (CWTF Models Only)

18 32540.0000 1 Decal, Batch Set (Digital Timers)

5

10789.2 090203

BUNN

TRUNKS AND PANELS - SST AND BLACK CWT MODELS W/ONE

®

WARMER BASE

14

CWT, CWTF-DV

CWT, CWTF APS-DV

1

13

12

11

10

2

16

4

3

15

5

6

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

:

N

O

I

T

U

A

C

7

8

9

P2735.60

6

10789.2 090203

TRUNKS AND PANELS - SST AND BLACK CWT MODELS W/ONE WARMER BASE

ITEM PART NO. QTY. DESCRIPTION

1 23320.1003 1 Trunk W/Decals BLK Painted (Includes Items 11, 12, 13 & 14)

25352.0001 1 Trunk W/Decals SST (Includes items 11, 12, 13 & 14)

2 25144.0033 1 Panel W/Decals, Trunk - BLK Painted (Includes items 3, 4 & 15)

25144.0034 1 Panel W/Decals, Trunk - SST (Includes items 3, 4 & 15)

01382.0000 4 Screw, Truss Head SST #6-32 x .375”

01382.0002 4 Screw, Truss Head BLK #6-32 x .375”

00988.0000 4 Fastener, U-Type #6-32

3 00658.0000 1 Decal, Caution - Decanter/Funnel

4 10836.0010 1 Schematic, Electrical 120V & 120V/240V

5 25351.0000 1 Housing W/Decals, Base SST (Includes items 6 & 7)

25351.0002 1 Housing W/Decals, Base BLK (Includes items 6 & 7)

02308.0000 9 Screw, Pan Head #8-32 x .38”

6 12364.0000 1 Decal, Caution - Warmers And Surfaces Are Hot

7 22306.0000 1 Decal, Decorative Stripe

8 24805.0000 1 Cover, Base

02332.0002 4 Screw, Hex-Crimptite #6 x .38”

9 25137.0000 4 Foot, Rubber

10 01593.0000 1 Bushing, Snap 1.5” Dia.

11 00831.0000 1 Decal, Warning - Electrical

12 00656.0000 1 Decal, Comply To Plumbing Code

13 26225.0000 1 Decal, Flow Control/Strainer( Brewers W/External Flow Control and Faucet)

14 00669.0003 1 Plug, Hole - .43” Hole Dia (Brewers W/Out Faucet)

15 32540.0000 1 Decal, Batch Set (Digital Timer)

16 34955.0001 1 Decal, Optional Field wiring

7

10789.2 090203

BUNN

®

TRUNKS AND PANELS - W/ONE LOWER & TWO UPPER WARMERS

14

CWT, CWTF-DV

CWT, CWTF APS-DV

1

13

12

11

10

2

13

4

3

14

5

6

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

:

N

O

I

T

U

A

C

7

8

9

P2736.60

8

10789.2 090203

TRUNKS AND PANELS - W/ONE LOWER & TWO UPPER WARMERS

ITEM PART NO. QTY. DESCRIPTION

1 25352.0001 1 Trunk W/Decals SST (Includes items 10, 11, & 12)

2 25144.0027 1 Panel W/Decals, Trunk - SST (Includes items 3, 4, 13 & 14)

01382.0000 4 Screw, Truss Head SST #6-32 x .375”

00988.0000 4 Fastener, U-Type #6-32

3 00658.0000 1 Decal, Caution - Decanter/Funnel

4 10836.0009 1 Schematic, Electrical 120V

5 25351.0000 1 Housing W/Decals, Base (Includes items 6 & 7)

34065.1000 1 Housing W/Decals, Base (Includes items 6 & 7) (CWT Models)

02308.0000 9 Screw, Pan Head #8-32 x .38”

6 12364.0000 2 Decal, Caution - Warmers And Surfaces Are Hot

7 22306.0000 2 Decal, Decorative Stripe

8 24805.0000 1 Cover, Base

02332.0002 6 Screw, Hex-Crimptite #6 x .38” (Eight less used on late Models)

9 25137.0000 4 Foot, Rubber

10 00831.0000 1 Decal, Warning - Electrical

11 00656.0000 1 Decal, Comply To Plumbing Code

12 26225.0000 1 Decal, Flow Control/Strainer

13 34955.0002 1 Decal, Optional Field Wiring

14 32540.0000 1 Decal, Batch Set (Digital Timer)

9

10789.2 090203

BUNN

TRUNKS AND PANELS - SST AND BLACK CWT W/ONE LOWER &

®

ONE UPPER WARMER

14

CWT, CWTF-DV

CWT, CWTF APS-DV

1

13

12

11

10

2

16

4

3

15

5

6

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

:

N

O

I

T

U

A

C

7

8

9

P2736.60

10

10789.2 090203

TRUNKS AND PANELS - SST AND BLACK CWT W/ONE LOWER & ONE UPPER WARMER

ITEM PART NO. QTY. DESCRIPTION

1 23320.1003 1 Trunk W/Decals BLK Painted (Includes Items 11, 12, 13 & 14)

25352.0001 1 Trunk W/Decals SST (Includes items 11, 12, 13 & 14)

2 25144.0029 1 Panel W/Decals, Trunk - BLK (Includes items 3, & 4)

25144.0028 1 Panel W/Decals, Trunk - SST (Includes Items 3 & 4)

01382.0000 4 Screw, Truss Head SST #6-32 x .375”

00988.0000 4 Fastener, U-Type #6-32

3 00658.0000 1 Decal, Caution - Decanter/Funnel

4 10836.0009 1 Schematic, Electrical 120V

5 25351.0000 1 Housing W/Decals, Base (Includes items 6 & 7)

02308.0000 9 Screw, Pan Head #8-32 x .38”

6 12364.0000 2 Decal, Caution - Warmers And Surfaces Are Hot

7 22306.0000 2 Decal, Decorative Stripe

8 24805.0000 1 Cover, Base

02332.0002 6 Screw, Hex-Crimptite #6 x .38” (Eight less used on late Models)

9 25137.0000 4 Foot, Rubber

10 01593.0000 1 Bushing, Snap 1.5” Dia.

11 00831.0000 1 Decal, Warning - Electrical

12 00656.0000 1 Decal, Comply To Plumbing Code

13 26225.0000 1 Decal, Flow Control/Strainer

14 00669.0003 1 Plug, Hole - .43” Hole Dia (Brewers W/Out Faucet)

15 32540.0000 1 Decal, Batch Set (Digital Timer)

16 34955.0001 1 Decal, Optional Field Wiring

11

10789.2 090203

BUNN

®

TRUNKS AND PANELS - CWT & CWTF W/THREE OR MORE

WARMERS

CWT, CWTF-DV

CWT, CWTF APS-DV

15

17

14

6

13

1

2

16

4

12

3

18

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

:

N

O

I

T

U

A

C

5

11

10

6

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

:

N

O

I

T

U

A

C

7

8

9

12

P2737.60

10789.2 090203

TRUNKS AND PANELS - CWT & CWTF W/THREE OR MORE WARMERS

ITEM PART NO. QTY. DESCRIPTION

1 25352.0001 1 Trunk W/Decals SST (Includes items 12, 13, & 14) (CWTF Models)

23320.1003 1 Trunk W/Decals BLK (Includes Items 12, 13, 14 & 17) (CWT Models)

2 25144.0027 1 Panel W/Decals, Trunk SST (Includes items 3, 4, 16 & 17)

25144.0035 1 Panel W/Decals, Trunk BLK (Includes items 3, 4, 16 & 17)

01382.0000 4 Screw, Truss Head SST #6-32 x .375”

00988.0000 4 Fastener, U-Type #6-32

3 00658.0000 1 Decal, Caution - Decanter/Funnel

4 10836.0009 1 Schematic, Electrical 120V

5 25657.0000 1 Housing W/Decals SST (Includes items 6 & 7)

25658.0000 1 Housing W/Decals BLK (Includes Items 6 & 7)

02308.0000 9 Screw, Pan Head #8-32 x .38”

6 12364.0000 2 Decal, Caution - Warmers And Surfaces Are Hot

7 22306.0000 2 Decal, Decorative Stripe

8 12667.0001 1 Cover, Base

02332.0002 4 Screw, Hex-Crimptite #6 x .38”

9 25137.0000 4 Foot, Rubber

10 01592.0000 2 Bushing, Snap 1” Dia.

11 01593.0000 2 Bushing, Snap 1.5” Dia.

12 00831.0000 1 Decal, Warning - Electrical

13 00656.0000 1 Decal, Comply To Plumbing Code

14 26225.0000 1 Decal, Flow Control/Strainer

15 25658.0000 1 Housing W/Decal, Side Warmer (Includes Item 6)

16 34955.0003 1 Decal, Optional Field Wiring

17 00669.0003 1 Plug, Hole - .43” Hole Dia (Brewers W/Out Faucet)

18 32540.0000 1 Decal, Batch Set (Digital Timer)

13

10789.2 090203

BUNN

®

HOOD AND TOP COVERS

12 1 532

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

N
O

I

T

U

A

C

!

5

CWT, CWTF-DV

CWT, CWTF APS-DV

2

465

3

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

N
O

I

T

U

A
C

!

1

3

T

O

H

E

R

A

S

E

C

A

F

R

U

S

D

N

A

S

R

E

M

R

A

W

N

IO

T

U

A

C

!

1

14

P652.50

10789.2 090203

HOOD AND TOP COVERS

ITEM PART NO. QTY. DESCRIPTION

1 25310.0001 1 Cover, Top (Models W/No Upper Warmer)

25311.0001 1 Cover, Top (Models W/One Upper Warmer)

25312.0001 1 Cover, Top (Models with One Lower and Two Upper Warmers)

01303.0000 1 Screw, Pan Head #4-40 x .50"

00916.0000 1 Fastener, J-Type #4-40

2 02722.0000 1 Lid, Pour-In

01319.0000 1 Screw, Thumb #8-32 x .75"

00912.0000 1 Fastener, J-Type #8-32

3 02765.0000 1 Decal, Caution - Warmers and Surfaces Are Hot

4 13350.0006 1 Housing, Hood

02308.0000 6 Screw, Pan Head #8-32 x .38"

5 01592.0000 1 Bushing, Snap 1.0" Dia. (Not used on APS Models)

6 02732.0000 1 Panel, Rear Top Warmer

01315.0000 2 Screw, Truss Head 8 - 32 x .375"

15

10789.2 090203

BUNN

®

1 11 12 2

3

FILL BASIN

CWT, CWTF-DV

CWT, CWTF APS-DV

7 9 6

10

5

7 8

4

P653

16

10789.2 090203

FILL BASIN

ITEM PART NO. QTY. DESCRIPTION

1 27514.0000 1 Plate, Splash Guard

2 04270.0002 1 Fill Basin

3 01201.0000 1 Gasket, Tank Inlet

4 ------------- - Solenoid Assembly (See STRAINER-FLOW CONTROL, SOLENOID & LINES)

5 12914.0002 1 Tube Assembly, Solenoid To Fill Basin (Includes item 6 thru 10)

6 12928.0000 1 Grommet, Basin (See Item 5)

7 12422.0000 2 Clamp, Hose-Snap (See Item 5)

8 22397.0001 1 Fitting, .25 Barb x .12 MPT (See Item 5)

9 12913.0000 1 Tube, Fill Basin (See Item 5)

10 11707.1001 1 Tube, Silicone - 36" lg (Cut to 21.5") (See Item 5)

11 32063.0000 1 Fitting

12 - - - - - - - - 1 Tube, Silicone .313" I.D. x 4.0" (Order item 13)

13 28526.1000 - Tube, Silicone .313" I.D. x 12.0" (Cut to required length)

17

10789.2 090203

BUNN

4

®

TANK AND COMPONENTS W/OUT FAUCET

10 11

5

6

7

CWT, CWTF-DV

CWT, CWTF APS-DV

18

12

13

14

15

2

1

8

3

9

9

16

18

P654

10789.2 090203

TANK AND COMPONENTS W/OUT FAUCET

ITEM PART NO. QTY. DESCRIPTION

- 25319.1000 1 Tank Assy, 1320W 120V (Includes Items 1 thru 14)

25319.1002 1 Tank Assy, 35001W 120/240V (Includes Items 1 thru 14)

01315.0000 2 Screw, Truss Head #8-32 x .3/8”

00912.0000 2 Fastener, J-Type #8-32

1 04119.0000 1 Tank W/Blanket Warmer, 120V

2 04118.0000 1 Tank

3 04260.0000 1 Blanket Warmer, 50W 120V ( Includes Items 1 & 2)

4 04221.0000 1 Gasket, Tank Lid

5 25158.0000 1 Tank Lid Weldment

25158.0002 1 Tank Lid Weldment (CWT Models W/Four warmers)

00908.0000 8 Nut, Hex #8-32

6 00942.0000 2 Nut, Hex .50"-20

7 29329.1000 1 Thermostat, Limit

8 00943.0000 2 Gasket, Tank Heater

9 04236.1000 1 Tank Heater, 1320W 120V (Includes Item 8)

04637.1000 1 Tank Heater, 3500W 120V (Includes Item 8)

10 23769.0000 1 Lead, Electrical BLK (Thermostat to Heater)

11 23768.0000 1 Lead, Electrical BLU (Thermostat to Limit)

12 11431.0002 1 Sprayhead Tube Kit (Includes 3 mounting nuts below & items 13 & 14)

00908.0000 3 Nut, Hex #8-32

13 05515.0000 1 Gasket, Sprayhead Tube

14 05518.0000 1 Hub, Syphon

15 01075.0000 1 Nut, Hex .438" - 20

16 01082.0000 1 Sprayhead, 6-Hole

01082.0005 1 Sprayhead, 5-Hole

17 ------------- - Thermostat Leads (See Electrical and Operating Controls)

19

10789.2 090203

BUNN

4

®

TANK AND COMPONENTS WITH FAUCET

CWT, CWTF-DV

CWT, CWTF APS-DV

6

7

10

5

2

1

3

12

8

16

13

9

14

7

11

18

20

21

19

15

22

17

20

P2752.80

10789.2 090203

TANK AND COMPONENTS WITH FAUCET

ITEM PART NO. QTY. DESCRIPTION

- -------------- 1 Tank Assy, 1320W/1800W 120V/240V (Includes items 1 thru 19) (Not Available.
Order Components.)

01315.0000 2 Screw, Truss Head #8-32 x .375”

00912.0000 2 Fastener, J-Type #8-32

1 04119.0000 1 Tank W/Blanket Warmer, 120V (Includes item 2 & 3)

2 04118.0000 1 Tank

3 04260.0000 1 Blanket Warmer, 50W 120V

4 04221.0000 1 Gasket, Tank Lid

5 25158.0004 1 Tank Lid Weldment

00908.0000 8 Nut, Hex #8-32

6 00400.0001 2 Elbow, Male .250" Flare x .125" MPT

7 12687.0000 2 Nut, Hex Brass .562"-24 (Water Coil)

8 12688.0000 2 Gasket, Water Coil

9 12689.1000 1 Coil Assy, Hot Water (Includes item 8)

10 29329.1000 1 Thermostat, Limit

11 00942.0000 4 Nut, Hex .50"-20 (Tank Heater)

12 00943.0000 4 Gasket, Tank Heater

13 28226.1000 1 Tank Heater, 1320W 120V (Includes two of Item 12)

14 22918.0001 1 Thermal Safety Fuse (Thermostat to Heater)

15 23768.0000 1 Lead, Electrical BLU (Thermostat to Limit)

16 04636.1000 1 Tank Heater, 1800W 120V (Includes two of item 12)

17 11431.0002 1 Sprayhead Tube Kit (Includes 3 mounting nuts below & items 21 & 22)

00908.0000 3 Nut, Hex #8-32

18 05515.0000 1 Gasket, Sprayhead tube

19 05518.0000 1 Hub, Syphon

20 01075.0000 1 Nut, Hex .438”-20

21 01082.0000 1 Sprayhead, 6-Hole

01082.0005 1 Sprayhead, 5-Hole

22 -------------- - Thermostat Lead (See Electrical and Operating Controls)

21

10789.2 090203

BUNN

®

EXTERNAL STRAINER - FLOW CONTROL, SOLENOID AND LINES

13 14 15 16

2

3

4

1

6

5

CWT, CWTF-DV

CWT, CWTF APS-DV

789

10 11 12

STRAINER/FLOW CONTROL

REPAIR PARTS

23 22

20

21

SOLENOIDS W/1.0" DIA COIL

26

6 27

24 25 18 19 18 17

BREWERS WITH FAUCET

13 28 14 15

24

BREWERS WITHOUT FAUCET

22

25 18 19 18 17

P2753.75

10789.2 090203

EXTERNAL STRAINER - FLOW CONTROL, SOLENOID AND LINES

ITEM PART NO. QTY. DESCRIPTION

1 24394.0222 1 Strainer/Flow Control Assembly (.222 GPM) (Includes items 2 thru 6)

(Brewers with Faucet and 6-Hole Sprayhead)

-------------- 1 Strainer/Flow Control Assembly (.175 GPM) (Includes items 2 thru 4 & 6)
(Brewers with Faucet and 5-Hole Sprayhead) (Not Available. Order 24394.0175)

2 26216.0000 1 Tube Assembly, Flow Control to Tee

3 20577.0001 1 Tee, .250” Flare

4 21814.0016 1 Tube Assembly, Tee to Bulkhead

5 26217.0000 1 Tube Assembly, Flow Control to Bulkhead

6 -------------- 1 Strainer/Flow Control Assembly (.222 GPM) (Includes items 7 thru 12)

(Brewers with Faucet and 6-Hole Sprayhead) Not Available. Order item 1)

22300.0222 1 Strainer/Flow Control Assembly (.222 GPM) (Includes items 7 thru 12)
(Brewers without Faucet and with 6-Hole Sprayhead) (Also used on Brewers with
second type strainer/flow control and faucet)

7 22249.0000 1 Fitting, Flow Control Inlet

8 23721.0000 1 Screen

9 ------------- 1 Body (Not Available. Order Item 6)

10 20526.1222 1 Flow Washer/Gasket Set (.222 GPM) (Includes item 11)

11 01155.0000 1 Gasket, Flow Control

12 01154.0000 1 Fitting, Flow Control Outlet

13 00459.0000 2 Fitting, Bulkhead .250” Flare

14 01532.0000 2 Lockwasher, Internal Tooth .438”

15 00463.0000 2 Nut, Hex .438”-20

16 20690.0000 1 Tube Assembly, Bulkhead to Coil

17 12645.0002 1 Tube Assembly, Bulkhead to Solenoid

18 00402.0001 2 Connector, Male .250” Flare x .125”MPT

19 - - - - - - - - 1 Solenoid Valve, 120V-1.48" Dia Coil (Not available, order 01085.0002)

01085.0002 1 Solenoid Valve, 120V-1.0" Dia Coil

01327.0000 2 Screw, Pan Head #10-32 x .375”

01502.0000 2 Lockwasher, Split #10

20 28479.0000 1 Solenoid Valve Base Kit - 1.0" Dia Coil (Includes O-ring)

21 28481.0000 1 Guide Kit - 1.0" Dia Coil (Includes Washer & O-ring)

22 28480.0000 1 Solenoid Valve Coil, 120V - 1.0" Dia Coil

23 01111.0002 1 Solenoid Valve Repair Kit - 1.0" Dia Coil (Includes Plunger, Spring and O-ring)

24 07441.0000 1 Bracket, Solenoid Mounting

02308.0000 2 Screw, Pan Head Serrated #8-32 x .375”

25 -------------- 1 Tube Assembly, Solenoid to Fill Basin (See FILL BASIN)

26 24356.0222 1 Strainer/Flow Control Assembly (.222 GPM) (Includes Items 6 & 27)

(Brewers without Faucet and with 6-Hole Sprayhead)

27 00310.0000 1 Tube Assembly, Flow Control to Bulkhead

23

10789.2 090203

BUNN

®

1

FAUCET AND TUBING

5

11 10 9 8 7 6

14

12

13

CWT, CWTF-DV

CWT, CWTF APS-DV

2 3 4

24

P2754.80

10789.2 090203

FAUCET AND TUBING

ITEM PART NO. QTY. DESCRIPTION

1 20691.0000 1 Tube Assembly, Coil to Faucet

2 13059.0000 1 Faucet Jam Nut

3 01532.0000 1 Lockwasher, Internal Tooth .438” I.D.

4 12915.0000 1 Faucet, Hot Water (Includes items 5 thru 14)

5 13061.0000 1 Faucet Handle/Stem Assembly (Includes items 6 thru 11)

6 13053.0000 1 Faucet Handle Kit (Includes item 7)

7 02858.0000 1 Pin, Spring .125” Dia x .50”

8 13060.0000 1 Faucet Bonnet Nut

9 13055.0000 1 Faucet Spring

10 13054.0000 1 Faucet Stem

11 13056.0000 1 Faucet Seat Cup

12 13057.0000 1 Faucet Safety Clip

13 13058.0000 1 Faucet Aerator Kit

14 ------------- 1 Body, Faucet (Not available. Order item 4)

25

10789.2 090203

BUNN

®

ELECTRICAL AND OPERATING CONTROLS

1 2 3 1 4 1 2 3 2 1 5 1 2 3 2 6 1 2 3 2 7 2 3 2 8

R
A

ONE LOWER

WARMER

E
R

-

E
D
I

S

P

O

T
R
A

T
S

R
E

W

O

/L

N

O

ONE LOWER & 0NE

UPPER WARMER

T

T
R
A

T
S

R
E

W
O
L

/
N

O

THREE LOWER WARMERS

(LEFT OR RIGHT)

­T

N

O
R
F

T

R
A
T

S

R
E

W

O
L
/

N
O

ONE LOWER & TWO

UPPER WARMERS

R
A
E

R

-

P

O

-T

T
N
O

R
F

T

R
A
T

S

R

E
W
O

L
/

N

O

ONE UPPER & THREE

LOWER WARMERS

(LEFT OR RIGHT

R
A
E

R

-

E
D
I

S

-

T
N
O

R
F

T

R
A
T

S

R
E
W

O

L
/
N

O

P
O
T

CWT, CWTF-DV

CWT, CWTF APS-DV

)

9101112

21 22 23

24

25

MODEL 20 & 35

BREWERS

26

31

17

30

13

18

15

14

19

27

28

16

29

20

26

P2755.50

10789.2 090203

ELECTRICAL AND OPERATING CONTROLS

ITEM PART NO. QTY. DESCRIPTION

1 12921.0000 - Switch Blank, BLK

2 12920.0000 - Switch ON/OFF

3 01063.0000 1 Switch, Momentary Start

4 22295.0004 1 Label, Switch ON/OFF, Lighted Red (CWT Models W/One Warmer)

5 22295.0005 1 Label, Switch ON/OFF, Lighted Red (CWT Models W/Two Warmers)

6 22295.0006 1 Label, Switch ON/OFF (Three lower warmer brewer left or right)

7 22295.0010 1 Label, Switch ON/OFF (One lower warmer and two upper warmer brewer)

22295.0011 1 Label, Switch ON/OFF (CWT-APS Models)

8 22295.0007 1 Label, Switch ON/OFF, (CWT Models W/Four Warmers)

9 04243.0000 2 Terminal Housing, Receptacle

04242.0000 2 Terminal Housing, Receptacle

10 13352.0008 1 Control Panel

02301.0000 4 Screw, Phillip Pan Head #6-32 x .625"

00973.0000 4 Nut, Keps #6-32

11 22289.0003 1 Decal, Control Panel

22289.0001 1 Decal, Control Panel (CWT Models)

12 12984.0004 1 Light Assembly, 120V Green (Includes Item 6)

12984.0002 1 Light Assembly, 125V Green (CWT Models)

25292.0000 1 Lockwasher M6

34130.0000 1 Nut M6

13 00606.0000 1 Bushing, Snap .875" Dia

14 32400.0002 1 Timer Kit, Digital 120V

01320.0000 1 Screw, Round Head #8-32 x 1.0"

15 32530.0001 2 Spacer, Nylon .50"

16 04314.0001 1 Thermostat Kit (Includes item 24)

02308.0000 1 Screw, Pan Head #8-32 x .375" (Mounting)

20762.0000 2 Screw, Binding Head #8-32 x .25” (Terminal)

17 02337.0001 1 Screw, Hex Head #10 x .375" (Cord Ground)

01309.0000 1 Screw, Pan Head #10 x .50” (Cord Ground on APS Models)

18 12698.0000 1 Bracket Assembly, Component Mounting

02308.0000 1 Screw, Pan Head #8-32 x .375"

02332.0001 1 Screw, Hex-Crimptite #6 x .250"

19 07038.0000 1 Terminal Block, 3 Pole-Red/White/Black

01317.0000 2 Screw, Truss Head #8-32 x .50"

20 07073.0000 1 Grommet, Thermostat

21 23697.0000 1 Facenut, Plastic

22 23696.0000 1 Nut, Hex

(Continued)

27

10789.2 090203

BUNN

®

ELECTRICAL AND OPERATING CONTROLS

(Continued)

1 2 3 1 4 1 2 3 2 1 5 1 2 3 2 6 1 2 3 2 7 2 3 2 8

R
A

ONE LOWER

WARMER

E
R

-

E
D
I

S

P

O

T
R
A

T
S

R
E

W

O

/L

N

O

ONE LOWER & 0NE

UPPER WARMER

T

T
R
A

T
S

R
E

W
O
L

/
N

O

THREE LOWER WARMERS

(LEFT OR RIGHT)

­T

N

O
R
F

T

R
A
T

S

R
E

W

O
L
/

N
O

ONE LOWER & TWO

UPPER WARMERS

R
A
E

R

-

P

O

-T

T
N
O

R
F

T

R
A
T

S

R

E
W
O

L
/

N

O

ONE UPPER & THREE

LOWER WARMERS

(LEFT OR RIGHT

R
A
E

R

-

E
D
I

S

-

T
N
O

R
F

T

R
A
T

S

R
E
W

O

L
/
N

O

P
O
T

CWT, CWTF-DV

CWT, CWTF APS-DV

)

9101112

21 22 23

24

25

MODEL 20 & 35

BREWERS

26

31

17

30

13

18

15

14

19

27

28

16

29

20

28

P2755.50

10789.2 090203

ELECTRICAL AND OPERATING CONTROLS

ITEM PART NO. QTY. DESCRIPTION

(Continued)

23 25102.0000 1 Bracket, Switch Indicator/Guard

24 23522.0000 1 Switch, ON/OFF Toggle (Includes item 16)

25 01686.0000 1 Bushing, Strain Relief (CWT-APS Models)

26 01685.0000 1 Connector, Cable .50 MPT

27 07441.0000 1 Bracket, Relay Mounting

02308.0000 2 Screw, Pan Head #8-32 x .375"

28 11111.0000 1 Relay. 120V (Includes Item 30)

29 00720.0000 1 Knob, Thermostat

30 34056.0000 1 Decal, Switch Dual Volt

31 23522.0001 1 Switch, Toggle (Includes mounting nut)

Note: The following items are not illustrated.

32 01533.0002 2 Spacer. Nylon .171” I.D. x .375” O.D. x .30”LG

33 01719.0000 1 Power Cord Assembly (CWT-APS Models)

34 12985.0000 1 Wiring Harness, Ready Light (CWT & APS Models)

35 33985.0001 1 Wiring Harness, Main 120V

33985.0000 1 Wiring Harness, Main 120V (CWT Models)

34026.0002 1 Wiring Harness, Main 120V (CWTF-APS Models)

36 25347.0000 1 Wiring Harness, 120V Thermostat to Tank

Heater

37 23331.0006 1 Wiring Harness, 120V (CWT-APS Models)

38 34023.0000 1 Wiring Harness, 120V (CWT Models W/Four Warmers)

39 25326.0000 1 Wiring Harness, 120V To Upper Warmer (CWT Models W/Four Warmers)

29

10789.2 090203

BUNN

®

WARMER ASSEMBLIES

3

4

8

9

5

6

1

7

CWT, CWTF-DV

CWT, CWTF APS-DV

8

9

7

2

1

2

8

9

1

3

4

5

6

1

2

7

2

1

30

7

2

P2756.85

10789.2 090203

WARMER ASSEMBLIES

ITEM PART NO. QTY. DESCRIPTION

1 03652.0000 2 Warmer Assembly 100W 120V, Top and Side Warmers (Includes items 3 thru 6)

01303.0000 3 Screw, Pan Head - SST #4-40 x .50”

00916.0000 3 Fastener, J-Type #4-40

2 11440.0005 1 Warmer Assembly 100W 120V, Base Warmers (Includes items 3 thru 6)

01303.0000 3 Screw, Pan Head - SST #4-40 x .50”

00916.0000 3 Fastener, J-Type #4-40

3 03656.0000 1 Warmer Dish, Blk 45 Hole

4 01227.0000 1 Warmer Element 100W 120V Top and Side Warmers

5 13042.0001 1 Spacer, .174” I.D. x .188

6 05212.0000 1 Plate, Element Retaining

00970.0000 2 Nut, Keps #8-32

7 -------------- 2 Tube, Silicone .250” Dia x 1.88” LG. (Order Item 10)

8 -------------- 1 Bushing, Snap 1.188” Dia. (See Hood And Top Covers)

9 28382.0000 1 Clamp, Routing

02332.0003 1 Screw, Hex-Crimptite #6-32 x . 375”

10 04828.1001 - Tube, Silicone .250” Dia. x 24” LG (Use as required) (Not Illustrated)

11 24204.0001 1 Wiring Harness, Three Warmer Brewers 120V & CWTF-APS Models

(Not Illustrated)

31

10789.2 090203

BUNN

®

FUNNELS AND FILTER BASKET

2

7

CWT, CWTF-DV

CWT, CWTF APS-DV

2

Gourmet ‘C’ Funnel

6
3

9

4

3

6

1

4

5

7

8

1

32

6

7

1

9

P2805

10789.2 102703

FUNNELS AND FILTER BASKET

ITEM PART NO. QTY. DESCRIPTION

1 20583.0003 1 Funnel W/Decals, Plastic (Black 7.25’ Dia) (Includes items 6, 7 and 8)

20216.0000 1 Funnel Assy, SST W/Black Handle (7.125” Dia) (Includes items 2 thru 5)

34559.0000 1 Funnel, Gourmet ‘C’ SST (7.125”Flange O.D.)(Includes items 2,3,4,6,7 & 9)

2 33088.0000 1 Filter Basket (7.125” Dia)

34546.0000 1 Filter Basket, Gourmet ‘C’

3 28553.0000 1 Funnel W/Decals, SST (7.125” Dia) (Includes items 6 and 7)

34558.0000 1 Funnel, Gourmet ‘C’, SST

4 20244.1000 1 Handle Kit, Black (Includes Screw)

01331.0002 1 Screw, Round Head #10-32 x 1.50”

5 01031.0000 1 Funnel Tip Kit

6 03408.0002 1 Decal, Warning-Remove Funnel

7 03409.0002 1 Decal, Warning-Hot Liquid

8 32964.0000 1 Splashguard

9 28694.0000 1 Decal, Warning-Hot Liquid/Remove Funnel

33

10789.2 102703

NUMERICAL INDEX

PART NO. PAGE NO. PART NO. PAGE NO. PART NO. PAGE NO. PART NO. PAGE NO.

00310.0000 ....................... 23

00400.0001 ....................... 21

00402.0001 ....................... 23

00459.0000 ....................... 23

00463.0000 ....................... 23

00606.0000 ....................... 27

00656.0000 ......... 5,7,9,11,13

00658.0000 ......... 5,7,9,11,13

00669.0003 ............ 5,7,11,13

00720.0000 ....................... 29

00754.0001 ......................... 5

00831.0000 ......... 5,7,9,11,13

00908.0000 .................. 19,21

00912.0000 .......... 5,15,19,21

00916.0000 .................. 15,31

00942.0000 .................. 19,21

00943.0000 .................. 19,21

00970.0000 ....................... 31

00973.0000 ....................... 27

00988.0000 ......... 5,7,9,11,13

01031.0000 ....................... 33

01063.0000 ....................... 27

01075.0000 .................. 19,21

01082.0000 .................. 19,21

01082.0005 .................. 19,21

01085.0002 ....................... 23

01111.0002 ....................... 23

01154.0000 ....................... 23

01155.0000 ....................... 23

01201.0000 ....................... 17

01227.0000 ....................... 31

01303.0000 ............... 5,15,31

01309.0000 ....................... 27

01315.0000 ............. 15,19,21

01317.0000 ....................... 27

01319.0000 ....................... 15

01320.0000 ....................... 27

01327.0000 ....................... 23

01331.0002 ....................... 33

01382.0000 ......... 5,7,9,11,13

01502.0000 ....................... 23

01532.0000 .................. 23,25

01533.0002 ....................... 29

01592.0000 .................. 13,15

01593.0000 ............... 7,11,13

01685.0000 ....................... 29

01686.0000 ....................... 29

01719.0000 ....................... 29

02301.0000 ....................... 27

02308.0000 ........ 5,7,9,11,13,

................................ 23,27,29

02332.0001 ....................... 27

02332.0002 ......... 5,7,9,11,13

02332.0003 ....................... 31

02337.0001 ....................... 27

02722.0000 ....................... 15

02732.0000 ....................... 15

02765.0000 ....................... 15

02858.0000 ....................... 25

03408.0002 ....................... 33

03409.0002 ....................... 33

03652.0000 ....................... 31

03656.0000 ....................... 31

04118.0000 .................. 19,21

04119.0000 .................. 19,21

04221.0000 .................. 19,21

04236.1000 ....................... 19

04242.0000 ....................... 27

04243.0000 ....................... 27

04260.0000 .................. 19,21

04270.0002 ....................... 17

04314.0001 ....................... 27

04636.1000 ....................... 21

04637.1000 ....................... 19

04828.1001 ....................... 31

05212.0000 ....................... 31

05515.0000 .................. 19,21

05518.0000 .................. 19,21

07038.0000 ....................... 27

07073.0000 ....................... 27

07441.0000 .................. 23,29

10836.0009 ............... 9,11,13

10836.0010 ...................... 5,7

11111.0000 ....................... 29

11431.0002 .................. 19,21

11440.0005 ....................... 31

11707.1001 ....................... 17

12364.0000 ............ 7,9,11,13

12422.0000 ....................... 17

12645.0002 ....................... 23

12667.0001 ....................... 13

12687.0000 ....................... 21

12688.0000 ....................... 21

12689.1000 ....................... 21

12698.0000 ....................... 27

12913.0000 ....................... 17

12914.0002 ....................... 17

12915.0000 ....................... 25

12920.0000 ....................... 27

12921.0000 ....................... 27

12928.0000 ....................... 17

12984.0002 ....................... 27

12984.0004 ....................... 27

12985.0000 ....................... 29

13042.0001 ....................... 31

13053.0000 ....................... 25

13054.0000 ....................... 25

13055.0000 ....................... 25

13056.0000 ....................... 25

13057.0000 ....................... 25

13058.0000 ....................... 25

13059.0000 ....................... 25

13060.0000 ....................... 25

13061.0000 ....................... 25

13350.0000 ......................... 5

13350.0006 .................... 5,15

13352.0008 ....................... 27

20216.0000 ....................... 33

20244.1000 ....................... 33

20526.1222 ....................... 23

20577.0001 ....................... 23

20583.0003 ....................... 33

20690.0000 ....................... 23

20691.0000 ....................... 25

20762.0000 ....................... 27

21814.0016 ....................... 23

22249.0000 ....................... 23

22289.0001 ....................... 27

22289.0003 ....................... 27

22295.0004 ....................... 27

22295.0005 ....................... 27

22295.0006 ....................... 27

22295.0007 ....................... 27

22295.0010 ....................... 27

22295.0011 ....................... 27

22300.0222 ....................... 23

22306.0000 ......... 5,7,9,11,13

22397.0001 ....................... 17

22730.1025 ......................... 5

22918.0001 ....................... 21

22999.0000 ......................... 5

23320.1003 ............... 7,11,13

23321.0000 ......................... 5

23331.0006 ....................... 29

23522.0000 ....................... 29

23696.0000 ....................... 27

23697.0000 ....................... 27

23721.0000 ....................... 23

23768.0000 .................. 19,21

23769.0000 ....................... 19

24204.0001 ....................... 31

24356.0222 ....................... 23

24394.0222 ....................... 23

24805.0000 ................. 7,9,11

25102.0000 .................. 27,29

25137.0000 ............ 7,9,11,13

25137.0001 ......................... 5

25144.0027 .................... 9,13

25144.0028 ....................... 11

25144.0029 ....................... 11

25144.0033 ......................... 7

25144.0034 ......................... 7

25144.0035 ....................... 13

25158.0000 ....................... 19

25158.0002 ....................... 19

25158.0004 ....................... 21

25292.0000 ....................... 27

25310.0001 ....................... 15

34

25311.0001 ....................... 15

25312.0001 ....................... 15

25319.1000 ....................... 19

25319.1002 ....................... 19

25326.0000 ....................... 29

25347.0000 ....................... 29

25351.0000 ................. 7,9,11

25352.0001 ............ 7,9,11,13

25352.0002 ......................... 7

25657.0000 ....................... 13

25658.0000 ....................... 13

26216.0000 ....................... 23

26217.0000 ....................... 23

26225.0000 ......... 5,7,9,11,13

27514.0000 ....................... 17

27929.0000 ......................... 5

28226.1000 ....................... 21

28382.0000 ....................... 31

28479.0000 ....................... 23

28480.0000 ....................... 23

28481.0000 ....................... 23

28526.1000 ....................... 17

28553.0000 ....................... 33

28694.0000 ....................... 33

29329.1000 .................. 19,21

32063.0000 ....................... 17

32400.0002 ....................... 27

32530.0001 ....................... 27

32540.0000 ......... 5,7,9,11,13

32964.0000 ....................... 33

33088.0000 ....................... 33

33985.0000 ....................... 29

33985.0001 ....................... 29

34023.0000 ....................... 29

34026.0002 ....................... 29

34065.1000 ......................... 9

34070.0003 ......................... 5

34081.1000 ......................... 5

34130.0000 ....................... 27

34546.0000 ....................... 33

34558.0000 ....................... 33

34599.0000 ....................... 33

34955.0000 ......................... 5

34955.0001 .................... 7,11

34955.0002 ......................... 9

34955.0003 ....................... 13

10789.2 102703
