Page 1

IMPORTANT

READ CAREFULLY BEFORE USE

KEEP SAFE FOR LATER REFERENCE

E l e c t r i c b i c y c l e

O P E R A T I N G

I N S T R U C T I ON S

C r o s s E , C r o s s E 8 , U r b a n , Grinder, T w e n t y 4 ,

Am i n g a , S i x 5 0, Twenty9, M o n s t e r , C r u i s e r,

C r o s s M o v e r S p e e d , C r o s s L i t e, Iconic,

Sentinel, Six50 E 2 Street

Page 2

Distribution or reproduction of these operating instructions and utilization or communication of their content is prohibited render the offender liable for compensation. All rights reserved in the event that a patent, utility model or industrial design is registered.

unless expressly approved. Any infringement will

Page 3

Data sheet

Name of the purchaser:

Date of purchase:

Model:

Frame number:

Type number:

Unloaded weight (lbs):

Tire size:

Recommended tire pressure (psi)*: front:

Wheel circumference (mm):

Company stamp and signature:

*After a tire change, refer to the tire markings for the permitted tire pressures and make sure that they are observed. The recommended tire pressure must not be exceeded.

rear:

Page 4

1 Technical data

Bicycle

Transportation temperature

Ideal transportation temperature

Storage temperature

Ideal storage temperature

Operation temperature

Working environment temperature

Charging temperature

Power output/system

Shut-off speed - Class 1 bicycle

Shut-off speed - Class 3 bicycle

Table 1: Bicycle technical data

Battery

Transportation temperature

Ideal transportation temperature

41°F - 77°F

50°F - 59°F

41°F - 77°F

50°F - 59°F

41°F - 95°F

59°F - 77°F

50°F - 86°F

250 W (0.25 W)

20 mph

28 mph

41°F - 77°F

50°F - 59°F

Storage temperature

Ideal storage temperature

Charging ambient temperature

Table 2: Battery technical data

41°F - 77°F

50°F - 59°F

50°F - 86°F

Page 5

Command console with display

Internal cell batteries

Type

Storage temperature

Table 3: Technical data for battery of the command console with display

Emissions

A-weighted emission sound pressure level < 70 dB(A)

Total vibration level for the hands and arms

Highest effective value of weighted acceleration for the entire body

Table 4: Emissions from the bicycle*

*The safety requirements as per Electromagnetic Compatibility Directive 2014/30/EU have been met. The bicycle and the charger can be used in residential areas without restriction.

3V, 90mAh

CR2016

14 °F to 140°F

<2.5m/s²

<0.5m/s²

Tightening torque

Axle nut tightening torque 35 Nm - 40 Nm

Handlebars clamping screw maximum tightening torque*

5Nm - 7Nm

Page 6

1 Technical data 2

2 About these instructions 9

2.1 Manufacturer 9

2.2 Laws, standards and directives 10

2.3 Other valid documents 10

2.4 Subject to change 10

2.5 Language

2.6 Identifying 12

2.6.1 Operating instructions 12

2.6.2 Bicycle 12

2.7 For your safety 14

2.7.1 Instruction, training and customer service 14

2.7.2 Basic safety notes 15

2.7.3 Warni

ngs 15

2.7.4 Safety markings 16

2.8 For your information 16

2.8.1 Instructions for actions 16

2.8.2 Information on the type plate 16

2.8.3 Language conventions 19

2.9 Type plate 20

3 Safety 21

3.1 Requirements for the rider 21

3.2 Proper use 21

3.2.1 City and trekking bicycle 22

3.3 Improper use 22

3.4 Personal protective equipment 22

3.5 Hazards for vulnerable groups 22

3.6 Duty of care 23

3.6.1 Rider

3.6.2 User 24

4 Description 25

4.1 Overview 25

4.2 Handlebars

4.3 Wheel and fork 27

4.3.1 Valve 27

4.3.2 Suspension 28

4.4 Brake system 30

4.4.1 Rim brake 30

4.4.1.1 Locking lever 31

Page 7

4.4.2 32

4.4.3 33

4.5 34

4.5.1

4.5.1.1 38

4.5.2 38

4.5.3 38

4.5.3.1 40

4.5.3.2

Disc brake Coaster brake Electric drive system

attery

B Operating and charge status indicator Running light Command console with display USB port

ays

Displ

5 43

5.1 43

5.2 45

5.2.1 45

5.2.1.1 46

5.2.1.2 46

5.3 47

5.3.1 47

5.3.2 48

5.3.3 48

5.3.3.1 50

5.3.4 50

6 52

6.1 52

6.1.1 52

6.1.2 53

6.1.3 54

6.2 54

6.3 55

6.4 56

6.5 57

6.5.1 57

6.5.1.1 57

6.5.1.2 58

6.5.1.3 58

6.5.2 61

6.5.3 63

6.6 64

6.6.1 64

6.6.2

Transportation,storageandassembly

Transportation Storing Break in operation Preparing a break in operation Carrying out break in operation Assembly Unpacking Scope of delivery Commissioning Checking the battery Installing the wheels with quick release

Adjustingthebicycletotherider

Adjusting the saddle Determining the seat height Clamp the seat post with the quick release Adjusting the sitting position and saddle tilt Setting the handlebars Setting the stem with quick release Checking the clamping force of the quick releases Basic setting for suspension and damping Adjusting the hardness of the spring elements Adjusting the hardness of the steel suspension fork Adjusting the hardness of the air suspension elements Front wheel Setting the rebound damper Setting the compression damper Setting the grip distance of the brake lever Hydraulically operated rim brake Hydraulically operated disc brake

Page 8

7 66

7.1 68

7.2 70

7.3 71

7.4

7.4.1 75

7.4.1.1 75

7.4.1.2 75

7.4.2 76

7.4.2.1 76

7.4.2.2 76

7.4.3 76

7.4.3.1 76

7.4.3.2 77

7.4.4 77

7.4.5 79

7.5 80

7.5.1 80

7.5.2 81

7.6 82

7.6.1 82

7.6.2 82

7.6.3 83

7.6.4 83

7.6.5 83

7.6.5.1 84

7.6.5.2 84

7.6.5.3 84

7.6.5.4 84

7.7 85

7.8

7.8.1 86

7.8.2 87

7.9 88

7.9.1 88

7.9.1.1 88

7.9.1.2 89

7.9.1.3 89

7.9.1.4 90

7.9.1.5 90

7.9.1.6 90

7.9.2

Operation

Before each ride Using the kickstand Using the pannier rack

Batte

n tube battery

Dow

Removing the down tube battery Inserting the down tube battery Pannier rack battery Removing the pannier rack battery Inserting the pannier rack battery Integrated battery Removing the integrated battery Inserting the integrated battery Charging the battery Waking the battery Electric drive system Switching on the drive system Switching off the drive system Command console with display Using the USB diagnostics port Using the pushing aid Using the running light Selecting the level of assistance Journey information Switching the displayed journey information Resetting the journey distance Changing the unit for speed Displaying system data Gear shift Brake

86 Using the brake Using the coaster brake Suspension and damping Locking the front wheel suspension Fork lock on the suspension head Locking lever on handlebars, version I Locking lever on handlebars, version II

Fork lock on handlebars, version III Fork lock on handlebars, version IV Fork lock on handlebars, version V Locking the compression damper 91

Page 9

8 92

8.1 93

8.1.1 93

8.1.2 93

8.1.3 94

8.1.4

8.2 95

8.2.1 95

8.2.2 96

8.2.3 96

8.2.4 96

8.2.5 96

8.2.6 97

8.3

8.4 99

8.4.1 99

8.4.2 100

8.4.2.1 101

8.4.2.2 101

8.4.2.3 102

8.4.2.4 103

8.4.2.5 104

8.4.2.6 105

8.4.3 108

8.4.3.1 108

8.4.3.2 109

8.4.3.3 110

8.4.4 111

8.4.4.1 111

8.4.4.2 112

8.4.4.3 113

8.4.5 114

8.4.6 114

8.4.7 114

8.4.8 115

8.4.8.1 115

8.4.8.2 116

8.4.9

8.5

8.5.1 119

8.5.2

Maintenance

Cleaning and servicing Battery Display Basic cleaning and preservation

hain

C Maintenance Wheel Brake system Electrical cables and brake cables Gear shift USB port Chain or belt tension

vice

Ser Correcting and repairing Using original parts only Wheel quick release Clamping the clamping lever Clamping version I Clamping version II Clamping version III Clamping version IV Clamping version V Adjusting the tire pressure Dunlop valve Presta valve Schrader valve Adjusting the gear shift Cable-operated gear shift, single-cable Cable-operated gear shift, dual-cable Cable-operated twist grip, dual-cable Replacing the lighting Setting the lamp Repair by the specialist dealer First aid for system messages First aid Specific fault eradication The electric drive system of drive system does not start up Accessori

es Child seat Bicycle trailer

117 118

121

Page 10

9 Recycling and disposal 122

10 EC declaration of conformity 124

12 Table of figures 125

13 Index 127

Page 11

About these instructions

Read these operating instructions before commissioning the bicy functions correctly and safely. They are not a substitute for personal training by the BULLS specialist dealer. The operating instructions are a component part of the bicycle. Therefore, if it is resold at a later time, they must be handed over to the subsequent owner.

These operating instructions are mainly directed towards the rider and user of the bicycle. In general,

they are technical laypersons.

Text passages which are directed expressly at specialist staff (e.g. bicycle mechanics), are clearly marked with a blue tool symbol.

Staff at all BULLS specialist dealers have specialist training and qualifications, and are therefore capable of identifying risks arise during maintenance, servicing and repairs on the bicycle. Information for specialist staff does not require technical laypersons to take any action.

cle in order to use

and preventing hazards which may

all the

2.1

Manufacturer

The manufacturer of the bicycle is:

BULLS Bikes USA 11854 Alameda St Lynwood, CA 90262

Tel.:

E-mail: Internet:

(310) 763-0677

contact@bullsbikesusa.com

www.bullsebikes.com

Page 12

2.2

Laws, standards and directives

This electric bicycle complies with the ISO 4210 norm.

2.3 Other valid documents

These operating instructions are only complete in conjunction with the other valid documents.

The following document applies for this product:

• Charger operating instructions.

No other information is also applicable.

2.4

The constantly updated lists of approved accessories and parts are available to BULLS specialist dealers.

Subject to change

The information contained in these operating instructions are the approved specifications at the time of printing. Any significant changes are included in a new issue of the operating instructions.

technical

Page 13

2.5

Language

This operating instructions are written in English. A translation is not valid without this original operating instructions.

Page 14

2.6

Identifying

2.6.1

Table 6:

2.6.2

Operating instructions

These operating instructions are printed in color. BULLS (BULLS Bikes USA) assumes no liability for copies of any kind, for example, black and white copies, loose pages or electronic copies.

Identification of the operating instructions

Bicycle

This operating instructions are a component part of the following bicycles:

Type no. Model Bicycle type

790-814XX Twenty9 EVO 1

598-094XX Monster E S

775-356XX Twenty4 E

785-855XX

770-404XX

Table 7: Type number, model and bicycle type categorisation

Urban EVO

Six50 E 2 Street

Class 1

Class 3

Page 15

Type no. Model Bicycle type

790-736XX

785-732XX

785-744XX

785-747XX

784-654XX

790-750XX

780-512XX

784-365XX

784-156XX

784-160XX

780-868XX

780-870XX

780-872XX

785-660XX

;;

785-837XX

7-8XX

785-599XX

790-946XX

790-948XX

Six50 EVO AM 1

Six50 EVO AM 2

Six50 EVO AM 3

Six50 EVO AM 4

Aminga E TR1

Aminga EVA TR2

Monster E FS

Cruiser E

Cross E8 (ST)

Cross E8 (Wave)

Cross Mover Speed (Diam)

Cross Mover Speed (ST)

Cross Mover Speed (Wave)

Six50 TR Street

Cross Lite EVO (Diam)

Cross Lite EVO (ST)

Cross Lite EVO (Wave)

Cross E (Wave)

Twenty8 E45 (Diam)

Twenty8 E45 (ST)

Class 1

Class 3

Class 1

Class 3

785-858XX

790-738XX

785-633XX

Table 7: Type number, model and bicycle type categorisation

Grinder EVO

Iconic EVO TR 1

Sentinel

Class 3

Page 16

2.7

For your safety

The safety riding of the bicycle compromises four elements:

• the instruction of the rider and/or user, and maintenance and repair of the bicycle by the BULLS specialist dealer,

• the section on general safety,

• the warnings in this instructions and

• the safety marking on the type plate.

2.7.1

Instruction, training and customer service

The BULLS specialist dealer is in charge of the customer service. Contact details can be found on the back page of these operating instructions data sheet. If you are unable to contact your specialist dealer, you will find a list of BULLS specialist dealers on www.bullsebikes.com They will also be able to attend your customer service needs.

A BULLS specialist dealer commissioned to perform repairs and maintenance work receives regular training.

The rider or the user of the bicycle will be instructed in person about the functions of the bicycle, in particular its electrical functions and the correct use of the charger, at the time when the bicycle is handed over by the supplying BULLS specialist dealer.

Each rider or user, should receive instructions on the functions of the bicycle. The operating instructions must be handed to each rider in printed form and must be acknowledged and adhered to.

and in the

Page 17

2.7.2 Basic safety notes

SIGNAL WORD

DANGER

WARNING

CAUTION

NOTICE

These operating instructions have a chapter with general safety notes [ chapter stands out because of its grey background.

2.7.3 Warnings

Hazardous situations and actions are marked with warnings. The warnings in these operating instructions are shown as follows:

Type and source of the danger

Description of the danger and the consequences.

Measures



The following pictograms and signal words are used in the operating instructions for warnings and information notices:

Will lead to serious or even fatal injuries if ignored. High-risk hazard.

 Chapter 3, page 21]. The

May lead to serious or even fatal injuries if ignored. Medium-risk hazard.

May lead to minor or moderate injuries. Low-risk hazard.

May lead to material damage if ignored.

Table 8: Meanings of the signal words

Page 18

2.7.4 Safety markings

The following safety markings are used on the type plates of the bicycle:

General warning

Adhere to the instructions for use

Table 9: Safety markings on the product

2.8 For your information

2.8.1 Instructions for actions

Instructions for actions are structured in accordance with the following pattern:

 Requirements (optional)



Instruction for action

 Result of the action (optional)

2.8.2 Information on the type plate

Alongside the warnings, the type plates of the products also contain other important information on the bicycle:

Page 19

only suitable for the road, no off-road riding or jumps

suitable for roads, off-road riding and jumps of up to 15 cm

suitable for rough off-road riding and jumps of up to 61 cm

suitable for rough off-road riding and jumps of up to 122 cm

suitable for the most difficult terrain

Table 10: Area of use

City and trekking bicycle

Child's bicycle / bicycle for young adults

BMX bicycle

Mountain bike

Racing bicycle

Carrier bicycle

Folding bicycle

Table 11: Bicycle type

Page 20

Read the instructions

max. 50°C

Separate collection of e

lectrical and electronic

devices

Separate collection of batteries

Must not be thrown into fire (burning prohibited)

Battery must not be opened

Device of protection class II

Only suitable for use indoors

Fuse (device fuse)

EU conformity

Recyclable material

Protect from temperatures above 122 °F and direct sunlight

Table 12: Further information on the product

Page 21

2.8.3 Language conventions

The bicycle described in these operating instructions may be equipped with alternative components. The equipment of the bicycle is defined by the respective type number. If applicable, the notes alternative equipment and alternative version make reference to the use of alternative components.

Alternative equipment describes additional components which are not necessarily an integral part of every bicycle in these instructions.

Alternative version explains the various variants of components if they differ in use.

The following terms are used for better legibility:

Term Meaning

Operating instructions

Bicycle

Motor

Table 13: Simplified terms

Original operating instructions or translation of the original operating instructions

Electric motor driven bicycle

Drive motor

The following conventions are used in these operating instructions:

Convention Use

Italics Entry in the index

SPACED Displays on the display

[

 Example, page

numbering]

• Bulleted lists

Table 14: Conventions

screen

Cross references

Page 22

2.9 Type plate

The type plate is situated on the frame. The type plate features the following information:

Figure 1: Type plate, example

1 2 3 4

Classification

(1) A “class 1 electric bicycle,” or “low-speed pedal-assisted electric bicycle,” is a bicycle equipped with a assistance only when the rider is pedaling, and that ceases to provide assistance when the bicycle reaches the speed of 20 miles per hour. (2) A “class 2 electric bicycle,” or “low-speed throttle-assisted electric bicycle,” is a bicycle equipped with a motor that may be used exclusively to propel the bicycle, and that is not capable of providing assistance when the bicycle reaches the speed of 20 miles per hour. (3) A “class 3 electric bicycle,” or “speed pedal-assisted electric bicycle,” is a bicycle equipped with a motor that provides assistance only when the rider is pedaling, and that ceases to provide assistance when the bicycle reaches the speed of 28 miles per hour.

Identification

Classification Maximum power output

Shut-off speed

CLASS

250W

20mph

motor that provides

Page 23

Safety

3.1

3.2

Requirements for the rider

If there are no legal requirements for the rider of electrically the rider should be a minimum 15 years of age and have experience with muscle-powered bicycles.

The physical and mental abilities of the rider must be sufficient for the use of a muscle-powered bicycle.

If the bicycle is used by minors, as well as thorough instruction to be provided by or in the presence of the legal guardians, supervised use should also be scheduled until there is certainty that the bicycle is being used in accordance with these operating instructions. The legal guardians hold sole responsibility for determining whether minors are suitable to use the bicycle.

power assisted

cycles, we reco

mmend that

Proper use

The bicycle must only be used in perfect, fully functional condition. National requirements may apply to the bicycle which differ from the standard equipment. For riding on public roads, some special regulations apply in relation to running light, reflectors and other components.

The general laws and the regulations for the prevention of accidents and environmental protection in the respective country, state and/or city of use must be adhered to. Proper use also includes all instructions for actions and check lists in these operating instructions. Approved accessories can be installed by specialist staff.

Each bicycle is assigned to a bicycle type which determines the proper use.

Page 24

3.2.1 City and trekking bicycle

City and trekking bicycles are designed for daily, comfortable use on asphalted roads and paths. They are suitable for riding on public roads.

City and trekking bicycles are not sports bicycles. If used for sports, reduced riding stability and diminished comfort are to be expected. City and trekking bicycles are not suitable for riding off-road.

3.3 Improper use

Failure to adhere to the proper use causes a risk of personal injury and material damage. The bicycle is not suitable for the following uses:

• riding with a damaged or incomplete bicycle,

• riding over steps,

• riding through deep water,

• lending the bicycle to untrained riders,

• carrying further passengers,

• riding with excessive luggage,

• riding with no hands,

• riding on ice and snow,

• improper servicing,

• improper repair,

• demanding areas of use, such as professio competition, and

• stunt riding or acrobatics.

nal

3.4 Personal protective equipment

We recommend that you wear a suitable safety helmet. We also recommend that you wear typical, close-fitting cycling clothing and sturdy footwear.

3.5 Hazards for vulnerable groups

The battery and the charger must be kept out of the reach of children.

Page 25

3.6 Duty of care

The safety of the bicycle can only be assured if all the necessary measures are taken.

3.6.1 Rider

The rider:

• receives instruction before the first ride. He/she can clarify any questions relating to the operating instructions with the user or the BULLS specialist dealer.

• wears personal protective equipment.

• assumes all the responsibilities of the user when ridding the bicycle.

Page 26

3.6.2 User

The user has the duty of care and responsibility for scheduling these measures and checking that they are implemented.

The user:

• makes these operating instructions available to the

rider for the duration of use of the bicycle. If necessary, he translates the operating instructions into a language which the rider understands.

• familiarises the rider with the functions of the bicycle

before the first ride. Only riders who have received instruction must be allowed to ride the bicycle.

• instructs the rider on proper use and the wear

personal protective equipment.

• employs specialist staff only for maintenance and

repair of the bicycle.

The declaration of conformity in the appendix is valid as long as the As soon as the user makes any relevant modifications or additions, he legally becomes the manufacturer.

ing of

bicycle remains in original condition.

Page 27

13 15 1614

4 Description

4.1 Overview

Figure 2: Bicycle, viewed from the right, example of Six50

1 Front wheel 2 Fork 3 Front mudguard 4 Handlebars 5 Stem 6 Frame 7 Seat post 8 Saddle 9 Reflector 10 Pannier rack 11 Rear mudguard 12 Kickstand 13 Rear wheel 14 Chain 15 Frame number and type plate 16 Battery

Page 28

4.2 Handlebars

Figure 3: Detailed view of bicycle from rider position, example

1 2 3 4 5 6 7

Front brake lever Bell Lamp Front brake lever Command console with display Fork lock Shifter

Page 29

4.3 Wheel and fork

Figure 4: Components of the wheel, example of front wheel

4.3.1

1 2 3 4 5 6 7 8 9

Valve

Each wheel has a valve. It is used to fill the tire with air. There is a valve cap on each valve. The on valve cap keeps out dust and dirt.

The bicycle either has a classical Dunlop valve, a Presta valve or a Schrader valve.

Tire Rim Preload adjuster Shock absorber Spoke Quick release Hub

Valve

Fork end of the shock absorber

screw-

Page 30

4.3.2 Suspension

A suspension fork has two functions which improve the floor contact and the comfort: the suspension and the damping.

Figure 5:

Bicycle without suspension (1) and with suspension (2) when riding over an obstacle

The suspension prevents an impact, e.g. caused by a stone lying

in the way, from being directed directly into the rider's body via a fork. Instead, it is absorbed by the suspension system. This causes the suspension fork to compress. The compression can be disabled so that a suspension fork reacts like a rigid fork.

The compressed suspension fork then returns to its original position. The damper decelerates the movement and thus prevents the suspension system from springing back in an uncontrolled manner, and the fork from oscillating up and down.

Dampers which dampen the compressive deflection movements, i.e. the compression load, are called compression dampers or dashpots.

Page 31

This model series features up to three different

1 2 3 4

suspension and damping systems:

Figure 6: Arrangement of the suspension systems for the front wheel (I) and

rear wheel (II)

1 Suspension system (steel suspension fork or air

suspension fork) 2 Compression damper 3 Rebound damper 4 Fork housing

Page 32

4.4 Brake system

The bicycle's brake system comprises:

• a rim brake on the front and rear wheels,

• a disc brake on the front and rear wheels or

• a rim brake on the front and rear wheels and an additional coaster brake.

4.4.1 Rim brake (Alternative equipment)

Figure 7: Components of the rim brake with details, example

1 Rear wheel brake 2 Brake pad 3 Brake arm 4 Rim 5 Handlebars with brake levers 6 Front wheel brake

The rim brake stops the movement of the wheel when the rider pulls the brake lever, causing two brake pads, positioned opposite one another, to be pressed onto the rims.

Page 33

There are two alternative versions of the rim brake:

• the hydraulically operated rim brake and

• the cable-operated rim brake.

4.4.1.1 Locking lever (Alternative equipment)

The bicycle with hydraulically operated rim brakes is equipped with a locking lever on both the front wheel brake and the rear wheel brake.

Figure 8: Rim brake locking lever, on rear wheel (1) and front wheel (2)

The locking levers are not labelled. The loc

king

levers must only be set by a BULLS specialist dealer.

Page 34

4.4.2

Disc brake (Alternative equipment)

Figure 9:

Bicycle brake system with a disc brake, example

1 2 3 4 5

Disc brake Brake caliper with brake linings

Handlebars with brake levers

Front wheel disc brake Rear wheel disc brake

On a bicycle with a disc brake, the brake rotor is fixed to the hub of the

wheel. If the brake lever is pulled, the brake linings are pressed against the disc brake, and the movement of the wheel is stopped.

Page 35

4.4.3

Coaster brake (Alternative equipment)

Figure 10:

Brake system with a coaster brake, example

1 2 3 4 5

Rear wheel rim brake

Handlebars

Fro

nt wheel rim brake

with brake levers

Pedal

Coaster brake

The coaster brake stops the movement of the rear wheel when the rider pedals in the opposite direction to the direction of travel.

Page 36

4.5

Electric drive system

The bicycle is driven by muscle power via the chain drive. The force which

is applied by pedaling in the direction of travel, drives the front chain ring. The chain transmits the force onto the cassette and then onto the rear wheel.

Figure 11: Diagram of mechanical drive system

1 Direction of travel 2Chain 3 Rear chain wheel 4 Front chain wheel 5 Pedal

In addition, the bicycle has an integrated, electric drive system, with a command console with display.

Page 37

The electric drive system is made up of six

components:

Figure 12: Diagram of electric drive system

1 Lamp 2 Command console with display 3 Down tube battery 4 Rear light 5 Motor

• a charger which is designed for this battery.

As soon as the required muscle power from the rider pedaling passes a certain level, the motor is activated gently and assists the pedaling motion of the rider. The motor force is determined by the set level of assistance.

Page 38

The bicycle does not have a separate EMERGENCY STOP or EMERGENCY SHUT-OFF button. The drive system with removable display can be stopped in case of emergency by removing the display.

The motor switches off automatically as soon as the rider no longer pedals, the temperature is outside the permitted range, there is an overload or the shut-off speed limit has been reached.

A pushing aid can be activated. The pushing aid continues to drive the bicycle as long as the rider pushes the plus button on the handlebars. The maximum speed in the process is 3.75 mph. The drive stops when the plus button is released.

4.5.1

Battery

The lithium ion battery has an internal electronic protection circuit. It is matched to the charger and the bicycle. The temperature of the battery is monitored constantly. The battery is safeguarded against deep discharge, overcharging, overheating and short circuit. In case of a risk the battery is switched off automatically by a protective circuit. The battery also switches to sleep mode for self-protection when not used for a longer period.

The service life of the battery can be extended if it is well cared for and, above all, stored at the correct temperatures. Even if the battery is cared for properly, the charge status of the battery reduces as it ages. If the operating time is severely shortened after charging, this is a sign that the battery is spent.

Page 39

Transportation temperature

41°F - 77°F

Ideal transportation temperature

Storage temperature

Ideal storage temperature

Charging ambient temperature

Table 15: Battery technical data

The bicycle has a down tube battery.

Figure 13: Details of the down tube battery

50°F - 59°F

41°F - 77°F

50°F - 59°F

50°F - 86°F

1 Battery housing 2Battery lock 3 Key for the battery lock 4 Battery lock cover 5 On-Off button (battery) 6 Operating and charge status indicator 7 Charging port cover 8 Port for charger plug

Page 40

4.5.1.1 Operating and charge status indicator

The five green LEDs of the operating and charge status indicator indicate the charge status when the battery is switched on. Each LED represents 20% of the charge status. The charge status of the activated battery is also shown on the display.

If the charge status of the battery is below 5%, all the LEDs of the operating and charge status indicator go out. However, the charge status is still shown on the display.

4.5.2 Running light

When the running light is activated, the lamp and the rear light are switched on together.

4.5.3 Command console with display

The command console with display controls the drive system with four operating controls, and displays the journey data.

The bicycle's battery supplies the command console

with display with energy. The command console with display also has two internal non-rechargeable button

cell batteries. This ensures that the system can be switched on using the command console with display.

Table 16:

Internal button cell batteries 3V, 90mAh

Type

Storage temperature

Technical data for battery of the command console with display

CR2016

14 °F to 140°F

Page 41

The pane of glass on the display may steam up from

WALK

the inside in the event of abrupt temperature fluctuations. This is not a malfunction.

The command console with display has four buttons.

Figure 14: Overview of the command console with display

Symbol Surname

WALK

2USB port 3 On-Off button 4Display 5

Table 17: Overview of the command console with display

Pushing aid button

Plus button

Minus button

–

Page 42

4.5.3.1 USB port

Test instruments can be connected to the USB diagnostics port to check the drive system. The USB diagnostics port does not have any other functions.

4.5.3.2 Displays

The command console with display has seven display screens:

Figure 15: Overview of the screen displays

Use

1 Unit of speed

2 Current speed

3 Function display

4 Running light symbol

5 Service symbol

6 Battery charge status

Table 18: Overview of the screen display

7 Level of assistance

Page 43

Level of assistance

The higher the level of assistance, the more the drive system assists the rider when pedaling. The levels of assistance are available.

Level of assistance Use

When the drive system is switched on,

OFF

ECO

TOUR

SPORT

TURBO

Table 19: Overview of levels of assistance

the motor assistance is switched off. The pushing aid cannot be activated with this level of assistance.

Low assistance

Normal assistance

Powerful assistance

Maximum assistance

Current speed

In the system settings, you can select whether the speed is displayed in kilometres or miles.

Function display

The function display shows three different items of information:

following

• Journey information,

• Sys

tem data and

• system messages.

Page 44

Journey information

The command console with display shows one of three items of journey information. The displayed item of journey information can be switched

Display Function

TRI P Distance travelled since the last RESET

TOT A L Display of the total distance travelled

RAN G E Anticipated range of the available

Table 20: Journey information

System data

To view all the information on the system being used and the software, the rider has to call up the system data.

Display Function

SER I E NNU M M ER D U Serial number of the drive system

SER I E NNU M M ER H MI Serial number of the command console

SW- V E RSI O N HM I Software version of the command

SW- V E RSI O N DU Software version of the drive system

SW- V E RSI O N PP Software version of the battery

Table 21: System data, not changeable

(cannot be changed)

battery charge, calculated based on the most recent manner of riding

with display

console with display

System message

The drive system monitors itself continuously and if a fault is detected, it is indicated by a system message. The system may switch off automatically depending on the type of fault. There is a table of system messages in the appendix

Page 45

5 Transportation, storage and

CAUTION

NOTICE

assembly

5.1 Transportation

Crash caused by unintentional activation

There is a risk of injury if the drive system is activated unintentionally.

 Remove the battery before

transported.

Risk of fire and explosion due to high temperatures

Excessively high temperatures damage the batteries. The batteries may self-ignite and explode.

 Never expose the battery to sustained direct

sunlight.

If the bicycle is lying flat, oil and grease may leak from the bicycle.

If the shipping carton with a bicycle is lying flat or on one end, it does not provide sufficient protection from damage to the frame and the wheels.

 Only transport the bicycle in an upright position.

Bicycle rack systems which secure the bicycle standing on its head by the handlebars or frame, generate inadmissible forces on the components during transportation. This can cause the supporting parts to break.

 Never use bicycle rack systems which secure t

bicycle standing on its head by the handlebars or frame.

the bicycle is

Page 46

u Take into account the weight of the complete

bicycle when transporting it.

u Remove the display and the

battery before

transportation of the bicycle.

u Protect the electrical components and connections

on the bicycle from the elements with suitable protective covers.

u Remove accessories, for example drinking bottles,

before transportation of the bicycle.

u When transporting by car, you must use a suitable

bicycle rack system.

The BULLS specialist dealer will advise you on how to select a suitable rack system properly and how to use it safely.

 Transport the bicycle in a dry, clean place which is

protected from direct sunlight.

For shipping the bicycle, we recommend that you have the bicycle partially dismantled in the proper manner and packaged by the BULLS specialist dealer.

Page 47

5.2 Storing

CAUTION

NOTICE

Risk of fire and explosion due to high temperatures

Excessively high temperatures damage the battery. The battery may self-ignite and explode.

 Never expose the battery to sustained direct

sunlight.

If the bicycle is lying flat, oil and grease may leak from the bicycle.

If the shipping carton with a bicycle is lying flat or on one end, it does not provide sufficient protection from damage to the frame and the wheels.

 Only store the bicycle in an upright position.

 Store the bicycle, battery and charger in a dry and

clean place.

Storage temperature

Ideal storage temperature

Table 22: Storage temperature for the battery, the bicycle and the charger

5.2.1 Break in operation

The battery discharges when it is not used. This can cause damage to the battery.

 The battery has to be recharged every 8 weeks.

The battery may become damaged if it is connected permanently to the charger.

 Do not connect the battery to the charger

permanently.

41 °F - 77 °F

50°F - 59°F

Page 48

The internal battery in the display discharges when it

NOTICE

is not used. This can cause it to be irreparably damaged.

 Charge the internal battery in the display every 3

months for at least 1 hour.

If the bicycle is to be removed from service for longer than four weeks, e.g. in winter, a break in operation has to be prepared.

5.2.1.1 Preparing a break in operation

ü Remove the battery from the bicycle.

ü Charge the battery to around 60% (three to four LEDs

of the charge status indicator light up).

ü The bicycle has to be cleaned with a damp cloth and

preserved with wax spray. Never wax the friction surfaces of the brake.

ü Before

longer periods without use, it is

recommendable for the BULLS specialist dealer to carry out servicing, basic cleaning and to apply preservative agent.

5.2.1.2 Carrying out break in operation

 Store the bicycle, battery and charger in a dry and

clean environment.

 Charge the internal battery in the display every 3

months for at least 1 hour.

 Check the charge status of the battery after 8

weeks. If only one LED of the charge status indicator lights up, recharge the battery to around 60%.

Page 49

5.3 Assembly

CAUTION

Crushing caused by unintentional activation

There is a risk of injury if the drive system is activated unintentionally.

 Remove the battery if the battery is not absolutely

necessary for assembly.

ü Assemble the bicycle in a clean and dry environment.

ü The working environment should have a temperature

of 59°F - 77°F.

Working environment temperature

Table 23: Working environment temperature

ü If a fitting stand is used, it must be approved for a

weight of at least 66 lbs.

ü To reduce the weight, we recommend that you always

disconnect the battery from the bicycle for the duration of use of the fitting stand.

ü Universal tools, a torque wrench with an operating

range of 5 Nm to 40 Nm and the special tools, as recommended by BULLS, must be available.

5.3.1 Unpacking

Hand injuries caused by cardboard packaging

The shipping carton is closed with metal staples. There is a risk of puncture wounds and cuts when unpacking and crushing the packaging.

 Wear suitable hand protection.

 Remove the metal staples with pliers before the

shipping carton is opened.

59°F - 77°F

The packaging material consists mainly of cardboard and plastic film.

Page 50

 The packaging has to be disposed of in accordance

CAUTION

with the regulations of the authorities.

5.3.2 Scope of delivery

The bicycle was completely assembled in the factory for test purposes and then dismantled for transportation.

The scope of delivery includes:

• the bicycle, 98% pre-assembled,

• the front wheel,

• the battery or batteries,

• the charger,

• the pedals,

• the operating instructions.

5.3.3 Commissioning

Fire and explosion caused by incorrect charger

Batteries which are charged with an unsuitable charger, may become internally damaged. This may result in fire or an explosion.

 Only ever use the battery with the supplied charger.

 To prevent mix-ups, mark the supplied charger a

nd these operating instructions clearly, for example with the frame number or type number of the bicycle.

Given that initial commissioning of the bicycle requires special tools and specialist knowledge, it must be performed by trained specialist staff only.

Experience has shown that a bicycle which has not yet been sold, is spontaneously handed to consumers as soon as it appears ready to ride.

 Every bicycle must be prepared so that it is in fully

usable condition immediately after being set up.

Page 51

Initial commissioning includes the following work:

 Check the battery [

 The battery is supplied partially charged. In order to

guarantee full power, charge the battery fully.

 Install the wheels with quick release and the pedals.

 Move the handlebars and saddle into the functio

position.

 Check all the components to make sure that they

are firmly in place.

 Check all the settings and the tightening torque of

the axle nuts.

Axle nut tightening torque 35 Nm - 40 Nm

Table 24: Axle nut tightening torque

 Check the entire cable harness to make sure that it

is routed pr

operly:

• You must prevent the cable harness from coming into contact with moving parts.

• The cable routes must be smooth and free from sharp

ges.

• Moving parts must not apply any pressure or tension to the cable harness.

 Chapter 5.3.3.1, page 50].

nal

u Set the lamp.

u Check the drive sy

brakes to make sure that they are fully

the

stem, the ligh

t equipme

nt and

functional and effective.

u Set the language to English and imperial

measurement units.

u Check the software version of the drive system and

update it as necessary.

Page 52

Sale of the bicycle

CAUTION

 Fill out the data sheet on the first page of the

operating instructions.

 Adjust the bicycle to the rider.

 Set the kickstand and the shifter, and show the

purchaser the settings.

 Instruct the user or rider how to use all the functions

of the bicycle.

5.3.3.1 Checking the battery

The battery has to be checked before it is charged for the first time.

 Press the On-Off button (battery).

 If none of the LEDs on the operating and charge

status indicator light up, the battery may damaged.

 If at least one of the LEDs of the operating and

charge status indicator lights up, but not all of th the battery can be charged.

em,

5.3.4 Installing the wheels with quick release

Crash caused by unfastened quick release

A faulty or incorrectly installed quick release may become caught in the wheel. This will cause a crash.

u Install the front wheel quick release lever on the

opposite side to the disc brake.

disc brake and block the

Page 53

Crash caused by faulty or incorrectly installed quick

CAUTION

release

The disc brake becomes very hot during operation. Parts of the quick release may become damaged as a result. The quick release may loosen up and ultimately this could result in an crash accident.

u The front wheel quick release lever and the

brake rotor must be situated on opposite sides.

Crash caused by incorrectly set clamping force

Excessively high clamping force will damage the quick release and cause it to lose its function.

Insufficient clamping force will cause a detrimental transmission of force. The suspension fork or the frame may break. This will result in a crash and injuries.

 Never fasten a quick release using a tool (e.g.

hammer or pliers).

 Only use the clamping lever with the specified set

clamping force.

 Open the clamping lever.  Insert the hub in the fork end of the fork so that it

rests fully in place.

 Push the opened clamping lever with the wheel

axle from the right-hand side through the hub.

 Clamp the wheel and set the clamping force,

depending on the version.

Page 54

6 Adjusting the bicycle to the rider

CAUTION

The BULLS specialist dealer checks all the factory settings and, when the bicycle is sold, adapts the settings of the saddle, handlebars, suspension fork and the spring damper

6.1 Adjusting the saddle

6.1.1 Determining the seat height

Crash caused by an excessively high seat post setting

elements to the rider.

A seat pos the seat post or the frame crack and break. This will result in a crash accident with injuries.

 Do not pull the seat post out of the frame beyond

the minimum insertion depth marking.

Figure 16: Detailed view of the seat post, examples of the minimum insertion

depth marking

1 III marking for minimum insertion depth 2 Seat post I 3 Seat post II 4 MIN marking for minimum insertion depth

t which

is positioned too high could cause

Page 55

From an ergonomic point of view, the seat height

should be set so that the heel touches the lowest point of the pedal when the leg is outstretched.

Figure 17: Determining the saddle height

6.1.2 Clamp the seat post with the quick release

The BULLS specialist dealer demonstrates the function of the quick release to

the rider or user.

Figure 18: Seat post quick release in the final position

1 Seat post clamping lever 2 Seat post 3 Knurled nut

Page 56

Clamping

 Only clamp the seat post when the bicycle is

stationary.

The seat post clamping lever is not marked with any lettering. You can tell whether it is open or closed from its shape.

• To close it, push the seat post clamping lever as far as

it will go into the seat post.

• To open it, pull the seat post clamping lever away from

the seat post.

 Check the clamping force of the quick releases.

6.1.3 Adjusting the sitting position and saddle tilt

Special tools are required to adjust the seat length and the saddle tilt. The BULLS specialist dealer adjusts the saddle setting to the rider.

6.2 Setting the handlebars

 The handlebars setting must only be made while the

bicycle is stationary.

 Unfasten and adjust the designated screw

connections, and clamp them with the maximum tightening torque for the clamping screws of the handlebars.

Maximum tightening torque for the clamping screws of the handlebars*

*if there is no other data on the component

Table 25: Handlebars clamping screw maximum tightening torque

5Nm - 7Nm

Page 57

6.3 Setting the stem with quick release

CAUTION

(Alternative version)

Crash caused by incorrectly set clamping force

Excessively high clamping force will damage the quick release and cause it to lose its function.

Insufficient clamping force will cause a detrimental transmission of force. This can cause components to break. This will result in a crash and injuries.

 Never fasten a quick release using a tool (e

.g.

hammer or pliers).

 Only use the clamping lever with the specified

set

clamping force.

 Open the clamping lever for the quick release on

the stem.

 Pull the locking lever on the stem up, and

simultaneously pivot the handlebars into the desired position.

 You feel the locking lever click into place.

 Pull out the handlebars to the required height.

 Lock the quick release.

 Check the clamping force of the quick releases.

Figure 19: Closed clamping lever (2) with knurled nut (3) and locking lever (1)

on the stem

Page 58

6.4 Checking the clamping force of the quick releases

 Open and close the quick releases on the stem or

the seat post.

 The clamping force is sufficient if the clamping

lever can be moved easily from the open final position into the middle and has to be pressed with the fingers or base of the thumb from the middle point onwards.

Setting the clamping force

 If the clamping lever on the handlebars cannot be

moved into its final position, screw out the knur nut.

the clamping force of the clamping lever on the

 If

seat post is not sufficient, screw in the knurled nut.

If the clamping force cannot be set, the BULLS specialist dealer will need to check the quick release.

led

Page 59

6.5 Basic setting for suspension and damping

The adjustment shown here represents a basic setting. The rider should change the basic setting to suit the surface and his/her preferences.

 It is recommendable to make a note of the basic

setting. This way, it can be used as the starting point for subsequent, optimised settings and to safeguard against unintentional changes.

6.5.1 Adjusting the hardness of the spring elements

6.5.1.1 Adjusting the hardness of the steel suspension fork

 Only make the steel suspension fork setting with the

bicycle stationary.

 The setting wheel may be located under a plastic

cover on the head of the left-hand shock absorber. Remove the plastic cover by pulling it off upwards.

Figure 20: Suspension fork setting wheel, example

 Use the setting wheel on the left-hand suspension

fork head to adjust the hardness of the steel

suspension fork. Adjust the hardness of the steel suspension fork by turning the setting wheel in the plus or minus direction.

 The ideal setting in relation to the weight of the ride

r has been achieved when the shock absorber deflects 3 mm under the stationary load of the rider.

 If applicable, re-attach the plastic cover after

setting the suspension fork.

Page 60

6.5.1.2 Adjusting the hardness of the air suspension

NOTICE

elements

Riding without filling pressure will destroy the suspension, the frame, and the air suspension components.

 Never ride without filling pressure in the air

suspension elements.

A normal air pump cannot build up the required pressure with sufficient sensitivity.

u Use a special suspension pump to adjust the

filling pressure.

6.5.1.3 Front wheel

 Only make the air suspension fork setting with the

bicycle stationary.

 The fork valve is located underneath a screw cover

on the head of the left-hand fork tube. Unscrew and remove the screw cover.

Figure 21: Fork valve, example

 Set the filling pressure using the filling pressure

recommendations on the air suspension fork as the initial value.

 Set the O-rings on the stanchion or the piston to the

minimum possible deflection.

 Sit on the bicycle and dismount again.

 Read the position of the displaced O-ring.

Page 61

 The ideal setting for the weight of the rider has

been achieved when the measured position is between 20 - 30%.

 For fine setting, adjust the filling pressure using the

fork valve.

 Screw the screw cover back on.

Rear wheel

 Unscrew the valve cap from the rear wheel dampe

val

ve.

 Push the O-ring on the dial directly onto

the

housing of the suspension damping element.

 Sit on the bicycle and dismount again.

 Read the position of the displaced O-ring.

 The ideal setting for the weight of the rider ha

s been achieved when the measured position is between 20 - 30%.

 If the setting is incorrect, adjust the filling pressure

using the suspension damping element valve:

• If the pressure is too high, let out air

• If the pressure is too high, carefully pump up th

suspension damping element.

 Screw the valve cap back on.

Page 62

Figure 22: Setting the hardness on the suspension damping element

1 Dial 2 Valve cap on suspension damping element 3O-ring

Page 63

6.5.2 Setting the rebound damper

Front wheel

 The rebound damper for the front wheel is situated

on the fork leg. It may be marked with either hare/ tortoise symbols or plus and minus symbols.

Figure 23: Setting the rebound damper, example with hare and tortoise

symbol

1 Setting bolt 2 Tortoise symbol 3 Suspension fork 4 Hare symbol

 Open the rebound damper completely. To do so,

turn the setting bolt all the way towards the hare symbol or the minus symbol.

 Stand next to the bicycle. Deflect the fork as far as

possible by pushing down the handlebars.

 Release the handlebars abruptly.

 The ideal setting for the rebound damper has be

achieved when the wheel maintains contact with the floor when springing back.

Page 64

 If the wheel loses contact with the floor, turn back

in small steps towards the tortoise symbol or plus symbol.

Rear wheel

The rebound damper for the rear wheel is situated on the suspension damping element.

Figure 24: Setting the hardness on the suspension damping element

1 Setting wheel 2 Hare symbol 3 Tortoise symbol

 Set the setting wheel to the middle position

between the hare and the tortoise symbols.

 Ride over a small obstacle with the bicycle.

 The ideal setting for the rebound damper has bee

achieved when the rebound movement of the rear

wheel feels comparable to that of the front wheel.

 If the rear wheel springs much quicker or slower

than the front wheel, change the setting by turning the setting wheel.

Page 65

6.5.3 Setting the compression damper

The basic setting only has to be determined for compression dampers which have to be set with multiple clicks. A setting of 5 clicks is recommended as the basic setting.

Response of the damper

sensitive select opened damping or low

soft or delayed moderately closed pressure level

Table 26: Setting the compression damper

Setting

pressure level

 Set the ideal basic setting using the locking lever.

Figure 25: Compression damper with locking lever (1), example

Page 66

6.6 Setting the grip distance of the brake lever

CAUTION

(Alternative version)

6.6.1 Hydraulically operated rim brake

(Alternative equipment

Crash caused by incorrectly set grip distance

If brake cylinders are set incorrectly or installed wrongly, the braking power may be lost at any time. This may result in a crash and injuries.

u Once the grip distance has been set, check the

position of the brak necessary.

)

e cylinder and adjust it as

u Never adjust the position of

without special tools. Have a BULLS specialist dealer carry out the adjustment.

u Set the slider to one of the three positions with the

brake lever gently applied.

 The rider can use the brake lever comfortably.

Figure 26: Brake lever with slider (1) and its three positions (2)

the

brake cylinder

Page 67

6.6.2

Hydraulically operated disc brake (Alternative equipment)

 Set the grip distance using the knurled screw on the

brake lever.

 The rider can use the brake lever comfortably.

Figure 27: Brake lever (1) with knurled screw (2)

Page 68

7 Operation

CAUTION

NOTICE

Crash caused by loose clothing

Laces, scarves and other loose items may become entangled in the spokes on the wheels and the chain drive. This may result in a crash and injuries.

 Wear sturdy footwear and close-fitting clothing.

Crash caused by accumulated dirt

Accumulated dirt can disrupt the functions of the bicycle, e.g. the functions of the brakes, lighting or reflectors. This may

u Remove accumulated dirt before riding.

Crash caused by poor road conditions

Loose objects, for example, branches and twigs, may become caught in the wheels and cause a crash.

 Be aware of the road conditions.

 Ride slowly and brake in good time.

result in a crash and injuries.

NOTICE

When riding on a downhill bicycle, high speeds may be reached. The bicycle is only engineered for exceeding a speed of 20 mph (class 1) or 28 mph

(class 3) briefly. In particular the tire can fail if exposed to a continuous load.

u Decelerate the bicycle with the brakes if higher

speeds are reached.

Heat or direct sunlight can cause the tire pressure to increase above the permitted maximum pressure. This can destroy the tire.

u Never park the bicycle in the sun.

u On hot days, regularly check the tire pressure and

adjust it as necessary.

Page 69

Paths in poor condition subject the joints in the arms to severe strain. Take a break from riding every 30 to 90 minutes, depending on the condition of the roads.

Page 70

7.1 Before each ride

CAUTION

Crash caused by unidentified damage

After a crash, accident or if the bicycle falls over, there may be barely identifiable damage, e.g. to the brake system, the quick releases or the frame. This may result in a crash and injuries.

u Remove the bicycle from service and have a

BULLS specialist dealer carry out an

Crash caused by material fatigue

A component may suddenly fail in case of material fatigue. This may result in a crash and injuries.

Remove the bicycle from service immediately in case of any signs of material fatigue. Have a BULLS specialist dealer check the situation.

u Have the BULLS specialist dealer carry out basic

cleaning regularly. During basic cleaning, the

BULLS

any signs of material fatigue.

specialist dealer inspects the bicycle for

inspection.

u Check the bicycle before each ride.

 In case of any discrepancies from the Check list

before each ride, or any anomalies of any kind, the

bicycle must not be used until the cause has been clarified.

Page 71

Check list before each ride

Check that the bicycle is complete.



Check that the lighting, reflector and brake, for instance, are



sufficiently clean.

You must check that the mudguards, the pannier rack and the



chain guard are securely installed.

Check that the front and rear wheels run true. This is particularly important if the bicycle has been transported or secured with a



lock.

Check the valves and the tire pressure. Adjust as necessary



before each ride.

Check the front and rear wheel brakes to make sure that they are working properly. To do so, operate the brake levers while



the bicycle is stationary in order to check whether resistance is generated in the usual brake lever position.

Check that the running light is working.



Check for unusual noises, vibrations, smells, discolouration,



deformation, abrasion and wear. This indicates material fatigue.

Watch out for any unusual operating sensations when braking,



pedaling or steering.

Check the quick releases to make sure that they are fully closed



in their final position.

On a bicycle with a hydraulic rim brake, check whether the



locking levers are fully closed in their final positions.

Page 72

7.2 Using the kickstand

CAUTION

NOTICE

Crash caused by a lowered kickstand

The kickstand does not fold up automatically. There is a risk of crashing if riding with the kickstand lowered.

 Raise the kickstand completely before the ride.

Because of the heavy weight of the bicycle, the kickstand may sink into soft ground, the bicycle may topple and fall over.

 The bicycle must only be parked on level, firm

ground.

 It is particularly important to check

bicycle is equipped with accessories or loaded with luggage.

 Before the ride, raise the kickstand completely with

your foot.

the stability if the

Page 73

7.3 Using the pannier rack

CAUTION

(Alternative equipment)

Crash caused by loaded pannier rack

The riding performance of the bicycle changes with a loaded pannier rack, in particular when steering and braking. This can lead to a loss of control. This may result in a crash and injuries.

 You should practice how to use a loaded pannier

rack safely and reliably before using the bicycle in

public spaces.

Crash caused by unsecured luggage

Loose or unsecured objects on the pannier rack, e.g. belts, may become caught in the rear wheel. This may result in a crash and injuries.

Objects which are fastened to the pannier rack may cover the bicycle's reflectors and the running light. The bicycle may be overseen on public roads. This may result in a crash and injuries.

 Secure any objects which are attached to the

pannier rack sufficiently.

 Objects fastened to the pannier rack must never

cover the reflectors, the lamp or the rear light.

Crushing the fingers in the spring flap

The spring flap on the pannier rack operates with a high clamping force. There is a risk of crushing the fingers.

 Never allow the spring flap to snap shut in

uncontrolled manner.

 Be careful where you position your fingers when

closing the spring flap.

Page 74

The maximum load bearing capacity is indicated on the

NOTICE

pannier rack.

 Never exceed the permitted total weight when

packing the bicycle.

 Never exceed the maximum load bearing capacity

of the pannier rack.

 Never modify the pannier rack.

 Distribute the luggage as evenly as possible on the

left and right-hand side of the bicycle.

 We recommend the use of panniers and luggage

baskets.

Page 75

7.4 Battery

WARNING

CAUTION

Risk of fire and explosion due to faulty battery

The safety electronics on damaged or faulty batteries may fail. The residual voltage can cause a short circuit. The batteries may self-ignite and explode.

 Remove batteries with external damage from

service immediately and never charge them.

 If the battery becomes deformed or begins to

smoke, keep at a safe distance, disconnect the power supply at the socket, and notify the fire service immediately.

 Never extinguish damaged batteries with water or

allow them to come into contact with water.

 If a battery is dropped or struck but shows no signs

of external damage, remove the battery from service and observe it for at least 24 hours.

 Faulty batteries are hazardous goods. Dispose of

faulty batteries properly and as quickly as possible.

 Store in a dry place until disposal. Never store

the vicinity of flammable substances.

 Never open or repair the ba

Risk of fire and explosion due to high temperatures

Excessively high temperatures damage the battery. The battery may self-ignite and explode.

 Never expose the battery to sustained dire

sunlight.

ttery.

Page 76

Fire and explosion caused by short circuit

CAUTION

Small metal objects may jumper the electrical connections of the battery. The batteries may selfignite and explode.

 Keep paper clips, screws, coins, keys and other

small parts away from the battery and do not insert them into the battery.

Chemical burns to the skin and eyes caused by faulty battery

Liquids and vapours may leak from damaged or faulty batteries. They can irritate the airways and cause burns.

 Avoid contact with leaked liquids.

 Immediately consult a doctor in case of contact with

the eyes or any discomfort.

 In case of contact with the skin, rinse off

immediately with water.

 Ventilate the room well.

Fire and explosion caused by penetration by water

The battery is only protected from simple spray water. Penetration by water can cause a short circuit. The battery may self-ignite and explode.

 Never immerse the battery in water.

 If there is reason to believe that water may ente

into the battery, the battery must be removed from service.

Page 77

If a key is left inserted when transporting the bicycle,

NOTICE

or when riding, it may break off or the compartment may open accidentally.

 Remove the key from the battery

after use.

 We recommend that you attach the ke

ring, for example.

7.4.1 Down tube battery (Alternative version)

Before the battery is to be removed or inserted, switch



off the battery and the drive system.

7.4.1.1 Removing the down tube battery

 Open the battery lock with the key.

 Tip the down tube battery out of the top mount.

 Pull the down tube battery out of the bottom mount.

7.4.1.2 Inserting the down tube battery

 Place the down tube battery on the contacts in th

bottom mount.

 Remove the key from the lock.

lock immediately

y to a key

 Tip the battery into the top mount as far as it will go.

 There is an audible clicking noise.

 Check the battery to make sure it is firmly in place.

Page 78

7.4.2 Pannier rack battery (Alternative version)



Before the battery is to be removed or inserted, switch off the battery and the drive system.

7.4.2.1 Removing the pannier rack battery

 Open the battery lock with the key.

 Pull the pannier rack battery backwards and out of

the pannier rack battery mount.

7.4.2.2 Inserting the pannier rack battery

 Remove the key from the lock.

 Insert the pannier rack battery into the pannier rack

battery mount with the contacts first so that it clicks into place.

 Check the battery to make sure it is firmly in place.

7.4.3 Integrated battery (Alternative version)



Before the battery is to be removed or inserted, switch off the battery and the drive system.

7.4.3.1 Removing the integrated battery

 Open the battery lock with the key.

 The integrated battery is released and falls into the

retainer guard.

 Support the battery from below with your hand

the other hand to push on the retainer guard from above.

 The integrated battery is completely released and

falls into your hand.

 Pull the integrated battery from the frame.

 Remove the key from the lock.

. Use

Page 79

7.4.3.2 Inserting the integrated battery

CAUTION

 Place the battery in the bottom mount with the

contacts first.

 Flip the integrated battery up so that it is held by the

retainer guard.

 Push the integrated battery upwards so that it

audibly clicks into place.

 Check the battery to make sure it is firmly in place.

 Lock the battery with the key. Otherwise the batte

may fall out of the mount when you open the lock.

 Remove the key from the lock.

7.4.4 Charging the battery

Fire caused by overheated charger

The charger heats up when charging the battery. In case of insufficient cooling, this can result in fire or burns to the hands.

 Never use the charger on a highly flammable

surface (e.g. paper, carpet etc.).

 Never cover the charger during the charging

process.

Electric shock caused by penetration by water

If water penetrates into a charger, there is a risk of electric shock.

 Never charge the battery outdoors.

Page 80

Electric shock in case of damage

CAUTION

Damaged chargers, cables and plug connectors increase the risk of electric shock.

 Check the charger, cable and plug connector before

each use. Never use a damaged charger.

u The ambient temperature during the charging

process must be within the range from 50°F to 86°F.

Charging temperature

50°F - 86°F

 The battery can remain on the bicycle or be removed

for charging.

 Interrupting the charging process does not damage

the battery.

 On a bicycle which is equipped with two batteries, the

charging process for both batteries is started from the pannier rack battery.

 Remove the rubber cover from the battery.

 Connect the mains plug of the charger to a normal

domestic, grounded socket.

Connection data

 Connect the charging cable to the battery's

charging port.

 The charging process starts automatically.

 During the charging process the operating and

charge status indicator indicates the charge status. When the drive system is switched on, the display shows the charging process.

230 V, 50 Hz

 The charging process is complete when the LEDs

of the operating and charge status indicator go out.

Page 81

Risk of fire and explosion caused by

CAUTION

NOTICE

damaged batteries. The safety electronics on damaged or faulty batteries may fail. The residual voltage can cause a short circuit. The batteries may self-ignite and explode. If the battery becomes deformed or begins to smoke, keep at a safe distance, disconnect the power supply at the socket, and notify the fire service immediately. Never extinguish damaged batteries with water or allow them to come into contact with water.

If a fault occurs during the charging process, a system message is displayed. Remove the charger and the battery from operation immediately and follow the instructions.

7.4.5 Waking the battery

When not used for a longer period, the battery



switches to sleep mode for self-protection. The LEDs of the operating and charge status indicator do not light up.

 Pr

ess the On-Off button (battery).

 The battery's operating and charge status indi

indicates the charge status.

cator

Page 82

7.5 Electric drive system

CAUTION

7.5.1 Switching on the drive system

Crash caused by lack of readiness for braking

A drive system which has been switched on can be activated by the application of force on the pedals. There is a risk of a crash if the drive is activated unintentionally, and the brake is not reached.

 Never start the electric drive system, or switch it off

immediately, if the brake cannot be reached safely and reliably.



A sufficiently charged battery has been inserted on the bicycle.

 The battery is firmly in place. The key has been

removed.

 After switching off, the drive system shuts down. It

is possible to switch back on immediately. Wait a moment as necessary.

There are two options for switching on the drive system.

1 Battery On-Off button

 Press the On-Off button (battery) once.

2 Display On-Off button

 Press the On-Off button (command console with

integrated display) once.

 If the drive system is switched on, the drive

activated as soon as the pedals are moved with sufficient force.

Page 83

7.5.2 Switching off the drive system

The system switches off automatically ten minutes after the last command. The are two options for switching off the drive system manually.

1 Display On-Off key

 Press the On-Off button (command console with

integrated display) once.

2 Battery On-Off key

 Press the On-Off button (battery).

Page 84

7.6 Command console with display

NOTICE

(Alternative version)

7.6.1 Using the USB diagnostics port

Test instruments can be connected to the USB diagnostics port to check the drive system. The USB diagnostics port does not have any other functions.

 Never connect a charger or current consumer (e.g.

mobile phone or computer) to the USB diagnostics port.

7.6.2 Using the pushing aid

The pedals turn when using the pushing aid because of the design.

 When the pushing aid is in use, the bicycle must be

steered securely with both hands.

 Allow for enough freedom of movement for the

pedals.

The pushing aid provides the rider with assistance when pushing the bicycle. The maximum speed in the process is 3.75 mph.

 The tractive power of the pushing aid and its speed

can be influenced by the selection of gear. To spare the drive, first gear is recommended for travelling uphill.

 The level of assistance O F F must not be selected.

 Press the pushing aid button once, holding it for

less than a second, to activate the pushing aid.

 Press and hold the plus button within three

seconds.

 The motor starts.

Page 85

Switching off the pushing aid

The pushing aid is switched off in case of three events.

•The plus button is released.

•The wheels are blocked.

•At speeds above 3.75 mph

7.6.3 Using the running light

To switch on the running light, the drive system has to



be switched on already.

 Press and hold the plus button for around two

seconds.

 The running light is switched on, the running light

symbol is displayed.

 Press and hold the plus button for longer than

three seconds.

 The running light is switched off, running light symbol

is not displayed.

7.6.4 Selecting the level of assistance

 Press the plus button once, holding it for less than

one second.

 The level of assistance is increased.

 Press the minus button, holding it for less than one

second.

 The level of assistance is reduced.

7.6.5 Journey information

The displayed journey information can be changed and partially reset.

Page 86

7.6.5.1 Switching the displayed journey information

 Press and hold the minus button (command

console with display) again for around two

seconds, until the desired item of journey information is displayed.

7.6.5.2 Resetting the journey distance

 Press and hold the plus and minus buttons

simultaneously for around three seconds.

 RESET is shown on the display.

 Continue to press the plus and minus buttons

together.

 The item of journey information TRIP is reset.

7.6.5.3 Changing the unit for speed

The speed can be displayed in either kilometres or miles.

 Press and hold the minus button (command

console with display) for longer than three seconds.

 Press the On-Off button (command console

integrated display), holding it for less than one

second.

 The speed display changes to the other unit.

7.6.5.4 Displaying system data

 The drive system is switched off.

 Press the plus and minus buttons simultaneously.

 After three seconds, press the On-Off button

(command console with integrated display).

 Press the plus or minus button repeatedly until the

desired item of system data is displayed.

with

Page 87

7.7

Gear shift

The selection of the appropriate gear is a prerequisite for a physically comfortable ride and making sure that the electric drive s ideal pedaling frequency is between 40 and 60 revolutions per minute.

 Select the appropriate gear with the gear shift

shifter.

 The gear shift switches the gear.

ystem functions properly. The

Page 88

7.8 Brakes

CAUTION

Crash caused by incorrect use

Handling the brake improperly can lead to loss of control or crashes, which may result in injuries.

 Shift your weight back and down as far as possible.

 Practise braking and emergency braking before

bicycle is used in public spaces.

Crash caused by wet conditions

The tyres may slip on wet roads. In wet conditions you must also expect a longer braking distance. The braking sensation differs from the usual sensation. This can cause loss of control or a crash, which may result in injuries.

 Ride slowly and brake in good time.

Crash after cleaning, servicing or repair

After cleaning, servicing or repairing the bicycle, the braking effect may be temporarily unusually weak. This may result in a crash and injuries.

 After cleaning, servicing or repair, carry out a fe

test brake applications.

Burns caused by heated brake

The brakes may become very hot during operation. There is a risk of burns in case of contact.

the

 Never touch the components of the brake dire

after the ride.

7.8.1 Using the brake

 Pull the brake lever until the desired speed has

been reached.

ctly

Page 89

7.8.2

Using the coaster brake (Alternative equipment)



The best braking effect is achieved if the pedals are in the 3 o'clock and 9 o'clock position when braking. To bridge the free travel between the riding movement and the braking movement, it is recommendable to pedal a little beyond the 3 o'clock and 9 o'clock position before you pedal in the opposite direction to the direction of travel and start braking.

 Pedal in the opposite direction to the direction of

travel until the desired speed has been reached.

Page 90

7.9 Suspension and damping

7.9.1 Locking the front wheel suspension (Alternative equipment)

When the fork lock is in the open position, the suspension system has activated suspension and thus

provides the rider and the bicycle with relief. Riding with the fork lock open should therefore be preferred for everyday riding.

When riding downhill or at high speed, for instance, the force which is exerted on the drive is absorbed by the suspension system and reduced by up to 50%. In these cases it is recommendable to close the suspension fork.

The fork lock may be situated directly on the fork or on the handlebars, depending on the version.

7.9.1.1 Fork lock on the suspension head

 In order to lock the front wheel

suspension, shift the locking lever to the LOC K position.

 In order to release the front

wheel suspension, shift the locking lever to the OPEN

position.

Figure 28: Fork lock on the suspension for head with locking lever (1),

example

Page 91

7.9.1.2 Locking lever on handlebars, version I

 To lock the suspension system, push the locking

slider out of the pushed-in position.

 The locking slider stops in the pushed-out position.

A padlock symbol indicates that the fork lock is locked.

 To release the front wheel

suspension, push the locking

slider out of the pushed-out position.

 You can tell that the fork lock

is open if the locking slider is pushed in.

Figure 29: Fork lock on handlebars, version I, with locking slider (1)

7.9.1.3 Locking lever on handlebars, version II

 To lock the suspension systems, push the black

locking lever. The locking lever features a closed padlock symbol.

 To release the front wheel

suspension, push the blue

unlocking lever.

 The unlocking lever features

an open padlock symbol.

Figure 30: Fork lock on handlebars, version II, with locking lever (1) and

unlocking lever (2) (example)

Page 92

7.9.1.4 Fork lock on handlebars, version III

 To lock or release the front

wheel suspension, push the long lever.

 To reset the function of th

long lever, push the short lever.

Figure 31: Fork lock on handlebars, version III, with long lever (1) and short

lever (2), example

7.9.1.5 Fork lock on handlebars, version IV

 To lock the front wheel

suspension, push the locking

lever upwards.

 To release the front wheel

suspension, push the

unlocking knob.

Figure 32: Fork lock on handlebars, version IV, with locking lever (1) and

unlocking knob (2)

7.9.1.6 Fork lock on handlebars, version V

 To lock the front wheel suspension, push the upper

locking lever.

Page 93

 The locking lever features a closed padlock

symbol.

 To release the front wheel

suspension, push the side

unlocking lever.

 The

side unlocking lever features an open padlock symbol.

Figure 33: Fork lock on handlebars, version V, with locking lever (1) and

unlocking lever (2)

7.9.2 Locking the compression damper

 In order to lock the

suspension, turn the locking lever in the plus direction.

 In order to release th

suspension, turn the locking lever in the minus direction.

Figure 34: Compression damper with locking lever (1), example

Page 94

8 Maintenance

Cleaning check list

Lubricating the chain once a month



Cleaning the battery once a month



Basic cleaning and preservation of all



components

Cleaning the charger at least every six



at least every six months

months

Maintenance check list

Checking the position of the USB rubber cover before each ride



Checking for tire wear



Checking for rim wear once a week



Checking the tire pressure



Checking for brake wear once a month



Checking the electrical cables and Bowden cables for damage and to make sure they are



fully functional

Checking the chain tension once a month



Checking the tension of the spokes every three



Checking the gear shift setting every three



Checking the suspension fork for wear and to



make sure it is fully functional

once a week

once a month

months

every three months

Service check list

Service by the specialist dealer every six months



Page 95

8.1 Cleaning and servicing

CAUTION

NOTICE

Crash and falling caused by unintentional activation

There is a risk of injury if the drive system is activated unintentionally.

 Remove the battery before cleaning.

The following servicing measures must be carried out regularly [wCheck list, page 92]. Servicing can be performed by the user and rider. In case of any doubt, consult the BULLS specialist

dealer.

8.1.1

Battery

Fire and explosion caused by penetration by water

The battery is only protected from simple spray water. Penetration by water can cause a short circuit. The battery may self-ignite and explode.

 Never clean the battery with a high-pressure water

device, water jet or compressed air.

 Never immerse the battery in water.

 Remove the battery from the bicycle before

cleaning.

 Only clean the electrical connections of the battery

with a dry cloth or brush.

 Wipe off the decorative sides with a damp cloth.

8.1.2 Display

If water enters into the display, it will be destroyed.

 Never immerse the display in water.

 Remove the display from the bicycle before

cleaning.

Page 96

 Carefully clean the display with a damp, soft cloth.

CAUTION

NOTICE

8.1.3 Basic cleaning and preservation

Crash caused by brake failure

After cleaning, servicing or repairing the bicycle, the braking effect may be temporarily unusually weak. This may result in a crash and injuries.

 Never apply care products or oil to the brake disks

or brake pads, or the braking surfaces on the rims.

 After cleaning, servicing or repair, carry out a fe

test brake applications.

Water may enter into the inside of the bearings if you use a steam jet. The lubricant inside is diluted, the friction increases and, as a result, the bearings are destroyed in the long term.

 Never clean the bicycle with a steam jet.

Greased parts, e.g. the seat post, the handlebars or the stem, may no longer be safely and reliably clamped.

 Never apply grease or oil to the clamping areas.

 Clean the bicycle with a damp cloth. Mix a little

neutral soap with the cleaning water.

 Then use wax or oil on the bicycle as a preservative

agent.

8.1.4 Chain

 Clean and lubricate the chain and the chain wheels

using the stipulated care products.

Page 97

8.2 Maintenance

CAUTION

NOTICE

Crash and falling caused by unintentional activation

There is a risk of injury if the drive system is activated unintentionally.

 Remove the battery before maintenance.

The following maintenance measures must be carried out regularly [wCheck list, can be carried out by the user and rider. In case of any doubt, consult the BULLS specialist dealer.

page 92]. They

8.2.1

Wheel

If the pressure is too low in the tire, the tire does not achieve its load bearing capacity. The tire is not stable and may

If the pressure in the tire is too high, the tire may burst.

u Check the tire pressure against the specifications

u Adjust the tire pressure as necessary.

u Check the tire wear.

u Check the

• The rims

• The rims with visible wear indicator are worn as soon

come off the rim.

[ Data sheet, page 1]

rim wear.

of a rim brake with invisible wear indicator are worn as soon as the wear indicator becomes visible in the area of the rim joint.

as the black, all-round groove on the pad friction surface becomes invisible. We recommend that you also replace the rims with every second brake lining replacement.

 Check the tension of the spokes.

Page 98

8.2.2 Brake system

NOTICE

u On bicycles with a rim brake, check the position of

the brake exactly to the rims. Replace the brake pads on the rim brake when the profile (check notches) has reached a remaining depth of 1 mm.

u Replace the brake linings on the disc brake when

the pad thickness has reached 0.5 mm.

pads. The brake pads must be aligned

8.2.3 Electrical cables and brake cables

 Check all visible electrical cables and brake cables

for damage. If, for example, the sheathing is compressed, the bicycle will need to be removed from service until the brake cables have been replaced.

8.2.4 Gear shift

8.2.5 USB port

 Che

 Check the gear shift and the shifter or the twist grip

Any moisture which enters through the USB port may trigger a short circuit in the display.

 Regularly check the position of the cover on the USB

ck all electrical cables and Bowden cables to

make sure they are fully functional.

setting and adjust it as necessary.

port and adjust it as necessary.

Page 99

8.2.6 Chain or belt tension

NOTICE

2 cm

Excessive chain or belt tension increases wear.

If the chain or belt tension is too low, there is a risk that the chain or belt will slip off the chain wheels.

 Check the chain and belt tension once a month.

u Check the chain or belt tension in three or four

positions, turning the crank a full revolution.

u If the chain or the

belt can be pushed more than 2

cm, the chain or belt will need to be tensioned again by the BULLS specialist dealer.

u If the chain or the belt can only be pushed less than

1 cm, the chain or belt will need to be relieved of tension accordingly.

 The ideal chain or b

elt tension has been achieved if the chain or the belt can be pushed a maximum of 2 cm in the middle between the pinion and the toothed wheel. The crank must also turn without resistance.

Figure 35: Checking the chain and belt tension

Page 100

8.3 Service

CAUTION

Crash and falling caused by unintentional activation

There is a risk of injury if the drive system is activated unintentionally.

 Remove the battery before the service.

Crash caused by material fatigue

If the service life of a component has expired, the component may suddenly fail. This may result in a crash and injuries.

u Have the BULLS specialist dealer carry out six-

monthly basic cleaning of the bicycle, preferably at the same time as the stipulated servicing work.

A service must be performed by the BULLS

ialist dealer at least every six months [w

spec

Check list,

en functional.

u During basic cleaning, the BULLS specialist dealer

that

sure

inspects the bicycle for any signs of material fatigue.

page

the bicycle remains safe and fully

]. This is the

only way to

u The BULLS specialist dealer checks the software

version of the drive system and updates it. The electrical connections are checked, cleaned and preservative agent is applied. The electrical cables are inspected for damage.

u The further servicing measures correspond to those

which are recommended for a bicycle as per ISO 4210. Particular attention is paid to the rim and brake wear. The spokes are re-tightened in accordance with the findings.

Bulls Twenty 9, Urban, Cruiser, Monster, Cross Mover Speed Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
