Bulgin Buccaneer 6000 Series, Buccaneer PXP0611, Buccaneer PXP0610 Wiring And Assembly Instructions

Buccaneer 6000 Series
Waterproof Connector

For Power - Thermoplastic Body

IMPORTANT - PLEASE READ

It is important that these instructions are fully complied with to ensure this product is
completely watertight and electrically safe - IF IN DOUBT CONSULT A QUALIFIED
ELECTRICIAN.

Always wire socket insert to supply, wire plug insert to appliance.

However plug/socket inserts can be fitted into any style of main body to give correct
plug/socket combination for your application.

Do not twist bodies when unmating connector, ensure a linear pull is applied.

Cable Glands

To ensure the correct cable sealing pairs of cable glands and collets are available to
accurately fit cable diameters from 4.0mm up to 10.0mm. It is important to match the
correct gland to the cable used, these are:

Cable diameter Gland Colour

4.0-5.0mm Dark Grey

5.0-7.0mm White

7.0-9.0mm Yellow

9.0-10.0mm Light Grey

Ratings

Poles: 2 3 8 16 22
Current Rating: 16A 12A 10A 3A 3A
Voltage Rating: 277V 277V 277V 60V 60V
Conductor
accommodation:

14-18 AWG 14-18 AWG 18-20AWG 22-26 AWG 22-26AWG

metric equivalents:

2.0-0.75mm22.0-0.75mm20.75-0.5mm20.33-0.14mm20.33-0.14mm

2

For full technical specification visit: www.elektron-bulgin.com

GB

www.elektron-bulgin.com

Wiring and Assembly instructions

bulgin

a brandof Elektron Technology

6000 Series - PXP0610 & PXP0611

1

2

6

5

3

4

6000 Series - PXP0612

1

5

2

3

4

6

6000 Series

14917/SP

14944-45-46

Contact carrier removal

Contact pin/socket extraction

Part no: 15054 Issue no: 1.1
