Buhler Genesis II 2145, Genesis II 2160, Genesis II 2180, Genesis II 2210, Genesis 2145 Brochure & Specs

Genesis Series

Models :: 2145, 2160, 2180, 2210 (145-210 PTO-HP)

e Genesis is an industry leading, full-featured 2WD/FWD tractor with over a decade of eld proven performance. e

Genesis is available with 145, 160, 180 or 210 PTO-HP (at 2100 RPM). All models are equipped with a 7.5L Constant Power

Plus Genesis engine that delivers a combination of power and performance. e Constant Power Plus engine is matched to

a smooth shiing Powershi transmission that has 18 forward and 9 reverse speeds with operator programmable features

designed to match your work requirements. Finger tip electro-hydraulics with the optional HydraFlow® Plus package deliver

55 GPM to meet today’s high ow demands.

MEETING THE DEMANDS OF MODERN EQUIPMENT

Constant Power Plus

All models are equipped with a 7.5L
Constant Power Plus Genesis engine
that delivers a combination of power and
performance.

Powershift transmission

Power is transferred to the ground through
an 18 x 9 full powershi transmission that
includes these shiing features:

• Pulse shi

• Sequential shiing

• Straight-line shuttle

• Programmable upshi & downshi

• Automatic speed matching

• Programmable reverse

Electro-hydraulics

Electro-hydraulics are standard equipment,
with nger tip operation to control the
raising, lowering, oat, neutral and pro­grammable timed self-centering detents.
Convenient thumb wheels provide precise
ow from 0 to 30 GPM at rated engine
speed (2100 RPM). e optional Hydra­Flow® Plus package boosts output to 55
GPM at rated engine speed.

MAXIMIZE PRODUCTIVITY

All Genesis FWD models are available with an optional Ultrasteer®
front axle for a sharper turning radius that increases productivity.
Tighter turning yields better fuel eciency and reduces time
wasting maneuvers. Add the optional traction control system
(TCS), with front dierential locks to make this tractor a real
workhorse in the eld. All TCS models can be ordered with
optional front duals for increased traction and otation.

3895 Self-Leveling Loaders

Add versatility to your Genesis with the addition of a 3895
True Self-Leveling Loader. Designed with the latest in front-

end loader technology, the 3895 True Self-Leveling Loader
is factory installed on the Genesis by trained technicians.
Easy-to-use mechanical or electronic control joysticks and a
steering column mounted shuttle shi are available to further
enhance productivity.

e Self-Leveling system keeps the bucket in one constant
position during the total li and lower cycle. e system provides
full dump at ground and additional roll back as the loader raises.
e level indicator rod shows the position of the bucket or
attachment relative to the ground.

COMFORT AND CONVENIENCE

e Genesis combines operator comfort and function. Two
doors access the clean, quiet and ergonomically correct cab inte­rior. e cab is designed for excellent visibility to all interior and
exterior tractor functions.

An ecient climate control system keeps the operator environ­ment clean and dust free. e adjustable side console moves
forward and backward with the touch of a button so the shi
lever, throttle, hydraulics and 3-point hitch controls are in the
perfect position.

e bright easy to read electronic instrument display, monitors
and provides feedback on all critical tractor functions. Tilt and
telescopic steering and an adjustable air ride seat complete the
package.

Service and Maintenance

Buhler factory trained dealer service technicians are up to date
with the latest repair technology. Ecient troubleshooting by
trained professionals provides timely service support that mini­mizes your downtime.

DIMENSIONS AND SPECIFICATIONS

DIMENSIONS 2145 2160 2180 2210

Height to top of cab 122" (3080 mm) 122" (3080 mm) 122" (3080 mm) 122" (3080 mm)

Top of exhaust 124" (3158 mm) 124" (3158 mm) 124" (3158 mm) 124" (3158 mm)

Ground clearance 18.6" (471 mm) 18.6" (471 mm) 18.6" (471 mm) 18.6" (471 mm)

Wheel base, Standard steer
Wheel base, Ultra Steer

Length, Standard steer
Length, Ultra Steer

®

®

GENESIS 2WD/FWD 2145 2160 2180 2210

Engine type 6 cylinder Genesis Diesel, Tier II, turbo charged and air to air cooled electronic fuel injection pump control

Engine HP 196 hp (145 kW) 227 hp (169 kW) 260 hp (194 kW) 278 hp (207 kW)

PTO-HP@2100 rpm 145 hp (108 kW) 160 hp (119 kW) 180 hp (134 kW) 210 hp (157 kW)

Engine displacement / bore and stroke Displacement: 456 cu.in. (7.5 L) / bore and stroke: 4.4" x 5.0" (112 x 127 mm)

Cruise control / fuel cooler Standard / N/A Standard / N/A Standard / Standard Standard / Standard

Transmission type Genesis Full Powershift

Standard - full powershift 18 forward speeds, 9 reverse: 25 mph (40 km/h)

Straight-line shuttle shift with programming Yes

Electrical system Advanced diagnostics with 2-12 volt low maintenance 950 CCA each battery and 12 V-130 amp alternator

Standard lights Halogen - 2 headlights, 9 worklights, 2 front roof mounted

Optional lights available High intensity discharge (HID) lighting

Radar / rear wiper / washer Optional

Hydraulic type Closed Center Load Sensing, relief- 2900 psi (200 Bar)

Flow at 2100 rpm Standard: 30 GPM (117 L/min), Optional: HydraFlow® Plus 55 GPM (208 L/min)

Number of remotes Standard: color coded system with 3 valves, Optional: 4th valve available

Front axle - track setting, 2WD 61" to 87" (1575 mm to 2210 mm) N/A

- track setting, FWD

- track setting, Ultra Steer

Rear axle length 112" (2845 mm) 112" or 120" (2845 mm or 3050 mm)

Rear axle diameter 3.62" (92 mm) 4.13" (105 mm)

Rear axle track - width adjustable Axle A-112" 60" to 124" (1524 mm to 3150 mm)

Rear axle track - width adjustable Axle B-120" N/A 60" to 128" (1524 mm to 3255 mm)

Three-point hitch Category III

Standard (SAE) lift capacity 12,500 lbs (5670 kg) 15,000 Ibs (6804 kg)

Electronic draft sensing Standard

®

118.3" (3005 mm)

122.6" (3115 mm)

200.4" (5010 mm)

204.8" (5120 mm)

118.3" (3005 mm)

122.6" (3115 mm)

200.4" (5010 mm)

204.8" (5120 mm)

60" to 88" (1524 mm to 2235 mm)

60" to 88" (1524 mm to 2235 mm)

118.3" (3005 mm)

122.6" (3115 mm)

201.5" (5038 mm)

205.9" (5148 mm)

118.3" (3005 mm)

122.6" (3115 mm)

201.5" (5038 mm)

205.9" (5148 mm)

PTO-SHAFT 2145 2160 2180 2210

Type Wet / multi-plate clutch

Speed 540 / 1000 rpm 1000 rpm (540 rpm opt.) 1000 rpm 1000 rpm

540 rpm 1.375" (34.9 mm) dia. 6 spline 1.375" (34.9 mm) dia. 6 spline N/A N/A

1000 rpm 1.375" (34.9 mm) dia. 21 spline 1.375" (34.9 mm) dia. 21 spline 1.75" (44.5 mm) dia. 20 spline 1.75" (44.5 mm) dia. 20 spline

1000 rpm † N/A 1.75" (44.5 mm) dia. 20 spline 1.375" (34.9 mm) dia. 21 spline 1.375" (34.9 mm) dia. 21 spline

† optional output shaft

CAPACITIES 2145 2160 2180 2210

Fuel tank 110 U.S. gal (416 L) 110 U.S. gal (416 L) 110 U.S. gal (416 L) 110 U.S. gal (416 L)

Engine oil 22.5 qt (21 L) 22.5 qt (21 L) 22.5 qt (21 L) 22.5 qt (21 L)

Hydraulic system 124 qt (117 L) 148 qt (140 L) 148 qt (140 L) 148 qt (140 L)

Coolant system 26 qt (25 L) 26 qt (25 L) 28 qt (26.5 L) 28 qt (26.5 L)

3895 SLR LOADER SPECIFICATIONS 3895 SLR ULTRA STEER 3895 SLS STANDARD STEER

Type of loader Mechanical true self leveling system complete with manifold and block relief valve

Breakout force 8500 lb-ft at pivot pin 9950 lb-ft at pivot pin

Maximum lift capacity 6900 lbs (3129 kg) 6875 lbs (3125 kg)

Lift cylinders 3.5" (90 mm) diameter, 32.5" (825 mm) stroke, 2" (51 mm) shaft 3.5" (90 mm) diameter, 32.5" (825 mm) stroke, 2" (51 mm) shaft

Bucket cylinders 3.0" (76 mm) diameter, 24.5" (612 mm) stroke, 1.75" (44 mm) shaft 3.0" (76 mm) diameter, 24.5" (612 mm) stroke, 1.75" (44 mm) shaft

Maximum lift height 181" (4.6 m) to pivot pin 169" (4.3 m) to pivot pin

Maximum dump angle 61° 61°

Maximum rollback angle 35° 35°

OPTIONAL ACCESSORIES FOR THE BUHLER VERSATILE 3895 SL LOADER

QUICK-TACH BUCKETS

100S" 3.78 m), multi-purpose
100H" (4.02 m), multi-purpose
96" (3.78 m), snow
85" (3.35 m), manure

GRAPPLES

A-FRAME

BALE SPEARS

1.20 cu.yd. capacity, prepunched for grapple tines

1.65 cu.yd. capacity, prepunched for grapple tines

2.25 cu.yd. capacity

1.20 cu.yd. capacity, complete with 36" (0.9 m) tines

Standard and large capacity 6' bale models available
84" cross tube, adjustable grapple weldments

Accepts bale spears and pallet forks

49" (1.24 m) with 1, 2, or 3 spears

BUCKET TINES

For 96" bucket
For 102" bucket

Bolt on 21" (0.52 m), quantity of 10
Bolt on 21" (0.52 m), quantity of 10

PALLET FORK KIT

Dimensions of tine
Weight capacity
Amount of adjustment on shaft

CUSHION RIDE

48" (1.22 m) long x 1.5" (38 mm) thick x 4" (102 mm) wide
4400 lbs (2000 kg)

11.25" (280 mm)

Absorbs abrupt forces caused by suddenly dropping a heavy
load or when driving across rough ground.

JOYSTICK OPTIONS MECHANICAL ELECTRONIC

Location Cab right hand console Cab right hand console

Circuits Two or three circuit.

Three circuit valve
has separate grapple
function with thumb
controlled rocker switch.

Float function On the loader lift circuit On the loader lift circuit

All 3895 SL Loaders come with standard color coded hookup quick attach system,
parking stand, hydraulic lift lock, bucket level indicator and grill guard.

Three circuit for
grapple operation.
In console options for
tractors equipped with
shuttle shift.
