User Manual for User-friendly Firmware
Nniti High Power Wireless N Router & Access Point
WZR-HP-G300NH
www.bualotech.com
35011575ver.01
Contents
Chapter 1 Product Overview ...........................................5
Features .................................................................................. 5
Air Navigator CD Requirements .............................................. 7
300 Mbps High Speed Mode ................................................... 7
Package Contents ................................................................... 7
Hardware Overview ................................................................. 8
Front Panel LEDs ........................................................................... 8
Back Panel ..................................................................................... 10
Bottom ............................................................................................ 12
Right Side ...................................................................................... 12
Chapter 2 Placing Your AirStation ..................................13
Vertical Placement .................................................................. 13
Horizontal Placement .............................................................. 13
Wall-Mounting ......................................................................... 14
Chapter 3 Installation ....................................................... 15
CD Setup ................................................................................. 15
Manual Setup .......................................................................... 15
Chapter 4 Conguration ..................................................20
How to Access the Web-Based Conguration Utility ............... 20
Conguration Utility Menus in Router Mode ............................ 22
Conguration Utility Menus in Bridge Mode ............................ 24
Setup ....................................................................................... 26
Internet/LAN (LAN Cong) ...................................................... 28
Internet (Router Mode only) ........................................................... 28
WZR-HP-G300NH User Manual 1
PPPoE (Router Mode only) ............................................................ 29
DDNS (Router Mode only) ............................................................. 32
VPN server (Router Mode Only) .................................................... 34
LAN ................................................................................................ 36
DHCP Lease (Router Mode only) .................................................. 38
NAT (Router Mode only) ................................................................ 39
Route ............................................................................................. 40
Wireless Cong ....................................................................... 41
WPS ............................................................................................... 41
AOSS ............................................................................................. 42
Basic .............................................................................................. 44
Advanced ....................................................................................... 48
WMM .............................................................................................. 49
MAC Filter ...................................................................................... 51
Multicast Control ............................................................................ 52
WDS ............................................................................................... 53
Security (Router Mode only) ................................................... 55
Firewall (Router Mode only) ........................................................... 55
IP Filter (Router Mode only) ........................................................... 57
VPN Pass Through (Router Mode only) ........................................ 58
LAN Cong (QoS) ................................................................... 59
Port Forwarding (Router Mode only) .............................................. 59
DMZ (Router Mode only) ............................................................... 61
UPnP (Router Mode only) .............................................................. 62
QoS (Router Mode only) ................................................................ 63
Movie Engine (QoS) ....................................................................... 65
NAS ......................................................................................... 67
Disk management .......................................................................... 67
Shared Folder ................................................................................ 69
User Management ......................................................................... 71
Shared Service .............................................................................. 72
Web Access ................................................................................... 74
Media Server .................................................................................. 76
BitTorrent ........................................................................................ 77
WZR-HP-G300NH User Manual 2
Admin Cong ........................................................................... 79
Name ............................................................................................. 79
Password ....................................................................................... 80
Time/Date ...................................................................................... 81
NTP ................................................................................................ 82
ECO ............................................................................................... 83
Access ........................................................................................... 85
Log ................................................................................................. 86
Save/Restore ................................................................................. 87
Initialize/Restart ............................................................................. 88
Update ........................................................................................... 89
Diagnostic ............................................................................... 90
System Info .................................................................................... 90
Logs ............................................................................................... 92
Packet Info ..................................................................................... 93
Client Monitor ................................................................................. 94
Ping ................................................................................................ 95
Chapter 5 Connect to a Wireless Network ..................... 96
Automatic Secure Setup (AOSS/WPS) ................................... 96
Windows 7/Vista (Client Manager V) ............................................. 97
Windows XP (Client Manager 3) .................................................... 98
Other Devices (e.g. Game Console) .............................................. 99
Manual Setup .......................................................................... 99
Windows 7 (WLAN AutoCong) ..................................................... 99
Windows Vista (WLAN AutoCong) ............................................... 100
Windows XP (Wireless Zero Conguration) ................................... 103
Chapter 6 Trouble Shooting ............................................ 104
Cannot connect to the Internet over wired connection. ........... 104
Cannot access the web-based conguration utility. ................ 104
Cannot connect to the network wirelessly. .............................. 105
WZR-HP-G300NH User Manual 3
You forgot AirStation’s SSID, Encryption Key, or Password. ... 105
The link speed is slower than 300 Mbps (Maximum link speed is
only 150Mbps). ........................................................................ 105
Other Tips ................................................................................ 106
Appendix A Specications .............................................. 109
Appendix B Default Conguration Settings ...................111
Appendix C TCP/IP Settings in Windows ....................... 118
Appendix D Restoring the Default Conguration ..........121
Appendix E Shared Folders and the USB Port .............. 122
Appendix F Regulatory Compliance Information .......... 124
Appendix G Environmental Information .........................130
Appendix H GPL Information ..........................................131
Appendix I Warranty Information .................................... 132
WZR-HP-G300NH User Manual 4
Chapter 1 Product Overview
Installing Your AirStation
To install your AirStation, insert the software CD from your package into your computer and follow
the directions on the screen. For more infomation about installation, turn to chapter 3 of this
manual.
Professional or User-friendly?
This AirStation wireless router comes with two dierent rmware packages. You may use either the
dd-wrt-based Professional rmware or the simple User-friendly rmware. By default, the Professional
firmware is installed. Turn to page 26 for instructions on switching between the two firmware
packages.
Note : Most of this manual documents the User-friendly firmware. For more information on the
dd-wrt-based Professional firmware, consult the help files in its web-based configuration
interface or go to www.dd-wrt.com/wiki.
Features
Supports IEEE802.11n and IEEE802.11b/g
With support for current Wireless-N, Wireless-G, and Wireless-B standards, the AirStation can transfer
data to and from all standard 2.4 GHz wireless clients.
Dual speed mode
Dual speed mode makes wireless transmission faster by using 2 channels, allowing 300 Mbps data
transmission.
Support AOSS and WPS
Both AOSS (AirStation One-touch Secure System) and WPS (Wi-Fi Protected Setup) are supported.
These automatic connection standards make connection with compatible wireless devices easier.
Security Features
The AirStation is equipped with following security features:
• AOSS
• WPS
• WPA-PSK (TKIP/AES)
• WPA2-PSK(TKIP/AES)
• WPA/WPA2 mixed PSK
WZR-HP-G300NH User Manual 5
Chapter 1 Product Overview
• WEP (128/64 bit)
• Privacy Separator
• MAC address access restriction
• Deny Any Connection/Stealth SSID
• Password protection for settings
• Firewall with easy rules
Automatic Channel Selection
Monitors wireless interference and automatically assigns the clearest, best channel.
Roaming
You can use multiple AirStations to cover a large area. Wireless clients can automatically switch
AirStations for the best signal.
Initialization
To restore settings back to the factory defaults, hold down the reset button on the bottom of the
unit.
Browser Based Administration
This unit can be easily congured from a web browser on your computer.
Auto Mode (Router/Bridge Automatic Recognition)
In Auto mode, the AirStation will detect whether or not your network has a router and automatically
switch to the appropriate router or bridge mode. You can also manually switch between modes.
(See page 10.)
MovieEngine
MovieEngine uses QoS to optimise your network for mutimedia streaming. This can reduce jumps,
distorted audio, and dropped frames while watching streamed video.
NAS (Network Attached Storage)
Attach a USB hard drive to the AirStation and share it on the network as a NAS. All connected clients
can access it.
Gigabit Ethernet
This unit supports gigabit Ethernet, allowing transmission rates of up to a billion bits per second.
WZR-HP-G300NH User Manual 6
Chapter 1 Product Overview
Air Navigator CD Requirements
The AirStation wireless router and access point works with most wired and wireless devices.
However, the automatic installation program on the CD requires a connected Windows 7, Vista or
XP computer to run. If you use the AirStation with a dierent operating system, you will have to
congure your network settings manually from a browser window.
300 Mbps High Speed Mode
300 Mbps is the link speed when using Wireless-N mode. It represents actual wireless data speeds,
including overhead. Because the overhead is not available for user data transfer, usable wireless
throughput will be substantially slower.
Package Contents
The following items are included in your AirStation package. If any of the items are missing, please
contact your vender.
• WZR-HP-G300NH ........................................................................................................................1
• AC adapter ..................................................................................................................................... 1
• Stand for vertical/wall-mounting .......................................................................................... 1
• Screws for wall-mounting ........................................................................................................2
• LAN cable ....................................................................................................................................... 1
• Air Navigator CD .......................................................................................................................... 1
• Quick Setup Guide ......................................................................................................................1
WZR-HP-G300NH User Manual 7
Chapter 1 Product Overview
Hardware Overview
Front Panel LEDs
1
1
2
3
4
5
6
7
8
9
2
3
AOSS Button
To initiate AOSS, hold down this button until the Security
LED ashes (about 1 second). Then, push or click the AOSS
button on your wireless client device to complete the
connection. Both devices must be powered on for this to
work.
Power LED (Green)
On: The AC adapter is connected.
O: The AC adapter is not connected.
Security LED (Amber)
Indicates security status.
O: AOSS or Encryption is not set.
On: AOSS/WPS activated; accessed to exchange
security keys.
Encryption has been set.
2 blinks: The unit is waiting for an AOSS or WPS security
key.
Blinking: AOSS/WPS error; failed to exchange security
keys.
Note: The Security LED is lit if an encryption key has been
set.
4
Wireless LED (Green)
Indicates wireless LAN status.
On: Wireless LAN is transmitting.
O: Wireless LAN is connected but not active.
5
Router LED (Green)
On: Router functionality is enabled.
O: Router functionality is disabled.
WZR-HP-G300NH User Manual 8
Chapter 1 Product Overview
6
Diag LED (Red) This indicates the status of this unit depending on the number of blinks
per cycle.
Note: When the unit is rst turned on or restarted, the Diag LED will blink
for almost a minute during boot. This is normal.
Diag LED
status
2 blinks *
3 blinks *
4 blinks *
5 blinks IP address setting error Because the network addresses of both the Internet port (WAN
Continuously
blinking
Meaning Status
1
Flash ROM error Cannot read or write to the ash memory.
1
Ethernet (wired) LAN
error
1
Wireless LAN error Wireless LAN controller is malfunctioning.
Updating the rmware
*2
Saving settings
Initializing settings
Ethernet LAN controller is malfunctioning.
port) and the LAN port are the same, it is not possible to establish
communication. Change the LAN side IP address of this unit.
Updating the rmware.
Saving the settings.
Initializing the settings.
*1 Unplug the AC adapter from the wall socket, wait for a few seconds, and then plug it again. If the
light still ashes, please contact technical support.
*2 Never unplug the AC adapter while the Diag LED is blinking.
Movie Engine On LED (Blue)
7
On: Movie Engine functionality is enabled.
O: Movie Engine functionality is disabled.
Movie Engine O LED (Blue)
8
On: Movie Engine functionality is disabled.
O: Movie Engine functionality is enabled.
Movie Engine Switch
9
Switches the movie engine function between enabled and disabled.
On: Movie Engine functionality is enabled.
O: Movie Engine functionality is disabled.
WZR-HP-G300NH User Manual 9
Chapter 1 Product Overview
Back Panel
ROUTER
ON
OFF
AUTO
USB
11
EJECT
USB
LAN
1
10
12
13
10
Router Switch
Switches router mode between enabled, disabled, and auto.
On: Router functionality is enabled (router mode).
O: Router functionality is disabled (bridge/AP
mode).
Auto: This switches between modes automatically
based on whether or not another router is
detected on the Internet port. The default setting
for this switch is Auto.
11
USB Eject Button
14
2
3
4
15
To dismount a USB hard drive, hold down this button until
the USB LED ashes (about 3 seconds). The USB drive can
then be unplugged safely.
12
USB LED (Blue)
On: The USB disk is connected.
16
INTERNET
POWER
17
18
Flashing: The USB disk can be removed.
O: The USB disk is not connected.
Note: Never disconnect the USB disk or turn o the unit,
while the USB LED lights up.
13
USB Port
Connect the USB drive.
Note: Refer to the technical restriction on page 122.
14
LAN Port Connect your computer, hub, or other Ethernet devices to these
ports. This switching hub supports 10Mbps,100Mbps, and 1000Mbps
connections.
15
LAN LED (Green)
On: An Ethernet device is connected.
Flashing: An Ethernet device is communicating.
WZR-HP-G300NH User Manual 10
Chapter 1 Product Overview
16
Internet Port 10Mbps, 100Mbps, and 1000Mbps connections are supported.
Note: In bridge/AP mode (router switch o), the Internet port becomes a
regular LAN port, for a total of 5 usable LAN ports.
17
Internet LED (Green)
On: The Internet port is connected.
Flashing: The Internet port is transmitting data.
18
DC Connector Connect the included AC adapter here.
WZR-HP-G300NH User Manual 11
Chapter 1 Product Overview
Bottom
13
13
Reset Button To reset all settings, hold down this button until the Diag LED comes on
(about 3 seconds). Power must be on.
Right Side
14
14
Factory Default Settings This sticker shows the AirStation’s SSID, default encryption
key, and WPS PIN code. Encryption key is blank if encryption is
disabled in default settings.
Note: The right side of the unit may become
hot. Please be careful not to place
anything next to it that could be
damaged by heat.
WZR-HP-G300NH User Manual 12
Chapter 2 Placing Your AirStation
Vertical Placement
If the AirStation is to be placed vertically, attach the stand as shown.
AOS S
ON
OFF
MOVIE
ENGINE
1
2
Horizontal Placement
The stand is not used if the AirStation is placed horizontally.
stand
WZR-HP-G300NH User Manual 13
Chapter 2 Placing Your AirStation
Wall-Mounting
1
2
FRONT
8.6 cm
(~3.4 inches)
Snap the center of the AirStation to the stand as shown.
To wall-mount the AirStation, attach
the stand to the wall with the two
screws (included).
FRONT
stand
WZR-HP-G300NH User Manual 14
Chapter 3 Installation
USB
EJECT
ON
OFF
AUTO
ROUTER
CD Setup
The AirNavigator CD can step you through installing your AirStation. To step through the setup
program, insert the CD into your Windows 7/Vista/XP PC and follow the instructions on the screen.
If your computer uses a dierent operating system, use manual setup instead.
Manual Setup
To congure your AirStation manually, follow the procedure below.
1
2
3
4
Turn o your computer and modem.
2) disconnect
2) disconnect 1) turn o the computer
OFF
computer
modem
Unplug the LAN cable which connects
your computer and modem.
Make sure the mode switch on the back of
the AirStation is in the [AUTO] position.
Conrm that the
switch is positioned to
[AUTO].
Plug one end of the LAN cable into your modem and the other side to the Internet port of the
AirStation. Turn on your modem.
modem
LAN cable
1) connect
2) connect
ROUTER
ON
OFF
AUTO
USB
EJECT
USB
LAN
1
2
3
INTERNET port
4
INTERNET
POWER
Wireless Router
WZR-HP-G300NH User Manual 15
Chapter 3 Installation
5
6
Connect your computer to one of the AirStation’s LAN ports with the LAN cable.
Wireless Router
ROUTER
ON
OFF
AUTO
USB
EJECT
USB
LAN
1
2
3
1) connect
4
INTERNET
POWER
2) connect
LAN cable
OFF
computer
Turn on the AirStation, wait one minute, and then turn on your computer.
Wireless Router
(rear side)
ROUTER
ON
OFF
AUTO
USB
EJECT
USB
LAN
1
2
3
4
INTERNET
POWER
7
8
power outlet
1) Connect the power supply
Once your computer has booted, the AirStation’s LEDs should be lit as described below:
POWER Green light on.
WIRELESS Green light on or blinking.
ROUTER Green light on or o depending on your network.
DIAG O
LAN Green light on or blinking.
INTERNET Green light on or blinking.
For LED locations, refer to chapter 1.
Launch a web browser. If the [home] setup screen is displayed, setup is complete.
If a user name and password screen is displayed, enter [root] (in lower case) for the user
name, leave the password blank, and click [OK]. Step through the wizard to complete setup.
You’ve completed initial setup of your AirStation. Refer to Chapter 4 for advanced settings.
WZR-HP-G300NH User Manual 16
Chapter 3 Installation
Firmware Differences
You can choose between two dierent rmwares for your AirStation. By default, the Professional
rmware (DD-WRT) is installed. If you prefer, you may install the User-friendly rmware instead. the
two rmwares have slightly dierent features, as shown in the chart below.
Function Professional rmware (DD-WRT) User-friendly rmware
Router switch function
Default administrator name root root (xed)
Default administrator password admin none
AOSS
WPS
WDS
─
a a
─
a a
a
a
Changing Firmware
To change between the Professional rmware (DD-WRT) and the User-friendly rmware, follow the
steps below.
1
Insert the AirNavigator CD into your computer. The setup wizard will automatically launch.
Note: If the Setup Wizard does not launch, open the CD and double-click [ASSetWiz.exe] to launch manually.
2
Click [Change Firmware].
WZR-HP-G300NH User Manual 17
Chapter 3 Installation
3
4
The procedure for wiring will be displayed.
Step through the wizard to connect your
AirStation.
When this screen is displayed, click
[Change Firmware].
5
If requested, enter the AirStation’s username
and password.
Note: By default, the Professional rmware doesn’t have
a username and a password congured. Set them
before you go to the next step.
WZR-HP-G300NH User Manual 18
Chapter 3 Installation
6
When the following screen is displayed, make sure that the rmware le name is displayed,
click [Update] or [Update Firmware], and follow the instructions on the screen.
Note: If the rmware name is not displayed on the screen, click [Browse...] and select the desired rmware.
Firmware les are in the root directory on the AirNavigator CD.
Professional rmware (DD-WRT) update screen:
User-friendly rmware update screen:
About this User Manual
This user manual is primarily for AirStations with the User-friendly rmware. For more information
on the Professional rmware (DD-WRT), refer to the WZR-HP-G300NH Professional Firmware user
manual or to www.dd-wrt.com/wiki.
WZR-HP-G300NH User Manual 19
Chapter 4 Conguration
The web-based conguration tool lets you change advanced settings for the AirStation. Don’t
change these settings unless you know what you’re doing.
How to Access the Web-Based Conguration Utility
To congure the AirStation’s advanced settings manually, log in to the web-based conguration
utility as shown below.
1
2
3
Launch a web browser.
Enter the AirStation’s LAN-side IP address in the
address eld, and press the [Enter] key.
Note: · The AirStation’s default LAN-side IP address depends on the position of the mode switch.
In router mode: 192.168.11.1
In bridge mode: 192.168.11.100
Note: If the router switch is set to [AUTO] and the unit is in bridge mode, then the AirStation’s IP
address was assigned by an external DHCP server.
· If you changed the IP address of the AirStation, then use the new IP address.
When this screen appears, enter [root]
(in lower case) for the user name and the
password that you set during initial setup.
Click [OK].
Note: · By default, the password is blank (not set).
· If you forget your password, hold down
the Reset button (page 12) to initialize all
settings. The password will then be blank.
Note that all other settings will also revert to
their default values.
WZR-HP-G300NH User Manual 20
Chapter 4 Conguration
4
This is the conguration utility,
where most AirStation settings
can be congured.
Help is always displayed on
the right side of each screen.
Refer to the Help screens for
more information on using the
conguration utility.
Note : This example, like others in this manual, shows the User-friendly rmware. The dd-wrt based
Professional rmware is somewhat dierent. For more information on the Professional
rmware, visit dd-wrt’s website at www.dd-wrt.com.
WZR-HP-G300NH User Manual 21
Chapter 4 Conguration
Conguration Utility Menus in Router Mode
The menu structure for the AirStation in router mode is as follows. Please refer to the pages listed at
right for explanations of each item.
Main screen Descriptions Page
Internet/LAN
Internet Congure Internet side port and settings. Page 28
PPPoE PPPoE settings (DSL login). Page 29
DDNS DNS settings. Page 32
VPN Server VPN server settings. Page 33
LAN LAN side port conguration. Page 36
DHCP Lease DHCP lease settings. Page 38
NAT Network address translation settings, used to connect LAN side devices
to the Internet.
Route Congure the AirStation’s IP communication route. Page 40
Wireless Cong
WPS WPS settings and status. Page 41
AOSS AOSS (AirStation One-touch Secure System) settings and status. Page 42
Basic Congure basic wireless settings. Page 44
Advanced Congure advanced wireless settings. Page 48
WMM Set priorities for Wireless Multimedia Extensions (Wi-Fi Multimedia). Page 49
MAC Filter Limit access to specic devices. Page 51
Multicast Control Congure limits on sending unnecessary multicast packets to the
wireless LAN port.
WDS Congure communication among AirStation Page 53
Security
Firewall Protect your computer from outside intruders. Page 55
IP Filter IP lters for packets passing through the LAN side and the Internet side. Page 57
VPN
Passthrough
Congure IPv6 passthrough, PPPoE passthrough, and PPTP passthrough. Page 58
Page 39
Page 52
LAN Cong
Port Forwarding Congure port translation and exceptions for games and other
programs.
WZR-HP-G300NH User Manual 22
Page 59
Chapter 4 Conguration
DMZ Congure a destination to transfer communication packets without a
Page 61
LAN side destination.
UPnP Congure UPnP (Universal Plug and Play). Page 62
QoS Congure priority for packets that require a guaranteed data ow. Page 63
Movie Engine Congure options for the Movie Engine feature. Page 62
NAS
Disk Management View the status and congure of attached USB disks. Page 67
Shared Folder Set the USB disk to use as shared folders. Page 69
User Management Congure users to access shared folders. Page 71
Shared Service Congure shared folder access. Page 72
Web Access Congure Web Access. Page 71
Media Server Congure a Media Server. Page 76
BitTorrent Congure a BitTorrent client. Page 77
Admin Cong
Name Congure the AirStation’s name. Page 79
Password Congure the AirStation’s login password for access to the conguration
Page 80
utility.
Time/Date Congure the AirStation’s internal clock. Page 81
NTP Congure the AirStation to synchronize with an NTP server to
Page 82
automatically set the AirStation’s internal clock.
ECO Congure the AirStation’s ECO Mode. Page 83
Access Congure access restrictions to the AirStation’s conguration screens. Page 85
Log Congure a syslog server to manage the AirStation’s logs. Page 88
Save/Restore Save or restore the AirStation’s conguration from a conguration le. Page 87
Initialize/Restart Initialize the AirStation or reboot it. Page 88
Update Update the AirStation’s rmware. Page 89
Diagnostic
System Info View current system information for the AirStation. Page 90
Logs Check the AirStation’s logs. Page 92
Packet Info View all packets transferred by the AirStation. Page 93
Client Monitor View all devices currently connected to the AirStation. Page 94
Ping Test the AirStation’s connection to other devices on the network. Page 95
Logout
Click this to log out of the AirStation’s conguration screens.
WZR-HP-G300NH User Manual 23
Chapter 4 Conguration
Conguration Utility Menus in Bridge Mode
The menu structure in bridge mode is as follows. Please refer to the pages listed at right for
explanations of each item.
Main screen Descriptions Page
LAN Cong
LAN Congure LAN side ports and devices. Page 36
Route Congure the AirStation’s IP communication route. Page 40
Wireless Cong
WPS WPS settings and status. Page 41
AOSS AOSS (AirStation One-touch Secure System) settings and status. Page 42
Basic Congure basic wireless settings. Page 44
Advanced Congure advanced wireless settings. Page 48
WMM Set priorities for Wireless Multimedia Extensions (Wi-Fi Multimedia). Page 49
MAC Filter Limit access to specic devices. Page 51
Multicast Control Congure limits on sending unnecessary multicast packets to the
wireless LAN port.
WDS Congure communication among AirStation Page 53
QoS
Movie Engine Congure options for the Movie Engine feature. Page 65
NAS
Disk Management View the status and congure of attached USB disks. Page 67
Shared Folder Set the USB disk to use as shared folders. Page 69
User Management Congure the name to access shared folders. Page 71
Shared Service Congure the name to access shared folders. Page 72
Web Access Set to use the Web Access function. Page 74
Media Server Set to use the Media Server function. Page 76
BitTorrent Set to use the BitTorrent function. Page 77
Admin Cong
Name Congure the AirStation’s name. Page 79
Page 52
Password Congure the AirStation’s login password for access to conguration
screens.
Time/Date Congure the AirStation’s internal clock. Page 81
WZR-HP-G300NH User Manual 24
Page 80
Chapter 4 Conguration
NTP Congure the AirStation to synchronize with an NTP server to
Page 82
automatically set the AirStation’s internal clock.
ECO Congure the AirStation’s ECO Mode. Page 83
Access Congure access restrictions to the AirStation’s conguration screens. Page 85
Log Check the AirStation’s logs. Page 86
Save/Restore Save or restore the AirStation’s conguration from a conguration le. Page 87
Initialize/Restart Initialize the AirStation or reboot it. Page 88
Update Update the AirStation’s rmware. Page 89
Diagnostic
System Info View current system information for the AirStation. Page 90
Logs Check the AirStation’s logs. Page 92
Packet Info View all packets transferred by the AirStation. Page 93
Client Monitor View all devices currently connected to the AirStation. Page 94
Ping Test the AirStation’s connection to other devices on the network. Page 95
Logout
Click this to log out of the AirStation’s conguration screens.
WZR-HP-G300NH User Manual 25
Chapter 4 Conguration
Setup
Setup is the home page of the conguration utility. You can verify settings and the status of the
AirStation here.
Parameter Meaning
Internet/LAN (LAN Cong) Displays the conguration screen for the Internet port and LAN
ports.
Wireless Cong Click this button to display the conguration screen for wireless
settings.
Security Click this button to display the conguration screen for security.
LAN Cong Click this button to display the conguration screen to open ports
for games and applications.
WZR-HP-G300NH User Manual 26
Chapter 4 Conguration
Parameter Meaning
NAS Click this button to display the conguration screen for NAS
settings.
Admin Cong Click this button to display the conguration screen for
administration settings.
Diagnostic Click this button to display the status of the AirStation.
Easy Setup Enables you to easily congure the AirStation’s network settings
automatically.
Internet Information Displays WAN-side system information for the AirStation.
Check Connection Click this button to check if the AirStation is connected to the
Internet properly.
Refresh Click this button to refresh the current screen.
WIRELESS Displays the current wireless settings.
AOSS Setup Click this button to display the AOSS conguration screen.
WPS Setup Click this button to display the WPS conguration screen.
Network Service List Displays the list of the network devices for which information is
provided from the network on the LAN-side.
Media Server Displays the status of the media server.
Download List Displays the list of BitTorrent les downloading.
Language Enables you to select the language you use.
Logout Log out from the conguration screen of the AirStation. If the
AirStation does not communicate for 5 minutes, it will log out
automatically.
WZR-HP-G300NH User Manual 27
Chapter 4 Conguration
Internet/LAN (LAN Cong)
Internet (Router Mode only)
Congure a WAN-side port.
Parameter Meaning
Method of Acquiring IP Address Specify how the WAN-side IP address is obtained.
Default Gateway Congure an IP address for the default gateway.
Address of DNS Name Server Specify an IP address for the DNS server.
Internet MAC Address Congure the Internet side MAC address.
Note: Conguring an improper MAC address may make the AirStation
unusable. Change this setting at your own risk.
MTU size of Internet Port Congure the MTU value of the Internet port. Values of 578 to 1500
bytes may be entered.
WZR-HP-G300NH User Manual 28
Chapter 4 Conguration
PPPoE (Router Mode only)
Congure PPPoE settings.
Parameter Meaning
Default PPPoE Connection If you have registered multiple connection destinations in the
PPPoE Connection List, connection destinations selected here
have priority. You need to congure the route to which PPPoE is
connected to if you don’t use the default settings.
IP Unnumbered PPPoE Connection Select the destination from the PPPoE Connection List which is
used when specifying [Use IP Unnumbered] in Method of Acquiring
IP Address (page 28).
PPPoE Connection List Edit PPPoE destination. You can register up to 5 sessions.
[Edit Connection List] Click this button to display the screen to edit the settings of
destination.
WZR-HP-G300NH User Manual 29
Chapter 4 Conguration
Parameter Meaning
PPPoE Connection No.*-Add This is displayed when [Edit Connection List] is clicked.
Name of Connection
Enter the name to identify the connected destination. You may
enter up to 32 alphanumerical characters and symbols.
User Name
Enter the user name specied by your ISP for PPPoE certication.
You may enter up to 32 alphanumerical characters and symbols.
Password
Enter the password specied by your ISP for PPPoE certication.
You may enter up to 32 alphanumerical characters and symbols.
Service Name
Fill in this eld only if your ISP species a Service Name. Leave
blank otherwise. You may enter up to 32 alphanumerical
characters and symbols.
Connection Type
Species the timing for the AirStation to connect to your
provider.
Automatic disconnection
Set time to disconnect after communication is stopped when the
connection method is set to [Connect on Demand] or [Manual].
You can enter up to 1440 minutes.
Authorization
Congure an authorization method with a provider.
MTU Size
Congure the MTU value for PPPoE. Values of 578 to 1500 bytes
may be entered..
MRU Size
Congure MRU (Maximum Receive Unit) for PPPoE. Values of 578
to 1492 may be entered.
WZR-HP-G300NH User Manual 30
Chapter 4 Conguration
Parameter Meaning
PPPoE Connection No. *-Add Keep Alive
If Keep Alive is enabled, then the AirStation will issue an LCP
echo request once a minute in order to maintain the connection
with the PPPoE. If the server does not respond for more than
6 minutes, the line is recognized as disconnected and the
AirStation will terminate the connection. [Disabled] is the
recommended setting.
Preferred Connections Displays information you have set regarding to the connection
destination route.
[Edit Preferred Connections] Click to edit the connection destination route settings.
Preferred PPPoE Connection -Add Click [Edit Preferred Connections] to display.
Name
The destination to connect by PPPoE if [Destination address] and
[Source address] match. Select the destination registered to the
PPPoE Connection List.
Destination address
When communicating to this address, the AirStation will
communicate with [Name of Connection].
Source address
When communicating from this address, the AirStation will
communicate with [Name of Connection].
WZR-HP-G300NH User Manual 31
Chapter 4 Conguration
DDNS (Router Mode only)
Congure Dynamic DNS settings. Many settings are only available when the appropriate Dynamic
DNS service is enabled.
Parameter Meaning
Dynamic DNS Service Select a provider (DynDNS or TZO) for Dynamic DNS.
User Name Enter the Dynamic DNS user name. You may enter up to 64
alphanumerical characters and symbols.
Password Enter the Dynamic DNS password. You may enter up to 64
alphanumerical characters and symbols.
Host Name Enter the Dynamic DNS host name. You may enter up to 255
alphanumerical characters, hyphens, and periods.
Email Address Enter the email address which is registered to the Dynamic DNS
service. You may enter up to 64 alphanumerical characters and
symbols.
TZO Key Enter the TZO Key which is registered to the Dynamic DNS service.
You may enter up to 64 alphanumerical characters and symbols.
Domain Name Enter the domain name which is registered to the Dynamic DNS
service. You may enter up to 255 alphanumerical characters,
hyphens, and periods.
WZR-HP-G300NH User Manual 32
Chapter 4 Conguration
Parameter Meaning
IP Address Update Period Species the period to notify the dynamic DNS service provider of
the current IP address. For DynDNS, set it between 0 and 35 days.
For TZO, set it between 0 and 99 days. If 0 (zero) days is set, no
periodic update is performed.
Internet Side IP Address The WAN-side IP address of the AirStation’s Internet port. This
address is sent to the dynamic DNS service provider.
Domain Name The domain name assigned by the dynamic DNS Service provider.
The AirStation can be accessed from the Internet using this domain
name.
Status Display the status of dynamic DNS service.
WZR-HP-G300NH User Manual 33
Chapter 4 Conguration
VPN server (Router Mode Only)
Congure the VPN server.
WZR-HP-G300NH User Manual 34
Chapter 4 Conguration
Parameter Meaning
Auto Input Click to generate a random IP address.
LAN Side IP Address
DHCP Server
Set a LAN side IP address and subnet mask.
Enable or disable the DHCP server, which assigns IP addresses
automatically.
DHCP IP Address Pool
Congure the range of IP addresses to be assigned by the DHCP
server and IP addresses to be excluded from that range. Values
from 0-253 may be entered.
PPTP Server
Authorization Type
Enable to use a PPTP server.
Select the authentication method for PPTP connection.
Server IP Address Select the server IP address.
Client IP Address Select the IP address range.
DNS Server IP Address Set the DNS server IP address for the DHCP server to issue to
clients.
WINS Server IP Address Set the WINS server IP address for the DHCP server to issue to
clients.
[Edit User Information] Click to edit user information.
User Name Enter the user name to connect to the PPTP server. You may enter
up to 16 alphanumerical characters and symbols.
Password Enter the password to connect to the PPTP server. You may enter
up to 16 alphanumerical characters and symbols.
Method of Acquiring IP Address Select the method to be used to assign the IP address is assigned to
the PPTP client.
PPTP User List Displays the PPTP connection user information.
WZR-HP-G300NH User Manual 35
Chapter 4 Conguration
LAN
Congure LAN-side settings.
Parameter Meaning
LAN Side IP Address By default, the LAN side IP address is 192.168.11.1 with subnet
mask 255.255.255.0. You may change it here.
DHCP Server Function Enable or disable the DHCP server, which assigns LAN-side IP
addresses automatically.
DHCP IP Address Pool Congure the range of IP addresses to be assigned by the DHCP
server and IP addresses to be excluded from that range. Values
from 0 - 253 may be entered.
LAN Side IP Address
(For IP Unnumbered)
Advanced Settings Check [Display] to display DHCP server advanced settings options.
Lease Period Set the eective period of an IP address assigned by the DHCP
Set an IP unnumbered LAN side IP address.
Note: A PC with a normal LAN side IP address and a PC with an IP
Unnumbered IP address cannot communicate each other.
server. Up to 999 hours may be entered.
Default Gateway Set the default gateway IP address for the DHCP server to issue to
clients.
WZR-HP-G300NH User Manual 36
Chapter 4 Conguration
Parameter Meaning
DNS Servers
* Router Mode only
WINS Server
* Router Mode only
Domain Name
* Router Mode only
Default Gateway
* Bridge Mode only
DNS Server Address
* Bridge Mode only
Set the DNS server IP address for the DHCP server to issue to
clients.
Set the WINS server IP address for the DHCP server to issue to
clients.
Set the domain name for the DHCP server to issue to clients. You
may enter up to 127 alphanumerical characters, hyphens, and
periods.
Set the default gateway IP address.
Set the DNS server IP address.
WZR-HP-G300NH User Manual 37
Chapter 4 Conguration
DHCP Lease (Router Mode only)
Congure DHCP Exceptions.
Parameter Meaning
IP Address Enter an IP address to lease manually. The IP address should be
from the same subnet as the DHCP scope, but not be within the
range that DHCP is assigning to other devices.
MAC Address Enter the MAC address which identies the client.
Current DHCP Client Information Displays information for current leases. An IP address which is
leased automatically can be changed to be leased manually by
clicking [Manual Assignment].
WZR-HP-G300NH User Manual 38
Chapter 4 Conguration
NAT (Router Mode only)
Congure network address translation settings. This enables LAN-side devices to communicate with
the Internet.
Parameter Meaning
Address Translation Enable to use Network Address Translation.
Log Output of Deleted Packets Enable to log deleted packets (such as errors) during address
translation.
WZR-HP-G300NH User Manual 39
Chapter 4 Conguration
Route
Congure the AirStation’s IP communication route.
Parameter Meaning
Destination Address Adds a destination IP address and subnet mask to a routing table.
Gateway Adds a gateway address to a routing table.
Metric The metric is the maximum number of router hops a packet may
take on the way to its destination address. Values between 1 and 15
may be entered. The default value is 15.
Routing Information Manual entries will appear here after being added.
WZR-HP-G300NH User Manual 40
Chapter 4 Conguration
Wireless Cong
WPS
WPS Status and Settings.
Parameter Meaning
WPS Enable to use WPS automatic conguration.
External Registrar Enable to accept the external congure requests from other WPS
devices.
Note: External congure requests will not be accepted if AOSS is in use.
AirStation PIN Displays the PIN code of the AirStation. Clicking [Generate PIN]
will generate a new PIN code. This code can be entered into other
wireless devices that support WPS.
Enrollee PIN Enter the PIN code for the other wireless device and click [OK].
WPS status Displays [congured] if all available wireless bands are
congured. Displays [uncongured]if at least one wireless band is
uncongured.
WZR-HP-G300NH User Manual 41
Chapter 4 Conguration
AOSS
AOSS Status and Settings.
WZR-HP-G300NH User Manual 42
Chapter 4 Conguration
Parameter Meaning
Initiates AOSS automatic wireless conguration. Click this, then
press or click the AOSS button on your AOSS-compatible wireless
client. Repeat for additional AOSS clients.
Click this button to disconnect AOSS connections.
Note: If AOSS connections are disconnected, the SSID and encryption keys
will be restored to their most recent settings before using AOSS.
Encryption Type of Exclusive SSID for
WEP
You may allow a separate SSID specically for WEP connections. If
[disabled] is selected, then clients will not be able to connect with
WEP.
Encryption level expansion function Expands security method from TKIP to WPA/WPA2-PSK-mixed
mode.
Dedicated WEP SSID isolation Set a separate SSID and network segment specically for WEP
connections. Devices connected with WEP will not be able
to communicate with devices connected using AES/TKIP. All
connected devices will be able to communicate with the internet.
Dedicated WEP for game consoles When enabled, the AirStation allows wireless devices to connect
with 64 or 128 bit WEP.
AOSS Button on the AirStation Unit Uncheck to disable the physical AOSS button on the AirStation.
Current Encryption Information
* AOSS Connection only
Displays the encryption type, SSID, an encryption key congured
by AOSS.
[Random] Click to enter random values for SSID, encryption key, and other
settings.
[KEY base] Click to return the SSID, encryption key, and other wirelesss settings
to the values on the case sticker.
[Reset] Click to return the SSID, encryption key, and other wireless settings
to their previous values.
AOSS Client Information
* Displays AOSS clients connected to the AirStation and information
of the devices which are wirelessly communicated.
AOSS Ethernet Converter
Information
* Only displayed if there are AOSS
Connections
WZR-HP-G300NH User Manual 43
*
Displays information about ethernet converters connected to the
AirStation via AOSS.
Chapter 4 Conguration
Basic
The screen to congure a basic wireless settings.
Parameter Meaning
Wireless Radio Determines whether to allow wireless communication. If this is
unchecked, then no wireless connections will be allowed.
Wireless Channel Sets a channel (a range of frequencies) used for wireless
connections. With Auto Channel selected, the AirStation will
automatically use the best available channel.
300Mbps Mode 300 Mbps mode uses twice the normal frequency range, 40
MHz instead of 20 MHz. In uncongested areas this can increase
performance. To use 300 Mbps mode, set the Bandwidth to 40 MHz
and choose an Extension Channel.
Note: If using Auto Channel for the wireless channel, then the Extension
Channel is set automatically.
WZR-HP-G300NH User Manual 44
Chapter 4 Conguration
Parameter Meaning
Broadcast SSID If [Allow] is checked, then the AirStation will respond to SSID
searches from wireless devices by broadcasting its SSID. If [Allow] is
unchecked, then the AirStation ignores SSID searches from wireless
devices.
[Use Multi Security function]
[Do not use Multi Security function]
Clicking [Use Multi Security function] will enable Multi Security,
allowing the use of multiple SSIDs, each with dierent wireless
security settings. Clicking [Do not use Multi Security function] will
disable the Multi Security function. The AirStation will then allow
one SSID and one type of wireless security.
Note: When using Multi Security, you need to enable at least one of the
following: SSID1, SSID2, or SSID3.
SSID1 Multi Security SSID1 can use WPA-PSK-TKIP or WPA/WPA2-Mixed for
wireless security.
SSID2 Multi Security SSID2 can use WPA-PSK-AES for wireless security.
SSID3 Multi Security SSID3 can use WEP for wireless security.
Separate feature When [Separate] is enabled, wireless devices connected to the
AirStation can communicate only with the Internet side, not with
each other.
SSID Set SSID using 1 - 32 alphanumeric characters.
Wireless authentication Species an authentication method used when connecting to a
wireless device.
WZR-HP-G300NH User Manual 45
Chapter 4 Conguration
Parameter Meaning
Wireless encryption You may use any of the following types of encryption:
No encryption
Data is transmitted without encryption. Avoid this option since
any communication may be intercepted.
[No encryption] can be selected only when [No authentication] is
selected for Wireless authentication.
WEP
WEP is a common encryption method supported by most
devices. Use an encryption key to communicate with a wireless
device.
WEP can only be selected when [No authentication] is selected
for Wireless authentication.
TKIP
TKIP is an encryption method which is more secure than WEP, but
slower. Use an pre-shared-key to communicate with a wireless
device.
TKIP can be selected only when WPA-PSK or WPA2-PSK is selected
for Wireless authentication.
AES
AES is more secure than TKIP, and faster. Use a pre-shared-key to
communicate with a wireless device.
AES can be selected only when WPA-PSK or WPA2-PSK is selected
for Wireless authentication.
TKIP/AES mixed mode
TKIP/AES mixed mode allows both TKIP and AES authentication
and communication.
TKIP/AES mixed mode can be selected only when WPA/WPA2
mixed mode - PSK is selected for Wireless authentication.
WPA-PSK (Pre-Shared Key) A pre-shared key or passphrase is the [password] for your wireless
connections. There are two dierent formats for a pre-shared
Use 8 to 63 alphanumeric characters (case-sensitive) for an ASCII
key.
passphrase, or use 64 digits using 0 to 9 and a to f (not case-sensitive) for a
hexadecimal passphrase..
Rekey interval Set the update interval for the encryption key between 0 and 1440
(minutes).
WZR-HP-G300NH User Manual 46
Chapter 4 Conguration
Parameter Meaning
Set up WEP encryption key A WEP encryption key (passphrase) may have any of four dierent
formats. An
characters (case-sensitive). A hexadecimal passphrase may use either 10
or 26 digits using 0 to 9 and a to f (not case-sensitive).
ASCII passphrase may use either 5 or 13 alphanumeric
WZR-HP-G300NH User Manual 47
Chapter 4 Conguration
Advanced
Congure advanced wireless settings.
Parameter Meaning
Multicast Rate Set the communication speed for multi-cast packets.
DTIM Period Set the beacon responding interval (1 -255) for which the AirStation
responds to a wireless device. This setting is eective only when
power management is enabled for the wireless device.
Privacy Separator If enabled, the Privacy Separator blocks communication between
wireless devices connected to the AirStation. Wireless devices will
be able to connect to the Internet but not with each other. Devices
that are connected to the AirStation with wired connections will
still be able to connect to wireless devices normally.
WZR-HP-G300NH User Manual 48
Chapter 4 Conguration
WMM
Set priorities for specic communications.
WZR-HP-G300NH User Manual 49
Chapter 4 Conguration
Parameter Meaning
WMM-EDCA Parameters You don't usually need to change these settings. Using the default
settings is recommended.
Priority
The following priorities may be applied to individual
transmission packets: (Highest) 8, (High) 4, (Normal) 2, and
(Low) 1. From the queue, these packets are processed in order of
priority.
CWmin, CWmax
The maximum and minimum value of the contention window.
The contention window is used in the frame collision avoidance
structure performed in IEEE802.11, and generally, the smaller the
value in the window, the higher the probability that the queue
obtains the right to send.
AIFSN
The interval to send frames. The unit of the AIFSN is a slot, just as
the window dened by CWmin and CWmax is. The smaller the
interval of sending frames, the faster the algorithm can restart.
As a result, the priority of the queue is higher.
TXOP Limit
The period of time that the queue can use after obtaining the
right to send. The unit is 32 ms. The longer this time, the more
frames can be sent per right to send. However, the queue may
interfere with other packet transmissions. If TXOP Limit is set to 0
(zero), only one frame can be sent per right to send.
Admission Control
Restricts new frames from interfering with a previous queue. New
packets are prioritized lower until a queue of them is collected. As
the new queue accumulates more packets, its priority increases.
WZR-HP-G300NH User Manual 50
Chapter 4 Conguration
MAC Filter
Restrict access to specic wireless devices.
Parameter Meaning
Enforce MAC Filtering Enable to restrict wireless connections to devices with registered
MAC addresses.
Registration List Displays the MAC addresses of registered devices which are
permitted to connect wirelessly.
[Edit Registration List] Click to add a wireless device to the list of permitted devices.
MAC Addresses to be Registered Enter a MAC address of a wireless device to permit to connect to
the AirStation. Click [Register] to add that MAC address to the list.
List of all clients that are associated
with this AirStation
Display the list of all MAC addresses of wireless devices connected
to the AirStation.
WZR-HP-G300NH User Manual 51
Chapter 4 Conguration
Multicast Control
Congure restrictions on unnecessary multicast packets sent to the wireless LAN port.
Parameter Meaning
Snooping If enabled, snooping supervises multicast administrative packets
such as IGMP and restricts unnecessary multicast transfers to wired
or wireless ports.
Multicast Aging Time Set the time to hold the data from multicast snooping in the range
of 1 to 3600 (seconds). Enter a value bigger than the IGMP/MLD
query interval.
WZR-HP-G300NH User Manual 52
Chapter 4 Conguration
WDS
WDS bridging allows communication between AirStations.
Parameter Meaning
WDS Check to use WDS bridging.
Specify Master/Slave Dene this AirStation's role in a WDS bridge.
Master
This AirStation will the master in a WDS bridge. It will have the
Internet connection, and other AirStations in the bridge will be
connected through this AirStation.
Slave
Slave AirStations are connected to the master AirStation.
Auto
Automatically switches between Master and Slave modes
depending on the surrounding network.
If an AirStation works as a router, it will automatically be set as a
master.
If the Airstation works as a bridge and a DHCP server exists
in the network, it will automatically be set as a master . If the
AirStation works as a bridge and no DHCP server is available, it
will automatically be set as a slave.
WZR-HP-G300NH User Manual 53
Chapter 4 Conguration
Parameter Meaning
SSID Congure the Master Airstation's SSID.
［ Search ］
Click to search for other AirStations' SSIDs.
Wireless authentication Congure authentication method for the master AirStation
Encryption for wireless Choose encryption type for the master AirStation.
WPA-PSK (Pre Shared Key) Set the master AirStation's Encryption key.
Notes: A master AirStation can communicate with two slaves only.
A slave AirStation cannot communicate with any AirStation other than its master.
Master
Slave1
POWER
SECURITY
WEIRELESS
ROUTER
DIAG
Slave2
POWER
SECURITY
WEIRELESS
ROUTER
DIAG
POWER
SECURITY
WEIRELESS
ROUTER
DIAG
POWER
SECURITY
WEIRELESS
ROUTER
DIAG
POWER
SECURITY
WEIRELESS
ROUTER
DIAG
POWER
SECURITY
WEIRELESS
ROUTER
DIAG
WZR-HP-G300NH User Manual 54
Chapter 4 Conguration
Security (Router Mode only)
Firewall (Router Mode only)
Congure the AirStation’s rewall.
Parameter Meaning
Log Output Enable to output a log of rewall activity.
Basic Rules Enable to use any of the quick lters. Precongured quick lters
include:
Prohibit NBT and Microsoft-DS Routing
When this is enabled, you cannot use these protocols between
the LAN and WAN sides of the router. You can congure this with
PPPoE if you select [Use PPPoE Client] or [Use IP Unnumbered]
in Method of Acquiring IP address (on page 28), or if Easy Setup
identied a PPPoE connection during setup.
WZR-HP-G300NH User Manual 55
Chapter 4 Conguration
Parameter Meaning
Reject IDENT Requests
Enabling this option will answer IDENT requests from the Internet
side with corresponding rejection packets. Enable this option if
you experienced slow transfer speeds for network applications
such as sending mail, using ftp, or browsing. If you have
congured transfer of IDENT requests to the LAN side computer
in the address translation settings (DMZ or TCP port:113), then
that setting has higher priority, and overrides this setting.
Block Ping from Internet
If this is enabled, the AirStation will not respond to pings from
the Internet (WAN) side. You can congure this with PPPoE if you
select [Use PPPoE Client] or [Use IP Unnumbered] in Method of
Acquiring IP address (page 28), or if Easy Setup identied a PPPoE
connection during setup.
WZR-HP-G300NH User Manual 56
Chapter 4 Conguration
IP Filter (Router Mode only)
Edit IP lters.
Parameter Meaning
Log Output If enabled, IP lter activity is saved to a log.
Operation Specify how to process target packets.
Direction Specify the transmission direction of target packets.
IP Address Specify the sender's IP address and receiver's IP address of the
target packets.
Protocol Select a protocol for target transmission packet.
IP Filter Information Display the list of IP lters which have been registered.
WZR-HP-G300NH User Manual 57
Chapter 4 Conguration
VPN Pass Through (Router Mode only)
Congure IPv6 pass through, PPPoE pass through, and PPTP pass through.
Parameter Meaning
IPv6 Pass Through Enable to use IPv6 pass-through for address translation.
PPPoE Pass Through Enable to use PPPoE bridge. Using PPPoE bridge lets you
automatically obtain an IP address from your provider using the
PPPoE protocol from your computer connected to the LAN side
because all PPPoE packets can pass through between the Internet
and LAN.
PPTP Pass Through Enable to use PPTP pass-through for address translation.
WZR-HP-G300NH User Manual 58
Chapter 4 Conguration
LAN Cong (QoS)
Port Forwarding (Router Mode only)
Congure port translation.
Parameter Meaning
Group Specify a group name for a new rule to belong to. Select [New
Group] and enter the new group name in the Group Name
eld to create a new group. A group name can include up to 16
alphanumeric letters.
Internet Side IP Address Enter the Internet side IP address (before translation) for the port
translation table entry.
Protocol Select the Internet side protocol (before translation) for the port
translation table entry.
WZR-HP-G300NH User Manual 59
Chapter 4 Conguration
Parameter Meaning
LAN Side IP Address Enter the LAN side IP address (after translation) for the port
translation table entry.
LAN Side Port Select the LAN side (after translation) port number (1 - 65535) for
the port translation table entry.
Port Forwarding Registration
Information
Shows current entries in the port translation table.
WZR-HP-G300NH User Manual 60
Chapter 4 Conguration
DMZ (Router Mode only)
Congure a destination to transfer communication packets without a LAN side destination to.
Parameter Meaning
IP Address of DMZ Enter the IP address of the destination to which packets which are
not routed by a port translation table are forwarded.
Note: RIP protocol packets (UDP port number 520) will not be
forwarded.
WZR-HP-G300NH User Manual 61
Chapter 4 Conguration
UPnP (Router Mode only)
Congure UPnP (Universal Plug and Play).
Parameter Meaning
UPnP Enable or disable Universal Plug and Play (UPnP) functionality.
WZR-HP-G300NH User Manual 62
Chapter 4 Conguration
QoS (Router Mode only)
Congure the priority of packets sent to the Internet.
Parameter Meaning
QoS for transmission to the Internet Determine whether or not to prioritize packets sent to the Internet.
Check this box to enable QoS.
Upload bandwidth Specify the upstream bandwidth in kbps from the AirStation to the
internet side.
Enable Enable or disable this entry.
application name Enter an application name. Names may use up to 32 alphanumeric
characters, double or single tick marks ("'), quotation marks (“), and
semicolons (;).
protocol Select either TCP or UDP.
destination Port Specify a destination port with the value of 1 - 65535. If this eld is
empty, a random port is selected.
Set the actual value for the upstream bandwidth.
WZR-HP-G300NH User Manual 63
Chapter 4 Conguration
Parameter Meaning
priority Select high, medium or low. If packets do not qualify for classication
as a type on the list, then their priority is treated as a level between
medium and low.
WZR-HP-G300NH User Manual 64
Chapter 4 Conguration
Movie Engine
Congure Movie Engine options.
WZR-HP-G300NH User Manual 65
Chapter 4 Conguration
Parameter Meaning
Movie Engine switch status Display the status of the Movie Engine switch.
IPv6 Pass Through Set to enable the IPv6 Pass Through.
Multicast Rate Select the rate of the Multicast Control.
Multicast Control Set the Multicast Control setting to on.
TCP Rwin Size Limit Congure TCP packets Rwin size limitation to pass AirStation’s
wireless LAN.
Wireless Priority Control Rules Display the list of rules controls the priority pass through of packets
in the AirStation wireless LAN.
Transmission Rate Limit Select the transmission limit to prevent transmission rate fall down.
Number of Retries Select limit number of retries.
WZR-HP-G300NH User Manual 66
Chapter 4 Conguration
NAS
Disk management
View the status of and congure attached USB hard disks.
Parameter Meaning
Device Displays information for attached USB disks. Disks are removed
when [Remove] in the Device column is clicked.
Disk Assignment A disk number will be automatically assigned to the disk or you can
choose a number. Select a disk number, or select [Do not assign],
and then click [Apply] to assign a disk number.
Partition Information Displays the partition information for the selected USB disk. Click
[Format] to format the disk. Note: formatting a disk will erase all
information from it.
Re-recognize USB devices Click this to re-scan for connected USB disks.
WZR-HP-G300NH User Manual 67
Chapter 4 Conguration
Parameter Meaning
Automatic USB Disk Assignment Check [Use] to automatically select an attached USB hard disk. The
entire drive will be used as the shared folder. To congure your disk
and share manually, uncheck [Use].
[Use] is selected by default.
FAT format le name character code Select the le name character code used for FAT formatting.
HDD power-saving function Set the HDD power saving function.
HDD stop time Select a time duration after which to stop the HDD.
WZR-HP-G300NH User Manual 68
Chapter 4 Conguration
Shared Folder
Congure a USB hard disk for use with shared folders.
WZR-HP-G300NH User Manual 69
Chapter 4 Conguration
Parameter Meaning
Shared Folder Name* Enter a name for the shared folder. Up to 18 alphanumeric
characters, space, hyphens (-), and underscores (_) may be used.
Shared Folder Description* Enter a description of the shared folder (optional). Up to 75
alphanumeric characters, space, hyphens (-), and underscores (_)
may be used.
Disk Partition Area* Displays the partition area, format type, and the capacity of the USB
disk.
Disclosed to* Check the functionality that you want to support. Win/Mac OS
(Samba NAS), Web Access, Media Server, and/or BitTorrent may be
checked. Only one folder may be chosen for either Media Server or
BitTorrent functionality.
Access Limits If access limits are enabled, use the arrows to move highlighted
users between the columns for [Read/Write], [Read-only] or [No
access] privileges.
Web Access You may also select to enforce access limits on users accessing
through Web Access by checking the Access Limits checkbox.
Users will have the same access levels as assigned above. If Access
Limits is not checked, then all users accessing the shared folder via
Web Access will have [Read only] access..
Shared Folder Registration
Information*
* These parameters are displayed when [Automatic USB Disk Assignment] (page 68) is not set to [Use]:
Displays information about the shared folder.
The following settings are used for [Shared Folder] when [Disk Management] is activated.
• All folders: [Access Limits] settings in eect.
• Shared Folder/ Web Access: All folders are shared.
• Media Server/BitTorrent: The rst folder is shared.
WZR-HP-G300NH User Manual 70
Chapter 4 Conguration
User Management
This screen lets you add users to the access list with the ability to access shared folders.
Parameter Meaning
User Name Enter the name of a user to be given access to the shared folder.
Up to 20 alphanumeric characters, space, hyphens (-), and
underscores (_) may be used for each user. Up to 16 users may be
entered.
Password Enter the user’s password. Use of the same password that
they use to log into their computer is recommended. Up to 20
alphanumeric characters, space, hyphens (-), and underscores
(_) may be used. For Windows 98SE/98/95 users, up to 14
alphanumeric characters may be used. Mac OS users may use up
to 8 alphanumeric characters. If you enter a longer password than
your users can use, then they will not be able to access the share.
User Description Describe the user (optional). Up to 75 alphanumeric characters,
space, hyphens (-), and underscores (_) may be used.
Current Users Lists current users, including [guest]. [guest] is a built-in account
that cannot be changed or deleted.
WZR-HP-G300NH User Manual 71
Chapter 4 Conguration
Shared Service
Assign AirStation and workgroup names to access shared folders.
Parameter Meaning
Shared Folder Enable to make a USB disk available on your local network.
AirStation name Rename your AirStation if desired. Up to 15 alphanumeric
characters, space, and hyphens (-), may be used. The AirStation
name is also used as the host name that will be used with the
shared service. The shared service may not be available you use
over 15 alphanumeric characters in your AirStation’s name.
AirStation Description Describe the AirStation (optional). Up to 48 alphanumeric
characters, space, hyphens (-), and underscores (_) may be used.
Workgroup name Enter your workgroup name. Up to 15 alphanumeric characters,
space, hyphens (-), underscores (_) and period (.) may be used.
Windows Client Language Select the language to be used by the Windows client.
WZR-HP-G300NH User Manual 72
Chapter 4 Conguration
Parameter Meaning
Shared Service Displays the status of the USB disk that is to be used with the
shared service.
WZR-HP-G300NH User Manual 73
Chapter 4 Conguration
Web Access
The screen to set to use the Web Access function.
Parameter Meaning
Web Access Check [Enable] to use Web Access.
Web Access Display Language Set the language to be used with Web Access.
HTTPS/SSL Encryption Check [Enable] to use SSL encryption for protected data transfer.
Web Access External Port Automatically sets the external port used for Web access. To select
the port manually, select [Manual].
DNS Service Host Name Sets the DNS Service Host Name when the Web access function
is activated. Select [Use BualoNAS.com registration function]
to use the Web access function easily. You’ll have to congure
a [BualoNAS.com name] and [BualoNAS.com key] to use
BualoNAS.com. Up to 3-20 alphanumeric characters, space,
hyphens (-), underscores (_) and period (.), may be used in the
BualoNAS.com name. Up to 3-20 alphanumeric characters, space,
hyphens (-), underscores (_) and period (.), may be used in the
BualoNAS.com key.
Note: The registered name is deleted from the server if the AirStation is
disconnected from power, even for a moment.
WZR-HP-G300NH User Manual 74
Chapter 4 Conguration
Parameter Meaning
Web Access Displays the status of web access.
External Port Status Display the status of the external port.
BualoNAS.com Display the status of BualoNAS.com.
WZR-HP-G300NH User Manual 75
Chapter 4 Conguration
Media Server
Media Server settings.
Parameter Meaning
Media Server Enable to use the media server.
Status Displays the status of the media server.
WZR-HP-G300NH User Manual 76
Chapter 4 Conguration
BitTorrent
Congure the BitTorrent client.
Parameter Meaning
BitTorrent Function Enable to use the BitTorrent client. If the BitTorrent client is
enabled, overall communication performance may decrease
and the reactions to setting screens slow down. If that happens,
reformat the USB disk with XFS. This may reverse the performance
slowdown.
External Port Number Select the external port number.
WZR-HP-G300NH User Manual 77
Chapter 4 Conguration
Parameter Meaning
Bandwidth Restriction Set a bandwidth limit for BitTorrent.
[Download Manager] Displays the BitTorrent download manager screen. Add a torrent
and then click [Add] to download the le(s).
[Delete BitTorrent information] Deletes all les, including the torrent les and les which are
currently downloading. The downloaded le is not deleted.
BitTorrent Status Display the status of the BitTorrent client.
BitTorrent External Port Status Display the external port status of the BitTorrent client.
Access here to download the latest BitTorrent client for PC.
http://www.bittorrent.com/
WZR-HP-G300NH User Manual 78
Chapter 4 Conguration
Admin Cong
Name
Congure basic AirStation’s settings.
Parameter Meaning
AirStation Name Enter a name for the AirStation. Names may include up to 64
alphanumeric characters and hyphens (-).
List Network Services Enable or disable this item to display the computers and devices on
your network with their supported services.
WZR-HP-G300NH User Manual 79
Chapter 4 Conguration
Password
Congure the password to log in to the AirStation’s conguration screen.
Parameter Meaning
Administrator Name The Administrator name is used to log in to the AirStation’s
conguration utility. This name is xed as [root].
Administrator Password The password is required to log in. It may contain up to 8
alphanumeric characters and underscores (_).
WZR-HP-G300NH User Manual 80
Chapter 4 Conguration
Time/Date
Congure the AirStation’s internal clock.
Parameter Meaning
Local Date You may manually set the date of the AirStation’s internal clock.
Local Time You may manually set the time of the AirStation’s internal clock.
Time Zone Specify the time zone (oset of Greenwich Mean Time) of the
AirStation's internal clock.
DST(Daylight Saving Time) You may congure the AirStation to use DST(Daylight Saving Time).
Select appropriate time according to your local time, and it
changes time when DST starts it and also returns it automatically
when DST nishes .
WZR-HP-G300NH User Manual 81
Chapter 4 Conguration
NTP
Congure an NTP server to automatically synchronise the AirStation’s internal clock.
Parameter Meaning
NTP Functionality Enable to use an NTP server. The default is Enabled.
NTP Server Enter the name of the NTP server as a host name, host name with
domain name, or IP address. Up to 255 alphanumeric characters,
hyphens (-), and underscores (_) may be used. The default is [time.
nist.gov].
Update Interval How often will the AirStation check the NTP server for the correct
time? Intervals of 1 - 24 hours may be set. The default is 24 hours.
WZR-HP-G300NH User Manual 82
Chapter 4 Conguration
ECO
Congure Eco mode from this screen.
WZR-HP-G300NH User Manual 83
Chapter 4 Conguration
Parameter Meaning
Schedule feature Enable to schedule Eco mode.
Note: If Schedule is enabled, AOSS will only function while the
AirStation is in Normal Operating Mode.
Weekly schedule Graphically displays the congured schedule.
Register schedule Congure operational mode for time periods in the weekly
schedule. If User Dened mode is chosen, congure it below.
User Dene Mode Individual power saving elements may be congured individually
for User Dened mode.
WZR-HP-G300NH User Manual 84
Chapter 4 Conguration
Access
Restrict access to the AirStation’s settings screens.
Parameter Meaning
Log Output Enabling outputs a log of changes to access settings.
Prohibit conguration from wireless
LAN
Prohibit conguration from wired
LAN
Permit conguration from wired
Internet
Permitted IP address Displayed only if Internet side conguration is enabled. Enter the
Permitted Port Displayed only if Internet side conguration is enabled. Set a port
If enabled, prevents access to settings screens from wirelessly
connected devices (only wired devices may congure).
If enabled, prevents access to settings screens from wired devices
(only wirelessly connected devices may congure).
If enabled, allows access to settings screens from network devices
on the WAN (Internet) side.
IP address of a device that is permitted to congure the AirStation
remotely from the WAN (Internet) side.
number (1 - 65535) to congure the AirStation from the WAN
(Internet) side.
WZR-HP-G300NH User Manual 85
Chapter 4 Conguration
Log
Transfer the AirStation’s logs to a syslog server.
Parameter Meaning
Log Transfer Enable to send logs to a syslog server.
Syslog Server Identify the syslog server by host name, host name with domain
name, or IP address. You may enter up to 255 alphanumeric
characters, hyphens (-), and underscores (_).
Transfer Logs Choose which logs will be transferred to the syslog server.
WZR-HP-G300NH User Manual 86
Chapter 4 Conguration
Save/Restore
Save AirStation settings as a le, and restore from them later.
Parameter Meaning
Save current settings Clicking [Save] will save the current conguration of the AirStation
to a le. If the [Encrypt the conguration le with a password]
option is checked, then the conguration le will be password
protected with the current Administrator Password.
Restore Conguration from Backup
File
Restore the conguration of the AirStation from a saved
conguration le by clicking the [Browse...] button, navigating to
the conguration le, and then clicking Restore. If the conguration
le was password protected, then put a check next to [To restore
from the le you need the password], enter the password, and click
[Open].
WZR-HP-G300NH User Manual 87
Chapter 4 Conguration
Initialize/Restart
Initialize or restart the AirStation.
Parameter Meaning
Restart Click [Restart Now] to restart the AirStation.
Initialize Click [Initialize Now] to initialize and restart the AirStation.
WZR-HP-G300NH User Manual 88
Chapter 4 Conguration
Update
Update the AirStation’s rmware.
Parameter Meaning
Firmware Version Displays the current rmware version of the AirStation.
Update method Specify Local File
Updates the rmware stored on your computer.
Automatic Update (On Line Version Up)
Automatically updates the latest rmware that is available online.
Firmware File Name Click [Browse...] to specify a rmware le and click [Update
Firmware.] You don’t need to specify the rmare lodcation if
selecting [Automatic Update].
WZR-HP-G300NH User Manual 89
Chapter 4 Conguration
Diagnostic
System Info
View system information for the AirStation.
WZR-HP-G300NH User Manual 90
Chapter 4 Conguration
Parameter Meaning
Model Displays the product name of the AirStation and the rmware
version.
AirStation Name Displays the AirStation Name.
Mode Switch Status Displays the status of the mode switch on the back of the
AirStation.
Operational Mode Displays the current operational mode of the AirStation.
Movie Engine Status Displays the current Movie Engine Status.
Internet Displays the information about the Internet port.
LAN Displays the information about the LAN port.
Wireless Displays the wireless status.
NAS Displays the information about USB disk.
WZR-HP-G300NH User Manual 91
Chapter 4 Conguration
Logs
The AirStation’s logs are recorded here.
Parameter Meaning
Display log info Choose the types of logs to display.
Logs Displays the log information recorded in the AirStation.
WZR-HP-G300NH User Manual 92
Chapter 4 Conguration
Packet Info
Viewpacket transfer information.
Parameter Meaning
Sent Displays the number of packets sent to the Internet side of
Ethernet, the LAN side of the Ethernet, and the LAN side of the
wireless connection.
Received Displays the number of packets received from the Internet side
of Ethernet, the LAN side of the Ethernet, and the LAN side of the
wireless connection.
WZR-HP-G300NH User Manual 93
Chapter 4 Conguration
Client Monitor
This screen shows devices that are connected to the AirStation.
Parameter Meaning
Client Monitor Displays information ( MAC address, lease IP address, host name,
communication method, wireless authentication and 802.11n) for
devices that are connected to the AirStation.
WZR-HP-G300NH User Manual 94
Chapter 4 Conguration
Ping
A Ping test checks whether the AirStation can communicate with a specic network device.
Parameter Meaning
Destination Address Enter an IP address or a host name of the device for which you
try to verify the connection, and click [Execute]. The result will be
displayed in the [Result] eld.
Note : Examples in this manual show the [User-friendly] rmware. The dd-wrt based Professional
rmware is somewhat dierent. For more information on the Professional rmware, visit ddwrt’s website at www.dd-wrt.com.
WZR-HP-G300NH User Manual 95
Chapter 5 Connect to a Wireless Network
Automatic Secure Setup (AOSS/WPS)
AOSS and WPS are systems which enable you to automatically congure wireless LAN settings. Just
pressing the buttons will connect wireless devices and complete security settings. Easily connect to
any wireless devices, computers, or game machines which support AOSS or WPS.
AOSS (AirStation One-Touch Secure System) was developed by Bualo Technology. WPS
was created by the Wi-Fi Alliance.
Internet
Modem
PUSH
AirStation PC or
Game console
(AOSS Devices)
PUSH
• Before using AOSS or WPS to connect to a Bualo wireless client, install Client Manager software
from the included AirNavigator CD. Consult your wireless client’s documentation for more
information.
• Bualo’s Client Manager software can be used with the wireless LAN devices built into your
computer. However, it is not guaranteed to work with all wireless LAN devices available. Some
wireless clients may require manual setup.
WZR-HP-G300NH User Manual 96
Chapter 5 Connect to a Wireless Network
Windows 7/Vista (Client Manager V)
If you are using Windows 7/Vista, use the included Client Manager V software to connect wirelessly
with AOSS/WPS.
1
2
3
4
Click the icon in the system tray.
When the screen at left is displayed, click [Create
Prole].
When the message [A Program needs your permission to continue] appears, click [Continue].
Click the [WPS AOSS] button.
Follow any instructions displayed on the screen. When the Security LED on the front of the AirStation
stops ashing and is lit steadily, the connection is complete.
WZR-HP-G300NH User Manual 97
Chapter 5 Connect to a Wireless Network
Windows XP (Client Manager 3)
If you are using Windows XP, use Client Manager 3 to connect wirelessly with AOSS/WPS.
1
Right-click on the icon in the system tray, and select [Prole].
2
Click the [WPS AOSS] button.
Follow any instructions displayed on the screen. When the Security LED on the front of the AirStation
stops ashing and is lit steadily, the connection is complete.
WZR-HP-G300NH User Manual 98
Chapter 5 Connect to a Wireless Network
Other Devices (e.g. Game Console)
If you are using a game machine which supports AOSS or WPS, refer to that device’s manual to
initiate AOSS/WPS. When instructed, hold down the AOSS button on the AirStation for 1 second.
When the Security LED stops blinking and is lit steadily, the connection is complete.
Manual Setup
You can also connect to the AirStation without installing Client Manager V or Client Manager 3 by
using the utility built-in to Windows. The procedure varies depending on which version of Windows
you are using.
Windows 7 (WLAN AutoCong)
With Windows 7, use WLAN AutoCong to connect to the AirStation.
1
2
Click on the network icon in the system tray.
Select the target AirStation’s name and click
[Connect]. If you will be connecting to this
device in the future, checking [Connect
automatically] is recommended.
WZR-HP-G300NH User Manual 99
Loading...
