Buffalo Technology HD-QSTSU2 User Manual

Mac User Guide

HD-QSTSU2/R5 DriveStation Quattro

Package contents:

• Main Unit (DriveStation)

• Power Cord

• USB Cable

• eSATA Cable

• eSATA Backplate

• DriveNavigator Installation CD

• User Guides

eSATA

USB

Auto On/Off

Manual On/Off

Back Panel Layout

Socket for
Power Cord

Power On
Off

Note: Changing between RAID modes is done with the RAID Utility, included
with the software on your DriveNavigator CD.

2

DriveStation Setup

Flip the power switch on the back of the DriveStation to the OFF position. Plug
DriveStation’s power cord into the power socket as shown, as well as a power
outlet or surge protector. Then, connect a USB or eSATA cable into a matching
port on the back of the DriveStation.

Connect the USB or eSATA cable to your Mac or other device you are adding
the DriveStation to.

3

DriveStation Setup

Flip the power switch on the back of the DriveStation to the ON (“I”) position.

Your Mac will detect the new drive and place an icon on your desktop.

Your DriveStation is now ready for use! Double-click on the icon to open the hard
drive.
