Page 1

54 Mbps Wireless Cable/DSL Router

www.buffalotech.com/wireless

User Manual

AirStation G54

WYR-G54

Rev B

Page 2

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 05

Installation / Setup . . . . . . . . . . . . . . . . . . . . . . 11

Antenna Installation. . . . . . . . . . . . . . . . . . . . . . 13

Logging In . . . . . . . . . . . . . . . . . . . . . . . 14

Installation Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Advanced Setup

Wireless Settings . . . . . . . . . . . . . . . . . . 22

Wireless LAN Security . . . . . . . . . . . . . . 25

WAN Port . . . . . . . . . . . . . . . . . . . . . . . . 27

Dynamic DNS . . . . . . . . . . . . . . . . . . . . .

Rou tin g . . . . . . . . . . . . . 3 2

Address Translation . . . . . . . . . . . . .

Packet Filtering . . . . . . . . . . . . . . . . . . . . . . . . 36

Intrusion Detector . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . 22

Page 3

Table of Contents

UPnP. . . . . . . . . . . . . . . . . . . . 38

System Information . . . . . . . . . . . . . . . .

Administrator Password . . . . . . . . . . . . . . . . . . . . . . 40

Client Monitor . . . . . . . . . . . . . . . . . 41

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Log Information . . . . . . . . . . . . . . . .

Save or Restore Settings. . . . . . . . . . . . . . . . . 44

Restore Defaults . . . . . . . . . . . . . . . . . . . . . .

Update Firmware . . . . . . . . . . . . . . . . . 46

Page 4

Table of Contents

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 47

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

FCC Information . . . . . . . . . . . . . . . . . . . . . . . . 55

Warranty Information. . . . . . . . . . . . . . . . . . . . . 58

Contact Information . . . . . . . . . . . . . . . . . . . . .

Page 5

Introduction

AirStation G54 Wireless Cable/DSL Router (WYR-G54)

This manual introduces you to the AirStation Cable/DSL Router, and will help you connect to your network quickly.

The WYR-G54 router, is a wireless 4-port router network device that complies with the 2.4GHz IEEE 802.11g standard speciﬁcation on wireless LANs. It also supports various advanced router technologies. The WYR-G54 supports enhanced built-in NAT/SPI ﬁrewall functions and is used as a multi-functional router/link between wired and wireless LAN computers.

Summary of the AirStation WYR-G54 features:

• Support for wireless security encryption using TKIP and WEP.

• DHCP client/server function.

• VPN pass-through, for secure communications using IPSec or PPTP.

• Packet Filtering for eliminating unwanted communication types.

• SOHO/SMB routing and ﬁrewall functions provide a safer private networking environment, includ ing support for MS NetMeeting and MSN-Messenger.

• Additional SPI Firewall Functions - DMZ, intrusion detection and notiﬁcation

• Supports Universal Plug and Play (UPnP).

• Enhanced security features:

- SPI Firewall and DMZ zone functions to prevent unknown intruders.

- Intrusion Detector Firewall (NAT)

Page 6

Introduction

- Dynamic packet ﬁltering.

- Wireless encryption via TKIP and WEP.

- VPN pass-through for IPSec and PPTP connections.

- Packet monitoring and ﬁltering by MAC address, IP address and port.

- PPPoE support

• Buffalo’s easy web interface conﬁguration

• Broadband router static and dynamic routing methods between WAN and LAN based on updated routing tables. An economical way to bridge multiple networks.

• Web based setup wizards for both Cable and DSL broadband connections

Home Networking 1

Buffalo AirStation wireless access points enable sharing broadband by simply connecting the AirStation to a DSL or Cable modem to:

• Share ﬁles and printers

• Access and share the Internet

• Share media ﬁles

SOHO/SMB Networking

With high-speed DSL or Cable connections readily available, many users can work effectively from a home ofﬁce, connected securely to a corporate network. Buffalo’s solutions are ideal for home

Page 7

Introduction

networks that require secure, high-speed access to the corporate LAN. Tools that play an integral part in Buffalo’s solutions include VPN connectivity for secure access to corporate resources, which enable the remote employee to handle information from clients or coworkers as if they were in the ofﬁce. Connect the Buffalo AirStation Broadband router AP to a Cable or DSL modem in order to:

•Share broadband access

•Share ﬁles and printers

•Bridge between multiple networks and multiple computer platforms

•Provide easy and secure access to home or company networks from remote locations

System Requirements

• Broadband (High-Speed) Internet connection or existing Local area connection

• Any Wi-Fi (wireless) compatible computer with a Web Browser Internet Explorer or Netscape 4.5 or later. (Safari 1.0 is supported with Macintosh OS X.2)

AirStation WYR-G54 Package Contents

The AirStation WYR-G54 package consists of the following items.

1. WYR-G54 Base Station

2. AC adapter/power cable

3. CAT5 LAN cable

4. Utility CD with Manual

Page 8

Introduction

5. Quick Setup Guide

6. Warranty Statement

Product Views

Power - Lit when the device is powered on.

Wireless - Lit when the wireless radio is on. Flashes when wireless trafﬁc is present.

WAN - Lit when connection to Cable/DSL modem is present. Flashes when internet trafﬁc is present.

Status - Flashes red when performing diagnostic functions or when an error exists.

Link/Act - Indicates an active link between the corresponding LAN port and another network device.

100 - Lit orange when the corresponding LAN port is communicating at 100 Mbps (otherwise 10 Mbps).

Page 9

Introduction

About the AirStation CD

The AirStation does not require any software to be installed on your computer for conﬁ guration. The AirStation CD contains client drivers for Buffalo Wireless Adapters (i.e. Notebook Adapter and Desktop PCI Adapter) and the AirStation documentation.

Prior to copying or installing any software, please read the Software License Agreement “license.

Page 10

Introduction

txt”, located in the root folder of the CD. By installing, copying or using the AirStation software, you are consenting to the terms of this agreement. If you do not agree to all of the terms of the Software License Agreement, do not download, copy or install the AirStation software.

It is the policy of Buffalo Technology to improve products as new technology, components, software and ﬁrmware become available.

Please consult the AirStation wireless website (http://www.buffalotech.com/wireless and install the latest ﬁrmware for your product.

Follow these simple steps to connect the AirStation to your Broadband Internet connection allowing you to combine and share wired and wireless computers and printers with the high-speed internet connection.

1. Power down the Cable or DSL modem and the computer which will be used to conﬁgure the

) to download

Page 11

Installation / Setup

AirStation router.

2. Plug the Cable or DSL’s LAN Ethernet cable into the AirStation’s WAN port. Initially, you may need to unplug this cable from your computer, hub or other router.

3. Plug the provided Ethernet cable into a LAN port on the AirStation and plug the other end into your computer Ethernet adapter’s (NIC) port. If you plan to initially conﬁgure the AirStation via a wireless connection, (not recommended), you may skip this step.

4. Power on your cable or DSL modem, wait one full minute, Power on the AirStation router, wait another full minute and then power on the computer which will be used to conﬁgure the AirSta tion. If the red DIAG light on the AirStation is lit or ﬂashing after several minutes of being powered on, please consult Buffalo Technical Support.

Introduction

Conﬁguring the AirStation using a standard web browser requires basic wireless conﬁguration knowledge. Setup includes manual wireless conﬁguration and basic administrative management.

Setup Preparation

Make note of the AirStation’s wired MAC address found on the rear of the AirStation. It is also recommended you record any other broadband ISP information such as global IP address, subnet mask address, default gateway address, DNS server address and PPPoE parameters.

Setup Overview

Page 12

Installation / Setup

Buffalo recommends using a wired connection, meaning your computer is physically connected to the AirStation with a CAT5 straight cable plugged into one of the four LAN ports This type of setup will eliminate possible setup problems due to any issues with the wireless adapter on the computer being used to conﬁgure the AirStation.

A Web browser version 4.5 or later can be used to conﬁgure the AirStation. Advanced settings for security, ﬁltering and other features will be explained in later sections.

Open the Setup Screen

• Connect the WYR-G54 according to the wiring instructions in Section 2.

• The WYR-G54 has a default LAN IP address of 192.168.11.1 and Subnet Mask of 255.255.255.0.

n Note: The computer used to conﬁgure the AirStation should be set to obtain an IP address automatically using a DHCP server. The Quick Setup Guide enclosed with the product contains detailed instructions on how to conﬁgure your computer for initial conﬁguration.

On the computer used to conﬁgure the AirStation, launch a Web Browser 4.5 or later.

- Enter 192.168.11.1 into the URL ﬁeld.

- A window will open prompting you to enter a User ID and Password.

Page 13

Antenna

The WYR-G54 has one internal omnidirectional antenna. The transmission of wireless signals is isotropic, meaning that the waves are emitted much like the sun distributes light in every direction. However, connection problems can occasionally be remedied by simply adjusting the position of the antenna. External antennas come in all shapes and sizes. Antennas also come with different connectors. The WHR2-G54 has an ‘TNC Connector (male)’ on it. Thus, the antenna must also have a RP-TNC connector (female).

The antenna can be removed to replace with a higher gain antenna or directional antenna simply by unscrewing it counter-clockwise.

Please be familiar with and adhere to all FCC regulations when introducing new hardware in use with your AirStation.

Page 14

Enter “root” as the User ID and leave the password ﬁeld blank.

n Note: These are the factory default settings

Logging In

Page 15

Setup Wizard - Launch

Initial

Settings

Screen

Choosing a Connection

Type

Internet Setup

• Click the Internet Setup arrow button to begin the Internet Setup Wizard.

• Advanced users have the option of skipping this step and begin manually conﬁ guring the access point.

Choosing a Connection Type

Click on the type of broadband connection your ISP is providing.

Note:

If you are unsure of whether you are using cable or DSL broadband, please contact your ISP.

DSL users can now skip to Page 18!

Page 16

Setup Wizard - Setup

Cable

Connection

Options

DSL PPPoE

Settings

Screen

Cable Connection Options

- Choose the type of connection conﬁ guration as provided by your ISP

- Most Cable operators provide the ﬁ rst type of conﬁ guration - Automatic (DHCP)

Automatic IP Assignment by ISP

- Select ‘Automatic IP Assignment by ISP’ if your ISP’s DHCP server assigns an IP address automatically.

Page 17

Setup Wizard - Cable

Manual IP

Address Settings

Automatic IP

Address

Settings with

Manually Entered

DNS Settings

Manual Entry of IP Information

- If your IP Information is provided by your ISP, ﬁ elds are provided to ﬁ ll in the information.

- Some ISPs also require that a certain MAC Address is used. If this is not speciﬁ cally required, just use the default MAC Address.

The IP Address is Acquired Au to mat i cal ly but DNS Server Address is Entered Manually

If the ISP provides your IP conﬁ guration automatically, but requires manual entry of DNS information, ﬁ elds will be provided for DNS information after an IP Address is successfu acquired.

Cable Users can now skip to Page 19!

lly

Page 18

Setup Wizard - DSL

DSL

Connection

Options

DSL PPPoE

Settings

Screen

DSL Connection Options

- Choose the type of connection conﬁ guration as provided by your ISP

- Most DSL operators provide the ﬁ rst type of conﬁ guration - Automatic (DHCP)

- When using a LAN connection type of DSL, network settings are automatically delivered by your ISP.

PPPoE Setup

- Enter the requested information into the ﬁ elds provided. Note that DNS information is only required to complete setup if speciﬁ cally required by the ISP.

Page 19

Setup Wizard - Line Test

Line Test

If the Line Test is successful, the AirStation is now ﬁ nished with basic setup and client devices should be able to connect to the Internet through the AirStation. The next step involves setting up wireless security, which is optional.

Line Test

Once the Setup Wizard is complete a line test to the Internet will launch to verify successful entry of settings.

If the connection fails, please verify the accuracy of the entered information with the ISP.

Page 20

Setup Wizard - Security

Security

Setup

TKIP - check with your client adapter vendors to make sure that ALL of your wireless adapters support this method of WPA encryption.

WEP - while most wireless adapters support WEP, it has been shown not to be as robust as TKIP, though it is considered adequate for home use.

Disabled - when security is disabled, clicking Continue will return you to the Home screen where other conﬁ gurations can be made or you can AirStation normally.

Wireless Security Setup

Encrypting your wireless data is important to prevent other devices from being able to monitor your wireless data transmissions.

There are two options available TKIP or WEP. One or the other may be selected, or you can choose not to enable security and allow open movement of trafﬁ c.

Log Out of the access point and begin using your

Page 21

Wireless Settings

WEP Setup

- If WEP is chosen as the encryption type, you need only to enter in an encryption key. Note that depending on the type (ASCII vs. HEX), the length of the key will vary depending on the numbers of bits in use.

TKIP Setup

- If TKIP is chosen as the encryption type, you need only to enter a pre-shared key. Note that depending on the type (ASCII vs. HEX), the limitations of the key length will vary. The rekey interval can be left at its default settings unless advanced conﬁ guration is needed.

Security Setup Completion

- Once the encryption key has been successfully added, the AirStation will save the key and restart. At this point, the key will need to be entered into any device connecting wirelessly to pass data through the AirStation. If problems are encountered connecting wirelessly with the encryption key, please use a wired connection to attempt conﬁ guration or reset the AirStation with its reset button on the rear face.

Page 22

Wireless Settings

LAN

Settings

LAN Settings

Click on the LAN Settings button within the left frame to conﬁ gure basic or advanced LAN settings.

Wireless Settings

Wireless Mode - Allows you to choose between supported rate sets.

- Mixed - supports both 11b and 11g clients (default setting)

- Turbo - supports only 11g clients. 11b clients will not be allowed to associate, thus improving overal performance of the wireless network.

- Legacy - only 11b rates are supported. Use this for troubleshooting older wireless adapters.

Page 23

Wireless Settings

SSID - Allows administrator to alter the SSID of the AirStation. To communicate with a speciﬁ c AP only, the AP’s SSID must be entered in the client computer. The client computer looks for the speciﬁ c AP (or SSID) for wireless communication. Use up to 32 al pha nu mer ic characters for the SSID (case sensitive). By default the SSID is the LAN Mac address of the AirStation.

Wireless

Settings

If there are multiple APs in close proximity using the same channel, there may be interference. In this case, change to a non-overlapping channel.

Broadcast SSID - Enable or Disable the SSID (SSID) from being broadcasted. If denied, the

n Note: Roaming - When multiple AirStations have an identical SSID, WEP key (if WEP is used), (and channel in WDS mode) , client computers may Roam between the AirStations.

Wireless Channel - Select the channel used for wireless communication. There are 11 overlapping channels. Channels 1, 6 and 11 are non-overlapping. The ‘Auto-Channel’ option is recommended, as it constantly assesses the best available channel for the AirStation to operate on.

Page 24

Wireless Settings

AirStation will not be found unless the speciﬁ c AirStation’s SSID is entered in the client computer manually.

Wireless Radio Enabled

wireless communications can take place. Wired connections can continue uneffected though.

Access to LAN - Speciﬁ c clients can be given access to the local network (LAN) by enabling this limitation. By default all clients (wired and wireless) have access to the local network resources. Local network resources can include but are not limited to, other computers’ shared ﬁ les, networked printers and scanners.

Access to WAN - Speciﬁ c clients can be given access to the Internet (WAN) by enabling this limitation. By default all clients (wired and wireless) have access to the Internet through the WAN port.

Choosing Clients that can Access

LAN or WAN

Resources

- By default the wireless radio is turned on, however by disabling the radio, no

To add users to the access tables, they must have previously connected to the AirStation. Select the clients you wish to limit access to and click Apply.

Clients can be removed from the table at a later time if needed.

Note: Always click Apply to save your changed settings to the AirStation.

Page 25

Wireless Security

Wireless Security Setup

Encrypting your wireless data is important to prevent other devices from being able to monitor your wireless data transmissions.

There are two options available TKIP or WEP. One you can choose not to enable security and allow open movement of trafﬁ c.

TKIP - check with your client adapter vendors to make sure that ALL of your wireless adapters support this method of WPA encryption.

WEP - while most wireless adapters support WEP, it has been shown not to be as robust as TKIP, though it is considered adequate for home use.

Disabled - when security is disabled, clicking Continue will return you to the Home screen where other conﬁ gurations can be made or you can AirStation normally.

or the other may be selected, or

Security

Setup

Log Out of the access point and begin using your

Page 26

Wireless Security

WEP Setup

TKIP Setup

Security Setup Completion

Page 27

WAN Port Settings

WAN MAC Address - The WAN

Ports MAC Address occassionaly is required to be set to a value other than the default. Only change the value if required by your ISP.

Login Method - There are several ways of creating a connection to your broadband provider. In most cases, your ISP will use a Direct Connection, however, in some cases PPPoE or IP Unnumbered is used which will require the entering of information provided by your ISP. If you are unsure of which to use, please contact your ISP.

WAN Port

Settings

Page 28

Advanced Settings

Direct

Connection

Options

Direct Connection Options

- IP Address and DNS Server Address settings may have been provided by your ISP. If this is the case, they should be entered here, otherwise leave the default settings in place to acquire these settings automatically via DHCP.

Page 29

PPPoE Client Options

PPPoE Client Options - If you are using PPPoE for your broadband connection, your ISP should have given some custom information to enter. If you do not have this information, it will be necessary to collect it from them.

The connection can be set to the following types:

Connection on Demand - The connection is opened when activity is detected and terminated after a set period of inactivity (20 minutes by default).

Manual Connection - The connection must be manually started and stopped.

Continuous Connection - The AirStation will keep the connection alive indeﬁ nitely. PPPoE Multisession - The AirStation supports PPPoE Multisession as well. If your class of broad-

band requires this information, hit the Multisession to enter the information in a separate window. Make sure to hit Apply when the data entry is complete.

The MTU value (578-1492) should only be changed if speciﬁ cally instructed to by your ISP.

PPPoE Client

Options

Page 30

Advanced Settings

WAN Network Settings

Reply to Ping from WAN Port - When the Air acknowledge its IP Address and various other information from over the Internet. This is useful to managing remote access points and ensuring uptime, but it can be considered a security breach as well as it does distribute some minimal information about your router. At the minimum, make sure you have changed your root (administrator) password with either of these functions enabled.

Station is set to respond to Ping requests, it will

Remote Management - When enabled, remote management will allow you to conﬁ gure your access point remotely over the Internet. A port should be speciﬁ ed between the ranges of 1 and

65535. The management interface can

then be accessed by your IP Address as shown and the port as in http://244.244.222.130:10500 where 244.244.222.130 is the WAN IP Address and 105 the speciﬁ ed port.

00 is

Page 31

Dyanmic DNS

Dynamic DNS

While each has been prescreened for compatibility and customer service, Buffalo Technology USA can not provide adquate technical support for these services. For complete support and setup procedures, please visit the website of the service of your choosing.

Dynamic DNS is useful to allow your AirStation requests for a domain name such as www.yourname.com or mail.yourname.com.

Due to the fact that many ISPs use DHCP rather than ﬁ xed IP Addresses, hosting services like web servers, game servers, FTP servers or mail servers can be very challenging. DDNS provides a solution.

Entry ways for several third party services are included on your access point.

to respond to

Page 32

Routing Information

Routing

Information

Static Routes - Static routes can be added to the routing table to facilitate routing amongst devices. By entering the necessary IP Information about a property and a metric to specify the required number of hops between routers to reach a device, the most efﬁ cient path can be calculated among multiple routers. The values entered for the IP Address, Subnet Mask and Gateway should be the IP information of the remote network device that is being routed to by the AirStation.

RIPv1 Routing - RIP dyanmic routing allows routing information to be shared with out ther routers using RIPv1 routing. This will allow easy sharing of information between multiple routers in regards to their own resources or stored entries within their routing tables. This improves the overall performance within a complex set of separate networks.

Page 33

Address Translation

Bridging PPPoE and

VPN Pass-Through

Address Translation (NAT)

PPPoE Bridging - If a device

on the LAN Ports is capable of managing PPPoE client communications, enabling this option will allow the device the necessary direct, pass-through access to the WAN port

VPN Pass-Through - If you have client devices that will need to create VPN tunnels with IPSec or PPTP, this option should not be disabled. It is enabled by default.

Page 34

Address Translation

In some situations, it is beneﬁ cial to have a device designated as a catchall, with all ports opened to enable better functionality with services like messaging or gaming.

Using a Demilitarized zone will allow one local network device to be exposed to the Internet for use of a specialpurpose service such as Internet gaming or videoconferencing. DMZ hosting forwards all the ports at the same time to the selected device.

Packet Filtering is more secure as it only opens the ports designated to be opened, while a Demiliatrarized Zone will open every port of a designated device.

client network

Demilitarized

Zone Client

Page 35

Network Address Translation

Address

Translation

by Service

NAT by Service and Device

Some of the common services that address translation is necessary to use with are offered preconﬁ

By selecting a service, most ﬁ elds will be autoﬁ lled to make setup easier, however if you

using a service different from what is offered or with different conﬁ gurations, you can a a new service by clicking the Add New Server button.

Be sure to accurately enter the appropriate settings and clicking the appropriate network device from the Local Client Server dropdown list while it is connected to

the AirStation.

gured.

are

Page 36

Packet Filtering

Packet

The AirStation supports the TCP and UDP protocols for Network Address Translation.

Packet Filtering

Packet Filtering conﬁ gures advanced public services on your local network, such as web servers, FTP servers, email servers, gaming servers or other specialized Internet services that require delivery of speciﬁ c requests through the router to the appropriate local network device for delivering speciﬁ c appication requests.

When unique requests for a particular response are delivered to your router via the Internet, the router will forward those requests to the designated local network device for appropriate response.

Because when DHCP is in use, IP Addresses could change for a client device over time, it is best practice to assign local network devices that have packet ﬁ ltering rules assigned to them to use a ﬁ xed IP Address to prevent failures due to a change in IP Address that the packet ﬁ lter does not acknowledge.

Filtering

Page 37

Intrustion Detector Firewall

In t r u s i on

Detector

Even at the Low setting, your AirStation will provide an ample amount of security for your network.

Intrusion Detector

There are three levels for Intrusion Detector to function at.

High: Recommended for Internet bandwidth of 2 Mbps or higher.

Medium: Recommended for Internet bandwidth between 1 and 2 Mbps bandwidth.

Low: Recommended for bandwidth under 1 Mbps.

Because your AirStation uses an SPI Firewall, it is important to temper your security level to your broadband connection speed.

Page 38

UPnP

UPnP Service

Enabling the UPnP Service enables other UPnP enable devices to easily regonize and conﬁ gure one another according to the developing UPnP standard.

Note: If IP-Unnumbered conﬁ guration is in use for DSL connections, UPnP should not be enabled to prevent conﬂ icts.

Page 39

System Information

AirStation.

System

Information

System Information

Firmware Version

rent ﬁ rmware version AirStation.

DHCP - Displays whether the AirStation is operating as a DHCP client on its WAN port. The amount of time left on the DHCP lease is shown as well as the ability to have the AirStation release and renew its current IP conﬁ guration on the WAN port.

LAN/WAN

IP conﬁ guration information is shown about the LAN and WA

The connection method of the WAN port and the status of that connection is

dis- played as well.

-Various details about the

N ports.

- Displays the currunning on the

and MAC Addressing

Page 40

Basic Settings

Basic

Settings

Basic Settings

The AirStation is conﬁ gured with a ministrator account named root. It can not be changed to another name.

The default password of the AirStation is blank (i.e. no text). This value can and should be changed.

The new password should be 8 alphanumeric characters long and can include an underscore character ( _ ). The pass-

word is case sensitive.

If the password is forgotten, it will be necessary to reset the AirStation via the Reset button on the rear face, which will cause all other conﬁ gurations to restore

to factory defaults.

n ad-

Page 41

Advanced Settings

Client

Monitor

Client Monitor

Client Monitor allows you to view the currently connected clients.

While DHCP clients are shown automatically, it is necessary to manually add clients with ﬁ xed IP Addresses in order for them to appear in Client Monitor

By clicking Detailed PC Settings a new window will appear where you can manually ﬁ x what IP Address is assigned to DHCP clients. This is useful for managing multiple DHCP clients will have the same IP Address at each connection.

that

Page 42

Diagnostics

Diagnostics The Diagnostics screen allows

you to perform some basic connectivity troubleshooting. A local or external IP Address can be entered and checked for connectivity by clicking Ping.

The results from the Ping will show whether external or internal connectivity is present to a client device or remote resource from the router. This is useful to conﬁ rm that a connectivity problem exists on a client rather than on the router.

Also, to check name resolution via DNS, a domain name can be entered. The results will show the IP Address of the domain name if successful. A failure coul entries for the router that should be conﬁ rmed with your ISP.

Diagnostics

d indicate an error in the DNS Server

Page 43

Log Information

You can specify the types of events that are recorded into the log for later viewing.

Internet Connection - Logs successes for failures when connecting externally via the WAN port.

Access Restrictions - Logs successes or failures of clients connecting via the LAN port.

Intrustion Detector - Logs possible malicious attacks that are blocked by the Intrusion Detector ﬁ rewall

Note: To add value to the recorded logs, be sure to set your time zone accurately.

Information

Log

Page 44

Save or Restore Settings

Save or

Restore

Settings

Save Settings - Your current settings can be saved as an image ﬁ le

that can be restored to your AirStation at a later date. This is also useful for easily setting up multiple AirStations with identical settings.

Restore Settings - If a settings

ﬁ le was previously created, it can be quickly restored to the AirStation. Note that the settings ﬁ le will overwrite all current settings when it

is restored.

Page 45

Restore Defaults

Restart or

Restore

Settings

Restart

Occasionally it may be necessary to restart your AirStation. Often the ﬁ rst start in troubleshooting a problem is to simply restart the device.

Restore Factory Defaults

To return the AirStation ba to its original out of the box conﬁ guration, click the Restore button. All changes will be lost, so it is best practice to create a saved settings ﬁ le in advance.

Page 46

Firmware Update

Buffalo Technology USA regularly provides ﬁ rmware updates to enhance performance, provide additional features and to ﬁ x bugs. Please check our website listed below for udpates.

Firmware updates should be done with a wired connection as opposed to wirelessly. Also, it is best practice to save your current settings to a saved settings ﬁ le in advance.

Please review the release notes to see if a ﬁ rmware update is necessary. Your current update version can be found in the System Information section of your management screen.

Use of ﬁ rmware outside of the geographic region that the AirStation is being used in may be a violation of your country or state laws.

To update your ﬁ rm sary to a known location on your computer. Click the Browse button and point it at the image ﬁ le. Then click Update to proceed. The AirStation will restart after the process is complete and normal operation should resume.

Firmware updates can be found for the USA and Canada only at: http://www.buffalotech.com/support/downloads.php

ware download the image from our website. Then unzip the package if neces-

Page 47

Troubleshooting

Common Problems:

• Out of range, client cannot connect to the AirStation.

• Conﬁguration mismatch, client cannot connect to the AirStation.

• Absence or conﬂict with the Client Driver.

• Conﬂict of another device with the AirStation hardware.

Status LED Lit Red

Unplug the power for three seconds. Plug the power back in to monitor the DIAG LEDs during start-up. If any symptoms match section B.1.1, call the Buffalo Tech Support line 24 hours a day, 7 days a week

at 866-752-6210 or email info@buffalotech.com for USA and Canada only.

Table B.1.1 DIAG LED Activity Table

DIAG LED Display Time Description/Action

Continuous Red Starting RAM Error Red ﬂash, 2 times Starting Flash ROM

Error

Red ﬂash, 3 times

Red ﬂash, 4 times

B. 1.2 LEDs Work But Client PC Cannot Connect to Network

Starting A problem on the wired LAN side

Starting A problem on the wireless LAN side

Page 48

Troubleshooting

If the LEDs indicate that the network is working properly (Power LED is on, Transmit/Receive LED blinks), check the TCP/IP settings of the network.

Changing Client TCP/IP Settings in Windows

Consult the LAN Administrator for TCP/IP settings. To add or change the TCP/IP Settings:

1. On the Windows task bar click Start.

2. Select Settings, then Control Panel.

3. Double-click on the Network icon to view the Network Properties.

4. From the list of installed components, verify the TCP/IP => wireless LAN adapter protocol is installed.

• If the wireless adapter protocol is not yet installed, click the Add button and select the TCP/IP protocol from the list. Refer to Windows Help for more information.

• If the wireless adapter protocol is installed, select the protocol and click the Properties button. Verify the parameters match the settings provided by your LAN Administrator. Make changes if necessary, and click OK.

5. When or if prompted, restart your computer.

B. 1.3 Other Problems

Please refer to www.buffalotech.com for further reference materials.

Page 49

Glossary

10BaseT or 100BaseTx: 802.3 based Ethernet network that uses UTP (Unshielded twisted pair) cable and a star topology. 10 is 10 Mbps and 100 is 100 Mbps.

802.1x: The standard for wireless LAN authentication used between an AP and a client. 802.1x with EAP will initiate key handling.

Ad-Hoc Network: The wireless network based on a peer-to-peer communications session. Also referred to as AdHoc.

Bandwidth: The transmission capacity of a computer or a communication channel, stated in Megabits per second (Mbps).

BSS (Basic Service Set): An 802.11 networking framework that includes an Access Point.

Bus Mastering: A system in which the speciﬁed Input/Output device (e.g. NIC Card) can perform tasks without the intervention of the CPU.

Client: A PC or workstation on a network.

Cross-Over Wiring: A UTP cable that has its

transmit and receive pair crossed to allow communications between two devices.

DCE (Data Communications Equipment): Hardware used for communication with a Data Terminal Equipment (DTE) device.

Default Gateway: The IP Address of either the nearest router or server for the LAN.

Default Parameter: Parameter set by the manufacturer.

Destination Address:

a packet that identiﬁes the intended recipient station.

DHCP (Dynamic Host Conﬁguration Pro tocol): Based on BOOTP, it uses a pool of IP

addresses, which it assigns to each device connected to it, and retrieves the address when the device becomes dormant for a period of time.

DNS (Domain Name System): System used to map readable machine names into IP ad dresses

The address portion of

Page 50

Glossary

Driver: Software that interfaces a computer with a speciﬁc hardware device.

DSSS (Direct Sequence Spread Spectrum): Method of spreading a wireless signal into wide frequency bandwidth.

DTE (Data Terminal Equipment): Device that con10BaseT or 100BaseTx: 802.3 based

Ethernet network that uses UTP (Unshielded twisted pair) cable and a star topology. 10 is 10 Mbps and 100 is 100 Mbps.

Dynamic IP Address: An IP address that is automatically assigned to a client station in a TCP/IP network, typically by a DHCP server.

ESS (Extended Service Set): A set of two or more BSSs that form a single sub-network. SSID is user identiﬁcation used in the ESS LAN conﬁguration.

Ethernet: The most widely used architecture for Local Area Networks (LANs). It is a sharedmedia network architecture. The IEEE 802.3 standard details its functionality.

Ethernet cable: A wire similar to telephone cable that carries signals between Ethernet devices.

File and Print Sharing: A Microsoft application that allows computers on a network to share ﬁles and printers.

Firmware: Programming inserted into programmable read-only memory, thus becoming a permanent part of a computing device.

Frame: A ﬁxed block of data, transmitted as a single entity. Also referred to as packet.

Full-Duplex: To transmit on the same channel in both directions simultaneously.

Half-duplex: To transmit on the same channel in both directions, one direction at a time.

Hub: A device which allows connection of computers and other devices to form a LAN.

IEEE (Institute of Electrical and Electronics Engineers): The professional organization

which promotes development of electronics technology.

Page 51

Glossary

IP (Internet Protocol) Address: A unique 32binary-digit number that identiﬁes each sender or receiver of information sent in packets.

Infrastructure: A wireless network or other small network in which the wireless network devices are made a part of the network through the Access Point.

ISP (Internet Service Provider): A company that provides access to the Internet and other related services.

IV (Initialization Vector): The header section of an encrypted message packet.

LAN (Local Area Network): A group of com puters and peripheral devices connected to share resources.

LED (Light Emitting Diode): The lights on a hardware device representing the activity through the ports.

MAC (Medium Access Control) Address:

A unique number that distinguishes network cards.

Mbps (Mega Bits Per Second): A measurement of millions of bits per second.

MDI/X (Media Dependent Interface/Crossover): Port on a network hub or switch that

crosses the incoming transmit lines with the outgoing receive lines.

MHz (MegaHertz): One million cycles per second.

NAT (Network Address Translation): An inter net standard that enables a LAN to use one set of IP addresses for internal trafﬁc and a second set for external trafﬁc.

NIC (Network Interface Card): An expansion card connected to a computer so the computer can be connected to a network.

Packet: A block of data that is transferred as a single unit, also called a frame or a block.

Packet Filtering: Discarding unwanted network trafﬁc based on its originating address or its type.

Page 52

Glossary

PCI (Peripheral Component Interconnect): A bus that is connected directly to the CPU.

PCMCIA (Personal Computer Memory Card International Association) Card:

able module that adds features to a portable computer.

Ping (Packet Internet Groper): An Internet utility used to determine whether a particular IP address is online.

Plug and Play: Hardware that, once installed (“plugged in”), can immediately be used (“played”), as opposed to hardware that requires manual conﬁguration.

PoE (Power over Ethernet): A mechanism to send DC power to a device using a CAT5 Ethernet cable.

PPPoE (Point-to-Point Protocol over Ethernet): A speciﬁcation for connecting users on an

Ethernet line to the Internet through a common broadband medium.

Protocol: A standard way of exchanging infor-

Remov-

mation between computers.

RADIUS (Remote Authentication Dial In User Service): A server that issues authentication key to

clients.

RAM (Random Access Memory):

memory. Repeater Hub: A device that collects, strengthens

and transmits information to all connected devices, allowing the network to be extended to accommodate additional workstations.

RC4: The encryption algorithm that is used in WEP. RJ-45 connector: An 8-pin connector used be-

tween a twisted pair cable and a data transmission device.

ROM (Read Only Memory): Permanent memory. Router: Device that can connect individual LANs

and remote sites to a server. Roaming: The ability to use a wireless device while

moving from one access point to another without losing the connection.

Non-permanent

Page 53

Glossary

Script: A macro or batch ﬁle containing instructions and used by a computer to perform a task.

Server: Any computer that makes ﬁles or peripheral devices available to users of the network and has a resident Network OS.

SMTP (Simple Mail Transfer Protocol): The protocol used to deﬁne and deliver electronic mail (E-mail) from one location to another.

SNMP (Simple Network Management Proto col: An application layer protocol that outlines

the formal structure for communication among network devices.

Static IP Address: A permanent IP address is assigned to a node in a TCP/IP network. Also known as global IP.

STP (Shielded Twisted Pair): Twisted Pair cable wrapped in a metal sheath to provide extra protection from external interfering signals.

Subnet Mask: An eight-byte address divided into 4 parts separated by periods.

TCP/IP (Transmission Control Protocol/In ternet Protocol: Protocol used by computers

when communicating across the Internet or Intranet.

TKIP (Temporal Key Integrity Protocol): An encryption method replacing WEP. TKIP uses random IV and frequent key exchanges.

Topology: The shape of a LAN (Local Area Network) or other communications system.

Twisted Pair:

pair of insulated wires twisted together. UDP (User Datagram Protocol): A com

munication method (protocol) that offers a limited amount of service when messages are exchanged between computers in a network. UDP is used as an alternative to TCP/IP.

Uplink: Link to the next level up in a communication hierarchy.

UTP (Unshielded Twisted Pair) cable: Two or more unshielded wires twisted together to form a cable.

Cable that comprises 2 or more

Page 54

WAN (Wide Area Network): A networking system covering a wide geographical area.

WEP (Wired Equivalent Privacy): An encryp tion method based on 64 or 128-bit algorithm.

Web Browser: A software program that allows viewing of web pages.

Wi-Fi (Wireless Fidelity): An organization that tests and assures interoperability among WLAN devices.

Wire Speed: The maximum speed at which a given packet can be transferred using Ethernet and Fast Ethernet standard speciﬁcations.

WLAN (Wireless LAN): A LAN topology using wireless devices.

VPN (Virtual Private Network): A security method to connect remote LAN users to a corporate LAN system.

Glossary

Page 55

FCC / CE Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is con nected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, (example - use only shielded interface cables when connecting to computer or peripheral devices). Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 56

FCC / CE Information

IMPORTANT NOTE:

Federal Communication Commission Interference Statement

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

Page 57

FCC / CE Information

FCC RF Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. BUFFALO declared that WYR-G54 is limited in CH1~11 by specified firmware controlled in USA.

Europe – EU Declaration of Conformity

This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of compliance with the R&TTE Directive 1999/5/EC:

- EN 60950-1: 2001, First Edition Safety of Information Technology Equipment

- EN 300 328-1 V1.3.1 (2001-12)

- EN 300 328-2 V1.2.1 (2001-12) Technical requirements for spread-spectrum radio equipment

- EN 301 489-1 V1.4.1 (2002-08)

- EN 301 489-17 V1.2.1 (2002-08) EMC requirements for spread-spectrum radio equipment.

This device is a 2.4 GHz wireless LAN transceiver, intended for home and office use in all EU and EFTA member states, except in France, Belgium and Italy where restrictive use applies.

In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain

Page 58

FCC / CE Information

an authorization to use the device for setting up outdoor radio links.

In Belgium there is a restriction in outdoor use. The frequency range in which outdoor operation in Belgium is permitted is 2460 – 2483.5 MHz.

This device may not be used for setting up outdoor radio links in France. For more information see http://www.anfr.fr/ and/or http://www.art-telecom.fr

English Hereby, BUFFALO, INC., declares that this Wireless Router is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Finnish BUFFALO, INC. vakuuttaa täten että Wireless Router tyyppinen laite on direktiivin 1999/5/ EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.

Dutch Hierbij verklaart BUFFALO, INC. dat het toestel Wireless Router in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG Bij deze verklaart BUFFALO, INC. dat deze Wireless Router voldoet aan de essentiële eisen en aan de overige relevante bepalingen van Richtlijn 1999/5/EC.

French Par la présente BUFFALO, INC. déclare que l’appareil Wireless Router est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE Par la présente, BUFFALO, INC. déclare que ce Wireless Router est conforme aux exigences essentielles et aux autres dispositions de la directive 1999/5/CE qui lui sont applicables

Page 59

FCC / CE Information

Swedish Härmed intygar BUFFALO, INC. att denna Wireless Router står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/ EG.

Danish Undertegnede BUFFALO, INC. erklærer herved, at følgende udstyr Wireless Router overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF

German Hiermit erklärt BUFFALO, INC., dass sich dieser/diese/dieses Wireless Router in Übereinstimmung mit den grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG befindet”. (BMWi) Hiermit erklärt BUFFALO, INC. die Übereinstimmung des Gerätes Wireless Router mit den grundlegenden Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/ EG. (Wien)

Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ BUFFALO, INC. ΔΗΛΩΝΕΙ ΟΤΙ Wireless Router ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ

Italian Con la presente BUFFALO, INC. dichiara che questo Wireless Router è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Spanish Por medio de la presente (nombre del fabricante) declara que el (clase de equipo) cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE

Portuguese BUFFALO, INC. declara que este Wireless Router está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.

Page 60

FCC / CE Information

Safety This equipment is designed with the utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this manual and of the computer manufacturer must therefore be allowed at all times to ensure the safe use of the equipment.

EU Countries intended for use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France (with Frequency channel restrictions), Germany, Greece, Iceland, Ireland, Italy, Luxembourg, Norway, The Netherlands, Portugal, Spain, Sweden, Switzerland and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states Iceland,

Liechtenstein, Norway and Switzerland.

EU Countries Not intended for use None. Potential restrictive use France: Only channels 10,11,12, and 13.

Page 61

FCC / CE Information

Important Notice: This device is a 2.4 GHz wireless LAN trans-

ceiver, intended for indoor home and ofﬁce use in all EU and EFTA member states. Please refer to previous page in the user manual for further details.

Intended use

This device is a 2.4 GHz wireless LAN transceiver, intended for indoor home and ofﬁce use in all

EU and EFTA member states.

EU Countries intended for use

This device is intended for indoor Home and ofﬁce use in the following countries,

Austria, Belgium, Germany, Denmark, Spain, Greece, France, Finland, Italy, Ireland, Luxembourg,

The Netherlands, Portugal, Sweden, United Kingdom, Cyprus, Czech Republic, Estonia, Hungry, Latvia, Lithuania, Malta, Poland, Slovak Republic and Slovenia.

The device is also authorised for use in all EFTA member states Iceland, Liechtenstein, Norway

and Switzerland.

Page 62

FCC / CE Information

EU countries not intended for use

None

Potential restrictive use

This device is a 2.4 GHz wireless LAN transceiver, intended for indoor home and ofﬁce use in all

EU and EFTA member states, except in France, Belgium and Italy where restrictive use applies.

In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain

an authorization to use the device for setting up outdoor radio links.

In Belgium there is a restriction in outdoor use. The frequency range in which outdoor operation in

Belgium is permitted is 2460 – 2483.5 MHz.

This device may not be used for setting up outdoor radio links in France. For more information see

http://www.anfr.fr/ and/or http://www.art-telecom.fr

Page 63

Warranty Information

Buffalo Technology (Melco Inc.) products comes with a two-year limited warranty from the date of purchase. Buffalo Technology (Melco Inc.) warrants to the original purchaser the product; good operating condition for the warranty period. This warranty does not include non-Buffalo Technology (Melco Inc.) installed components. If the Buffalo product malfunctions during the warranty period, Buffalo Technology/(Melco Inc.) will, replace the unit, provided the unit has not been subjected to misuse, abuse, or non-Buffalo Technology/(Melco Inc.) authorized alteration, modiﬁcations or repair.

All expressed and implied warranties for the Buffalo Technology (Melco Inc) product line including, but not limited to, the warranties of merchantability and ﬁtness of a particular purpose are limited in duration to the above period.

Under no circumstances shall Buffalo Technology/(Melco Inc.) be liable in any way to the user for damages, including any lost proﬁts, lost savings or other incidental or consequential damages arising out of the use of, or inability to use the Buffalo products.

In no event shall Buffalo Technology/(Melco Inc.) liability exceed the price paid for the product from direct, indirect, special, incidental, or consequential damages resulting from the use of the product, its accompanying software, or its documentation. Buffalo Technology/(Melco Inc.) does not offer refunds for any product.

@ 2004 Buffalo Technology (Melco, Inc.)

Page 64

Contact Information

ADDRESS

Buffalo Technology (USA), Inc. 4030 West Braker Lane, Suite 120 Austin, TX 78759-5319

GENERAL INQUIRIES

Monday through Friday 8:30am-5:30pm CST

Direct: 512-794-8533 | Toll-free: 800-456-9799 | Fax: 512-794-8520 | Email: sales@buffalotech. com

TECHNICAL SUPPORT

North American Technical Support by phone is available 24 hours a day, 7 days a week. (USA and Canada).

Toll-free:

* When operating in High-Speed Mode, this Wi-Fi device achieves an actual throughput of up to 34.1 Mbps, which is the equivalent throughput of a system following 802.11g protocol and operating at a signaling rate of 125 Mbps.

(866) 752-6210 | Email: info@buffalotech.com

Page 65

4030 W. Braker Ln. Suite 120

Austin, Texas 78759

Tel: 800-456-9799

Fax: 512-794-8606

Technical Support is available 24 hours a day, 7 days a week

(USA / Canada)

Toll-Free: 866-752-6210

email: info@buffalotech.com

Buffalo WYR-G54 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
