BUFFALO Gas Equipment Stand
Installation and Operation Instructions
Model: DH525
IMPORTANT FOR FUTURE REFERENCE
Please retain this manual for the life of the equipment. For Warranty Service and/or parts, this information is
Required.
Model Number Serial Number Date Purchased
WARNING：Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury, or death. Read the installation operating and maintenance instructions
thoroughly before installing, or servicing this equipment.
Nisbets PLC
Fourth Way, Avonmouth, Bristol, BS11 8TB,
Unit 9003, Blarney Business Park, Blarney,Co. Cork
Page 2
Introduction
We are confident that you will be delighted with your BUFFALO Gas Equipment Stand.
To ensure you receive the utmost benefit from your new Gas Equipment Stand, there are two important
things you can do.
A colour version of this manual is available online
Firstly:
Please read the instruction book carefully and follow the directions given. The time taken will be well
spent.
Secondly:
If you are unsure of any aspect of the installation, instructions or performance of your appliance, contact
your dealer promptly.
WARNING:
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN
CAUSE PROPERTY DAMAGE, INJURY OR DEATH.
READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS APPLIANCE.
Specifications
General
Commercial, heavy duty, gas equipment
Pack Contents
The following is included:
NO.
DESCRIPTION
CODE
QTY
1
Support tube Assembly
06.05.1473547
4
2
Base plate Assembly
06.05.1473209
1 3 Universal Wheel
01.02.1005698
2
4
Universal Wheel(brake)
01.02.1005876
2
5
Stopper Screw
66.01.1800288
4
6
Hexagon Socket Screw Keys
66.99.1845007
1
7
Instruction Manual
04.05.1330671
1
Page 3
Installation
Installation Requirements
Remove the Stand from the packaging, ensuring that all protective packaging, plastic and residues are
cleaned from its surfaces. Layout all components of the stand on the floor ready for assembly. You will need
a spanner to assist in the assembly process
Step 1 –Universal Wheel and Universal wheel brake into the support tube to form the support tube bracket assembly.
Step 2 – Slot the stand support assembly and castors stand assembly into the stand support.
Step 3 –Disconnect, up-turn and support your gas
equipment, taking care as items may be heavy.
Screw the stand support assembly and castors
stand assembly into the gas equipment.
( Remove the cast iron to reduce the weight of
the chargrill before moving )
Step 4 – Fix and tighten the screws.
(The 100 reference height line is printed on the tube)
Step 5 – Locate the stand into required position, and adjust the adjustable feet into a level position.
Base plate assembly
Universal wheel assembly
Universal wheel Brake assembly
Universal wheel Brake assembly
Stopper Screw
Page 4
DH525 ML_A4_V1_Rev 0_20220310
