Buffalo DA957 User Manual

Convection
oven

Instruction manual

Caution: Read the instructions before using the machine

Model • Modèle • Modell • Modello • Modelo • Malli:

DA957

DA957_UK_A5_v1_20191210.indb 1 2019/12/10 15:08

UK

Telephone Helpline: 0845 146 2887

Safety Tips

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.

• Consult Local and National Standards to comply with the
following:

- Health and Safety at Work Legislation

- BS EN Codes of Practice

- Fire Precautions

- IEE Wiring Regulations

- Building Regulations

• Caution! Hot surface!

The temperature of accessible surfaces maybe high
when the appliance is operating. Always wear oven
mittens when removing food.

• DO NOT immerse the appliance in water.

• DO NOT clean with jet/pressure washers.

• DO NOT move or carry the appliance when it is switched on.

• DO NOT leave the appliance unattended during operation.

• DO NOT obstruct or cover the appliance in any way when in
use.

• During and after cooking, the unit is still hot. Never touch the
surface to avoid scalding.

• Always switch off and disconnect the power supply to the
appliance when not in use.

• This appliance must only be used in accordance with these
instructions and by persons competent to do so.

• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.

2

DA957_UK_A5_v1_20191210.indb 2 2019/12/10 15:08

UK

Telephone Helpline: 0845 146 2887

• If the power cord is damaged, it must be replaced by an
BUFFALO agent or a recommended qualified technician in
order to avoid a hazard.

• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play
with the appliance.

• Buffalo recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.

Introduction

Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your BUFFALO product.

Pack Contents

The following is included:

• Buffalo Commercial Convection Oven - 21Ltr • Grill shelf (x1)

• Instruction manual • Baking tray (x1)

BUFFALO prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.

Should you find any damage as a result of transit, please contact your BUFFALO dealer immediately.

Installation

• Place the unit on a heat-resistant surface. Avoid placing it on or close to flammable materials.
Maintain a distance of 20cm (7 inches) between the appliance and walls or other objects for
ventilation.

• Keep the unit away from splashing water and countertop’s edge.

3

DA957_UK_A5_v1_20191210.indb 3 2019/12/10 15:08

UK

Telephone Helpline: 0845 146 2887

Operation

Grill shelf

Baking tray

Power Indicator light (Green)Timer knob

Handle

Temperature knob

Temperature Indicator
light (Orange)

Before using for the first time

1. Wash the appliance and baking accessories thoroughly (See section “Cleaning, Care & Maintenance “).

2. Place the grill shelf and baking tray inside the oven.

3. Close the door.

4. Set the Timer knob to 5 minutes and the Temperature knob to MAX setting (250°C).

Note:

• If the desired time is under 20 minutes, turn the Timer knob beyond 20 first,
then turn back to the required setting.

• The Timer knob also acts as the Power switch. When it is set to “OFF”, the
appliance will switch off automatically.

• When the timer knob is set to “Stay on”, the appliance will keep working
continuously.

5. When the set time elapses, the timer knob will go back to “OFF” to switch the appliance off.

6. Disconnect the appliance from the power supply and allow it to cool down.

Start cooking

1. Connect the appliance to the mains power supply.

2. Set the Timer knob to the desired time (0-120 minutes). The power indicator light will come on and
the fan will start to run.

3. Set the Temperature Knob to the desired temperature (50°C-250°C). The temperature indicator light
will come on and the appliance will start to heat up.

4

DA957_UK_A5_v1_20191210.indb 4 2019/12/10 15:08

UK

Telephone Helpline: 0845 146 2887

4. When the set temperature is reached, the temperature indicator light will turn off.

Note:

• During use, the temperature indicator light will cycle on/off, indicating the
set temperature is being maintained.

• During cooking, the temperature and cooking time can be adjusted at any
time.

5. When the cooking time elapses, the appliance will beep then turn Off.

Overheating protection

This appliance is featured with an overheat protection. Should the temperature exceed safe levels the
appliance will automatically cut off power.
The thermal Cut-out switch is located on the rear of the appliance. To reset the appliance after a sufficient
cool-down period:

1. Press the small reset switch down until it clicks.

2. The appliance is now reset and can be used as normal.

Cleaning, Care & Maintenance

• Warning: Always turn off and disconnect the appliance from the power supply before
cleaning. Always allow the appliance to cool before cleaning.

• Clean the interior of the appliance as often as possible.

• Do not use abrasive cleaning agents. These can leave harmful residues.

• For stains on the interior walls, wipe with a cloth damped with some mild soapy solution. Ensure no
moisture enters the inside of the cabinet.

• Always wipe dry after cleaning.

• A BUFFALO dealer or qualified technician should carry out repairs if required.

Cleaning the grill shelf and baking tray

• After use, remove the parts from the appliance for cleaning.

• Clean using warm, soapy water. Rinse thoroughly and dry well.

• Re-locate into the appliance.

Troubleshooting

If your BUFFALO appliance develops a fault, please check the following table before making a call to the
Helpline.

Fault Probable Cause Solution

The unit is not
working

Unit heats up but
indicator light does
not come on

The unit is not switched on Check the unit is plugged in correctly and

switched on

Plug and lead are damaged Call BUFFALO agent or qualified Technician

Fuse in the plug has blown Replace the plug fuse

Power supply Check power supply

Internal wiring fault Call BUFFALO agent or qualified technician

Overheating protection is activated Reset the appliance

Bulb has expired Call BUFFALO agent or qualified technician

5

DA957_UK_A5_v1_20191210.indb 5 2019/12/10 15:08

UK

Telephone Helpline: 0845 146 2887

Technical Specifications

Model Voltage Power

DA957 220-240V~

50/60Hz

2100W 50ºC - 250ºC 21 380 x 475 x 510 15.5Kg

Temperature

Range

Capacity

(Litre)

Dimensions

h x w x d mm

Electrical Wiring

This appliance is supplied with a 3 pin BS1363 plug and lead.

The plug is to be connected to a suitable mains socket.

This appliance is wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.

Compliance

The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.

Weight

BUFFALO parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.

BUFFALO products have been approved to carry the following symbol:

All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,

Every effort is made to ensure all details are correct at the time of going to press, however, BUFFALO reserve the right to

DA957_UK_A5_v1_20191210.indb 6 2019/12/10 15:08

mechanical, photocopying, recording or otherwise, without the prior written permission of BUFFALO.

change specifications without notice.

6

DECLARATION OF CONFORMITY

Equipment Type • Uitrustingstype • Type d'équipement •

Model • Modèle • Modell • Modello • Modelo • Malli

DA957

Application of Council Directives(s)

Low Voltage Directive (LVD) 2014/35/EC

Producer Name • Naam fabrikant • Nom du producteur • Name

Buffalo

Producer Address • Adres fabrikant • Adresse du producteur •

Fourth Way,

United Kingdom

42 North Point Business

Ireland

Date • Data • Date • Datum • Data • Fecha • Data

3rd December 2019

Signature • Handtekening • Signature • Unterschrift

Full Name • Volledige naam • Nom et prénom • Vollständiger Name •

Position • Functie • Fonction • Position • Qualifica • Posición • Função

Technical & Quality Manager

• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •

Gerätetyp •Tipo di apparecchiatura • Tipo de equipo • Tipo de
equipamento

Toepassing van Europese Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare EU-Richtlinie(n) •
Applicazione delle Direttive • Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do Conselho

des Herstellers • Nome del produttore • Nombre del fabricante •
Nome do fabricante

Anschrift des Herstellers • Indirizzo del produttore • Dirección
del fabricante • Morada do fabricante

• Declaración de conformidad • Declaração de conformidade

Convection Oven

EN 60335-1:2012 + AC:2014 + A11:2014 + A12:2017 +
A13:2017
EN 60335-2-42:2003 + AC:2007 + A1:2008 + A11:2012
EN 62233:2008

Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU

EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013

Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU

Avonmouth,
Bristol,
BS11 8TB

Park
New Mallow Road
Cork

I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and
Standard(s).

Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de
bovenstaande Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n)
und Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s)
anterior(es) Directiva(s) e Norma(s)

Firma • Firma • Assinatura

Nome completo • Nombre completo • Nome por extenso

DA957_UK_A5_v1_20191210.indb 7 2019/12/10 15:08

Ashley Hooper
