Buffalo WZR-G240, AirStation MIMO 240 Specifications

MIMO 240 Wireless Router

SMART

ROUTER

CABLE/DSL

SECURITY

WPA AES

G/B

GHz

CHANNEL

SELECTION

AUTOAUTO

2x3

TRUE

MIMO

MIMO 240* Offers the Fastest Wireless Throughput at
Improved Range – Great for High-Speed Media Streaming!

Standard G

Turbo G

MIMO 240

Speed and Range*

AOSS™– One Touch. One Click. Done.

(1) Press the AOSS button on the router.

(2) Click on the AOSS icon in the Client Manager screen.

Done! A secure wireless connection is automatically established

between the router and the card.

Wireless PC
Desktop or Laptop

MIMO 240

MIMO 240 Offers up to 10x Faster Wireless Connections than Standard 802.11g!

Multiple In, Multiple Out (MIMO) technology utilizes multiple antennas to transmit and receive multiple wireless signals simultaneously, resulting in a
faster and more reliable wireless network at greater range than standard 802.11g solutions.

3x Faster

6x Faster

10x
Faster

he Buffalo AirStation MIMO 240 Wireless Cable/DSL Router WZR-G240 offers

T
up to 10X faster wireless throughput than a standard 802.11g router. Airgo
Gen-3 MIMO (Multiple In, Multiple Out) technology utilizes multiple antennas

o transmit and receive multiple wireless signals simultaneously, resulting in

t
a faster and more reliable wireless network than conventional wireless
solutions. With Adaptive Channel Expansion (ACE) technology, the

irStation MIMO 240 wireless solutions automatically detect and adjust to

A
interference allowing for maximum wireless throughput in any
environment. In addition to improved performance, the AirStation One­Touch Secure System

™

(AOSS™) allows you to set up a high-speed secure
wireless network within minutes. With 10/100 switch, you can add up to 4
LAN connections. The AirStation MIMO 240 Router is a great solution for
multimedia streaming offering high-speed wireless performance.

• MIMO 240* Technology (Multiple In, Multiple Out)

• Great for High-Speed Multimedia Streaming or Online Gaming

• Simple Web Browser Configuration

™

• Easy Setup With AirStation One-Touch Secure System

(AOSS™)

• Supports WPA-PSK (AES) and 128/64-bit WEP Security

• Includes NAT/SPI Firewall and Intrusion Detector

• Dynamic Packet Filtering

• Built-in DHCP Server

• Built-in 10/100 4-Port Auto-Sensing Switch

• Optimized High-Speed Routing, up to 10 Times Faster than Standard Routers

™

WZR-G240

MIMO 240 Wireless Router

MIMO 240:

W

LI-CB-G240*

H

igh Power Turbo G
Wireless Ethernet
Converter:

WLI-TX4-G54HP

Great for wireless

gaming!

802.

11

g/b

Wireles

s

Cli

ent Adapt

ers

:

WLI

-CB

-G5

4HP

WLI

-CB

-G5

4S

WLI

2-PCI

-G5

4S

WLI

-U2

-KG5

4-AI

*Recommended for maximum
performance and range

FOUR LAN Ports!

Connect additional PCs, Macs and other devices

WAN Port

Power Supply

Technical Specifications - WZR-G240

Wireless LAN Interface

tandard Compliance MIMO (Multiple In, Multiple Out),

S

IEEE802.11b, IEEE802.11g
Frequency Range 2.412 - 2.462 GHz (Channels 1-11)
Access Mode Infrastructure mode
Communication Protocol OFDM, DSSS
Antenna 2.4 GHz Antenna x 3 (external)
Security WPA-PSK (AES), 128/64-bit WEP,

MAC Address Registration

Wired LAN Interface

Standards Compliance IEEE802.3u (100 Base-TX)

IEEE802.3 (10 Base-T)
Transmission Encoding Method 100 BASE-TX 4B5B/MLT-3

10 Base-T Manchester Coding
Access Method CSMA/CD
LAN Port 10/100 Mbps, Auto Sensing, Auto MDIX
Number of LAN Ports 4
WAN Port 10/100 Mbps, Auto Sensing, Auto MDIX

High-Speed Routing to Support FTTH
Number of WAN Ports 1
WAN/LAN Port Connector RJ-45
Security Dynamic Packet Filtering, Intrusion

Detector, NAT/SPI Firewall

Related Products

Other

Power Supply 100-240V AC Universal, 50/60 Hz
Power Consumption 9.4W
Dimensions 8.5 x 7.0 x 1.9 in. (215 x 177.6 x 47.5 mm)
Weight 1.2 lbs. (560 g)
Operating Environment 0-40°C, 20-80% (non-condensing)
OS Support W

indows

Windows®Me, Windows®98SE

Package Contents

MIMO 240 Router, Quick Setup Guide, Ethernet Cable, Setup CD-ROM, Power Supply,
Warranty Statement

* 11 Mbps is the maximum wireless signal rate derived fr
from IEEE 802.11b Standard specifications. 240 Mbps is the maximum wireless signal rate utilizing two antenna/ three radio MIMO (Multiple In, Multiple
Out) technology when used with supported devices. Actual data throughput and range will vary depending upon network conditions and environmental
factors, including volume of network traf

© Buffalo Technology (USA), Inc. Buffalo Technology, Buffalo Technology logo and AOSS logo are registered trademarks of Buffalo Technology (USA), Inc.
The names and logos of other companies mentioned herein belong to their respective owners.

fic, building materials and construction, and network overhead.

om IEEE Standard 802.11b specifications. 54 Mbps is the maximum wireless signal rate derived

®

2000, Windows®XP,
