Buffalo WLE-DA2, AirStation G54 WLE-DA2 Specifications

Buffalo AirS tation™ G54

9 dBi High Gain Indoor Directional Antenna - WLE-DA2

The AirStation 9 dBi High Gain Wireless Indoor Directional Antenna, model

WLE-DA2 supports 2.4 GHz 802.1 1g and 802.11b wireless devices to increase

signal gain up to 2 times and boost wireless performance. An external MC to
RP-TNC connector is included for use with other manufacturers’ wireless devices.
The long 9 ft. cable offers the option for desktop placement or wall mounting.
Compact design, easy installation and adjustable antenna face angle provides a
perfect high gain antenna solution for any wireless network.

●●

9 dBi High Gain Yagi (Directional) Antenna

●●

Compatible with 2.4 GHz 802.11g/b Wireless

●●

Supports MC and RP-TNC Interfaces (connector included)

●●

Adjustable Antenna Face Angle

●●

Wall or Desk Mount

●●

Easy to Install, no software needed

●●

9 ft. Cable Included for Flexible Placement

●●

2-Year Warranty

●●

RP-SMA to MC coupler required for use
with the WHR-series routers.
Coupler not included.

WLE-DA2

Specifications

Polarization Method Vertical or Horizontal; Horizontal during

transmission

Connector Type MC, external MC to RP-TNC connector included

Frequency Range 2,401- 2,484 MHz (1-11 channels)

Antenna Gain 9 dBi (5.4 dBi including cable loss)

Operating Environment

40ºC, 20-80% (non-condensing)

Others

Dimensions: 100 x 100 x 17 mm (3.94 x 3.94 x 0.67 in.)

Weight: 0.3 kg (0.66 lbs.)

Package Contents: WLE-DA2 Antenna, Antenna Connector Adapter, Two

screws, Quick Setup Guide, W

Related Products: AirStation 2.4 GHz 802.11g and 802.11b wireless products,

other manufacturer’s 2.4 GHz wireless devices, MC and/or
RP-TNC connector interface

arranty Statement

© Buffalo Technology (USA), Inc. Buf

(USA), Inc. The names and logos of other companies mentioned herein belong to their respective owners.

falo Technology, Buffalo Technology logo and AOSS logo are registered trademarks of Buffalo Technology

www.buffalotech.com
