Bubbli BBPSWINGSTA User Manual

IMPORTANT! READ CAREFULLY AND

KEEP FOR FUTURE REFERENCE.

PORTABLE SWING

BBPSWINGSTA

READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE OF THIS CARRIER.
RETAIN THIS USER GUIDE FOR FUTURE REFERENCE.

WARNING

Failure to follow these warnings and assembly instructions could result in serious
injury or death. To prevent children from falling or being strangled in straps:

• Use the product only if your child meets all the following conditions:

o Cannot sit up by himself or herself.

o Is not an active child who may be able to climb out of the seat.

o Is less than 6 months old and weighs less than 20 lbs. (9 kg)

• Never leave a child unattended.

• Do not use this product if your child is able to sit up unaided.

• Do not let children play with this product.

• Always use the restraint system.

• This product is not intended for carrying a baby.

• Never move or lift the product while a child is in the seat.

• Never lift swing using the toy bar or harness as a handle.

• Never attach any additional strings or straps to product or toy bar.

• FALL HAZARD: Never place the swing on countertops, tables, on or near steps or

on any other elevated surfaces.

• Always use on a flat, stable floor.

IMPORTANT

• This product needs to be assembled by an adult and always used under adult
supervision.

• Swinging speed should be checked and tested before using with a child to gain an
understanding of each setting’s intensity.

• Care should be taken in unpacking and assembly.

• Examine product frequently for damaged, missing, or loose parts.

• Do not use if any parts are missing, damaged, or broken.

• Contact help.Kogan.com for replacement parts and instructions if needed. Never

substitute parts.

• This product is not intended for prolonged periods of sleeping. This product should
not replace a cot or bed. Should your child need to sleep, it should be placed in a
suitable cot or bed.

To Prevent Serious Injury or Death:

• Use only in reclined position until your child can hold head unassisted. Young
infants have limited head and neck control. If the swing is too upright, infant’s head
can drop forward, compress the airway, and result in death.

• Never use as an infant carrier for automobile or airline travel.

• To avoid injury, ensure that children are kept away when unfolding and folding this

product.

• Do not allow children play with this product.

• Be aware of the risk of open fire and other sources of strong heat, such as electric

bar fires, gas fires, etc. Near the product.

• This product is not intended for prolonged periods of sleeping. This product does
not replace a cot or a bed. Should your child need to sleep, then it should be
placed in a suitable cot or bed.

• Do not use the product without the seat cushion.

• If this product shows any sign of damage, cease use immediately and contact

help.Kogan.com for support.

• Do not place the swing near windows or walls, where strings, curtains or other
objects may be used by the child to climb out of the swing seat and to prevent the
risk of suffocation or choking.

• Do not place the swing near windows or walls, to prevent your child from affecting
the stability of the swing making it topple over, by pushing against the wall.

• When not in use, remove the batteries and store safely away from children.

• SUFFOCATION HAZARD: Never use on soft surface (bed, sofa, cushion), as seat

may tip over and cause suffocation.

For Safe Battery Use:

• Keep the batteries out of children’s reach.

• Do not mix old and new batteries.

• Do not mix alkaline, standard, or rechargeable batteries.

• Only batteries of the same or equivalent type as recommended are to be used.

• Install the batteries so that the polarity of each one matches the markings in the

battery compartment.

• Do not short-circuit the batteries.

• Do not store batteries in areas that have extreme temperatures (such as garages,

or automobiles).

• Remove exhausted batteries from the battery compartment.

• Never attempt to recharge a battery unless it is specifically marked

“rechargeable.”

• Rechargeable batteries are to be removed before being charged.

• Rechargeable batteries are only to be charged under adult supervision.

• Do not use rechargeable alkaline batteries in a Ni-Cad or Ni-MH battery charger.

• Ensure batteries are disposed of in accordance with your local environmental

authorities.

• Always remove batteries before putting the swing into storage for an extended
period.

• Weak batteries cause erratic product operation, including distorted sound,
dimming or failed lights, and slow or non-working motorized parts. Because each
electrical component requires a different operating voltage, replace the batteries
when any function fails to operate.

• Do not dispose of product or batteries in fire, batteries may explode or leak.

• Only the recommended batteries (voltage and size) or equivalent are to be used.

• Any battery may leak battery acid if mixed with a different battery type, if inserted

incorrectly (put in back-wards) or if all batteries are not replaced or recharged at
the same time. Do not mix old and new batteries. Do not mix alkaline,
standard(carbon-zinc) or rechargeable(nickel-cadmium) batteries.

• Any battery may leak battery acid or explode if disposed of in fire or an attempt is
made to charge a battery not intended to be recharged.

• Never recharge a battery of one type in a recharger made for another type of
battery.

• Dispose of leaky batteries immediately. Leaky batteries can cause skin burns or
other personal injury.

• Always remove batteries if the product is not going to be used for a month or more.
Batteries left in the unit may leak and cause damage.

• Recommended type batteries-alkaline disposables, size AA (LR6-1.5V). Never mix
battery types. Change batteries when product ceases to operate satisfactorily.

A. Left Seat Frame

B. Right Seat Frame

C. Seat Pad

D. Toy Bar

E. Left Motor Assembly

F. Right Motor Assembly

G. Footrest Tube (x2)

H. Power Adapter

I. Remote Control

Power

Speed buttons

(1 – 5)

Music (9 Melodies)

Volume decrease

Nature sounds button

(5 songs)

Volume increase
Timer buttons

(15, 30 & 60Minutes)

Battery

Compartment

Power

Speed (1 – 5)
Timer

Music (9 Melodies)

Volume decrease

Volume increase

Nature sounds button

(5 songs)

Timer

indicator

Speed

indicator

Remote control

receiver

Remote Control:

Control Panel:

Left

Right

Power

input

Right

Left

"Click"

Step 1:

Remove the left and right motor assemblies then open the two legs until a “click” is heard.

Step 2:

Attach both footrest tubes to the left and right motor assemblies until a “click” is heard.

Note: Pay attention to the orientation of motor assemblies, as shown below.

"Click"

Step 3:

Attach the left & right seat frames together until a "click" is heard.

Step 4:

Attach the seat pad to the assembled seat frame ensuring it is securely in place.

Step 5:

• Attach the assembled seat frame to motor assemblies until a “click” is heard.

• Install the toy bar and toys by inserting both ends of the toy bar into the support

hole at either side of the seat frame.

• To release the toy bar, press the two release buttons at the end of the toy bar and
pull away from the seat frame.

x4 AA Batteries

Button battery

(CR2025)

Battery Installation

Remote control:

• Slide out the remote control battery tray and insert a CR2025 button battery (not
supplied) into the tray. Pay close attention to the orientation of the polarity
symbols.

• Replace the battery tray.

Control panel:

• Release the Philips head screw and remove the battery compartment cover.

• Install four (4) AA batteries into the battery compartment. Pay close attention to

the orientation of the polarity symbols.

• Replace the battery

Button

Description

Power

Turns the swing on and off

Speed
Remote control

Select from one of the five speed settings (1 - 5)

Control panel

Cycles through the five speed settings

Timer
Remote control

Sets the timer (15, 30 & 60mins)

Control panel

Cycles through the three timer options

Music

Cycles through the 9 different melodies

Nature sounds

Cycles through the five different nature sounds

Power Adaptor

Power

• Connect the power adaptor to the motor assembly power input.

• Connect the power adaptor plug into a power socket.

Button Functions

Press the two buttons on the sides of the toy bar simultaneously to adjust the position of the
toy bar. There are two positions available.

Folding:

To fold the swing frame, press the buttons in the front and back sides of the swing frame.

WARNING: Ensure your child’s fingers are kept away when fastening
the buckles. Always use the restraint system.

CLICK

Swing Lock:

Press the lock button to stop the sear from swinging. If you want to resume swinging, just
release the lock button.

Safety Belt:

• Use the two shoulder straps to secure your child in position.

• Carefully attach the side to the central buckle.

• Adjust the safety harnesses belts so your child is securely in place as shown below.

Maintenance

• This product requires regular maintenance to keep it in good working order.

• Regularly check all parts of the product to ensure that they are operating correctly

and for signs of wear or damage.

• All electrical components should be regularly examined for signs of wear or
damage. If damaged, cease use immediately and contact help.Kogan.com for
support.

Cleaning

• Refer to care label on the product for cleaning instructions for fabrics.

• Clean metal or plastic components with mild detergent and warm water.

• Never use abrasive, ammonia based, bleach based or spirit type cleaners.

• Ensure the product is fully dry before use or storage.

Need more information?

We hope that this user guide has given you

the assistance needed for a simple set-up.

For th e mo st u p-to-date guide for your product,

as well as any additional assistance you may require,

head online to help.kogan.com.
