bto plus deck2c Manual For Use And Installation

BTO Co., Ltd. www.plusdeck.com

Manual for Use and Installation(a warranty card enclosed)

Thank you for using Plusdeck2c

This manual includes the installation process, Plusdeck2c operation, and troubleshooting. In the back of the manual included is the registration card.

User manual (a warranty card enclosed) Version. 3.50

■The contents of this manual can be changed without prior notice due to any

change in the product.

■ Printed images may differ from the actual images.

■Copying or distribution of the contents of this material without our written

permission is forbidden.

Before Installation

1. About Plusdeck2c ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 4

2. Product Information and Requirements ⋯⋯⋯⋯ 5

3. Plusdeck2c components ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 5

4. Plusdeck2c specification and electromagnetic wave regulation⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 6

5. Suggestions when installing and using Plusdeck2c ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 7

6. Electromagnetic Waves Validation ⋯⋯⋯⋯⋯⋯ 7

7. Suggestions about Installation And Use ⋯⋯⋯⋯ 8

Note: Throughout this manual, the names PC and

computer are used interchangeably.

플러스데크2c사용

1.Before installation ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 3

2.Installing Plusdeck2c ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 9

3.Connecting Plusdeck2c⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 15

4.Getting Started ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 21

5.Using Plusdeck2c ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 33

6.Getting more out of Plusdeck2c⋯⋯⋯⋯⋯⋯ 47

7.Warranty and Registration Card⋯⋯⋯⋯⋯⋯ 63

Contents

Part 1

Before Installation

•It uses normal type cassette tapes.

•It is a cassette deck for PC.

•It has software controlled full logic mechanism.

•It is assembled with a high quality Japanese deck and audio mechanism to deliver

CD quality sound.

•It has auto-reverse function.

■ The followings are possible with the Plusdeck2c.

•Play the tape: Listen to the cassette tape on your PC.

•Convert the tape: Sounds in cassette tapes can be converted to the digital

files on PC as wav or mp3 format.

•Save Streaming audio into files on PC

www.plusdeck.com

●

About Plusdeck2c

Patent issue 0390012/International patent PCT/KR01/1567 Registration of design 30-2001-0034551 Registration of program 2001-01-23-4046

Best prize of the second Digital Innovation/Success Design of KIDP (Korea Institute of Design Promotion, 2002)/Procurement Success Designed Special Product chosen by Supply Administration/Best New Product chosen by Hankook Ilbo/Hit Product chosen by Electronic Newspaper/Hit Product chosen by Computer Times/Emerging SuccessTechnique Award chosen by the Seoul Economy, etc..

•5.25” bay 1EA

•Expansion slot 1EA

•Soundcard(analog Line In)

•Minimum 10M of hard drive space for the software installation

•Windows 95/98/ME/2000/XP(Windows is the trademark of Microsoft)

Product Information

Requirements for Plusdeck2c installation

Part 1

Before Installation

www.plusdeck.com

●

Check all following components are in the box. If you find any component missing or damaged, contact the distributor or manufacturer.

1. Plusdeck2c main body 2. 20 pin cable

3. Connection card 4. Serial cable(RS232C cable)

5. Stereo cable 3 EA 6. Installation CD

7. User manual 8. Fixing screws

■A crossed screwdriver is needed to install the Plusdeck2c.

■ If you move it to a different computer, all other components should follow it.

Plusdeck2c components

❶ Plusdeck2c main body

❸ Connection card

❺Stereo Cable 3 EA

❼User manual ❽Fixing screws

❻Software CD

❹Serial cable (RS232C cable)

❷20 pin cable

green

blue

pink

Plusdeck2c Specification

Electromagnetic Wave Compliances

E-H900-01-5845(B)

•Size (W×H×D): 145×40×215mm

•Tape speed: 4.75Cm/sec

•Wow & Flutter: 0.09%(WRMS)

•Frequency response: 20 ~ 18,000Hz

•Separation: 40dB

•Signal to Noise Ratio : 55dB

•Power: DC12V

FCC Information

This is device complies with Part 15 of the FCC Results. Operation is subject to the Following two conditions: (1) This Device may not cause harmful interface, and (2) This Device must accept any interference received,

including interference that may cause undesired

operation. Note: This equipment has been tested and found to comply with the limits for CLASS B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radiocommunications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures:

1.1.Reorient or relocate the receiving antenna.

1.2.Increase the separation between the equipment and receiver.

1.3.Connect the equipment into an outlet on a circuit different from that to which receiver is connected.

1.4.Consult the dealer or experienced radio/TV technician for help.

WARNING

Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment.

FCC ID : R4EPlusdeck2c-1

Installing Plusdeck2c

1 Make room for the installation ⋯⋯⋯⋯⋯⋯⋯⋯10 2 Inserting Plusdeck2c ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯11 3 Connecting 20 pin cable⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯11 4 Connecting power cable ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯12 5 Fixing connection card and Plusdeck2c ⋯⋯⋯⋯13 6 Closing PC case ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯14

Part 1

Before Installation

•Make sure that the power is off during the installation.

•A caution should be given with the sharp edges inside the PC

•Do not leave other materials or do not touch other parts inside the PC.

•Avoid a direct exposure to the sun or moisture when installing.

•Mechanical or chemical damage should be avoided.

•Keep screws or other small components out of children’s reach.

•Do not use bent or damaged tapes.

•Do not move the product while in operation.

•A great care must be given when using important tapes.

•Avoid inserting the finger or materials other than tapes.

•Do not disassemble, modify, fix the product by an unauthorized personnel.

www.plusdeck.com

●

Suggestions when installing and using Plusdeck2c.

1.Fully insert the Plusdeck2c into an empty 5.25”bay.

2.Make sure that the back of the Plusdeck2c does not touch other PC components.

3.For some PC models, you may need a side bracket to hold the Plusdeck2c. (A side bracket is sold separately.)

1.Connect one end of the 20 pin cable to the Plusdeck2c and the other end to the connection card. Connecting 20 pin cable may well be done after step 5.

2.The 20 pin cable is connected between the Plusdeck2c and ocnnection card. Notice that there is a notch in the middle of the connector which prevents you from connecting the cable upside down.

Inserting Plusdeck2c

Connecting 20 pin cable

Part 2

Installing Plusdeck2c

www.plusdeck.com

●

Make room for installation

1.Open the PC case.

2.Caution should be given with sharp edges inside PC.

3.Locate an empty 5.25 inch bay where Plusdeck2c is installed.

Note •How to open the case differs from manufacturer to manufacturer.

•If you are having a difficulty, read the user’s guide or contact the PC manufacturer.

•Turn the power of PC off before installing.

•It can cause an electrical shock if it is installed with the power switch

on.

Caution

1.Fix the connection card at an empty slot of PC with a screw.

2. It can be installed in any empty slot as it does not connect to a PCI bus or controller.

3. Fix the Plusdeck2c main body with screws as shown in the picture on the left.

4. In order to reduce noise or other related problems, fix all PC components firmly.

5. It is recommended that you use the screws that come with the product to fix the product well.

Fixing Connection Card and Plusdeck2c

Part 2

Installing Plusdeck2c

www.plusdeck.com

●

1. The internal power cable is shown in the picture on the left.

2. A 4 pin power cable supplies 5V and 12V.

3. Before connecting the power cable, check the power cable direction as shown in the picture.

4. The rounded edge of the power cable must face downward when inserted.

5. An extra caution should be used as the power cable connection of the Plusdeck2c can be different from that of CD or DVD drive.

6. If the power cable is connected wrong, it could damage the the unit.

7. If there is no available power cable, a Y adapter power cable can be used for extension.

Connecting Power Cable

four lines of power cable (yellow, black, black, red)

power cable of computer(inside computer)

Connecting Plusdeck2c

1. About the connection card ⋯⋯⋯⋯⋯⋯⋯⋯⋯16

2. Connect serial cable ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 17

3. Connect to the sound card ⋯⋯⋯⋯⋯⋯⋯⋯⋯ 18

1. Standard connection

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

2. Advanced connection

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

3. Microphone connection

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

Part 2

Installing Plusdeck2c

1.A completed cable connection inside PC is shown in the figure on the left side.

2.Close the PC case to finish the installation.

www.plusdeck.com

●

Closing PC case

1. Connect the serial cable between the serial ports of the connection card and PC.

2. “Hardware Connect error”message appears if the serial cable is not properly connected and the software will not work.

3. The PC serial port is usually located near the printer port below the mouse and key board port.

4. The 15 pin port in the sound card is a MIDI port not a serial port.

5. The serial cable included in the product uses 1:1 direct communication. The crossly connected serial cable will not work with the Plusdeck2c.

6. In case the serial port in the PC is out of order or not available, install a PCI RS232 expansion card to make a serial port.

7. The USB/serial connector will not work as it does not allow two way communication.

Part 3

Connecting Plusdeck2c

1. The connection card can be installed in any slot of the PC as it does not connect to a PCI interface. It lets the Plusdeck2c communicate with the PC(serial port and sound card).

2. Its main components as shown on the left side consist of A. 20 pin cable connector B. audio input/ouput ports C. serial port D. Jumper (default value – open)

3. The jumper D is the switch to ground the Plusdeck2c circuitry. The default value is open position. Changing it to short position could improve the sound quality.

4. The tape sound from the Plusdeck2c flows out of the blue jack of the connection card and flows into the PC.

www.plusdeck.com

●

About Connection card

Connecting Serial Cable

The same port can be found in the back of the PC.

Part 3

1. Standard Connection

①Connect the blue jack of the connectin card to the blue jack of the sound card

with the blue stereo cable. If the sound card jacks do not have color distinction, find the jack with “inward arrow” icon.

②If “Line In” of the soundcard can not be located, contact the sound card

manufacturer for more information.

③The tape sound flows out of the blue jack of the connection cand and flows into

the blue jack of the sound card. Then the sound card delivers this sound to the speaker or store it on the PC

④Using with the TV capture car

The TV capture card works like the Plusdeck2c by sending the analog sound to Line In jack of the sound card. Since two cables need to be connected to one input jack, a Y jack can be used. But with a Y jack, one of the input sound levels could be reduced due to an impedance difference. If this happens, use an audio splitter instead.

www.plusdeck.com

●

Connecting to Soundcard

2. Advanced connection

①The advanced connection is useful when a headphone set is used. The

headphone sound volume can be adjusted by the volume control located in the front panel of the Plusdeck2c. Since the headphone is a two channel system, output sounds from rear and center speakers can still be heard if you are using a multichannel system.

② Connection to use a headphone set

A. Move the speaker cable connected to the green jack(Line Out)of the sound

card to the black jack of the connection card. (If a multi channel speaker setup is used, other speaker cables except the one to the green jack of the sound card should remain where they are.)

B. Connect the green jack of the connection card to the green jack of the sound

card with the green stereo cable.

C. Sound flow -Before advanced connection : green jack(Line Out) of the sound

card 󱈇 speaker After Advanced connection : green jack(Line Out) of the sound card 󱈇 green jack of the connection card 󱈇 headphone in the front panel(or black jack of the connection card 󱈇speaker)

Connecting Plusdeck2c

•Tape sound out jack

•This is connected to Line In of the sound card.

CBA

Part 3

Connecting Plusdeck2c

3. Connecting to Soundcard

①Connect the pink jack(D) of the connection card to the pink jack of the soundcard

with the pink stereo cable.

www.plusdeck.com

●

•

If the advanced connection is not done, no sound will be heard through the

headphone jack.

•

The tape playing sound will be heard from the front panel jack only when the advanced connection is done.

•

Make sure that the headphone volume control is not in the minimum position.

Caution

Now all cable connections are completed. Follow the steps in Section 4 to test the installation.

Check

Getting Started

1. Starting PC ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯23

2. Checking power supply⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 24

3. Checking tape playback sound ⋯⋯⋯⋯⋯⋯⋯ 26

4. Installing Software ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 28

1. Methods of installation

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

2. Installation

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

5. Running Software ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 31

Starting the PC

www.plusdeck.com

●

Part 4

Getting Started

•Check if the power cable is connected properly or power switch is on.

•There are too many devices connected or power supply is not sufficient.

Upgrade the power supply or remove devices no longer in use

•Check if other PC parts are properly connected or get loosened.

Problem/Solution - PC won’t start

Start PC after you plug the power switch on.

After the installation and cable connection is finished, this section lets you test the setup and helps familiarize yourself with the Plusdeck2c operation.

Getting started with the Plusdeck2c

Part 4

Getting Started

•If you push the tape by 2~3 cm, it will be inserted by itself.

•Do not insert the tape by force. If the tape is not inserted automatically,

most likely the power is not supplied. See the next page.

•Plusdeck2c assumes the top side of the inserted tape as A side.

•When the tape is inside Plusdeck2c, the swinging door in the front face

may look open.

www.plusdeck.com

●

Checking the power supply to the Plusdeck2c

󱈻󱈻

Side A

The tape should be inserted as shown in the picture on the left. When the power is normally supplied to the Plusdeck2c, the tape should be inserted without excessive force and ejected by itself with the eject button.

When the power is not supplied or the power cable is not properly connected, the Plusdeck2c will not operate. Check these

1. The power supply cable to the Plusdeck2c is connected upside down

- the rounded side of the power supply should go downward.

2. The power supply cable is dead

- connect with a different power supply cable.

Problem/Solution

•If all LED lights are dimmer, the power cable is connected upside down.

•If all LED lights are flashing constantly and the tape can not be inserted or

ejected, the tape gets stuck or the Plusdeck2c has a mechanical problem.

•Contact the distributor or manufacturer for service.

Caution

Part 4

Getting Started

www.plusdeck.com

●

Checking the tape playback sound

1. Check the standard connection in page 18.

2. To hear the sound from the headphone jack in the front panel, the advanced connection in page 19 must be completed.

Problem / Solution 1

1. Check if Line In in the Recording control window is selected.

•Windows98 : Start

Control Panel 1Multimedia 1Audio

Click Sound playback

•Windows XP : Start

Control Panel 1Sound and Audio devices 1Audio

Click Volume in Sound playback.

(If line in is not seen in the recording control window, click Option -

Properties and select line in and click OK.)

2. If Line In in the volume control is muted, mute must be unchecked. Also increase the Line In level if it is set too low.

Problem / Solution 2

If you still not hear the sound after steps 1 and 2 are checked, it is likely that the Line In of the soundcard has been assigned to perform a different function. In order for the sound card with only three jacks(Line In, Line Out, Mic) to support a multichannel speaker setup, Line In and Mic jack are used as Line Out. To fix this problem, you need to select desktop stereo speaker(2 channel) setup instead of multichannel speaker setup.

Problem / Solution 3

•After the tape is inserted, play the tape by pushing the playback button shown in the picture on the left side.

•If you don’t hear the tape sound, check the following problem/solution.

PlayBack Button

Part 4

Getting Started

www.plusdeck.com

●

If you agree to te terms of the licence, click Next to continue the installation.

Click Next

Specify a folder where Plusdeck2c is Installed.

Installing Software

1. Methods of installation

1) Install over the internet

① Go to http://www.plusdeck.com ② Search for the latest version at DOWNLOAD menu ③ Download the software

2) Install from a CD

① Insert the Plusdeck2c installation CD in the CD-ROM drive ②If the setup program is not started automatically, double click setup.exe in the

disc.

2. Start Installing

Running the software

Part 4

Getting Started

www.plusdeck.com

●

①The software can be started by either double clicking the shortcut icon in the

desktop or clicking start

Plusdeck2c

② When the software has started, the interface as shown on the left appears. ③ The software is closed by clicking X on the upper right corner.

Click Next

The installation is in progress.

Click Stop to finish the installation.

Close program

Part 4

Getting Started

www.plusdeck.com

●

Using Plusdeck2c

1. Inserting the tape ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 34

2. Plusdeck2c hardware⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 36

1. Command Buttons

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

2. LED lights

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

3. Using Software ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯39

1. Operating Deck

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

2. Converting and Recording

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

3. Menu List

⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯

1. The problem with the serial cable

① The serial cable is not properly connected. (See page 17) ②The serial cable you are using is not provided by us. (The Plusdeck2c uses 1:1

direct communication. The crossly connected serial cable will not work with the Plusdeck2c.)

③ The pin in the serial cable has been bent.

2. The problem with the serial port

①The serial port is already in use by other device.

- Other program (including previously installed program) may be blocking the serial port. This program must be removed.

②The serial port is set to disable at the BIOS setup.

- Change the setting to auto or enable.

3. Others

① When there is no power supplied ② When multiple Plusdeck2c software’s were launched ③ When the serial port has gone bad

Software will not run

Problem / Solution

If the serial port is not available or out of order, a PCI RS232 expansion card can be used to make an additional serial port. An unknown serial port problem may go away if you use a PCI RS232 card.

Note

Part 5

Using Plusdeck2c

www.plusdeck.com

●

1. Wet tapes(can cause rust in the deck)

2. Physically bent or damaged tape

3. Tape with loose label or partly detached label

Do not use the Following T apes

1. Insert the tape as shown in the picture on the left.

2. If you push the tape gently, it is inserted by itself.

3. Do not insert the tape by force. It can damage the deck.

4. The Plusdeck2c recognizes the top of the inserted tape as A side.

5. When the tape is inside the deck, the swinging door in the front face may look open.

6. Make sure the tape is well winded before inserting. A loosened tape could get entangled.

7. Foreign materials inserted inside the deck could damage the deck.

Inserting the tape

■When the tape can not be inserted, the possible causes are

A. The tape is bent significantly B. The power supply problem - the power cable is connected upside down or

the power cable is dead

Caution

󱈻󱈻

Side A

Caution

■Do not leave the tape inside the deck for long when it is not in use.

■When longer tapes(C-90 or C-120 minutes) are used, a care must

be given to prevent any damage as these tapes are thinner than C-60 minute tapes.

Caution

I : Headphone jack - You can hear all sounds from PC or tape sound using a

headphone set.

J : Microphone jack - You can connect an external microphone to this port. It

supports mono and stereo microphone.

L : LED lights - 2 green and 1 red LED lights show the status of the Plusdeck2c

operation.

Part 5

Using Plusdeck2c

1. Command Buttons

A : Playback A side B : Playback B side C : Stop - Stop all Plusdeck2c operation D : Pause playing back the tape E : Volume Control - adjusting the volume of the headphone jack in the font panel

of the deck F and K : Eject the tape G : Fast forward H : Fast rewind

www.plusdeck.com

●

Plusdeck2c main body

CA E F G H J KI

If E is at the minimum position, no sound will be heard from the headphone jack.

Caution

The stereo cable connection described in page 19 must be done properly in order to use the front panel headphone and microphone jack.

Caution

1. Deck control buttons

- Control buttons for playing the tape on the PC

A. Window shows the status of Plusdeck2c operation.

B. Mode of operation

󱂧 stops at the end of the current side 󱂨 auto-reverse mode 󱂩 continuous playing mode

C. Control buttons – play, fast froward, fast rewind, pause, stop, eject

Plusdeck2c main body

Part 5

Using Plusdeck2c

www.plusdeck.com

●

2. LED indicator

LED lights(1 red, 2 green) show the status of the Plusdeck2c operation.

※◀▶ : Flashing arrow

All 3 LED lights are flashing constantly when the tape gets stuck or the Plusdeck2c has a mechanical problem.

Note

ejectstoppause

fast

rewind

play B side play A side

fast forward

LED Condition

Nothing No tapes Gray shows flickered

◀▶ Tapes are inside

▶ Play side A

◀ Play side B

▶ Fast forward

◀ Fast rewind

Part 5

Using Plusdeck2c

www.plusdeck.com

●

1. file setting

Press Configure to open the file setting window.

A-1(Tape Side) option includes ① A side ② Bside ③ auto reverse

④ auto reverse but it splits between A and B side ⑤the timer

2. Converting and Recording

Digital files are generated using A, B, and C control buttons. A (Configure) : File setting can be changed.

B (Convert) : Convert the tape into digital files C (Save) : Record the PC output sound to digital files.

AB C

A-1

A-2

A-3

①② ③ ④ ⑤

Part 5

Using Plusdeck2c

www.plusdeck.com

●

A-3(Auto Cut) One file option generates an entire tape in one file. Files option

splits the tracks and creates each track as a separate file. It is not recommended to use Files option for the tape with voice recording because it can create numerous files as it cuts wherever there is no sound.

A-2(Type) specifies file format

①

Wave is a Windows native file format which requires a large storage space

②

Mp3 is a compressed file format which requires a less storage space. The number following Mp3 indicates bit rate. The higher the number is, the better the sound quality is. Mp3 64 option is recommended for converting voice and mp3 64 or higher for converting music.

③

The table below shows the file size comparison table between wave and various mp3 bit rate file format.

(

The number of after mp3 is bitrate. The size of file is approximation.

)

A-1 A-2

A-3

①②③ ④ ⑤

A-1 A-2

A-3

①②③ ④ ⑤

Why converting can be done only in real time

High speed recording between different medium can not be done at this point due to the speed error problem.

Recommended option

When using Files option, the number of created files differ from soundcard to soundcard as input level values depend on soundcard. So Line In level in Recording Control window should be adjusted for Files option to improve.

Note

The file setting will not change once it is set.

Note

Sorts of file Capacity for 1 min Sorts of file Capacity for 1 min

Wave 10MB Mp3 64 0.5MB

Mp3 256 2MB Mp3 32 0.25MB Mp3 192 1.5MB Mp3 16 0.125MB

Mp3 128 1MB Mp3 8 0.063MB

Part 5

Using Plusdeck2c

www.plusdeck.com

●

3. Save button in C records PC output sound to digital files ①All output sounds from the PC, such as, internet radio, CD, DVD, can be

recorded to the PC.

②A window which lets you specify a folder and file name appears when Save

button is pressed. Recording is stopped by pressing ■button located on the right side.

2. Convert button in B convert the tape to digital files

① This is the main funtion of the Plusdeck2c. ②Converting can be started when the tape is inside the deck and the deck is not

in operation.

③A window which lets you specify a folder and file name appears when convert

button is pressed. After you click OK button, the tape palys and converting is started.

④You can manually stop converting by pressing button on the right side.

Othewise, it will stop accoding to the option selected.

It is recommended that you test a short portion of the tape before converting an entire tape.

AB C

Getting more out of Plusdeck2c

1. Deck operation ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 49

2. Converting the tape to digital files ⋯⋯⋯⋯⋯⋯ 50

3. Saving PC output sound as digital files ⋯⋯⋯⋯ 53

4. Optimizing sound quality ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 56 5 Editing digital files ⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 61

Part 5

Using Plusdeck2c

www.plusdeck.com

●

3. Menu list

① Shows the version of the current software. ② Directs you to the online manual. ③ Directs you to the manufacturer’s web site. ④ Lets you send you an email to the manufacturer. ⑤ Lets you to adjust the soundcard setting.

A. Auto setting off turns off auto setting B. View volume opens volume cotrol panel C. View Control Panel opens control panel

⑥Lets you operate the Plusdeck2c by the keyboard. ⑦ Lets the Plusdeck2c appear above other windows. ⑧ Close the program.

① ② ③ ④

⑤ ⑥ ⑦

⑧

1. Inset the tape as shown in the picture on the left and start the software.

2. Try fast forward or fast rewind to check the tape condition.

3. The Plusdeck2c assumes the top of the inserted tape as A side.

4. F.F. (▶▶) winds the tape to the end of Side A and REW (◀◀) rewinds to the

beginning of Side A.

Operating deck

www.plusdeck.com

●

Part 6

Getting more out of Plusdeck2c

This section explains step by step

1. how to operate the deck,

2. how to convert the tape into digital files,

3. how to save PC output sound as digital file

4. how to troubleshoot

5. how to optimize sound quality.

6. How to edit digital files

Familiarize yourself with these features by repeating several times.

Note

󱈻󱈻

Side A

If the tape is not inserted, see page 24. If the tape sound is not heard, see page 26.

Problem/Solution

www.plusdeck.com

●

Converting the tape to digital files

Part 6

Getting more out of Plusdeck2c

1. Insert the tape to be converted.

2. Start the Plusdeck2c software.

3. Find where you want to start converting in the tape and stop all Plusdeck2c operation.

4. Setting can be changed by clicking Configure button. The setting does not need to be changed each time because the previous setting is stored.

5. Click Convert button under Tape ▶Digital File menu

6. Specify a folder and file name when Save As window appears. (Special characters such as ?./ can not be used in the name.)

7. If you click Save button, converting is started while the tape is being played.

8. Click ■(Stop) button to finish the process manually or the process will continue until it stops according to the stop option selected.

9. File is stored first as native wave format. If mp3 format is selected, wave file is compressed to mp3 and wave file is removed afterward.

10. If wave format is selected, the process ends without mp3 compression process.

(If the intended job is to make an audio CD, it is recommended that file be stored as wave format.)

Specify a folder and file name

Compressing wave to mp3

In case there is no sound in created files, the sound card setting needs to be changed as shown in the picture on the left.

1. Check the sound card setting in the control panel Windows98: Start

Control Panel 1Multimedia

WindowsXP: Start 1Control Panel 1Sounds and Audio devices 1Audio tab

2. Sound playback and recording device must use the same device. If Sound recording appears gray, the sound card driver needs to be reinstalled.

3. Click Volume in Sound recording and check if Line In is selected. The Line In volume level should be increased if it is set too low.

Problem/Solution 1

Windows

1. Start the software.

2. File setting can be changed by clicking Configure button. The setting does not need to be changed each time because the previous setting is stored.

3. Click Save button in PC ▶ Digital File menu.

4. Specify a folder and file name when Save As window appears. (Special characters such as ?./ can not be used in the name.)

5. If you click Save button, PC output sound is recorded as a file.

6. Click ■(Stop) button to stop recording.

7. File is stored first as native wave format. If mp3 format is selected, wave file is compressed to mp3 and wave file is removed afterward.

8. If wave format is selected, the process ends without mp3 compression process. (If the intended job is to make an audio CD, it is recommended that file be stored as wave format.)

Saving PC output sound as digital file

Part 6

Getting more out of Plusdeck2c

www.plusdeck.com

●

If the above step does not fix the problem, Line In of the sound card functions as Line Out or it is out of order.

1. In the program which controls the sound card, check if Line In jack is set to Line Out jack.

2. If none of the above fixes the problem, it is likely that Line In of the sound card(Line In) is out order. You should use a different sound card.

Problem/Solution 2

Even if the sound card driver is not installed, the sound card can output sound. However, the sound card driver must be installed to use Plusdeck2c as it uses other sound card functions also.

Note

Specify a folder and file name

Compressing wave to mp3

󱈨

Part 6

Getting more out of Plusdeck2c

www.plusdeck.com

●

In case there is no sound in created files, the sound card setting needs to be changed as shown in the picture on the left.

1. Check the sound card setting in the control panel Windows98 : Start

Control Panel 1Multimedia

WindowsXP : Start 1Control Panel 1Sound and Audio devices 1Audio tab

2. Sound playback and recording device must use the same device. If Sound recording appears gray, the sound card driver needs to be reinstalled.

3. Click Volume in Sound recording and check if Stereo Mix is selected. The Stereo Mix volume level should be increased if it is set too low.

Problem/Solution

The name Stereo Mix may be called differently in some sound cards. The item which corresponds to Stereo Mix must be selected.

In order to find the correct one, refer to the manual or select the item one by one to find which one successfully saves.

Problem/Solution

The items on the Recording control window are sound sources which the PC can recognize. Only one sound source can be selected. When converting the tape, the PC accepts sound from Line In source. When saving PC output sound, the PC accepts sound from Stereo Mix source.

Note

2. Controling tape playing sound

1. Line In level in master volume control panel controls the tape palying sound level.

2. If Line In volume level is the minimum or muted, the tape sound will not be heard.

3. When converting the tape to digital files, if Line In in master volume panel is muted, you will not hear the tape playing sound but converting will be done.

4. If volume level in volume control or wave is the minimum or muted, you will not hear any PC output sound.

5. Unneccessary items, such as phone or AUX, should be muted to improve sound quality.(Volume control, wave, Line In must NOT be muted.)

Part 6

Getting more out of Plusdeck2c

1. Understanding Sound Card Setting

There are two sound control panels - one is master volume control panel which controls output sound and the other is recording control panel which controls input sound.

•Windows98 : Start

Control Panel 1Multimedia

•WindowsXP : Start

Control Panel 1Sounds and Audio devices 1Audio tab

▶Click Volume button in Sound playback to open master volume control panel and

click Volume button in Sound recording to open recording control panel.

▷If you don’t see the items you want, they may be added. In each panel, go to

Option - Properties and select items you want to add. Click OK to complete the process.

www.plusdeck.com

●

Optimizing Sound Quality

Master Volume control panel

▶

◀

Recording control panel

Part 6

Getting more out of Plusdeck2c

3. Controling volume level when converting the tape

1. Line In volume level in Recording control panel controls the input volume level

2. If Line In is not selected or volume level is the minimum, created digital files will have no sound.

3. If volume level is too high, sound can be distorted. So adjust volume level bar up and down to optmize sound quality.

4. In most sound cards, 50~70% value should be good but this depends on the sound card you have.

5. After the sound card setting is optimized, if sound quality of created file is significantly degraded from the original tape, most likely Line In of the sound card has gone bad. You should test with a different sound card.

www.plusdeck.com

●

4. Controlling volume level when saving PC output sound

1. Stereo Mix volume level in recording control panel controls the input volume level.

2. If Stereo Mix is not selected or volume level is the minimum, created digital files will have no sound.

3. If volume level is too high, sound can be distorted. So adjust volume level bar up and down to optmize sound quality.

4. In most sound cards, 50~70% value should be good but this depends on the sound card you have.

The name Stereo Mix is called differently depending on the sound card you have. Some of other names are What you hear, Wave Out, etc⋯

Note

1. It is very difficult to edit sounds in the tape but it is simple to edit converted files using a sound editing software.

2. Ther are many programs available, such as Gold Wave, Cool edit. Among them, the simplest but very powerful to use is Wave Pad by NCH.

3. Wave Pad can be downloaded from http://www.nch.com.au/wavepad/index.html

4. Wavepad features

① Copy, cut, paste ② noise reduction ③ playback speed control ④ Adding silence, Fade In/Out, reverse play

Editing digital files

Part 6

Getting more out of Plusdeck2c

5. Getting rid of sound effect

1. Go to Start 1Control Panel 1Sounds and Audio devices.

2. In the Sounds and Audio devices window, select Sounds tab.

3. Select “none”in the sound scheme.

www.plusdeck.com

●

Converting analog sound to digital sound process requires a large hard drive space. Check your available hard drive space frequently.

In My Documents or desktop folder, there may be a limit set for saving. It is recommended that you save fles in other folders.

Caution

Wave Pad

Part 6

Getting more out of Plusdeck2c

If you have any question or suggestion, send an email to us at (info@plusdeck.com). Also visit us at http://www.plusdeck.com for updated product information.

Thank you!

www.plusdeck.com

●

■ This product is manufactured under thorough quality control and test.

During the warranty period, you can get the product serviced by the distributor or manufacturer.

■ Warranty period: 1 year from date of purchase

■ Warranty guidelines

1. If a mechanical or other serious problem is found within 10 days from date of purchase, contact the distributor with the product registration and receipt for refund.

2. If a problem occurs which is not caused by user mishandling within the warranty period, you can get the product serviced for free.

3. If a problem occurs after the warranty period is over, a service fee will be charged.

4. A service fee will be charged within the warranty period in the following cses.

- malfunction, damage, or lost components by user mishandling or error

- problem or damage caused by natural disasters

- problem or damage caused from repair by unauthorized personnel

- problem or damage caused by the PC

- problem or damage caused by defective tapes

Warranty Card

BTO Co.,Ltd. www.plusdeck.com

Product

Purchased date

Purchased place

Customers’ address

Name

Trouble particulars

plusdeck 2c 20 . . .

5. We are not responsible for any damage done on the tape or computer caused by user mishandling or error.

Serial number

Warranty period

Phone number

Within 1 year from purchased

bto plus deck2c Manual For Use And Installation

Specifications and Main Features

Frequently Asked Questions

User Manual
