BT Glide 7163 User Manual

BT Glide – Edition 07 – 20.01.06 – 7163

User Guide

BT Glide – Edition 07 – 20.01.06 – 7163

Welcome…

to your BT Glide Bluetooth

Cordless Home Phone

Stylish slide-design phone – slide the handset open

•

to reveal the hidden keypad.

Large, full colour screen with icons.

•

Phonebook to store up to 200 names each with

•

home, mobile and work numbers for easy dialling.

Answering machine with remote operation.

•

Send and receive text messages using T9™Text

•

Input predictive text.

Bluetooth®wireless technology lets you pair a

•

compatible mobile phone and

Copy contacts from your mobile SIM card to your

•

BT Glide phonebook.

Caller Display lets you see who’s calling and the

•

50 number Calls list helps you to keep track of received calls*

Polyphonic ringtones.

•

3 Games including Mars Lander and Solitaire.

•

Bluetooth®headset.

* Requires subscription to a Caller Display service. A quarterly fee

may be payable.

BT Glide – Edition 07 – 20.01.06 – 7163

This User Guide provides you with all the information you need to get the most from your phone.

You must first set up your phone before you can use it. This doesn’t take long and is easy to do. Just follow the simple instructions on the next few pages.

Need help?

If you have any problems setting up or using your BT Glide, contact the Helpline on 0870 605 8047.

Alternatively, you may find the answer in ‘Help’ at the back of this guide.

Hearing aid user?

Please note that the BT Glide works by sending radio signals between the base and handset. These signals may interfere with some hearing aids, causing a humming noise.

Got everything?

BT Glide base

•

BT Glide handset

•

Battery pack (already

•

installed)

Mains power adaptor

•

Telephone line cord

•

Earpiece headset

•

Wrist strap

•

CD with picture/

•

ringtone manager

If you have purchased a BT Glide multiple pack, you will also have the following for each additional handset:

BT Glide charger

•

Battery pack

•

Mains power adaptor

•

Earpiece headset

•

Wrist strap

•

In this guide

BT Glide – Edition 07 – 20.01.06 – 7163

Getting started

Location . . . . . . . . . . . . . . . . . . . . 6

Setting up . . . . . . . . . . . . . . . . . . . 6

Set the time and date manually . . . 8

Getting to know your phone

Handset buttons . . . . . . . . . . . . . . 10

Base . . . . . . . . . . . . . . . . . . . . . . . 11

Standby screen and icons. . . . . . . . 12

Navigating the menus and

selecting options . . . . . . . . . . . . . . 13

Handset menu. . . . . . . . . . . . . . . . 14

Using the phone

Switch handset on/off . . . . . . . . . . 15

Make a call . . . . . . . . . . . . . . . . . . 15

End a call. . . . . . . . . . . . . . . . . . . . 15

Receiving calls . . . . . . . . . . . . . . . . 15

Handsfree . . . . . . . . . . . . . . . . . . . 16

Headset socket . . . . . . . . . . . . . . . 16

Adjust earpiece/handsfree volume . 16

Secrecy . . . . . . . . . . . . . . . . . . . . . 17

Redial a number . . . . . . . . . . . . . . 17

Keypad lock. . . . . . . . . . . . . . . . . . 17

Find handsets . . . . . . . . . . . . . . . . 17

Using the phonebook

Add a new entry manually . . . . . . . 18

Dial a phonebook entry . . . . . . . . . 19

View an entry . . . . . . . . . . . . . . . . 19

Modify/edit an entry . . . . . . . . . . . 19

Delete an entry . . . . . . . . . . . . . . . 19

Delete all phonebook entries . . . . . 20

Copy the phonebook from

another BT Glide handset . . . . . . . 20

If you experience any problems, please call the Helpline on 0870 605 8047

Copy entries from a SIM card. . . . . 20

Send an entry from one

BT Glide handset to another . . . . . 21

Set dialling codes. . . . . . . . . . . . . . 21

Using Bluetooth

Pairing a Bluetooth mobile phone . 22

Pairing a Bluetooth headset . . . . . . 23

Using your Bluetooth headset . . . . 24

Send a vCard to another

Bluetooth device . . . . . . . . . . . . . . 25

Receive a vCard . . . . . . . . . . . . . . . 25

Add entries via Phonebook

Synchronisation . . . . . . . . . . . . . . . 26

Set the synchronisation interval . . . 26

Using your BT Glide with a PC . . . . 27

Transferring images and

ringtones via a PC . . . . . . . . . . . . . 28

Multiple Bluetooth devices. . . . . . . 28

Call another handset . . . . . . . . . . . 30

Transfer a call or start a 3-Way call. . 30

Using the calls list

Missed calls list

Using the calls list . . . . . . . . . . . . . 31

Deleting Calls lists . . . . . . . . . . . . . 32

BT Calling Features

1471 . . . . . . . . . . . . . . . . . . . . . . . 33

Call Diversion . . . . . . . . . . . . . . . . 34

Call Waiting. . . . . . . . . . . . . . . . . . 34

Reminder Call . . . . . . . . . . . . . . . . 35

Change numbers . . . . . . . . . . . . . . 35

. . . . . . . . . . . . . . . 31

BT Glide – Edition 07 – 20.01.06 – 7163

5In this guide

Text messaging

Subscribe to the text

messaging service . . . . . . . . . . . . . 36

Cost of the fixed line service . . . . . 36

Entering text . . . . . . . . . . . . . . . . . 37

Text character map . . . . . . . . . . . . 38

Write and send a text message . . . 39 Send a text message from the

phonebook . . . . . . . . . . . . . . . . . . 39

Read messages in your Inbox . . . . . 40

Use a template . . . . . . . . . . . . . . . 41

Edit or delete a template . . . . . . . . 41

Save your own template . . . . . . . . 41

Checking your Outbox . . . . . . . . . . 42

Set Sending Service Centre number . 43 Set Receiving Service Centre number . 43

Add a user area . . . . . . . . . . . . . . . 44

Edit a user area . . . . . . . . . . . . . . . 45

Delete a user area . . . . . . . . . . . . . 45

Set the font size for messages . . . . 46

Change the language for

predictive text (T9™) . . . . . . . . . . . 46

Set message alert beeps on/off . . . 46

Set the first ring on/off. . . . . . . . . . 47

Using the answering machine

Switch the answer machine on/off . 48

Playing messages . . . . . . . . . . . . . 49

Delete all old messages . . . . . . . . 50

Call screening . . . . . . . . . . . . . . . . 50

Memory full . . . . . . . . . . . . . . . . . 50

Select answer mode . . . . . . . . . . . 51

Record your own OGM . . . . . . . . . 52

Play/check OGM . . . . . . . . . . . . . . 52

If you experience any problems, please call the Helpline on 0870 605 8047

Answer delay . . . . . . . . . . . . . . . . . 53

Message alert on/off . . . . . . . . . . . 53

Remote access . . . . . . . . . . . . . . . 54

Switch remote access on/off . . . . . 54

Change the remote access PIN . . . 54 Operate your answering

machine remotely . . . . . . . . . . . . . 55

Personalise your phone

Change the handset wallpaper . . . . 56

External ringer melody/volume . . . . 56

Internal ringer melody/volume . . . . 57

Base ringer melody/volume . . . . . . 57

Handset and base settings

Change the handset name . . . . . . . 58

Earpiece volume . . . . . . . . . . . . . . 58

Handsfree/headset volume . . . . . . 58

Auto talk on/off . . . . . . . . . . . . . . . 59

Key clicks on/off . . . . . . . . . . . . . . 59

Display language . . . . . . . . . . . . . . 59

Display contrast. . . . . . . . . . . . . . . 60

Base name . . . . . . . . . . . . . . . . . . 60

Dialling mode . . . . . . . . . . . . . . . . 60

PABX (switchboard) code . . . . . . . . 61

Restore factory (default) settings . . 61

Games . . . . . . . . . . . . . . . . . . . . . 63

Help . . . . . . . . . . . . . . . . . . . . . . . 66

General information . . . . . . . . . . . 70

Safety . . . . . . . . . . . . . . . . . . . . . . 70

Technical information . . . . . . . . . . 71

Switchboard compatibility . . . . . . . 71

Guarantee . . . . . . . . . . . . . . . . . . . 72

BT Glide – Edition 07 – 20.01.06 – 7163

Getting started

WARNING

Do not place your BT Glide in the bathroom or other humid areas.

Handset range

The BT Glide has a range of 300 metres outdoors when there is a clear line of sight between the base and the handset. Any obstruction between the base and handset will reduce the range significantly. With the base indoors and handset either indoors or outdoors, the range will normally be up to 50 metres. Thick stone walls can severely affect the range.

Signal strength

When you are out of range of the BT Glide base, you will hear a warning beep in the earpiece.

IMPORTANT

Do not connect the telephone line until the handset is fully charged for 24 hours. The base must be plugged into the mains power at all times.

Location

You need to place your BT Glide within 2 metres of a mains power and telephone socket so that the cables will reach.

Make sure it is at least 1 metre away from other electrical appliances to avoid interference.

Your BT Glide works by sending radio signals between the handset and base. The strength of the signal depends on where you site the base. Putting it as high as possible ensures the best signal.

Setting up

1. Plug the mains power cable into the socket marked on the underside of the base. The Power light

comes on.

Power

adaptor

cable

Route the cable through the channel on the base.

Plug the other end of the adaptor into the wall socket and switch the power on.

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

7Getting started

2. Remove the battery guard tab from the bottom of the handset.

Battery guard tab

3. Place the handset on the base to charge for at least 24 hours. The charging light comes on. The handset is pre-registered to the base as

BT Glide

. The screen

shows the standby display.

The charging light stays on while the handset is being charged. Once fully charged the light will go off.

4. After 24 hours charging, plug one end of the telephone line cord into the socket marked on the base and the other end into the telephone line wall socket.

Only use the telephone line cord supplied.

Telephone

line cord

Battery low warning

The handset battery symbol has only one red bar left and you will hear a warning beep every 5 minutes. Start recharging your handset right away or the handset will shut down.

Battery low

Battery full

When charging, the battery symbol is blue and it scrolls.

When you place a handset with a completely flat battery on to the base, the charge light will come on but the handset will not start. You must wait up to 10 minutes before the battery has enough charge for the handset to start.

Battery performance

Running the battery right down at least once a week will help it last as long as possible.

On a full charge, your B handset gives you up to 7 hours talk time or up to 72 hours standby.

The charge capacity of a rechargeable battery will reduce with time as it wears out, giving the handset less talk/standby time. Eventually it will need to be replaced.

The battery and handset may become warm during charging. This is normal.

T Glide

Route the cable through the channel on the base.

If you experience any problems, please call the Helpline on 0870 605 8047

8 Getting started

BT Glide – Edition 07 – 20.01.06 – 7163

Battery performance (continued)

Only use a Li-ion rechargeable battery pack with a recommended capacity of

3.7V 1150mAh. Using an inappropriate battery will invalidate your guarantee and may damage the telephone.

Your BT Glide uses the 24-hour clock.

Connect the wrist strap (optional)

Turn the handset over and thread the thin cord of the wrist strap through the hole on the top left corner. Then loop the thin cord over the thick strap and pull to secure.

Set the time and date manually

If you have subscribed to your network’s Caller Display service, the time will be set automatically when you receive your first call. However, this will not set the date.

1. Press the Menu option button.

2. Use the Settings menu and press the

Navigation buttons to highlight the

Select option button

or .

3. Press to highlight

Time & Date

and press the

Select option button. The current time setting is

highlighted.

4. Enter the time, eg. for 9.30pm, press

2, 1, 3 and 0.

5. Press to highlight the current date setting. Enter the date, eg. for 30 September 2005,

30 / 09 / 05.

press

6. Press the

Save option button to confirm.

Helpline

If you are having difficulties setting up or using your BT Glide, please call the BT Glide Helpline on 0870 605 8047.

If you experience any problems, please call the Helpline on 0870 605 8047

Your BT Glide is ready to use.

BT Glide – Edition 07 – 20.01.06 – 7163

Additionally, if you have purchased a BT Glide multiple pack

For each additional handset and charger:

1. Connect the power adaptor to the charger and switch on.

2. Remove the battery guard tab as instructed on page 7.

3. Place the handset on the charger and let the battery charge for at least 24 hours. The Charging light will come on.

Your BT Glide additional handset comes pre-registered to the base.

9Getting started

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

Getting to know your phone

Handset buttons

Connection point for wrist strap, page 8

Full colour screen

Headset socket (on side of

handset), page 16.

Select the option displayed

on screen directly above the

Use to move up, down, left

and right around the screen,

handsfree modes,

Option buttons

button,

page 13.

Navigation buttons

page 13.

Talk / Handsfree

Press to answer calls.

Press again to switch

between handset and

Used to change the dial

page 16.

mode if required.

✱

R (Recall)

For use with a switchboard.

Press to confirm options displayed on the screen.

End Call / Power on/off

Press to end a call. Press and hold to switch the handset on/off, page 15.

Bluetooth®button

Press to access the Bluetooth menu, page 22.

Press and hold to lock/unlock the keypad, page 17. Press and hold to enter a pause.

Also used to switch between upper and lower case characters, page 18.

Int

Lets you make calls between handsets registered to the base,

page 30.

If you experience any problems, please call the Helpline on 0870 605 8047

Base

BT Glide – Edition 07 – 20.01.06 – 7163

SIM card reader

Enables you to copy the directory from a compatible GSM mobile phone SIM card to a handset, page 20.

Find

Press to ring a handset if you have misplaced it, page 17.

11Getting to know your phone

Power light

Comes on when the

mains power is

connected,

page 6.

If you experience any problems, please call the Helpline on 0870 605 8047

Charging light

Comes on when the

handset is charging.

Once fully charged, the

light will go out,

page 7.

In Use light

ON = Line in use FLASHES = When receiving an incoming call

Message received light

Flashes when you have new messages.

BT Glide – Edition 07 – 20.01.06 – 7163

12 Getting to know your phone

Handset standby screen and icons

Handsfree on

Answering machine on

Bluetooth range indication

You have new text message(s)

You have missed calls

Press the left-hand option

button to open the main menu,

Menu option

see next page.

Handset ringer off

Keypad locked

Battery status

Handset name

If you wish, the handset name can be changed, page 58.

You have new answering machine message(s)

Date and time

Names option

Press the right-hand option button to open the phonebook.

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

Navigating the menus and selecting options

Your BT Glide has a handset menu system that is easy to use. The menus are shown as icons on the display. Each menu leads to a list of options, which can be seen on the following page.

1. In the bottom left of the standby screen, the

option is displayed. Press the option button beneath

2. Use the

Menu to open the main menu.

Up/Down/Left/Right navigation buttons to

highlight a menu icon. The name of the highlighted menu is shown on the top line of the display.

3. To open the highlighted menu, press the

Select

option or press the button.

4. The options within the menu you have chosen are then displayed in a list. Use the and buttons to scroll through the list. When the option you want is highlighted, press Select or .

Back (if displayed) to go back to the

Press previous screen.

Select the option displayed on screen by pressing the button underneath it.

For example, to open the main menu select option button below it, as shown.

The use the navigation buttons to scroll Up/Down/Left/Right.

Menu by pressing the

13Getting to know your phone

To exit a menu

To exit the menu and return to standby at any time, press or close the BT Glide handset.

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

14 Getting to know your phone

Handset menu

Settings (page 58)

Handset Base Time & Date Network Services Answer Machine Text Messaging Phonebook Reset All Settings

Phonebook (page 18)

Add Entry Mobile Synch Copy from Handset Copy from SIM Names Search Delete Phonebook Status

Games (page 63)

Mars Lander Apples and Pears Solitaire

Calls Lists (page 31)

Received Calls Missed Calls Dialled Calls Delete Calls Lists

Answer Machine (page 48)

Play Messages Delete Messages Answer On/Off Outgoing Message

Bluetooth®(page 22)

Mobile Synch Pair with Mobile Send via Bluetooth Pair Headset Connect Headset Disconnect Headset Register Headset De-Register

Text Messaging (page 36)

Write Message Inbox Outbox Templates

Images & Sounds (page 56)

Melodies Pictures Memory Status

Network Services (page 33)

Helpline Number BT 1471 Call Diversion On Call Diversion Off Call Diversion Check

aiting On

Call W Call Waiting Off Call Waiting Check Reminder Call Set Reminder Call Clear

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

Using the phone

Switch handset on/off

1. Press and hold to switch the handset off.

2. Press again to switch the handset back on.

Make a call

1. Slide the handset open and enter the telephone number using the keypad.

2. Press to dial.

End a call

1. Press or slide the handset closed or place the handset back on the base.

Receiving calls

If you have subscribed to your network’s Caller Display service, the caller’s details are displayed.

1. Press or slide the handset open to answer the call.

Or if the handset is on the base, simply lift up the handset to take the call (if auto-talk is switched on).

Dialling numbers quickly

Numbers can be dialled direct from the phonebook (page 19), the Calls list (page 31) or the redial list (page 17).

Call timer

The call timer shows the duration of your call on your handset display.

Auto-answer

You can answer a call just by lifting the handset off the base. If you would rather press to receive a call when the handset is on the base, you need to switch Auto-talk off, page 59.

Divert call to the answering machine

1. Press when the phone is ringing to divert a call to the answering machine. The call will be diverted even if the answering machine is switched off.

If you experience any problems, please call the Helpline on 0870 605 8047

16 Using the phone

To switch to handsfree during a call press .

Switch back to the handset at any time by pressing again.

BT Glide – Edition 07 – 20.01.06 – 7163

Handsfree

Handsfree switches on the handset loudspeaker so you can talk to your caller without holding the handset. It also enables other people in the room to listen to both sides of your conversation.

To make a handsfree call:

1. Press

twice. The display shows the icon. Your

call can be heard over the handset’s loudspeaker.

2. To switch back to the handset at any time, press again.

Headset socket

1. Peel back the rubber bung on the side of the handset and plug the earpiece headset (supplied) into the socket.

2. Make and receive calls as normal.

Adjust earpiece/handsfree volume

1. During a call, press the or navigation button to raise or lower the volume. The current setting is displayed.

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

Secrecy

During a call, use secrecy to talk to someone nearby without your caller hearing you.

1. During the call, press

Secrecy. Your caller cannot

hear you.

2. Press

Off to return to your caller.

Redial a number

You can redial up to 20 of the last numbers called from your handset.

1. Press to open the redial list.

2. Scroll or to highlight the number or name you want.

3. Press or press the

Select option button to dial

the number.

If you are using your Bluetooth headset the secrecy function will not work, it only applies to handset and handsfree usage.

Once the list is full, new dialled numbers replace the oldest.

If you have stored a name in the phonebook to go with the number, the name will be displayed instead, see phonebook,

page 18.

17Using the phone

Keypad lock

1. From the standby screen, press and hold to lock/unlock the keypad.

When the keypad is locked, the icon will be displayed.

Find handsets

1. Briefly press on the base. All handsets registered to the base will ring and display

Paging

2. Press to stop the ringing.

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

Using the phonebook

Each BT Glide handset can store up to 200 names along with home, mobile and work numbers. You can store new entries in many ways:

Adding an entry manually (see below)

•

Copy phonebook from another BT Glide handset

•

see page 20)

(

Copy phonebook from compatible mobile phone

•

SIM cards (

Synchronise contacts with a mobile phone enabled

•

see page 20)

with Bluetooth

Receive names and numbers (vCard) via

•

Bluetooth

wireless technology (see page 26)

wireless technology (see page 25).

Names can be up to 16 characters long and numbers up to 20 digits.

Entering names

Use the keypad letters to enter names, e.g. to store TOM:

Press

If you make a mistake, press Clear to delete the last character or digit.

Press to switch between upper and lower case letters.

Press to insert a space.

You can also enter a pause in a stored number (see more information).

once to enter T.

three times to enter O.

once to enter M.

page 72 for

If you experience any problems, please call the Helpline on 0870 605 8047

Add a new entry manually

1. Press Menu and use the Navigation buttons to

highlight the Phonebook menu. Press

Select

or .

Add Entry

is highlighted, press Select or .

3. Use the keypad to enter a contact name and any numbers for the contact.

If you subscribe to your network’s Caller Display service and want the names in your phonebook displayed instead of the phone numbers, you must store the full telephone number including the dialling code.

4. Press

Save to store the new entry.

BT Glide – Edition 07 – 20.01.06 – 7163

19Using the phonebook

Dial a phonebook entry

1. Press Names, scroll or to the person you want

to call and press .

2. The display will show a list of numbers. Scroll or to the number you want to dial and press ,

Select or to dial.

then

View an entry

1. Press Names and scroll or to the entry you

want to view and press

2. Scroll to

View Entry

Options.

and press Select to view

the contact’s details.

Modify/edit an entry

1. Press Names and scroll or to the entry you

want to modify and press

2. Scroll to

Modify Entry

Options.

and press Select.

3. Use the and buttons to move between fields

Clear to delete any incorrect characters or

and digits. Press

Save to store the modified details.

Delete an entry

1. Press Names and scroll or to the entry you

want to delete and press

2. Scroll to

Delete Entry

3. The display shows

the contact or

No to return to the previous screen.

If you experience any problems, please call the Helpline on 0870 605 8047

Options.

and press Select.

Delete Entry?

. Press Yes to delete

Quick-search the phonebook

If you have many stored entries you can search the phonebook alphabetically. Use the keypad to enter the first letter of the name, eg. press four times to jump to names beginning with S. If there is more than one name scroll to the required entry.

20 Using the phonebook

BT Glide – Edition 07 – 20.01.06 – 7163

Delete all phonebook entries

1. Press Menu and use the Navigation buttons to

highlight the menu. Press

2. Scroll to

Really delete all?

3. Press

Delete Phonebook

is displayed.

Ye s to delete all contacts or No to return to

Select or .

and press Select .

the previous screen.

Both BT Glide handsets have to be registered to the same base.

IMPORTANT

Your BT Glide will only copy numbers stored on your SIM card. If fewer numbers than you expect copy into your BT Glide, check that all numbers are stored on your SIM and not on your mobile phone. Refer to your mobile phone user guide for instructions on how to do this.

WARNING

Keep SIM cards away from small children as they are a possible choking hazard.

If you experience any problems, please call the Helpline on 0870 605 8047

Copy the phonebook from another BT Glide handset

1. Press Menu and use the Navigation buttons to

highlight the menu. Press

2. Scroll to

Copy from Handset

Select or .

and press Select

or . A list of registered handsets is displayed.

3. Use the and buttons to select from the list of handsets displayed.

4. Press

Select to begin copying.

Copy entries from a SIM card

You can copy the SIM directory of a compatible GSM mobile phone to a BT Glide handset. Entries are copied one by one from the SIM card.

To be able to copy your SIM card, you must first disable the SIM card lock on your mobile phone. Refer to your mobile phone user guide for instructions on how to do this.

BT Glide – Edition 07 – 20.01.06 – 7163

1. Press Menu and use the Navigation buttons to

highlight the menu. Press

2. Scroll to

Copy from SIM

Select or .

and press Select to

begin copying.

Send an entry from one BT Glide handset to another BT Glide handset

1. Press Names and scroll or to the entry you

want to send and press

2. Scroll to

Send to handset

Options.

and press Select or .

A list of registered handsets is displayed.

3. Use the and buttons to select the handset you want to send the contact to.

4. Press

Select to send the contact.

Set dialling codes

1. Press Menu and use the Navigation buttons to highlight the Settings menu. Press

2. Scroll to

Scroll to

Phonebook

Dialling codes

and press Select or .

and press Select or

Select or .

4. Use the and buttons to move between the text fields and enter the correct International, Local and Country codes.

5. Press the

Save option button to confirm.

If the handset phonebook becomes full during copying,

Memory full

copying stops.

For the UK, the correct dialling codes are:

International code: 00

Local code: 0

Country code: 44

is displayed and

21Using the phonebook

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

Using Bluetooth

Bluetooth®range

Bluetooth wireless technology provides a typical range of around 10 metres from the base, although this will vary depending on your environment.

When pairing a Bluetooth headset, the distance from the base can be critical. Some headsets need to be

0.5m away.

TANT

IMPOR

Familiarise yourself with the pairing instructions before attempting this process.

IMPORTANT

Due to variations between different manufacturer’s mobile phone devices, please refer to the user guide for your specific mobile phone for exact instructions on switching Bluetooth on and selecting a device to pair with.

Your BT Glide has built-in Bluetooth®wireless technology which makes it possible to connect your phone wirelessly with other Bluetooth devices. You can use your BT Glide with one Bluetooth enabled mobile phone and one Bluetooth headset.

Once a mobile phone or headset is paired with your BT Glide you can:

use your Bluetooth headset to answer calls on your

•

BT Glide

copy your mobile directory to the BT Glide

•

send and receive vCards with any Bluetooth device

•

– it does not have to be paired with the BT Glide.

Pairing

Pairing is the process for connecting two Bluetooth enabled devices together, for example a mobile phone or Bluetooth headset to your BT Glide. You must complete the pairing procedure before the two devices can be used together. Pairing only has to be completed once for each mobile phone or Bluetooth headset.

Pairing a Bluetooth®mobile phone

On your mobile phone:

1. Make sure your mobile is in range – i.e within 10m of the BT Glide. Following your mobile phone user guide, switch Bluetooth on and make sure your mobile phone is set to ‘visible’ or ‘discoverable’.

If you experience any problems, please call the Helpline on 0870 605 8047

BT Glide – Edition 07 – 20.01.06 – 7163

Then search for/discover other devices. Do not select BT Glide yet.

On your BT Glide:

1. Press either the Bluetooth button, or press Menu and use the Navigation buttons to highlight the Bluetooth menu. Press

2. Scroll to

Pair with Mobile

3. The display shows

Ye s to confirm the mobile handset is

Press discoverable. The handset searches for and then displays a list of all visible Bluetooth

Select or .

and press Select or .

Is Mobile Discoverable?

devices.

4. Scroll or to select the mobile you want to pair with and press

Select. The display returns to

the previous screen.

Pairing a Bluetooth®headset

1. Press Menu and use the Navigation buttons to highlight the Bluetooth menu. Press

2. Scroll to

Pair Headset

3. The display shows

and press Select or .

Make Headset Discoverable

Select or .

4. Put your Bluetooth headset into discoverable mode. Your headset will flash.

5. On your BT Glide handset, press to confirm.

6. Enter the PIN code for your headset (will depend on your headset, eg. 0000).

7. Press to confirm. The headset is now ready for use.

If you experience any problems, please call the Helpline on 0870 605 8047

Location of the Bluetooth button

23Using Bluetooth

+ 53 hidden pages
