THERMOSTATS
TM
THERMIDISTAT
ELECTRO-MECHANICAL THERMOST A TS
HEAT OFF COOL
90
80
70
60
AUTO FAN ON
* Air Conditioner Model * Heat Pump Model
(HH07AT212) (HH07AT214)
NON-PROGRAMMABLE THERMOST A T
®
CONTROL
80
80
70
70
60
60
50
50
ONCOOLOFFHEATEM. HEAT AUTO
FAN
EM. HEAT
MODEL
The Bryant electronic thermostat product line consists of programmable and non-programmable air conditioner, heat pump,
and 2-speed models; a programmable dual fuel model, and a
programmable Thermidistat
non-mercury based electronic controls built into a subtle, slim
plastic enclosure. They require no battery back-up and are not
power stealing. Bryant also offers conventional electromechanical thermostats in both air conditioner and heat pump
models.
AUX. HEAT
FEATURES/BENEFITS
ELECTRO-MECHANICAL THERMOST A TS
COMPLETE OFFERING —Non-programmable air conditioner
and heat pump models available.
EASY TO USE —Manual switches provide easy changes to heat-
ing/cooling mode operation, fan operation, and desired
temperature setting.
MANUAL CHANGEOVER —Allows manual switches in system
operation when both heating and cooling are needed on the
same day.
TM
Control. These units feature
TSTAT
* Standard Model (AC, HP, 2S)
PROGRAMMABLE THERMOST A T
AND THERMIDIST A T
* Standard Model (AC, HP, 2S)
* Dual Fuel Model (DF)
* Thermidistat
TM
CONTROL
TM
Control Model (RH)
®
NON-PROGRAMMABLE THERMOSTATS
CLEAN DESIGN —Features soft, responsive buttons and an
easy-to-read backlit Liquid Crystal Display (LCD).
ACCURATE, RELIABLE TEMPERATURE CONTROL —LCD
shows current room temperature at all times, and desired temperature prompts upon demand.
AUTO CHANGEOVER —Switches system operation automati-
cally when both heating and cooling are needed on the same day.
OUTDOOR TEMPERATURE DISPLAY —Allows a check of the
temperature outside before leaving home . (Optional on all models
except non-programmable air conditioner.)
CLEAN FILTER INDICATOR —Tells when it is time to clean the
system’s filter.
PERFECT COMPLEMENT —Completes your Bryant total com-
fort system needs.
LIMITED WARRANTY —Standard 1-year warranty available on
all parts.
PROGRAMMABLE THERMOSTATS
Bryant programmable thermostats possess the same features as
non-programmable thermostats plus:
COMFORT AND ENERGY SAVINGS —Seven day program-
ming, with 4 temperature changes provided per day, means
comfort when the family is at home and savings through reduced
energy usage when the family is away or asleep.
EASY TO USE —Simple instructions are located inside the ther-
mostat’s door.
Form No. PDS TSTAT.0.1
DUPLICATE PROGRAMMING —Copy
the comfort schedule from one day to the
next using the copy previous day
function.
OVERRIDE CAPABILITY —Hold func-
tion allows the regular schedule to be
bypassed with a temporary setting.
BATTERY-FREE —Non-volatile RAM chip
requires no battery backup. Program is retained in memory so reprogramming is not
required after power loss.
TIMEGUARD —Equipment protection.
DUAL FUEL MODEL —The dual fuel
thermostat can be used to control a gas
furnace and a heat pump. This thermostat
eliminates the need for an interface control kit.
THERMIDISTAT
Bryant’s Thermidistat Control can be used
to control any equipment application except zoning. It possesses all the features
and benefits of Bryant’s non-programmable and programmable thermostats plus:
ENHANCED COMFORT —Allows the ho-
meowner to accurately maintain the
desired temperature and humidity settings in the home. By combining the
functions of a programmable thermostat
and a humidistat, the Thermidistat Control
provides temperature control, humidity
control, and dehumidification.
HUMIDITY CONTROL —The Thermidi-
stat Control accurately controls humidity.
It humidifies during heating and dehumidi-
TM
CONTROL
MODEL NUMBER NOMENCLATURE
ELECTRONIC THERMOST A TS
fies during cooling.
AUTOMATIC HUMIDITY ADJUSTMENT —When used with the outdoor
temperature sensor, the Thermidistat
Control automatically adjusts the humidity setting reducing excess condensation
on the windows.
VACATION MODE —With a single touch
of a button, vacation mode adjusts all
comfort levels for optimum efficiency
while the home is unoccupied—or restores the settings to normal upon return.
SMART RECOVERY —Provides consis-
tent heating and cooling right on time as it
gradually adjusts indoor temperatures before a scheduled change.
T STAT
THERMOSTAT
BH
BH – BRYANT BRAND
ACN
AC – AIR CONDITIONING
HP – HEAT PUMP
2S – TWO SPEED/TWO STAGE
DF – DUAL FUEL
RH – RELATIVE HUMIDITY (THERMIDISTAT CONTROL)
P – PROGRAMMABLE
N – NON-PROGRAMMABLE
ELECTRO-MECHANICAL THERMOST A TS
HH07AT
XXX
01
QUANTITY
–A
SERIES
A96562
SM
As an ENERGY STAR
Bryant Heating & Cooling Systems
has determined that the
programmable thermostats and
Thermidistat Control meet the
ENERGY STAR guidelines for
energy efficiency.
Partner,
THERMOSTAT
212 = NON-PROGRAMMABLE, AC
214 = NON-PROGRAMMABLE, HP
A97379
—2—
4 3⁄8″
3 1⁄2″
DIMENSIONS
5 13⁄16″
Non-Programmable Thermostat
3
⁄8″
1
®
1 3⁄8″
7 3⁄8″
Programmable Thermostat and Thermidistat Control
1 3⁄8″
HEAT OFFCOOL
90
80
2 7⁄8″
AUTO FANON
70
60
4 3⁄4″
Electro - Mechanical Air Conditioner Thermostat
2 1⁄16″
80
80
70
70
60
60
3 1⁄4″
50
50
ONCOOLOFFHEATEM. HEAT AUTO
FAN
EM. HEAT
AUX. HEAT
4 11⁄16″
Electro - Mechanical Heat Pump Thermostat
—3—
A97289
PRODUCT DATA INFORMATION
PHYSICAL CHARACTERISTICS
Dimensions: See drawing
Appearance: Plastic, eggshell color, textured
ELECTRICAL CHARACTERISTICS
Input Volts/Amps: 24vac, 5 VA
ENVIRONMENTAL REQUIREMENTS:
Operating Temperature/Relative Humidity: 32 ° F (0 ° C) to 104 ° F (40 ° C)/95% rh non-condensing
Storage Temperature/Relative Humidity: –40 ° F (–40 ° C) to 134 ° F (56 ° C)/95% rh non-condensing
PROGRAM SPECIFICATIONS:
Non-Programmable Models:
Temperature setpoint range: 40 ° F (4 ° C) to 90 ° F (32 ° C)
Separate heat and cool setpoints
Auto changeover
Clean filter reminder: installer adjustable
Permanent memory
Programmable Models:
Temperature setpoint range: 40 ° F (4 ° C) to 90 ° F (32 ° C)
Separate heat and cool setpoints
Auto changeover
Clean filter reminder: installer adjustable
Permanent memory
Programming days: 7 day
Programming periods: 4—Wake, Day, Eve, Sleep
Hold function
Copy previous day function
Humidity display and control (Thermidistat Control only)
WIRING REQUIREMENTS:
Power: 24vac nominal, 18- to 30-vac, 50/50 Hz
Wiring: Standard thermostat wire 18 to 24 gage.
—4—
° F/ °
° F/ °
° F/ °
° F/ °
° F
DESCRIPTION
PROGRAMMABLE ELECTRONIC THERMOSTATS
PART NO. DESCRIPTION
TSTATBHPAC01-A Thermostat, Auto Changeover, 7-Day Programmable, ° F/ ° C, 1-Stage Heat/1-Stage Cool
TSTATBHPHP01-A Thermostat, Auto Changeover, 7-Day Programmable,
TSTATBHP2S01-A Thermostat, Auto Changeover, 7-Day Programmable,
in AC Mode, 3-Stage Heat/2-Stage Cool in HP Mode
TSTATBHPDF01-A* Dual Fuel Thermostat, Must Be Used with Outdoor Air Temperature Sensor (TSTATXXSEN01)
TSTATBHPRH01-A* Thermidistat Control — Programmable Thermostat with Humidity Control
NON-PROGRAMMABLE ELECTRONIC THERMOSTATS
PART NO. DESCRIPTION
TSTATBHNAC01-A Thermostat, Auto Changeover, Non-Programmable, ° F/ ° C, 1-Stage Heat/1-Stage Cool
TSTATBHNHP01-A Thermostat, Auto Changeover, Non-Programmable,
TSTATBHN2S01-A Thermostat, Auto Changeover, Non-Programmable,
in AC Mode, 3-Stage Heat/2-Stage Cool in HP Mode
C, 2-Stage Heat/1-Stage Cool
C, 2-Stage Heat/2-Stage Cool
C, 2-Stage Heat/1-Stage Cool
C, 2-Stage Heat/2-Stage Cool
MECHANICAL MODELS
PART NO. DESCRIPTION
HH07AT212 Thermostat, Air Conditioner, Non-Programmable, 1-Stage Heat/1-Stage Cool, Manual Changeover, ° F
HH07AT214* Thermostat, Heat Pump, Non-Programmable, 2-Stage Heat/1-Stage Cool, Manual Changeover,
* Do not use in zoning heat pump applications.
THERMOSTAT ACCESSORIES
PART NO. DESCRIPTION
TSTATXXSEN01* Outdoor Air Temperature Sensor
TSTATXXNBP01† Backplate for Non-Programmable Thermostat
TSTATXXPBP01† Backplate for Programmable Thermostat and Thermidistat Control
TSTATXXCNV10‡ Thermostat Conversion Kit (4 to 5 wire) — 10 pack
* Outdoor air temperature sensor is an accessory for all Bryant electronic thermostats, except the non-programmable air conditioner version. It allows the
temperature at a remote location (outdoors) to be displayed on the thermostat. The outdoor air temperature sensor must be used with the Thermidistat
Control to automatically adjust humidity setting.
The outdoor air temperature sensor
† Thermostat backplate can be used for programmable and non-prog r ammab le electronic thermostats only. This plate is designed to cover surrounding wall
area located behind thermostat.
‡ Thermostat conversion kit is a 24-vac accessory that can turn a 4-wire thermostat application into a 5-wire application. This kit can also be used to replace
a broken thermostat wire, or add an extra wire when needed.
must be
used with the dual fuel thermostat. Do not use with electro-mechanical models.
—5—
THERMOSTAT AND THERMIDISTAT CONTROL APPLICATION
NON-PROGRAMMABLE ELECTRONIC THERMOSTAT USAGE
OUTDOOR UNIT
Air Conditioner Heat Pump
INDOOR UNIT
1-Stage Furnace Model AC or HP* Model 2S † Model 2S‡
2-Stage Furnace Model AC or HP* Model 2S † Model 2S‡
Typical Fan Coil Model AC or HP* Model 2S Model HP Model 2S
FK4C Fan Coil Model AC or HP* Model 2S Model HP Model 2S
* Model HP thermostat must be field converted to air conditioner operation.
† Must use Programmable Dual Fuel Thermostat or Thermidistat Control in this application.
‡ Dual Fuel operation controlled by heat pump when using Model 2S Thermostat.
The TSTATBHNAC01-A Electronic Thermostat provides single-stage, non-programmable heat/cool temperature control for 24-vac
heating-cooling systems with auto changeover. Temperature display can be selected to read ° F or ° C.
The TSTATBHNHP01-A Electronic Ther mostat provides versatile 2-stage heating and single-stage cooling, non-programmable temperature control for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read ° F or ° C.
Thermostat comes factory set to operate as a heat pump model with second-stage controlling auxiliary electric heat. This model can
easily be converted from heat pump operation to air conditioning operation requiring 2 stages of gas or electric heat.
The TSTATBHN2S01-A Electronic Thermostat provides versatile multiple stage, non-programmable heat/cool temperature control for
24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read ° F or ° C. Thermostat is
designed for 2-speed compressor bearing units. Thermostat comes factory set to operate as a heat pump model with 2-stage cooling
and 3 stages of heat, third-stage controlling auxiliary electric heat. This model can easily be converted from heat pump operation to
air conditioning operation requiring 2 stages of cooling and 2 stages of heating.
1 Speed 2 Speed 1 Speed 2 Speed
Non-Programmable Models
PROGRAMMABLE ELECTRONIC THERMOSTAT USAGE
OUTDOOR UNIT
Air Conditioner Heat Pump
INDOOR UNIT
1-Stage Furnace Model AC or HP* Model 2S Model DF Model DF or 2S‡
2-Stage Furnace Model AC or HP* Model 2S Model DF Model DF or 2S‡
Typical Fan Coil Model AC or HP* Model 2S Model HP Model 2S
FK4C Fan Coil Model AC or HP* Model 2S Model HP or 2S† Model 2S
* Model HP thermostat must be field converted to AC operation.
† For use with special 3-stage electric heat setup.
‡ Dual Fuel operation controlled by heat pump when using Model 2S thermostat.
1 Speed 2 Speed 1 Speed 2 Speed
Programmable Models
The TSTATBHPAC01-A Electronic Thermostat provides single-stage, 7-day programmable heat/cool temperature control for 24-vac
heating-cooling systems with auto changeover. Temperature display can be selected to read ° F or ° C.
The TSTATBHPHP01-A Electronic Ther mostat provides versatile 2-stage heating and single-stage cooling, 7-day programmable
temperature control for 24-vac heating-cooling systems with auto changeo ver. Temperature display can be selected to read ° F or ° C.
Thermostat comes factory set to operate as a heat pump model with second-stage controlling auxiliary electric heat. This model can
easily be converted from heat pump operation to air conditioning operation requiring 2 stages of gas or electric heat.
The TSTATBHP2S01-A Electronic Ther mostat provides versatile multiple stage, 7-day programmable heat/cool temperature control
for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read ° F or ° C. Ther mostat is
designed primarily for 2-speed compressor bearing units. Ther mostat comes factory set to operate as a heat pump model with 2stage cooling and 3-stages of heat, third-stage controlling auxiliary electric heat. This model can also perf orm smart-staging with FK4
fan coils (special heaters and setup required) using a single-speed heat pump with 3-stages auxiliary electric heat. In addition, this
model can easily be converted from heat pump operation to air conditioning operation requiring 2 stages of cooling and 2 stages of
heating (e.g. gas or electric heat).
—6—
Programmable Dual Fuel Model
The TSTATBHPDF01-A Electronic Thermostat provides single-stage or multiple-stage dual fuel oper ation, 7-day programmable heat/
cool temperature control for 24-vac systems with auto changeover. Temperature display can be selected to read ° F or ° C. The Dual
Fuel Thermostat is designed with an adjustable balance point for heat pumps when using a gas furnace for backup or auxiliary heat.
Thermostat comes factory set to operate single-speed equipment, but is easily configured to match multiple stage equipment combinations. This model requires use of the Outdoor Air Temperature Sensor accessory. Using the dual fuel thermostat eliminates the
need for an interface control.
THERMIDISTAT CONTROL USAGE
OUTDOOR UNIT
Air Conditioner Heat Pump
INDOOR UNIT
1-Stage Furnace
2-Stage Furnace
Typical Fan Coil
FK4C Fan Coil
* The Thermidistat Control may be used in all applications but must be field configured for specific application.
1 Speed 2 Speed 1 Speed 2 Speed
Model RH*
°
Thermidistat Control
The TSTATBHPRH01-A Electronic Thermidistat Control provides single-stage or multiple-stage equipment oper ation, 7-da y prog rammable heat/cool temperature control for 24-vac systems with auto changeover. It controls both humidification and dehumidification
and can be used to control heat pumps, air conditioners, or dual fuel applications. Temperature display can be selected to read ° F or
C. The Thermidistat Control is designed primarily as an extension of the programmable thermostat line to provide humidify and
dehumidify outputs in controlling humidity. Humidify outputs connect directly to 24-v humidifiers. Dehumidify outputs connect directly
to variable-speed furnaces or fan coils that have dehumidification capabilities. This model requires use of the Outdoor Air Temperature Sensor accessory, which is included with the Thermidistat Control.
—7—
OPERATIONAL INFORMATION FOR ELECTRONIC MODELS
FIVE-MINUTE COMPRESSOR TIMEGUARD
This timer prevents the compressor from starting unless it has been off for at least 5 minutes. It can be defeated for 1 cycle by simultaneously pressing the F AN mode button and INCREASE TEMPERATURE (UP) button.
FIFTEEN-MINUTE CYCLE TIMER
This timer prevents the start of a heating or cooling cycle until at least 15 minutes after the last start of the same cycle. Its function is to
assure that equipment is not cycled more than 4 times per hr. This timer is defeated for 1 cycle when the desired temperature is manually changed. It can also be defeated for 1 cycle by simultaneously pressing the FAN mode button and INCREASE TEMPERATURE
button.
FIFTEEN-MINUTE STAGING TIMER
In multistage heating or cooling, this timer prevents any higher stage from turning on until preceding stage has been on for 15 minutes.
This timer is defeated if temperature error is greater than 5°F (usually due to a large change in desired temperature).
MINIMUM ON TIME
In normal operation, when a stage turns on, it will not turn off for a minimum of 2 minutes (3 minutes on Thermidistat Control).
HEAT/COOL SETPOINTS (DESIRED TEMPERATURE)
A minimum difference of 3° is enforced between heating and cooling desired temperatures. This is done by allowing 1 setting to “push”
the other, to maintain this diff erence. (Thermidistat Control 2° and adjustable.)
EQUIPMENT ON INDICATORS (THERMIDISTAT CONTROL)
When cooling equipment is ON, a COOL icon preceded by a small triangle is displayed below the cool setpoint. While cooling equipment turn on is delayed by a staging or cycle timer, the triangle will be flashing. The same is true for the HEAT icon and its preceding
triangle located under the heat setpoint. These 2 triangles are also used to indicate the state of the humidify and dehumidify outputs.
See next section.
HUMIDIFY/DEHUMIDIFY OUTPUT ON INDICATORS (THERMIDISTAT CONTROL)
Within humidity select screen (selected by Humidity button and indicated by “hu” or “dhu” on clock display), the triangle under humidity
setpoint will be on while humidify output is on. The triangle under dehumidify setpoint will be on while dehumidify output is active (turned
off, because this output is reverse logic).
AUTO CHANGEOVER
When auto changeover mode is selected, a change from heat to cool (or vice versa) will not occur until an opposite mode demand has
existed for 20 minutes. If setpoint is changed, the 20 minute requirement is deleted.
EMERGENCY HEAT MODE
When thermostat is controlling as a heat pump and emergency heat is selected, all Y signals are loc ked out, and W becomes energized
upon a call for heat.
SMART RECOVERY
With Smart Recovery selected, transition out of setback begins a fixed time period before selected recovery time and gradually adjusts
room temperature so that the desired temperature will be achiev ed at selected recovery time.
© 1997 Bryant Heating & Cooling Systems, 7310 W. Morris St., Indpls., IN 46231
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
UNIT MUST BE INSTALLED IN ACCORDANCE
WITH INSTALLATION INSTRUCTIONS
Cancels: New
—8— PRINTED IN U.S.A. Catalog No. 12TS-TA0 8-97
Loading...
