Bryant PACKAGED HEAT PUMP 548J, Legacy 548J Product Data

548J PACKAGED HEAT PUMP 3 TO 8.5 NOMINAL TONS

Product Data

(Optional hail guard shown.)

This product has been design ed and m anufactured to meet En ergy St ar® criteria for energy effici ency. However, proper ref rigerant charge an d proper air flow are critical to achieve rated capacity and efficiency. Installation of this product should follow all manufacturer’s refrigerant charging and air flow instructions. Failure to con firm proper charge an d

air flow may reduc e energy effic iency and shorten equipment lif e.

C08515

the environmentally sound refrigerant

TABLE OF CONTENTS

PAGE

FEATURES AND BENEFITS 3....................

MODEL NUMBER NOMENCLA TURE 4............

FACTORY OPTIONS & ACCESSORIES 5...........

ARI CAPACITY RATING 8.......................

SOUND PERFORMANCE 9.......................

PHYSICAL DATA 10.............................

WEIGHTS & DIMENSIONS 18....................

APPLICATION DATA 24.........................

548J

COOLING TABLES 26...........................

STATIC PRESSURE TABLES 35...................

F AN PERFORMANCE 36.........................

OUTDOOR AIR INTAKE & EXHAUST PERF 46.....

ELECTRICAL INFO 47...........................

MCA / MOCP 49................................

TYPICAL WIRING DIAGRAMS 61................

GUIDE SPECIFICATIONS 68......................

Your Bryant Packaged Heat Pump rooftop unit (RTU) was designed by customers for customers. With no--strip screw collars, handled access panels, and more we’ve made your unit easy to install, easy t o maintain and easy to use.

Easy to install:

All Legacy Linet units are field--convertible to horizontal air flow; no special adapter curbs or kits are necessary. Convertible airflow design makes it easy to adjust to unexpected job--site complications. Light er units make easy replacement. Bryant 3--8.5 ton 548J rooftops fit on existing Bryant curbs dating back to 1989. Also, our large control box gives you room to work and room to mount Bryant accessory controls.

Easy to maintain:

Easy access handles by Bryant provide quick and easy access to all normally serviced components. Our “no--strip” screw system has superior holding power and guides screws into position while preventing the screw from stripping the unit’s metal. Take accurate pressure readings by reading condenser pressure with panels on. Simply remove the black, composite plug, route your gauge line(s) through the hole, and connect them to the refrigeration service valve(s). Now, you can take refrigeration system pressure readings without affecting the condenser airflow.

Easy to use:

The newly designed, master terminal board by Bryant puts all your connect ions and troubleshooting points in one convenient place, standard. Most low voltage connections are made to the same board and make it easy to find what you’re looking for and easy to access it. Bryant rooftops have high and low pressure switches, a filter drier, and 2” (51mm) filters standard.

FEATURES AND BENEFITS

S Up to 28% lighter than similar industry units. Lighter rooftops make easier replacement jobs.

S 3--8. 5 ton units fit on existing Bryant rooftop curbs making the utility connections the same. This saves time and money

on replacement jobs.

S Standardized components a nd layout. Standardized com ponents and controls make service and stocking parts easie r.

S Scroll compressors on all units. This makes service, stocking parts, replacement, and trouble-- shooting easier.

S Crankcase heater on all models (except 04 siz e) provide s added protection in all applications.

S Precession sized suction line accumulator provide high reliability by preventing liquid from entering the compressor

during low ambient conditions and reverse cycle switch over.

S Field convertible airflow (3--8. 5 tons). Being able to convert a unit from vertical airflow to horizontal makes it easy to

overcome job site complications.

S 4--way reversing valve rapidly changes the flow of refrigerant to quickly changeover from cooling to heating and heating

to cooling.

S Easy--adjust, belt--drive motor available on all sizes. Bryant provides a factory solution for most points in the fan

performance table. There’s no need for field--supplied drives or motors.

S 3--5 ton models come standard with an Electric Drive X13, 5 speed/torque motor to provide exact performance in many

applications. Belt drive motor optional.

S Provisions for bottom or side condensate drain.

S Capable of thru--the--base or thru--the--curb electrical routing.

S Dependable time/temperature defrost logic provides a defrost cycle, if needed, every 30, 60, 90 or 120 minutes and is

adjustable.

S Single--point electrical connection.

S Sloped, composite drain pan. Sloped, composite drain pan sheds water; and won’t rust.

548J

S Standardized controls and control box layout. Standardized components and controls make stocking parts and service

easier.

S Clean, easy to use control box.

S Standard coils are copper round tube, aluminum plate fin with optional coil coatings and copper fin design.

S Color--coded wir ing.

S Large, laminated wiring and power wiring drawings which are affixed to unit make troubleshooting easy.

S Single, central terminal board for test and wiring connections.

S Fast--access, handled, panels for easy access to the blower and blower motor, control box, and compressors.

S “No--strip” screw system guides screws into the panel and captures them tightly without stripping the screw, the panel, or

the unit.

S Exclusive, newly--design indoor refrigerant header for easier maintenance and replacement.

S Mechanical cooling (115_Fto25_For46_Cto--4_C) on Electro--Mechanical (E/M) and Direct Digital Controller

(DDC) (RTU--MP controller).

S 2” (51mm) disposable filters on all units.

S High capacity refrigerant filter--drier on each circuit.

S High pressure switch, loss of charge switch and freeze protection adds greater unit reliability.

548J

MODEL NUMBER NOMENCLATURE

123456789101112131415161718

5 4 8 J P 0 6 A 0 0 0 A 0 B 0 A A --

____________ ______ ________ ______

Unit Type Design Revision

548J = High Eff. Heat Pump --- = First Revision

Voltage Packaging

E = 4 6 0 --- 3 --- 6 0 A=Standard

J = 208/230--- 1-- -60 B=LTL

P = 208/230---3--- 60

T = 5 7 5 --- 3 --- 6 0 Factory Installed Options

0A = None

Cooling Tons

04=3Ton 07=6Ton Outdoor Air Options

05 = 4 Ton 08 = 7.5 Ton A=None

06 = 5 Ton 09 = 8.5 Ton B=Tempeconow/barorelief

E=Tempeconow/barorelief&CO

Refrig. System Options H = Enthalpy econo w/ baro relief

A = One--- Stage Cooling Models L = Enthalpy econo w/ baro relief & CO

D = Two--- Stage Cooling Models Q = Motorized 2 pos damper

Heat Level (Field --- installed electric heaters available Indoor Fan Options

000 = No Heat 0 = Electric Drive X13 Motor (04--- 06)

1 = Standard static option --- Belt Drive

Coil Options (Outdoor --- Indoor) 2 = Medium static option --- Belt Drive

A = Al/Cu ---Al/Cu 3 = High static option --- Belt Drive

B = P r e c o a t A l / C u --- A l / C u

C = E --- c o a t A l / C u --- A l / C u

D = E --- c o a t A l / C u --- E --- c o a t A l / C u

E = C u / C u --- A l / C u

F = Cu/Cu --- Cu/Cu

M = A l / C u --- A l / C u --- L o u v e r e d H a i l g u a r d s

N = P r e c o a t A l / C u --- A l / C u --- L o u v e r e d H a i l G u a r d s

P = E c o a t A l / C u --- A l / C u --- L o u v e r e d H a i l G u a r d s

Q = E c o a t A l / C u --- E co a t A l / C u --- L o u v e r e d H a i l G u a r d s

R = C u / C u --- A l / C u --- L o u v e r e d H a i l G u a r d s

S = C u / C u --- C u / C u --- L o u v e r e d H a i l G u a r d s

air flow may reduc e energy effic iency and shorten equipment lif e.

the environmentally sound refrigerant

FACTORY OPTIONS AND/OR ACCESSORIES

Table 1 – FACTORY--INSTALLED OPTIONS AND FIELD--INSTALLED ACCESSORIES

FACTORY

CATEGORY ITEM

Cabinet T h r u --- t h e --- b a s e e l e c t r i c a l c o n n e c t i o n s X X

Cu/Cu indoor and/or outdoor coils X

Coil Options

Condenser Protection Condenser coil hail guard (louvered design) X X

Controls

Economizers

& Outdoor Air

Dampers

Economizer Sensors &

IAQ Devices

Electric Heat

Indoor Motor & Drive

Low Ambient Control Motormaster head pressure controller

Power

Options

Roof Curbs

NOTES:

1. Included with economizer.

2. Sensors for optimizing economizer.

3. See application data for assistance.

Pre--- coated outdoor coils X Premium, E --- coated outdoor coils X

Thermostats, temperature sensors, and subbases X R T U --- M P M u l t i --- p r o t o c o l c o n t r o l l e r X Smoke detector (supply and/or return air) X Time Guard II compressor delay control circuit X Phase Monitor X EconoMi$er IV (for electro ---mechanical controlled RTUs) X X EconoMi$er2 (for DDC controlled RTUs) X X Motorized 2 position outdoor--- air damper X X Manual outdoor---air damper (25% and 50%) X Barometric relief Power exhaust X Single dry bulb temperature sensors Differential dry bulb temperature sensors Single enthalpy sensors Differential enthalpy sensors CO2sensor (wall, duct, or unit mounted) Electric Resistance Heaters X Single Point Kit X Multiple motor and belt drive packages X Electric Drive, X13, 5 ---speed/torque (3 ---5 ton) X

Convenience outlet (powered) X Convenience outlet (unpowered) X Non ---fused disconnect X Roof curb 14” (356mm) X Roof curb 24” (610mm) X

INSTALLED

OPTION

X X

FIELD

INSTALLED

ACCESSORY

548J

FACTORY OPTIONS AND/OR ACCESSORIES (cont.)

Economizer (dry--bulb or enthalpy)

Economizers save money. They bring in fresh, outside air for ventilation; and provide cool, outside air to cool your building. This is the preferred method of low--ambient cooling. When coupled to CO provide even more savings by coupling the ventilation air to only that amount re quired.

Economizers are available, installed and tested by the factory, with either enthalpy or dry--bulb temperat ure inputs. There are also models for elect romechanical as well as direct digital controllers. Additional sensors are available as accessories to optimize the economizers.

Economizers include gravity controlled, barometric relief equalizes building pressure and ambient air pressures.

548J

This can be a cast effective solution to prevent building pressurization.

sensors, Economizers can

CO2Sensor

Improves productivity and saves money by working with the economizer to intake only the correct amount of outside air for ventilation. As occupants fill your building, the CO CO

When the occupants leave, the CO the sensor appropriately closes the economizer. This intelligent control of the ventilation air, called Demand Control Ventilation (DCV) reduces the overall load on the rooftop, saving money.

sensor detects their presence through increasing

levels, and opens the economizer appropriately.

levels decrease, and

Smoke Detectors

Trust the expe rts. Smoke detectors make your application safer and your job easier. Bryant smoke detectors immediately shut down the rooftop unit when smoke is detected. They are available, installed by the factory, for supply air, return air, or both.

Louvered Hail Guards

Sleek, louvered panels protect the condenser coil from hail damage, foreign objects, and incidental contact.

Non--fused Disconnect

This OSHA--compliant, factory--installed, safety switch allows a service technician to locally secure power to the rooftop.

Power Exhaust Pressure Relief

Superior internal building pressure control. This field-- installed accessory may eliminate the need for costly, external pressure control fans.

RTU--MP, Multi--protocol Controller

Connect the rooftop to an existing BAS without needing complicated translators or adapter modules using the RTU--MP controller. This new controller speaks the 4 most common building automation system languages (Bacnet, Modbus, N2, and Lonworks). Use this controller when you have an existing BAS.

Time Guard II Control Circuit

This accessory protects your compressor by preventing short--cycling in the event of some other failure, prevents the compressor from restarting for 30 seconds after stopping. Not required with RTU--MP or authorized commercial thermostats.

Filter or Fan Status Switches

Use these differential pressure switches to detect a filter clog or indoor fan motor failure. When used in conjunction with a compatible unit controller/thermostat, the switches will activate an alarm to warn the appropriate personnel.

Motorized 2--Position Damper

The new Bryant 2--position, motorized outdoor air damper admits up to 100% outside air. Using reliable, gear --driven technology, the 2--position damper opens to allow ventilation air and c loses when the rooftop stops, stopping unwanted infiltration.

Manual OA Damper

Convenience Outlet (powered or un--powered)

Lower service bills by including a convenience outlet in your specification. Bryant will install this service feature at our factory, powered. Provides a convenient, 15 amp, 115V GFCI receptacle.

Manual out door air dampers are an econom ical way to bring in ventilation air. The dampers are available in 25% and 50% versions.

FACTORY OPTIONS AND/OR ACCESSORIES (cont.)

Motormaster Head Pressure Controller

The Motormaster motor controller is a low ambient, head pressure controller kit that is designed to maintain the unit’s condenser head pressure during periods of low ambient cooling operation. This device should be used as an alternative to economizer free cooling not when economizer usage is either not appropriate or desired. The Motormaster will either cycle the outdoor--fan motors or operate them at reduced speed to maintain the unit operation, depending on the model.

Alternate Motors and Drives

Some applications need larger horsepower motors, some need more airflow, and some need both. Regardless of the case, your Bryant expert has a factory installed combination to meet your application. A wide selection of motors and pulleys (drives) are available, factory installed, to handle nearly any application.

Thru--the--Base Connections

Thru--the--base connections, available as either an accessory or as a factory option, are necessary to ensure proper connection and seal when routing wire and piping through the rooftop’s basepan and curb. T hese couplings eliminate roof penetration and should be considered for gas lines, main power lines, as well as control power.

Electric Heaters

Bryant offers a full--line of field--installed accessory heaters. The heaters are very easy to use, install and are all pre--engineered and certified.

548J

Table 2 – ARI COOLING RATING TABLES

COOLING MODE

NOMINAL

548J*

CAPACITY

(TONS)

04A 3 37,000 3.3 13.40** 11.00 N/A 05A 4 47,000 4.1 13.10** 11.20 N/A 06A 5 61,500 5.5 13.20** 11.15 N/A 07A 6 70,000 6.3 N/A 11.10 N/A 08D 7.5 88,000 7.8 N/A 11.20 12.40 09D 8.5 99,000 8.8 N/A 11.20 12.40

NOTE: All AHRI ratings are based on 230, 460 and 575 volt. ** Electric Drive (direct drive) X13 5 speed/torque motor. SEER rating is 13.0 for belt drive. NA Not applicable

548J* HSPF

548J

04A 7.70 18,200 N/A 35,600 N/A 05A 7.70 23,600 N/A 45,500 N/A 06A 7.70 31,200 N/A 58,000 N/A 07A N/A 34,800 2.25 67,000 3.30 08D N/A 48,000 2.25 86,000 3.30 09D N/A 54,500 2.25 96,000 3.30

LEGEND

ARI --- Air--- Conditioning, Heating and Refrigeration

Institute

ASHRAE --- American Society of Heating, Refrigerating

and Air Conditioning, Inc. COP --- Coefficient of Performance EER --- Energy Efficiency Ratio HSPF --- Heating Seasonal Performance Factor IPLV --- Integrated Part Load Value SEER --- Seasonal Energy Efficiency Ratio

NET COOLING

CAPACITY

(BTUH)

CAPACITY

(BTUH)

TOTAL

POWER

(kW)

HEATING MODE

HEATING, LOW HEATING, HIGH

NOTES:

1. Rated and certified under ARI Standard 210/240 --- 06 or

2. Ratings are based on:

3. All 548J units comply with ASHRAE 90.1 2001, 2004 Energy

4. Where appropriate, 548J units comply with US Energy Policy

SEER EER IPLV

COP

CAPACITY

(BTUH)

COP

340/360--- 07, as appropriate.

Cooling Standard: 80_F(27_C) db, 67_F(19_C) wb indoor air temp and 95_F db outdoor air temp. IPLV Standard:80_F(27_C) db, 67_F(19_C) wb indoor air temp and 80_F(27_C) db outdoor air temp.

Standard for minimum SEER and EER requirements.

Act (2005). Refer to state and local codes or visit the following website: http://bcap--- energy. org to determine if compliance with this standard pertains to your state, territory, or municipality.

air flow may reduc e energy effic iency and shorten equipment lif e.

Table 3 – MINIMUM -- MAXIMUM AIRFLOWS ELECTRIC HEAT

UNIT

548J*04 900 1500 900 1500 548J*05 1200 2000 1200 2000 548J*06 1500 2500 1500 2500 548J*07 1800 3000 1800 3000 548J*08 2250 3750 2250** 3750 548J*09 2550 4250 2250** 4250

MINIMUM MAXIMUM MINIMUM MAXIMUM

COOLING ELECTRIC HEATERS

**Minimum electric heat CFM exceptions :

UNIT UNIT VOLTAGE HEATER kW

548J*08 548J*09

575

17.0

34.0 2350

UNIT

CONFIGURATION

Horizontal or Vertical

REQUIRED MINIMUM

CFM

2800

Table 4 – SOUND PERFORMANCE TABLE

548J*

04A 77 78.9 81.7 74.9 72.5 70.3 65.6 65.6 62.6 05A 80 90.4 84.6 77.6 77.5 74.8 70.6 68.0 64.2 06A 80 92.7 84.9 79 76.7 73.8 69.6 66.4 62.8 07A 78 88.0 79.5 76.2 75.8 72.5 68.6 65.7 62.4 08D 82 89.7 81.5 80.5 79.2 77.1 73.2 70.2 67.4 09D 84 90.8 85.2 81.6 79.5 78.1 74.0 70.4 66.5

LEGEND

dB --- Decibel

A --- W E I G H T E D 63 125 250 500 1000 2000 4000 8000

OUTDOOR SOUND (DB)

NOTES:

1. Outdoor sound data is measure in accordance with ARI standard 270 ---95.

2. Measurements are expressed in terms of sound power. Do not compare these values to sound pressure values because sound pressure accounts for specific environmental factors which do not match individual applications. Sound power values are independent of the environment and therefore more accurate.

3. A--- weighted sound ratings filter out very high and very low frequencies, to better approximate the response of an “average” human ear. A --- weighted measurements for Bryant units are taken in accordance with 270 --- 95.

548J

Table 5 – PHYSICAL DATA (COOLING) 3 -- 6 TONS

548J*04 548J*05 548J*06 548J*07

Refrigeration System

#Circuits/#Comp./Type 1/1/Scroll 1/1/Scroll 1/1/Scroll 1/1/Scroll

Puronr refrig. (R--- 410A) charge per circuit A/B (lbs--- oz) 9 --- 8 / --- 1 0 --- 3 / --- 1 2 --- 1 3 / --- 1 6 --- 1 3 / ---

O i l A / B ( o z ) 4 2 / --- 4 2 / --- 4 2 / --- 5 6 / ---

Metering Device Acutrol Acutrol Acutrol Acutrol

High---pressure Trip / Reset (psig) 630 / 505 630 / 505 630 / 505 630 / 505

Loss of Charge Pressure Trip / Reset (psig) 27 / 44 27 / 44 27 / 44 27 / 44

Evap. Coil

Material Cu / Al Cu / Al Cu / Al Cu / Al

Coil type 3/8” RTPF 3/8” RTPF 3/8” RTPF 3/8” RTPF

Rows / FPI 3 / 15 3/15 4/ 15 4/ 15

Total Fa c e Ar e a (ft2)5.5 5.5 7.3 7.3

Condensate Drain Conn. Size 3/4” 3/4” 3/4” 3/4”

Evap. Fan and Motor

548J

Motor Qty / Drive Type 1/Direct 1/Direct 1/Direct N/A

Max BHP 1 1 1

RPM Range 600--- 1200 600---1200 600 ---1200

1phase

Standard Static

3phase

Standard Static

3phase

Medium Static

3phase

High Static

Fan Diameter x Length (in) 10 x 10 10 x 10 11 x 10

Fan Diameter x Length (in) 10 x 10 10 x 10 11 x 10 10 x 10

Fan Diameter x Length (in) 10 x 10 10 x 10 10 x 10 10 x 10

Motor Frame Size 48 48 48

Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal n/Centrifugal

Motor Qty / Drive Type 1/Direct 1/Direct 1/Direct 1/Belt

Max BHP 1 1 1 1.5

RPM Range 600--- 1200 600---1200 600 ---1200 878--- 1192

Motor Frame Size 48 48 48 56

Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal

Motor Qty / Drive Type

Max BHP

RPM Range 819--- 1251 920---1303 1066--- 1380 1066 --- 1380

Motor Frame Size 56 56 56 56

Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal

Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt 1/Belt

Max BHP 2 2 2.9 2.9

RPM Range 1035 ---1466 1035--- 1466 1208--- 1639 1208 ---1639

Motor Frame Size 56 56 56 56

Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal

1/Belt 1/Belt 1/Belt 1/Belt

1.5 1.5 2 2.9

Cond. Coil

Total Fa c e Ar e a (ft2) 10.7 12.7118055 15 21.25

Cond. fan / motor

Qty / Motor Drive Type 1 / direct 1/direct 1/direct 1/direct

Motor HP / RPM 1/8 / 825 1/4 / 1100 1/4 / 1100 1/4 / 1100

Fan diameter (in) 22 22 22 22

Filters

RAFilter#/Size(in) 2/16x25x2 2/16x25x2 4/16x16x2 4/16x16x2

OA inlet screen # / Size (in) 1/20x24x1 1/20x24x1 1/20x24x1 1/20x24x1

Material Cu / Al Cu / Al Cu / Al Cu / Al

Coil type 3/8” RTPF 3/8” RTPF 3/8” RTPF 3/8” RTPF

Rows / FPI 2 / 17 2/17 2/17 2/17

Table 6 – PHYSICAL DATA (COOLING) 7.5 -- 8.5 TONS

548J*08 548J*09

Refrigeration System

#Circuits/#Comp./Type 2/2/Scroll 2/2/Scroll

Puronr refrig. (R--- 410A) charge per circuit A/B (lbs--- oz) 1 0 --- 3 / 1 0 --- 3 1 1 --- 2 / 1 1 --- 2

Oil A/B (oz) 42 / 42 42 / 42

Metering Device Accutrol Accutrol

High---pressure Trip / Reset (psig) 630 / 505 630 / 505

Loss of Charge Pressure Trip / Reset (psig) 27 / 44 27 / 44

Evap. Coil

Material Cu / Al Cu / Al

Coil type 3/8” RTPF 3/8” RTPF

Rows / FPI 3 / 15 4/15

Total Fa c e Ar e a (ft2) 11.1 11.1

Condensate Drain Conn. Size 3/4” 3/4”

Evap. Fan and Motor

Motor Qty / Drive Type 1/Belt 1/Belt

Max BHP 1.2 1.2

RPM Range 460--- 652 460--- 652

3phase

Standard Static

Fan Diameter x Length (in) 15 x 15 15 x 15

Motor Frame Size 56 56

Fan Qty / Type 1/Centrifugal 1/Centrifugal

548J

3phase

Medium Static

3phase

High Static

Cond. Coil

Cond. fan / motor

Filters

Motor Qty / Drive Type

Max BHP

RPM Range 591--- 838 591--- 838

Motor Frame Size 56 56

Fan Qty / Type 1/Centrifugal 1/Centrifugal

Fan Diameter x Length (in) 15 x 15 15 x 15

Motor Qty / Drive Type 1/Belt 1/Belt

Max BHP 2.9 2.9

RPM Range 838---1084 838--- 1084

Motor Frame Size 56 56

Fan Qty / Type 1/Centrifugal 1/Centrifugal

Fan Diameter x Length (in) 15 x 15 15 x 15

Material Cu / Al Cu / Al

Coil type 3/8” RTPF 3/8” RTPF

Rows / FPI 2 / 17 2/17

Total Fa c e Ar e a (ft2) 25.1 25.1

Qty / Motor Drive Type 2 / direct 2/direct

Motor HP / RPM 1/4 / 1100 1/4 / 1100

Fan diameter (in) 22.0 22.0

RAFilter#/Size(in) 4/16x20x2 4/20x20x2

OA inlet screen # / Size (in) 1/20x24x1 1/20x24x1

1/Belt 1/Belt

2.9 2.9

Table 7 – ELECTRIC HEAT -- ELECTRICAL DATA 3 TONS

SINGLE POINT KIT PART NUMBER

IFM

UNIT

548J

548J*04

--- No Single Point Kit required

LEGEND

APP PWR --- 208 / 230V / 460V / 575V BD --- Belt drive motor C.O. --- Convenient outlet DD --- Electric Drive X13 5 speed/torque motor FLA - -- Full load amps IFM --- Indoor fan motor NOM PWR --- 240V / 480V / 600V P.E . --- P o w e r e x h a u s t PWRD --- Powered convenient outlet UNPWRD --- Unpowered convenient outlet

TYPE

N O M . V --- P H --- H Z

STD

208/230--- 1 --- 60

STD

MED

208/230--- 3 --- 60

HIGH

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

ELECTRIC HEATER

PAR T NU MB ER

CRHEATERXXXXXX

101A00 4.4 3.3/4.0 037A00 037A00 037A00 040A00 102A00 6.5 4.9/6.0 040A00 040A00 040A00 040A00 103B00 8.7 6.5/8.0 040A00 040A00 040A00 040A00 104B00 10.5 7.9/9.6 040A00 040A00 040A00 040A00

102A00,102A00 13.0 9.8/11.9 041A00 041A00 041A00 041A00

101A00 4.4 3.3/4.0 --- --- --- --102A00 6.5 4.9/6.0 --- --- --- 037A00 103B00 8.7 6.5/8.0 037A00 037A00 037A00 037A00 104B00 10.5 7.9/9.6 037A00 037A00 038A00 038A00 105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 101A00 4.4 3.3/4.0 --- --- --- --102A00 6.5 4.9/6.0 --- --- --- --103B00 8.7 6.5/8.0 --- 037A00 037A00 037A00 104B00 10.5 7.9/9.6 037A00 037A00 037A00 038A00 105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 101A00 4.4 3.3/4.0 --- --- --- --102A00 6.5 4.9/6.0 --- --- --- --103B00 8.7 6.5/8.0 --- 037A00 037A00 037A00 104B00 10.5 7.9/9.6 037A00 037A00 037A00 038A00 105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 106A00 6.0 5.5 --- --- --- --107A00 8.8 8.1 --- --- --- --108A00 11.5 10.6 --- --- --- --109A00 14.0 12.9 --- --- --- --106A00 6.0 5.5 --- --- --- --107A00 8.8 8.1 --- --- --- --108A00 11.5 10.6 --- --- --- --109A00 14.0 12.9 --- --- --- --106A00 6.0 5.5 --- --- --- --107A00 8.8 8.1 --- --- --- --108A00 11.5 10.6 --- --- --- --109A00 14.0 12.9 --- --- --- ---

NOM PWR

(kW)

APP PWR (kW)

WITHOUT C.O. or UNPWRD C.O. WITH PWRD C.O.

WITHOUT P.E. WITH P.E. WITHOUT P.E. WITH P.E.

CRSINGLEXXXXXX

Table 7 -- (cont.) ELECTRIC HEAT -- ELECTRICAL DATA 4 TONS

SINGLE POINT KIT PART NUMBER

IFM

UNIT

548J*05

--- No Single Point Kit required

LEGEND

TYPE

N O M . V --- P H --- H Z

STD

208/230--- 1 --- 60

STD

MED

208/230--- 3 --- 60

HIGH

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

ELECTRIC HEATER

PAR T NU MB ER

CRHEATERXXXXXX

101A00 4.4 3.3/4.0 037A00 040A00 040A00 040A00

103B00 8.7 6.5/8.0 040A00 040A00 040A00 040A00 102A00,102A00 13.0 9.8/11.9 041A00 041A00 041A00 041A00 103B00,103B00 17.4 13.1/16.0 041A00 041A00 041A00 041A00 104B00,104B00 21.0 15.8/19.3 041A00 041A00 041A00 041A00

102A00 6.5 4.9/6.0 --- --- --- 037A00

103B00 8.7 6.5/8.0 037A00 037A00 037A00 037A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00

102A00 6.5 4.9/6.0 --- --- --- ---

103B00 8.7 6.5/8.0 --- 037A00 037A00 037A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00

102A00 6.5 4.9/6.0 --- --- --- ---

103B00 8.7 6.5/8.0 --- 037A00 037A00 037A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- --108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- --108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- --108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00

NOM PWR

(kW)

APP PWR (kW)

WITHOUT C.O. or UNPWRD C.O. WITH PWRD C.O.

WITHOUT P.E. WITH P.E. WITHOUT P.E. WITH P.E.

CRSINGLEXXXXXX

548J

Table 7 -- (cont.) ELECTRIC HEAT -- ELECTRICAL DATA 5 TONS

SINGLE POINT KIT PART NUMBER

IFM

UNIT

TYPE

N O M . V --- P H --- H Z

STD

208/230--- 1 --- 60

STD

548J

MED

208/230--- 3 --- 60

HIGH

548J*06

--- No Single Point Kit required

LEGEND

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

ELECTRIC HEATER

PAR T NU MB ER

CRHEATERXXXXXX

102A00 6.5 4.9/6.0 040A00 040A00 040A00 040A00

102A00 6.5 4.9/6.0 --- --- 037A00 037A00

104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00 104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00

102A00 6.5 4.9/6.0 --- --- --- 037A00

104B00 10.5 7.9/9.6 037A00 037A00 038A00 038A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00 104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00

102A00 6.5 4.9/6.0 --- --- 037A00 037A00

104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00 104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- --108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00 108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- --108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00 108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- --108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00 108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00

NOM PWR

(kW)

APP PWR (kW)

WITHOUT C.O. or UNPWRD C.O. WITH PWRD C.O.

WITHOUT P.E. WITH P.E. WITHOUT P.E. WITH P.E.

CRSINGLEXXXXXX

Table 7 -- (cont.) ELECTRIC HEAT -- ELECTRICAL DATA 6 TONS

SINGLE POINT KIT PART NUMBER

IFM

UNIT

548J*07

--- No Single Point Kit required

LEGEND

APP PWR --- 208 / 230V / 460V / 575V C.O. --- Convenient outlet FLA - -- Full load amps IFM --- Indoor fan motor NOM PWR --- 240V / 480V / 600V P.E . --- P o w e r e x h a u s t PWRD --- Powered convenient outlet UNPWRD --- Unpowered convenient outlet

TYPE

N O M . V --- P H --- H Z

STD

MED

208/230--- 3--- 60

HIGH

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

ELECTRIC HEATER

PAR T NU MB ER

CRHEATERXXXXXX

102A00 6.5 4.9/6.0 --- 037A00 037A00 037A00 104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00 104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00

102A00 6.5 4.9/6.0 037A00 037A00 037A00 037A00

104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00 104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00

102A00 6.5 4.9/6.0 037A00 037A00 037A00 037A00

104B00 10.5 7.9/9.6 038A00 038A00 038A00 038A00

105A00 16.0 12.0/14.7 038A00 038A00 038A00 038A00 104B00,104B00 21.0 15.8/19.3 039A00 039A00 039A00 039A00 104B00,105A00 26.5 19.9/24.3 039A00 039A00 039A00 039A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- ---

108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00 108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- ---

108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00 108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00

106A00 6.0 5.5 --- --- --- ---

108A00 11.5 10.6 --- --- --- ---

109A00 14.0 12.9 --- --- --- ---

108A00,108A00 23.0 21.1 037A00 037A00 037A00 037A00 108A00,109A00 25.5 23.4 037A00 037A00 037A00 037A00

NOM PWR

(kW)

APP PWR (kW)

WITHOUT C.O. or UNPWRD C.O. WITH PWRD C.O.

WITHOUT P.E. WITH P.E. WITHOUT P.E. WITH P.E.

CRSINGLEXXXXXX

548J

Table 7 -- (cont.) ELECTRIC HEAT -- ELECTRICAL DATA 7.5 TONS

SINGLE POINT KIT PART NUMBER

IFM

UNIT

TYPE

N O M . V --- P H --- H Z

STD

MED

208/230--- 3 --- 60

548J

HIGH

STD

548J*08 (2---STAGE COOL)

--- No Single Point Kit required

LEGEND

MED

4 6 0 --- 3 --- 6 0

HIGH

STD

MED

5 7 5 --- 3 --- 6 0

HIGH

ELECTRIC HEATER

PAR T NU MB ER

CRHEATERXXXXXX

117A00 10.4 7.8/9.6 049A00 049A00 049A00 049A00 110A00 16.0 12.0/14.7 049A00 049A00 049A00 049A00 111A00 24.8 18.6/22.8 051A00 051A00 051A00 051A00 112A00 32.0 24.0/29.4 051A00 051A00 051A00 051A00

112A00,117A00 42.4 31.8/38.9 053A00 053A00 053A00 053A00

117A00 10.4 7.8/9.6 049A00 049A00 049A00 049A00 110A00 16.0 12.0/14.7 049A00 049A00 049A00 049A00 111A00 24.8 18.6/22.8 051A00 051A00 051A00 051A00 112A00 32.0 24.0/29.4 051A00 051A00 051A00 051A00

112A00,117A00 42.4 31.8/38.9 053A00 053A00 053A00 053A00

117A00 10.4 7.8/9.6 049A00 049A00 049A00 049A00 110A00 16.0 12.0/14.7 049A00 049A00 049A00 049A00 111A00 24.8 18.6/22.8 051A00 051A00 051A00 051A00 112A00 32.0 24.0/29.4 051A00 051A00 051A00 051A00

112A00,117A00 42.4 31.8/38.9 053A00 053A00 053A00 053A00

116A00 13.9 12.8 047A00 047A00 047A00 047A00 113A00 16.5 15.2 047A00 047A00 047A00 047A00 114A00 27.8 25.5 047A00 050A00 050A00 050A00 115A00 33.0 30.3 050A00 050A00 050A00 050A00

114A00,116A00 41.7 38.3 052A00 052A00 052A00 052A00

116A00 13.9 12.8 047A00 047A00 047A00 047A00 113A00 16.5 15.2 047A00 047A00 047A00 047A00 114A00 27.8 25.5 050A00 050A00 050A00 050A00 115A00 33.0 30.3 050A00 050A00 050A00 050A00

114A00,116A00 41.7 38.3 052A00 052A00 052A00 052A00

116A00 13.9 12.8 047A00 047A00 047A00 047A00 113A00 16.5 15.2 047A00 047A00 047A00 047A00 114A00 27.8 25.5 050A00 050A00 050A00 050A00 115A00 33.0 30.3 050A00 050A00 050A00 050A00

114A00,116A00 41.7 38.3 052A00 052A00 052A00 052A00

118A00 17.0 17.0 047A00 047A00 047A00 047A00 119A00 34.0 34.0 050A00 050A00 050A00 050A00 118A00 17.0 17.0 047A00 047A00 047A00 047A00 119A00 34.0 34.0 050A00 050A00 050A00 050A00 118A00 17.0 17.0 047A00 047A00 047A00 047A00 119A00 34.0 34.0 050A00 050A00 050A00 050A00

NOM PWR

(kW)

APP PWR (kW)

WITHOUT C.O. or UNPWRD C.O. WITH PWRD C.O.

WITHOUT P.E. WITH P.E. WITHOUT P.E. WITH P.E.

CRSINGLEXXXXXX

Table 7 -- (cont.) ELECTRIC HEAT -- ELECTRICAL DATA 8.5 TONS

SINGLE POINT KIT PART NUMBER

IFM

N O M . V --- P H --- H Z

208/230--- 3--- 60

4 6 0 --- 3 --- 6 0

5 7 5 --- 3 --- 6 0

TYPE

STD

MED

HIGH

STD

MED

HIGH

STD

MED

HIGH

UNIT

548J*09 (2---STAGE COOL)

--- No Single Point Kit required

LEGEND

ELECTRIC HEATER

PAR T NU MB ER

CRHEATERXXXXXX

117A00 10.4 7.8/9.6 049A00 049A00 049A00 049A00 110A00 16.0 12.0/14.7 049A00 049A00 049A00 049A00 111A00 24.8 18.6/22.8 051A00 051A00 051A00 051A00 112A00 32.0 24.0/29.4 051A00 051A00 051A00 051A00

112A00,117A00 42.4 31.8/38.9 053A00 053A00 053A00 053A00

117A00 10.4 7.8/9.6 049A00 049A00 049A00 049A00 110A00 16.0 12.0/14.7 049A00 049A00 049A00 049A00 111A00 24.8 18.6/22.8 051A00 051A00 051A00 051A00 112A00 32.0 24.0/29.4 051A00 051A00 051A00 051A00

112A00,117A00 42.4 31.8/38.9 053A00 053A00 053A00 053A00

117A00 10.4 7.8/9.6 049A00 049A00 049A00 049A00 110A00 16.0 12.0/14.7 049A00 049A00 049A00 049A00 111A00 24.8 18.6/22.8 051A00 051A00 051A00 051A00 112A00 32.0 24.0/29.4 051A00 051A00 051A00 051A00

112A00,117A00 42.4 31.8/38.9 053A00 053A00 053A00 053A00

116A00 13.9 12.8 047A00 047A00 047A00 047A00 113A00 16.5 15.2 047A00 047A00 047A00 047A00 114A00 27.8 25.5 050A00 050A00 050A00 050A00 115A00 33.0 30.3 050A00 050A00 050A00 050A00

114A00,116A00 41.7 38.3 052A00 052A00 052A00 052A00

116A00 13.9 12.8 047A00 047A00 047A00 047A00 113A00 16.5 15.2 047A00 047A00 047A00 047A00 114A00 27.8 25.5 050A00 050A00 050A00 050A00 115A00 33.0 30.3 050A00 050A00 050A00 050A00

114A00,116A00 41.7 38.3 052A00 052A00 052A00 052A00

116A00 13.9 12.8 047A00 047A00 047A00 047A00 113A00 16.5 15.2 047A00 047A00 047A00 047A00 114A00 27.8 25.5 050A00 050A00 050A00 050A00 115A00 33.0 30.3 050A00 050A00 050A00 050A00

114A00,116A00 41.7 38.3 052A00 052A00 052A00 052A00

NOM PWR

(kW)

APP PWR (kW)

WITHOUT C.O. or UNPWRD C.O. WITH PWRD C.O.

WITHOUT P.E. WITH P.E. WITHOUT P.E. WITH P.E.

CRSINGLEXXXXXX

548J

WEIGHTS & DIMENSIONS

C09018

Fig. 1 -- Dimensions 548J 04--07

WEIGHTS & DIMENSIONS (cont.)

Fig. 2 -- Dimensions 548J 04--07

548J

C09019

Fig. 3 -- Service Clearance

LOC DIMENSION CONDITION

48” (1219 mm) Unit disconnect is mounted on panel

18” (457 mm) No disconnect, convenience outlet option 18” (457 mm) Recommended service clearance 12” (305 mm) Minimum clearance

42” (1067 mm) Surface behind servicer is grounded (e.g., metal, masonry wall)

36” (914 mm) Surface behind servicer is electrically non ---conductive (e.g., wood, fiberglass)

Special Check for sources of flue products within 10--- ft of unit fresh air intake hood 36” (914 mm) Side condensate drain is used 18” (457 mm) Minimum clearance

42” (1067 mm) Surface behind servicer is grounded (e.g., metal, masonry wall, another unit)

36” (914 mm) Surface behind servicer is electrically non ---conductive (e.g., wood, fiberglass)

C08337

WEIGHTS & DIMENSIONS (cont.)

548J

ROOFCURB ACCESSORY

CRRFCURB001A01

CRRFCURB002A01

1’ - 2” [356]

2’ - 0” [610]

UNIT SIZE

548J*04-07A

C08560

Fig. 4 -- Curb Dimensions 548J 04--07

WEIGHTS & DIMENSIONS (cont.)

548J

Vertical Connections / Economizer

Horizontal Connections / Economizer

Fig. 5 -- Dimensions 548J 08--09

C08679

548J

WEIGHTS & DIMENSIONS (cont.)

C08680

Fig. 6 -- Dimensions 548J 08--09

Fig. 7 -- Service Clearance

LOC DIMENSION CONDITION

48” (1219 mm) Unit disconnect is mounted on panel

18” (457 mm) No disconnect, convenience outlet option 18” (457 mm) Recommended service clearance 12” (305 mm) Minimum clearance

42” (1067 mm) Surface behind servicer is grounded (e.g., metal, masonry wall)

36” (914 mm) Surface behind servicer is electrically non ---conductive (e.g., wood, fiberglass)

Special Check for sources of flue products within 10--- ft of unit fresh air intake hood 36” (914 mm) Side condensate drain is used 18” (457 mm) Minimum clearance

42” (1067 mm) Surface behind servicer is grounded (e.g., metal, masonry wall, another unit)

36” (914 mm) Surface behind servicer is electrically non ---conductive (e.g., wood, fiberglass)

C08337

WEIGHTS & DIMENSIONS (cont.)

548J08, 09

ROOFCURB ACCESSORY

CRRFCURB003A01

CRRFCURB004A01

1’ - 2” [356]

2’ - 0” [610]

UNIT SIZE

548J08, 09

548J

C08561

Fig. 8 -- Curb Dimensions 548J 08--09

APPLICATION DATA

Min operating ambient temp (cooling):

In mechanical cooling mode, your Bryant rooftop can safely operate down t o an outdoor ambient temperature of 25_F(--4_C). It is possible to provide cooling at lower outdoor ambient temperatures by using less outside air, economizers, and/or accessory low ambient kits.

Max operating ambient temp (cooling):

The maximum operating ambient temperature for cooling mode is 115_F(46_C). While cooling operation above 115_F(46_C) may be possible, it could cause either a reduction in performance, reliability, or a protective action by the unit’s internal safety devices.

Min and max airflow (cooling mode):

548J

To maintain safe and reliable operation of your rooftop, operate within the c ooling airflow limits. Operating above the max may ca use blow--off, undesired airflow noise, or airflow related problems with the rooftop unit. Operating below the min may cause problems with coil freeze--up.

Airflow:

All units are draw--though in cooling mode.

Outdoor air application strategies:

Economizers reduce operating expenses and compressor run time by providing a free source of cooling and a means of ventilation to match application changing needs. In fact, they should be considered for most applications. Also, consider the various economizer control methods and their benefits, as well as sensors required to accomplish your application goals. Please contact your local Bryant representative for assistance.

Motor limits, break horsepower (BHP):

Due to Bryant’s internal unit design, air path, and specially designed motors, the full horsepower (maximum continuous BHP) band, as listed in this manual, can be used with the utmost confidence. There is no need for extra safety factors, as Bryant’s motors are designed and rigorously tested to use the entire, listed BHP range without either nuisance tripping or premature motor failure.

Sizing a rooftop

Bigger isn’t necessarily better. While an air conditioner needs to have enough capacity to meet the load, it doesn’t need excess capacity. In fact, having excess capacity typically results in very poor part load performance and humidity control.

Using higher design temperatures than ASHRAE recommends for your location, adding “safety factors” to the calculated load, and rounding up to the next largest unit, are all signs of oversizing air conditioners. Oversizing can cause short--cycling, and short cycling leads to poor humidity control, reduced efficiency, higher utility bills, drastic indoor temperature swings, excessive noise, and increased wear and tear on the air conditioner.

Rather tha n oversizing an air conditioner, wise contractors and engineers “right--size ” or even slightly undersize air conditioners. Correctly sizing an air conditioner controls humidity better; promotes efficiency; reduces utility bills; extends equipment life, and maintains even, comfortable temperatures.

Low ambient applications

When equipped with a Bryant economizer, your rooftop unit can cool your space by bringing in fresh, cool outside air. In fact, when so equipped, accessory low--ambient kit may not be necessary. In low ambient conditions, unless the outdoor air is excessively humid or contaminated, economizer--based “free cooling” is the preferred less costly and energy conscious method.

In low ambient applications where outside air might not be desired (such as contaminated or excessively humid outdoor environments), your Bryant rooftop can operate t o ambient tempe ratures down to --20_F(--29_C) using the recommended accessory Motor master low ambient controller.

SELECTION PROCEDURE (WITH 548J*07 EXAMPLE)

(Selection software by Bryant saves time by performing many of the steps below.)

I. Determine cooling and heating loads.

Given: Mixed Air Drybulb 80_F(27_C) Mixed Air Wetbulb 67_F(19_C) Ambient Drybulb 95_F(35_C) TC

Load

SHC

Load

Outdoor-Air Winter Design Temp 0_F(--18_C) Indoor-Air Winter Design Temp 70_F(21_C) Vertical Supply Air 2100 CFM External Static Pressure 0.66 in.wg Electrical Characteristics 230--3--60

II. Make an initial guess at cooling tons.

Refrig. tons = TC Refrig. tons = 65.0 / 12 = 5.42 tons

In this case, start by looking at t he 548J*07.

III. Look up the rooftop’s TC and SHC.

Table 11 shows that, at the application’s supply air CFM, mixed air and ambient temperatures, the 548J*07 supplies: TC SHC

= 69.0 MBH

Load

= 50.7 MBH.

/ 12 MBH per ton

Load

65.0 MBH

46.0 MBH

45.0 MBH

The require d heating capacity is 45,000 Btuh. Therefore, 20,700 Btuh (45,000 – 24,300) additional electric heat is required.

Determine additional electric heat capacity in kW.

20,700 Btuh

3413 Btuh/kW

=6.1kWofheatrequired.

Enter the Electric Heating Capacities table for 548J*07 at 208/230, 3--phase. The 6.5-kW heater at 230V most closely satisfies the heating required.

6.5 kW x 3413 = 22,185 Btuh

Total unit heating capacity is 46,485 Btuh (22,185 + 24,300).

VI. Calculate RTU Latent Heat Capacity

LC = TC -- SHC LC = 69.0 MBH -- 50.7 MBH = 18.3 MBH

VII. Compare RTU capacities to loads.

Compare the rooftop’s SHC and LC to the building’s Sensible and Latent Heat Loads. See Notes 1 and 2.

VIII. Select factory options (FIOP)

Local code requi res an economizer for any unit with TC larger than 65.0 MBH.

548J

IV. Calculate the building Late nt Heat Load.

LC LC

=TC

Load

= 65.0 MBH -- 46.0 MBH = 19.0 MBH

Load

-- S H C

Load

V. Select electric heat.

Enter the Instantaneous and Integrated Heating Ratings, Table 17 at 2100 cfm. At 70_F(21_C) return indoor air and 0°F(--18_C) air entering outdoor coil, the integrated heating capacity after interpolation, is 24,300 Btuh. (Select integrated heating capacity value since deductions for outdoor-coil frost and defrosting have already been made. No correction is required.)

Legend

BHP — Break horsepower FLA — Full load amps HC — Heating Capacities LC — Latent capacity LRA — Lock rotor amp MBH — (1,000) BTUH MCA — Min. circuit ampacity MOCP — Max. over- -- current protection RPM — Revolutions per minute RTU — Rooftop unit SHC — Sensible heat capacity TC — Total capacity

IX. Calculate the total static pressure.

External static pressure 0.66 in. wg Sum of FIOP/Accessory static +0.14 in.

Total Static Pressure 0.80 in. wg

X. Look up the Indoor Fan RPM & BHP.

Table 34 shows, at 2100 CFM & ESP= 0.8, RPM = 1268 & BHP = 1.52

XI. Determine electrical requirements

Table 25 shows the MCA and MOCP of a 548J*07 (without convenience outlet) with 6.5 kW electric heater as:

MCA = 52.3 amps & MOCP = 60 amps Min. Disconnect Size: FLA = 50 & LRA = 199.

NOTES:

1. Selecting a unit with a SHC slightly lower than the SHC often better than oversizing. Slightly lower SHC’s will help control indoor humidity, and prevent temperature swings.

2. If the rooftop’s capacity meets the Sensible Heat Load, but not the Latent H eat Load.

Load

Table 8 – COOLING CAPACITIES 1--STAGE COOLING 3 TONS

AMBIENT TEMPERATURE

548J*04

75 80 85 75 80 85 75 80 85 75 80 85

THC 31.4 31.4 35.7 29.6 29.6 33.6 27.6 27.6 31.5 25.6 25.6 29.1

SHC 27.1 31.4 35.7 25.5 29.6 33.6 23.8 27.6 31.5 22.0 25.6 29.1 THC 33.5 33.5 34.4 30.9 30.9 33.2 28.3 28.3 31.9 25.7 25.7 30.4

SHC 24.8 29.6 34.4 23.6 28.4 33.2 22.3 27.1 31.9 20.9 25.7 30.4 THC 38.0 38.0 38.0 35.3 35.3 35.3 32.4 32.4 32.4 29.4 29.4 29.4

900 Cfm

EAT (wb)

548J

EAT (wb)

1050 Cfm

EAT (wb)

1200 Cfm

EAT (wb)

1350 Cfm

EAT (wb)

1500 Cfm

LEGEND

--- --- D o n o t o p e r a t e Cfm --- Cubic feet per minute (supply air) EAT(db) --- Entering air temperature (dry bulb) EAT(wb) --- Entering air temperature (wet bulb) SHC --- Sensible heat capacity TC --- Total capacity

SHC 21.0 25.8 30.7 19.8 24.6 29.5 18.6 23.4 28.2 17.3 22.2 27.0 THC 42.1 42.1 42.1 39.7 39.7 39.7 37.1 37.1 37.1 34.0 34.0 34.0

SHC 16.7 21.6 26.4 15.8 20.6 25.5 14.7 19.6 24.4 13.6 18.4 23.2 THC --- 44.9 44.9 --- 43.0 43.0 --- 40.5 40.5 --- 37.5 37.5

SHC --- 17.8 22.7 --- 17.1 22.0 --- 16.2 21.1 --- 15.2 20.1 THC 33.7 33.7 38.3 31.7 31.7 36.0 29.6 29.6 33.6 27.4 27.4 31.2

SHC 29.1 33.7 38.3 27.3 31.7 36.0 25.5 29.6 33.6 23.6 27.4 31.2 THC 35.0 35.0 38.1 32.3 32.3 36.7 29.7 29.7 35.1 27.4 27.4 32.5

SHC 26.9 32.5 38.1 25.6 31.2 36.7 24.2 29.7 35.1 22.4 27.4 32.5 THC 39.4 39.4 39.4 36.7 36.7 36.7 33.7 33.7 33.7 30.5 30.5 30.5

SHC 22.4 28 33.6 21.2 26.8 32.4 20.0 25.6 31.2 18.7 24.3 29.9 THC 43.3 43.3 43.3 41.0 41.0 41.0 38.3 38.3 38.3 35.2 35.2 35.2

SHC 17.2 22.8 28.4 16.4 22.0 27.7 15.3 21.0 26.6 14.2 19.8 25.4 THC --- 45.8 45.8 --- 44.0 44.0 --- 41.6 41.6 --- 38.6 38.6

SHC --- 18.4 24.2 --- 17.8 23.5 --- 16.9 22.7 --- 15.9 21.6 THC 35.7 35.7 40.5 33.5 33.5 38.1 31.3 31.3 35.6 28.9 28.9 32.9

SHC 30.8 35.7 40.5 28.9 33.5 38.1 27.0 31.3 35.6 24.9 28.9 32.9 THC 36.3 36.3 41.5 33.6 33.6 39.7 31.3 31.3 37.1 29.0 29.0 34.3

SHC 28.9 35.2 41.5 27.4 33.6 39.7 25.6 31.3 37.1 23.6 29.0 34.3 THC 40.4 40.4 40.4 37.8 37.8 37.8 34.7 34.7 34.7 31.4 31.4 32.6

SHC 23.6 30.0 36.4 22.5 28.9 35.3 21.3 27.6 34.0 19.9 26.3 32.6 THC 44.1 44.1 44.1 42.0 42.0 42.0 39.2 39.2 39.2 36.0 36.0 36.0

SHC 17.7 23.9 30.2 16.9 23.3 29.6 15.9 22.3 28.6 14.7 21.1 27.5 THC --- 46.6 46.6 --- 44.4 44.4 --- 42.3 42.3 --- 39.4 39.4

SHC --- 19.0 25.5 --- 18.3 24.7 --- 17.6 24.0 --- 16.6 23.1 THC 37.5 37.5 42.6 35.1 35.1 40.0 32.8 32.8 37.3 30.3 30.3 34.5

SHC 32.4 37.5 42.6 30.3 35.1 40.0 28.3 32.8 37.3 26.1 30.3 34.5 THC 37.6 37.6 44.4 35.2 35.2 41.6 32.8 32.8 38.8 30.3 30.3 35.9

SHC 30.7 37.6 44.4 28.8 35.2 41.6 26.8 32.8 38.8 24.8 30.3 35.9 THC 41.2 41.2 41.2 38.6 38.6 38.6 35.6 35.6 36.7 32.2 32.2 35.3

SHC 24.8 31.9 39 23.7 30.8 38.0 22.5 29.6 36.7 21.1 28.2 35.3 THC 44.7 44.7 44.7 42.7 42.7 42.7 39.9 39.9 39.9 36.7 36.7 36.7

SHC 18.0 24.9 31.8 17.3 24.4 31.5 16.3 23.5 30.6 15.2 22.3 29.5 THC --- 47.2 47.2 --- 44.9 44.9 --- 42.9 42.9 --- 39.9 39.9

SHC --- 19.5 26.6 --- 18.7 25.7 --- 18.1 25.2 --- 17.2 24.4 THC 38.8 38.8 44.1 36.6 36.6 41.6 34.1 34.1 38.8 31.5 31.5 35.8

SHC 33.5 38.8 44.1 31.6 36.6 41.6 29.4 34.1 38.8 27.2 31.5 35.8 THC 38.8 38.8 45.9 36.6 36.6 43.3 34.1 34.1 40.4 31.6 31.6 37.3

SHC 31.7 38.8 45.9 29.9 36.6 43.3 27.9 34.1 40.4 25.8 31.6 37.3 THC 41.8 41.8 41.8 39.2 39.2 40.6 36.3 36.3 39.3 32.8 32.8 37.9

SHC 25.8 33.6 41.4 24.9 32.7 40.6 23.7 31.5 39.3 22.3 30.1 37.9 THC 45.2 45.2 45.2 43.2 43.2 43.2 40.5 40.5 40.5 37.2 37.2 37.2

SHC 18.4 25.8 33.3 17.7 25.4 33.2 16.8 24.6 32.5 15.6 23.5 31.4 THC --- 47.6 47.6 --- 45.2 45.2 --- 43.2 43.2 --- 40.3 40.3

SHC --- 19.9 27.5 --- 19.1 26.7 --- 18.6 26.3 --- 17.7 25.6

85 95 105 115

EA (dB) EA (dB) EA (dB) EA (dB)

Table 9 – COOLING CAPACITIES 1--STAGE COOLING 4 TONS

AMBIENT TEMPERATURE

548J*05

75 80 85 75 80 85 75 80 85 75 80 85

TC 41.7 41.7 46.9 39.9 39.9 45.1 37.8 37.8 43.1 35.6 35.6 41.0

SHC 36.5 41.7 46.9 34.7 39.9 45.1 32.5 37.8 43.1 30.3 35.6 41.0

TC 44.1 44.1 44.1 42.0 42.0 43.1 39.4 39.4 41.9 36.7 36.7 40.6

SHC 33.7 38.9 44.1 32.6 37.8 43.1 31.3 36.6 41.9 29.8 35.2 40.6

TC 48.8 48.8 48.8 46.4 46.4 46.4 43.7 43.7 43.7 40.9 40.9 40.9

EAT (wb)

1200 Cfm

EAT (wb)

1400 Cfm

EAT (wb)

1600 Cfm

EAT (wb)

1800 Cfm

EAT (wb)

2000 Cfm

LEGEND

SHC 28.2 33.4 38.6 27.1 32.4 37.6 25.9 31.3 36.6 24.6 30.0 35.4

TC 53.2 53.2 53.2 50.7 50.7 50.7 48.1 48.1 48.1 45.2 45.2 45.2

SHC 22.3 27.5 32.7 21.3 26.5 31.8 20.2 25.5 30.8 18.9 24.4 29.8

TC --- 56.2 56.2 --- 53.8 53.8 --- 51.1 51.1 --- 48.0 48.0

SHC --- 22.5 27.7 --- 21.7 27.0 --- 20.8 26.1 --- 19.7 25.1

TC 44.1 44.1 50.2 42.2 42.2 48.3 40.2 40.2 46.4 38.0 38.0 44.3

SHC 38.1 44.1 50.2 36.1 42.2 48.3 34.0 40.2 46.4 31.7 38.0 44.3

TC 45.8 45.8 48.3 43.3 43.3 47.1 40.8 40.8 45.8 38.0 38.0 44.3

SHC 36.2 42.3 48.3 34.9 41.0 47.1 33.4 39.6 45.8 31.7 38.0 44.3

TC 50.2 50.2 50.2 47.7 47.7 47.7 44.9 44.9 44.9 42.0 42.0 42.0

SHC 29.7 35.8 41.9 28.7 34.8 40.9 27.5 33.7 39.9 26.2 32.5 38.8

TC 54.4 54.4 54.4 52.0 52.0 52.0 49.2 49.2 49.2 46.2 46.2 46.2

SHC 22.9 28.9 35.0 21.9 28.0 34.1 20.8 27.0 33.2 19.5 25.8 32.2

TC --- 57.1 57.1 --- 54.8 54.8 --- 52.0 52.0 --- 48.7 48.7

SHC --- 23.3 29.4 --- 22.5 28.6 --- 21.5 27.7 --- 20.3 26.7

TC 46.1 46.1 53.1 44.0 44.0 51.0 41.9 41.9 48.9 39.6 39.6 46.8

SHC 39.2 46.1 53.1 37.1 44.0 51.0 34.8 41.9 48.9 32.4 39.6 46.8

TC 46.9 46.9 52.1 44.6 44.6 50.5 42.0 42.0 49.0 39.6 39.6 46.8

SHC 38.2 45.2 52.1 36.5 43.5 50.5 34.9 42.0 49.0 32.4 39.6 46.8

TC 51.2 51.2 51.2 48.7 48.7 48.7 45.9 45.9 45.9 42.8 42.8 42.8

SHC 31.1 38.0 45.0 30.1 37.1 44.0 28.9 35.9 43.0 27.5 34.7 42.0

TC 55.3 55.3 55.3 52.9 52.9 52.9 50.0 50.0 50.0 46.9 46.9 46.9

SHC 23.2 30.1 37.1 22.3 29.3 36.3 21.2 28.3 35.4 19.9 27.1 34.4

TC --- 57.8 57.8 --- 55.4 55.4 --- 52.6 52.6 --- 49.3 49.3

SHC --- 23.9 30.8 --- 23.1 30.1 --- 22.1 29.2 --- 20.9 28.2

TC 47.7 47.7 55.5 45.6 45.6 53.5 43.4 43.4 51.3 41.0 41.0 49.1

SHC 39.9 47.7 55.5 37.8 45.6 53.5 35.4 43.4 51.3 32.8 41.0 49.1

TC 47.9 47.9 55.7 45.7 45.7 53.5 43.4 43.4 51.4 41.0 41.0 49.1

SHC 40.1 47.9 55.7 37.8 45.7 53.5 35.5 43.4 51.4 32.9 41.0 49.1

TC 52.0 52.0 52.0 49.4 49.4 49.4 46.6 46.6 46.6 43.5 43.5 45.0

SHC 32.3 40.1 47.9 31.3 39.2 47.1 30.1 38.1 46.0 28.7 36.9 45.0

TC 55.9 55.9 55.9 53.5 53.5 53.5 50.6 50.6 50.6 47.4 47.4 47.4

SHC 23.4 31.3 39.1 22.6 30.5 38.3 21.5 29.5 37.4 20.1 28.3 36.4

TC --- 58.3 58.3 --- 55.9 55.9 --- 53.1 53.1 --- 49.6 49.6

SHC --- 24.4 32.2 --- 23.6 31.5 --- 22.6 30.6 --- 21.4 29.6

TC 49.1 49.1 57.7 46.9 46.9 55.7 44.6 44.6 53.5 42.1 42.1 51.1

SHC 40.4 49.1 57.7 38.2 46.9 55.7 35.8 44.6 53.5 33.1 42.1 51.1

TC 49.1 49.1 57.7 47.0 47.0 55.7 44.7 44.7 53.5 42.2 42.2 51.2

SHC 40.4 49.1 57.7 38.2 47.0 55.7 35.8 44.7 53.5 33.1 42.2 51.2

TC 52.6 52.6 52.6 50.0 50.0 50.0 47.1 47.1 49.0 44.0 44.0 47.9

SHC 33.4 42.0 50.7 32.5 41.2 49.9 31.2 40.1 49.0 29.8 38.8 47.9

TC 56.4 56.4 56.4 53.9 53.9 53.9 51.1 51.1 51.1 47.8 47.8 47.8

SHC 23.6 32.2 40.9 22.8 31.5 40.3 21.7 30.6 39.4 20.3 29.3 38.4

TC --- 58.6 58.6 --- 56.3 56.3 --- 53.4 53.4 --- 49.9 49.9

SHC --- 24.8 33.5 --- 24.0 32.8 --- 23.1 32.0 --- 21.8 30.9

85 95 105 115

EA (dB) EA (dB) EA (dB) EA (dB)

548J

Table 10 – COOLING CAPACITIES 1--STAGE COOLING 5 TONS

AMBIENT TEMPERATURE

548J*06

75 80 85 75 80 85 75 80 85 75 80 85

TC 52.7 52.7 59.2 49.9 49.9 56.5 46.9 46.9 53.6 43.6 43.6 50.4

SHC 46.2 52.7 59.2 43.4 49.9 56.5 40.3 46.9 53.6 36.8 43.6 50.4

TC 55.5 55.5 55.8 52.1 52.1 54.3 48.1 48.1 52.4 43.7 43.7 50.3

SHC 42.8 49.3 55.8 41.1 47.7 54.3 39.2 45.8 52.4 36.7 43.5 50.3

TC 61.7 61.7 61.7 58.1 58.1 58.1 54.1 54.1 54.1 49.6 49.6 49.6

EAT (wb)

1500 Cfm

548J

EAT (wb)

1750 Cfm

EAT (wb)

2000 Cfm

EAT (wb)

2250 Cfm

EAT (wb)

2500 Cfm

LEGEND

SHC 35.6 42.1 48.6 34.0 40.5 47.1 32.2 38.8 45.5 30.2 37.0 43.8

TC 68.0 68.0 68.0 64.3 64.3 64.3 60.1 60.1 60.1 55.5 55.5 55.5

SHC 27.9 34.4 40.9 26.4 33.0 39.6 24.7 31.4 38.1 22.8 29.7 36.5

TC --- 72.9 72.9 --- 69.0 69.0 --- 64.5 64.5 --- 59.5 59.5

SHC --- 28.0 34.5 --- 26.6 33.2 --- 25.1 31.8 --- 23.4 30.2

TC 56.0 56.0 63.6 53.0 53.0 60.7 49.9 49.9 57.7 46.5 46.5 54.5

SHC 48.4 56.0 63.6 45.4 53.0 60.7 42.2 49.9 57.7 38.6 46.5 54.5

TC 57.6 57.6 61.6 54.1 54.1 59.9 50.1 50.1 57.6 46.6 46.6 54.5

SHC 46.4 54.0 61.6 44.6 52.2 59.9 42.1 49.8 57.6 38.7 46.6 54.5

TC 63.6 63.6 63.6 59.9 59.9 59.9 55.7 55.7 55.7 51.1 51.1 51.1

SHC 38.0 45.6 53.2 36.4 44.0 51.7 34.5 42.3 50.1 32.5 40.5 48.4

TC 69.9 69.9 69.9 66.0 66.0 66.0 61.7 61.7 61.7 56.9 56.9 56.9

SHC 29.0 36.6 44.2 27.5 35.2 42.8 25.7 33.5 41.3 23.7 31.7 39.7

TC --- 74.6 74.6 --- 70.6 70.6 --- 65.8 65.8 --- 60.5 60.5

SHC --- 29.2 36.8 --- 27.8 35.5 --- 26.1 34.0 --- 24.3 32.3

TC 58.8 58.8 67.4 55.8 55.8 64.5 52.5 52.5 61.4 48.8 48.8 57.9

SHC 50.1 58.8 67.4 47.0 55.8 64.5 43.6 52.5 61.4 39.7 48.8 57.9

TC 59.3 59.3 66.9 55.9 55.9 64.6 52.5 52.5 61.4 48.8 48.8 57.9

SHC 49.5 58.2 66.9 47.1 55.9 64.6 43.6 52.5 61.4 39.8 48.8 57.9

TC 65.1 65.1 65.1 61.3 61.3 61.3 56.9 56.9 56.9 52.2 52.2 52.8

SHC 40.2 48.9 57.6 38.6 47.3 56.1 36.7 45.6 54.5 34.6 43.7 52.8

TC 71.3 71.3 71.3 67.3 67.3 67.3 62.8 62.8 62.8 57.8 57.8 57.8

SHC 29.9 38.6 47.3 28.3 37.1 45.9 26.5 35.5 44.4 24.5 33.6 42.7

TC --- 75.9 75.9 --- 71.7 71.7 --- 66.6 66.6 --- 61.2 61.2

SHC --- 30.2 38.9 --- 28.7 37.6 --- 27.0 36.0 --- 25.1 34.3

TC 61.0 61.0 70.8 57.9 57.9 67.8 54.5 54.5 64.5 50.7 50.7 60.9

SHC 51.3 61.0 70.8 48.1 57.9 67.8 44.5 54.5 64.5 40.5 50.7 60.9

TC 61.1 61.1 70.8 58.0 58.0 67.8 54.6 54.6 64.6 50.7 50.7 61.0

SHC 51.3 61.1 70.8 48.1 58.0 67.8 44.6 54.6 64.6 40.5 50.7 61.0

TC 66.2 66.2 66.2 62.3 62.3 62.3 57.9 57.9 58.8 53.1 53.1 57.0

SHC 42.3 52.0 61.8 40.6 50.5 60.4 38.7 48.7 58.8 36.6 46.8 57.0

TC 72.3 72.3 72.3 68.3 68.3 68.3 63.7 63.7 63.7 58.5 58.5 58.5

SHC 30.6 40.4 50.2 29.1 39.0 48.9 27.2 37.3 47.3 25.0 35.3 45.5

TC --- 76.9 76.9 --- 72.5 72.5 --- 67.4 67.4 --- 61.8 61.8

SHC --- 31.1 40.9 --- 29.6 39.5 --- 27.9 37.9 --- 25.9 36.2

TC 63.0 63.0 73.8 59.8 59.8 70.7 56.2 56.2 67.3 52.3 52.3 63.7

SHC 52.1 63.0 73.8 48.8 59.8 70.7 45.1 56.2 67.3 41.0 52.3 63.7

TC 63.0 63.0 73.9 59.8 59.8 70.8 56.3 56.3 67.4 52.4 52.4 63.7

SHC 52.2 63.0 73.9 48.9 59.8 70.8 45.2 56.3 67.4 41.0 52.4 63.7

TC 67.2 67.2 67.2 63.1 63.1 64.5 58.7 58.7 62.8 53.8 53.8 61.0

SHC 44.2 55.0 65.9 42.5 53.5 64.5 40.6 51.7 62.8 38.3 49.6 61.0

TC 73.2 73.2 73.2 69.0 69.0 69.0 64.3 64.3 64.3 59.0 59.0 59.0

SHC 31.3 42.2 53.1 29.7 40.7 51.7 27.8 38.9 50.1 25.5 36.9 48.3

TC --- 77.7 77.7 --- 73.1 73.1 --- 67.9 67.9 --- 62.2 62.2

SHC --- 32.0 42.9 --- 30.5 41.5 --- 28.6 39.8 --- 26.6 38.0

85 95 105 115

EA (dB) EA (dB) EA (dB) EA (dB)

Table 11 – COOLING CAPACITIES 1--STAGE COOLING 6 TONS

AMBIENT TEMPERATURE

548J*07

75 80 85 75 80 85 75 80 85 75 80 85

TC 61.1 61.1 68.9 58.3 58.3 66.1 55.2 55.2 63.2 51.8 51.8 59.9

SHC 53.3 61.1 68.9 50.4 58.3 66.1 47.2 55.2 63.2 43.7 51.8 59.9

TC 64.1 64.1 65.2 60.5 60.5 63.6 56.5 56.5 61.8 52.1 52.1 59.7

SHC 49.6 57.4 65.2 47.8 55.7 63.6 45.8 53.8 61.8 43.4 51.6 59.7

TC 70.8 70.8 70.8 67.2 67.2 67.2 63.1 63.1 63.1 58.6 58.6 58.6

EAT (wb)

1800 Cfm

EAT (wb)

2100 Cfm

EAT (wb)

2400 Cfm

EAT (wb)

2700 Cfm

EAT (wb)

3000 Cfm

LEGEND

--- --- D o n o t o p e r a t e i n t h i s r e g i o n Cfm --- Cubic feet per minute (supply air) EAT(db) --- Entering air temperature (dry bulb) EAT(wb) --- Entering air temperature (wet bulb) SHC --- Sensible heat capacity TC --- Total capacity

SHC 40.7 48.5 56.3 39.1 47.0 54.9 37.3 45.3 53.3 35.3 43.5 51.7

TC 77.4 77.4 77.4 73.7 73.7 73.7 69.5 69.5 69.5 64.9 64.9 64.9

SHC 31.1 38.9 46.7 29.6 37.5 45.5 27.9 36.0 44.0 26.0 34.2 42.5

TC --- 82.0 82.0 --- 78.4 78.4 --- 73.9 73.9 --- 68.8 68.8

SHC --- 30.9 38.8 --- 29.7 37.6 --- 28.1 36.2 --- 26.4 34.6

TC 64.6 64.6 73.7 61.6 61.6 70.8 58.4 58.4 67.7 54.8 54.8 64.3

SHC 55.5 64.6 73.7 52.5 61.6 70.8 49.1 58.4 67.7 45.3 54.8 64.3

TC 66.1 66.1 71.7 62.5 62.5 69.9 58.5 58.5 67.8 54.9 54.9 64.4

SHC 53.4 62.5 71.7 51.5 60.7 69.9 49.2 58.5 67.8 45.3 54.9 64.4

TC 72.8 72.8 72.8 69.0 69.0 69.0 64.8 64.8 64.8 60.2 60.2 60.2

SHC 43.1 52.2 61.3 41.5 50.7 59.9 39.7 49.1 58.4 37.7 47.3 56.8

TC 79.2 79.2 79.2 75.4 75.4 75.4 71.0 71.0 71.0 66.2 66.2 66.2

SHC 31.9 41.1 50.2 30.5 39.7 49.0 28.7 38.1 47.5 26.7 36.3 45.9

TC --- 83.1 83.1 --- 79.8 79.8 --- 75.1 75.1 --- 69.7 69.7

SHC --- 32.0 41.2 --- 30.7 39.9 --- 29.1 38.5 --- 27.3 36.9

TC 67.4 67.4 77.8 64.4 64.4 74.9 61.0 61.0 71.7 57.3 57.3 68.2

SHC 57.0 67.4 77.8 53.9 64.4 74.9 50.3 61.0 71.7 46.4 57.3 68.2

TC 67.8 67.8 77.4 64.4 64.4 74.9 61.0 61.0 71.7 57.3 57.3 68.3

SHC 56.5 66.9 77.4 53.9 64.4 74.9 50.3 61.0 71.7 46.4 57.3 68.3

TC 74.3 74.3 74.3 70.4 70.4 70.4 66.1 66.1 66.1 61.4 61.4 61.7

SHC 45.3 55.7 66.1 43.7 54.2 64.7 41.9 52.6 63.3 39.9 50.8 61.7

TC 80.4 80.4 80.4 76.6 76.6 76.6 72.1 72.1 72.1 67.1 67.1 67.1

SHC 32.6 43.0 53.4 31.2 41.7 52.3 29.3 40.1 50.8 27.2 38.2 49.2

TC --- 84.0 84.0 --- 80.7 80.7 --- 76.0 76.0 --- 70.4 70.4

SHC --- 32.6 43.1 --- 31.6 42.2 --- 30.0 40.8 --- 28.1 39.1

TC 69.7 69.7 81.5 66.6 66.6 78.5 63.1 63.1 75.2 59.3 59.3 71.6

SHC 58.0 69.7 81.5 54.8 66.6 78.5 51.1 63.1 75.2 47.0 59.3 71.6

TC 69.8 69.8 81.5 66.6 66.6 78.4 63.2 63.2 75.2 59.4 59.4 71.7

SHC 58.0 69.8 81.5 54.8 66.6 78.4 51.2 63.2 75.2 47.1 59.4 71.7

TC 75.4 75.4 75.4 71.4 71.4 71.4 67.1 67.1 67.9 62.3 62.3 66.4

SHC 47.2 59.0 70.7 45.7 57.6 69.4 43.9 55.9 67.9 41.8 54.1 66.4

TC 81.3 81.3 81.3 77.5 77.5 77.5 72.9 72.9 72.9 67.8 67.8 67.8

SHC 33.0 44.8 56.5 31.7 43.6 55.5 29.8 41.9 54.0 27.7 40.0 52.4

TC --- 84.9 84.9 --- 81.3 81.3 --- 76.6 76.6 --- 70.8 70.8

SHC --- 33.4 45.2 --- 33.0 44.9 --- 30.8 43.0 --- 28.8 41.3

TC 71.7 71.7 84.7 68.5 68.5 81.7 64.9 64.9 78.3 61.0 61.0 74.7

SHC 58.7 71.7 84.7 55.4 68.5 81.7 51.6 64.9 78.3 47.3 61.0 74.7

TC 71.7 71.7 84.8 68.6 68.6 81.7 65.0 65.0 78.3 61.0 61.0 74.7

SHC 58.7 71.7 84.8 55.4 68.6 81.7 51.6 65.0 78.3 47.4 61.0 74.7

TC 76.4 76.4 76.4 72.3 72.3 73.8 67.9 67.9 72.4 63.0 63.0 70.8

SHC 49.0 62.1 75.1 47.5 60.7 73.8 45.7 59 72.4 43.4 57.1 70.8

TC 82.0 82.0 82.0 78.2 78.2 78.2 73.5 73.5 73.5 68.2 68.2 68.2

SHC 33.4 46.5 59.5 32.1 45.3 58.5 30.2 43.6 57.1 28.0 41.7 55.5

TC --- 85.5 85.5 --- 81.8 81.8 --- 77.1 77.1 --- 71.3 71.3

SHC --- 34.2 47.2 --- 33.0 46.3 --- 31.6 45.1 --- 29.5 43.3

85 95 105 115

EA (dB) EA (dB) EA (dB) EA (dB)

548J

Table 12 – COOLING CAPACITIES 2--STAGE COOLING 7.5 TONS

AMBIENT TEMPERATURE

548J*08

75 80 85 75 80 85 75 80 85 75 80 85

TC 77.4 77.4 87.8 74.1 74.1 84.1 69.8 69.8 79.2 65.2 65.2 74.1

SHC 66.9 77.4 87.8 64.0 74.1 84.1 60.3 69.8 79.2 56.4 65.2 74.1

TC 81.8 81.8 83.7 77.2 77.2 81.4 71.9 71.9 78.9 66.6 66.6 75.9

SHC 60.6 72.1 83.7 58.4 69.9 81.4 55.9 67.4 78.9 53.2 64.5 75.9

TC 90.6 90.6 90.6 86.0 86.0 86.0 80.8 80.8 80.8 75.1 75.1 75.1

2250Cfm

EAT (wb)

548J

EAT (wb)

2625 Cfm

EAT (wb)

3000 Cfm

EAT (wb)

3375 Cfm

EAT (wb)

3750 Cfm

LEGEND

SHC 50.4 62.0 73.5 48.4 60.0 71.6 46.2 57.8 69.3 43.9 55.4 67.0

TC 99.4 99.4 99.4 94.7 94.7 94.7 89.5 89.5 89.5 83.8 83.8 83.8

SHC 39.6 51.3 62.9 37.7 49.4 61.0 35.8 47.4 59.0 33.6 45.2 56.8

TC --- 105.7 105.7 --- 100.8 100.8 --- 95.5 95.5 --- 89.7 89.7

SHC --- 42.1 54.5 --- 40.4 52.8 --- 38.6 50.9 --- 36.5 48.8

TC 81.8 81.8 92.8 78.0 78.0 88.6 74.1 74.1 84.2 69.5 69.5 78.9

SHC 70.7 81.8 92.8 67.5 78.0 88.6 64.1 74.1 84.2 60.1 69.5 78.9

TC 84.7 84.7 91.7 79.9 79.9 89.2 75.2 75.2 86.2 69.8 69.8 81.6

SHC 65.2 78.5 91.7 62.9 76.1 89.2 60.3 73.3 86.2 56.8 69.2 81.6

TC 93.4 93.4 93.4 88.6 88.6 88.6 83.2 83.2 83.2 77.4 77.4 77.4

SHC 53.4 66.7 80.1 51.4 64.7 78.1 49.2 62.5 75.9 46.8 60.2 73.5

TC 101.9 101.9 101.9 97.1 97.1 97.1 91.8 91.8 91.8 86.0 86.0 86.0

SHC 40.8 54.1 67.5 38.9 52.3 65.6 36.9 50.3 63.6 34.8 48.1 61.5

TC --- 107.7 107.7 --- 102.6 102.6 --- 97.2 97.2 --- 91.2 91.2

SHC --- 43.7 58.1 --- 41.9 56.0 --- 39.9 53.9 --- 37.9 51.6

TC 85.6 85.6 97.2 81.8 81.8 92.9 77.6 77.6 88.0 72.9 72.9 82.8

SHC 74.1 85.6 97.2 70.7 81.8 92.9 67.1 77.6 88.0 63.0 72.9 82.8

TC 87.0 87.0 98.9 82.5 82.5 95.4 78.0 78.0 90.5 73.3 73.3 85.6

SHC 69.4 84.1 98.9 66.6 81.0 95.4 63.1 76.8 90.5 59.6 72.6 85.6

TC 95.5 95.5 95.5 90.5 90.5 90.5 85.1 85.1 85.1 79.0 79.0 79.6

SHC 56.1 71.2 86.2 54.1 69.2 84.2 51.9 67.0 82.1 49.5 64.6 79.6

TC 103.8 103.8 103.8 98.8 98.8 98.8 93.4 93.4 93.4 87.5 87.5 87.5

SHC 41.8 56.7 71.6 39.9 54.8 69.8 37.9 52.9 67.8 35.8 50.7 65.7

TC --- 109.1 109.1 --- 104.0 104.0 --- 98.3 98.3 --- 92.2 92.2

SHC --- 44.9 60.6 --- 43.1 58.6 --- 41.1 56.4 --- 39.0 54.2

TC 88.9 88.9 100.9 84.9 84.9 96.4 80.5 80.5 91.4 75.7 75.7 86.0

SHC 76.9 88.9 100.9 73.4 84.9 96.4 69.6 80.5 91.4 65.5 75.7 86.0

TC 89.6 89.6 103.8 85.1 85.1 100.4 81.0 81.0 94.1 75.8 75.8 89.5

SHC 72.4 88.1 103.8 69.7 85.0 100.4 65.6 79.8 94.1 62.1 75.8 89.5

TC 97.1 97.1 97.1 92.1 92.1 92.1 86.5 86.5 87.9 80.3 80.3 85.4

SHC 58.7 75.3 92.0 56.7 73.4 90.1 54.5 71.2 87.9 52.0 68.7 85.4

TC 105.2 105.2 105.2 100.0 100.0 100.0 94.5 94.5 94.5 88.5 88.5 88.5

SHC 42.6 59.0 75.3 40.7 57.1 73.5 38.8 55.2 71.6 36.6 53.1 69.5

TC --- 110.1 110.1 --- 105.0 105.0 --- 99.2 99.2 --- 92.9 92.9

SHC --- 45.9 62.8 --- 44.1 60.9 --- 42.1 58.7 --- 40.0 56.4

TC 91.6 91.6 104.0 87.5 87.5 99.4 83.0 83.0 94.3 78.1 78.1 88.7

SHC 79.2 91.6 104.0 75.7 87.5 99.4 71.8 83.0 94.3 67.6 78.1 88.7

TC 91.7 91.7 108.3 87.7 87.7 103.5 83.1 83.1 98.1 78.2 78.2 92.3

SHC 75.2 91.7 108.3 71.8 87.7 103.5 68.1 83.1 98.1 64.1 78.2 92.3

TC 98.4 98.4 98.4 93.3 93.3 95.6 87.7 87.7 93.4 81.5 81.5 90.9

SHC 61.1 79.3 97.5 59.1 77.3 95.6 56.9 75.2 93.4 54.5 72.7 90.9

TC 106.2 106.2 106.2 101.0 101.0 101.0 95.4 95.4 95.4 89.3 89.3 89.3

SHC 43.4 61.1 78.8 41.5 59.2 76.9 39.5 57.3 75.0 37.4 55.2 73.0

TC --- 111.0 111.0 --- 105.8 105.8 --- 99.8 99.8 --- 93.5 93.5

SHC --- 46.8 64.9 --- 45.1 63.1 --- 43.0 60.8 --- 40.9 58.4

85 95 105 115

EA (dB) EA (dB) EA (dB) EA (dB)

Table 13 – COOLING CAPACITIES 2--STAGE COOLING 8.5 TONS

AMBIENT TEMPERATURE

548J*09

75 80 85 75 80 85 75 80 85 75 80 85

TC 91.1 91.1 102.9 86.4 86.4 97.5 81.2 81.2 91.7 75.7 75.7 85.5

SHC 79.4 91.1 102.9 75.2 86.4 97.5 70.8 81.2 91.7 66.0 75.7 85.5

TC 96.0 96.0 99.4 89.2 89.2 96.4 83.0 83.0 93.4 76.5 76.5 88.0

SHC 72.7 86.0 99.4 69.6 83.0 96.4 66.7 80.0 93.4 62.4 75.2 88.0

TC 106.4 106.4 106.4 100.4 100.4 100.4 92.9 92.9 92.9 86.0 86.0 86.0

EAT (wb)

2550 Cfm

EAT (wb)

2975 Cfm

EAT (wb)

3400 Cfm

EAT (wb)

3825 Cfm

EAT (wb)

4250 Cfm

LEGEND

SHC 60.4 73.8 87.2 57.7 71.1 84.5 54.7 68.1 81.6 51.8 65.2 78.6

TC 117.3 117.3 117.3 111.2 111.2 111.2 104.3 104.3 104.3 97.0 97.0 97.0

SHC 47.4 60.9 74.4 45.1 58.5 72.0 42.4 55.9 69.4 39.7 53.1 66.6

TC --- 126.1 126.1 --- 119.9 119.9 --- 113.0 113.0 --- 105.6 105.6

SHC --- 50.3 64.3 --- 48.0 61.8 --- 45.6 59.4 --- 43.0 56.7

TC 96.5 96.5 109.0 91.7 91.7 103.5 86.7 86.7 97.9 80.5 80.5 90.9

SHC 84.1 96.5 109.0 79.9 91.7 103.5 75.5 86.7 97.9 70.1 80.5 90.9

TC 98.2 98.2 109.0 92.9 92.9 105.4 87.0 87.0 100.5 80.6 80.6 94.5

SHC 78.1 93.6 109.0 75.1 90.2 105.4 71.3 85.9 100.5 66.7 80.6 94.5

TC 109.5 109.5 109.5 103.0 103.0 103.0 96.3 96.3 96.3 87.6 87.6 87.6

SHC 64.1 79.6 95.2 61.4 76.9 92.5 58.7 74.3 89.8 55.3 70.9 86.5

TC 120.6 120.6 120.6 114.2 114.2 114.2 107.3 107.3 107.3 99.5 99.5 99.5

SHC 49.1 64.7 80.3 46.7 62.3 77.9 44.1 59.7 75.3 41.3 56.9 72.5

TC --- 129.2 129.2 --- 122.9 122.9 --- 115.7 115.7 --- 108.1 108.1

SHC --- 52.3 68.4 --- 50.0 65.8 --- 47.6 63.5 --- 45.0 60.8

TC 101.0 101.0 114.0 96.7 96.7 109.1 90.9 90.9 102.6 84.9 84.9 95.8

SHC 88.0 101.0 114.0 84.2 96.7 109.1 79.2 90.9 102.6 74.0 84.9 95.8

TC 102.3 102.3 116.5 96.9 96.9 112.5 90.7 90.7 106.3 84.6 84.6 99.1

SHC 82.9 99.7 116.5 79.7 96.1 112.5 75.1 90.7 106.3 70.0 84.6 99.1

TC 112.1 112.1 112.1 105.5 105.5 105.5 98.4 98.4 98.4 90.8 90.8 94.2

SHC 67.7 85.3 102.9 65.1 82.7 100.2 62.2 79.8 97.3 59.2 76.7 94.2

TC 123.0 123.0 123.0 116.5 116.5 116.5 109.4 109.4 109.4 101.6 101.6 101.6

SHC 50.5 68.2 85.9 48.2 65.8 83.5 45.6 63.2 80.8 42.8 60.4 78.1

TC --- 131.5 131.5 --- 124.9 124.9 --- 117.7 117.7 --- 109.9 109.9

SHC --- 54.1 72.1 --- 51.8 69.7 --- 49.4 67.2 --- 46.8 64.6

TC 104.5 104.5 118.0 99.8 99.8 112.6 94.4 94.4 106.6 87.9 87.9 99.2

SHC 91.1 104.5 118.0 86.9 99.8 112.6 82.3 94.4 106.6 76.6 87.9 99.2

TC 105.0 105.0 123.0 100.3 100.3 117.5 93.4 93.4 109.5 87.3 87.3 102.3

SHC 86.9 105.0 123.0 83.0 100.3 117.5 77.4 93.4 109.5 72.3 87.3 102.3

TC 114.1 114.1 114.1 107.4 107.4 107.6 99.4 99.4 104.6 92.0 92.0 101.3

SHC 71.2 90.8 110.4 68.5 88.1 107.6 65.4 85.0 104.6 62.4 81.9 101.3

TC 124.9 124.9 124.9 118.2 118.2 118.2 111.0 111.0 111.0 103.1 103.1 103.1

SHC 51.9 71.5 91.1 49.5 69.1 88.7 47.0 66.6 86.2 44.2 63.8 83.4

TC --- 133.3 133.3 --- 126.5 126.5 --- 119.2 119.2 --- 111.2 111.2

SHC --- 55.7 75.6 --- 53.5 73.3 --- 51.1 70.8 --- 48.5 68.1

TC 108.6 108.6 122.6 102.7 102.7 115.9 97.4 97.4 110.0 90.8 90.8 102.5

SHC 94.6 108.6 122.6 89.5 102.7 115.9 84.9 97.4 110.0 79.1 90.8 102.5

TC 109.0 109.0 126.4 103.4 103.4 121.2 97.5 97.5 114.2 91.3 91.3 106.9

SHC 89.5 107.9 126.4 85.6 103.4 121.2 80.7 97.5 114.2 75.6 91.3 106.9

TC 115.6 115.6 117.4 108.9 108.9 114.7 101.6 101.6 111.4 93.6 93.6 108.1

SHC 74.3 95.9 117.4 71.7 93.2 114.7 68.7 90.1 111.4 65.6 86.8 108.1

TC 126.4 126.4 126.4 119.7 119.7 119.7 112.3 112.3 112.3 104.2 104.2 104.2

SHC 53.1 74.6 96.1 50.8 72.3 93.8 48.2 69.8 91.4 45.4 67.0 88.5

TC --- 134.6 134.6 --- 127.8 127.8 --- 120.3 120.3 --- 112.3 112.3

SHC --- 57.2 78.8 --- 55.0 76.6 --- 52.6 74.1 --- 50.0 71.5

85 95 105 115

EA (dB) EA (dB) EA (dB) EA (dB)

548J

Table 14 – HEATING CAPACITIES 3 TONS

548J*04

548J

RETURN

AIR

(°Fdb)

CFM

(STANDARD AIR)

900

1200

1500

900

1200

1500

900

1200

1500

Capacity 11.6 15.1 18.9 21.7 27.6 32.7 36.0 37.1 41.8

Int. Cap. 10.7 13.9 17.4 19.8 24.2 32.7 36.0 37.1 41.8

Capacity 12.0 15.5 19.4 22.3 28.4 33.5 36.7 37.8 42.7

Int. Cap. 11.1 14.3 17.8 20.3 24.9 33.5 36.7 37.8 42.7

Capacity 12.6 16.3 20.2 23.1 29.5 34.2 37.5 38.6 43.5

Int. Cap. 11.6 15.0 18.5 21.1 25.8 34.2 37.5 38.6 43.5

Capacity 9.8 13.3 17.2 20.0 25.6 30.4 34.5 35.5 40.2

Int. Cap. 9.0 12.3 15.7 18.2 22.5 30.4 34.5 35.5 40.2

Capacity 10.1 13.8 17.7 20.7 26.6 31.7 35.4 36.5 41.2

Int. Cap. 9.3 12.7 16.3 18.8 23.3 31.7 35.4 36.5 41.2

Capacity 10.8 14.6 18.6 21.5 27.7 33.0 36.4 37.4 42.0

Int. Cap. 10.0 13.4 17.1 19.6 24.3 33.0 36.4 37.4 42.0

Capacity 8.3 11.9 15.7 18.6 24.1 29.0 32.7 34.1 39.0

Int. Cap. 7.7 10.9 14.4 16.9 21.2 29.0 32.7 34.1 39.0

Capacity 8.6 12.4 16.3 19.3 25.1 30.2 34.3 35.4 40.1

Int. Cap. 8.0 11.4 15.0 17.6 22.0 30.2 34.3 35.4 40.1

Capacity 9.3 13.2 17.2 20.2 26.2 31.4 35.5 36.5 41.1

Int. Cap. 8.6 12.1 15.8 18.4 23.0 31.4 35.5 36.5 41.1

--- 1 0 0 10 17 30 40 47 50 60

TEMPERATURE AIR ENTERING OUTDOOR COIL (°F db at 70% rh)

Table 15 – HEATING CAPACITIES 4 TONS

548J*05

RETURN

AIR

(°Fdb)

LEGEND

Capacity --- Instantaneous Capacity (1000 Btuh) includes indoor fan motor heat @ARI static conditions Int. Cap. --- Integrated Capacity is Instantaneous Capacity minus the effects of frost on the outdoor coil and the heat required to defrost rh --- Relative Humidity d b --- D r y B u l b

CFM

(STANDARD AIR)

1200

1600

2000

1200

1600

2000

1200

1600

2000

Capacity 17.5 22.0 26.6 30.0 36.8 42.6 47.1 48.9 55.3

Int. Cap. 16.2 20.2 24.4 27.3 32.2 42.6 47.1 48.9 55.3

Capacity 17.5 22.1 26.7 30.2 37.3 43.5 47.9 49.8 56.1

Int. Cap. 16.2 20.3 24.5 27.5 32.7 43.5 47.9 49.8 56.1

Capacity 18.5 23.1 27.8 31.3 38.7 44.9 49.1 50.9 57.1

Int. Cap. 17.1 21.3 25.5 28.6 33.9 44.9 49.1 50.9 57.1

Capacity 15.8 20.3 25.0 28.3 35.0 40.5 44.7 46.7 53.0

Int. Cap. 14.6 18.7 22.9 25.8 30.6 40.5 44.7 46.7 53.0

Capacity 15.9 20.5 25.3 28.7 35.6 41.3 45.8 47.8 53.9

Int. Cap. 14.7 18.9 23.2 26.1 31.2 41.3 45.8 47.8 53.9

Capacity 17.0 21.7 26.5 29.9 36.9 42.9 47.3 49.1 55.2

Int. Cap. 15.7 20.0 24.3 27.3 32.4 42.9 47.3 49.1 55.2

Capacity 14.2 18.8 23.5 26.9 33.6 39.0 43.2 45.1 51.4

Int. Cap. 13.1 17.3 21.6 24.6 29.4 39.0 43.2 45.1 51.4

Capacity 14.4 19.1 23.9 27.4 34.2 39.8 44.2 46.1 52.4

Int. Cap. 13.3 17.6 22.0 25.0 30.0 39.8 44.2 46.1 52.4

Capacity 15.5 20.3 25.2 28.7 35.6 41.4 45.9 47.8 53.8

Int. Cap. 14.3 18.7 23.1 26.1 31.2 41.4 45.9 47.8 53.8

--- 1 0 0 10 17 30 40 47 50 60

TEMPERATURE AIR ENTERING OUTDOOR COIL (°F db at 70% rh)

Table 16 – HEATING CAPACITY 5 TONS

548J*06

RETURN

AIR

(°FDB)

CFM

(STANDARD AIR)

1500

2000

2500

1500

2000

2500

1500

2000

2500

Capacity 22.7 28.3 34.2 38.6 47.4 54.3 60.0 62.6 70.3

Int. Cap. 21.0 26.1 31.4 35.2 41.5 54.3 60.0 62.6 70.3

Capacity 22.8 28.5 34.4 38.9 47.9 55.3 60.9 63.1 70.9

Int. Cap. 21.1 26.2 31.6 35.4 42.0 55.3 60.9 63.1 70.9

Capacity 24.2 30.0 35.9 40.4 49.6 56.9 62.3 64.4 72.0

Int. Cap. 22.4 27.6 33.0 36.8 43.5 56.9 62.3 64.4 72.0

Capacity 19.9 25.8 31.9 36.3 45.2 51.7 57.6 60.0 67.9

Int. Cap. 18.4 23.7 29.3 33.1 39.6 51.7 57.6 60.0 67.9

Capacity 20.1 26.1 32.3 36.7 45.8 52.9 58.4 61.0 68.8

Int. Cap. 18.6 24.0 29.6 33.5 40.1 52.9 58.4 61.0 68.8

Capacity 21.5 27.6 33.8 38.3 47.5 54.7 60.4 62.7 70.2

Int. Cap. 19.9 25.4 31.1 35.0 41.6 54.7 60.4 62.7 70.2

Capacity 17.6 23.7 30.0 34.6 43.5 50.2 55.7 58.2 66.1

Int. Cap. 16.3 21.9 27.6 31.5 38.1 50.2 55.7 58.2 66.1

Capacity 17.8 24.1 30.5 35.1 44.3 51.2 56.6 59.4 67.2

Int. Cap. 16.5 22.2 28.0 32.0 38.8 51.2 56.6 59.4 67.2

Capacity 19.3 25.6 32.1 36.8 46.0 53.1 58.8 61.1 68.8

Int. Cap. 17.8 23.6 29.4 33.5 40.3 53.1 58.8 61.1 68.8

--- 1 0 0 10 17 30 40 47 50 60

TEMPERATURE AIR ENTERING OUTDOOR COIL (°F DB AT 70% RH)

Table 17 – HEATING CAPACITY 6 TONS

548J*07

RETURN

AIR

(°FDB)

LEGEND

CFM

(STANDARD AIR)

1800

2400

3000

1800

2400

3000

1800

2400

3000

Capacity 22.4 29.8 37.1 42.5 53.5 62.4 68.6 71.2 80.3

Int. Cap. 20.7 27.4 34.1 38.8 46.9 62.4 68.6 71.2 80.3

Capacity 24.6 32.1 39.6 45.1 56.4 65.6 71.5 74.2 83.8

Int. Cap. 22.7 29.5 36.3 41.1 49.4 65.6 71.5 74.2 83.8

Capacity 27.4 35.0 42.5 48.2 59.5 68.6 74.5 77.2 86.8

Int. Cap. 25.3 32.2 39.0 43.9 52.1 68.6 74.5 77.2 86.8

Capacity 17.7 25.5 33.2 38.6 49.5 58.5 65.0 67.7 76.5

Int. Cap. 16.4 23.5 30.5 35.2 43.4 58.5 65.0 67.7 76.5

Capacity 19.9 27.9 35.8 41.4 52.7 62.0 68.4 71.0 80.3

Int. Cap. 18.4 25.7 32.9 37.7 46.2 62.0 68.4 71.0 80.3

Capacity 22.8 30.9 38.9 44.5 56.1 65.5 71.7 74.4 83.9

Int. Cap. 21.1 28.4 35.7 40.6 49.2 65.5 71.7 74.4 83.9

Capacity 13.9 21.9 29.9 35.5 46.2 55.3 62.0 64.9 73.7

Int. Cap. 12.8 20.2 27.4 32.3 40.5 55.3 62.0 64.9 73.7

Capacity 16.0 24.4 32.6 38.4 49.6 59.0 65.8 68.6 77.5

Int. Cap. 14.8 22.5 29.9 35.0 43.5 59.0 65.8 68.6 77.5

Capacity 18.8 27.4 35.8 41.6 53.1 62.7 69.4 72.1 81.4

Int. Cap. 17.4 25.2 32.8 37.9 46.6 62.7 69.4 72.1 81.4

--- 1 0 0 10 17 30 40 47 50 60

TEMPERATURE AIR ENTERING OUTDOOR COIL (°F DB AT 70% RH)

548J

Table 18 – HEATING CAPACITY 7.5 TONS

548J*08

548J

RETURN

AIR

(°Fdb)

CFM

(STANDARD AIR)

2250

3000

3750

2250

3000

3750

2250

3000

3750

Capacity 46.9 53.5 66.3 77.2 86.2 89.4 103.3

Int. Cap. 43.1 48.7 58.1 77.2 86.2 89.4 103.3

Capacity 68.5 80.2 89.8 93.1 106.7

Int. Cap. 60.0 80.2 89.8 93.1 106.7

Capacity 58.9 72.5 84.6 94.5 97.6 110.6

Int. Cap. 53.7 63.5 84.6 94.5 97.6 110.6

Capacity 25.9 34.6 43.6 50.2 62.7 73.0 81.4 84.5 98.0

Int. Cap. 23.9 31.8 40.0 45.7 55.0 73.0 81.4 84.5 98.0

Capacity 27.4 36.2 45.5 52.2 65.1 75.9 85.0 88.2 102.1

Int. Cap. 25.3 33.4 41.8 47.6 57.0 75.9 85.0 88.2 102.1

Capacity 31.0 40.0 49.3 56.1 69.1 80.4 89.8 93.2 106.5

Int. Cap. 28.6 36.8 45.3 51.1 60.6 80.4 89.8 93.2 106.5

Capacity 22.5 31.5 40.7 47.3 60.1 70.3 78.2 81.2 94.3

Int. Cap. 20.8 29.0 37.3 43.1 52.6 70.3 78.2 81.2 94.3

Capacity 24.1 33.3 42.7 49.5 62.5 73.1 81.6 84.7 98.6

Int. Cap. 22.3 30.6 39.2 45.2 54.8 73.1 81.6 84.7 98.6

Capacity 27.8 37.1 46.6 53.5 66.7 77.5 86.4 89.7 103.4

Int. Cap. 25.7 34.1 42.8 48.8 58.4 77.5 86.4 89.7 103.4

--- 1 0 0 10 17 30 40 47 50 60

TEMPERATURE AIR ENTERING OUTDOOR COIL (°F db at 70% rh)

Table 19 – HEATING CAPACITY 8.5 TONS

548J*09

RETURN

AIR

(°Fdb)

--- Indicates operation not permissible

LEGEND

CFM

(STANDARD AIR)

2550

3400

4250

2550

3400

4250

2550

3400

4250

Capacity 33.1 42.7 52.7 60.0 75.6 87.4 97.5 100.6 113.8

Int. Cap. 30.7 39.3 48.3 54.7 66.2 87.4 97.5 100.6 113.8

Capacity 34.4 44.0 54.2 61.8 77.5 89.9 100.2 103.1 115.7

Int. Cap. 31.8 40.5 49.8 56.4 67.9 89.9 100.2 103.1 115.7

Capacity 38.0 47.7 58.0 65.8 81.5 94.2 103.9 106.6 118.2

Int. Cap. 35.2 43.9 53.2 60.0 71.4 94.2 103.9 106.6 118.2

Capacity 29.0 38.6 48.6 55.9 70.7 83.5 93.1 96.2 109.5

Int. Cap. 26.8 35.5 44.6 51.0 61.9 83.5 93.1 96.2 109.5

Capacity 30.3 40.2 50.4 58.0 73.5 86.1 96.5 99.2 111.9

Int. Cap. 28.0 37.0 46.3 52.9 64.4 86.1 96.5 99.2 111.9

Capacity 34.0 44.0 54.4 62.1 77.8 90.5 100.5 103.3 115.2

Int. Cap. 31.5 40.5 50.0 56.6 68.2 90.5 100.5 103.3 115.2

Capacity 25.3 35.0 45.2 52.6 67.1 80.0 90.0 93.2 106.5

Int. Cap. 23.4 32.2 41.5 48.0 58.8 80.0 90.0 93.2 106.5

Capacity 26.6 36.7 47.2 54.8 69.8 83.0 93.1 96.2 109.2

Int. Cap. 24.6 33.8 43.3 50.0 61.2 83.0 93.1 96.2 109.2

Capacity 30.4 40.6 51.2 59.0 74.4 87.7 97.7 100.7 112.8

Int. Cap. 28.1 37.4 47.0 53.8 65.1 87.7 97.7 100.7 112.8

--- 1 0 0 10 17 30 40 47 50 60

TEMPERATURE AIR ENTERING OUTDOOR COIL (°F db at 70% rh)

Table 20 – STA TIC PRESSURE ADDERS (Factory Options and/or Accessories)

Economizer

3 --- 6 T O N S CFM (in. wg) 600 800 1000 1250 1500 1750 2000 2250 2500 2750 3000 Vertical

Economizer

Horizontal Economizer

CFM (in. wg) 2250 2500 2750 3000 3250 3500 3750 4000 4250 4500 4750 5000 5250 5500 5750 6000 Vertical

Economizer

Horizontal Economizer

0.01 0.02 0.04 0.05 0.07 0.09 0.12 0.15 0.18 0.22 0.26

0.02 0.03 0.04 0.06 0.08 0.10 0.13 0.15 0.18 0.23 0.28

7.5 --- 8.5 TONS

0.06 0.08 0.09 0.12 0.13 0.15 0.17 0.20 0.22 0.25 0.29 0.33 0.36 0.40 0.44 0.48

0.08 0.10 0.13 0.15 0.18 0.21 0.25 0.28 0.30 0.34 0.39 0.43 0.47 0.51 0.56 0.60

Electric Heaters

3 --- 6 T O N S CFM (in. wg) 600 900 1200 1400 1600 1800 2000 2200 2400 2600 1Electric

Heater Module

2Electric Heater Modules

CFM (in. wg) 2250 2500 2750 3000 3250 3500 3750 4000 4250 4500 4750 5000 5250 5500 5750 6000 1Electric

Heater Module

2Electric Heater Modules

0.03 0.05 0.07 0.09 0.09 0.10 0.11 0.11 0.12 0.13

0.13 0.15 0.16 0.16 0.16 0.17 0.17 0.17 0.18 0.18

7.5 --- 8.5 TONS

0.03 0.04 0.04 0.05 0.06 0.07 0.08 0.09 0.10 0.11 0.12 0.13 0.14 0.15 0.16 0.18

0.04 0.05 0.05 0.06 0.07 0.08 0.09 0.10 0.11 0.12 0.13 0.15 0.16 0.17 0.19 0.20

General fan performance notes:

1. Interpolation is permissible. Do not extrapolate.

2. External static pressure is the static pressure difference between the return duct and the supply duct plus the static pressure caused by any FIOPs or accessories.

3. Tabular data accounts for pressure loss due to clean filters, unit casing, and wet coils. Factory options and accessories may add static pressure losses, as shown in Table 20. Selection software is available, through your salesperson, to help you select the best motor/drive combination for your application.

4. The Fan Performance tables offer motor/drive recommendations. In cases when two motor/drive combinations would work, Bryant recommended the lower horsepower option.

5. For information on the electrical properties of Bryant motors, please see the Electrical information section of this book.

6. For more information on the performance limits of Bryant motors, see the application data section of this book.

548J

FAN PERFORMANCE

Table 21 – 548J*04 ELECTRIC DRIVE, X13 MOTOR, 3 TON HORIZONTAL SUPPLY

SPEED

(TORQUE)

TAP

548J

CFM ESP BHP

900 0.70 0.31

975 0.60 0.30 1050 0.50 0.29 1125 0.39 0.27 1200 0.29 0.26 1275 0.21 0.24 1350 0.12 0.23 1425 0.03 0.21 1500 --- ---

900 0.85 0.37

975 0.76 0.36 1050 0.66 0.36 1125 0.55 0.34 1200 0.46 0.34 1275 0.36 0.32 1350 0.27 0.31 1425 0.17 0.29 1500 0.07 0.27

900 1.02 0.44

975 0.94 0.45 1050 0.86 0.45 1125 0.79 0.45 1200 0.71 0.45 1275 0.61 0.44 1350 0.51 0.43 1425 0.40 0.41 1500 0.29 0.39

900 1.12 0.49

975 1.06 0.50 1050 1.00 0.52 1125 0.95 0.53 1200 0.89 0.54 1275 0.80 0.53 1350 0.70 0.52 1425 0.57 0.50 1500 0.46 0.49

900 1.18 0.52

975 1.14 0.54 1050 1.10 0.56 1125 1.06 0.58 1200 1.02 0.60 1275 0.98 0.63 1350 0.94 0.65 1425 0.90 0.68 1500 0.87 0.71

Table 22 – 548J*04 ELECTRIC DRIVE, X13 MOTOR, 3 TON VERTICAL SUPPLY

SPEED

(TORQUE)

TAP

CFM ESP BHP

900 0.44 0.22

975 0.35 0.21 1050 0.24 0.20 1125 0.15 0.19 1200 0.08 0.19 1275 0.02 0.18 1350 --- --1425 --- --1500 --- ---

900 0.64 0.30

975 0.53 0.29 1050 0.42 0.28 1125 0.32 0.27 1200 0.24 0.26 1275 0.15 0.25 1350 0.07 0.24 1425 --- --1500 --- ---

900 0.93 0.42

975 0.80 0.41 1050 0.68 0.39 1125 0.57 0.38 1200 0.47 0.37 1275 0.35 0.36 1350 0.26 0.34 1425 0.13 0.33 1500 0.08 0.32

900 1.04 0.47

975 0.92 0.46 1050 0.80 0.45 1125 0.71 0.45 1200 0.62 0.45 1275 0.52 0.44 1350 0.43 0.44 1425 0.27 0.42 1500 0.22 0.41

900 1.10 0.50

975 1.00 0.49 1050 0.90 0.49 1125 0.82 0.50 1200 0.75 0.51 1275 0.70 0.54 1350 0.67 0.57 1425 0.60 0.60 1500 0.62 0.64

FAN PERFORMANCE (cont.)

Table 23 – 548J*05 ELECTRIC DRIVE, X13 MOTOR, 4 TON HORIZONTAL SUPPLY

SPEED

(TORQUE)

TAP

CFM ESP BHP

1200 0.75 0.48 1300 0.63 0.46 1400 0.48 0.44 1500 0.33 0.41 1600 0.19 0.39 1700 0.05 0.36 1800 --- --1900 --- --2000 --- --1200 0.97 0.58 1300 0.88 0.59 1400 0.77 0.59 1500 0.64 0.59 1600 0.50 0.57 1700 0.36 0.54 1800 0.21 0.52 1900 0.06 0.49 2000 --- --1200 0.98 0.59 1300 0.91 0.60 1400 0.82 0.62 1500 0.71 0.62 1600 0.58 0.61 1700 0.45 0.60 1800 0.31 0.58 1900 0.16 0.56 2000 0.03 0.52 1200 0.98 0.59 1300 0.92 0.62 1400 0.86 0.64 1500 0.79 0.66 1600 0.70 0.68 1700 0.62 0.70 1800 0.52 0.71 1900 0.37 0.69 2000 0.21 0.67 1200 1.02 0.60 1300 0.97 0.64 1400 0.92 0.67 1500 0.87 0.71 1600 0.82 0.75 1700 0.77 0.79 1800 0.71 0.84 1900 0.65 0.88 2000 0.58 0.92

Table 24 – 548J*05 ELECTRIC DRIVE, X13 MOTOR, 4 TON VERTICAL SUPPLY

SPEED

(TORQUE)

TAP

CFM ESP BHP

1200 0.50 0.39 1300 0.36 0.37 1400 0.19 0.35 1500 0.10 0.33 1600 0.02 0.32 1700 --- --1800 --- --1900 --- --2000 --- --1200 0.80 0.55 1300 0.69 0.55 1400 0.50 0.54 1500 0.38 0.52 1600 0.24 0.50 1700 0.13 0.48 1800 0.01 0.46 1900 --- --2000 --- --1200 0.89 0.59 1300 0.78 0.61 1400 0.59 0.60 1500 0.46 0.58 1600 0.31 0.56 1700 0.20 0.54 1800 0.07 0.52 1900 --- --2000 --- --1200 0.89 0.60 1300 0.80 0.63 1400 0.67 0.64 1500 0.57 0.65 1600 0.43 0.65 1700 0.31 0.66 1800 0.23 0.65 1900 0.12 0.63 2000 0.01 0.62 1200 0.94 0.62 1300 0.85 0.65 1400 0.73 0.68 1500 0.65 0.70 1600 0.55 0.72 1700 0.47 0.75 1800 0.42 0.78 1900 0.39 0.82 2000 0.38 0.88

548J

FAN PERFORMANCE (cont.)

Table 25 – 548J*06 ELECTRIC DRIVE, X13 MOTOR, 5 TON HORIZONTAL SUPPLY

SPEED

(TORQUE)

TAP

548J

CFM ESP BHP

1500 1.19 0.74 1625 1.01 0.73 1750 0.82 0.70 1875 0.60 0.66 2000 0.38 0.62 2125 0.16 0.57 2250 --- --2375 --- --2500 --- --1500 1.40 0.86 1625 1.25 0.88 1750 1.08 0.86 1875 0.90 0.84 2000 0.67 0.80 2125 0.44 0.75 2250 0.20 0.71 2375 --- --2500 --- --1500 1.41 0.87 1625 1.28 0.89 1750 1.13 0.89 1875 0.96 0.88 2000 0.74 0.85 2125 0.51 0.80 2250 0.27 0.75 2375 0.02 0.70 2500 --- --1500 1.44 0.89 1625 1.35 0.93 1750 1.24 0.96 1875 1.11 0.98 2000 0.90 0.96 2125 0.69 0.92 2250 0.43 0.86 2375 0.17 0.81 2500 --- --1500 1.49 0.90 1625 1.38 0.95 1750 1.28 1.00 1875 1.18 1.05 2000 1.11 1.09 2125 0.97 1.11 2250 0.72 1.07 2375 0.47 1.02 2500 0.20 0.96

Table 26 – 548J*06 ELECTRIC DRIVE, X13 MOTOR, 5 TON VERTICAL SUPPLY

SPEED

(TORQUE)

TAP

CFM ESP BHP

1500 1.00 0.70 1625 0.72 0.65 1750 0.46 0.60 1875 0.28 0.55 2000 0.14 0.51 2125 0.00 0.52 2250 --- --2375 --- --2500 --- --1500 1.18 0.88 1625 1.00 0.90 1750 0.75 0.87 1875 0.51 0.83 2000 0.30 0.79 2125 0.13 0.75 2250 --- --2375 --- --2500 --- --1500 1.19 0.88 1625 1.03 0.91 1750 0.80 0.90 1875 0.56 0.87 2000 0.35 0.83 2125 0.19 0.80 2250 0.01 0.77 2375 --- --2500 --- --1500 1.25 0.89 1625 1.09 0.93 1750 0.89 0.96 1875 0.65 0.94 2000 0.45 0.93 2125 0.26 0.89 2250 0.12 0.86 2375 --- --2500 --- --1500 1.26 0.90 1625 1.16 0.96 1750 0.99 1.01 1875 0.80 1.05 2000 0.67 1.07 2125 0.48 1.07 2250 0.26 1.03 2375 0.11 1.00 2500 --- ---

FAN PERFORMANCE (cont.)

Table 27 – 548J*04 3 TON HORIZONTAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

900 574 0.13 707 0.23 817 0.34 913 0.47 999 0.61

975 597 0.15 727 0.25 835 0.37 929 0.50 1015 0.64 1050 621 0.18 747 0.28 853 0.40 946 0.53 1030 0.68 1125 646 0.20 768 0.31 872 0.43 964 0.57 1047 0.72 1200 671 0.23 790 0.34 892 0.47 982 0.61 1064 0.76 1275 696 0.26 812 0.38 912 0.51 1001 0.65 1082 0.81 1350 723 0.30 835 0.42 933 0.55 1020 0.70 1100 0.86 1425 749 0.34 859 0.46 955 0.60 1040 0.75 1119 0.91 1500 776 0.38 883 0.51 977 0.65 1061 0.80 1138 0.97

CFM

900 1078 0.77 1151 0.93 1220 1.11 1284 1.30 1346 1.49

975 1093 0.80 1165 0.97 1233 1.15 1297 1.33 1358 1.53 1050 1108 0.84 1180 1.01 1247 1.19 1311 1.38 1371 1.58 1125 1123 0.88 1195 1.05 1261 1.23 1325 1.42 1385 1.62 1200 1140 0.92 1210 1.10 1276 1.28 1339 1.47 1399 1.68 1275 1157 0.97 1226 1.15 1292 1.33 1354 1.53 1414 1.73 1350 1174 1.02 1243 1.20 1308 1.39 1370 1.59 1429 1.80 1425 1192 1.08 1260 1.26 1325 1.45 1386 1.65 1444 1.86 1500 1210 1.14 1278 1.33 1342 1.52 1403 1.72 1461 1.93

Italicized area --- X13 electric (direct drive motor, see page 36 for speed/torque setting).

Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

548J

Table 28 – 548J*04 3 TON VERTICAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

900 594 0.15 740 0.25 867 0.37 981 0.52 1084 0.68

975 618 0.17 758 0.28 881 0.40 991 0.55 1092 0.71 1050 642 0.19 777 0.30 896 0.43 1003 0.58 1102 0.75 1125 668 0.22 797 0.34 912 0.47 1017 0.62 1113 0.79 1200 695 0.25 818 0.37 930 0.51 1032 0.66 1126 0.83 1275 722 0.29 841 0.41 949 0.55 1048 0.71 1140 0.88 1350 750 0.33 864 0.46 968 0.60 1065 0.76 1155 0.93 1425 778 0.37 888 0.50 989 0.65 1083 0.81 1171 0.99 1500 807 0.42 913 0.56 1011 0.71 1103 0.87 1188 1.05

CFM

900 1180 0.86 1269 1.05 1354 1.25 1434 1.47 1511 1.70

975 1186 0.89 1275 1.08 1358 1.29 1437 1.51 1513 1.74 1050 1194 0.92 1281 1.12 1363 1.32 1441 1.54 1516 1.78 1125 1204 0.97 1289 1.16 1370 1.37 1447 1.59 1520 1.82 1200 1215 1.01 1298 1.21 1378 1.42 1454 1.64 1526 1.87 1275 1227 1.06 1309 1.26 1387 1.47 1462 1.69 1533 1.92 1350 1240 1.12 1321 1.32 1397 1.53 1471 1.75 1541 1.99 1425 1254 1.18 1333 1.38 1409 1.59 1481 1.82 --- --1500 1270 1.24 1347 1.45 1421 1.66 1492 1.89 --- ---

Italicized area --- X13 electric (direct drive motor, see page 36 for speed/torque setting).

Med static motor and drive (belt drive) High static motor and drive (belt drive)

Bold Face indicates field ---supplied drive

1. Recommend using field ---supplied fan pulley (part no. KR11AD561), motor pulley (part no. KR11HY181) and belt (part no.KR29AF041).

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

FAN PERFORMANCE (cont.)

Table 29 – 548J*05 4 TON HORIZONTAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

1200 671 0.23 790 0.34 892 0.47 982 0.61 1064 0.76 1300 705 0.28 820 0.39 919 0.52 1007 0.67 1088 0.82 1400 740 0.33 851 0.45 947 0.58 1034 0.73 1113 0.89 1500 776 0.38 883 0.51 977 0.65 1061 0.80 1138 0.97 1600 813 0.45 916 0.58 1007 0.73 1089 0.89 1165 1.05 1700 851 0.52 949 0.66 1038 0.81 1118 0.97 1192 1.15 1800 888 0.60 984 0.75 1069 0.90 1148 1.07 1221 1.25 1900 927 0.69 1019 0.84 1102 1.00 1179 1.18 1250 1.36 2000 965 0.78 1054 0.94 1135 1.11 1210 1.29 1280 1.48

CFM

548J

1200 1140 0.92 1210 1.10 1276 1.28 1339 1.47 1399 1.68 1300 1162 0.99 1232 1.16 1297 1.35 1360 1.55 1419 1.75 1400 1186 1.06 1254 1.24 1319 1.43 1381 1.63 1439 1.84 1500 1210 1.14 1278 1.33 1342 1.52 1403 1.72 1461 1.93 1600 1236 1.23 1302 1.42 1365 1.62 1425 1.82 1483 2.04 1700 1262 1.33 1328 1.52 1390 1.72 1449 1.93 1505 2.15 1800 1289 1.44 1354 1.63 1415 1.84 1473 2.05 1529 2.27 1900 1317 1.55 1380 1.75 1441 1.96 1498 2.18 --- --2000 1345 1.68 1408 1.88 1467 2.10 1524 2.32 --- ---

Italicized area --- X13 electric (direct drive motor, see page 37 for speed/torque setting).

Med static motor and drive (belt drive) High static motor and drive (belt drive)

Bold Face indicates field ---supplied drive

1. Recommend using field ---supplied fan pulley (part no. KR11AD561), motor pulley (part no. KR11HY181) and belt (part no.KR29AF041).

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

Table 30 – 548J*05 4 TON VERTICAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

1200 695 0.25 818 0.37 930 0.51 1032 0.66 1126 0.83 1300 731 0.30 849 0.43 955 0.57 1053 0.72 1145 0.89 1400 769 0.36 880 0.49 982 0.63 1077 0.79 1166 0.97 1500 807 0.42 913 0.56 1011 0.71 1103 0.87 1188 1.05 1600 847 0.49 948 0.63 1042 0.79 1130 0.96 1213 1.14 1700 887 0.57 983 0.72 1073 0.88 1158 1.06 1239 1.24 1800 928 0.66 1020 0.82 1106 0.98 1188 1.16 1266 1.35 1900 969 0.76 1057 0.92 1140 1.09 1219 1.28 1295 1.48 2000 1010 0.87 1095 1.04 1175 1.21 1251 1.41 1325 1.61

CFM

1200 1215 1.01 1298 1.21 1378 1.42 1454 1.64 1526 1.87 1300 1231 1.08 1313 1.28 1390 1.49 1465 1.71 1536 1.94 1400 1249 1.16 1329 1.36 1405 1.57 1478 1.79 --- --1500 1270 1.24 1347 1.45 1421 1.66 1492 1.89 --- --1600 1292 1.34 1367 1.54 1440 1.76 1509 1.99 --- --1700 1315 1.44 1389 1.65 1459 1.88 1527 2.11 --- --1800 1341 1.56 1412 1.77 1481 2.00 --- --- --- --1900 1367 1.68 1437 1.90 1504 2.13 --- --- --- --2000 1395 1.82 1463 2.04 1528 2.28 --- --- --- ---

Italicized area --- X13 electric (direct drive motor, see page 37 for speed/torque setting).

Med static motor and drive (belt drive) High static motor and drive (belt drive)

Bold Face indicates field ---supplied drive

1. Recommend using field ---supplied fan pulley (part no. KR11AD561), motor pulley (part no. KR11HY181) and belt (part no.KR29AF041).

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

FAN PERFORMANCE (cont.)

Table 31 – 548J*06 5 TON HORIZONTAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

1500 725 0.33 840 0.46 937 0.60 1023 0.75 1101 0.90 1625 765 0.40 876 0.54 970 0.68 1054 0.84 1131 1.00 1750 806 0.48 912 0.63 1004 0.78 1087 0.94 1162 1.11 1875 847 0.57 950 0.72 1039 0.88 1120 1.05 1194 1.23 2000 889 0.66 988 0.83 1075 1.00 1154 1.18 1226 1.36 2125 931 0.78 1027 0.95 1112 1.13 1189 1.31 1260 1.50 2250 974 0.90 1067 1.08 1149 1.27 1224 1.46 1294 1.66 2375 1018 1.03 1107 1.23 1187 1.43 1261 1.63 1329 1.84 2500 1061 1.19 1148 1.39 1226 1.59 1297 1.81 1364 2.02

CFM

1500 1172 1.06 1239 1.23 1302 1.40 1361 1.58 1418 1.77 1625 1201 1.16 1267 1.34 1329 1.52 1388 1.71 1444 1.90 1750 1231 1.28 1296 1.46 1358 1.65 1416 1.84 1472 2.04 1875 1262 1.41 1326 1.60 1387 1.79 1445 1.99 1499 2.20 2000 1294 1.55 1357 1.74 1417 1.95 1474 2.15 1528 2.36 2125 1326 1.70 1388 1.90 1447 2.11 1504 2.33 1557 2.55 2250 1359 1.87 1420 2.08 1479 2.29 1534 2.51 1587 2.74 2375 1393 2.05 1453 2.27 1511 2.49 1566 2.72 --- --2500 1427 2.24 1487 2.47 1543 2.70 1597 2.94 --- ---

Italicized area --- X13 electric (direct drive motor, see page 38 for speed/torque setting).

Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

548J

Table 32 – 548J*06 5 TON VERTICAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

1500 794 0.41 902 0.55 993 0.69 1074 0.85 1147 1.00 1625 840 0.49 945 0.64 1034 0.80 1113 0.96 1185 1.13 1750 888 0.59 988 0.75 1075 0.92 1153 1.09 1223 1.26 1875 936 0.70 1033 0.87 1117 1.05 1193 1.23 1263 1.41 2000 984 0.82 1078 1.00 1160 1.19 1235 1.39 1303 1.58 2125 1033 0.96 1124 1.15 1204 1.35 1277 1.56 1343 1.76 2250 1083 1.11 1170 1.32 1248 1.53 1319 1.74 1385 1.96 2375 1133 1.28 1217 1.50 1293 1.72 1363 1.95 1427 2.17 2500 1183 1.47 1265 1.70 1339 1.93 1406 2.17 1470 2.41

CFM

1500 1214 1.16 1277 1.33 1336 1.50 1392 1.67 1445 1.85 1625 1251 1.30 1313 1.47 1371 1.65 1427 1.83 1479 2.02 1750 1289 1.44 1350 1.63 1407 1.81 1462 2.01 1514 2.20 1875 1327 1.60 1387 1.80 1444 1.99 1498 2.19 1550 2.40 2000 1366 1.78 1426 1.98 1482 2.19 1535 2.40 1586 2.61 2125 1406 1.97 1464 2.18 1520 2.40 1573 2.62 1623 2.84 2250 1446 2.18 1504 2.40 1559 2.62 1611 2.85 --- --2375 1487 2.40 1544 2.63 1598 2.87 --- --- --- --2500 1529 2.64 1585 2.89 --- --- --- --- --- ---

Italicized area --- X13 electric (direct drive motor, see page 38 for speed/torque setting).

Non--- shaded area --- X13 electric drive motor, see page 38 for speed/torque setting. Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

FAN PERFORMANCE (cont.)

Table 33 – 548J*07 6 TON HORIZONTAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

1800 --- --- 927 0.66 1018 0.82 1100 0.98 1174 1.15 1950 --- --- 973 0.79 1061 0.95 1140 1.13 1213 1.31 2100 923 0.75 1019 0.92 1104 1.10 1182 1.29 1253 1.48 2250 974 0.90 1067 1.08 1149 1.27 1224 1.46 1294 1.66 2400 1026 1.06 1115 1.26 1195 1.46 1268 1.66 1336 1.87 2550 1079 1.25 1164 1.46 1241 1.67 1312 1.88 1379 2.10 2700 1132 1.46 1214 1.67 1289 1.90 1358 2.12 1422 2.35 2850 1186 1.69 1264 1.92 1336 2.15 1404 2.39 1467 2.63 3000 1240 1.94 1315 2.18 1385 2.43 1451 2.68 1512 2.93

CFM

548J

1800 1244 1.33 1308 1.51 1369 1.70 1427 1.90 1483 2.10 1950 1281 1.49 1345 1.68 1405 1.88 1462 2.09 1517 2.30 2100 1320 1.67 1382 1.87 1441 2.08 1498 2.29 1552 2.51 2250 1359 1.87 1420 2.08 1479 2.29 1534 2.51 1587 2.74 2400 1400 2.09 1460 2.31 1517 2.53 1572 2.76 --- --2550 1441 2.33 1500 2.55 1557 2.79 --- --- --- --2700 1483 2.59 1541 2.83 --- --- --- --- --- --2850 1527 2.87 --- --- --- --- --- --- --- --3000 --- --- --- --- --- --- --- --- --- ---

Std static motor and drive (belt drive) Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

Table 34 – 548J*07 6 TON VERTICAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

1800 907 0.63 1006 0.80 1092 0.97 1169 1.14 1239 1.32 1950 965 0.77 1060 0.95 1143 1.13 1218 1.32 1287 1.51 2100 1024 0.93 1115 1.12 1195 1.32 1268 1.52 1335 1.72 2250 1083 1.11 1170 1.32 1248 1.53 1319 1.74 1385 1.96 2400 1143 1.32 1227 1.54 1302 1.76 1371 1.99 1435 2.22 2550 1203 1.55 1284 1.78 1357 2.02 1424 2.26 1487 2.50 2700 1264 1.81 1342 2.06 1412 2.31 1478 2.56 1539 2.82 2850 1326 2.09 1400 2.36 1469 2.62 1532 2.89 --- --3000 1387 2.41 1459 2.69 --- --- --- --- --- ---

CFM

1800 1304 1.51 1365 1.69 1422 1.88 1477 2.08 1528 2.28 1950 1350 1.71 1410 1.91 1467 2.11 1520 2.31 1572 2.52 2100 1398 1.93 1457 2.14 1512 2.35 1565 2.57 1616 2.79 2250 1446 2.18 1504 2.40 1559 2.62 1611 2.85 --- --2400 1496 2.45 1552 2.68 --- --- --- --- --- --2550 1546 2.75 --- --- --- --- --- --- --- --2700 --- --- --- --- --- --- --- --- --- --2850 --- --- --- --- --- --- --- --- --- --3000 --- --- --- --- --- --- --- --- --- ---

Std static motor and drive (belt drive) Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

FAN PERFORMANCE (cont.)

Table 35 – 548J*08 7.5 TON HORIZONTAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

2250 --- --- 509 0.40 587 0.52 659 0.66 725 0.80 2438 --- --- 525 0.46 600 0.59 669 0.73 733 0.88 2625 465 0.40 543 0.53 614 0.67 680 0.82 743 0.97 2813 487 0.47 561 0.61 629 0.76 693 0.91 753 1.08 3000 510 0.55 580 0.70 646 0.86 707 1.02 765 1.19 3188 534 0.65 600 0.80 663 0.96 722 1.13 779 1.31 3375 557 0.75 621 0.91 681 1.08 738 1.26 793 1.44 3563 582 0.86 642 1.03 700 1.21 755 1.39 808 1.58 3750 606 0.99 664 1.17 720 1.35 773 1.54 824 1.74

CFM

2250 788 0.94 847 1.09 903 1.25 957 1.41 1009 1.58 2438 794 1.03 852 1.19 907 1.36 959 1.52 1010 1.70 2625 802 1.13 858 1.30 911 1.47 963 1.64 1012 1.82 2813 811 1.24 865 1.41 917 1.59 967 1.77 1016 1.96 3000 821 1.36 874 1.54 925 1.72 974 1.91 1021 2.11 3188 832 1.49 884 1.68 933 1.87 981 2.06 1028 2.26 3375 845 1.63 895 1.82 943 2.02 990 2.22 1035 2.43 3563 858 1.78 907 1.98 954 2.19 1000 2.40 1044 2.61 3750 873 1.94 920 2.15 966 2.36 1011 2.58 1054 2.80

Std static motor and drive (belt drive) Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

548J

Table 36 – 548J*08 7.5 TON VERTICAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

2250 --- --- 528 0.43 597 0.54 658 0.66 713 0.78 2438 470 0.37 548 0.50 615 0.62 675 0.75 729 0.88 2625 494 0.45 569 0.58 634 0.71 692 0.85 745 0.99 2813 518 0.53 590 0.67 653 0.82 710 0.96 763 1.11 3000 543 0.62 612 0.77 673 0.93 729 1.08 780 1.24 3188 568 0.72 635 0.89 694 1.05 749 1.21 799 1.38 3375 593 0.84 658 1.01 716 1.19 769 1.36 818 1.53 3563 619 0.97 681 1.15 737 1.33 789 1.52 837 1.70 3750 645 1.11 705 1.30 760 1.49 810 1.68 857 1.88

CFM

2250 764 0.89 812 1.02 856 1.14 899 1.26 939 1.39 2438 779 1.00 826 1.13 870 1.26 912 1.40 952 1.53 2625 795 1.12 841 1.26 885 1.40 926 1.54 966 1.68 2813 811 1.25 857 1.40 900 1.55 941 1.69 980 1.84 3000 828 1.39 873 1.55 916 1.70 956 1.86 995 2.02 3188 846 1.54 890 1.71 932 1.87 972 2.04 1010 2.21 3375 864 1.70 907 1.88 949 2.05 988 2.23 1026 2.40 3563 882 1.88 925 2.06 966 2.25 1005 2.43 1042 2.62 3750 902 2.07 944 2.26 984 2.45 1022 2.65 1059 2.84

Std static motor and drive (belt drive) Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

FAN PERFORMANCE (cont.)

Table 37 – 548J*09 8.5 TON HORIZONTAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

2550 468 0.39 546 0.52 618 0.66 684 0.80 747 0.96 2763 493 0.47 567 0.61 635 0.76 699 0.91 760 1.07 2975 520 0.57 589 0.72 654 0.87 716 1.03 774 1.20 3188 547 0.68 613 0.83 675 1.00 733 1.17 789 1.34 3400 575 0.80 637 0.96 696 1.14 752 1.31 806 1.50 3613 603 0.94 662 1.11 719 1.29 773 1.48 824 1.67 3825 631 1.09 688 1.27 742 1.46 794 1.66 843 1.86 4038 660 1.26 714 1.45 766 1.65 816 1.85 864 2.06 4250 689 1.45 741 1.65 790 1.86 838 2.07 885 2.29

CFM

548J

2550 806 1.11 863 1.28 916 1.45 968 1.62 1018 1.80 2763 817 1.24 871 1.41 924 1.59 974 1.77 1022 1.95 2975 829 1.37 882 1.55 932 1.74 981 1.93 1028 2.12 3188 843 1.53 894 1.71 943 1.90 990 2.10 1036 2.30 3400 858 1.69 907 1.88 955 2.09 1001 2.29 1046 2.50 3613 874 1.87 922 2.07 968 2.28 1013 2.49 1057 2.71 3825 891 2.07 938 2.28 983 2.49 1027 2.71 --- --4038 910 2.28 955 2.50 999 2.72 1041 2.95 --- --4250 930 2.51 973 2.74 1015 2.97 1057 3.21 --- ---

Std static motor and drive (belt drive) Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

Table 38 – 548J*09 8.5 VERTICAL SUPPLY

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

CFM

2550 495 0.43 570 0.56 634 0.70 693 0.83 746 0.96 2763 524 0.53 595 0.67 657 0.81 714 0.95 766 1.09 2975 552 0.63 620 0.79 681 0.94 736 1.09 787 1.24 3188 582 0.76 647 0.92 705 1.08 759 1.25 808 1.41 3400 611 0.89 674 1.07 730 1.24 782 1.42 831 1.59 3613 641 1.05 701 1.23 756 1.42 806 1.60 854 1.79 3825 672 1.22 729 1.42 782 1.61 831 1.81 877 2.00 4038 702 1.41 758 1.62 809 1.83 857 2.03 901 2.24 4250 733 1.62 787 1.84 836 2.06 883 2.28 926 2.49

CFM

2550 795 1.09 841 1.23 885 1.36 926 1.50 965 1.64 2763 814 1.24 859 1.38 902 1.53 943 1.68 982 1.82 2975 834 1.40 878 1.55 921 1.71 961 1.86 999 2.02 3188 855 1.57 898 1.74 940 1.90 979 2.07 1017 2.24 3400 876 1.76 919 1.94 960 2.12 998 2.29 1036 2.47 3613 898 1.97 940 2.16 980 2.34 1018 2.53 1055 2.72 3825 921 2.20 962 2.40 1001 2.59 1039 2.79 --- --4038 944 2.45 984 2.65 1023 2.86 - -- --- --- --4250 968 2.71 --- --- --- --- --- --- --- ---

Std static motor and drive (belt drive) Med static motor and drive (belt drive) High static motor and drive (belt drive)

0.2 0.4 0.6 0.8 1.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

AVAILABLEEXTERNALSTATICPRESSURE(IN.WG)

1.2 1.4 1.6 1.8 2.0

RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

FAN PERFORMANCE (cont.)

Table 39 – PULLEY ADJUSTMENT

UNIT MOTOR/DRIVE COMBO

Medium Static 1251 1208 1165 1121 1078 1035 992 949 905 862 819

3phase

NOTE: Do not adjust pulley further than 5 turns open.

--- F a c t o r y s e t t i n g s

High Static 1466 1423 1380 1337 1294 1251 1207 1164 1121 1078 1035

Medium Static 1303 1265 1226 1188 1150 1112 1073 1035 997 958 920

High Static 1466 1423 1380 1337 1294 1251 1207 1164 1121 1078 1035

Medium Static 1380 1349 1317 1286 1254 1223 1192 1160 1129 1097 1066

High Static 1639 1596 1553 1510 1467 1424 1380 1337 1294 1251 1208

Standard Static 1192 1161 1129 1098 1066 1035 1004 972 941 909 878

Medium Static 1380 1349 1317 1286 1254 1223 1192 1160 1129 1097 1066

High Static 1639 1596 1553 1510 1467 1424 1380 1337 1294 1251 1208

Standard Static 652 633 614 594 575 556 537 518 498 479 460

Medium Static 838 813 789 764 739 715 690 665 640 616 591

High Static 1084 1059 1035 1010 986 961 936 912 887 863 838

Standard Static 652 633 614 594 575 556 537 518 498 479 460

Medium Static 838 813 789 764 739 715 690 665 640 616 591

High Static 1084 1059 1035 1010 986 961 936 912 887 863 838

0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5

MOTOR PULLEY TURNS OPEN

548J

ECONOMIZER, BAROMETRIC RELIEF AND PE PERFORMANCE

500

1000

1500

2000

2500

0 0.05 0.1 0.15 0.2 0.25 0.3

RETURN DUCT STATIC PRESS URE (in. wg)

RELI EF FLOW (CF M)

3-6 Ton

7.5-8.5 Ton

Horizo ntal Ec onomiz ers

0.00 0.10 0.20 0.30 0.40 0.50

STATIC PRESSURE DELTA (in. wg)

LEAKAGE ACROSS DAMPER (CFM)

3 - 6 Ton

7.5 - 8.5 Ton

Horizontal Economizers

1000

2000

3000

4000

5000

6000

0 0 .1 0.2 0.3 0.4

RETURN DUCT STATIC PRESS URE DROP (in. wg)

RETU RN AIR F LOW (CFM)

3 - 6 Ton

7.5 - 8.5 Ton

Horizontal Economizers

500

1000

1500

2000

2500

0 0.05 0.1 0.15 0.2 0.25 0.3

RETURN DUCT STATIC PRESS URE (in. wg)

RELIEF FLOW (CFM)

3 - 6 Ton

7.5 - 8.5 Ton

Vertical Economizers

0.00 0.10 0.20 0.30 0.40 0.50

STATIC PRESSURE DELTA (in. wg)

LEAKAGE ACROSS DAMPER (CFM)

3 - 6 Ton

7.5 - 8.5 Ton

Vertical Economizers

1000

2000

3000

4000

5000

6000

0 0.1 0.2 0.3 0.4

RETURN DUCT STATIC PRESS URE DROP (in. wg)

RETU RN AIR F LOW (CFM)

3 - 6 Ton

7.5 - 8.5 Ton

Vertical Economizers

548J

Fig. 9 -- Barometric Relief Flow Capacity

Fig. 10 -- Outdoor Air Damper Leakage

C09028

C09029

C09031

Fig. 13 -- Barometric Relief Flow Capacity

C09032

Fig. 14 -- Outdoor Air Damper Leakage

Fig. 11 -- Return Air Pressure Drop

5000

4000

3000

EXHAUST

2000

AIRFLOW (cfm)

1000

0 0.1 0.2 0.3 0.4 0.5

RETURN DUCT STATIC PRESSURE (in. wg)

Fig. 12 -- Horizontal Power Exhaust Performance

C09030

Vertical Power Exhaust

2- 6

Ton

7. 5-8.5 Ton

C08012

EXHAUST

Fig. 15 -- Return Air Pressure Drop

5000

4000

3000

2000

AIRFLOW (cfm)

1000

0 0.1 0.2 0.3 0.4 0.5

RETURN DUCT STATIC PRESSURE (in. wg)

Fig. 16 -- Power Exhaust Performance

C09033

2- 6 Ton

7. 5-12 .5 Ton

C09034

ELECTRICAL INFORMATION

Table 40 – 548J*04 1--Stage Cooling 3 TONS

VO LTAG E

V--Ph--Hz

208--1--60 187 253 17.9 112 190 0.9 DD-- STD 980 7.8 84% 7.4 230--1--60 187 253 17.9 112 190 0.9 DD-- STD 980 7.8 84% 7.4

208--3--60 187 253 13.2 88 190 0.9

230--3--60 187 253 13.2 88 190 0.9

460--3--60 414 506 6.0 44 190 0.5

575--3--60 518 633 NA NA 190 0.4

RANGE

MIN MAX RLA LRA WATTS FLA TYPE

COMP (ea) OFM (ea) IFM

Max

WATTS

DD-- STD 980 7.8 84% 7.4

MED 2000 5.5 80% 5.2

HIGH 2000 5.5 80% 5.2

DD-- STD 980 7.8 84% 7.4

MED 2000 5.5 80% 5.2

HIGH 2000 5.5 80% 5.2

DD-- STD 980 8.0 84% 7.6

MED 2000 2.7 80% 2.6

HIGH 2000 2.7 80% 2.6

DD-- STD 980 4.2 84% 4.0

MED 2000 2.5 80% 2.4

HIGH 2000 2.1 80% 2.0

Max

AMP Draw

EFF at Full Load FLA

Table 41 – 548J*05 1--Stage Cooling 4 TONS

VO LTAG E

V--Ph--Hz

208--1--60 187 253 21.8 117 325 1.5 D D --- S T D 980 7.8 84% 7.4 230--1--60 187 253 21.8 117 325 1.5 D D --- S T D 980 7.8 84% 7.4

208--3--60 187 253 13.7 83 325 1.5

230--3--60 187 253 13.7 83 325 1.5

460--3--60 414 506 6.2 41 325 0.8

575--3--60 518 633 4.8 37 325 0.6

RANGE

MIN MAX RLA LRA WATTS FLA TYPE

COMP (ea) OFM (ea) IFM

Max

WATTS

D D --- S T D 980 7.8 84% 7.4

MED 2000 5.5 80% 5.2

HIGH 2000 5.5 80% 5.2

D D --- S T D 980 7.8 84% 7.4

MED 2000 5.5 80% 5.2

HIGH 2000 5.5 80% 5.2

D D --- S T D 980 8.0 84% 7.6

MED 2000 2.7 80% 2.6

HIGH 2000 2.7 80% 2.6

D D --- S T D 980 4.2 84% 4.0

MED 2000 2.5 80% 2.4

HIGH 2000 2.1 80% 2.0

Max

AMP Draw

EFF at Full Load FLA

548J

Table 42 – 548J*06 1--Stage Cooling 5 TONS

VOLTAGE

V --- P h --- H z

2 0 8 --- 1 --- 6 0 187 253 26.2 134 325 1.5 D D --- S T D 980 7.8 84% 7.4 2 3 0 --- 1 --- 6 0 187 253 26.2 134 325 1.5 D D --- S T D 980 7.8 84% 7.4

2 0 8 --- 3 --- 6 0 187 253 15.6 110 325 1.5

2 3 0 --- 3 --- 6 0 187 253 15.6 110 325 1.5

4 6 0 --- 3 --- 6 0 414 506 7.7 52 325 0.8

5 7 5 --- 3 --- 6 0 518 633 5.8 39 325 0.6

RANGE

MIN MAX RLA LRA WATTS FLA TYPE

COM

(ea)

OFM (ea) IFM

D D --- S T D 980 7.8 84% 7.4

MED 2000 5.5 80% 5.2

HIGH 2770 7.9 81% 7.5

D D --- S T D 980 7.8 84% 7.4

MED 2000 5.5 80% 5.2

HIGH 2770 7.9 81% 7.5

D D --- S T D 980 8.0 84% 7.6

MED 2000 2.7 80% 2.6

HIGH 2770 3.6 81% 3.4

D D --- S T D 980 4.2 84% 4.0

MED 2000 2.1 80% 2.0

HIGH 2770 2.9 81% 2.8

Max

WATTS

Max

AMP Draw

EFF at Full Load FLA

ELECTRICAL INFORMATION (cont.)

Table 43 – 548J*07 1--Stage Cooling 6 TONS

VOLTAGE

V --- P h --- H z

2 0 8 --- 3 --- 6 0 187 253 19.0 123 325 1.5

2 3 0 --- 3 --- 6 0 187 253 19.0 123 325 1.5

4 6 0 --- 3 --- 6 0 414 506 9.7 62 325 0.8

5 7 5 --- 3 --- 6 0 518 633 7.4 50 325 0.6

RANGE

MIN MAX

548J

COMP (ea) OFM (ea) IFM

RLA LRA WATTS FLA TYPE

STD 1600 5.5 80% 5.2

MED 2770 7.9 81% 7.5

HIGH 2770 7.9 81% 7.5

STD 1600 5.5 80% 5.2

MED 2770 7.9 81% 7.5

HIGH 2770 7.9 81% 7.5

STD 1600 2.7 80% 2.6

MED 2770 3.6 81% 3.4

HIGH 2770 3.6 81% 3.4

STD 1600 2.5 80% 2.4

MED 2770 2.9 81% 2.8

HIGH 2770 2.9 81% 2.8

Max

WATTS

Max

AMP Draw

EFF at Full Load FLA

Table 44 – 548J*08 2--Stage Cooling 7.5 TONS

VOLTAGE

V --- P h --- H z

2 0 8 --- 3 --- 6 0 187 253 13.1 83 13.1 83 325 1.5

2 3 0 --- 3 --- 6 0 187 253 13.1 83 13.1 83 325 1.5

4 6 0 --- 3 --- 6 0 414 506 6.1 41 6.1 41 325 0.8

5 7 5 --- 3 --- 6 0 518 633 4.4 33 4.4 33 325 0.6

RANGE

MIN MAX

COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM

RLA LRA RLA LRA WAT TS FLA TYPE

STD 1310 5.5 80% 5.2

MED 2770 7.9 81% 7.5

HIGH 2770 7.9 81% 7.5

STD 1310 5.5 80% 5.2

MED 2770 7.9 81% 7.5

HIGH 2770 7.9 81% 7.5

STD 1310 2.7 80% 2.6

MED 2770 3.6 81% 3.4

HIGH 2770 3.6 81% 3.4

STD 1310 2.5 80% 2.4

MED 2770 2.9 81% 2.8

HIGH 2770 2.9 81% 2.8

Max

WATTS

Max

AMP

Draw

EFF at

Full

Load

FLA

Table 45 – 548J*09 2--Stage Cooling 8.5 TONS

VOLTAGE

V --- P h --- H z

2 0 8 --- 3 --- 6 0 187 253 16.0 91 13.7 83 325 1.5

2 3 0 --- 3 --- 6 0 187 253 16.0 91 13.7 83 325 1.5

4 6 0 --- 3 --- 6 0 414 506 7.0 46 6.2 41 325 0.8

5 7 5 --- 3 --- 6 0 518 633 5.6 37 4.8 37 325 0.6

RANGE

MIN MAX

COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM

RLA LRA RLA LRA WAT TS FLA TYPE

STD 1310 5.5 80% 5.2

MED 2770 7.9 80% 7.5

HIGH 2770 7.9 80% 7.5

STD 1310 5.5 80% 5.2

MED 2770 7.9 80% 7.5

HIGH 2770 7.9 80% 7.5

STD 1310 2.7 80% 2.6

MED 2770 3.6 80% 3.4

HIGH 2770 3.6 80% 3.4

STD 1310 2.5 80% 2.4

MED 2770 2.9 80% 2.8

HIGH 2770 2.9 81% 2.8

Max

WATTS

Max

AMP

Draw

EFF at

Full

Load

FLA

Table 46 – MCA/MOCP DETERMINATION WITHOUT C.O. OR UNPWRD C.O.

ELEC. HTR WITHOUT C.O. or UNPWR C.O.

IFM

UNIT

TYPE

Nom (kW)

FLA

MCA MOCP

N O M . V --- P H --- H Z

--- --- 30.7 45 30 121 32.6 50 32 123

3.3/4.4 15.9/18.3 50.6/53.6 60/60 48/51 137/139 52.5/55.5 60/60 51/53 139/141

D D --- S T D

4.9/6.5 23.5/27.1 60.1/64.6 70/70 57/61 145/148 62.0/66.5 70/70 59/63 147/150

6.5/8.7 31.4/36.3 69.9/76.1 70/80 66/72 152/157 71.8/78.0 80/80 68/74 154/159

7.9/10.5 37.9/43.8 78.1/85.4 80/90 74/81 159/165 80.0/87.3 80/90 76/83 161/167

208/230--- 1 --- 60

9.8/13.0 46.9/54.2 89.3/98.4 90/100 84/92 215/229 91.2/100.3 100/110 86/95 217/231

--- --- 24.8 30 25 97 26.7 30 27 99

3.3/4.4 9.2/10.6 36.3/38.1 45/45 35/37 106/108 38.2/40.0 45/50 37/39 108/110

D D --- S T D

4.9/6.5 13.6/15.6 41.8/44.3 50/50 40/43 111/113 43.7/46.2 50/50 43/45 113/115

6.5/8.7 18.1/20.9 47.4/50.9 50/60 46/49 115/118 49.3/52.8 50/60 48/51 117/120

7.9/10.5 21.9/25.3 52.2/56.4 60/60 50/54 119/122 54.1/58.3 60/60 52/56 121/124

12.0/16.0 33.4/38.5 66.6/72.9 70/80 63/69 130/136 68.5/74.8 70/80 65/71 132/138

--- --- 22.6 30 22 109 24.5 30 24 111

3.3/4.4 9.2/10.6 34.1/35.9 45/45 33/34 118/120 36.0/37.8 45/45 35/37 120/122

MED

4.9/6.5 13.6/15.6 39.6/42.1 45/50 38/40 123/125 41.5/44.0 50/50 40/42 125/127

6.5/8.7 18.1/20.9 45.2/48.7 50/50 43/46 127/130 47.1/50.6 50/60 45/48 129/132

7.9/10.5 21.9/25.3 50.0/54.2 50/60 47/51 131/134 51.9/56.1 60/60 50/53 133/136

208/230--- 3 --- 60

12.0/16.0 33.4/38.5 64.4/70.7 70/80 61/66 142/148 66.3/72.6 70/80 63/69 144/150

--- --- 22.6 30 22 120 24.5 30 24 122

3.3/4.4 9.2/10.6 34.1/35.9 45/45 33/34 129/131 36.0/37.8 45/45 35/37 131/133

HIGH

548J*04

4.9/6.5 13.6/15.6 39.6/42.1 45/50 38/40 134/136 41.5/44.0 50/50 40/42 136/138

6.5/8.7 18.1/20.9 45.2/48.7 50/50 43/46 138/141 47.1/50.6 50/60 45/48 140/143

7.9/10.5 21.9/25.3 50.0/54.2 50/60 47/51 142/145 51.9/56.1 60/60 50/53 144/147

12.0/16.0 33.4/38.5 64.4/70.7 70/80 61/66 153/159 66.3/72.6 70/80 63/69 155/161

--- --- 16.0 20 16 53 17.0 20 17 54

6.0 7.2 25.0 30 24 60 26.0 30 26 61

D D --- S T D

8.8 10.6 29.3 30 28 64 30.3 35 30 65

11.5 13.8 33.3 35 32 67 34.3 35 33 68

14.0 16.8 37.0 40 36 70 38.0 40 37 71

--- --- 10.6 15 10 54 11.6 15 12 55

6.0 7.2 19.6 20 19 61 20.6 25 20 62

MED

4 6 0 --- 3 --- 6 0

8.8 10.6 23.9 25 23 65 24.9 25 24 66

11.5 13.8 27.9 30 26 68 28.9 30 27 69

14.0 16.8 31.6 35 30 71 32.6 35 31 72

--- --- 10.6 15 10 60 11.6 15 12 61

6.0 7.2 19.6 20 19 67 20.6 25 20 68

HIGH

8.8 10.6 23.9 25 23 71 24.9 25 24 72

11.5 13.8 27.9 30 26 74 28.9 30 27 75

14.0 16.8 31.6 35 30 77 32.6 35 31 78

D D --- S T D --- --- 5.4 15 5 5 7.4 15 7 7

MED --- --- 3.4 15 3 8 5.4 15 5 10

HIGH --- --- 2.9 15 3 12 4.9 15 5 14

7 5 --- 3 --- 6 0

LEGEND

C.O. --- Convenient outlet DD --- Electric Drive X13 Motor DISC - -- Disconnect FLA --- Full load amps IFM --- Indoor fan motor LRA --- Locked rotor amps MCA --- Minimum circuit amps MOCP --- Maximum over current protection P.E . --- P o w e r e x h a u s t UNPWRD C.O. --- Unpowered convenient outlet NOTES:

1. In compliance with NEC requirements for multimotor and combination load equipment (refer to NEC Articles 430 and

440), the overcurrent protective device for the unit shall be fuse or HACR breaker. Canadian units may be fuse or circuit breaker.

2. Unbalanced 3-Phase Supply Voltage Never operate a motor where a phase imbalance in supply voltage is greater than 2%. Use the following formula to determine the percentage of voltage imbalance.

% Voltage Imbalance = 100 x

max voltage deviation from average voltage

average voltage

WITHOUT P.E. WITH P.E.

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

Example: Supply voltage is 230-3-60

AB = 224V BC = 231V AC = 226V

Average Voltage =

(224 + 231 + 226)

= 227

Determine maximum deviation from average voltage. (AB) 227 – 224 = 3V Maximum deviation is 4V. (BC) 231 – 227 = 4V Determine percent of voltage imbalance.

% Voltage Imbalance = 100 x

= 1.76%

227

This amount of phase imbalance is satisfactory as it is below the maximum allowable 2%.

IMPORTANT: If the supply voltage phase imbalance is more than 2%, contact your local electric utility company immediately.

DISC. SIZE

548J

681

Table 46 – (cont.) MCA/MOCP DETERMINATION WITHOUT C.O. OR UNPWRD C.O.

ELEC. HTR WITHOUT C.O. or UNPWR C.O.

WITHOUT P.E. WITH P.E.

DISC. SIZE

FLA LRA FLA LRA

UNIT

548J

548J*05

See Notes page 49.

IFM

TYPE

N O M . V --- P H --- H Z

D D --- S T D

208/230--- 1 --- 60

D D --- S T D

MED

208/230--- 3 --- 60

HIGH

D D --- S T D

MED

4 6 0 --- 3 --- 6 0

HIGH

D D --- S T D --- --- 10.6 15 11 43 12.5 15 13 45

MED --- --- 9.0 15 9 46 10.9 15 11 48

HIGH --- --- 8.6 15 9 50 10.5 15 11 52

5 7 5 --- 3 --- 6 0

Nom (kW)

--- --- 36.2 50 35 128 38.1 50 37 130

3.3/4.4 15.9/18.3 56.0/59.0 60/60 54/56 144/146 57.9/60.9 60/70 56/59 146/148

6.5/8.7 31.4/36.3 75.4/81.5 80/90 71/77 159/164 77.3/83.4 80/90 74/79 161/166

9.8/13.0 46.9/54.2 94.8/103.9 100/110 89/98 222/236 96.7/105.8 100/110 91/100 224/238

13.1/17.4 62.8/72.5 114.7/126.8 125/150 108/119 254/273 116.6/128.7 125/150 110/121 256/275

15.8/21.0 75.8/87.5 130.9/145.5 150/150 122/136 280/303 132.8/147.4 150/150 125/138 282/305

--- --- 26.0 30 26 94 27.9 40 28 96

4.9/6.5 13.6/15.6 43.0/45.5 50/50 42/44 108/110 44.9/47.4 50/50 44/46 110/112

6.5/8.7 18.1/20.9 48.7/52.2 50/60 47/50 112/115 50.6/54.1 60/60 49/52 114/117

12.0/16.0 33.4/38.5 67.8/74.2 70/80 64/70 127/133 69.7/76.1 70/80 67/72 129/135

15.8/21.0 43.8/50.5 80.8/89.2 90/90 76/84 182/195 82.7/91.1 90/100 79/86 184/197

--- --- 23.8 30 23 106 25.7 30 26 108

4.9/6.5 13.6/15.6 40.8/43.3 50/50 39/41 120/122 42.7/45.2 50/50 41/44 122/124

6.5/8.7 18.1/20.9 46.5/50.0 50/50 44/47 124/127 48.4/51.9 50/60 46/50 126/129

12.0/16.0 33.4/38.5 65.6/72.0 70/80 62/68 139/145 67.5/73.9 70/80 64/70 141/147

15.8/21.0 43.8/50.5 78.6/87.0 80/90 74/82 194/207 80.5/88.9 90/90 76/84 196/209

--- --- 23.8 30 23 117 25.7 30 26 119

4.9/6.5 13.6/15.6 40.8/43.3 50/50 39/41 131/133 42.7/45.2 50/50 41/44 133/135

6.5/8.7 18.1/20.9 46.5/50.0 50/50 44/47 135/138 48.4/51.9 50/60 46/50 137/140

12.0/16.0 33.4/38.5 65.6/72.0 70/80 62/68 150/156 67.5/73.9 70/80 64/70 152/158

15.8/21.0 43.8/50.5 78.6/87.0 80/90 74/82 205/218 80.5/88.9 90/90 76/84 207/220

--- --- 16.5 20 17 51 17.5 25 18 52

6.0 7.2 25.5 30 25 58 26.5 30 26 59

11.5 13.8 33.8 35 33 65 34.8 35 34 66

14.0 16.8 37.5 40 36 68 38.5 40 37 69

23.0 27.7 51.1 60 49 106 52.1 60 50 107

--- --- 11.2 15 11 52 12.2 15 12 53

6.0 7.2 20.2 25 19 59 21.2 25 20 60

11.5 13.8 28.4 30 27 66 29.4 30 28 67

14.0 16.8 32.2 35 30 69 33.2 35 32 70

23.0 27.7 45.8 50 43 107 46.8 50 44 108

--- --- 11.2 15 11 58 12.2 15 12 59

6.0 7.2 20.2 25 19 65 21.2 25 20 66

11.5 13.8 28.4 30 27 72 29.4 30 28 73

14.0 16.8 32.2 35 30 75 33.2 35 32 76

23.0 27.7 45.8 50 43 113 46.8 50 44 114

FLA

MCA MOCP

DISC. SIZE

Table 46 – (cont.) MCA/MOCP DETERMINATION WITHOUT C.O. OR UNPWRD C.O.

ELEC. HTR WITHOUT C.O. or UNPWR C.O.

IFM

UNIT

548J*06

See Notes page 49.

TYPE

N O M . V --- P H --- H Z

D D --- S T D

208/230--- 1 --- 60

D D --- S T D

MED

208/230--- 3 --- 60

HIGH

D D --- S T D

MED

4 6 0 --- 3 --- 6 0

HIGH

D D --- S T D --- --- 11.9 15 12 45 13.8 20 14 47

MED --- --- 9.9 15 10 52 11.8 15 12 54

HIGH --- --- 10.7 15 11 63 12.6 15 13 65

5 7 5 --- 3 --- 6 0

WITHOUT P.E. WITH P.E.

Nom (kW)

--- --- 41.7 60 40 145 43.6 60 43 147

4.9/6.5 23.5/27.1 71.0/75.5 80/80 67/72 169/172 72.9/77.4 80/80 70/74 171/174

6.5/8.7 31.4/36.3 80.9/87.0 90/100 76/82 176/181 82.8/88.9 100/100 79/84 178/183

9.8/13.0 46.9/54.2 100.3/109.4 110/110 94/103 239/253 102.2/111.3 110/125 96/105 241/255

13.1/17.4 62.8/72.5 120.2/132.3 125/150 113/124 271/290 122.1/134.2 125/150 115/126 273/292

15.8/21.0 75.8/87.5 136.4/151.0 150/175 128/141 297/320 138.3/152.9 150/175 130/143 299/322

--- --- 28.4 40 28 121 30.3 45 30 123

4.9/6.5 13.6/15.6 45.4/47.9 50/50 44/46 135/137 47.3/49.8 50/60 46/48 137/139

7.9/10.5 21.9/25.3 55.8/60.0 60/70 53/57 143/146 57.7/61.9 60/70 56/59 145/148

12.0/16.0 33.4/38.5 70.2/76.5 80/80 67/72 154/160 72.1/78.4 80/80 69/75 156/162

15.8/21.0 43.8/50.5 83.2/91.5 90/100 79/86 209/222 85.1/93.4 90/100 81/88 211/224

19.9/26.5 55.2/63.8 97.4/108.2 100/110 92/102 231/249 99.3/110.1 100/125 94/104 233/251

--- --- 26.2 40 26 144 28.1 40 28 146

4.9/6.5 13.6/15.6 43.2/45.7 50/50 41/44 158/160 45.1/47.6 50/50 43/46 160/162

7.9/10.5 21.9/25.3 53.6/57.8 60/60 51/55 166/169 55.5/59.7 60/60 53/57 168/171

12.0/16.0 33.4/38.5 68.0/74.3 70/80 64/70 177/183 69.9/76.2 70/80 66/72 179/185

15.8/21.0 43.8/50.5 81.0/89.3 90/90 76/84 232/245 82.9/91.2 90/100 78/86 234/247

19.9/26.5 55.2/63.8 95.2/106.0 100/110 89/99 254/272 97.1/107.9 100/110 91/101 256/274

--- --- 28.5 40 28 170 30.4 45 30 172

4.9/6.5 13.6/15.6 45.5/48.0 50/50 44/46 184/186 47.4/49.9 50/60 46/48 186/188

7.9/10.5 21.9/25.3 55.9/60.1 60/70 53/57 192/195 57.8/62.0 60/70 56/60 194/197

12.0/16.0 33.4/38.5 70.3/76.6 80/80 67/73 203/209 72.2/78.5 80/80 69/75 205/211

15.8/21.0 43.8/50.5 83.3/91.6 90/100 79/86 258/271 85.2/93.5 90/100 81/89 260/273

19.9/26.5 55.2/63.8 97.5/108.3 100/110 92/102 280/298 99.4/110.2 100/125 94/104 282/300

--- --- 18.0 25 19 62 19.0 25 20 63

6.0 7.2 27.0 30 27 69 28.0 30 28 70

11.5 13.8 35.3 40 34 76 36.3 40 36 77

14.0 16.8 39.0 40 38 79 40.0 45 39 80

23.0 27.7 52.7 60 50 117 53.7 60 52 118

25.5 30.7 56.4 60 54 123 57.4 60 55 124

--- --- 13.0 20 13 69 14.0 20 14 70

6.0 7.2 22.0 25 21 76 23.0 25 22 77

11.5 13.8 30.3 35 29 83 31.3 35 30 84

14.0 16.8 34.0 35 32 86 35.0 40 33 87

23.0 27.7 47.7 50 45 124 48.7 50 46 125

25.5 30.7 51.4 60 48 130 52.4 60 49 131

--- --- 13.8 20 14 82 14.8 20 15 83

6.0 7.2 22.8 25 22 89 23.8 25 23 90

11.5 13.8 31.1 35 30 96 32.1 35 31 97

14.0 16.8 34.8 35 33 99 35.8 40 34 100

23.0 27.7 48.5 50 46 137 49.5 50 47 138

25.5 30.7 52.2 60 49 143 53.2 60 50 144

FLA

MCA MOCP

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

548J

Table 46 – (cont.) MCA/MOCP DETERMINATION WITHOUT C.O. OR UNPWRD C.O.

ELEC. HTR WITHOUT C.O. or UNPWR C.O.

UNIT

548J

548J*07

See Notes page 49.

IFM

TYPE

N O M . V --- P H --- H Z

STD

MED

208/230--- 3 --- 60

HIGH

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

STD --- --- 12.3 15 12 59 14.2 20 14 61

MED --- --- 12.7 20 12 74 14.6 20 15 76

HIGH --- --- 12.7 20 12 74 14.6 20 15 76

5 7 5 --- 3 --- 6 0

Nom (kW)

--- --- 30.5 45 30 146 32.4 50 32 148

4.9/6.5 13.6/15.6 47.5/50.0 60/60 45/47 160/162 49.4/51.9 60/60 47/50 162/164

7.9/10.5 21.9/25.3 57.8/62.1 60/70 55/59 168/171 59.7/64.0 60/70 57/61 170/173

12.0/16.0 33.4/38.5 72.2/78.6 80/80 68/74 179/185 74.1/80.5 80/90 70/76 181/187

15.8/21.0 43.8/50.5 85.2/93.6 90/100 80/88 234/247 87.1/95.5 90/100 82/90 236/249

19.9/26.5 55.2/63.8 99.5/110.2 100/125 93/103 256/274 101.4/112.1 110/125 95/105 258/276

--- --- 32.8 50 32 183 34.7 50 34 185

4.9/6.5 13.6/15.6 49.8/52.3 60/60 48/50 197/199 51.7/54.2 60/60 50/52 199/201

7.9/10.5 21.9/25.3 60.1/64.4 70/70 57/61 205/208 62.0/66.3 70/70 60/63 207/210

12.0/16.0 33.4/38.5 74.5/80.9 80/90 71/76 216/222 76.4/82.8 80/90 73/79 218/224

15.8/21.0 43.8/50.5 87.5/95.9 90/100 83/90 271/284 89.4/97.8 90/100 85/92 273/286

19.9/26.5 55.2/63.8 101.8/112.5 110/125 96/106 293/311 103.7/114.4 110/125 98/108 295/313

--- --- 32.8 50 32 183 34.7 50 34 185

4.9/6.5 13.6/15.6 49.8/52.3 60/60 48/50 197/199 51.7/54.2 60/60 50/52 199/201

7.9/10.5 21.9/25.3 60.1/64.4 70/70 57/61 205/208 62.0/66.3 70/70 60/63 207/210

12.0/16.0 33.4/38.5 74.5/80.9 80/90 71/76 216/222 76.4/82.8 80/90 73/79 218/224

15.8/21.0 43.8/50.5 87.5/95.9 90/100 83/90 271/284 89.4/97.8 90/100 85/92 273/286

19.9/26.5 55.2/63.8 101.8/112.5 110/125 96/106 293/311 103.7/114.4 110/125 98/108 295/313

--- --- 15.5 25 15 73 16.5 25 16 74

6.0 7.2 24.5 30 23 80 25.5 30 24 81

11.5 13.8 32.8 35 31 87 33.8 40 32 88

14.0 16.8 36.5 40 34 90 37.5 40 36 91

23.0 27.7 50.2 60 47 128 51.2 60 48 129

25.5 30.7 53.9 60 50 134 54.9 60 52 135

--- --- 16.3 25 16 92 17.3 25 17 93

6.0 7.2 25.3 30 24 99 26.3 30 25 100

11.5 13.8 33.6 35 32 106 34.6 40 33 107

14.0 16.8 37.3 40 35 109 38.3 40 36 110

23.0 27.7 51.0 60 48 147 52.0 60 49 148

25.5 30.7 54.7 60 51 153 55.7 60 52 154

--- --- 16.3 25 16 92 17.3 25 17 93

6.0 7.2 25.3 30 24 99 26.3 30 25 100

11.5 13.8 33.6 35 32 106 34.6 40 33 107

14.0 16.8 37.3 40 35 109 38.3 40 36 110

23.0 27.7 51.0 60 48 147 52.0 60 49 148

25.5 30.7 54.7 60 51 153 55.7 60 52 154

FLA

MCA MOCP

WITHOUT P.E. WITH P.E.

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

Table 46 – (cont.) MCA/MOCP DETERMINATION WITHOUT C.O. OR UNPWRD C.O.

ELEC. HTR WITHOUT C.O. or UNPWR C.O.

IFM

UNIT

548J*08

See Notes page 49.

TYPE

N O M . V --- P H --- H Z

STD

MED

208/230--- 3 --- 60

HIGH

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

STD

MED

5 7 5 --- 3 --- 6 0

HIGH

WITHOUT P.E. WITH P.E.

Nom (kW)

--- --- 37.7 50 40 193 41.5 50 44 197

7.8/10.4 21.7/25.0 64.8/68.9 70/70 65/68 215/218 68.6/72.7 70/80 69/73 219/222

12.0/16.0 33.4/38.5 79.4/85.8 80/90 78/84 226/232 83.2/89.6 90/90 82/88 230/236

18.6/24.8 51.7/59.7 102.3/112.3 110/125 99/108 245/253 106.1/116.1 110/125 103/113 249/257

24.0/32.0 66.7/77.0 121.1/133.9 125/150 116/128 260/270 124.9/137.7 125/150 121/132 264/274

31.8/42.4 88.4/102.0 148.2/165.2 150/175 141/157 370/397 152.0/169.0 175/175 146/161 374/401

--- --- 40.0 50 42 230 43.8 50 47 234

7.8/10.4 21.7/25.0 67.1/71.2 70/80 67/71 252/255 70.9/75.0 80/80 72/75 256/259

12.0/16.0 33.4/38.5 81.7/88.1 90/90 81/86 263/269 85.5/91.9 90/100 85/91 267/273

18.6/24.8 51.7/59.7 104.6/114.6 110/125 102/111 282/290 108.4/118.4 110/125 106/115 286/294

24.0/32.0 66.7/77.0 123.4/136.2 125/150 119/131 297/307 127.2/140.0 150/150 123/135 301/311

31.8/42.4 88.4/102.0 150.5/167.5 175/175 144/160 407/434 154.3/171.3 175/175 148/164 411/438

--- --- 40.0 50 42 230 43.8 50 47 234

7.8/10.4 21.7/25.0 67.1/71.2 70/80 67/71 252/255 70.9/75.0 80/80 72/75 256/259

12.0/16.0 33.4/38.5 81.7/88.1 90/90 81/86 263/269 85.5/91.9 90/100 85/91 267/273

18.6/24.8 51.7/59.7 104.6/114.6 110/125 102/111 282/290 108.4/118.4 110/125 106/115 286/294

24.0/32.0 66.7/77.0 123.4/136.2 125/150 119/131 297/307 127.2/140.0 150/150 123/135 301/311

31.8/42.4 88.4/102.0 150.5/167.5 175/175 144/160 407/434 154.3/171.3 175/175 148/164 411/438

--- --- 17.9 20 19 95 19.7 25 21 97

13.9 16.7 38.8 40 38 112 40.6 45 40 114

16.5 19.8 42.7 45 42 115 44.5 45 44 117

27.8 33.4 59.7 60 57 128 61.5 70 59 130

33.0 39.7 67.6 70 65 135 69.4 70 67 137

41.7 50.2 80.7 90 77 195 82.5 90 79 197

--- --- 18.7 25 20 114 20.5 25 22 116

13.9 16.7 39.6 40 39 131 41.4 45 41 133

16.5 19.8 43.5 45 43 134 45.3 50 45 136

27.8 33.4 60.5 70 58 147 62.3 70 60 149

33.0 39.7 68.4 70 65 154 70.2 80 68 156

41.7 50.2 81.5 90 78 214 83.3 90 80 216

--- --- 18.7 25 20 114 20.5 25 22 116

13.9 16.7 39.6 40 39 131 41.4 45 41 133

16.5 19.8 43.5 45 43 134 45.3 50 45 136

27.8 33.4 60.5 70 58 147 62.3 70 60 149

33.0 39.7 68.4 70 65 154 70.2 80 68 156

41.7 50.2 81.5 90 78 214 83.3 90 80 216

--- --- 13.5 15 14 77 17.3 20 19 81

17.0 20.4 39.0 40 38 97 42.8 45 42 101

34.0 40.9 64.6 70 61 118 68.4 70 66 122

--- --- 13.9 20 15 92 17.7 20 19 96

17.0 20.4 39.4 40 38 112 43.2 45 43 116

34.0 40.9 65.0 70 62 133 68.8 70 66 137

--- --- 13.9 20 15 92 17.7 20 19 96

17.0 20.4 39.4 40 38 112 43.2 45 43 116

34.0 40.9 65.0 70 62 133 68.8 70 66 137

FLA

MCA MOCP

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

548J

Table 46 – (cont.) MCA/MOCP DETERMINATION WITHOUT C.O. OR UNPWRD C.O.

ELEC. HTR WITHOUT C.O. or UNPWR C.O.

UNIT

548J

548J*09

See Notes page 49.

N O M . V --- P H --- H Z

208/230--- 3 --- 60

4 6 0 --- 3 --- 6 0

5 7 5 --- 3 --- 6 0

IFM

TYPE

STD

MED

HIGH

STD

MED

HIGH

STD

MED

HIGH

WITHOUT P.E. WITH P.E.

Nom (kW)

--- --- 41.9 50 44 201 45.7 60 48 205

7.8/10.4 21.7/25.0 69.0/73.2 70/80 69/72 223/226 72.8/77.0 80/80 73/77 227/230

12.0/16.0 33.4/38.5 83.7/90.0 90/100 82/88 234/240 87.5/93.8 90/100 86/92 238/244

18.6/24.8 51.7/59.7 106.5/116.5 110/125 103/112 253/261 110.3/120.3 125/125 107/117 257/265

24.0/32.0 66.7/77.0 125.3/138.2 150/150 120/132 268/278 129.1/142.0 150/150 125/137 272/282

31.8/42.4 88.4/102.0 152.4/169.4 175/175 145/161 378/405 156.2/173.2 175/175 150/165 382/409

--- --- 44.2 60 46 238 48.0 60 51 242

7.8/10.4 21.7/25.0 71.3/75.5 80/80 71/75 260/263 75.1/79.3 80/80 76/79 264/267

12.0/16.0 33.4/38.5 86.0/92.3 90/100 85/91 271/277 89.8/96.1 90/100 89/95 275/281

18.6/24.8 51.7/59.7 108.8/118.8 110/125 106/115 290/298 112.6/122.6 125/125 110/119 294/302

24.0/32.0 66.7/77.0 127.6/140.5 150/150 123/135 305/315 131.4/144.3 150/150 127/139 309/319

31.8/42.4 88.4/102.0 154.7/171.7 175/175 148/164 415/442 158.5/175.5 175/200 152/168 419/446

--- --- 44.2 60 46 238 48.0 60 51 242

7.8/10.4 21.7/25.0 71.3/75.5 80/80 71/75 260/263 75.1/79.3 80/80 76/79 264/267

12.0/16.0 33.4/38.5 86.0/92.3 90/100 85/91 271/277 89.8/96.1 90/100 89/95 275/281

18.6/24.8 51.7/59.7 108.8/118.8 110/125 106/115 290/298 112.6/122.6 125/125 110/119 294/302

24.0/32.0 66.7/77.0 127.6/140.5 150/150 123/135 305/315 131.4/144.3 150/150 127/139 309/319

31.8/42.4 88.4/102.0 154.7/171.7 175/175 148/164 415/442 158.5/175.5 175/200 152/168 419/446

--- --- 19.2 25 20 100 21.0 25 22 102

13.9 16.7 40.0 45 39 117 41.8 45 41 119

16.5 19.8 43.9 45 43 120 45.7 50 45 122

27.8 33.4 60.9 70 58 133 62.7 70 60 135

33.0 39.7 68.8 70 66 140 70.6 80 68 142

41.7 50.2 81.9 90 78 200 83.7 90 80 202

--- --- 20.0 25 21 119 21.8 25 23 121

13.9 16.7 40.8 45 40 136 42.6 45 42 138

16.5 19.8 44.7 45 44 139 46.5 50 46 141

27.8 33.4 61.7 70 59 152 63.5 70 61 154

33.0 39.7 69.6 70 67 159 71.4 80 69 161

41.7 50.2 82.7 90 79 219 84.5 90 81 221

--- --- 20.0 25 21 119 21.8 25 23 121

13.9 16.7 40.8 45 40 136 42.6 45 42 138

16.5 19.8 44.7 45 44 139 46.5 50 46 141

27.8 33.4 61.7 70 59 152 63.5 70 61 154

33.0 39.7 69.6 70 67 159 71.4 80 69 161

41.7 50.2 82.7 90 79 219 84.5 90 81 221

--- --- 15.4 20 16 85 19.2 25 20 89

17.0 20.4 40.9 45 40 105 44.7 45 44 109

34.0 40.9 66.5 70 63 126 70.3 80 68 130

--- --- 15.8 20 17 100 19.6 25 21 104

17.0 20.4 41.3 45 40 120 45.1 50 44 124

34.0 40.9 66.9 70 64 141 70.7 80 68 145

--- --- 15.8 20 17 100 19.6 25 21 104

17.0 20.4 41.3 45 40 120 45.1 50 44 124

34.0 40.9 66.9 70 64 141 70.7 80 68 145

FLA

MCA MOCP

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

Table 47 – MCA/MOCP DETERMINATION WITH PWRD C.O.

ELEC. HTR WITH PWRD C.O.

IFM

UNIT

548J*04

See Notes page 49.

TYPE

N O M . V --- P H --- H Z

D D --- S T D

208/230--- 1 --- 60

D D --- S T D

MED

208/230--- 3 --- 60

HIGH

D D --- S T D

MED

4 6 0 --- 3 --- 6 0

HIGH

D D --- S T D --- --- 7.1 15 7 7 9.5 15 9 9

MED --- --- 5.1 15 5 10 7.5 15 7 12

HIGH --- --- 4.6 15 5 14 7.0 15 7 16

5 7 5 --- 3 --- 6 0

WITHOUT P.E. WITH P.E.

Nom (kW)

--- --- 35.5 50 36 126 37.4 50 38 128

3.3/4.4 15.9/18.3 55.4/58.4 60/60 54/57 142/144 57.3/60.3 60/70 56/59 144/146

4.9/6.5 23.5/27.1 64.9/69.4 70/80 63/67 150/153 66.8/71.3 70/80 65/69 152/155

6.5/8.7 31.4/36.3 74.7/80.9 80/90 72/77 157/162 76.6/82.8 80/90 74/80 159/164

7.9/10.5 37.9/43.8 82.9/90.2 90/100 79/86 164/170 84.8/92.1 90/100 81/88 166/172

9.8/13.0 46.9/54.2 94.1/103.2 100/110 90/98 220/234 96.0/105.1 100/110 92/100 222/236

--- --- 29.6 40 30 102 31.5 40 32 104

3.3/4.4 9.2/10.6 41.1/42.9 50/50 41/42 111/113 43.0/44.8 50/50 43/45 113/115

4.9/6.5 13.6/15.6 46.6/49.1 50/50 46/48 116/118 48.5/51.0 50/60 48/50 118/120

6.5/8.7 18.1/20.9 52.2/55.7 60/60 51/54 120/123 54.1/57.6 60/60 53/56 122/125

7.9/10.5 21.9/25.3 57.0/61.2 60/70 55/59 124/127 58.9/63.1 60/70 58/62 126/129

12.0/16.0 33.4/38.5 71.4/77.7 80/80 69/75 135/141 73.3/79.6 80/80 71/77 137/143

--- --- 27.4 40 28 114 29.3 40 30 116

3.3/4.4 9.2/10.6 38.9/40.7 45/50 38/40 123/125 40.8/42.6 50/50 40/42 125/127

4.9/6.5 13.6/15.6 44.4/46.9 50/50 43/46 128/130 46.3/48.8 50/50 46/48 130/132

6.5/8.7 18.1/20.9 50.0/53.5 60/60 49/52 132/135 51.9/55.4 60/60 51/54 134/137

7.9/10.5 21.9/25.3 54.8/59.0 60/60 53/57 136/139 56.7/60.9 60/70 55/59 138/141

12.0/16.0 33.4/38.5 69.2/75.5 70/80 66/72 147/153 71.1/77.4 80/80 68/74 149/155

--- --- 27.4 40 28 125 29.3 40 30 127

3.3/4.4 9.2/10.6 38.9/40.7 45/50 38/40 134/136 40.8/42.6 50/50 40/42 136/138

4.9/6.5 13.6/15.6 44.4/46.9 50/50 43/46 139/141 46.3/48.8 50/50 46/48 141/143

6.5/8.7 18.1/20.9 50.0/53.5 60/60 49/52 143/146 51.9/55.4 60/60 51/54 145/148

7.9/10.5 21.9/25.3 54.8/59.0 60/60 53/57 147/150 56.7/60.9 60/70 55/59 149/152

12.0/16.0 33.4/38.5 69.2/75.5 70/80 66/72 158/164 71.1/77.4 80/80 68/74 160/166

--- --- 18.2 25 19 55 19.2 25 20 56

6.0 7.2 27.2 30 27 62 28.2 30 28 63

8.8 10.6 31.5 35 31 66 32.5 35 32 67

11.5 13.8 35.5 40 35 69 36.5 40 36 70

14.0 16.8 39.2 40 38 72 40.2 45 39 73

--- --- 12.8 15 13 56 13.8 20 14 57

6.0 7.2 21.8 25 21 63 22.8 25 22 64

8.8 10.6 26.1 30 25 67 27.1 30 26 68

11.5 13.8 30.1 35 29 70 31.1 35 30 71

14.0 16.8 33.8 35 32 73 34.8 35 33 74

--- --- 12.8 15 13 62 13.8 20 14 63

6.0 7.2 21.8 25 21 69 22.8 25 22 70

8.8 10.6 26.1 30 25 73 27.1 30 26 74

11.5 13.8 30.1 35 29 76 31.1 35 30 77

14.0 16.8 33.8 35 32 79 34.8 35 33 80

FLA

MCA MOCP

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

548J

Table 47– (cont.) MCA/MOCP DETERMINATION WITH PWRD C.O.

ELEC. HTR WITH PWRD C.O.

UNIT

548J

548J*05

See Notes page 49.

IFM

TYPE

N O M . V --- P H --- H Z

D D --- S T D

208/230--- 1 --- 60

D D --- S T D

MED

208/230--- 3 --- 60

HIGH

D D --- S T D

MED

4 6 0 --- 3 --- 6 0

HIGH

D D --- S T D --- --- 12.3 15 13 45 14.2 20 15 47

MED --- --- 10.7 15 11 48 12.6 15 13 50

HIGH --- --- 10.3 15 10 52 12.2 15 13 54

5 7 5 --- 3 --- 6 0

Nom (kW)

--- --- 41 60 41 133 42.9 60 43 135

3.3/4.4 15.9/18.3 60.8/63.8 70/80 59/62 149/151 62.7/65.7 80/80 61/64 151/153

6.5/8.7 31.4/36.3 80.2/86.3 90/90 77/83 164/169 82.1/88.2 90/100 79/85 166/171

9.8/13.0 46.9/54.2 99.6/108.7 100/110 95/103 227/241 101.5/110.6 110/125 97/105 229/243

13.1/17.4 62.8/72.5 119.5/131.6 125/150 113/124 259/278 121.4/133.5 125/150 115/126 261/280

15.8/21.0 75.8/87.5 135.7/150.3 150/175 128/141 285/308 137.6/152.2 150/175 130/144 287/310

--- --- 30.8 40 32 99 32.7 45 34 101

4.9/6.5 13.6/15.6 47.8/50.3 50/60 47/49 113/115 49.7/52.2 60/60 49/52 115/117

6.5/8.7 18.1/20.9 53.5/57.0 60/60 52/56 117/120 55.4/58.9 60/60 55/58 119/122

12.0/16.0 33.4/38.5 72.6/79.0 80/80 70/76 132/138 74.5/80.9 80/90 72/78 134/140

15.8/21.0 43.8/50.5 85.6/94.0 90/100 82/90 187/200 87.5/95.9 90/100 84/92 189/202

--- --- 28.6 40 29 111 30.5 40 31 113

4.9/6.5 13.6/15.6 45.6/48.1 50/50 45/47 125/127 47.5/50.0 50/60 47/49 127/129

6.5/8.7 18.1/20.9 51.3/54.8 60/60 50/53 129/132 53.2/56.7 60/60 52/55 131/134

12.0/16.0 33.4/38.5 70.4/76.8 80/80 67/73 144/150 72.3/78.7 80/80 70/75 146/152

15.8/21.0 43.8/50.5 83.4/91.8 90/100 79/87 199/212 85.3/93.7 90/100 82/89 201/214

--- --- 28.6 40 29 122 30.5 40 31 124

4.9/6.5 13.6/15.6 45.6/48.1 50/50 45/47 136/138 47.5/50.0 50/60 47/49 138/140

6.5/8.7 18.1/20.9 51.3/54.8 60/60 50/53 140/143 53.2/56.7 60/60 52/55 142/145

12.0/16.0 33.4/38.5 70.4/76.8 80/80 67/73 155/161 72.3/78.7 80/80 70/75 157/163

15.8/21.0 43.8/50.5 83.4/91.8 90/100 79/87 210/223 85.3/93.7 90/100 82/89 212/225

--- --- 18.7 25 19 53 19.7 25 20 54

6.0 7.2 27.7 30 28 60 28.7 30 29 61

11.5 13.8 36.0 40 35 67 37.0 40 36 68

14.0 16.8 39.7 40 39 70 40.7 45 40 71

23.0 27.7 53.3 60 51 108 54.3 60 52 109

--- --- 13.4 15 14 54 14.4 20 15 55

6.0 7.2 22.4 25 22 61 23.4 25 23 62

11.5 13.8 30.6 35 29 68 31.6 35 31 69

14.0 16.8 34.4 35 33 71 35.4 40 34 72

23.0 27.7 48.0 50 45 109 49.0 50 47 110

--- --- 13.4 15 14 60 14.4 20 15 61

6.0 7.2 22.4 25 22 67 23.4 25 23 68

11.5 13.8 30.6 35 29 74 31.6 35 31 75

14.0 16.8 34.4 35 33 77 35.4 40 34 78

23.0 27.7 48.0 50 45 115 49.0 50 47 116

FLA

MCA MOCP

WITHOUT P.E. WITH P.E.

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

Table 47 – (cont.) MCA/MOCP DETERMINATION WITH PWRD C.O.

ELEC. HTR WITH PWRD C.O.

IFM

UNIT

548J*06

See Notes page 49.

TYPE

N O M . V --- P H --- H Z

D D --- S T D

208/230--- 1 --- 60

D D --- S T D

MED

208/230--- 3 --- 60

HIGH

D D --- S T D

MED

4 6 0 --- 3 --- 6 0

HIGH

D D --- S T D --- --- 13.6 15 14 47 15.5 20 16 49

MED --- --- 11.6 15 12 54 13.5 15 14 56

HIGH --- --- 12.4 15 13 65 14.3 20 15 67

5 7 5 --- 3 --- 6 0

WITHOUT P.E. WITH P.E.

Nom (kW)

--- --- 46.5 60 46 150 48.4 60 48 152

4.9/6.5 23.5/27.1 75.8/80.3 80/90 73/77 174/177 77.7/82.2 80/100 75/79 176/179

6.5/8.7 31.4/36.3 85.7/91.8 100/100 82/88 181/186 87.6/93.7 100/100 84/90 183/188

9.8/13.0 46.9/54.2 105.1/114.2 110/125 100/108 244/258 107.0/116.1 110/125 102/110 246/260

13.1/17.4 62.8/72.5 125.0/137.1 125/150 118/129 276/295 126.9/139.0 150/150 120/131 278/297

15.8/21.0 75.8/87.5 141.2/155.8 150/175 133/147 302/325 143.1/157.7 150/175 135/149 304/327

--- --- 33.2 45 34 126 35.1 50 36 128

4.9/6.5 13.6/15.6 50.2/52.7 60/60 49/52 140/142 52.1/54.6 60/60 52/54 142/144

7.9/10.5 21.9/25.3 60.6/64.8 70/70 59/63 148/151 62.5/66.7 70/70 61/65 150/153

12.0/16.0 33.4/38.5 75.0/81.3 80/90 72/78 159/165 76.9/83.2 80/90 74/80 161/167

15.8/21.0 43.8/50.5 88.0/96.3 90/100 84/92 214/227 89.9/98.2 90/100 86/94 216/229

19.9/26.5 55.2/63.8 102.2/113.0 110/125 97/107 236/254 104.1/114.9 110/125 99/109 238/256

--- --- 31 45 31 149 32.9 45 33 151

4.9/6.5 13.6/15.6 48.0/50.5 60/60 47/49 163/165 49.9/52.4 60/60 49/51 165/167

7.9/10.5 21.9/25.3 58.4/62.6 60/70 56/60 171/174 60.3/64.5 70/70 59/62 173/176

12.0/16.0 33.4/38.5 72.8/79.1 80/80 70/75 182/188 74.7/81.0 80/90 72/78 184/190

15.8/21.0 43.8/50.5 85.8/94.1 90/100 82/89 237/250 87.7/96.0 90/100 84/91 239/252

19.9/26.5 55.2/63.8 100.0/110.8 100/125 95/105 259/277 101.9/112.7 110/125 97/107 261/279

--- --- 33.3 45 34 175 35.2 50 36 177

4.9/6.5 13.6/15.6 50.3/52.8 60/60 49/52 189/191 52.2/54.7 60/60 52/54 191/193

7.9/10.5 21.9/25.3 60.7/64.9 70/70 59/63 197/200 62.6/66.8 70/70 61/65 199/202

12.0/16.0 33.4/38.5 75.1/81.4 80/90 72/78 208/214 77.0/83.3 80/90 74/80 210/216

15.8/21.0 43.8/50.5 88.1/96.4 90/100 84/92 263/276 90.0/98.3 90/100 86/94 265/278

19.9/26.5 55.2/63.8 102.3/113.1 110/125 97/107 285/303 104.2/115.0 110/125 99/109 287/305

--- --- 20.2 25 21 64 21.2 25 22 65

6.0 7.2 29.2 30 29 71 30.2 35 30 72

11.5 13.8 37.5 40 37 78 38.5 40 38 79

14.0 16.8 41.2 45 40 81 42.2 45 42 82

23.0 27.7 54.9 60 53 119 55.9 60 54 120

25.5 30.7 58.6 60 56 125 59.6 60 58 126

--- --- 15.2 20 15 71 16.2 20 16 72

6.0 7.2 24.2 30 24 78 25.2 30 25 79

11.5 13.8 32.5 35 31 85 33.5 35 32 86

14.0 16.8 36.2 40 35 88 37.2 40 36 89

23.0 27.7 49.9 50 47 126 50.9 60 48 127

25.5 30.7 53.6 60 51 132 54.6 60 52 133

--- --- 16 20 16 84 17.0 20 17 85

6.0 7.2 25.0 30 24 91 26.0 30 26 92

11.5 13.8 33.3 35 32 98 34.3 35 33 99

14.0 16.8 37.0 40 36 101 38.0 40 37 102

23.0 27.7 50.7 60 48 139 51.7 60 49 140

25.5 30.7 54.4 60 52 145 55.4 60 53 146

FLA

MCA MOCP

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

548J

Table 47 – (cont.) MCA/MOCP DETERMINATION WITH PWRD C.O.

ELECTRIC HEATER WITH PWRD C.O.

UNIT

548J

548J*07

See Notes page 49.

IFM

TYPE

N O M . V --- P H --- H Z

STD

MED

208/230--- 3 --- 60

HIGH

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

STD --- --- 14.0 20 14 61 15.9 20 16 63

MED --- --- 14.4 20 14 76 16.3 20 17 78

HIGH --- --- 14.4 20 14 76 16.3 20 17 78

5 7 5 --- 3 --- 6 0

Nom (kW)

--- --- 35.3 50 35 151 37.2 50 37 153

4.9/6.5 13.6/15.6 52.3/54.8 60/60 51/53 165/167 54.2/56.7 60/60 53/55 167/169

7.9/10.5 21.9/25.3 62.6/66.9 70/70 60/64 173/176 64.5/68.8 70/80 62/66 175/178

12.0/16.0 33.4/38.5 77.0/83.4 80/90 73/79 184/190 78.9/85.3 80/90 76/82 186/192

15.8/21.0 43.8/50.5 90.0/98.4 90/100 85/93 239/252 91.9/100.3 100/110 88/95 241/254

19.9/26.5 55.2/63.8 104.3/115.0 110/125 99/108 261/279 106.2/116.9 110/125 101/111 263/281

--- --- 37.6 50 38 188 39.5 50 40 190

4.9/6.5 13.6/15.6 54.6/57.1 60/60 53/56 202/204 56.5/59.0 60/60 56/58 204/206

7.9/10.5 21.9/25.3 64.9/69.2 70/80 63/67 210/213 66.8/71.1 80/80 65/69 212/215

12.0/16.0 33.4/38.5 79.3/85.7 80/90 76/82 221/227 81.2/87.6 90/90 78/84 223/229

15.8/21.0 43.8/50.5 92.3/100.7 100/110 88/96 276/289 94.2/102.6 100/110 90/98 278/291

19.9/26.5 55.2/63.8 106.6/117.3 110/125 101/111 298/316 108.5/119.2 110/125 103/113 300/318

--- --- 37.6 50 38 188 39.5 50 40 190

4.9/6.5 13.6/15.6 54.6/57.1 60/60 53/56 202/204 56.5/59.0 60/60 56/58 204/206

7.9/10.5 21.9/25.3 64.9/69.2 70/80 63/67 210/213 66.8/71.1 80/80 65/69 212/215

12.0/16.0 33.4/38.5 79.3/85.7 80/90 76/82 221/227 81.2/87.6 90/90 78/84 223/229

15.8/21.0 43.8/50.5 92.3/100.7 100/110 88/96 276/289 94.2/102.6 100/110 90/98 278/291

19.9/26.5 55.2/63.8 106.6/117.3 110/125 101/111 298/316 108.5/119.2 110/125 103/113 300/318

--- --- 17.7 25 18 75 18.7 25 19 76

6.0 7.2 26.7 30 26 82 27.7 30 27 83

11.5 13.8 35.0 40 33 89 36.0 40 35 90

14.0 16.8 38.7 40 37 92 39.7 45 38 93

23.0 27.7 52.4 60 49 130 53.4 60 51 131

25.5 30.7 56.1 60 53 136 57.1 60 54 137

--- --- 18.5 25 19 94 19.5 25 20 95

6.0 7.2 27.5 30 27 101 28.5 30 28 102

11.5 13.8 35.8 40 34 108 36.8 40 36 109

14.0 16.8 39.5 45 38 111 40.5 45 39 112

23.0 27.7 53.2 60 50 149 54.2 60 52 150

25.5 30.7 56.9 60 54 155 57.9 60 55 156

--- --- 18.5 25 19 94 19.5 25 20 95

6.0 7.2 27.5 30 27 101 28.5 30 28 102

11.5 13.8 35.8 40 34 108 36.8 40 36 109

14.0 16.8 39.5 45 38 111 40.5 45 39 112

23.0 27.7 53.2 60 50 149 54.2 60 52 150

25.5 30.7 56.9 60 54 155 57.9 60 55 156

FLA

MCA MOCP

WITHOUT P.E. WITH P.E.

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

Table 47 – (cont.) MCA/MOCP DETERMINATION WITH PWRD C.O.

ELECTRIC HEATER WITH PWRD C.O.

IFM

UNIT

548J*08

See Notes page 49.

TYPE

N O M . V --- P H --- H Z

STD

MED

208/230--- 3 --- 60

HIGH

STD

MED

4 6 0 --- 3 --- 6 0

HIGH

STD

MED

5 7 5 --- 3 --- 6 0

HIGH

WITHOUT P.E. WITH P.E.

Nom (kW)

--- --- 42.5 50 45 198 46.3 50 49 202

7.8/10.4 21.7/25.0 69.6/73.7 70/80 70/74 220/223 73.4/77.5 80/80 74/78 224/227

12.0/16.0 33.4/38.5 84.2/90.6 90/100 83/89 231/237 88.0/94.4 90/100 88/94 235/241

18.6/24.8 51.7/59.7 107.1/117.1 110/125 105/114 250/258 110.9/120.9 125/125 109/118 254/262

24.0/32.0 66.7/77.0 125.9/138.7 150/150 122/134 265/275 129.7/142.5 150/150 126/138 269/279

31.8/42.4 88.4/102.0 153.0/170.0 175/175 147/162 375/402 156.8/173.8 175/175 151/167 379/406

--- --- 44.8 50 48 235 48.6 60 52 239

7.8/10.4 21.7/25.0 71.9/76.0 80/80 73/76 257/260 75.7/79.8 80/80 77/81 261/264

12.0/16.0 33.4/38.5 86.5/92.9 90/100 86/92 268/274 90.3/96.7 100/100 91/96 272/278

18.6/24.8 51.7/59.7 109.4/119.4 110/125 107/116 287/295 113.2/123.2 125/125 112/121 291/299

24.0/32.0 66.7/77.0 128.2/141.0 150/150 124/136 302/312 132.0/144.8 150/150 129/141 306/316

31.8/42.4 88.4/102.0 155.3/172.3 175/175 149/165 412/439 159.1/176.1 175/200 154/169 416/443

--- --- 44.8 50 48 235 48.6 60 52 239

7.8/10.4 21.7/25.0 71.9/76.0 80/80 73/76 257/260 75.7/79.8 80/80 77/81 261/264

12.0/16.0 33.4/38.5 86.5/92.9 90/100 86/92 268/274 90.3/96.7 100/100 91/96 272/278

18.6/24.8 51.7/59.7 109.4/119.4 110/125 107/116 287/295 113.2/123.2 125/125 112/121 291/299

24.0/32.0 66.7/77.0 128.2/141.0 150/150 124/136 302/312 132.0/144.8 150/150 129/141 306/316

31.8/42.4 88.4/102.0 155.3/172.3 175/175 149/165 412/439 159.1/176.1 175/200 154/169 416/443

--- --- 20.1 25 21 97 21.9 25 23 99

13.9 16.7 41.0 45 41 114 42.8 45 43 116

16.5 19.8 44.9 45 44 117 46.7 50 46 119

27.8 33.4 61.9 70 60 130 63.7 70 62 132

33.0 39.7 69.8 70 67 137 71.6 80 69 139

41.7 50.2 82.9 90 79 197 84.7 90 81 199

--- --- 20.9 25 22 116 22.7 25 24 118

13.9 16.7 41.8 45 42 133 43.6 45 44 135

16.5 19.8 45.7 50 45 136 47.5 50 47 138

27.8 33.4 62.7 70 61 149 64.5 70 63 151

33.0 39.7 70.6 80 68 156 72.4 80 70 158

41.7 50.2 83.7 90 80 216 85.5 90 82 218

--- --- 20.9 25 22 116 22.7 25 24 118

13.9 16.7 41.8 45 42 133 43.6 45 44 135

16.5 19.8 45.7 50 45 136 47.5 50 47 138

27.8 33.4 62.7 70 61 149 64.5 70 63 151

33.0 39.7 70.6 80 68 156 72.4 80 70 158

41.7 50.2 83.7 90 80 216 85.5 90 82 218

--- --- 15.2 20 16 79 19.0 25 21 83

17.0 20.4 40.7 45 40 99 44.5 45 44 103

34.0 40.9 66.3 70 63 120 70.1 80 68 124

--- --- 15.6 20 17 94 19.4 25 21 98

17.0 20.4 41.1 45 40 114 44.9 45 45 118

34.0 40.9 66.7 70 64 135 70.5 80 68 139

--- --- 15.6 20 17 94 19.4 25 21 98

17.0 20.4 41.1 45 40 114 44.9 45 45 118

34.0 40.9 66.7 70 64 135 70.5 80 68 139

FLA

MCA MOCP

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

548J

Table 47 – (cont.) MCA/MOCP DETERMINATION WITH PWRD C.O.

ELECTRIC HEATER WITH PWRD C.O.

UNIT

548J

548J*09

See Notes page 49.

N O M . V --- P H --- H Z

208/230--- 3 --- 60

4 6 0 --- 3 --- 6 0

5 7 5 --- 3 --- 6 0

IFM

TYPE

STD

MED

HIGH

STD

MED

HIGH

STD

MED

HIGH

WITHOUT P.E. WITH P.E.

Nom (kW)

--- --- 46.7 60 49 206 50.5 60 53 210

7.8/10.4 21.7/25.0 73.8/78.0 80/80 74/78 228/231 77.6/81.8 80/90 78/82 232/235

12.0/16.0 33.4/38.5 88.5/94.8 90/100 88/93 239/245 92.3/98.6 100/100 92/98 243/249

18.6/24.8 51.7/59.7 111.3/121.3 125/125 109/118 258/266 115.1/125.1 125/150 113/122 262/270

24.0/32.0 66.7/77.0 130.1/143.0 150/150 126/138 273/283 133.9/146.8 150/150 130/142 277/287

31.8/42.4 88.4/102.0 157.2/174.2 175/175 151/166 383/410 161.0/178.0 175/200 155/171 387/414

--- --- 49.0 60 52 243 52.8 60 56 247

7.8/10.4 21.7/25.0 76.1/80.3 80/90 77/81 265/268 79.9/84.1 80/90 81/85 269/272

12.0/16.0 33.4/38.5 90.8/97.1 100/100 90/96 276/282 94.6/100.9 100/110 95/100 280/286

18.6/24.8 51.7/59.7 113.6/123.6 125/125 111/120 295/303 117.4/127.4 125/150 116/125 299/307

24.0/32.0 66.7/77.0 132.4/145.3 150/150 128/140 310/320 136.2/149.1 150/150 133/145 314/324

31.8/42.4 88.4/102.0 159.5/176.5 175/200 153/169 420/447 163.3/180.3 175/200 158/173 424/451

--- --- 49.0 60 52 243 52.8 60 56 247

7.8/10.4 21.7/25.0 76.1/80.3 80/90 77/81 265/268 79.9/84.1 80/90 81/85 269/272

12.0/16.0 33.4/38.5 90.8/97.1 100/100 90/96 276/282 94.6/100.9 100/110 95/100 280/286

18.6/24.8 51.7/59.7 113.6/123.6 125/125 111/120 295/303 117.4/127.4 125/150 116/125 299/307

24.0/32.0 66.7/77.0 132.4/145.3 150/150 128/140 310/320 136.2/149.1 150/150 133/145 314/324

31.8/42.4 88.4/102.0 159.5/176.5 175/200 153/169 420/447 163.3/180.3 175/200 158/173 424/451

--- --- 21.4 25 23 102 23.2 30 25 104

13.9 16.7 42.2 45 42 119 44.0 45 44 121

16.5 19.8 46.1 50 45 122 47.9 50 47 124

27.8 33.4 63.1 70 61 135 64.9 70 63 137

33.0 39.7 71.0 80 68 142 72.8 80 70 144

41.7 50.2 84.1 90 80 202 85.9 90 82 204

--- --- 22.2 25 23 121 24.0 30 26 123

13.9 16.7 43.0 45 43 138 44.8 45 45 140

16.5 19.8 46.9 50 46 141 48.7 50 48 143

27.8 33.4 63.9 70 62 154 65.7 70 64 156

33.0 39.7 71.8 80 69 161 73.6 80 71 163

41.7 50.2 84.9 90 81 221 86.7 90 83 223

--- --- 22.2 25 23 121 24.0 30 26 123

13.9 16.7 43.0 45 43 138 44.8 45 45 140

16.5 19.8 46.9 50 46 141 48.7 50 48 143

27.8 33.4 63.9 70 62 154 65.7 70 64 156

33.0 39.7 71.8 80 69 161 73.6 80 71 163

41.7 50.2 84.9 90 81 221 86.7 90 83 223

--- --- 17.1 20 18 87 20.9 25 22 91

17.0 20.4 42.6 45 42 107 46.4 50 46 111

34.0 40.9 68.2 70 65 128 72.0 80 69 132

--- --- 17.5 20 19 102 21.3 25 23 106

17.0 20.4 43.0 45 42 122 46.8 50 46 126

34.0 40.9 68.6 70 66 143 72.4 80 70 147

--- --- 17.5 20 19 102 21.3 25 23 106

17.0 20.4 43.0 45 42 122 46.8 50 46 126

34.0 40.9 68.6 70 66 143 72.4 80 70 147

FLA

MCA MOCP

DISC. SIZE

MCA MOCP

FLA LRA FLA LRA

DISC. SIZE

TYPICAL WIRING DIAGRAMS

548J

C09063

Fig. 17 -- 1--Stage Cooling Typical Power Diagram

548J

C09065

Fig. 18 -- 2--Stage Cooling Typical Power Diagram

Fig. 19 -- Multi--Protocol Option Diagram

548J

C09067

548J

C09062

Fig. 20 -- 1--Stage Typical Wiring Diagram

C09064

548J

Fig. 21 -- 2--Stage Typical Wiring Diagram

SEQUENCE OF OPERATION

Cooling, unit without economizer

When thermostat calls for cooling, terminals G and Y1 are energized. The indoor-fan contactor (IFC), reversing valve solenoid (RVS) and compressor contactor are energized and indoor-fan motor, compressor, and outdoor fan starts. The outdoor fan motor runs continuously while unit is cooling.

Heating, unit without economizer

Upon a request for heating from the space thermostat, terminal W1 will be energized with 24V. The IFC, outdoor-fan contactor (OFC), C1, and C2 will be energized. The indoor fan, outdoor fans, and compressor no. 1, and compressor no. 2 are energized and reversing valves are deenergized and switch position.

548J

If the space temperature continues to fall while W1 is energized, W2 will be energized with 24V, and the heater contactor(s) (HC) will be energized, which will energize the electric heater(s).

When the space thermostat is satisfied, W2 will be deenergized first, and the electric heater(s) will be deenergized.

Upon a further rise in space temperature, W1 will be deenergized.

Cooling, unit with EconoMi$er IV

When free cooling is not available, the compressors will be controlled by the zone thermostat. When free cooling is available, the outdoor-air damper is modulated by the EconoMi$er IV control to provide a 50 to 55_F(10_ to 13_C) mixed-air temperature into the zone. As the mixed-air temperature fluc tuates a bove 55 or below 50_F (13_ to 10_C), the dampers will be modulated (open or close) to bring the mixed-air temperature back within control.

If mechanical cooling is utilized with free cooling, the outdoor-air damper will maintain its current position at the time the compressor is started. If the increase in cooling capacity causes the mixed-air temperature to drop below 45_F(7_C), then the outdoor-air damper position will be decreased to the minimum position. If the mixed-air temperature continues to fall, the outdoor-air damper will close. Control returns to normal once the mixed-air temperature rises above 48_F(9_C).

If optional power exhaust is installed, as the outdoor-air damper opens and closes, the power exhaust fans will be energized and deenergized.

If field-installed accessory CO the EconoMi$er IV control, a demand controlled ventilation strategy will begin to operate. As the CO level in the zone increases above the CO2setpoint, the minimum position of the damper will be increased proportionally. As the CO increase in fresh air, the outdoor-air damper will be proportionally closed.

sensors are connected to

level decreases because of the

For EconoMi$er IV operation, there must be a thermostat call for the fan (G). If the unit is occupied and the fan is on, the damper will operate at minimum position. Otherwise, the damper will be closed.

When the EconoMi$er IV control is in the occupied mode and a call for cooling exists (Y1 on the t hermostat), the control will first check for indoor fan operation. If the fan is not on, then cooling will not be activated. If the fan is on, then the control will open the Ec onoMi$er IV damper to the minimum position.

On the initial power to the EconoMi$er IV control, it will

take the damper up to 2

/2minutes before it begins to position itself. Any change in damper position will take up to 30 seconds to initiate. Damper movement from full closed to full open (or vice versa) will take between 1 and 21/2minutes.

If free cooling can be used as det ermined from the appropriate changeover command (switch, dry bulb, enthalpy curve, differential dry bulb, or differential enthalpy), then the control will modulate the dampers open to maintain the mixed-air temperature setpoint at 50_ to 55_F(10_ to 13_C).

If there is a further demand for cooling (cooling second stage — Y2 is energized), then the control will bring on compressor stage 1 to maintain the mixed-air temperature setpoint. The EconoMi$er IV damper will be open at maximum position. EconoMi$er IV operation is limited to a single compressor.

Heating, unit with EconoMi$er

When the room temperature calls for heat through terminal W1, the indoor (evaporator) fan contactor (IFC) and heater contactor no. 1 (HC1) are energized and the reversing va lve(s) deenergize and switches position. On units equipped for 2 stages of heat, when additional heat is needed, heater contactor no. 2 is energized through W2. The economizer damper moves to the minimum position. When the thermostat is satisfied, the damper moves to the fully closed position.

Defrost

When the tem perature of the outdoor coil drops below 28_F(--2_C) as sensed by the defrost thermostat (DFT2) and the defrost timer is at the end of a timed period (adjustable at 30, 60, 90 or 120 minutes), reversing valve solenoids (RVS1 and RVS2) are energized and the OFC is deenergized. This switches the position of the reversing valves and shuts off the outdoor fan. The electric heaters (if installed) will be energized.

The unit continues to defrost until the coil temperature as measured by DFT2 reaches 65_F(18_C), or the duration

of defrost c ycle completes a 10-minute period.

During the Defrost mode, if circuit 1 defrosts first, RVS1 will oscillate between Heating and Cooling modes until the Defrost mode is complete.

At the end of the defrost cycle, the electric heaters (if installed) will be deenergized; the reversing valves switch and the outdoor-fan motor will be energized. The unit will now operate in the Heating mode.

If the space thermostat is satisfied during a defrost cycle, the unit will continue in the Defrost mode until the time or temperature constraints are satisfied.

Automatic changeover

When the system selection switch is set at AUTO. position, unit automatically changes from heating operation to cooling operation when the temperature of the c onditioned space rises to the cooling level setting. When the temperature of the conditioned space falls to the heating level setting, unit automatically changes from cooling to heating operation (with a 3°F deadband in between).

Continuous air circulation

Turn unit power on. Set system control at OFF position. Set fan switch at ON position. The indoor-fan contactor is energized through the thermostat switch and the indoor fan runs continuously.

Cycle-LOC™ protection

If unit operati on is interrupted by an open high-pressure switch, low-pressure switch, indoor coil freeze stat, or by compressor internal line-break device (overcurrent or overtemperature), and compressor is calling for either cooling or heating, Cycle-LOC protection device simultaneously locks out uni t and lights a warning light on the thermostat. Restart the unit by manually turning thermostat to OFF and then to ON position. If any of the protective devices opens again, the unit continues to lock out until corrective action is taken.

NOTE: If the unit fails to operate due to compressor over-current condition, restart by manually resetting circuit breakers at the unit. Restart cannot be accomplished at the room thermostat.

Emergency heat

548J

If compressor is inoperative due to a tripped safety device (high or low pressure, indoor coil freeze stat, overcurrent, or overtemperature), the Cycle-LOC device locks out the compressor and lights a warning light on the room thermostat. When the switch is on (thermostat is set to the EM HT position), compressor circuit and outdoor thermostats are bypassed, and the second stage of thermostat energizes the indoor blower and the electric resistance heaters.

GUIDE SPECIFICATIONS -- 548J*04--09

Note about this specificati on:

Bryant created this specification in “Masterformat” as published by the Construction Specification Institute. Please feel free to copy this specifi cation directly into your building specifications.

Rooftop Packaged Heat Pump

HVAC Guide Specifications

Size Range: 3 to 8.5 Nominal T ons

This product has been design ed and m anufactured to meet En ergy St ar® criteria for energy effici ency.

548J

However, proper ref rigerant charge an d proper air flow are critical to achieve rated capacity and efficiency. Installation of this product should follow all manufacturer’s refrigerant charging and air flow instructions. Failure to con firm proper charge an d

air flow may reduc e energy effic iency and shorten equipment lif e.

Section Description

23 06 80 Schedules for Decentralized HVAC Equipment

23 06 80.13 Decentralized Unitary HVAC Equipment Schedule 23 06 80.13.A. Rooftop unit schedule

1. Schedule is per the project specification requirements.

23 07 16 HVAC Equipment Insulation

23 07 16.13 Decentralized, Rooftop Units: 23 07 16.13.A. Evaporator fan compartm ent:

1. Interior cabinet surfaces shall be insulated with a minimum 1/2 --in. thick, minimum 1 1/2 lb density, flexible fiberglass insulation bonded with a phenolic binder, neoprene coated on the air side.

2. Insulation and adhesive shall meet NFPA 90A requirements for flame spread and smoke generation.

23 07 16.13.B. Electric heat compartment:

1. Aluminum foil --faced fiberglass insulation shall be used.

2. Insulation and adhesive shall meet NFPA 90A requirements for flame spread and smoke generation.

23 09 13 Instrumentation and Control Devices for HVAC

23 09 13.23 Sensors and Transmitters 23 09 13.23.A. Thermostats

1. Thermostat must

a. have capability to energize 2 different stages of cooling, and 2 different stages of heating.

b. include capability for occupancy scheduling.

23 09 23 Direct--digital Control system for HVAC

23 09 23.13 Decentralized, Rooftop Units: 23 09 23.13.A. N/A 23 09 23.13.B. Multi--protocol, direct digital controller:

1. Shall be ASHRAE 62--2001 compliant.

2. Shall accept 18--30VAC, 50--60Hz, and consumer 15VA or less power.

3. Shall have an operating temperature range from --40_F(--40_C) to 130_F(54_C), 10% -- 90% RH (non--condens- ing).

4. Shall include built--in protocol for BACNET (MS/TP and PTP modes), Modbus (RTU and ASCII), Johnson N2 and LonWorks. LonWorks Echelon processor required for all Lon applications shall be contained in separate communication board.

5. Shall allow access of up to 62 network variables (SNVT). Shall be compatible with all open controllers

6. Baud rate Controller shall be selectable using a dipswitch.

7. Shall have an LED display independent ly showing t he stat us of serial communication, running, errors, power, all digital outputs, and all analog inputs.

8. Shall accept the following inputs: space temperature, setpoint adjustment, outdoor air temperature, indoor air quality, outdoor air quality, compressor lock--out, fire shutdown, enthalpy switch, and fan status/filter status/humidity/remote occupancy.

9. Shall provide the following outputs: economizer, fan, cooling stage 1, cooling stage 2, heat stage 1, heat stage 2, heat stage 3/ exhaust/ reversing valve.

10. Shall have built--in surge protection circuitry through solid state polyswitche s. Polyswitches shall be used on incoming power and network connections. Polyswitches will return to normal when the “trip” condition clears.

11. Shall have a battery back--up capable of a minimum of 10,000 hours of data and time clock retention during power outages.

12. Shall have built--in support for Bryant technician tool.

13. Shall include an EIA--485 protocol communication port, an access port for connection of either a computer or a Bryant technician tool, an EIA--485 port for network communication to intelligent space sensors and displays, and a port to connect an optional LonWorks communications card.

14. Software upgrades will be accomplished by either local or remote download. No software upgrades through chip replacements are allowed.

23 09 33 Electric and Electronic Control System for HVAC

23 09 33.13 Decentralized, Rooftop Units: 23 09 33.13.A. General:

1. Shall be complete with self--contained low--voltage control circuit protected by a resettable circuit breaker on the 24-- v transformer side. Transformer shall have 75VA capability.

2. Shall utilize color--coded wiring.

3. Shall include a central control terminal board to conveniently and safely provide connection points for vital control functions such as: smoke detectors, phase monitor, economizer, thermostat, DDC control options, loss of charge, freeze switch, high pressure switches.

4. Unit shall include a minimum of one 8--pin screw terminal connection board for connection of control wiring.

5. Shall include integrated defrost system to prevent excessive frost accumulation during heating duty, and shall be controlled as follows:

a. Defrost shall be initiated on the basis of time and coil temperature. b. A 30,60,90,120 minute timer shall activate the defrost cycle only if the coil temperature is low enough to indic-

ate a heavy frost condition.

c. Defrost cycle shall terminate when defrost thermostat are satisfied and shall have a positive termination time of

10 minutes.

6. Defrost system shall also include:

a. Defrost Cycle Indicator LED. b. Dip switch selectable defrost time between 30,60,90 and 120 minutes. Factory set at 30 minutes. c. Molded plug connection to insure proper connection.

23 09 33.23.B. Safeties:

1. Compressor over--temperature, over current.

2. Loss of charge switch.

a. Units with 2 compressors shall have different sized connectors for the circuit 1 and circuit 2 low and high pres-

sure switches. They shall physically prevent the cross--wiring of the safety switches between circuits 1 and 2.

b. Loss of charge switch shall use different color wire than the high pressure switch. The purpose is to assist the

installer and service technician to correctly wire and or troubleshoot the rooftop unit.

3. High--pressure switch.

a. Units with 2 compressors shall have different sized connectors for the circuit 1 and circuit 2 low and high pres-

sure switches. They shall physically prevent the cross--wiring of the safety switches between circuits 1 and 2.

b. High pressure switch shall use different color wire than the low pressure switch. The purpose is to assist the

installer and service technician to correctly wire and or troubleshoot the rooftop unit.

4. Freeze protection thermostat, evaporator coil.

5. Automatic reset, motor thermal overload protector.

23 09 93 Sequence of Operations for HVAC Controls

23 09 93.13 Decentralized, Rooftop Units: 23 09 93.13 INSERT SEQUENCE OF OPERATION

548J

23 40 13 Panel Air Filters

23 40 13.13 Decentralized, Rooftop Units: 23 40 13.13.A. Standard filter section

1. Shall consist of factory--installed, low velocity, throwaway 2 --in. thick fiberglass filters of commercially available sizes.

2. Unit shall use only one filter size. Multiple sizes are not acceptable.

3. Filters shall be accessible through an access panel with “no--tool” removal as described in the unit cabinet section of this specification (23 81 19.13.H).

23 81 19 Self--Contained Air Conditioners

23 81 19.13 Small--Capacity Self--Contained Air Conditioners (548J*04--09) 23 81 19.13.A. General

1. Outdoor, rooftop mounted, electrically controlled, heating and cooling unit utilizing a(n) hermetic scroll compressor(s) for cooling duty and heat pump for heating duty.

2. Factory assembled, single--piece heating and cooling rooftop unit. Contained within the unit enclosure shall be all factory wiring, piping, controls, and special features require d prior to fi eld start--up.

548J

3. Unit shall use environmentally safe, Puron refrigerant.

4. Unit shall be installed in accordance with the manufacturer’s instructions.

5. Unit must be selected and installed in compliance with local, state, and federal codes.

23 81 19.13.B. Quality Assurance

1. Unit meets ASHRAE 90.1--2004 minimum efficiency requirements.

2. 3--phase units are Energy Star qualified.

3. Unit shall be rated in accordance with AHRI Standards 210/240 and 340/360.

4. Unit shall be designed to conform to ASHRAE 15, 2001.

5. Unit shall be UL--tested and certified in accordance with ANSI Z21.47 Standards and UL--listed and certified under Canadian standards as a total package for safety requirements.

6. Insulation and adhesive shall meet NFPA 90A requirements for flame spread and smoke generation.

7. Unit casing shall be capable of withstanding 500--hour salt spray exposure per ASTM B117 (scribed specimen).

8. Unit casing shall be capable of withstanding Federal Test Method Standard No. 141 (Method 6061) 5000--hour salt spray.

9. Unit shall be designed in accordance with ISO 9001:2000, and shall be manufactured in a facility registered by ISO 9001:2000.

10. Roof curb shall be designed to conform to NRCA Standards.

11. Unit shall be subjected to a completely automated run test on the assembly line. The data for each unit will be stored at the factory, and must be available upon request.

12. Unit shall be designed in accordance with UL Standard 1995, including tested to withstand rain.

13. Unit shall be constructed to prevent intrusion of snow and tested to prevent snow intrusion into the control box up to 40 mph.

14. Unit shake tested to assurance level 1, ASTM D4169 to ensure shipping reliability.

23 81 19.13.C. Delivery, Storage, and Handling

1. Unit shall be stored and handled per manufacturer’s recommendations.

2. Lifted by crane requires either shipping top panel or spreader bars.

3. Unit shall only be stored or positioned in the upright position.

23 81 19.13.D. Project Conditions

1. As specified in the contract.

23 81 19.13.E. Project Conditions

1. As specified in the contract.

23 81 19.13.F. Operating Characteristics

1. Unit shall be capable of starting and running at 115_F(46_C) ambient outdoor temperat ure, meeting maximum load criteria of AHRI Standard 210/240 or 340/360 at ± 10% voltage.

2. Compressor with standard controls shall be capable of operation from 25_F(--4_C), ambient outdoor temperat- ures. Accessory winter start kit is necessary if mechanically cooling at ambient temperatures below 25_F(--4_C).

3. Unit shall be capable of simultaneous heating duty and defrost cycle operation when using accessory electric heaters.

4. Unit shall discharge supply air vertically or horizontally as shown on contrac t drawings.

5. Unit shall be factory configured for vertical supply & return configurations.

6. Unit shall be field convertible from vertical to horizontal configuration

7. Unit shall be capable of mixed operation: vertical supply with horizontal return or horizontal supply with vertical return.

23 81 19.13.G. Electrical Requirements

1. Main power supply voltage, phase, and frequency must match those required by the manufacturer.

23 81 19.13.H. Unit Cabinet

1. Unit cabinet shall be constructed of galvanized steel, and shall be bonderized and coated with a pre--painted baked enamel finish on all externally exposed surfaces.

2. Unit cabinet exterior paint shall be: film thickness, (dry) 0.003 inches minimum, gloss (per ASTM D523, 60_F): 60, Hardness: H--2H Pencil hardness.

3. Evaporator fan compa rtment interior cabinet insulation shall conform to AHRI Standards 210/240 or 340/360 minimum exterior sweat criteria. Interior surfaces shall be insulated with a minimum 1/2 --in. thick, 1 lb density, flexible fiberglass insulation, neoprene coated on the air side. Aluminum foil--faced fiberglass insulation shall be used in the heat compartment.

4. Base of unit shall have a minim um of three locations for thru--the--base electrical connections (factory installed or field installed), standard.

5. Base Rail

a. Unit shall have base rails on a minimum of 2 sides. b. Holes shall be provided in the base rails for rigging shackles to facilitate maneuvering and overhead rigging. c. Holes shall be provided in the base rail for moving the rooftop by fork truck. d. Base rail shall be a minimum of 16 gauge thickness.

6. Condensate pan and connections:

a. Shall be a sloped condensate drain pa n made of a non--corrosive material. b. Shall comply with ASHRAE Standard 62. c. Shall use a 3/4” --14 NPT drain connection, possible e ither through the bottom or end of the drain pan. Con-

nection shall be made per manufacturer’s recommendations.

7. Top panel:

a. Shall be a single piece top panel on 04 thru 09 sizes.

8. Electrical Connections

a. All unit power wiring shall enter unit cabinet a t a single, factory--prepared, knockout location. b. Thru--the--base capability

(1.) Standard unit shall have a thru--the--base electrical location(s) using a raised, embossed portion of the unit

basepan.

(2.) Optional, factory--approved, water--tight connection method must be used for thru--the--base electrical con-

nections.

(3.) No basepan penetration, other than those authorized by the manufacturer, is permitted.

9. Component access panels (standard)

a. Cabinet panels shall be easily removable for servicing. b. Unit shall have one factory installed, tool-- less, removable, filter access panel. c. Panels covering control box, indoor fan, indoor fan motor, gas components (where applic able), and com-

pressors shall have molded composite handles. d. Handles shall be UV modified, composite. permanently attached, and recessed into the panel. e. Screws on the vertical portion of all removable access panel shall engage into heat resistant, molded compos-

ite collars.

f. Collars shall be removable and easily replaceable using manufacturer recommended parts. 23 81 19.13.I. N/A 23 81 19.13.J. Coils

1. Standard Aluminum/Copper Coils: on all models. a. Standard evaporator and conde nser coils shall have aluminum lanced plate fins mechanically bonded to seam-

less internally grooved copper tubes with all joints brazed.

b. Evaporator coils shall be leak tested to 150 psig, pressure tested to 450 psig, and qualified to UL 1995 burst

test at 1775 psig.

c. Condenser coils shall be leak tested to 150 psig, pressure tested to 650 psig, and qualified to UL 1995 burst

test at 1980 psig.

548J

2. Optional Pre--coated aluminum--fin condenser coils: on all models. a. Shall have a durable epoxy--phenolic coating to provide protection in mildly corrosive coastal environments. b. Coating shall be applied to the aluminum fin stock prior to t he fin stamping process to create an inert barrier

between the aluminum fin and copper tube.

c. Epoxy--phenolic barrier shall minimize galvanic action between dissimilar metals.

3. Optional Copper--fin evaporator a nd condenser coils: on all models. a. Shall be constructed of copper fins mechanically bonded to copper tubes and copper tube sheets. b. Galvanized steel tube sheets shall not be acceptable. c. A polymer strip shall prevent coil assembly from contacting the sheet metal coil pan to minimize potential for

galvanic corrosion between coil and pan.

4. Optional E--coated aluminum--fin evaporator and condenser coils: on all m odels. a. Shall have a flexible epoxy polymer coating uniforml y applied to all coil surface areas without material

bridging between fins. b. Coating process shall ensure complete coil encapsulation of tubes, fins and headers. c. Color shall be high gloss black with gloss per ASTM D523--89. d. Uniform dry film thickness from 0.8 to 1.2 mil on all surface areas including fin edges. e. Superior hardness characteristics of 2H per ASTM D3363--92A and cross--hatch adhesion of 4B--5B per ASTM

D3359--93.

f. Impact resistance shall be up to 160 in.--lb (ASTM D2794--93).

g. Humidity and water immersion resistance shall be up to minimum 1000 and 250 hours respectively (ASTM

D2247--92 and ASTM D870--92). h. Corrosion durability shall be confirmed through testing to be no less than 1000 hours salt spray per ASTM

B117--90.

23 81 19.13.K. Refrigerant Components

1. Refrigerant circuit shall include the following control, safety, and maintenance features: a. Fixed orifice metering system shall prevent mal--distribution of two-- phase refrigerant by including multiple

fixed orifice devices in each refrigeration circuit. Each orifice is to be optimized to the coil circuit it serves. b. Refrigerant filter drier. c. Service gauge connections on suction and discharge lines. d. Pressure gauge access through a specially designed access port in the top panel of the unit. e. Suction line accumulator to provide protection in all operating modes from cooling, heating and reverse cycle

switching.

2. There shall be gauge line access port in the top of the rooftop, covered by a black, removable plug. a. The plug shall be easy to remove and replace. b. When the plug is removed, the gauge access port shall enable maintenance personnel to route their pressure

gauge lines.

c. This gauge access port shall facilitate correct and accurate condenser pressure readings by enabling the read-

ing with the compressor access panel on.

d. The plug shall be made of a leak proof, UV--resistant, composite material.

3. Compressors a. Unit shall use one fully hermetic, scroll compressor for each independent refrigeration circuit. b. Models shall be available with single compressor designs on 04--12 models, plus additional 2 compressor

(stage) models from 08--09 sizes. c. Compressor motors shall be cooled by refrigerant gas passing through motor windings. d. Compressors shall be internally protected from high discharge tem perature conditions. e. Compressors shall be protected from an over--temperature and over--amperage conditions by an internal, motor

overload device.

f. Compressor shall be factory mounted on rubber grommets.

g. Compressor motors shall have internal line break thermal, current overload and high pressure differential pro-

tection. h. Crankcase heaters shall be utilized on all models (except 04 size) to protect compressor with specific refriger-

ant charge.

23 81 19.13.L. Filter Section

1. Filters access is specified in the unit cabinet section of this specification.

2. Filters shall be held in place by a pivoting filter tray, facilitating easy removal and installation.

3. Shall consist of factory--installed, low velocity, throw--away 2--in. thick fiberglass filters.

4. Filters shall be standard, commercially available sizes.

5. Only one size filter per unit is allowed.

23 81 19.13.M. Evaporator Fan and Motor

1. Evaporator fan motor: a. Shall have permanently lubricated bearings. b. Shall have inherent automatic-- reset thermal overload protection or circuit breaker. c. Shall have a maximum continuous bhp rating for continuous duty operation; no safety factors above that rating

shall be required.

2.ElectricDrive(DirectDrive)X13–5Speed/TorqueEvaporatorFan: a. Multi speed motor with easy quick adjustment settings. b. Blower fan shall be double--inlet type with forward--curved blades. c. Shall be constructed from steel with a corrosion resistant finish and dynamically balanced. d. Standard on all 04--06 models with 208/230/1/60 operation e. Standard on all 04--06 3--phase models, with optional belt drive.

3. Belt--driven Evaporator Fan: a. Belt drive shall include an adjustable--pitch motor pulley. b. Shall use sealed, permanently lubricated ball --bearing type. c. Blower fan shall be double--inlet type with forward--curved blades. d. Shall be constructed from steel with a corrosion resistant finish and dynamically balanced. e. Standard on all 07 size models. Optional on all 04--06 3--phase models.

23 81 19.13.N. Condenser Fans and Motors

1. Condenser fan motors: a. Shall be a totally enclosed motor. b. Shall use permanently lubricated bearings. c. Shall have inherent thermal overload protection with an automatic reset feature. d.Shalluseashaft--downdesignon04to09models.

2. Condenser Fans: a. Shall be a direct--driven propeller type fan. b. Shall have aluminum blades riveted to corrosion--resistant steel spiders and shal l be dynamically balanced.

23 81 19.13.O. Special Features, Options and Accessories

1. Integrated Economizers: a. Integrated, gear--driven parallel modulating blade design type capable of simultaneous economizer and com-

pressor operation.

b. Independent modules for vertical or horizontal return configurations shall be available. Vertical return m odules

shall be available as a factory installed option.

c. Damper blades shall be galvanized steel with composite gears. Plastic or composite blades on intake or return

shall not be acceptable.

d. Shall include all hardware and controls to provide free cooling with outdoor air when temperature and/or hu-

midity are below setpoints.

e. Shall be equipped with gear driven dampers for both the outdoor ventilation air and the return air for positive

air stream control.

f. Shall be equipped with low--leakage dampers, not to exceed 2% leakage at 1 in. wg pressure differential. g. Shall be capable of introducing up to 100% outdoor air. h. Shall be equipped with a barometric relief damper capable of relieving up to 100% return air.

i. Shall be designed to close damper(s) during loss--of-- power situations with spring return built into motor.

j. Dry bulb outdoor--air temperature sensor shall be provided as standard. Outdoor air sensor setpoint shall be

adjustable and shall range from 40 to 100_F/4to38_C. Additional sensor options shall be available as ac- cessories.

k. The economizer controller shall also provide control of an accessory power exhaust unit function. Factory set

at 100%, with a range of 0% to 100%.

l. The economizer shall maintain minimum airflow into the building during occupied period and provide design

ventilation rate for full occupancy. A remote potentiometer may be used to override the damper setpoint.

m. Dampers shall be completely closed when the unit is in the unoccupied mode.

548J

n. Economizer controller shall accept a 2-- 10Vdc CO2sensor input for IAQ/DCV control. In this mode, dampers

shall modulate the outdoor--air damper to provide ventila tion based on the sensor input. o. Compressor lockout sensor shall open at 35_F(2_C) and closes at 50_F(10_C). p. Actuator shall be direct coupled to economizer gear. No linkage arms or control rods shall be acceptable. q. Economizer controller shall provide indications when in free cooling mode, in the DCV mode, or the exhaust

fan contact is closed.

2. Two--Position Motorized Damper a. Damper shall be a Two--Position Motorized Damper. Damper travel shall be from the full closed position to

the field adjustable %--open setpoint. b. Damper shall include adjustable damper travel from 25% to 100% (full open). c. Damper shall include single or dual blade, gear driven dampers and actuator m otor. d. Actuator shall be direct coupled to damper gear. No linkage arms or control rods shall be acceptable. e. Damper will admit up to 100% outdoor air for applicable rooftop units.

f. Damper shall close upon indoor (evaporator) fan shutoff and/or loss of power. g. The damper actuator shall plug into the rooftop unit ’s wiring harness plug. No hard wiring shall be required. h. Outside air hood shall include aluminum water ent rainment filter

3. Manual damper a. Manual damper package shall consist of damper, air inlet screen, and rain hood which can be preset to admit

up to 50% outdoor air for year round ventilation.

4. Head Pressure Control Package a. Controller shall control coil head pressure by condenser--fan speed modulation or condenser-- fan cycling and

wind baffles.

b. Shall consist of solid--state control and condenser--coil temperature sensor to maintain c ondensing temperature

between 90_F(32_C) and 110_F(43_C) at outdoor ambient temperatures down to -- 20_F(--29_C).

5. Condenser Coil Hail Guard Assembly a. Shall protect against damage from hail. b. Shall be louvered design.

6. Unit--Mounte d, Non--Fused Disconnect Switch: a. Switch shall be factory--installed, internally mounted. b. National Electric Code (NEC) and UL approved non--fused switch shall provi de unit power shutoff. c. Shall be accessible from outside the unit d. Shall provide local shutdown and lockout capability.

7. Convenience Outlet: a. Powered convenience outlet.

(1.) Outlet shall be powered from main line power to the rooftop unit. (2.) Outlet shall be powered from line side or load side of disconnect by installing contractor, as required by

code. If outlet is powered from load side of disconnect, unit electrical ratings shall be UL certified and

rated for additional outlet amperage. (3.) Outlet shall be factory--installed a nd internally mounted with easily accessible 115--v female receptacle. (4.) Outlet shall include 15 amp GFI receptacles with independent fuse protection. (5.) Voltage required to operate convenience outlet shall be provided by a factory--installed step--down trans-

former. (6.) Outlet shall be accessible from outside the unit.

b. Non--Powered convenience outlet.

(1.) Outlet shall be powered from a separate 115--120v power source. (2.) A transformer shall not be included. (3.) Outlet shall be factory--installed a nd internally mounted with easily accessible 115--v female receptacle. (4.) Outlet shall include 15 amp GFI receptacles. (5.) Outlet shall be accessible from outside the unit.

8. Thru--the--Base Connectors: a. Kits shall provide connectors to permit electrical connections to be brought to the unit through the unit base-

pan.

b. Minimum of three connection locations pe r unit.

9. Fan/Filter Status Switch: a. Switch shall provide status of indoor evaporator fan (ON/OFF) or filter (CLEAN/DIRTY). b. Status shall be displayed either over communication bus (when used with direct digital controls) or with an

indicator light at the thermostat.

10. Propeller Power Exhaust: a. Power exhaust shall be used in conjunction with an integrated economizer. b. Independent modules for vertical or horizontal return configurations shall be available. c. Horizontal power exhaust is shall be mounted in return ductwork. d. Power exhaust shall be controlled by economizer controller operation. Exhaust fans shall be energized when

dampers open past the 0--100% adjustable setpoint on the economizer control.

11. Roof Curbs (Vertical): a. Full perimeter roof curb with exhaust capability providing separate air streams for energy recovery from the

exhaust air without supply air contamination. b. Formed galvanized steel with wood nailer strip and shall be capable of supporting entire unit weight. c. Permits installation and securing of ductwork to curb prior to mounting unit on the curb.

12. High--Static Indoor Fan Motor(s) and Drive(s) (04-- 09): a. High--static motor(s) and drive(s) shall be factory--installed to provide additional performance range.

13. Thru--the--Bottom Utility Connectors: a. Kit shall provide connectors to permit el ectrical connections to be brought to the unit through the basepan.

14. Fan/Filter Status Switch: a. Provides status of indoor (evaporator) fan (ON/ OFF) or filter (CLEAN/DIRTY). Status shall be displayed over

communication bus when used with direct digital controls or with an indicator light at the thermostat.

15. Outdoor Air Enthalpy Sensor: a. The outdoor air enthalpy sensor shall be used to provide single enthalpy control. When used in conjunction

with a return air enthalpy sensor, t he unit will provide differential enthalpy cont rol. The sensor allows the unit to determine if outside air is suitable for free cooling.

16. Return Air Enthalpy Sensor: a. The return air enthalpy sensor shall be used in conjunction with an outdoor air enthalpy sensor to provide dif-

ferential enthalpy control.

17. Indoor Air Quality (CO

)Sensor:

a. Shall be able to provide demand ventilation indoor air quality (IAQ) control. b. The IAQ sensor shall be a vailable in duct mount, wa ll mount, or wall mount with LED display. The setpoint

shall have adjustment capability.

18. Smoke detectors: a. Shall be a Four--Wire Controller and Dete ctor. b. Shall be environmental compensated with differential sensing for reliable, stable, and drift--free sensitivity. c. Shall use magnet--activated test/reset sensor switches. d. Shall have tool-- less connection terminal access. e. Shall have a recessed momentary switch for testing and resetting the detector.

f. Controller shall include:

(1.) One set of normally open alarm initiation contacts for connection to an initiating device circuit on a fire

alarm control panel. (2.) Two Form-- C auxiliary alarm relays for interface with rooftop unit or other equipment. (3.) One Form--C supervision (trouble) relay to control the operation of the Trouble LED on a remote test/reset

station. (4.) Capable of direct c onnection to two individual detector modules. (5.) Can be wired to up to 14 other duct smoke detectors for multiple fan shutdown applications.

19. Time Guard a. Shall prevent compressor short cycling by providing a 5--minute delay (±2 minutes) before restarting a com-

pressor after shutdown for any reason.

b. One device shall be required per compressor.

20. Electric Heat: a. Heating Section

(1.) Heater element open coil resistance wire, nickel--chrome alloy, 0.29 inches inside diameter, strung through

ceramic insulators mounted on metal frame. Coil ends are staked and welded to terminal screw slots.

548J

(2.) Heater assemblies are provided with integral fusing for protection of internal heater circuits not exceeding

48 amps each. Auto reset thermo limit controls, magnetic heater contactors (24V coil) and terminal block all mounted in elect ric heater control box (minimum 18 ga galvanized steel) attached to end of heater assembly.

E2009 Bryant Heating & Cooling Systems D 7310 W. Mo rris St. D Indianapolis, IN 46231 Printed in U.S.A. Edition Date: 03/09

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Catalog No. PDS548J--- 01

Replaces: NEW

Bryant PACKAGED HEAT PUMP 548J, Legacy 548J Product Data

Specifications and Main Features

Frequently Asked Questions

User Manual
