MODEL 213R
LEGACYt--RNC SERIES HEAT PUMP
SIZES 018 TO 060
1--1/2 TO 5 NOMINAL T ONS

Produc t Data

Shown with optional dense coil guard

FEATURES / BENEFITS

Efficiency

13 SEER/ 11 EER / Up to 8.6 HSPF (Nominal)

S
S Microtube Technologyt refrigeration system
S Indoor air quality accessories available

Sound

Sound level as low as 75 dBA

S

Comfort

System supports Thermidistatt or standard thermostat

S

controls

Reliability

Front--seating service valves

S
S Scroll compressor
S Filter drier
S Loss of charge pressure switch
S Balanced refrigeration system for maximum reliability

Durability

DuraGuardt protection package:

S Solid, Durable sheet metal construction
S Wire coil guard
S Baked--on, complete coverage, powder paint

Applications

Long--line -- up to 250 feet total equivalent length, up

S

to 200 feet condenser above evaporator, or up to 80 ft.
evaporator above condenser (See Longline Guide for
more information.)

S Low ambient (down to --20_F) with accessory kit

Warranty

Single Phase

S 5 year limited compressor warranty
S 5 year limited parts warranty

Three Phase

S 5 year limited compressor warranty
S 1 year limited parts warranty

MODEL NUMBER NOMENCLATURE

12345678910111214

N N N A A/N N N N N A/N A/N N A

21 3 R N A 036 0 0 0 0

Prod-

uct

Famil y

2=HP1=Legacy

Tier SEER Major Series Voltage Variations

RNC

3=13 SEER R=R--- 22

N=
208/230--- 1
P=208/230

--- 3

E=460/3

A=Standard

G=Dense Coil

Guard

ISO 9001:2000

REGISTERED

Cooling Capacity

Open Open Open Series

0=Not

Defined

0=Not

Defined

0=Not

DefinedA=Original

213R

As an Energy Star® Partner, Bryant
Heating & Co oling Systems has
determined that this product meets the
ENERGY STAR® guidelines for energy
efficiency.

Refer to the combination ratings in
Product Data for system combinations that
meet Energy Star guidelines.

STANDARD FEATURES

Feature 18 24 30 36 42 48 60

13 SEER X X X X X X X

Scroll Compressor X X X X X X X

Wire Coil Guard X X X X X X X

FieldInstalledFilterDrier X X X X X X X

Front Seating Service Valves X X X X X X X

Internal Pressure Relief Valve X X X X X X X

Internal Thermal Overload X X X X X X X

Long Line capability X X X X X X X

Low Ambient capability with Kit X X X X X X X

Loss of Charge Pressure Switch X X X X X X X

Series

2

PHYSICAL DATA

UNIT SIZE --- SERIES 018 ---A 024 --- A 030 --- A 036 ---A 042 --- A 048 --- A 060--- A
Operating Weight (lb) 159 160 208 211 233 269 295
Shipping Weight (lb) 184 185 240 242 262 300 327
Compressor Type Scroll
REFRIGERANT Freon® ( R --- 2 2 )

Control T X V ( R --- 2 2 H a r d Sh u t o f f )
Charge (lb) 5.5 6 7.5 8 10 14 15.5

COND FAN Propeller Type, Direct Drive

Air Discharge Vertical
Air Qty. (CFM) 2233 2614 2614 3334 3334 4046 4046
Motor HP 1/12 1/10 1/10 1/8 1/8 1/5 1/5
Motor RPM 800 1100 1100 800 800 800 800

COND COIL

Face Area (Sq . ft.) 15.09 15.09 25.87 22.63 17.6 22.63 25.15
Fins per In. 20 20 20 20 20 20 20
Rows 1 1 1 1 2 2 2
Circuits 5 6 6 6 7 8 9

VALVECONNECT.(In.ID)

Vapor 5/8” 5/8” 3/4” 3/4” 7/8” 7/8” 7/8”
Liquid 3/8”

REFRIGERANT TUBES* (In. OD)

Vapor (0---80 Ft. Tube Length) 5/8” 5/8” 3/4” 3/4” 7/8” 7/8” 1 --- 1/8”
Liquid (0 --- 80 Ft. Tube Length) 3/8”

* For tubing sets between 80 and 200 ft. horizontal or 20 ft. vertical differential, consult the Longline Guideline.
Note: See unit Installation Instruction for proper installation.

VAPOR LINE SIZING AND COOLING CAPACITY LOSS
1--STAGE HEAT PUMP APPLICATIONS

LONG LINE APPLICATION: An application is considered
”Long line” when the total equivalent tubing length exceeds 80
ft. or when there is more than 20 Ft. vertical separation between
indoor and outdoor units. These applications require additional
accessories and system modifications for reliable system
operation. The maximum allowable total equivalent length is 250
ft. The maximum vertical separation is 200 ft. when outdoor unit

Unit Nominal Size (Btuh)

18000

R --- 22 H P

24000

R --- 22 H P

30000

R --- 22 H P

36000

R --- 22 H P

42000

R --- 22 H P

48000

R --- 22 H P

60000

R --- 22 H P

Acceptable Vapor
Line Diameter OD

(in.)

5/8 0 1 1 1 2 3 3 4 5 5 6

3/4 0 0 0 0 0 1 1 1 1 2 2

5/8 0 1 3 3 3 5 6 7 8 9 10

3/4 0 0 0 0 1 1 1 2 2 3 3

3/4 0 1 1 1 2 3 3 4 5 5 6

7/8 0 0 0 0 1 1 1 2 2 2 3

3/4 0 1 2 2 3 4 5 6 7 8 9

7/8 0 0 1 1 1 2 2 3 3 4 4

7/8 0 1 1 1 2 2 3 4 4 5 5

7/8 0 1 2 2 2 3 4 5 5 6 7

7/8 1 2 3 3 4 5 7 8 9 10 11

11/8 0 0 1 1 1 1 2 2 2 3 3

Standard Application

25 50 80 80+ 100 125 150 175 200 225 250

Standard Length = 80 ft. or less total equivalent length
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines

Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See
Long Line Application Guidelines

is above indoor unit, and 60 ft. when the outdoor unit is below
the indoor unit. Refer to Accessory Usage Guideline below for
required accessories. See Long--Line Application Guideline for
required piping and system modifications. Also, refer to the table
below for the acceptable vapor tube diameters based on the total
length to minimize the cooling capacity loss.

Cooling Capacity Loss (%)

Total Equivalent Line Length (ft.)

Long Line Application
Requires Accessories

213R

3

ACCESSORY THERMOSTATS

THERMOSTAT / SUBBASE PKG. DESCRIPTION

Thermidistatt Control — Non ---Programmable/Programmable Thermostat with

TSTATBBPRH01 --- B*

TSTATBBPHH01 --- B*

TSTATBBPHP01 ---B

TSTATBBNHP01 --- C

TSTATBBSHP01

TSTATBBBHP01* --- B

TSTATXXSEN01 ---B** Outdoor Air Temperature Sensor
TSTATXXNBP01 Backplate for Non --- Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat and Thermidistatt Control
TSTATXXSBP01 Backplate for Standard Programmable Thermostat
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXCNV10{ Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack

* D o not use in zoning heat pu mp applications.

213R

** Outdoor temperature sensor is an accessory for all Bryant electronic thermostats, except the non --- programmable air conditioner version and builder;s

thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat. The outdoor air temperature sensor must be used
with the HybridHeatt (dual fuel) thermostat.

{ Thermostat conversion kit is a 24 ---vac accessory that can turn a 4 --- wire thermostat application into a 5--- wire application. This kit can also be used to

replace a broken thermostat wire, or add an extra wire when needed.

The outdoor air temperature sensor is included with the Thermidistat Control and HybridHeatt (dual fuel) thermostat.

Humidity Control (For use in Dual Fuel, AC, HP, and 2S applications. Includes Out­door Air Temperature Sensor.)

HybridHeatt (Dual Fuel) Thermostat — Auto Changeover, 7--- Day Programmable,
°F/°C, Includes Outdoor Sensor (TSTATXXSEN01--- B)

Thermostat — Auto Changeover, 7--- Day Programmable, °F/°C , 2 --- S t a g e He a t ,
1 --- S t a g e C o o l

Thermostat — Auto Changeover, Non--- Programmable, °F/°C , 2 --- S t a g e He a t ,
1 --- S t a g e C o o l

Standard Programmable Thermostat—Manual C hangeover, 5--- 2 Day Program­mable, °F/°C , 1 --- S t a g e He a t / 1 --- S t a g e C o o l

Builder’s Thermostat — Heat Pump, Non --- Programmable, °F/°C , 2 --- S t a g e He a t ,
1--- Stage Cool, Manual Changeover

ACCESSORIES

ORDER NUMBER DESCRIPTION (N)

HC32GE229 BALL BEARING MOTOR X
HC34GE240 BALL BEARING MOTOR X X X
HC36GE232 BALL BEARING MOTOR X X X X
HC40GE228 BALL BEARING MOTOR X X X X
KAACH1201AAA CR ANKCASE HTR X X X X X X S S S S
KAACH1301AAA CR ANKCASE HTR X X S S
KAACH1401AAA CR ANKCASE HTR X X
KSACY0101AAA CYCLE PROTECTOR X X X X X X X X X X X X X X X X
KAAFT0101AAA F REEZE THERMOSTAT X X X X X X X X X X X X X X X X
KSAHS1501AAA HARD START X X X X X X
KSAHS1601AAA HARD START X
KSAHI0301R22 HIGH PRESS SW X X X X X X X X X X X X X X X X
KHAIR0101AAA ISOLATION RELAY X X X X X X X X X X X X X X X X
KSALA0201R22 LOW A MB IE NT X X X X X X X X X X X X X X X X
KSALA0601AAA MOTORMASTER 230V X X X X X X X X X X X X
KSALA0701AAA MOTORMASTER 460V X X X X
KHAOT0201SEC OUTDOOR THERMO-

KHAOT0301FST OUTDOOR THERMO-

KHALS0401LLS SOLENOID VALVE X X X X X X X X X X X X X X X X
KSASH0601COP SOUND BLKT X X X X X X X X X X X
KSASH1801COP SOUND BLKT X X
KSASH2101COP SOUND BLKT X X X
KAACS0201PTC START ASSIST PTC X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X X X X X X X X X X
KAATD0101TDR TI ME D ELAY X X X X X X X X X X X X X X X X
KSATX0601HSO TXV X X X X X X X X X X
KSATX0701HSO TXV X X X
KSATX1001HSO TXV X X X

STAT

STAT

(N)

(N)

(P)

(N)

(P)

(E)

(N)

(P)

(E)

(N)

(P)

(E)

(N)

018-- A

024-- A

030-- A

030-- A

036-- A

036-- A

036-- A

042-- A

042-- A

042-- A

048-- A

048-- A

048-- A

X X X X X X X X X X X X X X X X

X X X X X X X X X X X X X X X X

060-- A

(P)

060-- A

060-- A

(E)

4

ACCESSORY USAGE GUIDELINE

REQUIRED FOR LOW--- AMBI-

Accessory

Crankcase Heater Yes Yes No

Evaporator Freeze Thermostat Yes No No

Accumulator No No No

Compressor Start Assist Capacitor and

Relay

Motor Master®Control

o r L o w --- a m b i e n t P r e s s u r e S w i t c h

Support Feet Recommended No Recommended

Liquid Line Solenoid Valve No

Ball Bearing Fan Motor Ye s { No No

* For tubing line sets between 80 and 200 ft. and/or 20 ft. vertical differntial, refer to Residential Split ---System Longline Application Guideline.
{ Required for Low --- Ambient Controller (full modulation feature) and MotorMasterr Control only.

ENT APPLICATIONS

(Below 55° F)

Yes Yes No

Yes No No

Accessory Description and Usage (Listed Alphabetically)

1. Ball--Bearing Fan Motor

A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.

Usage Guideline:

Required on all units when MotorMasterr is used.

2. Compressor Start Assist -- Capacitor and Relay

Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.

Usage Guideline:

Required for reciprocating compressors in the

following applications:

Long line
Low ambient cooling

Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil

Required for single--phase scroll compressors in the

following applications:

Long line

Low ambient cooling

Suggested for all compressors in areas with a history of
low voltage problems.

3. Compressor Start Assist — PTC Type

Solid state electrical device which gives a ”soft” boost to the
compressor at each start-- up.

Usage Guideline:

Suggested in installations with marginal power supply.

4. Crankcase Heater

An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.

Usage Guideline:

Required in low ambient cooling applications.

Required in long line applications.
Suggested in all commercial applications.

5. Cycle Protector

The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay
after power to the compressor has been interrupted for any
reason, including power outage, protector control trip, thermostat
jiggling, or normal cycling.

6. Evaporator Freeze Thermostat

An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.

7. Isolation Relay

An SPDT relay which switches the low--ambient controller out of
the outdoor fan motor circuit when the heat pump switches to
heating mode.

8. Liquid--Line Solenoid Valve (LLS)

An electrically operated shutoff valve which stops and starts
refrigerant liquid flow in response to compressor operation. It is
to be installed at the outdoor unit to control refrigerant off cycle
migration in the heating mode.

9. Low--Ambient Pressure Switch Kit

A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low--ambient temperatures down to 0_F
when properly installed.

Low--Ambient Controller must be used when cooling operation is
used at outdoor temperatures below 55_F (12.8_C).

10. MotorMasterr Low --Ambient Controller

A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (-- 28.9_C),
it maintains condensing temperature at 100_F ±10_F (37.8_C ±

-- 1 2 _

REQUIRED FOR LONG

LINE APPLICATIONS*

(Over 80 Ft.)

See Long --- Line Application

Guideline

REQUIRED FOR SEA

COAST APPLICATIONS

(Within 2 miles)

Usage Guideline:

Required when low ambient kit has been added.

Usage Guideline:

Required in all heat pumps where low ambient kit has
been added.

Usage Guideline:

An LLS is required in all long line heat pump
applications to control refrigerant off cycle migration in
the heating mode. See Long Line Guideline.

Usage Guideline:

A Low--Ambient Pressure Switch or MotorMasterr

C).
Usage Guideline:

A MotorMasterr Low Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).

Suggested for all commercial applications.

No

213R

5

Accessory Description and Usage (Listed Alphabetically) -- CONTINUED

11. Outdoor Air Temperature Sensor

Designed for use with Bryant Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also is required to enable
special thermostat features such as auxiliary heat lock out.

Usage Guideline:

Suggested for all Bryant thermostats listed in this
publication.

12. Outdoor Thermostat

An SPDT temperature--actuated switch which turns on
supplemental electric heaters when outdoor air temperature drops
below a user--selected set point.

Usage Guideline:

Electric supplemental heat applications in non--variable
speed indoor units when electric heat staging is desired.

Usage Guideline:

Some local codes may require limiting the heating head

213R

13. Secondary Outdoor Thermostat

An SPDT temperature--actuated switch which turns on
third--stage of supplemental electric heaters when outdoor air
temperature drops below the second-- stage set point.

14. Sound Hood

Wraparound sound reducing cover for the compressor. Reduces
the sound level up to 2 dBA.

pressure in the vapor line in some applications.

Usage Guideline:

Outdoor thermostat applications where electric heater is
capable of 3--stage operation.

Usage Guideline:

Suggested when unit is installed closer than 15 ft to
quiet areas, bedrooms, etc.

Suggested when unit is installed between two houses less
than 10 ft apart.

Usage Guideline:

Suggested in the following applications:

Heat pump installations in heavy snowfall areas.
Heat pump installations in snowdrift locations.

Heat pump installations in areas of prolonged
subfreezing temperatures.

All commercial installations.

15. Thermostatic Expansion Valve (TXV) Bi-- Flow

A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.

Usage Guideline:

Required in all heat pump applications

16. Time--Delay Relay

An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.

Note: Most indoor unit controls include this feature. For those
that do not, use the guideline below.

Usage Guideline:

6

ELECTRICAL DATA

(VOLTAGE)

UNIT SIZE

--- S E R I E S

(N) 018 --- A
(N) 024 --- A 54 11.3 0.8 14.80 14 14 131 125 25
(N) 030 --- A 72.5 14.8 0.8 19.20 12 12 161 154 30
(N) 036 --- A 88 17.0 0.9 22.10 12 12 140 133 35
(N) 042 --- A 104 21.2 0.9 27.40 10 10 181 172 40
(N) 048 --- A 137 21.2 1.2 27.60 10 10 179 170 40
(N) 060 --- A 148 28.9 1.2 37.30 8 8 207 197 60
(P) 030 --- A
(P) 036 --- A 77 11.3 0.9 15.03 12 12 96 92 25
(P) 042 --- A 88 13.4 0.9 17.65 12 12 82 78 25
(P) 048 --- A 91 13.78 1.2 18.43 10 10 125 119 30
(P) 060 --- A 123 18.7 1.2 24.58 8 10 146 89 35
(E) 036--- A
(E) 042--- A 44 6.4 0.5 8.50 14 14 214 203 15
(E) 048--- A 46 7.1 0.6 9.41 14 14 193 184 15
(E) 060--- A 62 8.6 0.6 11.35 14 14 160 152 15

* Permissible limits of the voltage range at which the unit wil l operate satisfactorily
{ If wire is applied at ambient gr eater than 30° C(86° F), consult table 310 ---16 of the NEC (ANSI/NFPA 70). The ampacity of non --- metallic ---sheathed cable

(NM), trade name ROMEX, shall be that of 60° C (140° F) conditions, per the NEC (ANSI/NFPA 70) Article 336 --- 26. If other than uncoated (no--- plated), 60
or 75° C (140 or 167° C) insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables
of the NEC (ANSI/NFPA 70).

} Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i me --- D e la y f u se .
F L A --- F u l l L o a d A mp s
LRA --- Locked Rotor Amps
MCA --- Minimum Circuit Amps
RLA --- Rated Load Amps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit. All

motors/compressors contain internal overload protection.

V/PH

208/230/1 253 187

208/230/3 253 197

460/3 506 414

OPER VOLTS* COMPR FAN

MAX MIN LRA RLA FLA 60° C 75° C 60° C 75° C

41 9.0 0.5 11.70 14 14 166 158 20

63 10.4 0.75 13.75 14 14 66 63 20

39 5.5 0.5 7.38 14 14 247 235 15

MCA

MIN

WIRE
SIZE{

MIN

WIRE

SIZE{

MAX

LENGTH

(FT)}

MAX

LENGTH

(FT)}

MAX

FUSE**

or CKT

BRK

AMPS

213R

A--WEIGHTED SOUND POWER (DBA)

UNIT SIZE --- SERIES

STANDARD

RATING
018 ---A 75 52 59.5 64.5 71 67 61.5 54.5
024 ---A 76 52.5 63.5 69.5 72 67.5 64.5 59.5

030 ---A 76 52 64 70 71 68 66.5 65
036 ---A 76 53 69 66.5 69.5 66.5 63.5 62
042 ---A 76 57 65 68 72.5 67.5 64 59
048 ---A 76 57.5 65 68 70.5 69 64 60.5
060 ---A 77 61 62.5 70 72.5 70 67 60

TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)

125 250 500 1000 2000 4000 8000

A--WEIGHT ED SOUND POWER (DBA) WITH SOUND HOOD

UNIT SIZE --- SERIES

STANDARD

RATING
018 ---A 74 52.0 59.5 64.0 68.0 64.0 60.0 52.5
024 ---A 75 53.5 63.0 69.0 70.5 66.5 64.0 58.5
030 ---A 75 53.0 64.5 69.5 70.5 67.5 64.5 60.5
036 ---A 75 54.0 68.5 65.5 68.0 65.0 62.0 57.5
042 ---A 76 58.0 64.5 67.0 71.0 65.5 61.0 54.5
048 ---A 75 58.0 64.0 68.0 69.0 65.5 60.5 55.5
060 ---A 75 59.5 61.5 67.5 70.0 68.0 64.0 57.5

TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)

125 250 500 1000 2000 4000 8000

CHARGING SUBCOOLING (TXV-- T YPE EXPANSION DEVICE)

UNIT SIZE--- SERIES REQUIRED SUBCOOLING (_F)

018 ---A 11
024 ---A 11
030 ---A 9
036 ---A 11
042 ---A 13
048 ---A 13
060 ---A 11

7

213R

DIMENSIONS

NOTE: Optional “G” dense coil guard shown.

8

kW

0.0

FC4DNF060

17.6

213RN(A,G)048A

FC4DNF048

23.4

20.5

213RN(A,G)060A

213RN(A,G)042A

FC4DNF042

14.6

FC4DNF036

213RN(A,G)036A

11.7

FA4CNF030

213RN(A,G)030A

8.8

FA4CNF024

213RN(A,G)024A

5.9

FA4CNF018

213RN(A,G)018A

2.9

A05007

213R

ºF AND AT RATED CFM

BASED ON INDOOR ENT. AIR AT 70

213RN(A,G) BALANCE POINT WORKSHEET

80.00

70.00

60.00

50.00

40.00

30.00

OUTDOOR TEMPERATURE, ºF

--100 1020304050 607080

20.00

10.00

0.00

HEATING CAPACITY, MBTUH

BUILDING HEAT LOSS, UNIT INTEGRATED

9

COMBINATION RATINGS

Unit Size

--- S e r i e s

Indoor Model

*FA4CN(F,C)018 17,100 TDR&TXV 13.00 10.80 18,000 3.52 10,500 2.34 8.0

FA4CN(F,C)024 17,200 TDR&TXV 13.00 10.80 16,000 3.30 10,500 2.34 7.9

FC4DNF018 17,500 TDR&TXV 14.00 11.70 17,500 3.80 10,100 2.52 8.5
FC4DNF024 17,600 TDR&TXV 14.00 12.00 15,400 3.60 10,000 2.56 8.5
FF1ENE018 17,100 TDR&TXV 13.00 10.80 18,000 3.54 10,500 2.36 8.0
FF1ENE024 17,300 TDR&TXV 13.00 10.80 15,600 3.32 10,500 2.38 8.0
FK4DNF001 17,500 TDR&TXV 14.00 12.00 14,600 3.48 9,900 2.54 8.4
FK4DNF002 17,700 TDR&TXV 14.00 12.50 14,600 3.58 9,900 2.58 8.6

CAR**1814A** 16,900 TXV 13.00 10.80 18,100 3.46 10,400 2.34 7.9
CAR**1814A** 16,900 TDR&TXV 14.00 11.70 18,000 3.70 9,800 2.46 8.2 315(A,J)AV036070

CAR**2414A** 17,400 TXV 13.00 10.80 15,700 3.34 10,500 2.40 8.1
CAR**2414A** 17,300 TDR&TXV 14.00 12.00 15,600 3.70 9,900 2.50 8.4 315(A,J)AV036070

CAR**2417A** 17,400 TXV 13.00 10.80 15,700 3.34 10,500 2.40 8.1
CAR**2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.70 9,900 2.52 8.4 355AAV042060
CAR**2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.70 9,900 2.52 8.6 315(A,J)AV048090

Cooling

Capacity

Enhance

Cooling Heating

Standard

Rating

SEER

TDR

EER

ARI Standard Ratings

High Temp Low Temp

E

Capacity

ECOP

H

Capacity

HCOP

HSPF

Furnace ModelFactory

213R

018--- A

CNRV*1814A** 16,900 TXV 13.00 10.80 17,200 3.52 10,500 2.40 8.1
CNRV*1814A** 16,900 TDR&TXV 14.00 12.00 17,100 3.88 9,900 2.50 8.5 315(A,J)AV036070

CNRV*2414A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2
CNRV*2414A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 315(A,J)AV036070

CNRV*2417A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2
CNRV*2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 355AAV042060
CNRV*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.54 8.5 315(A,J)AV048090

CNRH*2417A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2
CNRH*2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 355AAV042040
CNRH*2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 355AAV042060
CNRH*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.82 9,900 2.52 8.5 355AAV042080
CNRH*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 315(A,J)AV036070
CNRH*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.54 8.5 315(A,J)AV048090

CNRF*2418A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2

CSRH*2412A** 17,400 TXV 13.00 10.80 14,800 3.26 10,500 2.42 8.0
CSRH*2412A** 17,300 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 355AAV042040
CSRH*2412A** 17,300 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 355AAV042060
CSRH*2412A** 17,400 TDR&TXV 14.00 12.00 14,800 3.60 9,900 2.52 8.5 355AAV042080
CSRH*2412A** 17,300 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 315(A,J)AV036070
CSRH*2412A** 17,400 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 315(A,J)AV048090

*FA4CN(F,C)024 22,600 TDR&TXV 13.00 10.80 23,800 3.52 14,400 2.36 7.9

FA4CN(F,C)030 22,800 TDR&TXV 13.00 10.80 22,600 3.46 14,400 2.38 7.9

FC4DNF024 23,000 TDR&TXV 14.00 11.50 23,400 3.70 13,900 2.48 8.3
FC4DNF030 23,200 TDR&TXV 14.00 11.50 22,200 3.66 13,900 2.52 8.4

FF1ENE030 22,600 TDR&TXV 13.00 10.80 23,600 3.52 14,400 2.36 8.0

FK4DNF001 23,000 TDR&TXV 14.00 11.70 22,600 3.66 13,700 2.48 8.3
FK4DNF002 23,200 TDR&TXV 14.00 11.70 22,600 3.78 13,700 2.54 8.5
FK4DNF003 23,200 TDR&TXV 14.00 11.70 20,800 3.60 13,600 2.54 8.5

024--- A

See notes on pg. 17

CAR**2414A** 22,800 TXV 13.00 10.80 23,800 3.56 14,400 2.38 8.1
CAR**2414A** 22,800 TDR&TXV 14.00 11.50 23,800 3.72 13,700 2.46 8.3 315(A,J)AV036070

CAR**2417A** 22,800 TXV 13.00 10.80 23,800 3.56 14,400 2.38 8.1
CAR**2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.74 13,700 2.48 8.3 355AAV042060
CAR**2417A** 22,800 TDR&TXV 14.00 11.70 23,600 3.76 13,600 2.50 8.4 315(A,J)AV048090

CAR**3014A** 22,800 TXV 13.00 10.80 20,800 3.30 14,500 2.38 7.8
CAR**3014A** 22,800 TDR&TXV 14.00 11.50 22,000 3.58 13,700 2.48 8.2 315(A,J)AV036070

CAR**3017A** 22,800 TXV 13.00 10.80 20,800 3.30 14,500 2.38 7.8
CAR**3017A** 22,800 TDR&TXV 14.00 11.70 20,800 3.60 13,700 2.50 8.3 355AAV042060
CAR**3017A** 23,000 TDR&TXV 14.00 11.70 20,800 3.62 13,600 2.52 8.3 315(A,J)AV048090

10
