USERS INFORMATION MANUAL

MODEL TSTATBBPF101
PROGRAMMABLE DIGITAL
THERMOSTAT

Am

I2:00

72

Heat Pump & Heat Cool

74

COOL

AUTO

HEAT

70

This manual must be left with the equipment user.

NOTE TO INSTALLER:

Mounts Flush to the Wall
7 Day Programmable
4 Time Periods per Day
Auto Changeover
Large, Easy To Read
Display
Thermoglow Backlight
Very Easy to Program
Programmable Fan
No Batteries Required
Outdoor Temperature
Sensor Available

Meets California Title 24 Residential

Table Of Contents

FRONT PANEL
DISPLAY
QUICK START Set the clock and go
BASIC OPERATION
PROGRAMMING 4 Time Periods
ADVANCED SETUP
ABOUT ADVANCED OPERATION
WARRANTY

CAUTION

Follow Installation Instructions before proceeding.

SET THERMOSTAT TO MODE “OFF” PRIOR TO

CHANGING SETTINGS IN SETUP OR RESTORING

FACTORY DEFAULTS.

Residiential Light Commercial Systems Carrier Corporation 4/01

2
3
5
6

8
12
17
22

TSTATBBPF701

Page 1

Front Panel

1

3

4

6

1

Liquid Crystal Display
with Thermoglow

Up/Down Buttons

2

Mode Button

3

5

2

Fan Button

4

5

Heat or Cool Indicator
Heat = Red, Cool = Green

6

Temperature Sensor Bubble

Page 2

Display

6

7

Am

Night

Day

Service

Pm

Setup

Evening

Filter

9

88

o

COOL

AUTO

Outside

Locked

ONOFF

Program

HEAT

88

On

2

3

6

8

1

Mode Indicators
Selects the operation mode of the equipment.
HEAT - indicates the heat mode.
COOL - indicates the air conditioning mode.
AUTO - indicates the system will automatically
changeover between heat and cool modes
as the temperature varies.
OFF - indicates the entire system is turned off.
PROGRAM ON - indicates the stored program
is enabled to run. Page 6.

2

Clock with Day of the Week
Indicates the current time and day. This clock is
also used to program the timer periods. Page 5.

I8:88

SuMoTuWeThFrSa

88

Morning

Fan On

4

1

1

5

10

1

1

4

3

Room Temperature Display
Indicates the current room temperature.

4

Desired Set Temperature
Indicates desired room temperature(s). Page 7.

Page 3

Display

5

6

7

8

9

10

Outside Indication
Indicates the temperature displayed is from
the optional outside sensor. Page 21.

Morning, Day, Evening & Night Indication
Indicates the program time period. Page 8-11.

Setup Indication
Indicates the thermostat is in the programming
mode. Page 12.

Fan Operation Indication
Fan On - indicates constant, continuous fan
operation.
When Fan On is not lit - indicates the fan will
only operate when necessary to heat or
to cool. Page 7.

Service Filter Indication
Service Filter indicates when the filter should
be serviced under normal conditions.
Appears after 0 - 1950 hours of blower
operation (adjustable). Page 15.

Locked Indication
Locked appears after the right combination of
buttons are pressed, rendering the buttons
inoperative. Page 19.

Page 4

Quick Start Set the Clock and Go

Press the Mode button.

MODE

FAN

I2:00

Su

While holding the Mode,
press the Fan button for
2 seconds to enter Setup
screens.

I

2

Press both Mode and

MODE

During Setup & Programming:
Pressing the Mode button
selects different flashing items.
(Represented in dark black)

Pressing the Up and Down
buttons will modify the flashing
selection.

Press

MODE

To adjust the

clock or Day use

buttons.

Fan buttons as
above to return to

FAN

normal operation.

The thermostat is preprogrammed from the
factory to operate 1 or 2 Stage equipment* without
the need for further programming. To optimize the
installation of this thermostat follow the instructions
in the Advanced Setup section.

* The thermostat is not preprogrammed from the

factory to operate electric heat or heat pump systems.
To control these systems, follow the steps in the
Advanced Setup section, pages 12 - 15.

Page 5

Basic Operation

Select Mode

The HEAT setting indicates the

temperature the room has to
reach before the furnace will

turn on to heat the room.

The COOL setting indicates the

temperature the room has to

reach before the air conditioner

will turn on to cool the room.

AUTO will automatically select

heat or cool based on room

temperature demand.

Program On will activate the

stored timer operation.
(Morning, Day, Evening

& Night periods.)

OFF indicates both heating

and air conditioning

systems are turned off.

Pm

I2:00

Mo

70

Pm

I2:00

Mo

70

Pm

I2:00

Mo

70

Pm

I2:00

Mo

70

ProgramOn

Pm

I2:00

Mo

70

Night

HEAT

69
72

COOL

72

COOL

AUTO

HEAT

69

73

COOL

HEAT

70

OFF

Press

MODE

Press

MODE

Press

MODE

Press

MODE

Page 6

Basic Operation

Select Desired Temperature

I2:00

Mo

70

Pm

72

COOL

AUTO

HEAT

In any mode, adjust the

desired Set Temperature

with

buttons.

69

Pressing the Up or Down buttons in Auto mode will adjust both the heat and cool
set temperatures simultaneously.
Pressing the Up or Down buttons in Heat or Cool modes will adjust only the
heat or cool set temperature.

Fan

Operation

I2:00

Su

Pm

65

FAN ON

85

COOL

HEAT

55

Press

FAN

Fan On indicates constant fan operation.
This feature is active even if the thermostat
is set to Off.

Page 7
