Bryant 550A User Manual

DELUXE 13 SEER AIR CONDITIONER WITH PURON

Bryant’s Air Conditioners with Puron® refrigerant provide a collection of features unmatched by any other family of equipment. The 550A family has been designed utilizing Bryant’s Puron refrigerant. The environmentally sound refrigerant allows you to make a responsible decision in the protection of the earth’s ozone layer. Bryant’s 550A system meets the Energy Star® guidelines for energy efﬁciency.

FEATURES

Puron Environmentally Sound Refrigerant —Is Bryant’s

refrigerant designed to help protect the environment. Puron is an HFC refrigerant which does not contain chlorine that can harm the ozone layer. The most important advantage of Puron refrigerant is that it has not been banned in future air conditioning systems as the traditional refrigerant R-22 has been. Puron refrigerant is in service in thousands of systems proving highly reliable, environmentally sound performance.

Bryant’s Evolution™ Controls —These industry-leading con-

trols, when installed with Bryant’s Perfect Humidity™ variablespeed furnaces or fan coils, provide the homeowner with:

–unparalleled control of temperature, humidity, indoor air quality, and zoning

–unprecedented ease of use –simple operation through on-screen, text-based service

reminders Optional remote access through telephone or Internet is also

available when combined with a remote connectivity kit.

Heavy Duty Inlet Grille —The DuraGuard™ coil protector,

made of a coated steel wire grid with vertical 3/8 in. spacing, is designed to help protect the coil from inclement weather, vandalism, and incidental damage. It provides protection while not restricting airﬂow and maintaining ease of coil inspection and cleaning.

High Efﬁciency Performance —Is delivered through a combi-

nation of features including Bryant’s Puron refrigerant, unique scroll compressor, and advanced heat transfer surfaces. Efﬁciency ratings are 13 SEER (Seasonal Energy Efﬁciency Ratio) with enhanced ratings of up to 14.5 SEER. Sophisticated heat transfer surfaces utilized in Bryant’s 550A design allow heat to easily be transferred to the outdoor air and require less energy. The unique scroll compressor found in the 550A design performs quietly and adds to the overall efﬁciency of the system. For improved serviceability, all models are equipped with a compressor terminal plug. Finally, Bryant’s Puron refrigerant operates more efﬁciently than ordinary R-22 refrigerant found in other systems. The efﬁciency levels provided by the 550A provide end users with lower costs of operation than traditional air conditioning systems.

Assured Future Service —By utilizing the environmentally

sound refrigerant, Puron, 550A models will remain serviceable well into the future. The Clean Air Act of 1990 has placed a cap

REFRIGERANT

550A

Sizes 024 thru 060

on production of most other refrigerants which has scheduled reductions beginning in 2004. The resulting cap in production ultimately results in a complete ban on many other refrigerants in new equipment by the year 2010. These changes required by federal law, mean the supply of other refrigerants may be limited in the near future making Puron refrigerant the correct choice when considering long term serviceability.

Highly Reliable Performance —Is delivered through the supe-

rior design of the system and componentry. The reliability of the 550A models has been proven to provide the lowest incidence of warranty service of any product in the Bryant family in the past three years of service. Long term reliability is assured through the use of both high and low pressure switches which will not allow the system to operate in the event of a signiﬁcant change in operating pressure. In doing this, the system is protected from damage if an unusual condition arises. Finally, Bryant includes a special liquid line ﬁlter drier designed to trap moisture and contaminants which could otherwise shorten the life of the system.

Bryant’s AeroQuiet System —Is one of the most sought after

features of the 550A family. Extremely low operating sound is the result of special attention to the air moving through the outdoor unit, a specially designed sound enclosure surrounding the compressor, and an exclusive laminated plate beneath the compressor to eliminate sound transmission to the rest of the system.

Application Versatility —Bryant’s systems utilizing Puron

refrigerant have the same application guidelines as other systems. Applications which include long line sets (50 to 175 ft) or applications which require the system to operate at low outdoor temperatures (below 55°F) are approved under Bryant’s standard guidelines.

Bryant Coils and Fan Coils to Complete the System —Bryant

specially designs both the outdoor product and indoor coil products to operate with assured reliability and performance. A wide range of indoor coil options are listed in the ratings sections of this publication.

Special Protective Devices —High and low pressure switches

and internal protection in the compressor including temperature and current sensing overloads prevent operation under potentially damaging circumstances. A special liquid line ﬁlter drier designed to trap nearly 4 times the volume of contaminants of standard driers provides superior protection from moisture trapped in the system.

Electrical Range —208/230v, single phase.

Wide Range of Sizes —Available in six sizes; 2, 2-1/2, 3, 3-1/2,

4, and 5 ton.

Cabinet —Galvanized steel is coated with powder paint to pro-

vide superior long-lasting protection and appearance.

Totally Enclosed Fan Motor —Protected from adverse weather

conditions.

Unit Design —Enhanced copper and aluminum heat transfer

surfaces with vertical air discharge to direct air up and away from the area.

External Service Valves —Both service valves are back seating

type valves which are externally located. These unique valves allow service technicians to evacuate or charge the system in less time than standard service valves.

Easy Serviceability —Removal of one panel provides access to

both electrical and refrigerant carrying components simplifying installation and service.

Agency Approvals —550A models are listed with UL (U.S. and

Canada), ARI, and CEC. Special endorsements have also been awarded these products by Energy Star® which recognizes energy efﬁcient products.

Limited Warranty —A standard ﬁve year warranty on parts

with extended warranty coverage on the compressor for a total of 10 years. A ﬁve year warranty is offered on the outdoor coil. Optional warranties are available through your Bryant distributor.

Form No. PDS 550A.24.10

PANEL

ACCESS

/8" DIA.

/8" DIA. KNOCKOUT

FIELD POWER SUPPLY CONN.

AND 1

HOLE WITH 1

DIMENSIONS

MOUNTING

PAD DIMENSIONSABCDEFGHJK LMN

A99067

/4"

/2"

/16"

/2"

AIR DISCHARGE

/8" DIA. TIEDOWN KNOCKOUTS

(2) PLACES

LINE CONN.

H DIA. VAPOR

/8" DIA. HOLE

FIELD CONTROL

SUPPLY CONN

/8" DIA. LIQUID

LINE CONN.

/16"

/4"

UNIT DIMENSIONS MINIMUM

DIMENSIONS (IN.)

NOTES:

1. ALLOW 30" CLEARANCE TO SERVICE SIDE OF UNIT, 48" ABOVE UNIT, 6" ON ONE

SIDE, 12" ON REMAINING SIDE, AND 24" BETWEEN UNITS FOR PROPER AIRFLOW.

2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING MODE IS 55°F,

(UNLESS LOW AMBIENT CONTROL IS USED) MAX. 125°F.

3. SERIES DESIGNATION IS THE 14TH POSITION OF THE UNIT MODEL NUMBER.

4. CENTER OF GRAVITY .

AIR IN

AIR DISCHARGE

AIR IN

AIR DISCHARGE

—2—

SIZE SERIES

UNIT

024 G 27-13/16 30 33 5-1/16 9-11/16 15-15/16 22-3/8 5/8 8-3/16 17 19-3/4 13 2-15/16 26 x 32

030 F 27-13/16 30 33 5-1/16 9-11/16 15-15/16 22-3/8 3/4 8-3/16 18-1/2 19-3/4 13 2-15/16 26 x 32

036 F, G 33-13/16 30 33 5-1/16 9-11/16 21-15/16 28-3/8 3/4 8-3/16 17 19-3/4 15-3/4 2-15/16 26 x 32

042 F 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 8-3/16 17-3/4 19 17-3/4 2-15/16 26 x 32

048 F 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 8-3/16 16-3/4 19-1/2 17-1/4 2-15/16 26 x 32

060 H 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 8-3/16 16-1/2 19 16-3/4 2-15/16 26 x 32

RECOMMENDED TUBE DIAMETERS

Liquid Tube Diameter (In.) Vapor Tube Diameter (In.)

UNIT SIZE

024 030, 036 3/4 7/8 042, 048 7/8 1-1/8

060 1-1/8 1-1/8

*For tube sets greater than 50 ft horizontal and/or 20 ft vertical differential, consult Residential Split System Application Guideline and Service Manual.

0 to 50 Ft

Tube Length Long-Line Applications*

3/8 3/8

0 to 50 Ft

Tube Length

Long-Line Applications*

(Maximum Diameter)

5/8 7/8

CHECK-FLO-RATER® PISTON

UNIT SIZE–SERIES

024-G 55

030-F 63

036-F, G 70

042-F 73 048-F 78

060-H TXV

*Piston listed is for any approved non-capillary tube coil combination. Piston is shipped with outdoor unit and must be installed in an approved indoor coil.

PISTON*

IDENTIFICATION NO.

MODEL NUMBER NOMENCLATURE

550A N X 024

Model Number

13 SEER Split-System Air Conditioner

Electrical Supply N – 208/230-1-60

Nominal Cooling Capacity 024 – 2 ton 042 – 3.5 ton 030 – 2.5 ton 048 – 4 ton 036 – 3 ton 060 – 5 ton

CHARGING SUBCOOLING (TXV-TYPE EXPANSION DEVICE*)

UNIT SIZE–SERIES REQUIRED SUBCOOLING (°F)

024-G 10 030-F 12

036-F, G 11

042-F 12 048-F 11 060-H 12

* Must be a Puron® approved hard shutoff TXV.

000 A A AA

N/A

Common Unit – U.S.A. Only

Heating Size

Standard Unit

Series A – Original Series Series B – Second Series, etc.

CERTIFICATION APPLIES ONLY

WHEN THE COMPLETE SYSTEM

IS LISTED WITH ARI.

As an ENERGY STAR® partner, Bryant Heating &

Cooling Systems has determined that this product meets the ENERGY STAR® guidelines for energy efﬁciency.

ISO 9001:2000

REGISTERED

REGISTERED QUALITY SYSTEM

*Refer to the combination ratings in the Product Data Sheet for system combinations meeting ENERGY STAR® efﬁciency standards.

—3—

SPECIFICATIONS

UNIT SIZE-SERIES 024-G 030-F 036-F/G

Operating Weight (Lb) 214 202 237

ELECTRICAL

Unit Volts—Hertz—Phase 208/230—60—1

Operating Voltage Range* 187—253

Compressor— Rated Load Amps 12.8 14.7 15.4/16.7

Locked Rotor Amps 60.0 72.5 83.0/79.0

Condenser Fan Motor—Full Load Amps 0.80 0.80 1.1

Min Unit Ampacity for Wire Sizing 16.8 19.2 20.2/22.0

Min Wire Size (60°C Copper) AWG† 14 14 12

Min Wire Size (75°C Copper) AWG† 14 14 12

Max Wire Length (Ft) (60°C Copper)‡ 46 41 62/57

Max Wire Length (Ft) (75°C Copper)‡ 44 39 59/54

Max Branch Circuit Fuse or

Circuit Breaker Size (Amps) 25 30 30

COMPRESSOR & REFRIGERANT

Compressor— Type Scroll

Temperature & Current Protection Internal Line Break

Refrigerant— Type Puron® (R-410A)

Amount (Lb) 5.50 6.00 6.88

CONDENSER COIL & FAN

Coil Face Area (Sq Ft) 12.2 12.2 15.2

Fins per In.—Rows—Circuits 25—1—2 25—1—2 25—1—2

Fan Motor—HP (PSC) & RPM 1/8 & 825 1/8 & 825 1/5 & 825

Volts—Her tz—Phase 208/230—60—1

Condenser Airﬂow (CFM) 2400 2400 2800

OPTIONAL EQUIPMENT

Support Feet KSASF0101AAA

Coastal Filter KAACF0801MED Time Delay Relay KAATD0101TDR

Cycle Protector KSACY0101AAA

Crankcase Heater KAACH1201AAA

Start Assist—Capacitor/Relay Type KSAHS1501AAA

Start Assist—PTC Type Standard KAACS0201PTC

TXV (Hard Shutoff) KSATX0201PUR KSATX0301PUR

Piston Body KSAPX0101PIS

Filter Drier (Suction Line) KH45LG140 (RCD)

Evaporator Freeze Thermostat** KAAFT0101AAA

Liquid-Line Solenoid Valve KAALS0201LLS

Winter Start Control** KAAWS0101AAA

Low-Ambient Pressure Switch KSALA0301410

MotorMaster® Low-Ambient Controller †† KSALA0401AAA

Ball Bearing Fan Motor HC38GE231 (RCD)

Thermidistat™ Control—

Programmable Thermostat with Humidity Control TSTATBBPRH01-B

Thermostat—Auto Changeover,

7-Day Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBPAC01-B

Thermostat—Auto Changeover,

Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBNAC01-C

Thermostat—Manual Changeover

5-2 Day Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBSAC01

Builder’s Thermostat—Manual Changeover,

Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBBAC01-B

Outdoor Air Temperature Sensor TSTATXXSEN01-B

Backplate for Non-Programmable Thermostat TSTATXXNBP01

Backplate for Programmable Thermostat TSTATXXPBP01

Backplate for Builder’s Thermostat TSTATXXBBP01

Backplate for Standard Thermostat TSTATXXSBP01

Thermostat Conversion Kit (4 to 5 wire)—10 Pack TSTATXXCNV10

Evolution Controls See chart.

See notes on page 5. .

—4—

SPECIFICATIONS Continued

UNIT SIZE-SERIES 042-F 048-F 060-H

Operating Weight (Lb) 247 295 331

ELECTRICAL

Unit Volts—Hertz—Phase 208/230—60—1

Operating Voltage Range* 187—253

Compressor— Rated Load Amps 18.6 20.5 27.6

Locked Rotor Amps 105.0 109.0 158.0

Condenser Fan Motor—Full Load Amps 1.1 1.4 1.4

Min Unit Ampacity for Wire Sizing 24.4 27.0 35.9

Min Wire Size (60°C Copper) AWG† 10 10 8

Min Wire Size (75°C Copper) AWG† 10 10 8

Max Wire Length (Ft) (60°C Copper)‡ 80 73 85

Max Wire Length (Ft) (75°C Copper)‡ 76 70 80

Max Branch Circuit Fuse or

Circuit Breaker Size (Amps) 40 40 60

COMPRESSOR & REFRIGERANT

Compressor— Type Scroll

Temperature & Current Protection Internal Line Break

Refrigerant— Type Puron® (R-410A)

Amount (Lb) 8.75 10.13 11.50

CONDENSER COIL & FAN

Coil Face Area (Sq Ft) 18.2 18.2 18.2

Fins per In.—Rows—Circuits 25—1—3 20—2—5 20—2—5

Fan Motor—HP (PSC) & RPM 1/5 & 825 1/4 & 1125 1/4 & 1125

Volts—Her tz—Phase

Condenser Airﬂow (CFM) 2800

OPTIONAL EQUIPMENT

Support Feet KSASF0101AAA

Coastal Filter KAACF0801MED Time Delay Relay KAATD0101TDR

Cycle Protector KSACY0101AAA

Crankcase Heater KAACH1201AAA

Start Assist—Capacitor/Relay Type KSAHS1501AAA KSAHS1601AAA

Start Assist—PTC Type KAACS0201PTC

TXV (Hard Shutoff) KSATX0301PUR KSATX0401PUR KSATX0501PUR

Piston Body KSAPX0101PIS

Filter Drier (Suction Line) KH45LG141 (RCD)

Evaporator Freeze Ther mostat** KAAFT0101AAA

Liquid-Line Solenoid Valve KAALS0201LLS

Winter Start Control** KAAWS0101AAA

Low-Ambient Pressure Switch KSALA0301410

MotorMaster® Low-Ambient Controller †† KSALA0401AAA

Ball Bearing Fan Motor HC38GE231 (RCD) HC40GE232 (RCD)

Thermidistat™ Control—

Programmable Thermostat with Humidity Control TSTATBBPRH01-B

Thermostat—Auto Changeover, 7-Day Programmable,

°F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBPAC01-B

Thermostat—Auto Changeover, Non-Programmable,

°F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBNAC01-C

Thermostat—Manual Changeover, 5-2 Day Programmable,

°F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBSAC01

Builder’s Thermostat—Manual Changeover,

Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBBAC01-B

Outdoor Air Temperature Sensor TSTATXXSEN01-B

Backplate for Non-Programmable Thermostat TSTATXXNBP01

Backplate for Programmable Thermostat TSTATXXPBP01

Backplate for Builder’s Thermostat TSTATXXBBP01

Backplate for Standard Thermostat TSTATXXSBP01

Thermostat Conversion Kit (4 to 5 wire)—10 Pack TSTATXXCNV10

Evolution Controls See chart.

*Permissible limits of the voltage range at which the unit will operate satisfactorily. Operation outside these limits may result in unit failure.

† If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70).

The ampacity of nonmetallic-sheathed cable (NM), trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-26. If other than uncoated (non-plated), 60 or 75°C (140 or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).

‡ Length shown is as measured 1 way along wire path between unit and service panel for a voltage drop not to exceed 2%.

** See low-ambient controller Installation Instructions for application. †† Fan motor with ball bearings required. N/A — Not Applicable.

NOTE: Copper wire must be used from service disconnect to unit. All motors/compressors contain internal overload protection.

—5—

208/230—60—1

3400 3400

EVOLUTION™* CONTROLS

DESCRIPTION ACCESSORY

Evolution Control Deluxe 7-Day Programmable (Wall-mounted system control.) SYSTXBBUID01

Evolution Zone Control Deluxe Zoning 7-Day Programmable (Wall-mounted control for a

multi-zone system.)

Evolution 4-Zone Damper Control Module (Wall-mounted control for a four-zone system.) SYSTXBB4ZC01

Evolution Smart Sensor (Optional wall control used to monitor temperature and/or fan control in an individual zone.)

Evolution Remote Room Sensor (Monitors temperature in an individual zone.) SYSTXBBRRS01

Evolution System Access Module (Hardware for wireless access and control via phone or internet.)

Evolution Network Interface Module (Connects Heat Recovery or Energy Recovery Ventilators or older two-speed outdoor models to system.)

Back Plate for Evolution Control (Decorative wall plate.) SYSTXXXBPU01

SYSTXBBUIZ01

SYSTXBBSMS01

SYSTXBBSAM01

SYSTXBBNIM01†

* When applied with Bryant’s Perfect Humidity™ series 355, 315 and FE Indoor Models.

† Must be installed in Dual-Fuel Evolution system applications.

ACCESSORY USAGE GUIDELINE

REQUIRED FOR

LOW-AMBIENT

ACCESSORY

Crankcase Heater Yes Yes No

Evaporator Freeze Thermostat Yes No No

Winter Start Control Yes† No No

Accumulator No No No

Compressor Start Assist

Capacitor and Relay

MotorMaster® Low-Ambient Controller

Low-Ambient Pressure Switch

Wind Bafﬂe See Low-Ambient Instructions No No

Coastal Filter No No Yes

Support Feet Recommended No Recommended

Liquid-Line Solenoid Valve

Hard Shutoff TXV

Ball Bearing Fan Motor Yes‡ No No

APPLICATIONS

(Below 55°F)

Ye s Yes No

Ye s N o N o

*For tubing line sets greater than 50 ft horizontal and/or 20 ft vertical differential, refer to Residential Split-System Long-Line Application Guideline

and Service Manual. † Only when low-pressure switch is used. ‡ Required for MotorMaster® Control only.

REQUIRED FOR

LONG-LINE

APPLICATIONS*

(Over 50 Ft)

See Long-Line

Application

Guideline

REQUIRED FOR

SEA COAST APPLICATIONS (Within 2 Miles)

ACCESSORY DESCRIPTION AND USAGE (Listed Alphabetically)

Ball-Bearing Fan Motor

A fan motor with ball bearings which permits speed reduction while maintaining bearing lubrication.

Usage Guideline:

Coastal Filter

A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from salt damage without restricting airflow.

Compressor Start Assist – Capacitor and Relay

Start capacitor and relay gives a "hard" boost to compressor motor at each start up.

Usage Guideline:

Compressor Start Assist — PTC Type

Solid state electrical device which gives a "soft" boost to the reciprocating compressor at each start-up.

Usage Guideline:

Required on all units when low-ambient controller (full modulation feature) or MotorMaster®—Low-Ambient Controller is installed.

Required for reciprocating

Long line Low ambient Hard shut off expansion valve on indoor coil Liquid line solenoid on indoor coil

Required for scroll

Long line Low ambient

Suggested for all compressors in areas with a history of low voltage problems.

Suggested in installations with marginal power supply.

compressors in the following applications:

—6—

ACCESSORY DESCRIPTION AND USAGE (Listed Alphabetically)

Crankcase Heater

An electric resistance heater which mounts to the base of the compressor to keep the lubricant warm during off cycles. Improves compressor lubrication on restart and minimizes the chance of liquid slugging.

Usage Guideline:

Evaporator Freeze Thermostat

An SPST temperature-actuated switch that stops unit operation when evaporator reaches freeze-up conditions.

Usage Guideline:

Liquid-Line Solenoid Valve (LLS)

This device serves two purposes. It is an electrically operated shutoff valve which stops and starts refrigerant liquid flow in response to compressor operation. It maintains a column of refrigerant liquid ready for action at next compressor operation cycle. It also provides system protection against off-cycle refrigerant migration.

Note: When LLS is used with reciprocating compressors, Compressor Start Assist — Capacitor and Relay is required.

Usage Guideline:

MotorMaster®—Low-Ambient Controller

A fan-speed control device activated by a temperature sensor, designed to control condenser fan motor speed in response to the saturated, condensing temperature during operation in cooling mode only. For outdoor temperatures down to –20°F (–28.9°C), it maintains condensing temperature at 100°F ± 10°F (37.8°C ± –12°C).

Usage Guideline:

Outdoor Air Temperature Sensor

Designed for use with Bryant Thermostats listed in this publication. This device enables the thermostat to display the outdoor temperature. This device also is required to enable special thermostat features such as auxiliary heat lock out.

Usage Guideline:

10.

Sound Hood

Wraparound sound reducing cover for the compressor. Reduces the sound level by about 2 dBA.

Usage Guideline:

11.

Support Feet

Four stick-on plastic feet that raise the unit 4 in. above the mounting pad. This allows sand, dirt, and other debris to be flushed from the unit base, minimizing corrosion.

Usage Guideline:

12.

Thermostatic Expansion Valve (TXV)

A modulating flow-control valve which meters refrigerant liquid flow rate into the evaporator in response to the superheat of the refrigerant gas leaving the evaporator. Kit includes valve, adapter tubes, and external equalizer tube. Hard shut off types are available.

Note: When using a hard shut off TXV with single phase reciprocating compressors, a Compressor Start Assist — Capacitor and Relay is required.

Usage Guideline:

13.

Time-Delay Relay

An SPST delay relay which briefly continues operation of indoor blower motor to provide additional cooling after the compressor cycles off.

Note: Most indoor unit controls include this feature. For those that do not, use the guideline below.

Usage Guideline:

Required in low ambient applications. Required in long line applications. Suggested in all commercial applications.

Required when low ambient kit has been added.

Required in air conditioner long line applications with a piston indoor metering device to prevent off cycle refrigerant migration. A hard shut off TXV can be used instead of an LLS in single flow air conditioner applications. See Long Line Application Guideline.

A MotorMaster®—Low Ambient Controller or Low-Ambient Pressure Switch must be used when cooling operation is used at outdoor temperatures below 55°F (12.8°C). Suggested for all commercial applications.

Suggested for all Bryant thermostats listed in this publication.

Suggested when unit is installed closer than 15 ft to quiet areas—bedrooms, etc. Suggested when unit is installed between two houses less than 10 ft apart.

Suggested in the following applications:

Coastal installations. Windy areas or where debris is normally circulating. Rooftop installations. For improved sound ratings.

Required to achieve ARI ratings in certain equipment combinations. Refer to combination ratings. Hard shut off TXV or LLS required in air conditioner long line applications Required for use on all zoning systems.

For improved efficiency ratings for certain combinations of indoor and outdoor units. Refer to ARI Unitary Directory..

A-WTD. SOUND POWER (dBA)

UNIT SIZE-

SERIES

024-G 72 61.0 60.5 63.5 66.5 63.0 57.0 49.5 030-F 70 57.5 60.0 64.0 66.0 62.0 58.5 53.5

036-F, G 72 58.5 60.5 65.0 65.0 62.0 59.0 52.5

042-F 72 55.5 62.5 66 65.5 63.5 62.0 55.5 048-F 76 62.0 67.5 70.0 69.5 67.5 66.0 60.5 060-H 78 66.0 68.0 71.5 72.5 70.5 65.0 59.5

NOTE: Tested in accordance with ARI standard 270.95. (Not listed with ARI.)

STANDARD

RATING

125 250 500 1000 2000 4000 8000

TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)

—7—

COMBINATION RATINGS

UNIT

SIZE-SERIES

024-G

See notes on page 22.

FAC TORY-

TOT.

INDOOR

MODEL

*CC5A/CD5AA030 23,000 NONE — 13.00 13.00 11.25

CC5A/CD5AA024 22,800 NONE — 12.50 12.50 11.15 CC5A/CD5AW024 22,800 NONE — 12.50 12.50 11.15 CC5A/CD5AW030 23,000 NONE — 13.00 13.00 11.25

CE3AA024 22,800 NONE — 12.50 12.50 11.25 CE3AA030 23,000 NONE — 13.00 13.00 11.35 CF5AA024 22,800 NONE — 12.50 12.50 11.15 CK3BA024 22,800 NONE — 12.50 12.50 11.30

CK3BA030 23,000 NONE — 13.00 13.00 11.35 CK5A/CK5BA024 22,800 NONE — 12.50 12.50 11.30 CK5A/CK5BA030 23,000 NONE — 13.00 13.00 11.35 CK5A/CK5BW024 22,800 NONE — 12.50 12.50 11.30 CK5A/CK5BW030 23,000 NONE — 13.00 13.00 11.35

CK5PA024 22,800 TXV — 12.50 — 11.30

CK5PA030 23,000 TXV — 13.00 — 11.35

CK5PW024 22,800 TXV — 12.50 — 11.30

CK5PW030 23,000 TXV — 13.00 — 11.35 F(A,B)4BN(F,C)024 23,000 TDR 13.00 — 13.00 11.40 F(A,B)4BN(F,C)030 23,400 TDR 13.00 — 13.00 11.50

FC4CNF024 23,000 TDR&TXV 13.00 — — 11.40 FC4CNF030 23,400 TDR&TXV 13.00 — — 11.55 FE4ANF002 23,600 TDR&TXV 14.50 — — 12.85 FE4ANF003 23,600 TDR&TXV 14.50 — — 13.00 FF1DNA024 23,000 TDR 12.50 — 12.50 11.20 FF1DNA030 23,400 TDR 13.00 — 13.00 11.35 FF1DNE024 23,000 TDR&TXV 12.50 — — 11.20 FF1DNE030 23,400 TDR&TXV 13.00 — — 11.35 FG3AAA024 22,000 NONE — 12.50 12.50 11.00 FK4DNF001 23,400 TDR&TXV 14.00 — — 12.65 FK4DNF002 23,600 TDR&TXV 14.50 — — 12.85 FK4DNF003 23,600 TDR&TXV 14.50 — — 13.00 FV4BNF002 23,600 TDR&TXV 14.50 — — 12.85 FV4BNF003 23,600 TDR&TXV 14.50 — — 13.00 FX4BNF030 23,400 TDR&TXV 13.00 — — 11.70

CC5A/CD5AA024 22,400 TDR 14.00 — 14.00 12.15

CC5A/CD5AA030 22,800 TDR 14.00 — 14.00 12.35 CC5A/CD5AW024 22,400 TDR 14.00 — 14.00 12.20 CC5A/CD5AW030 22,800 TDR 14.00 — 14.00 12.35

CE3AA024 22,400 TDR 14.00 — 14.00 12.25 CE3AA030 22,800 TDR 14.00 — 14.00 12.45 CK3BA024 22,400 TDR 14.00 — 14.00 12.50

CK3BA030 22,800 TDR 14.00 — 14.00 12.55 CK5A/CK5BA024 22,400 TDR 14.00 — 14.00 12.35 CK5A/CK5BA030 22,800 TDR 14.00 — 14.00 12.45 CK5A/CK5BW024 22,400 TDR 14.00 — 14.00 12.35 CK5A/CK5BW030 22,800 TDR 14.00 — 14.00 12.50

CK5PA024 22,400 TDR&TXV 14.00 — — 12.25

CK5PA030 22,800 TDR&TXV 14.00 — — 12.35

CK5PW024 22,400 TDR&TXV 14.00 — — 12.25 CK5PW030 22,800 TDR&TXV 14.00 — — 12.40

CC5A/CD5AA024 22,400 TDR 14.00 — 14.00 12.25 CC5A/CD5AA030 22,800 TDR 14.00 — 14.00 12.50

CC5A/CD5AW024 22,400 TDR 14.00 — 14.00 12.35 CC5A/CD5AW030 22,800 TDR 14.00 — 14.00 12.50

CE3AA024 22,400 TDR 14.00 — 14.00 12.35

CE3AA030 22,800 TDR 14.00 — 14.00 12.55

CK3BA024 22,400 TDR 14.00 — 14.00 12.60

CK3BA030 22,800 TDR 14.00 — 14.00 12.65 CK5A/CK5BA024 22,400 TDR 14.00 — 14.00 12.45 CK5A/CK5BA030 22,800 TDR 14.00 — 14.00 12.55 CK5A/CK5BW024 22,400 TDR 14.00 — 14.00 12.45 CK5A/CK5BW030 22,800 TDR 14.00 — 14.00 12.60

CK5PA024 22,400 TDR&TXV 14.00 — — 12.35

CK5PA030 22,800 TDR&TXV 14.00 — — 12.50

CK5PW024 22,400 TDR&TXV 14.00 — — 12.40 CK5PW030 22,800 TDR&TXV 14.00 — — 12.55

CC5A/CD5AW024 22,400 TDR 14.00 — 14.00 12.25 CC5A/CD5AW030 22,800 TDR 14.00 — 14.00 12.40

CE3AA024 22,400 TDR 14.00 — 14.00 12.20

CE3AA030 22,800 TDR 14.00 — 14.00 12.50

CK3BA024 22,400 TDR 14.00 — 14.00 12.55

CK3BA030 22,800 TDR 14.00 — 14.00 12.60 CK5A/CK5BW024 22,400 TDR 14.00 — 14.00 12.35 CK5A/CK5BW030 22,800 TDR 14.00 — 14.00 12.55

CK5PW024 22,400 TDR&TXV 14.00 — — 12.30 CK5PW030 22,800 TDR&TXV 14.00 — — 12.45

CE3AA024 22,400 TDR 14.00 — 14.00 12.25

CE3AA030 22,800 TDR 14.00 — 14.00 12.50

CAP.

BTUH

COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—8—

UNIT

SIZE-SERIES

024-G

030-F

See notes on page 22.

COMBINATION RATINGS Continued

FAC TORY-

TOT.

INDOOR

MODEL

CE3AA024 22,400 TDR 14.00 — 14.00 12.30 CE3AA030 22,800 TDR 14.00 — 14.00 12.55

CE3AA024 22,400 TDR 14.00 — 14.00 12.20 CE3AA030 22,800 TDR 14.00 — 14.00 12.45

CC5A/CD5AA024 22,400 TDR 14.00 — 14.00 12.15

CC5A/CD5AA030 22,800 TDR 14.00 — 14.00 12.40 CC5A/CD5AW024 22,400 TDR 14.00 — 14.00 12.25 CC5A/CD5AW030 22,800 TDR 14.00 — 14.00 12.40

CE3AA024 22,400 TDR 14.00 — 14.00 12.25 CE3AA030 22,800 TDR 14.00 — 14.00 12.45 CK3BA024 22,400 TDR 14.00 — 14.00 12.55

CK3BA030 22,800 TDR 14.00 — 14.00 12.60 CK5A/CK5BA024 22,400 TDR 14.00 — 14.00 12.35 CK5A/CK5BA030 22,800 TDR 14.00 — 14.00 12.45

CK5A/CK5BW024 22,400 TDR 14.00 — 14.00 12.40 CK5A/CK5BW030 22,800 TDR 14.00 — 14.00 12.55

CK5PA024 22,400 TDR&TXV 14.00 — — 12.30

CK5PA030 22,800 TDR&TXV 14.00 — — 12.40 CK5PW024 22,400 TDR&TXV 14.00 — — 12.30 CK5PW030 22,800 TDR&TXV 14.00 — — 12.45

CC5A/CD5AW024 22,400 TDR 14.00 — 14.00 12.20 CC5A/CD5AW030 22,800 TDR 14.00 — 14.00 12.35

CE3AA024 22,400 TDR 14.00 — 14.00 12.20 CE3AA030 22,800 TDR 14.00 — 14.00 12.45 CK3BA024 22,400 TDR 14.00 — 14.00 12.50

CK3BA030 22,800 TDR 14.00 — 14.00 12.55 CK5A/CK5BW024 22,400 TDR 14.00 — 14.00 12.35 CK5A/CK5BW030 22,800 TDR 14.00 — 14.00 12.50

CK5PW024 22,400 TDR&TXV 14.00 — — 12.30 CK5PW030 22,800 TDR&TXV 14.00 — — 12.40

CC5A/CD5AW024 22,400 TDR 14.00 — 14.00 12.25 CC5A/CD5AW030 22,800 TDR 14.00 — 14.00 12.40

CE3AA024 22,400 TDR 14.00 — 14.00 12.25

CE3AA030 22,800 TDR 14.00 — 14.00 12.45

CK3BA024 22,400 TDR 14.00 — 14.00 12.50

CK3BA030 22,800 TDR 14.00 — 14.00 12.55 CK5A/CK5BW024 22,400 TDR 14.00 — 14.00 12.40 CK5A/CK5BW030 22,800 TDR 14.00 — 14.00 12.50

CK5PW024 22,400 TDR&TXV 14.00 — — 12.30 CK5PW030 22,800 TDR&TXV 14.00 — — 12.45

CC5A/CD5AW024 22,400 TDR 14.00 — 14.00 12.25 CC5A/CD5AW030 22,800 TDR 14.00 — 14.00 12.40

CE3AA024 22,400 TDR 14.00 — 14.00 12.25

CE3AA030 22,800 TDR 14.00 — 14.00 12.50

CK3BA024 22,400 TDR 14.00 — 14.00 12.55

CK3BA030 22,800 TDR 14.00 — 14.00 12.60 CK5A/CK5BW024 22,400 TDR 14.00 — 14.00 12.40 CK5A/CK5BW030 22,800 TDR 14.00 — 14.00 12.50

CK5PW024 22,400 TDR&TXV 14.00 — — 12.30 CK5PW030 22,800 TDR&TXV 14.00 — — 12.45

CE3AA024 22,400 TDR 14.00 — 14.00 12.20

CE3AA030 22,800 TDR 14.00 — 14.00 12.45

*CC5A/CD5AA036 29,000 NONE — 13.00 13.00 11.20

CC5A/CD5AA030 28,000 NONE — 12.50 12.50 10.85 CC5A/CD5AW030 28,000 NONE — 12.50 12.50 10.85 CC5A/CD5AW036 29,000 NONE — 13.00 13.00 11.20

CE3AA030 28,000 NONE — 12.50 12.50 11.00 CE3AA036 28,400 NONE — 12.50 12.50 11.10

CF5AA036 28,400 NONE — 12.50 12.50 11.15 CK3BA030 28,000 NONE — 12.50 12.50 10.95 CK3BA036 29,000 NONE — 13.00 13.00 11.25

CK5A/CK5BA030 28,000 NONE — 12.50 12.50 10.95 CK5A/CK5BA036 29,000 NONE — 13.00 13.00 11.25

CK5A/CK5BT036 29,000 NONE — 13.00 13.00 11.25 CK5A/CK5BW030 28,000 NONE — 12.50 12.50 10.95 CK5A/CK5BW036 29,000 NONE — 13.00 13.00 11.25

CK5PA030 28,000 TXV — 12.50 — 10.95 CK5PA036 29,000 TXV — 13.00 — 11.25

CK5PT036 29,000 TXV — 13.00 — 11.25 CK5PW030 28,000 TXV — 12.50 — 10.95 CK5PW036 29,000 TXV — 13.00 — 11.25

F(A,B)4(A,B)N(F,C)030 28,600 TDR 12.50 — 12.50 11.10 F(A,B)4(A,B)N(F,C)036 29,000 TDR 12.50 — 12.50 10.95

FE4ANF002 29,000 TDR&TXV 13.50 — — 12.05 FE4ANF003 29,600 TDR&TXV 14.00 — — 12.55

CAP.

BTUH

COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE

COILS + 355MAV042040 VARIABLE-SPEED FURNACE

COILS + 355MAV042060 VARIABLE-SPEED FURNACE

COILS + 355MAV042080 VARIABLE-SPEED FURNACE

COILS + 355MAV060080 VARIABLE-SPEED FURNACE

COILS + 355MAV060100 VARIABLE-SPEED FURNACE

COILS + 355MAV060120 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

—9—

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

COMBINATION RATINGS Continued

UNIT

SIZE-SERIES

030-F

See notes on page 22.

FAC TORY-

TOT.

INDOOR

MODEL

FF1DNA030 28,600 TDR 12.50 — 12.50 11.05

FG3AAA036 28,400 NONE — 12.50 12.50 11.00 FK4(C,D)NF001 29,000 TDR&TXV 13.00 — — 11.95 FK4(C,D)NF002 29,000 TDR&TXV 13.50 — — 12.05 FK4(C,D)NF003 29,600 TDR&TXV 14.00 — — 12.40 FV4(A,B)NF002 29,000 TDR&TXV 13.50 — — 12.05 FV4(A,B)NF003 29,600 TDR&TXV 14.00 — — 12.55 FX4(A,B)NF030 28,600 TDR&TXV 12.50 — — 11.00 FX4(A,B)NF036 29,000 TDR&TXV 12.50 — — 10.95

CC5A/CD5AA030 28,000 TDR 13.50 — 13.50 11.65 CC5A/CD5AA036 29,000 TDR 14.00 — 14.00 12.00 CC5A/CD5AW030 28,000 TDR 13.50 — 13.50 11.65

CE3AA030 28,400 TDR 13.50 — 13.50 11.75 CE3AA036 28,600 TDR 13.50 — 13.50 11.85 CK3BA030 28,000 TDR 13.50 — 13.50 11.70

CK3BA036 29,000 TDR 14.00 — 14.00 12.05 CK5A/CK5BA030 28,000 TDR 13.50 — 13.50 11.70 CK5A/CK5BA036 29,000 TDR 14.00 — 14.00 12.05 CK5A/CK5BT036 29,000 TDR 14.00 — 14.00 12.05

CK5A/CK5BW030 28,000 TDR 13.50 — 13.50 11.70

CK5PA030 28,600 TDR&TXV 13.50 — — 11.70

CK5PA036 29,000 TDR&TXV 14.00 — — 12.05

CK5PT036 29,000 TDR&TXV 14.00 — — 12.05

CK5PW030 28,600 TDR&TXV 13.50 — — 11.70

CC5A/CD5AA030 28,000 TDR 13.50 — 13.50 11.80 CC5A/CD5AA036 29,000 TDR 14.00 — 14.00 12.15 CC5A/CD5AW030 28,000 TDR 13.50 — 13.50 11.80 CC5A/CD5AW036 29,000 TDR 14.00 — 14.00 12.15

CE3AA030 28,600 TDR 13.50 — 13.50 11.90

CE3AA036 28,800 TDR 13.50 — 13.50 12.05

CK3BA030 28,000 TDR 13.50 — 13.50 11.85

CK3BA036 29,000 TDR 14.00 — 14.00 12.20 CK5A/CK5BA030 28,000 TDR 13.50 — 13.50 11.85 CK5A/CK5BA036 29,000 TDR 14.00 — 14.00 12.20

CK5A/CK5BW030 28,600 TDR 13.50 — 13.50 11.85 CK5A/CK5BW036 29,000 TDR 14.00 — 14.00 12.20

CK5PA030 28,600 TDR&TXV 13.50 — — 11.80

CK5PA036 29,000 TDR&TXV 14.00 — — 12.20

CK5PT036 29,000 TDR&TXV 14.00 — — 12.20

CK5PW030 28,600 TDR&TXV 13.50 — — 11.80 CK5PW036 29,000 TDR&TXV 14.00 — — 12.20

CC5A/CD5AA036 29,000 TDR 14.00 — 14.00 12.40 CC5A/CD5AW030 28,000 TDR 13.50 — 13.50 12.05 CC5A/CD5AW036 29,000 TDR 14.00 — 14.00 12.45

CE3AA030 28,600 TDR 13.50 — 13.50 12.15

CE3AA036 29,000 TDR 14.00 — 14.00 12.30

CK3BA030 28,600 TDR 13.50 — 13.50 12.20

CK3BA036 29,000 TDR 14.00 — 14.00 12.45 CK5A/CK5BA036 29,000 TDR 14.00 — 14.00 12.45 CK5A/CK5BT036 29,000 TDR 14.00 — 14.00 12.45

CK5A/CK5BW030 28,600 TDR 13.50 — 13.50 12.15 CK5A/CK5BW036 29,000 TDR 14.00 — 14.00 12.50

CK5PA036 29,000 TDR&TXV 14.00 — — 12.45

CK5PT036 29,000 TDR&TXV 14.00 — — 12.45

CK5PW030 28,600 TDR&TXV 13.50 — — 12.15 CK5PW036 29,000 TDR&TXV 14.00 — — 12.50

CC5A/CD5AW036 29,000 TDR 14.00 — 14.00 12.55

CE3AA030 28,600 TDR 13.50 — 13.50 12.25

CE3AA036 29,000 TDR 14.00 — 14.00 12.40

CK5A/CK5BW036 29,000 TDR 14.00 — 14.00 12.60

CK5PW036 29,000 TDR&TXV 14.00 — — 12.60

CC5A/CD5AW036 29,000 TDR 14.00 — 14.00 12.60

CE3AA030 28,600 TDR 13.50 — 13.50 12.30

CE3AA036 29,000 TDR 14.00 — 14.00 12.45

CK5A/CK5BW036 29,000 TDR 14.00 — 14.00 12.65

CK5PW036 29,000 TDR&TXV 14.00 — — 12.65

CC5A/CD5AW030 28,400 TDR 13.20 — 13.20 11.55 CC5A/CD5AW036 29,600 TDR 13.50 — 13.50 11.90

CE3AA030 29,000 TDR 13.50 — 13.50 11.70

CE3AA036 29,200 TDR 13.50 — 13.50 11.75

CK3BA030 28,400 TDR 13.00 — 13.00 11.45

CK3BA036 29,600 TDR 13.50 — 13.50 11.95

CK5A/CK5BW030 28,400 TDR 13.00 — 13.00 11.45 CK5A/CK5BW036 29,600 TDR 13.50 — 13.50 11.95

CK5PW030 28,400 TDR&TXV 13.00 — — 11.45 CK5PW036 29,600 TDR&TXV 13.50 — — 11.95

CAP.

BTUH

COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE

COILS + 355MAV042040 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas

Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—10—

UNIT

SIZE-SERIES

030-F

036-F

See notes on page 22.

COMBINATION RATINGS Continued

FAC TORY-

TOT.

INDOOR

MODEL

CC5A/CD5AA036 29,600 TDR 13.50 — 13.50 11.90

CC5A/CD5AW030 28,400 TDR 13.20 — 13.20 11.50

CE3AA030 29,000 TDR 13.20 — 13.20 11.65 CE3AA036 29,200 TDR 13.50 — 13.50 11.75 CK3BA030 28,400 TDR 13.20 — 13.20 11.45 CK3BA036 29,600 TDR 13.50 — 13.50 11.95

CK5A/CK5BA036 29,600 TDR 13.50 — 13.50 11.95

CK5A/CK5BT036 29,600 TDR 13.50 — 13.50 11.95

CK5A/CK5BW030 28,400 TDR 13.20 — 13.20 11.45

CK5PA036 29,600 TDR&TXV 13.50 — — 11.95 CK5PT036 29,600 TDR&TXV 13.50 — — 11.95

CK5PW030 28,400 TDR&TXV 13.20 — — 11.45

CC5A/CD5AW030 28,600 TDR 13.50 — 13.50 11.65 CC5A/CD5AW036 29,600 TDR 14.00 — 14.00 12.10

CE3AA030 29,000 TDR 13.50 — 13.50 11.80 CE3AA036 29,200 TDR 13.50 — 13.50 11.90 CK3BA030 28,600 TDR 13.20 — 13.20 11.55

CK3BA036 29,600 TDR 14.00 — 14.00 12.10 CK5A/CK5BW030 28,600 TDR 13.20 — 13.20 11.55 CK5A/CK5BW036 29,600 TDR 14.00 — 14.00 12.10

CK5PW030 28,600 TDR&TXV 13.20 — — 11.55 CK5PW036 29,600 TDR&TXV 14.00 — — 12.10

*CC5A/CD5AA036 35,000 NONE — 13.00 13.00 11.20

CC5A/CD5AA042 35,000 NONE — 13.00 13.00 11.20

CC5A/CD5AW036 35,000 NONE — 13.00 13.00 11.20

CE3AA036 35,000 NONE — 12.50 12.50 11.05

CE3AA042 35,000 NONE — 13.00 13.00 11.30

CF5AA036 35,000 NONE — 13.00 13.00 11.15

CK3BA036 35,000 NONE — 13.00 13.00 11.20

CK3BA042 35,000 NONE — 13.00 13.00 11.20

CK5A/CK5BA036 35,000 NONE — 13.00 13.00 11.20 CK5A/CK5BA042 35,000 NONE — 13.00 13.00 11.20

CK5A/CK5BT036 35,000 NONE — 13.00 13.00 11.20 CK5A/CK5BT042 35,000 NONE — 13.00 13.00 11.20

CK5A/CK5BW036 35,000 NONE — 13.00 13.00 11.20

CK5PA036 35,000 TXV — 13.00 — 11.20

CK5PA042 35,000 TXV — 13.00 — 11.20

CK5PT036 35,000 TXV — 13.00 — 11.20

CK5PT042 35,000 TXV — 13.00 — 11.20

CK5PW036 35,000 TXV — 13.00 — 11.20

F(A,B)4(A,B)N(F,B,C)042 35,000 TDR 13.00 — 13.00 11.25

F(A,B)4(A,B)N(F,C)036 35,000 TDR 12.50 — 12.50 11.15

FE4ANF002 35,000 TDR&TXV 13.00 — — 11.75 FE4ANF003 35,000 TDR&TXV 13.50 — — 12.05 FE4ANF005 36,000 TDR&TXV 14.00 — — 12.20

FG3AAA036 35,000 NONE — 12.20 12.20 10.95 FK4(C,D)NF002 35,000 TDR&TXV 13.00 — — 11.75 FK4(C,D)NF003 35,000 TDR&TXV 13.50 — — 12.05 FK4(C,D)NF005 36,000 TDR&TXV 14.00 — — 12.20 FV4(A,B)NF002 35,000 TDR&TXV 13.00 — — 11.75 FV4(A,B)NF003 35,000 TDR&TXV 13.50 — — 12.05

FV4(A,BNF005 36,000 TDR&TXV 14.00 — — 12.20 FX4(A,B)NF036 34,000 TDR&TXV 12.25 — — 10.95 FX4(A,B)NF042 35,000 TDR&TXV 13.00 — — 11.20

CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 11.80

CE3AA036 35,000 TDR 13.20 — 13.20 11.70 CE3AA042 35,000 TDR 13.50 — 13.50 11.95

CK3BA036 35,000 TDR 13.50 — 13.50 11.90 CK5A/CK5BA036 35,000 TDR 13.50 — 13.50 11.90 CK5A/CK5BE042 35,000 TDR 13.50 — 13.50 12.00

CK5A/CK5BT036 35,000 TDR 13.50 — 13.50 11.90

CK5PA036 35,000 TDR&TXV 13.50 — — 11.90

CK5PE042 35,000 TDR&TXV 13.50 — — 12.00

CK5PT036 35,000 TDR&TXV 13.50 — — 11.90

CC5A/CD5AA036 35,000 TDR 13.50 — 13.50 12.00 CC5A/CD5AA042 35,000 TDR 14.00 — 14.00 12.15

CC5A/CD5AW036 35,000 TDR 13.50 — 13.50 12.00

CE3AA036 35,000 TDR 13.20 — 13.20 11.90

CE3AA042 35,000 TDR 14.00 — 14.00 12.15

CK3BA036 35,000 TDR 13.50 — 13.50 12.10

CK3BA042 35,000 TDR 14.00 — 14.00 12.15 CK5A/CK5BA036 35,000 TDR 13.50 — 13.50 12.10 CK5A/CK5BA042 35,000 TDR 14.00 — 14.00 12.15 CK5A/CK5BE042 35,000 TDR 14.00 — 14.00 12.20

CK5A/CK5BT036 35,000 TDR 13.50 — 13.50 12.10 CK5A/CK5BT042 35,000 TDR 14.00 — 14.00 12.15

CK5A/CK5BW036 35,000 TDR 13.50 — 13.50 12.10

CK5PA036 35,000 TDR&TXV 13.50 — — 12.05

CK5PA042 35,000 TDR&TXV 14.00 — — 12.15

CAP.

BTUH

COILS + 355MAV042060 VARIABLE-SPEED FURNACE

COILS + 355MAV042080 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas

Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—11—

COMBINATION RATINGS Continued

UNIT

SIZE-SERIES

036-F

See notes on page 22.

FAC TORY-

TOT.

INDOOR

MODEL

CK5PE042 35,000 TDR&TXV 14.00 — — 12.20 CK5PT036 35,000 TDR&TXV 13.50 — — 12.05 CK5PT042 35,000 TDR&TXV 14.00 — — 12.15

CK5PW036 35,000 TDR&TXV 13.50 — — 12.05

CC5A/CD5AA036 35,000 TDR 14.00 — 14.00 12.00

CC5A/CD5AA042 35,000 TDR 14.00 — 14.00 12.05 CC5A/CD5AW036 35,000 TDR 14.00 — 14.00 12.00 CC5A/CD5AW042 35,000 TDR 14.00 — 14.00 11.95

CE3AA036 35,000 TDR 13.50 — 13.50 11.85 CE3AA042 35,000 TDR 14.00 — 14.00 12.10 CK3BA036 35,000 TDR 14.00 — 14.00 12.00

CK3BA042 35,000 TDR 14.00 — 14.00 12.10 CK5A/CK5BA036 35,000 TDR 14.00 — 14.00 12.00 CK5A/CK5BA042 35,000 TDR 14.00 — 14.00 12.10 CK5A/CK5BE042 35,000 TDR 14.00 — 14.00 12.15

CK5A/CK5BT036 35,000 TDR 14.00 — 14.00 12.00 CK5A/CK5BT042 35,000 TDR 14.00 — 14.00 12.10

CK5A/CK5BW036 35,000 TDR 14.00 — 14.00 12.10

CK5PA036 35,000 TDR&TXV 14.00 — — 12.00

CK5PA042 35,000 TDR&TXV 14.00 — — 12.05

CK5PE042 35,000 TDR&TXV 14.00 — — 12.15

CK5PT036 35,000 TDR&TXV 14.00 — — 12.00

CK5PT042 35,000 TDR&TXV 14.00 — — 12.05

CK5PW036 35,000 TDR&TXV 14.00 — — 12.05

CC5A/CD5AA042 35,000 TDR 14.00 — 14.00 12.20

CC5A/CD5AW036 35,000 TDR 14.00 — 14.00 12.05 CC5A/CD5AW042 35,000 TDR 14.00 — 14.00 12.15

CE3AA036 35,000 TDR 13.50 — 13.50 11.95

CE3AA042 35,000 TDR 14.00 — 14.00 12.20

CK3BA042 35,000 TDR 14.00 — 14.00 12.20 CK5A/CK5BA042 35,000 TDR 14.00 — 14.00 12.20

CK5A/CK5BT042 35,000 TDR 14.00 — 14.00 12.20

CK5A/CK5BW036 35,000 TDR 14.00 — 14.00 12.10

CK5PA042 35,000 TDR&TXV 14.00 — — 12.20

CK5PT042 35,000 TDR&TXV 14.00 — — 12.20

CK5PW036 35,000 TDR&TXV 14.00 — — 12.10

CC5A/CD5AA042 35,000 TDR 14.00 — 14.00 12.30

CC5A/CD5AW036 35,000 TDR 14.00 — 14.00 12.10 CC5A/CD5AW042 35,000 TDR 14.00 — 14.00 12.25

CE3AA036 35,000 TDR 13.50 — 13.50 12.00

CE3AA042 35,000 TDR 14.00 — 14.00 12.30

CK3BA042 35,000 TDR 14.00 — 14.00 12.30 CK5A/CK5BA042 35,000 TDR 14.00 — 14.00 12.30

CK5A/CK5BT042 35,000 TDR 14.00 — 14.00 12.30

CK5A/CK5BW036 35,000 TDR 14.00 — 14.00 12.15

CK5PA042 35,000 TDR&TXV 14.00 — — 12.25

CK5PT042 35,000 TDR&TXV 14.00 — — 12.25

CK5PW036 35,000 TDR&TXV 14.00 — — 12.15

CC5A/CD5AA042 35,000 TDR 13.20 — 13.20 11.60

CE3AA036 35,000 TDR 13.00 — 13.00 11.35

CE3AA042 35,000 TDR 13.20 — 13.20 11.60

CK3BA036 35,000 TDR 13.00 — 13.00 11.45

CK3BA042 35,000 TDR 13.00 — 13.00 11.45 CK5A/CK5BA042 35,000 TDR 13.00 — 13.00 11.45

CK5A/CK5BT042 35,000 TDR 13.00 — 13.00 11.45

CK5A/CK5BW036 35,000 TDR 13.00 — 13.00 11.45

CK5PA042 35,000 TDR&TXV 13.00 — — 11.45

CK5PT042 35,000 TDR&TXV 13.00 — — 11.45

CK5PW036 35,000 TDR&TXV 13.00 — — 11.45

CC5A/CD5AA036 35,000 TDR 13.20 — 13.20 11.45

CE3AA036 35,000 TDR 13.00 — 13.00 11.35

CE3AA042 35,000 TDR 13.20 — 13.20 11.60

CK3BA036 35,000 TDR 13.00 — 13.00 11.50

CK3BA042 35,000 TDR 13.20 — 13.20 11.60 CK5A/CK5BA036 35,000 TDR 13.00 — 13.00 11.50

CK5A/CK5BT036 35,000 TDR 13.00 — 13.00 11.50

CK5A/CK5BW036 35,000 TDR 13.00 — 13.00 11.50

CK5PA036 35,000 TDR&TXV 13.00 — — 11.50

CK5PT036 35,000 TDR&TXV 13.00 — — 11.50

CK5PW036 35,000 TDR&TXV 13.00 — — 11.50

CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.85

CC5A/CD5AW036 35,000 TDR 13.20 — 13.20 11.65

CE3AA036 35,000 TDR 13.00 — 13.00 11.55

CE3AA042 35,000 TDR 13.50 — 13.50 11.85

CK3BA036 35,000 TDR 13.20 — 13.20 11.60

CAP.

BTUH

COILS + 315(A,J)AV060110 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE

COILS + 355MAV042040 VARIABLE-SPEED FURNACE

COILS + 355MAV042060 VARIABLE-SPEED FURNACE

COILS + 355MAV042080 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—12—

COMBINATION RATINGS Continued

UNIT

SIZE-SERIES

036-F

036-G

See notes on page 22.

FAC TORY-

TOT.

INDOOR

MODEL

CK3BA042 35,000 TDR 13.50 — 13.50 11.75 CK5A/CK5BA042 35,000 TDR 13.50 — 13.50 11.75 CK5A/CK5BT042 35,000 TDR 13.50 — 13.50 11.75

CK5A/CK5BW036 35,000 TDR 13.20 — 13.20 11.60

CK5PA042 35,000 TDR&TXV 13.50 — — 11.75

CK5PT042 35,000 TDR&TXV 13.50 — — 11.75

CK5PW036 35,000 TDR&TXV 13.20 — — 11.60

CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.90 CC5A/CD5AW036 35,000 TDR 13.50 — 13.50 11.75

CE3AA036 35,000 TDR 13.00 — 13.00 11.60

CE3AA042 35,000 TDR 13.50 — 13.50 11.90

CK3BA036 35,000 TDR 13.00 — 13.00 11.45

CK3BA042 35,000 TDR 13.00 — 13.00 11.60 CK5A/CK5BA042 35,000 TDR 13.00 — 13.00 11.60 CK5A/CK5BT042 35,000 TDR 13.00 — 13.00 11.60

CK5A/CK5BW036 35,000 TDR 13.00 — 13.00 11.45

CK5PA042 35,000 TDR&TXV 13.00 — — 11.60

CK5PT042 35,000 TDR&TXV 13.00 — — 11.60

CK5PW036 35,000 TDR&TXV 13.00 — — 11.45

CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.90 CC5A/CD5AW036 35,000 TDR 13.50 — 13.50 11.75

CE3AA036 35,000 TDR 13.00 — 13.00 11.60

CE3AA042 35,000 TDR 13.50 — 13.50 11.90

CK3BA036 35,000 TDR 13.50 — 13.50 11.80

CK3BA042 35,000 TDR 13.50 — 13.50 12.00 CK5A/CK5BA042 35,000 TDR 13.50 — 13.50 12.00 CK5A/CK5BT042 35,000 TDR 13.50 — 13.50 12.00

CK5A/CK5BW036 35,000 TDR 13.50 — 13.50 11.80

CK5PA042 35,000 TDR&TXV 13.50 — — 12.00

CK5PT042 35,000 TDR&TXV 13.50 — — 12.00

CK5PW036 35,000 TDR&TXV 13.50 — — 11.80

CC5A/CD5AA042 35,000 TDR 13.50 — 13.50 11.90 CC5A/CD5AW036 35,000 TDR 13.50 — 13.50 11.75

CE3AA036 35,000 TDR 13.00 — 13.00 11.60

CE3AA042 35,000 TDR 13.50 — 13.50 11.90

CK3BA036 35,000 TDR 13.50 — 13.50 11.85

CK3BA042 35,000 TDR 13.50 — 13.50 12.00 CK5A/CK5BA042 35,000 TDR 13.50 — 13.50 12.00 CK5A/CK5BT042 35,000 TDR 13.50 — 13.50 12.00

CK5A/CK5BW036 35,000 TDR 13.50 — 13.50 11.85

CK5PA042 35,000 TDR&TXV 13.50 — — 12.00

CK5PT042 35,000 TDR&TXV 13.50 — — 12.00

CK5PW036 35,000 TDR&TXV 13.50 — — 11.85

CC5A/CD5AA036* 35,000 NONE — 13.00 13.00 11.25

CC5A/CD5AA042 35,000 NONE — 13.00 13.00 11.25 CC5A/CD5AW036 35,000 NONE — 13.00 13.00 11.25 CC5A/CD5AW042 34,600 NONE — 12.50 12.50 11.10

CE3AA036 34,600 NONE — 12.50 12.50 11.15

CE3AA042 35,000 NONE — 13.00 13.00 11.30

CF5AA036 35,000 NONE — 12.50 12.50 11.20

CK3BA036 35,000 NONE — 13.00 13.00 11.30

CK3BA042 35,000 NONE — 13.00 13.00 11.30 CK5A/CK5BA036 35,000 NONE — 13.00 13.00 11.30 CK5A/CK5BA042 35,000 NONE — 13.00 13.00 11.30 CK5A/CK5BE042 35,000 NONE — 13.00 13.00 11.35 CK5A/CK5BT036 35,000 NONE — 13.00 13.00 11.30 CK5A/CK5BT042 35,000 NONE — 13.00 13.00 11.30

CK5A/CK5BW036 35,000 NONE — 13.00 13.00 11.30

CK5PA036 35,000 TXV — 13.00 — 11.30

CK5PA042 35,000 TXV — 13.00 — 11.30 CK5PE042 35,000 TXV — 13.00 — 11.35 CK5PT036 35,000 TXV — 13.00 — 11.30 CK5PT042 35,000 TXV — 13.00 — 11.30

CK5PW036 35,000 TXV — 13.00 — 11.30

F(A,B)4BN(F,B,C)042 35,000 TDR 12.50 — 12.50 11.20

F(A,B)4BN(F,C)036 34,600 TDR 12.50 — 12.50 10.90

FC4CN(F,B)042 35,000 TDR&TXV 12.50 — — 11.20

FC4CNF036 34,600 TDR&TXV 12.50 — — 10.90 FE4ANB006 36,000 TDR&TXV 14.50 — — 13.05 FE4ANF002 35,000 TDR&TXV 13.50 — — 12.00 FE4ANF003 35,000 TDR&TXV 14.00 — — 12.40 FE4ANF005 36,000 TDR&TXV 14.50 — — 12.85 FG3AAA036 34,000 NONE — 12.50 12.50 10.95 FG3AAA048 35,000 NONE — 12.50 12.50 11.20 FK4DNB006 36,000 TDR&TXV 14.50 — — 13.05 FK4DNF001 34,600 TDR&TXV 13.00 — — 11.75 FK4DNF002 35,000 TDR&TXV 13.50 — — 12.00 FK4DNF003 35,000 TDR&TXV 14.00 — — 12.40 FK4DNF005 36,000 TDR&TXV 14.50 — — 12.85 FV4BNB006 36,000 TDR&TXV 14.50 — — 13.05 FV4BNF002 35,000 TDR&TXV 13.50 — — 12.00

CAP.

BTUH

COILS + 355MAV060080 VARIABLE-SPEED FURNACE

COILS + 355MAV060100 VARIABLE-SPEED FURNACE

COILS + 355MAV060120 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—13—

COMBINATION RATINGS Continued

UNIT

SIZE-SERIES

036-G

See notes on page 22.

FAC TORY-

TOT.

INDOOR

MODEL

FV4BNF003 35,000 TDR&TXV 14.00 — — 12.40 FV4BNF005 36,000 TDR&TXV 14.50 — — 12.85 FX4BNF036 35,000 TDR&TXV 12.50 — — 11.20 FX4BNF042 35,600 TDR&TXV 13.00 — — 11.40

CC5A/CD5AA036 34,400 TDR 13.50 — 13.50 11.85

CE3AA036 34,000 TDR 13.50 — 13.50 11.70 CE3AA042 34,600 TDR 13.50 — 13.50 11.95

CK3BA036 34,600 TDR 13.50 — 13.50 11.90 CK5A/CK5BA036 34,600 TDR 13.50 — 13.50 11.90 CK5A/CK5BE042 34,600 TDR 14.00 — 14.00 12.00

CK5A/CK5BT036 34,600 TDR 13.50 — 13.50 11.90

CK5PA036 34,600 TDR&TXV 13.50 — — 11.90

CK5PE042 34,600 TDR&TXV 13.50 — — 12.00

CK5PT036 34,600 TDR&TXV 13.50 — — 11.90

CC5A/CD5AA036 34,400 TDR 13.50 — 13.50 12.05 CC5A/CD5AA042 34,400 TDR 14.00 — 14.00 12.10

CC5A/CD5AW036 34,400 TDR 14.00 — 14.00 12.10

CE3AA036 34,000 TDR 13.50 — 13.50 11.90

CE3AA042 34,600 TDR 14.00 — 14.00 12.15

CK3BA036 34,600 TDR 14.00 — 14.00 12.10

CK3BA042 34,600 TDR 14.00 — 14.00 12.15 CK5A/CK5BA036 34,600 TDR 14.00 — 14.00 12.10 CK5A/CK5BA042 34,600 TDR 14.00 — 14.00 12.15 CK5A/CK5BE042 34,600 TDR 14.00 — 14.00 12.20

CK5A/CK5BT036 34,600 TDR 14.00 — 14.00 12.10 CK5A/CK5BT042 34,600 TDR 14.00 — 14.00 12.15

CK5A/CK5BW036 34,600 TDR 14.00 — 14.00 12.15

CK5PA036 34,600 TDR&TXV 14.00 — — 12.05

CK5PA042 34,600 TDR&TXV 14.00 — — 12.15

CK5PE042 34,600 TDR&TXV 14.00 — — 12.20

CK5PT036 34,600 TDR&TXV 14.00 — — 12.05

CK5PT042 34,600 TDR&TXV 14.00 — — 12.15

CK5PW036 34,600 TDR&TXV 14.00 — — 12.10

CC5A/CD5AA036 34,400 TDR 13.50 — 13.50 12.05 CC5A/CD5AA042 34,400 TDR 14.00 — 14.00 12.10

CC5A/CD5AW036 34,400 TDR 14.00 — 14.00 12.10 CC5A/CD5AW042 34,200 TDR 14.00 — 14.00 12.00

CE3AA036 34,000 TDR 13.50 — 13.50 11.90

CE3AA042 34,600 TDR 14.00 — 14.00 12.15

CK3BA036 34,600 TDR 14.00 — 14.00 12.10

CK3BA042 34,600 TDR 14.00 — 14.00 12.15 CK5A/CK5BA036 34,600 TDR 14.00 — 14.00 12.10 CK5A/CK5BA042 34,600 TDR 14.00 — 14.00 12.15 CK5A/CK5BE042 34,600 TDR 14.00 — 14.00 12.20

CK5A/CK5BT036 34,600 TDR 14.00 — 14.00 12.10 CK5A/CK5BT042 34,600 TDR 14.00 — 14.00 12.15

CK5A/CK5BW036 34,600 TDR 14.00 — 14.00 12.15

CK5PA036 34,600 TDR&TXV 14.00 — — 12.05

CK5PA042 34,600 TDR&TXV 14.00 — — 12.15

CK5PE042 34,600 TDR&TXV 14.00 — — 12.20

CK5PT036 34,600 TDR&TXV 14.00 — — 12.05

CK5PT042 34,600 TDR&TXV 14.00 — — 12.15

CK5PW036 34,600 TDR&TXV 14.00 — — 12.10

CC5A/CD5AA042 34,400 TDR 14.00 — 14.00 12.20

CC5A/CD5AW036 34,400 TDR 14.00 — 14.00 12.15 CC5A/CD5AW042 34,200 TDR 14.00 — 14.00 12.10

CE3AA036 34,000 TDR 13.50 — 13.50 11.95

CE3AA042 34,600 TDR 14.00 — 14.00 12.25

CK3BA042 34,600 TDR 14.00 — 14.00 12.20 CK5A/CK5BA042 34,600 TDR 14.00 — 14.00 12.20

CK5A/CK5BT042 34,600 TDR 14.00 — 14.00 12.20

CK5A/CK5BW036 34,600 TDR 14.00 — 14.00 12.20

CK5PA042 34,600 TDR&TXV 14.00 — — 12.20

CK5PT042 34,600 TDR&TXV 14.00 — — 12.20

CK5PW036 34,600 TDR&TXV 14.00 — — 12.20

CC5A/CD5AA042 34,400 TDR 14.00 — 14.00 12.30

CC5A/CD5AW036 34,400 TDR 14.00 — 14.00 12.25 CC5A/CD5AW042 34,200 TDR 14.00 — 14.00 12.20

CE3AA036 34,000 TDR 14.00 — 14.00 12.05

CE3AA042 34,600 TDR 14.00 — 14.00 12.35

CK3BA042 34,600 TDR 14.00 — 14.00 12.30 CK5A/CK5BA042 34,600 TDR 14.00 — 14.00 12.30

CK5A/CK5BT042 34,600 TDR 14.00 — 14.00 12.30

CK5A/CK5BW036 34,600 TDR 14.00 — 14.00 12.30

CK5PA042 34,600 TDR&TXV 14.00 — — 12.30

CK5PT042 34,600 TDR&TXV 14.00 — — 12.30

CK5PW036 34,600 TDR&TXV 14.00 — — 12.30

CAP.

BTUH

COILS + 315(A,J)AV036070 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—14—

COMBINATION RATINGS Continued

UNIT

SIZE-SERIES

036-G

See notes on page 22.

FAC TORY-

TOT.

INDOOR

MODEL

CC5A/CD5AA042 34,400 TDR 13.50 — 13.50 11.85 CC5A/CD5AW036 34,400 TDR 13.50 — 13.50 11.85 CC5A/CD5AW042 33,800 TDR 13.50 — 13.50 11.75

CE3AA036 34,000 TDR 13.50 — 13.50 11.65 CE3AA042 34,600 TDR 13.50 — 13.50 11.90 CK3BA042 34,600 TDR 13.50 — 13.50 11.90

CK5A/CK5BA042 34,600 TDR 13.50 — 13.50 11.90

CK5A/CK5BT042 34,600 TDR 13.50 — 13.50 11.90

CK5A/CK5BW036 34,600 TDR 13.50 — 13.50 11.90

CK5PA042 34,600 TDR&TXV 13.50 — — 11.85 CK5PT042 34,600 TDR&TXV 13.50 — — 11.85

CK5PW036 34,600 TDR&TXV 13.50 — — 11.85

CC5A/CD5AA036 34,400 TDR 13.50 — 13.50 11.95

CC5A/CD5AA042 34,400 TDR 13.50 — 13.50 12.05 CC5A/CD5AW036 34,400 TDR 13.50 — 13.50 12.00

CE3AA036 34,000 TDR 13.50 — 13.50 11.80 CE3AA042 34,600 TDR 13.50 — 13.50 12.10 CK3BA036 34,600 TDR 13.50 — 13.50 12.00

CK3BA042 34,600 TDR 13.50 — 13.50 12.05 CK5A/CK5BA036 34,600 TDR 13.50 — 13.50 12.00 CK5A/CK5BA042 34,600 TDR 13.50 — 13.50 12.05 CK5A/CK5BE042 34,600 TDR 13.50 — 13.50 12.15

CK5A/CK5BT036 34,600 TDR 13.50 — 13.50 12.00 CK5A/CK5BT042 34,600 TDR 13.50 — 13.50 12.05

CK5A/CK5BW036 34,600 TDR 13.50 — 13.50 12.05

CK5PA036 34,600 TDR&TXV 13.50 — — 12.00

CK5PA042 34,600 TDR&TXV 13.50 — — 12.05

CK5PE042 34,600 TDR&TXV 13.50 — — 12.10

CK5PT036 34,600 TDR&TXV 13.50 — — 12.00

CK5PT042 34,600 TDR&TXV 13.50 — — 12.05

CK5PW036 34,600 TDR&TXV 13.50 — — 12.05

CC5A/CD5AA036 34,400 TDR 13.50 — 13.50 11.75 CC5A/CD5AA042 34,400 TDR 13.50 — 13.50 11.85

CC5A/CD5AW036 34,400 TDR 13.50 — 13.50 11.80 CC5A/CD5AW042 33,800 TDR 13.50 — 13.50 11.75

CE3AA036 34,000 TDR 13.50 — 13.50 11.60

CE3AA042 34,600 TDR 13.50 — 13.50 11.90

CK3BA036 34,600 TDR 13.50 — 13.50 11.80

CK3BA042 34,600 TDR 13.50 — 13.50 11.85 CK5A/CK5BA036 34,600 TDR 13.50 — 13.50 11.80 CK5A/CK5BA042 34,600 TDR 13.50 — 13.50 11.85 CK5A/CK5BE042 34,600 TDR 13.50 — 13.50 11.90

CK5A/CK5BT036 34,600 TDR 13.50 — 13.50 11.80 CK5A/CK5BT042 34,600 TDR 13.50 — 13.50 11.85

CK5A/CK5BW036 34,600 TDR 13.50 — 13.50 11.85

CK5PA036 34,600 TDR&TXV 13.50 — — 11.75

CK5PA042 34,600 TDR&TXV 13.50 — — 11.85

CK5PE042 34,600 TDR&TXV 13.50 — — 11.90

CK5PT036 34,600 TDR&TXV 13.50 — — 11.75

CK5PT042 34,600 TDR&TXV 13.50 — — 11.85

CK5PW036 34,600 TDR&TXV 13.50 — — 11.85

CC5A/CD5AA036 34,400 TDR 13.50 — 13.50 11.90 CC5A/CD5AA042 34,400 TDR 13.50 — 13.50 12.00

CC5A/CD5AW036 34,400 TDR 13.50 — 13.50 11.95 CC5A/CD5AW042 33,800 TDR 13.50 — 13.50 11.85

CE3AA036 34,000 TDR 13.50 — 13.50 11.80

CE3AA042 34,600 TDR 13.50 — 13.50 12.05

CK3BA036 34,600 TDR 13.50 — 13.50 12.00

CK3BA042 34,600 TDR 13.50 — 13.50 12.00 CK5A/CK5BA036 34,600 TDR 13.50 — 13.50 11.95 CK5A/CK5BA042 34,600 TDR 13.50 — 13.50 12.00 CK5A/CK5BE042 34,600 TDR 13.50 — 13.50 12.10

CK5A/CK5BT036 34,600 TDR 13.50 — 13.50 11.95 CK5A/CK5BT042 34,600 TDR 13.50 — 13.50 12.00

CK5A/CK5BW036 34,600 TDR 13.50 — 13.50 12.00

CK5PA036 34,600 TDR&TXV 13.50 — — 11.95

CK5PA042 34,600 TDR&TXV 13.50 — — 12.00

CK5PE042 34,600 TDR&TXV 13.50 — — 12.05

CK5PT036 34,600 TDR&TXV 13.50 — — 11.95

CK5PT042 34,600 TDR&TXV 13.50 — — 12.00

CK5PW036 34,600 TDR&TXV 13.50 — — 12.00

CC5A/CD5AA036 34,400 TDR 13.50 — 13.50 11.95 CC5A/CD5AA042 34,400 TDR 13.50 — 13.50 12.05

CC5A/CD5AW036 34,400 TDR 13.50 — 13.50 12.00 CC5A/CD5AW042 33,800 TDR 13.50 — 13.50 11.90

CE3AA036 34,000 TDR 13.50 — 13.50 11.85

CE3AA042 34,600 TDR 13.50 — 13.50 12.10

CAP.

BTUH

COILS + 355MAV042040 VARIABLE-SPEED FURNACE

COILS + 355MAV042060 VARIABLE-SPEED FURNACE

COILS + 355MAV042080 VARIABLE-SPEED FURNACE

COILS + 355MAV060080 VARIABLE-SPEED FURNACE

COILS + 355MAV060100 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas

Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—15—

UNIT

SIZE-SERIES

036-G

042-F

See notes on page 22.

COMBINATION RATINGS Continued

FAC TORY-

TOT.

INDOOR

MODEL

CK3BA036 34,600 TDR 13.50 — 13.50 12.00

CK3BA042 34,600 TDR 13.50 — 13.50 12.05 CK5A/CK5BA036 34,600 TDR 13.50 — 13.50 12.00 CK5A/CK5BA042 34,600 TDR 13.50 — 13.50 12.05 CK5A/CK5BE042 34,600 TDR 13.50 — 13.50 12.15 CK5A/CK5BT036 34,600 TDR 13.50 — 13.50 12.00 CK5A/CK5BT042 34,600 TDR 13.50 — 13.50 12.05

CK5A/CK5BW036 34,600 TDR 13.50 — 13.50 12.05

CK5PA036 34,600 TDR&TXV 13.50 — — 12.00

CK5PA042 34,600 TDR&TXV 13.50 — — 12.05

CK5PE042 34,600 TDR&TXV 13.50 — — 12.10

CK5PT036 34,600 TDR&TXV 13.50 — — 12.00

CK5PT042 34,600 TDR&TXV 13.50 — — 12.05

CK5PW036 34,600 TDR&TXV 13.50 — — 12.05

CC5A/CD5AA042 34,400 TDR 13.50 — 13.50 12.05

CC5A/CD5AW036 34,400 TDR 13.50 — 13.50 12.05 CC5A/CD5AW042 33,800 TDR 13.50 — 13.50 12.00

CE3AA036 34,000 TDR 13.50 — 13.50 11.85

CE3AA042 34,600 TDR 13.50 — 13.50 12.10

CK3BA042 34,600 TDR 13.50 — 13.50 12.10 CK5A/CK5BA042 34,600 TDR 13.50 — 13.50 12.10 CK5A/CK5BT042 34,600 TDR 13.50 — 13.50 12.10

CK5A/CK5BW036 34,600 TDR 13.50 — 13.50 12.10

CK5PA042 34,600 TDR&TXV 13.50 — — 12.10

CK5PT042 34,600 TDR&TXV 13.50 — — 12.10

CK5PW036 34,600 TDR&TXV 13.50 — — 12.10 *CD5AA048 40,500 NONE — 13.00 13.00 11.25

CC5A/CD5AA042 40,500 NONE — 13.00 13.00 11.15

CC5A/CD5AC048 40,000 NONE — 12.50 12.50 11.00 CC5A/CD5AW048 40,500 NONE — 13.00 13.00 11.20

CE3AA042 41,000 NONE — 13.00 13.00 11.30

CE3AA048 41,000 NONE — 13.00 13.00 11.35

CF5AA048 40,500 NONE — 12.50 12.50 11.20

CK3BA042 40,500 NONE — 13.00 13.00 11.20

CK3BA048 40,500 NONE — 13.00 13.00 11.30 CK5A/CK5BA042 40,500 NONE — 13.00 13.00 11.20 CK5A/CK5BA048 40,500 NONE — 13.00 13.00 11.30 CK5A/CK5BE042 39,500 NONE — 12.50 12.50 11.30 CK5A/CK5BT042 40,500 NONE — 13.00 13.00 11.20 CK5A/CK5BT048 40,500 NONE — 13.00 13.00 11.30

CK5A/CK5BW048 40,500 NONE — 13.00 13.00 11.30

CK5PA042 40,500 TXV — 13.00 — 11.20

CK5PA048 40,500 TXV — 13.00 — 11.30

CK5PE042 39,500 TXV — 12.50 — 11.30

CK5PT042 40,500 TXV — 13.00 — 11.20

CK5PT048 40,500 TXV — 13.00 — 11.30

CK5PW048 40,500 TXV — 13.00 — 11.30 F(A,B)4(A,B)N(F,B,C)042 40,500 TDR 12.50 — 12.50 11.25 F(A,B)4(A,B)N(F,B,C)048 41,000 TDR 13.00 — 13.00 11.45

FE4ANB006 41,500 TDR&TXV 14.00 — — 12.90 FE4ANF003 39,500 TDR&TXV 13.00 — — 11.95 FE4ANF005 41,000 TDR&TXV 13.50 — — 12.50

FG3AAA048 40,000 NONE — 12.50 12.50 11.25 FK4(C,D)NB006 41,500 TDR&TXV 14.00 — — 12.90 FK4(C,D)NF003 39,500 TDR&TXV 13.00 — — 12.00 FK4(C,D)NF005 41,000 TDR&TXV 13.50 — — 12.55 FV4(A,B)NB006 41,500 TDR&TXV 14.00 — — 12.90

FV4(A,B)NF003 39,500 TDR&TXV 13.00 — — 11.95 FV4(A,B)NF005 41,000 TDR&TXV 13.50 — — 12.50 FX4(A,B)NF042 40,000 TDR&TXV 12.50 — — 11.10 FX4(A,B)NF048 40,500 TDR&TXV 12.50 — — 11.20

CC5A/CD5AA042 40,000 TDR 13.50 — 13.50 11.85

CC5A/CD5AC048 40,000 TDR 13.50 — 13.50 11.85

CD5AA048 40,500 TDR 13.50 — 13.50 12.00 CE3AA042 40,500 TDR 13.50 — 13.50 11.90 CE3AA048 41,000 TDR 13.50 — 13.50 11.95 CK3BA042 40,500 TDR 13.50 — 13.50 11.90

CK3BA048 40,500 TDR 13.50 — 13.50 12.00 CK5A/CK5BA042 40,000 TDR 13.50 — 13.50 11.90 CK5A/CK5BA048 40,500 TDR 13.50 — 13.50 12.00 CK5A/CK5BE042 40,500 TDR 13.50 — 13.50 11.95 CK5A/CK5BT042 40,500 TDR 13.50 — 13.50 11.90 CK5A/CK5BT048 40,500 TDR 13.50 — 13.50 12.00

CK5PA042 40,500 TDR&TXV 13.50 — — 11.90

CK5PA048 40,500 TDR&TXV 13.50 — — 12.00

CK5PE042 40,500 TDR&TXV 13.50 — — 11.95

CK5PT042 40,500 TDR&TXV 13.50 — — 11.90

CK5PT048 40,500 TDR&TXV 13.50 — — 12.00

CC5A/CD5AA042 40,000 TDR 13.50 — 13.50 11.80

CC5A/CD5AC048 40,000 TDR 13.50 — 13.50 11.70 CC5A/CD5AW042 39,500 TDR 13.50 — 13.50 11.75

CAP.

BTUH

COILS + 355MAV060120 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

—16—

SEER

Bryant Gas

Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

COMBINATION RATINGS Continued

UNIT

SIZE-SERIES

042-F

See notes on page 22.

FAC TORY-

TOT.

INDOOR

MODEL

CC5A/CD5AW048 40,500 TDR 14.00 — 14.00 11.95

CD5AA048 40,500 TDR 14.00 — 14.00 11.90 CE3AA042 40,500 TDR 13.50 — 13.50 11.85 CE3AA048 41,000 TDR 13.50 — 13.50 11.90 CK3BA042 40,500 TDR 13.50 — 13.50 11.80

CK3BA048 40,500 TDR 14.00 — 14.00 12.00 CK5A/CK5BA042 40,500 TDR 13.50 — 13.50 11.80 CK5A/CK5BA048 40,500 TDR 14.00 — 14.00 11.95 CK5A/CK5BE042 40,500 TDR 13.50 — 13.50 11.85 CK5A/CK5BT042 40,500 TDR 13.50 — 13.50 11.80 CK5A/CK5BT048 40,500 TDR 14.00 — 14.00 11.95

CK5A/CK5BW048 40,500 TDR 14.00 — 14.00 12.05

CK5PA042 40,500 TDR&TXV 13.50 — — 11.75

CK5PA048 40,500 TDR&TXV 14.00 — — 11.95 CK5PE042 40,500 TDR&TXV 13.50 — — 11.85 CK5PT042 40,500 TDR&TXV 13.50 — — 11.75 CK5PT048 40,500 TDR&TXV 14.00 — — 11.95

CK5PW048 40,500 TDR&TXV 14.00 — — 12.05

CC5A/CD5AA042 40,500 TDR 13.50 — 13.50 11.95 CC5A/CD5AC048 40,000 TDR 13.50 — 13.50 12.00 CC5A/CD5AW042 40,000 TDR 13.50 — 13.50 11.85 CC5A/CD5AW048 40,500 TDR 14.00 — 14.00 12.15

CD5AA048 40,500 TDR 14.00 — 14.00 12.15 CE3AA042 40,500 TDR 13.50 — 13.50 12.05 CE3AA048 41,000 TDR 13.50 — 13.50 12.10 CK3BA042 40,500 TDR 13.50 — 13.50 12.00 CK3BA048 40,500 TDR 14.00 — 14.00 12.15

CK5A/CK5BA042 40,500 TDR 13.50 — 13.50 12.00 CK5A/CK5BA048 40,500 TDR 14.00 — 14.00 12.15 CK5A/CK5BT042 40,500 TDR 13.50 — 13.50 12.00 CK5A/CK5BT048 40,500 TDR 14.00 — 14.00 12.15

CK5A/CK5BW048 40,500 TDR 14.00 — 14.00 12.15

CK5PA042 40,500 TDR&TXV 13.50 — — 12.00

CK5PA048 40,500 TDR&TXV 14.00 — — 12.15 CK5PT042 40,500 TDR&TXV 13.50 — — 12.00 CK5PT048 40,500 TDR&TXV 14.00 — — 12.15

CK5PW048 40,500 TDR&TXV 14.00 — — 12.15

CC5A/CD5AA042 40,500 TDR 13.50 — 13.50 12.00 CC5A/CD5AC048 40,000 TDR 13.50 — 13.50 12.05 CC5A/CD5AW042 40,000 TDR 13.50 — 13.50 11.90 CC5A/CD5AW048 40,500 TDR 14.00 — 14.00 12.20

CD5AA048 40,500 TDR 14.00 — 14.00 12.20 CE3AA042 40,500 TDR 13.50 — 13.50 12.05 CE3AA048 41,000 TDR 13.50 — 13.50 12.10 CK3BA042 40,500 TDR 13.50 — 13.50 12.05 CK3BA048 40,500 TDR 14.00 — 14.00 12.20

CK5A/CK5BA042 40,500 TDR 13.50 — 13.50 12.05 CK5A/CK5BA048 40,500 TDR 14.00 — 14.00 12.20 CK5A/CK5BT042 40,500 TDR 13.50 — 13.50 12.05 CK5A/CK5BT048 40,500 TDR 14.00 — 14.00 12.20

CK5A/CK5BW048 40,500 TDR 14.00 — 14.00 12.20

CK5PA042 40,500 TDR&TXV 13.50 — — 12.05

CK5PA048 40,500 TDR&TXV 14.00 — — 12.20 CK5PT042 40,500 TDR&TXV 13.50 — — 12.05 CK5PT048 40,500 TDR&TXV 14.00 — — 12.20

CK5PW048 40,500 TDR&TXV 14.00 — — 12.20

CC5A/CD5AA042 40,500 TDR 12.80 — 12.80 11.05 CC5A/CD5AW048 40,500 TDR 13.00 — 13.00 11.30

CE3AA042 40,000 TDR 13.00 — 13.00 11.15 CE3AA048 40,000 TDR 13.00 — 13.00 11.20

CC5A/CD5AC048 40,000 TDR 12.50 — 12.50 11.15

CD5AA048 40,000 TDR 13.00 — 13.00 11.35 CE3AA042 40,500 TDR 13.00 — 13.00 11.20 CE3AA048 40,500 TDR 13.00 — 13.00 11.25

CC5A/CD5AA042 40,500 TDR 13.00 — 13.00 11.40 CC5A/CD5AC048 40,000 TDR 13.00 — 13.00 11.45

CD5AA048 40,500 TDR 13.50 — 13.50 11.60 CE3AA042 41,000 TDR 13.00 — 13.00 11.50 CE3AA048 41,000 TDR 13.20 — 13.20 11.55 CK3BA042 40,500 TDR 13.00 — 13.00 11.30 CK3BA048 40,500 TDR 13.20 — 13.20 11.55

CK5A/CK5BA042 40,500 TDR 13.00 — 13.00 11.30 CK5A/CK5BA048 40,500 TDR 13.20 — 13.20 11.55 CK5A/CK5BT042 40,500 TDR 13.00 — 13.00 11.30 CK5A/CK5BT048 40,500 TDR 13.20 — 13.20 11.55

CK5PA042 40,500 TDR&TXV 13.00 — — 11.30

CK5PA048 40,500 TDR&TXV 13.20 — — 11.55

CAP.

BTUH

COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE

COILS + 355MAV042040 VARIABLE-SPEED FURNACE

COILS + 355MAV042060 VARIABLE-SPEED FURNACE

COILS + 355MAV042080 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—17—

UNIT

SIZE-SERIES

042-F

048-F

See notes on page 22.

COMBINATION RATINGS Continued

FAC TORY-

TOT.

INDOOR

MODEL

CK5PT042 40,500 TDR&TXV 13.00 — — 11.30 CK5PT048 40,500 TDR&TXV 13.20 — — 11.55

CC5A/CD5AA042 40,500 TDR 13.20 — 13.20 11.50

CC5A/CD5AC048 40,000 TDR 13.20 — 13.20 11.55

CD5AA048 40,500 TDR 13.50 — 13.50 11.75 CE3AA042 41,000 TDR 13.20 — 13.20 11.60 CE3AA048 41,000 TDR 13.50 — 13.50 11.65

CC5A/CD5AA042 40,500 TDR 13.20 — 13.20 11.50

CC5A/CD5AC048 40,000 TDR 13.20 — 13.20 11.55

CD5AA048 40,500 TDR 13.50 — 13.50 11.75 CE3AA042 41,000 TDR 13.20 — 13.20 11.60 CE3AA048 41,000 TDR 13.50 — 13.50 11.65 CK3BA042 40,500 TDR 13.00 — 13.00 11.55

CK3BA048 40,500 TDR 13.50 — 13.50 11.80 CK5A/CK5BA042 40,500 TDR 13.00 — 13.00 11.55 CK5A/CK5BA048 40,500 TDR 13.50 — 13.50 11.80 CK5A/CK5BT042 40,500 TDR 13.00 — 13.00 11.55 CK5A/CK5BT048 40,500 TDR 13.50 — 13.50 11.80

CK5PA042 40,500 TDR&TXV 13.00 — — 11.55

CK5PA048 40,500 TDR&TXV 13.50 — — 11.80

CK5PT042 40,500 TDR&TXV 13.00 — — 11.55

CK5PT048 40,500 TDR&TXV 13.50 — — 11.80

CC5A/CD5AA042 40,500 TDR 13.20 — 13.20 11.50

CC5A/CD5AW048 40,500 TDR 13.50 — 13.50 11.75

CE3AA042 41,000 TDR 13.20 — 13.20 11.60

CE3AA048 41,000 TDR 13.50 — 13.50 11.65

CK3BA042 40,500 TDR 13.00 — 13.00 11.65

CK3BA048 40,500 TDR 13.50 — 13.50 11.85 CK5A/CK5BA042 40,500 TDR 13.00 — 13.00 11.65 CK5A/CK5BT042 40,500 TDR 13.00 — 13.00 11.65

CK5A/CK5BW048 40,500 TDR 13.50 — 13.50 11.85

CK5PA042 40,500 TDR&TXV 13.00 — — 11.65

CK5PT042 40,500 TDR&TXV 13.00 — — 11.65

CK5PW048 40,500 TDR&TXV 13.50 — — 11.85

*CC5A/CD5AA060 46,500 NONE — 13.00 13.00 11.50

CC5A/CD5AC048 45,000 NONE — 12.50 12.50 11.35 CC5A/CD5AW048 46,000 NONE — 13.00 13.00 11.50 CC5A/CD5AW060 47,000 NONE — 13.00 13.00 11.80

CD5AA048 46,000 NONE — 13.00 13.00 11.50

CD5PX060 47,500 TXV — 13.50 — 11.90

CE3AA048 46,500 NONE — 13.00 13.00 11.65

CE3AA060 47,000 NONE — 13.00 13.00 11.85

CF5AA048 46,000 NONE — 12.50 12.50 11.55

CK3BA048 46,000 NONE — 13.00 13.00 11.55

CK3BA060 46,500 NONE — 13.00 13.00 11.65 CK5A/CK5BA048 46,000 NONE — 13.00 13.00 11.55 CK5A/CK5BA060 46,500 NONE — 13.00 13.00 11.65 CK5A/CK5BT048 46,000 NONE — 13.00 13.00 11.55 CK5A/CK5BT060 46,500 NONE — 13.00 13.00 11.65

CK5A/CK5BW048 46,000 NONE — 13.00 13.00 11.55

CK5A/CK5BX060 47,000 NONE — 13.00 13.00 11.90

CK5PA048 46,000 TXV — 13.00 — 11.55

CK5PA060 46,500 TXV — 13.00 — 11.65

CK5PT048 46,000 TXV — 13.00 — 11.55

CK5PT060 46,500 TXV — 13.00 — 11.65

CK5PW048 46,000 TXV — 13.00 — 11.55

CK5PX060 47,000 TXV — 13.00 — 11.90

F(A,B)4(A,B)N(F,B,C)048 46,000 TDR 12.20 — 12.20 11.50 F(A,B)4(A,B)N(F,B,C)060 47,000 TDR 12.50 — 12.50 11.55

FB4(A,B)NB070 47,500 TDR 13.00 — 13.00 12.00

FE4ANB006 47,500 TDR&TXV 14.00 — — 13.15

FE4ANF005 47,000 TDR&TXV 13.80 — — 12.40 FG3AAA048 46,000 NONE — 12.20 12.20 11.50 FG3AAA060 46,500 NONE — 12.50 12.50 11.65

FK4(C,D)NB006 47,500 TDR&TXV 14.00 — — 13.15 FK4(C,D)NF005 47,000 TDR&TXV 13.80 — — 12.40 FV4(A,B)NB006 47,500 TDR&TXV 14.00 — — 13.15

FV4(A,B)NF005 47,000 TDR&TXV 13.80 — — 12.40

FX4(A,B)NB060 47,000 TDR&TXV 12.50 — — 11.50

FX4(A,B)NF048 46,000 TDR&TXV 12.20 — — 11.50

CC5A/CD5AC048 45,000 TDR 13.00 — 13.00 11.80

CD5AA048 46,000 TDR 13.50 — 13.50 11.95 CE3AA048 46,500 TDR 13.50 — 13.50 11.95 CE3AA060 47,000 TDR 13.50 — 13.50 12.25

CK3BA048 46,000 TDR 13.50 — 13.50 11.95 CK5A/CK5BA048 46,000 TDR 13.50 — 13.50 11.95 CK5A/CK5BT048 46,000 TDR 13.50 — 13.50 11.95

CK5PA048 46,000 TDR&TXV 13.50 — — 11.90

CK5PT048 46,000 TDR&TXV 13.50 — — 11.90

CAP.

BTUH

COILS + 355MAV060080 VARIABLE-SPEED FURNACE

COILS + 355MAV060100 VARIABLE-SPEED FURNACE

COILS + 355MAV060120 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

—18—

SEER

Bryant Gas

Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

UNIT

SIZE-SERIES

048-F

See notes on page 22.

COMBINATION RATINGS Continued

FAC TORY-

TOT.

INDOOR

MODEL

CC5A/CD5AA060 46,000 TDR 13.00 — 13.00 12.00 CC5A/CD5AC048 45,000 TDR 13.00 — 13.00 11.70 CC5A/CD5AW048 45,500 TDR 13.50 — 13.50 11.95

CD5AA048 45,500 TDR 13.50 — 13.50 11.95 CE3AA048 46,000 TDR 13.00 — 13.00 11.95 CE3AA060 47,000 TDR 14.00 — 14.00 12.35 CK3BA048 46,000 TDR 13.50 — 13.50 12.00

CK3BA060 46,500 TDR 13.50 — 13.50 12.35 CK5A/CK5BA048 46,000 TDR 13.50 — 13.50 11.95 CK5A/CK5BA060 46,500 TDR 13.50 — 13.50 12.35 CK5A/CK5BT048 46,000 TDR 13.50 — 13.50 11.95 CK5A/CK5BT060 46,500 TDR 13.50 — 13.50 12.40

CK5A/CK5BW048 46,000 TDR 13.50 — 13.50 12.05

CK5A/CK5BX060 47,500 TDR 14.00 — 14.00 12.50

CK5PA048 46,000 TDR&TXV 13.50 — — 11.90

CK5PA060 46,500 TDR&TXV 13.50 — — 12.35 CK5PT048 46,000 TDR&TXV 13.50 — — 11.90 CK5PT060 46,500 TDR&TXV 13.50 — — 12.35

CK5PW048 46,000 TDR&TXV 13.50 — — 12.00

CK5PX060 47,500 TDR&TXV 14.00 — — 12.50

CC5A/CD5AA060 46,000 TDR 13.50 — 13.50 12.15 CC5A/CD5AC048 45,000 TDR 13.50 — 13.50 12.00 CC5A/CD5AW048 46,000 TDR 13.50 — 13.50 12.15 CC5A/CD5AW060 47,000 TDR 14.00 — 14.00 12.45

CD5AA048 46,000 TDR 13.50 — 13.50 12.15 CD5PX060 47,500 TDR&TXV 14.00 — — 12.55 CE3AA048 46,500 TDR 13.50 — 13.50 12.10 CE3AA060 47,000 TDR 14.00 — 14.00 12.45 CK3BA048 46,000 TDR 13.50 — 13.50 12.15 CK3BA060 46,500 TDR 13.50 — 13.50 12.45

CK5A/CK5BA048 46,000 TDR 13.50 — 13.50 12.15 CK5A/CK5BA060 46,500 TDR 13.50 — 13.50 12.45 CK5A/CK5BT048 46,000 TDR 13.50 — 13.50 12.15 CK5A/CK5BT060 46,500 TDR 13.50 — 13.50 12.45

CK5A/CK5BW048 46,000 TDR 13.50 — 13.50 12.15

CK5A/CK5BX060 47,500 TDR 14.00 — 14.00 12.65

CK5PA048 46,000 TDR&TXV 13.50 — — 12.10

CK5PA060 46,500 TDR&TXV 13.50 — — 12.45 CK5PT048 46,000 TDR&TXV 13.50 — — 12.10 CK5PT060 46,500 TDR&TXV 13.50 — — 12.45

CK5PW048 46,000 TDR&TXV 13.50 — — 12.10

CK5PX060 47,500 TDR&TXV 14.00 — — 12.70

CC5A/CD5AA060 46,000 TDR 13.50 — 13.50 12.25 CC5A/CD5AC048 45,000 TDR 13.50 — 13.50 12.10 CC5A/CD5AW048 46,000 TDR 13.50 — 13.50 12.25 CC5A/CD5AW060 47,000 TDR 14.00 — 14.00 12.55

CD5AA048 46,000 TDR 13.50 — 13.50 12.25 CD5PX060 47,500 TDR&TXV 14.00 — — 12.65 CE3AA048 46,500 TDR 13.50 — 13.50 12.20 CE3AA060 47,000 TDR 14.00 — 14.00 12.55 CK3BA048 46,000 TDR 13.50 — 13.50 12.25 CK3BA060 46,500 TDR 13.50 — 13.50 12.55

CK5A/CK5BA048 46,000 TDR 13.50 — 13.50 12.25 CK5A/CK5BA060 46,500 TDR 13.50 — 13.50 12.55 CK5A/CK5BT048 46,000 TDR 13.50 — 13.50 12.25 CK5A/CK5BT060 46,500 TDR 13.50 — 13.50 12.55

CK5A/CK5BW048 46,000 TDR 13.50 — 13.50 12.25

CK5A/CK5BX060 47,500 TDR 14.00 — 14.00 12.75

CK5PA048 46,000 TDR&TXV 13.50 — — 12.15

CK5PA060 46,500 TDR&TXV 13.50 — — 12.55 CK5PT048 46,000 TDR&TXV 13.50 — — 12.15 CK5PT060 46,500 TDR&TXV 13.50 — — 12.55

CK5PW048 46,000 TDR&TXV 13.50 — — 12.15

CK5PX060 47,500 TDR&TXV 14.00 — — 12.75

CC5A/CD5AA060 46,500 TDR 13.00 — 13.00 11.55 CC5A/CD5AC048 45,000 TDR 12.50 — 12.50 11.20 CC5A/CD5AW060 47,000 TDR 13.50 — 13.50 12.00

CD5AA048 46,000 TDR 13.00 — 13.00 11.50 CE3AA048 46,500 TDR 13.00 — 13.00 11.55 CE3AA060 47,000 TDR 13.20 — 13.20 11.95

CC5A/CD5AA060 46,500 TDR 13.00 — 13.00 11.55 CC5A/CD5AC048 45,000 TDR 12.50 — 12.50 11.20 CC5A/CD5AW060 47,000 TDR 13.50 — 13.50 12.00

CD5AA048 46,000 TDR 13.00 — 13.00 11.50 CE3AA048 46,500 TDR 13.00 — 13.00 11.55 CE3AA060 47,000 TDR 13.20 — 13.20 11.95 CK3BA060 46,500 TDR 13.00 — 13.00 11.70

CK5A/CK5BA060 46,500 TDR 13.00 — 13.00 11.70 CK5A/CK5BT060 46,500 TDR 13.00 — 13.00 11.70 CK5A/CK5BX060 47,500 TDR 13.50 — 13.50 12.05

CAP.

BTUH

COILS + 315(A,J)AV060110 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE

COILS + 355MAV060080 VARIABLE-SPEED FURNACE

COILS + 355MAV060100 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

—19—

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

UNIT

SIZE-SERIES

048-F

See notes on page 22.

COMBINATION RATINGS Continued

FAC TORY-

TOT.

INDOOR

MODEL

CK5PA060 46,500 TDR&TXV 13.00 — — 11.70 CK5PT060 46,500 TDR&TXV 13.00 — — 11.70 CK5PX060 47,500 TDR&TXV 13.50 — — 12.05

CC5A/CD5AA060 46,500 TDR 13.00 — 13.00 11.55 CC5A/CD5AW048 46,000 TDR 13.00 — 13.00 11.50 CC5A/CD5AW060 47,000 TDR 13.50 — 13.50 12.00

CE3AA048 46,500 TDR 13.00 — 13.00 11.55 CE3AA060 47,000 TDR 13.20 — 13.20 11.95 CK3BA048 46,000 TDR 13.00 — 13.00 11.60 CK3BA060 46,500 TDR 13.00 — 13.00 11.80

CK5A/CK5BA060 46,500 TDR 13.00 — 13.00 11.80

CK5A/CK5BT060 46,500 TDR 13.00 — 13.00 11.80 CK5A/CK5BW048 46,000 TDR 13.00 — 13.00 11.60 CK5A/CK5BX060 47,500 TDR 13.50 — 13.50 12.15

CK5PA060 46,500 TDR&TXV 13.00 — — 11.80 CK5PT060 46,500 TDR&TXV 13.00 — — 11.80

CK5PW048 46,000 TDR&TXV 13.00 — — 11.60

CK5PX060 47,500 TDR&TXV 13.50 — — 12.15

CAP.

BTUH

COILS + 355MAV060120 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

SEER

Bryant Gas Furnace or

Accessory TDR†

Accessory

Puron TXV‡

EER

—20—

UNIT

SIZE-SERIES

060-H

See notes on page 22.

COMBINATION RATINGS Continued

SEER

FAC TORY-

TOT.

INDOOR

MODEL

*CD5PX060 59,000 TXV — 13.00 — — 11.05

CC5A/CD5AA060 56,000 NONE — — 12.50 — 10.65

CC5A/CD5AW060 58,000 NONE — — 12.50 — 10.90

CE3AA060 58,000 NONE — — 13.00 — 11.00

CK3BA060 58,000 NONE — — 12.50 — 10.95 CK5A/CK5BA060 58,000 NONE — — 12.50 — 10.95 CK5A/CK5BT060 58,000 NONE — — 12.50 — 10.95 CK5A/CK5BX060 59,000 NONE — — 13.00 — 11.10

CK5PA060 58,000 TXV — 12.50 — — 10.95 CK5PT060 58,000 TXV — 12.50 — — 10.95

CK5PX060 59,000 TXV — 13.00 — — 11.10

F(A,B)4BN(F,B,C)060 58,000 TDR — — — 12.50 10.70

FB4BNB070 59,000 TDR — — — 13.00 11.05

FC4CN(F,B)060 58,000 TDR&TXV 12.50 — — — 10.70

FC4CNB070 59,000 TDR&TXV 13.00 — — — 11.05

FE4ANB006 59,000 TDR&TXV 13.50 — — — 11.75 FG3AAA060 57,000 NONE — — 12.50 — 10.80 FK4DNB006 59,000 TDR&TXV 13.50 — — — 11.75

FV4BNB006 59,000 TDR&TXV 13.50 — — — 11.75

FX4BNB060 59,000 TDR&TXV 13.00 — — — 11.05

CC5A/CD5AA060 56,000 TDR — — — 12.50 10.75

CD5PX060 58,000 TDR&TXV 13.00 — — — 11.10 CE3AA060 58,000 TDR — — — 13.00 11.10

CK3BA060 57,500 TDR — — — 13.00 11.10 CK5A/CK5BA060 57,500 TDR — — — 13.00 11.10 CK5A/CK5BT060 57,500 TDR — — — 13.00 11.10 CK5A/CK5BX060 58,500 TDR — — — 13.00 11.25

CK5PA060 57,500 TDR&TXV 13.00 — — — 11.10 CK5PT060 57,500 TDR&TXV 13.00 — — — 11.10

CK5PX060 58,500 TDR&TXV 13.00 — — — 11.25

CC5A/CD5AA060 56,000 TDR — — — 12.50 10.90

CD5PX060 58,000 TDR&TXV 13.00 — — — 11.30

CE3AA060 58,000 TDR — — — 13.00 11.30

CK3BA060 57,500 TDR — — — 13.00 11.25 CK5A/CK5BA060 57,500 TDR — — — 13.00 11.25 CK5A/CK5BT060 57,500 TDR — — — 13.00 11.25 CK5A/CK5BX060 58,500 TDR — — — 13.00 11.40

CK5PA060 57,500 TDR&TXV 13.00 — — — 11.25 CK5PT060 57,500 TDR&TXV 13.00 — — — 11.25

CK5PX060 58,500 TDR&TXV 13.00 — — — 11.40

CC5A/CD5AA060 56,000 TDR — — — 13.00 11.00

CD5PX060 58,000 TDR&TXV 13.00 — — — 11.40

CE3AA060 58,000 TDR — — — 13.00 11.40

CK3BA060 57,500 TDR — — — 13.00 11.35 CK5A/CK5BA060 57,500 TDR — — — 13.00 11.35 CK5A/CK5BT060 57,500 TDR — — — 13.00 11.35 CK5A/CK5BX060 58,500 TDR — — — 13.00 11.50

CK5PA060 57,500 TDR&TXV 13.00 — — — 11.35 CK5PT060 57,500 TDR&TXV 13.00 — — — 11.35

CK5PX060 58,500 TDR&TXV 13.00 — — — 11.50

CK3BA060 57,500 TDR — — — 12.50 10.70 CK5A/CK5BA060 57,500 TDR — — — 12.50 10.70 CK5A/CK5BT060 57,500 TDR — — — 12.50 10.70

CK5PA060 57,500 TDR&TXV 12.50 — — — 10.70 CK5PT060 57,500 TDR&TXV 12.50 — — — 10.70

CK3BA060 57,500 TDR — — — 12.50 10.80 CK5A/CK5BA060 57,500 TDR — — — 12.50 10.85 CK5A/CK5BT060 57,500 TDR — — — 12.50 10.85

CK5PA060 57,500 TDR&TXV 12.50 — — — 10.85 CK5PT060 57,500 TDR&TXV 12.50 — — — 10.85

CC5A/CD5AA060 56,000 TDR — — — 12.50 10.55

CK3BA060 57,500 TDR — — — 12.50 10.90 CK5A/CK5BA060 57,500 TDR — — — 12.50 10.95 CK5A/CK5BT060 57,500 TDR — — — 12.50 10.95 CK5A/CK5BX060 58,500 TDR — — — 13.00 11.05

CK5PA060 57,500 TDR&TXV 12.50 — — — 10.95 CK5PT060 57,500 TDR&TXV 12.50 — — — 10.95

CK5PX060 58,500 TDR&TXV 13.00 — — — 11.05

CAP.

BTUH

COILS + 315(A,J)AV060110 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE

COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE

COILS + 355MAV060080 VARIABLE-SPEED FURNACE

COILS + 355MAV060100 VARIABLE-SPEED FURNACE

COILS + 355MAV060120 VARIABLE-SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

Standard

Rating

Bryant Gas Furnace or

Accessory

TDR†

Bryant Gas

Furnace or Accessory

TDR + TXV‡

Accessory

Puron TXV‡

EER

—21—

*Tested combination.

† In most cases, only one method should be used to achieve TDR function. Using more than one method in a system may cause degradation in performance.

Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Bryant furnaces are equipped with TDR.

‡ TXV must be Puron compatible and hard shutoff type.

EER — Energy Efﬁciency Ratio LLS — Liquid-Line Solenoid Valve SEER — Seasonal Energy Efﬁciency Ratio TDR — Time-Delay Relay TXV — Thermostatic Expansion Valve NOTES: 1. Ratings are net values reﬂecting the effects of circulating fan motor heat. Supplemental electric heat is not included.

2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for electric air conditioners. Ratings for other combinations are determined under DOE computer simulation procedures.

3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.

4. Do not apply with capillary tube coils as performance and reliability are signiﬁcantly affected.

—22—

DETAILED COOLING CAPACITIES*

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A024-G Outdoor Section With CC5A/CD5AA030 Indoor Section

57 21.18 21.18 1.55 20.24 20.24 1.75 19.29 19.29 1.98 18.25 18.25 2.22 17.12 17.12 2.47 15.93 15.93 2.75 62 22.64 20.05 1.55 21.22 19.43 1.77 19.94 18.79 1.99 18.56 18.06 2.22 17.12 17.12 2.47 15.93 15.93 2.75

700

67 24.77 16.75 1.56 23.85 16.60 1.78 22.47 16.09 2.02 21.00 15.48 2.28 19.45 14.85 2.53 17.78 14.18 2.81 72 25.81 13.18 1.58 25.61 13.23 1.79 24.84 13.05 2.03 23.58 12.61 2.29 22.06 12.07 2.57 20.37 11.46 2.87

57 22.22 22.22 1.58 21.17 21.17 1.80 20.15 20.15 2.03 19.06 19.06 2.27 17.91 17.91 2.53 16.64 16.64 2.81 62 23.20 21.31 1.59 21.76 20.74 1.81 20.42 20.01 2.03 19.06 19.06 2.27 17.91 17.91 2.53 16.64 16.64 2.81

800

67 25.02 17.33 1.60 24.32 17.46 1.81 23.00 17.09 2.05 21.46 16.52 2.32 19.85 15.87 2.58 18.15 15.19 2.86 72 25.88 13.37 1.62 25.75 13.52 1.83 25.15 13.50 2.07 23.95 13.15 2.33 22.44 12.65 2.61 20.72 12.06 2.91

57 23.03 23.03 1.62 22.01 22.01 1.84 20.90 20.90 2.07 19.81 19.81 2.32 18.59 18.59 2.59 17.27 17.27 2.87 62 23.64 22.41 1.63 22.28 21.90 1.84 20.89 20.89 2.07 19.80 19.80 2.32 18.58 18.58 2.59 17.27 17.27 2.87

900

67 25.15 17.80 1.64 24.64 18.20 1.85 23.38 18.01 2.09 21.84 17.50 2.35 20.17 16.86 2.63 18.42 16.15 2.91 72 25.90 13.52 1.65 25.81 13.75 1.87 25.31 13.85 2.11 24.19 13.62 2.37 22.71 13.17 2.64 20.99 12.62 2.95

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 024 0.99 1.00 CK3BA 024 0.97 0.88

030 1.00 1.00 030 0.99 0.89

CC5A/CD5AW 024 0.99 1.00 CK5A/CK5BA 024 0.97 0.89

030 1.00 1.00 030 0.99 0.90

CE3AA 024 0.99 0.99 CK5A/CK5BW 024 0.97 0.89

030 1.00 0.99 030 0.99 0.89 CF5AA 024 0.99 1.00 CK5PA 024 0.97 0.89 CK3BA 024 0.99 0.99 030 0.99 0.90

030 1.00 0.99 CK5PW 024 0.97 0.89

CK5A/CK5BA 024 0.99 0.99 030 0.99 0.90

030 1.00 0.99

CK5A/CK5BW 024 0.99 0.99 CC5A/CD5AA 024 0.97 0.89

030 1.00 0.99 030 0.99 0.89 CK5PA 024 0.99 0.99 CC5A/CD5AW 024 0.97 0.89

030 1.00 0.99 030 0.99 0.89

CK5PW 024 0.99 0.99 CE3AA 024 0.97 0.89

030 1.00 0.99 030 0.99 0.89

F(A,B)4BN(F,C) 024 1.00 0.99 CK3BA 024 0.97 0.87

030 1.02 1.00 030 0.99 0.88

FC4CNF 024 1.00 0.99 CK5A/CK5BA 024 0.97 0.88

030 1.02 0.99 030 0.99 0.89

FE4ANF 002 1.03 0.90 CK5A/CK5BW 024 0.97 0.88

003 1.03 0.89 030 0.99 0.89

FF1DNA 024 1.00 1.00 CK5PA 024 0.97 0.89

030 1.02 1.01 030 0.99 0.89

FF1DNE 024 1.00 1.00 CK5PW 024 0.97 0.88

030 1.02 1.01 030 0.99 0.89

FG3AAA 024 0.96 0.98 FK4DNF 001 1.02 0.90 CC5A/CD5AW 024 0.97 0.89

002 1.03 0.90 030 0.99 0.90

003 1.03 0.89 CE3AA 024 0.97 0.90

FV4BNF 002 1.03 0.90 030 0.99 0.89

003 1.03 0.89 CK3BA 024 0.97 0.87

FX4BNF 030 1.02 0.98 030 0.99 0.89

COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE

CC5A/CD5AA 024 0.97 0.90 030 0.99 0.89

030 0.99 0.90 CK5PW 024 0.97 0.89

CC5A/CD5AW 024 0.97 0.90 030 0.99 0.90

030 0.99 0.90 CE3AA 024 0.97 0.89 CE3AA 024 0.97 0.89

030 0.99 0.90 030 0.99 0.89

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE

CK5A/CK5BW 024 0.97 0.89

COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—23—

DETAILED COOLING CAPACITIES* continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A024-G Outdoor Section With CC5A/CD5AA030 Indoor Section continued

700

800

900

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE

CE3AA 024 0.97 0.89 030 0.99 0.89

030 0.99 0.89 CK5PW 024 0.97 0.89

COILS + 355MAV042040 VARIABLE SPEED FURNACE

CE3AA 024 0.97 0.90

030 0.99 0.90 CC5A/CD5AW 024 0.97 0.89

COILS + 355MAV042060 VARIABLE SPEED FURNACE

CC5A/CD5AA 024 0.97 0.90 CE3AA 024 0.97 0.89

030 0.99 0.90 030 0.99 0.90

CC5A/CD5AW 024 0.97 0.89 CK3BA 024 0.97 0.88

030 0.99 0.90 030 0.99 0.89

CE3AA 024 0.97 0.89 CK5A/CK5BW 024 0.97 0.88

030 0.99 0.90 030 0.99 0.89

CK3BA 024 0.97 0.87 CK5PW 024 0.97 0.89

030 0.99 0.89 030 0.99 0.90

CK5A/CK5BA 024 0.97 0.89

030 0.99 0.90 CC5A/CD5AW 024 0.97 0.89

CK5A/CK5BW 024 0.97 0.88 030 0.99 0.90

030 0.99 0.89 CE3AA 024 0.97 0.89

CK5PA 024 0.97 0.89 030 0.99 0.89

030 0.99 0.90 CK3BA 024 0.97 0.87

CK5PW 024 0.97 0.89 030 0.99 0.89

030 0.99 0.90 CK5A/CK5BW 024 0.97 0.88

COILS + 355MAV042080 VARIABLE SPEED FURNACE

CC5A/CD5AW 024 0.97 0.90 CK5PW 024 0.97 0.89

030 0.99 0.90 030 0.99 0.90

CE3AA 024 0.97 0.90

030 0.99 0.90 CE3AA 024 0.97 0.90

CK3BA 024 0.97 0.88 030 0.99 0.90

030 0.99 0.89 — — —

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

CK5A/CK5BW 024 0.97 0.89

030 0.99 0.90

COILS + 355MAV060080 VARIABLE SPEED FURNACE

030 0.99 0.90

COILS + 355MAV060100 VARIABLE SPEED FURNACE

030 0.99 0.89

COILS + 355MAV060120 VARIABLE SPEED FURNACE

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—24—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A030-F Outdoor Section With CC5A/CD5AA036 Indoor Section

72 33.4 16.3 1.80 32.2 15.9 1.99 31.1 15.6 2.21 29.7 15.2 2.46 27.9 14.5 2.73 26.0 13.9 3.05

1875

1000

1125

See notes on page 38.

67 31.4 21.2 1.79 30.0 20.7 1.97 28.6 20.1 2.19 27.0 19.6 2.43 24.5 18.6 2.69 21.7 17.5 2.97 63†† 29.4 20.9 1.77 27.8 20.2 1.96 25.1 19.0 2.15 22.3 17.8 2.37 20.4 17.0 2.63 18.2 16.1 2.91 62 28.6 25.7 1.77 26.6 24.7 1.95 24.5 23.6 2.15 22.3 22.3 2.37 20.5 20.5 2.63 19.4 19.4 2.93 57 26.6 26.6 1.75 25.1 25.1 1.93 23.6 23.6 2.14 21.9 21.9 2.37 20.8 20.8 2.63 19.6 19.6 2.93

72 33.9 16.9 1.85 32.7 16.5 2.04 31.6 16.3 2.26 30.0 15.8 2.50 28.2 15.2 2.78 26.3 14.7 3.10 67 31.9 22.3 1.83 30.5 21.8 2.02 29.0 21.3 2.23 27.4 20.8 2.47 25.2 20.0 2.74 22.3 18.9 3.02 63†† 30.0 22.1 1.82 28.5 21.5 2.00 25.8 20.3 2.20 23.1 19.2 2.42 21.1 18.3 2.68 18.9 17.4 2.96 62 29.4 27.5 1.81 27.2 26.4 1.99 25.1 25.1 2.19 23.3 23.3 2.43 22.3 22.3 2.69 20.3 20.3 2.99 57 27.9 27.9 1.80 26.4 26.4 1.99 24.7 24.7 2.19 23.7 23.7 2.43 22.6 22.6 2.70 20.4 20.4 2.99

72 34.2 17.4 1.89 33.0 17.1 2.08 31.7 16.7 2.30 30.1 16.3 2.54 28.5 15.9 2.82 26.5 15.4 3.15 67 32.2 23.3 1.87 30.8 22.9 2.06 29.3 22.4 2.27 27.7 22.0 2.51 25.7 21.3 2.78 22.7 20.2 3.07 63†† 30.3 23.1 1.86 29.0 22.7 2.05 26.3 21.6 2.25 24.1 20.6 2.47 21.8 19.6 2.73 19.6 18.7 3.01 62 29.9 29.0 1.86 28.1 27.9 2.04 26.6 26.6 2.25 25.1 25.1 2.49 23.8 23.8 2.75 21.2 21.2 3.04 57 29.5 29.5 1.85 28.2 28.2 2.04 26.6 26.6 2.25 25.3 25.3 2.49 23.5 23.5 2.75 21.1 21.1 3.04

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 030 0.97 1.00 CK5A/CK5BT 036 1.00 0.93

036 1.00 1.00 CK5A/CK5BW 030 0.97 0.92

CC5A/CD5AW 030 0.97 1.00 CK5PA 030 0.99 0.94

036 1.00 1.00 036 1.00 0.93 CE3AA 030 0.97 0.98 CK5PT 036 1.00 0.93

036 0.98 0.99 CK5PW 030 0.99 0.94 CF5AA 036 0.98 0.98 CK3BA 030 0.97 0.99 CC5A/CD5AA 030 0.97 0.92

036 1.00 1.00 036 1.00 0.92

CK5A/CK5BA 030 0.97 0.99 CC5A/CD5AW 030 0.97 0.92

036 1.00 1.00 036 1.00 0.92

CK5A/CK5BT 036 1.00 1.00 CE3AA 030 0.99 0.93

CK5A/CK5BW 030 0.97 0.99 036 0.99 0.92

036 1.00 1.00 CK3BA 030 0.97 0.91 CK5PA 030 0.97 0.99 036 1.00 0.92

036 1.00 1.00 CK5A/CK5BA 030 0.97 0.91 CK5PT 036 1.00 1.00 036 1.00 0.92

CK5PW 030 0.97 0.99 CK5A/CK5BW 030 0.99 0.93

036 1.00 1.00 036 1.00 0.92

F(A,B)4(A,B)N(F,C) 030 0.99 1.00 CK5PA 030 0.99 0.94

036 1.00 1.02 036 1.00 0.92

FE4ANF 002 1.00 0.93 CK5PT 36 1.00 0.92

003 1.02 0.91 CK5PW 030 0.99 0.94

FF1DNA 030 0.99 1.00 036 1.00 0.92 FG3AAA 036 0.98 1.00

FK4(C,D)NF 001 0.99 0.91

002 1.00 0.93

003 1.02 0.92

FV4(A,B)NF 002 1.00 0.93

003 1.02 0.91

FX4(A,B)NF 030 0.99 1.00

036 1.00 1.02

COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE CK5A/CK5BA 036 1.00 0.90

CC5A/CD5AA 030 0.97 0.93

036 1.00 0.93

CC5A/CD5AW 030 0.97 0.93

CE3AA 030 0.98 0.93

036 0.99 0.93 CK3BA 030 0.97 0.92

036 1.00 0.93

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE

CC5A/CD5AA 036 1.00 0.90 CC5A/CD5AW 030 0.97 0.90

036 1.00 0.90

CE3AA 030 0.99 0.91

036 1.00 0.91

CK3BA 030 0.99 0.90

036 1.00 0.90

CK5A/CK5BT 036 1.00 0.90

CK5A/CK5BW 030 0.99 0.91

036 1.00 0.90

CK5PA 036 1.00 0.90

CK5PT 036 1.00 0.90

CK5PW 030 0.99 0.91

036 1.00 0.90

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—25—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

72 33.4 16.3 1.80 32.2 15.9 1.99 31.1 15.6 2.21 29.7 15.2 2.46 27.9 14.5 2.73 26.0 13.9 3.05 67 31.4 21.2 1.79 30.0 20.7 1.97 28.6 20.1 2.19 27.0 19.6 2.43 24.5 18.6 2.69 21.7 17.5 2.97

1875

63†† 29.4 20.9 1.77 27.8 20.2 1.96 25.1 19.0 2.15 22.3 17.8 2.37 20.4 17.0 2.63 18.2 16.1 2.91 62 28.6 25.7 1.77 26.6 24.7 1.95 24.5 23.6 2.15 22.3 22.3 2.37 20.5 20.5 2.63 19.4 19.4 2.93 57 26.6 26.6 1.75 25.1 25.1 1.93 23.6 23.6 2.14 21.9 21.9 2.37 20.8 20.8 2.63 19.6 19.6 2.93

72 33.9 16.9 1.85 32.7 16.5 2.04 31.6 16.3 2.26 30.0 15.8 2.50 28.2 15.2 2.78 26.3 14.7 3.10 67 31.9 22.3 1.83 30.5 21.8 2.02 29.0 21.3 2.23 27.4 20.8 2.47 25.2 20.0 2.74 22.3 18.9 3.02

1000

63†† 30.0 22.1 1.82 28.5 21.5 2.00 25.8 20.3 2.20 23.1 19.2 2.42 21.1 18.3 2.68 18.9 17.4 2.96 62 29.4 27.5 1.81 27.2 26.4 1.99 25.1 25.1 2.19 23.3 23.3 2.43 22.3 22.3 2.69 20.3 20.3 2.99 57 27.9 27.9 1.80 26.4 26.4 1.99 24.7 24.7 2.19 23.7 23.7 2.43 22.6 22.6 2.70 20.4 20.4 2.99

72 34.2 17.4 1.89 33.0 17.1 2.08 31.7 16.7 2.30 30.1 16.3 2.54 28.5 15.9 2.82 26.5 15.4 3.15 67 32.2 23.3 1.87 30.8 22.9 2.06 29.3 22.4 2.27 27.7 22.0 2.51 25.7 21.3 2.78 22.7 20.2 3.07

1125

63†† 30.3 23.1 1.86 29.0 22.7 2.05 26.3 21.6 2.25 24.1 20.6 2.47 21.8 19.6 2.73 19.6 18.7 3.01 62 29.9 29.0 1.86 28.1 27.9 2.04 26.6 26.6 2.25 25.1 25.1 2.49 23.8 23.8 2.75 21.2 21.2 3.04 57 29.5 29.5 1.85 28.2 28.2 2.04 26.6 26.6 2.25 25.3 25.3 2.49 23.5 23.5 2.75 21.1 21.1 3.04

Indoor

Section Size

COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE COILS + 355MAV042060 VARIABLE SPEED FURNACE

CC5A/CD5AW 036 1.00 0.89

CE3AA 030 0.99 0.90

CK5A/CK5BW 036 1.00 0.89

CK5PW 036 1.00 0.89

COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE

CC5A/CD5AW 036 1.00 0.89

CE3AA 030 0.99 0.90

CK5A/CK5BW 036 1.00 0.88

CK5PW 036 1.00 0.89

COILS + 355MAV042040 VARIABLE SPEED FURNACE

CC5A/CD5AW 030 0.98 0.95 036 1.02 0.94

CE3AA 030 1.00 0.96 036 1.01 0.95

CK3BA 030 0.98 0.96 036 1.02 0.94

CK5A/CK5BW 030 0.98 0.96 036 1.02 0.94

CK5PW 030 0.98 0.96 036 1.02 0.94

See notes on page 38.

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

550A030-F Outdoor Section With CC5A/CD5AA036 Indoor Section Continued

036 1.00 0.90

036 1.02 0.96 CE3AA 030 1.00 0.95

036 1.01 0.96 CK3BA 030 0.99 0.96

036 1.02 0.96 CK5A/CK5BW 030 0.99 0.96

036 1.02 0.96 CK5PW 030 0.99 0.96

036 1.02 0.96 — — —

Capacity

MBtuh†

Multipliers for Determining the Performance With Other Indoor Sections

Capacity Power Capacity Power

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Cooling

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Indoor

Section Size

CC5A/CD5AA 036 1.02 0.96

CC5A/CD5AW 030 0.98 0.95

CK3BA 030 0.98 0.96

CK5A/CK5BA 036 1.02 0.96 CK5A/CK5BT 036 1.02 0.96

CK5A/CK5BW 030 0.98 0.96

CK5PA 036 1.02 0.96 CK5PT 036 1.02 0.96

CK5PW 030 0.98 0.96

COILS + 355MAV042080 VARIABLE SPEED FURNACE

CC5A/CD5AW 030 0.99 0.95

Total

kW**

Capacity

Sys

MBtuh†

036 1.02 0.96

Total

Sys

kW**

Capacity

MBtuh†

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—26—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A036-F Outdoor Section With CC5A/CD5AA042 Indoor Section

72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64 67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57

1050

63†† 34.9 24.6 2.12 32.5 23.6 2.35 30.1 22.5 2.60 27.5 21.4 2.87 24.9 20.3 3.17 22.3 19.2 3.50 62 33.9 30.2 2.12 31.6 29.1 2.34 29.2 27.9 2.59 26.7 26.5 2.86 24.5 24.5 3.17 23.2 23.2 3.51 57 31.3 31.3 2.09 29.5 29.5 2.32 27.5 27.5 2.57 26.4 26.4 2.86 25.1 25.1 3.17 23.6 23.6 3.51

72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70 67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62

1200

63†† 36.1 26.3 2.18 33.6 25.2 2.41 31.1 24.1 2.66 28.3 23.0 2.93 26.0 22.0 3.24 23.3 20.9 3.56 62 34.8 32.4 2.17 32.4 31.2 2.39 30.0 29.7 2.65 27.9 27.9 2.93 26.8 26.8 3.25 24.6 24.6 3.58 57 32.7 32.7 2.15 31.0 31.0 2.38 29.9 29.9 2.64 28.7 28.7 2.94 27.3 27.3 3.25 24.8 24.8 3.58

72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75 67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68

1350

63†† 36.9 27.8 2.23 34.5 26.8 2.46 31.9 25.7 2.71 29.4 24.6 2.99 26.9 23.6 3.30 24.2 22.4 3.62 62 35.8 34.5 2.22 33.2 32.9 2.45 31.1 31.1 2.70 30.0 30.0 3.00 28.6 28.6 3.32 25.8 25.8 3.65 57 34.8 34.8 2.22 33.3 33.3 2.45 32.0 32.0 2.72 30.7 30.7 3.01 28.3 28.3 3.32 25.9 25.9 3.65

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 036 1.00 1.00 CK5PT 036 1.00 0.94

042 1.00 1.00

CC5A/CD5AW 036 1.00 1.00 CC5A/CD5AA 036 1.00 0.93

CE3AA 036 1.00 1.01 042 1.00 0.92

042 1.00 0.99 CC5A/CD5AW 036 1.00 0.93 CF5AA 036 1.00 1.00 CE3AA 036 1.00 0.94 CK3BA 036 1.00 1.00 042 1.00 0.92

042 1.00 1.00 CK3BA 036 1.00 0.93

CK5A/CK5BA 036 1.00 1.00 042 1.00 0.92

042 1.00 1.00 CK5A/CK5BA 036 1.00 0.93

CK5A/CK5BT 036 1.00 1.00 042 1.00 0.92

042 1.00 1.00 CK5A/CK5BE 042 1.00 0.92

CK5A/CK5BW 036 1.00 1.00 CK5A/CK5BT 036 1.00 0.93

CK5PA 036 1.00 1.00 042 1.00 0.92

042 1.00 1.00 CK5A/CK5BW 036 1.00 0.93 CK5PT 036 1.00 1.00 CK5PA 036 1.00 0.93

042 1.00 1.00 042 1.00 0.92

CK5PW 036 1.00 1.00 CK5PE 042 1.00 0.92

F(A,B)4(A,B)N(F,B,C) 042 1.00 1.00 CK5PT 036 1.00 0.93

F(A,B)4(A,B)N(F,C) 036 1.00 1.00 042 1.00 0.92

FE4ANF 002 1.00 0.95 CK5PW 036 1.00 0.93

003 1.00 0.93

005 1.03 0.94

FG3AAA 036 1.00 1.02

FK4(C,D)NF 002 1.00 0.95

003 1.00 0.93

005 1.03 0.94

FV4(A,B)NF 002 1.00 0.95

003 1.00 0.93

005 1.03 0.94

FX4(A,B)NF 036 0.97 0.99

042 1.00 1.00

COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE CK5A/CK5BE 042 1.00 0.92

CC5A/CD5AA 036 1.00 0.95

CE3AA 036 1.00 0.96

042 1.00 0.94 CK3BA 036 1.00 0.94

CK5A/CK5BA 036 1.00 0.94 CK5A/CK5BE 042 1.00 0.93 CK5A/CK5BT 036 1.00 0.94

CK5PA 036 1.00 0.94 CK5PE 042 1.00 0.93

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE

CC5A/CD5AA 036 1.00 0.93

042 1.00 0.93

CC5A/CD5AW 036 1.00 0.93

042 1.00 0.94

CE3AA 036 1.00 0.94

042 1.00 0.92

CK3BA 036 1.00 0.93

042 1.00 0.93

CK5A/CK5BA 036 1.00 0.93

042 1.00 0.93

CK5A/CK5BT 036 1.00 0.93

042 1.00 0.93

CK5A/CK5BW 036 1.00 0.93

CK5PA 036 1.00 0.93

042 1.00 0.93

CK5PT 036 1.00 0.93

042 1.00 0.93

CK5PW 036 1.00 0.93

CK5PE 042 1.00 0.92

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—27—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A036-F Outdoor Section With CC5A/CD5AA042 Indoor Section continued

72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64 67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57

1050

72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70 67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62

1200

72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75 67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68

1350

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 1.00 0.92 042 1.00 0.97

CC5A/CD5AW 036 1.00 0.93 CK3BA 036 1.00 0.97

042 1.00 0.92 042 1.00 0.97

CE3AA 036 1.00 0.94 CK5A/CK5BA 036 1.00 0.97

042 1.00 0.92 CK5A/CK5BT 036 1.00 0.97

CK3BA 042 1.00 0.92 CK5A/CK5BW 036 1.00 0.97 CK5A/CK5BA 042 1.00 0.92 CK5PA 036 1.00 0.97 CK5A/CK5BT 042 1.00 0.92 CK5PT 036 1.00 0.97

CK5A/CK5BW 036 1.00 0.93 CK5PW 036 1.00 0.97

CK5PA 042 1.00 0.92

CK5PT 042 1.00 0.92 CC5A/CD5AA 042 1.00 0.95

CK5PW 036 1.00 0.93 CC5A/CD5AW 036 1.00 0.96

COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 1.00 0.91 042 1.00 0.95

CC5A/CD5AW 036 1.00 0.93 CK3BA 036 1.00 0.97

042 1.00 0.91 042 1.00 0.95

CE3AA 036 1.00 0.93 CK5A/CK5BA 042 1.00 0.95

042 1.00 0.91 CK5A/CK5BT 042 1.00 0.95

CK3BA 042 1.00 0.91 CK5A/CK5BW 036 1.00 0.97 CK5A/CK5BA 042 1.00 0.91 CK5PA 042 1.00 0.95 CK5A/CK5BT 042 1.00 0.91 CK5PT 042 1.00 0.95

CK5A/CK5BW 036 1.00 0.92 CK5PW 036 1.00 0.97

CK5PA 042 1.00 0.91

CK5PT 042 1.00 0.91 CC5A/CD5AA 042 1.00 0.94

CK5PW 036 1.00 0.92 CC5A/CD5AW 036 1.00 0.95

COILS + 355MAV042040 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 1.00 0.97 042 1.00 0.94

CE3AA 036 1.00 0.99 CK3BA 036 1.00 0.98

042 1.00 0.97 042 1.00 0.97

CK3BA 036 1.00 0.98 CK5A/CK5BA 042 1.00 0.97

042 1.00 0.98 CK5A/CK5BT 042 1.00 0.97 CK5A/CK5BA 042 1.00 0.98 CK5A/CK5BW 036 1.00 0.98 CK5A/CK5BT 042 1.00 0.98 CK5PA 042 1.00 0.97

CK5A/CK5BW 036 1.00 0.98 CK5PT 042 1.00 0.97

CK5PA 042 1.00 0.98 CK5PW 036 1.00 0.98 CK5PT 042 1.00 0.98

CK5PW 036 1.00 0.98 CC5A/CD5AA 042 1.00 0.94

COILS + 355MAV042060 VARIABLE SPEED FURNACE

CC5A/CD5AA 036 1.00 0.98 CE3AA 036 1.00 0.97

—— — 042 1.00 0.94

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

CE3AA 036 1.00 0.99

COILS + 355MAV042080 VARIABLE SPEED FURNACE

CE3AA 036 1.00 0.97

COILS + 355MAV060080 VARIABLE SPEED FURNACE

CE3AA 036 1.00 0.97

COILS + 355MAV060100 VARIABLE SPEED FURNACE

CC5A/CD5AW 036 1.00 0.95

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—28—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A036-F Outdoor Section With CC5A/CD5AA042 Indoor Section continued

72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64 67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57

1050

72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70 67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62

1200

72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75 67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68

1350

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CK3BA 036 1.00 0.95 CC5A/CD5AW 036 1.00 0.95

042 1.00 0.93 CE3AA 036 1.00 0.97 CK5A/CK5BA 042 1.00 0.93 042 1.00 0.94 CK5A/CK5BT 042 1.00 0.93 CK3BA 036 1.00 0.95

CK5A/CK5BW 036 1.00 0.95 042 1.00 0.93

CK5PA 042 1.00 0.93 CK5A/CK5BA 042 1.00 0.93 CK5PT 042 1.00 0.93 CK5A/CK5BT 042 1.00 0.93

CK5PW 036 1.00 0.95 CK5A/CK5BW 036 1.00 0.95

COILS + 355MAV060120 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 1.00 0.94 CK5PT 042 1.00 0.93

—— — CK5PW 036 1.00 0.95

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

CK5PA 042 1.00 0.93

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—29—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A036-G Outdoor Section With CC5A/CD5AA042 Indoor Section

72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64 67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57

1050

72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70 67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62

1200

72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75 67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68

1350

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 036* 1.00 1.00

042 1.00 1.00 CC5A/CD5AA 036 0.98 0.93

CC5A/CD5AW 036 1.00 1.00 CE3AA 036 0.97 0.93

042 0.99 1.00 042 0.99 0.93

CE3AA 036 0.99 1.00 CK3BA 036 0.99 0.93

042 1.00 0.99 CK5A/CK5BA 036 0.99 0.93 CF5AA 036 1.00 1.00 CK5A/CK5BE 042 0.99 0.93 CK3BA 036 1.00 1.00 CK5A/CK5BT 036 0.99 0.93

042 1.00 1.00 CK5PA 036 0.99 0.94

CK5A/CK5BA 036 1.00 1.00 CK5PE 042 0.99 0.93

042 1.00 1.00 CK5PT 036 0.99 0.94

CK5A/CK5BE 042 1.00 0.99 CK5A/CK5BT 036 1.00 1.00 CC5A/CD5AA 036 0.98 0.92

042 1.00 1.00 042 0.98 0.91

CK5A/CK5BW 036 1.00 1.00 CC5A/CD5AW 036 0.98 0.91

CK5PA 036 1.00 1.00 CE3AA 036 0.97 0.92

042 1.00 1.00 042 0.99 0.91 CK5PE 042 1.00 0.99 CK3BA 036 0.99 0.92 CK5PT 036 1.00 1.00 042 0.99 0.92

042 1.00 1.00 CK5A/CK5BA 036 0.99 0.92

CK5PW 036 1.00 1.00 042 0.99 0.92

F(A,B)4BN(F,B,C) 042 1.00 1.01 CK5A/CK5BE 042 0.99 0.91

F(A,B)4BN(F,C) 036 0.99 1.02 CK5A/CK5BT 036 0.99 0.92

FC4CN(F,B) 042 1.00 1.00 042 0.99 0.92

FC4CNF 036 0.99 1.02 CK5A/CK5BW 036 0.99 0.92 FE4ANB 006 1.03 0.89 CK5PA 036 0.99 0.92 FE4ANF 002 1.00 0.94 042 0.99 0.92

003 1.00 0.91 CK5PE 042 0.99 0.91

005 1.03 0.90 CK5PT 036 0.99 0.92

FG3AAA 036 0.97 1.00 042 0.99 0.92

048 1.00 1.01 CK5PW 036 0.99 0.92

FK4DNB 006 1.03 0.89 FK4DNF 001 0.99 0.95 CC5A/CD5AA 036 0.98 0.92

002 1.00 0.94 042 0.98 0.91

003 1.00 0.91 CC5A/CD5AW 036 0.98 0.91

005 1.03 0.90 042 0.98 0.91

FV4BNB 006 1.03 0.89 CE3AA 036 0.97 0.92 FV4BNF 002 1.00 0.94 042 0.99 0.91

003 1.00 0.91 CK3BA 036 0.99 0.92

005 1.03 0.90 042 0.99 0.92

FX4BNF 036 1.00 1.01 CK5A/CK5BA 036 0.99 0.92

042 1.02 1.01 042 0.99 0.92

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE

COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE

COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—30—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A036-G Outdoor Section With CC5A/CD5AA042 Indoor Section continued

72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64

1050

1200

1350

See notes on page 38.

67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57 63†† 34.9 24.6 2.12 32.5 23.6 2.35 30.1 22.5 2.60 27.5 21.4 2.87 24.9 20.3 3.17 22.3 19.2 3.50 62 33.9 30.2 2.12 31.6 29.1 2.34 29.2 27.9 2.59 26.7 26.5 2.86 24.5 24.5 3.17 23.2 23.2 3.51 57 31.3 31.3 2.09 29.5 29.5 2.32 27.5 27.5 2.57 26.4 26.4 2.86 25.1 25.1 3.17 23.6 23.6 3.51

72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70 67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62 63†† 36.1 26.3 2.18 33.6 25.2 2.41 31.1 24.1 2.66 28.3 23.0 2.93 26.0 22.0 3.24 23.3 20.9 3.56 62 34.8 32.4 2.17 32.4 31.2 2.39 30.0 29.7 2.65 27.9 27.9 2.93 26.8 26.8 3.25 24.6 24.6 3.58 57 32.7 32.7 2.15 31.0 31.0 2.38 29.9 29.9 2.64 28.7 28.7 2.94 27.3 27.3 3.25 24.8 24.8 3.58

72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75 67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68 63†† 36.9 27.8 2.23 34.5 26.8 2.46 31.9 25.7 2.71 29.4 24.6 2.99 26.9 23.6 3.30 24.2 22.4 3.62 62 35.8 34.5 2.22 33.2 32.9 2.45 31.1 31.1 2.70 30.0 30.0 3.00 28.6 28.6 3.32 25.8 25.8 3.65 57 34.8 34.8 2.22 33.3 33.3 2.45 32.0 32.0 2.72 30.7 30.7 3.01 28.3 28.3 3.32 25.9 25.9 3.65

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CK5A/CK5BE 042 0.99 0.91 CE3AA 036 0.97 0.94 CK5A/CK5BT 036 0.99 0.92 042 0.99 0.93

042 0.99 0.92 CK3BA 042 0.99 0.94

CK5A/CK5BW 036 0.99 0.92 CK5A/CK5BA 042 0.99 0.94

CK5PA 036 0.99 0.92 CK5A/CK5BT 042 0.99 0.94

042 0.99 0.92 CK5A/CK5BW 036 0.99 0.94

CK5PE 042 0.99 0.91 CK5PA 042 0.99 0.94

CK5PT 036 0.99 0.92 CK5PT 042 0.99 0.94

042 0.99 0.92 CK5PW 036 0.99 0.94

CK5PW 036 0.99 0.92

COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 0.98 0.91 042 0.98 0.92

CC5A/CD5AW 036 0.98 0.91 CC5A/CD5AW 036 0.98 0.92

042 0.98 0.91 CE3AA 036 0.97 0.92

CE3AA 036 0.97 0.91 042 0.99 0.92

042 0.99 0.91 CK3BA 036 0.99 0.93

CK3BA 042 0.99 0.91 042 0.99 0.92 CK5A/CK5BA 042 0.99 0.91 CK5A/CK5BA 036 0.99 0.93 CK5A/CK5BT 042 0.99 0.91 042 0.99 0.92

CK5A/CK5BW 036 0.99 0.91 CK5A/CK5BE 042 0.99 0.92

CK5PA 042 0.99 0.91 CK5A/CK5BT 036 0.99 0.93 CK5PT 042 0.99 0.91 042 0.99 0.92

CK5PW 036 0.99 0.91 CK5A/CK5BW 036 0.99 0.92

COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 0.98 0.90 042 0.99 0.92

CC5A/CD5AW 036 0.98 0.90 CK5PE 042 0.99 0.92

042 0.98 0.90 CK5PT 036 0.99 0.93

CE3AA 036 0.97 0.91 042 0.99 0.92

042 0.99 0.90 CK5PW 036 0.99 0.92

CK3BA 042 0.99 0.90 CK5A/CK5BA 042 0.99 0.90 CC5A/CD5AA 036 0.98 0.94 CK5A/CK5BT 042 0.99 0.90 042 0.98 0.93

CK5A/CK5BW 036 0.99 0.90 CC5A/CD5AW 036 0.98 0.94

CK5PA 042 0.99 0.91 042 0.97 0.93 CK5PT 042 0.99 0.91 CE3AA 036 0.97 0.94

CK5PW 036 0.99 0.91 042 0.99 0.94

COILS + 355MAV042040 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 0.98 0.93 042 0.99 0.94

CC5A/CD5AW 036 0.98 0.93 CK5A/CK5BA 036 0.99 0.94

042 0.97 0.92 042 0.99 0.94

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 355MAV042060 VARIABLE SPEED FURNACE

CC5A/CD5AA 036 0.98 0.92

CK5PA 036 0.99 0.93

COILS + 355MAV042080 VARIABLE SPEED FURNACE

CK3BA 036 0.99 0.94

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—31—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A036-G Outdoor Section With CC5A/CD5AA042 Indoor Section continued

72 40.4 19.6 2.15 39.0 19.2 2.40 37.4 18.6 2.66 35.6 18.0 2.96 33.4 17.3 3.28 30.9 16.4 3.64 67 38.0 25.3 2.14 36.4 24.8 2.38 34.6 24.1 2.65 32.5 23.3 2.94 30.4 22.4 3.24 26.5 20.9 3.57

1050

72 41.0 20.3 2.20 39.7 19.9 2.45 38.1 19.4 2.72 36.2 18.9 3.02 33.9 18.1 3.34 31.4 17.3 3.70 67 38.5 26.5 2.19 37.0 26.1 2.43 35.0 25.3 2.69 33.1 24.7 2.99 30.9 23.9 3.30 26.9 22.4 3.62

1200

72 41.4 20.9 2.25 40.2 20.6 2.50 38.2 19.9 2.76 36.4 19.4 3.06 34.2 18.8 3.38 31.7 18.2 3.75 67 39.0 27.8 2.24 37.4 27.3 2.48 35.5 26.7 2.74 33.5 26.1 3.03 31.2 25.4 3.35 27.2 23.8 3.68

1350

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CK5A/CK5BE 042 0.99 0.93 CC5A/CD5AW 036 0.98 0.92 CK5A/CK5BT 036 0.99 0.94 042 0.97 0.91

042 0.99 0.94 CE3AA 036 0.97 0.92

CK5A/CK5BW 036 0.99 0.94 042 0.99 0.92

CK5PA 036 0.99 0.94 CK3BA 036 0.99 0.93

042 0.99 0.94 042 0.99 0.92 CK5PE 042 0.99 0.93 CK5A/CK5BA 036 0.99 0.93 CK5PT 036 0.99 0.94 042 0.99 0.92

042 0.99 0.94 CK5A/CK5BE 042 0.99 0.92

CK5PW 036 0.99 0.94 CK5A/CK5BT 036 0.99 0.93

COILS + 355MAV060080 VARIABLE SPEED FURNACE

CC5A/CD5AA 036 0.98 0.93 CK5A/CK5BW 036 0.99 0.92

042 0.98 0.92 CK5PA 036 0.99 0.93

CC5A/CD5AW 036 0.98 0.92 042 0.99 0.92

042 0.97 0.92 CK5PE 042 0.99 0.92 CE3AA 036 0.97 0.93 CK5PT 036 0.99 0.93

042 0.99 0.92 042 0.99 0.92 CK3BA 036 0.99 0.93 CK5PW 036 0.99 0.92

042 0.99 0.93

CK5A/CK5BA 036 0.99 0.93 CC5A/CD5AA 042 0.98 0.92

042 0.99 0.93 CC5A/CD5AW 036 0.98 0.92

CK5A/CK5BE 042 0.99 0.92 042 0.97 0.91 CK5A/CK5BT 036 0.99 0.93 CE3AA 036 0.97 0.92

042 0.99 0.93 042 0.99 0.92

CK5A/CK5BW 036 0.99 0.93 CK3BA 042 0.99 0.92

CK5PA 036 0.99 0.93 CK5A/CK5BA 042 0.99 0.92

042 0.99 0.93 CK5A/CK5BT 042 0.99 0.92 CK5PE 042 0.99 0.92 CK5A/CK5BW 036 0.99 0.92 CK5PT 036 0.99 0.93 CK5PA 042 0.99 0.92

042 0.99 0.93 CK5PT 042 0.99 0.92

CK5PW 036 0.99 0.93 CK5PW 036 0.99 0.92

COILS + 355MAV060100 VARIABLE SPEED FURNACE

CC5A/CD5AA 036 0.98 0.92

042 0.98 0.92

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

042 0.99 0.92

COILS + 355MAV060120 VARIABLE SPEED FURNACE

—— —

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—32—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A042-F Outdoor Section With CD5AA048 Indoor Section

72 46.7 22.7 2.49 45.2 22.3 2.77 43.3 21.6 3.09 41.2 20.9 3.44 38.8 20.1 3.83 36.0 19.2 4.26 67 44.0 29.5 2.47 42.3 28.9 2.75 39.8 27.8 3.05 37.7 27.1 3.40 35.4 26.3 3.79 31.4 24.7 4.18

1225

63†† 40.5 28.7 2.44 37.8 27.5 2.70 35.0 26.3 3.00 32.0 25.0 3.32 30.2 24.3 3.70 27.8 23.3 4.11 62 39.3 35.4 2.43 36.7 34.1 2.69 33.9 32.7 2.98 31.1 30.9 3.31 29.5 29.5 3.69 27.9 27.9 4.11 57 36.4 36.4 2.40 34.3 34.3 2.67 32.1 32.1 2.96 30.8 30.8 3.30 29.4 29.4 3.69 27.7 27.7 4.11

72 47.1 23.3 2.55 45.8 23.0 2.83 43.9 22.5 3.15 41.8 21.8 3.51 39.3 21.1 3.90 36.5 20.2 4.33 67 44.3 30.5 2.52 42.7 30.2 2.81 40.5 29.4 3.12 38.4 28.8 3.47 35.9 27.9 3.85 31.7 26.4 4.25

1400

63†† 42.1 30.7 2.51 39.3 29.5 2.78 36.4 28.3 3.07 33.6 27.1 3.40 31.8 26.3 3.79 27.9 24.7 4.18 62 40.5 37.9 2.50 37.8 36.5 2.76 35.0 34.8 3.06 32.7 32.7 3.39 31.2 31.2 3.78 29.5 29.5 4.21 57 38.1 38.1 2.48 36.2 36.2 2.74 35.0 35.0 3.05 33.6 33.6 3.40 32.2 32.2 3.79 29.3 29.3 4.20

72 47.5 23.9 2.61 46.2 23.7 2.90 44.4 23.2 3.22 41.8 22.4 3.56 39.5 21.8 3.95 36.8 21.1 4.40 67 44.9 31.9 2.58 43.0 31.5 2.86 41.1 31.1 3.18 38.8 30.3 3.53 36.3 29.6 3.92 32.0 28.0 4.32

1575

63†† 42.5 32.0 2.57 40.5 31.4 2.85 37.6 30.1 3.15 35.0 29.1 3.48 33.1 28.3 3.87 27.9 26.0 4.24 62 41.6 40.2 2.57 38.9 38.5 2.83 36.5 36.5 3.13 35.4 35.4 3.49 32.7 32.7 3.86 30.7 30.7 4.29 57 40.7 40.7 2.56 39.0 39.0 2.83 37.6 37.6 3.15 35.8 35.8 3.49 33.5 33.5 3.87 30.7 30.7 4.29

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 042 1.00 1.01 CD5AA 048 1.00 0.94 CC5A/CD5AC 048 0.99 1.01 CE3AA 042 1.00 0.95

CC5A/CD5AW 048 1.00 1.00 048 1.01 0.95

CD5AA 048 1.00 1.00 CK3BA 042 1.00 0.95 CE3AA 042 1.01 1.01 048 1.00 0.94

048 1.01 1.00 CK5A/CK5BA 042 0.99 0.93 CF5AA 048 1.00 1.00 048 1.00 0.94 CK3BA 042 1.00 1.00 CK5A/CK5BE 042 1.00 0.94

048 1.00 1.00 CK5A/CK5BT 042 1.00 0.95

CK5A/CK5BA 042 1.00 1.00 048 1.00 0.94

048 1.00 1.00 CK5PA 042 1.00 0.95

CK5A/CK5BE 042 0.98 0.97 048 1.00 0.94

CK5A/CK5BT 042 1.00 1.00 CK5PE 042 1.00 0.94

048 1.00 1.00 CK5PT 042 1.00 0.95

CK5A/CK5BW 048 1.00 1.00 048 1.00 0.94

CK5PA 042 1.00 1.00

048 1.00 1.00 CK5PE 042 0.98 0.97 CK5PT 042 1.00 1.00

048 1.00 1.00

CK5PW 048 1.00 1.00

F(A,B)4(A,B)N(F,B,C) 042 1.00 1.00

048 1.01 0.99

FE4ANB 006 1.02 0.89 FE4ANF 003 0.98 0.92

005 1.01 0.91

FG3AAA 048 0.99 0.99

FK4(C,D)NB 006 1.02 0.89

FK4(C,D)NF 003 0.98 0.91

005 1.01 0.91

FV4(A,B)NB 006 1.02 0.89 FV4(A,B)NF 003 0.98 0.92

005 1.01 0.91

FX4(A,B)NF 042 0.99 1.00

048 1.00 1.00

COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE 048 1.00 0.94

CC5A/CD5AA 042 0.99 0.94 CC5A/CD5AC 048 0.99 0.94

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 0.99 0.94 CC5A/CD5AC 048 0.99 0.94

CC5A/CD5AW 042 0.98 0.93

048 1.00 0.94 CD5AA 048 1.00 0.94 CE3AA 042 1.00 0.94

048 1.01 0.95 CK3BA 042 1.00 0.95

048 1.00 0.93

CK5A/CK5BA 042 1.00 0.95

048 1.00 0.94

CK5A/CK5BE 042 1.00 0.95

CK5A/CK5BT 042 1.00 0.95

048 1.00 0.94

CK5A/CK5BW 048 1.00 0.93

CK5PA 042 1.00 0.95

048 1.00 0.94 CK5PE 042 1.00 0.95 CK5PT 042 1.00 0.95

CK5PW 048 1.00 0.93

—— —

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—33—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A042-F Outdoor Section With CD5AA048 Indoor Section Continued

72 46.7 22.7 2.49 45.2 22.3 2.77 43.3 21.6 3.09 41.2 20.9 3.44 38.8 20.1 3.83 36.0 19.2 4.26 67 44.0 29.5 2.47 42.3 28.9 2.75 39.8 27.8 3.05 37.7 27.1 3.40 35.4 26.3 3.79 31.4 24.7 4.18

1225

72 47.1 23.3 2.55 45.8 23.0 2.83 43.9 22.5 3.15 41.8 21.8 3.51 39.3 21.1 3.90 36.5 20.2 4.33 67 44.3 30.5 2.52 42.7 30.2 2.81 40.5 29.4 3.12 38.4 28.8 3.47 35.9 27.9 3.85 31.7 26.4 4.25

1400

72 47.5 23.9 2.61 46.2 23.7 2.90 44.4 23.2 3.22 41.8 22.4 3.56 39.5 21.8 3.95 36.8 21.1 4.40 67 44.9 31.9 2.58 43.0 31.5 2.86 41.1 31.1 3.18 38.8 30.3 3.53 36.3 29.6 3.92 32.0 28.0 4.32

1575

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 1.00 0.94 048 1.00 0.92 CC5A/CD5AC 048 0.99 0.93 CK5PT 042 1.00 0.93

CC5A/CD5AW 042 0.99 0.94 048 1.00 0.92

048 1.00 0.93 CK5PW 048 1.00 0.92 CD5AA 048 1.00 0.93 CE3AA 042 1.00 0.93 CC5A/CD5AA 042 1.00 1.02

048 1.01 0.94 CC5A/CD5AW 048 1.00 1.00 CK3BA 042 1.00 0.94 CE3AA 042 0.99 1.00

048 1.00 0.93 048 0.99 0.99

CK5A/CK5BA 042 1.00 0.94

048 1.00 0.93 CC5A/CD5AC 048 0.99 1.00

CK5A/CK5BT 042 1.00 0.94 CD5AA 048 0.99 0.98

048 1.00 0.93 CE3AA 042 1.00 1.00

CK5A/CK5BW 048 1.00 0.93 048 1.00 1.00

CK5PA 042 1.00 0.94

048 1.00 0.93 CC5A/CD5AA 042 1.00 0.99 CK5PT 042 1.00 0.94 CC5A/CD5AC 048 0.99 0.97

048 1.00 0.93 CD5AA 048 1.00 0.97

CK5PW 048 1.00 0.93 CE3AA 042 1.01 0.99

COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 1.00 0.94 CK3BA 042 1.00 1.00 CC5A/CD5AC 048 0.99 0.92 048 1.00 0.97

CC5A/CD5AW 042 0.99 0.93 CK5A/CK5BA 042 1.00 1.00

048 1.00 0.92 048 1.00 0.97 CD5AA 048 1.00 0.92 CK5A/CK5BT 042 1.00 1.00 CE3AA 042 1.00 0.93 048 1.00 0.97

048 1.01 0.94 CK5PA 042 1.00 1.00 CK3BA 042 1.00 0.93 048 1.00 0.97

048 1.00 0.92 CK5PT 042 1.00 1.00

CK5A/CK5BA 042 1.00 0.93 048 1.00 0.97

048 1.00 0.92

CK5A/CK5BT 042 1.00 0.93 CC5A/CD5AA 042 1.00 0.98

048 1.00 0.92 CC5A/CD5AC 048 0.99 0.96

CK5A/CK5BW 048 1.00 0.92 CD5AA 048 1.00 0.96

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

CK5PA 042 1.00 0.93

COILS + 355MAV042040 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

048 1.01 0.99

COILS + 355MAV060080 VARIABLE SPEED FURNACE

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—34—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

550A042-F Outdoor Section With CD5AA048 Indoor Section Continued

72 46.7 22.7 2.49 45.2 22.3 2.77 43.3 21.6 3.09 41.2 20.9 3.44 38.8 20.1 3.83 36.0 19.2 4.26 67 44.0 29.5 2.47 42.3 28.9 2.75 39.8 27.8 3.05 37.7 27.1 3.40 35.4 26.3 3.79 31.4 24.7 4.18

1225

72 47.1 23.3 2.55 45.8 23.0 2.83 43.9 22.5 3.15 41.8 21.8 3.51 39.3 21.1 3.90 36.5 20.2 4.33 67 44.3 30.5 2.52 42.7 30.2 2.81 40.5 29.4 3.12 38.4 28.8 3.47 35.9 27.9 3.85 31.7 26.4 4.25

1400

72 47.5 23.9 2.61 46.2 23.7 2.90 44.4 23.2 3.22 41.8 22.4 3.56 39.5 21.8 3.95 36.8 21.1 4.40 67 44.9 31.9 2.58 43.0 31.5 2.86 41.1 31.1 3.18 38.8 30.3 3.53 36.3 29.6 3.92 32.0 28.0 4.32

1575

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CE3AA 042 1.01 0.98 CK5PT 042 1.00 0.97

048 1.01 0.98 048 1.00 0.95

COILS + 355MAV060100 VARIABLE SPEED FURNACE COILS + 355MAV060120 VARIABLE SPEED FURNACE

CC5A/CD5AA 042 1.00 0.98 CC5A/CD5AA 042 1.00 0.98 CC5A/CD5AC 048 0.99 0.96 CC5A/CD5AW 048 1.00 0.96

CD5AA 048 1.00 0.96 CE3AA 042 1.01 0.98 CE3AA 042 1.01 0.98 048 1.01 0.98

048 1.01 0.98 CK3BA 042 1.00 0.97

CK3BA 042 1.00 0.97 048 1.00 0.95

048 1.00 0.95 CK5A/CK5BA 042 1.00 0.97

CK5A/CK5BA 042 1.00 0.97 CK5A/CK5BT 042 1.00 0.97

048 1.00 0.95 CK5A/CK5BW 048 1.00 0.95

CK5A/CK5BT 042 1.00 0.97 CK5PA 042 1.00 0.97

048 1.00 0.95 CK5PT 042 1.00 0.97

CK5PA 042 1.00 0.97 CK5PW 048 1.00 0.95

048 1.00 0.95 — — —

See notes on page 38.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

Cooling

MBtuh†

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—35—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

550A048-F Outdoor Section With CC5A/CD5AA060 Indoor Section

72 53.0 25.6 2.87 51.3 25.0 3.18 49.4 24.3 3.53 47.2 23.6 3.93 44.8 22.8 4.36 42.1 21.9 4.83

1400

1600

1800

F(A,B)4(A,B)N(F,B,C) 048 0.99 0.99

See notes on page 38.

67 50.3 33.2 2.85 48.0 32.2 3.16 45.8 31.4 3.51 43.5 30.5 3.89 41.0 29.6 4.32 38.4 28.6 4.80 63†† 47.2 32.8 2.84 45.0 31.8 3.14 42.8 30.9 3.49 40.5 29.9 3.88 38.1 28.8 4.30 33.9 27.0 4.76 62 46.2 40.4 2.83 44.0 39.3 3.14 41.5 38.1 3.48 38.9 36.8 3.86 36.1 35.3 4.28 33.2 33.2 4.75 57 42.3 42.3 2.81 40.1 40.1 3.12 38.0 38.0 3.46 36.7 36.7 3.85 35.2 35.2 4.28 33.6 33.6 4.75

72 53.9 26.4 2.94 52.2 25.9 3.26 50.2 25.2 3.61 48.0 24.5 4.00 45.5 23.8 4.44 42.4 22.6 4.90 67 51.1 34.7 2.92 48.7 33.7 3.23 46.5 32.9 3.58 44.1 32.2 3.96 41.6 31.3 4.39 38.8 30.4 4.86 63†† 48.1 34.5 2.91 45.8 33.5 3.22 43.7 32.8 3.57 41.3 31.7 3.95 38.7 30.6 4.37 34.4 28.8 4.83 62 47.2 43.0 2.91 45.1 42.0 3.22 42.4 40.6 3.56 39.7 39.0 3.94 37.0 37.0 4.36 34.5 34.5 4.83 57 45.0 45.0 2.89 42.6 42.6 3.20 40.4 40.4 3.55 39.0 39.0 3.93 37.5 37.5 4.36 35.4 35.4 4.83

72 53.7 26.7 3.00 52.9 26.7 3.33 50.9 26.1 3.68 47.9 25.0 4.06 45.6 24.3 4.50 42.3 23.1 4.96 67 51.5 35.9 2.99 49.5 35.3 3.30 47.2 34.6 3.65 44.8 33.9 4.04 42.0 32.8 4.46 39.1 31.9 4.93 63†† 48.6 35.9 2.97 46.5 35.1 3.29 44.4 34.5 3.64 41.9 33.4 4.02 39.2 32.3 4.45 35.2 30.6 4.91 62 47.8 45.0 2.97 45.7 44.1 3.29 43.1 42.6 3.63 40.5 40.5 4.02 39.0 39.0 4.45 36.7 36.7 4.92 57 46.6 46.6 2.97 44.8 44.8 3.28 42.5 42.5 3.63 41.1 41.1 4.02 39.0 39.0 4.45 36.7 36.7 4.92

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 060 1.00 1.00 CK3BA 048 0.99 0.95 CC5A/CD5AC 048 0.97 0.98 CK5A/CK5BA 048 0.99 0.95 CC5A/CD5AW 048 0.99 0.99 CK5A/CK5BT 048 0.99 0.95

060 1.01 0.99 CK5PA 048 0.99 0.96 CD5AA 048 0.99 0.99 CK5PT 048 0.99 0.96 CD5PX 060 1.02 0.99

CE3AA 048 1.00 0.99

060 1.01 0.98

CF5AA 048 0.99 0.98 CK3BA 048 0.99 0.98

060 1.00 0.99

CK5A/CK5BA 048 0.99 0.98

060 1.00 0.99

CK5A/CK5BT 048 0.99 0.98

060 1.00 0.99

CK5A/CK5BW 048 0.99 0.98

CK5A/CK5BX 060 1.01 0.98

CK5PA 048 0.99 0.98

060 1.00 0.99

CK5PT 048 0.99 0.98

060 1.00 0.99

CK5PW 048 0.99 0.98

CK5PX 060 1.01 0.98

060 1.01 1.01

FB4(A,B)NB 070 1.02 0.98

FE4ANB 006 1.02 0.89

FE4ANF 005 1.01 0.94 CC5A/CD5AA 060 0.99 0.94

FG3AAA 048 0.99 0.99 CC5A/CD5AC 048 0.97 0.93

060 1.00 0.99 CC5A/CD5AW 048 0.99 0.94

FK4(C,D)NB 006 1.02 0.89 060 1.01 0.93 FK4(C,D)NF 005 1.01 0.94 CD5AA 048 0.99 0.94 FV4(A,B)NB 006 1.02 0.89 CD5PX 060 1.02 0.94

FV4(A,B)NF 005 1.01 0.94 CE3AA 048 1.00 0.95

FX4(A,B)NB 060 1.01 1.01 060 1.01 0.93

FX4(A,B)NF 048 0.99 0.99 CK3BA 048 0.99 0.94

COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE

CC5A/CD5AC 048 0.97 0.94 CK5A/CK5BA 048 0.99 0.94

CD5AA 048 0.99 0.95 060 1.00 0.92

CE3AA 048 1.00 0.96 — — —

060 1.01 0.95

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE

CC5A/CD5AA 060 0.99 0.95 CC5A/CD5AC 048 0.97 0.95 CC5A/CD5AW 048 0.98 0.94

CD5AA 048 0.98 0.94

CE3AA 048 0.99 0.95

060 1.01 0.94

CK3BA 048 0.99 0.95

060 1.00 0.93

CK5A/CK5BA 048 0.99 0.95

060 1.00 0.93

CK5A/CK5BT 048 0.99 0.95

060 1.00 0.93 CK5A/CK5BW 048 0.99 0.94 CK5A/CK5BX 060 1.02 0.94

CK5PA 048 0.99 0.96

060 1.00 0.93

CK5PT 048 0.99 0.96

060 1.00 0.93

CK5PW 048 0.99 0.95

CK5PX 060 1.02 0.94

COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE

060 1.00 0.92

Cooling

MBtuh†

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—36—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A048-F Outdoor Section With CC5A/CD5AA060 Indoor Section Continued

72 53.0 25.6 2.87 51.3 25.0 3.18 49.4 24.3 3.53 47.2 23.6 3.93 44.8 22.8 4.36 42.1 21.9 4.83

1400

1600

1800

See notes on page 38.

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CK5A/CK5BT 048 0.99 0.94 CC5A/CD5AC 048 0.97 0.99

060 1.00 0.92 CC5A/CD5AW 060 1.01 0.97

CK5A/CK5BW 048 0.99 0.94 CD5AA 048 0.99 0.99

CK5A/CK5BX 060 1.02 0.93 CE3AA 048 1.00 1.00

CK5PA 048 0.99 0.94 060 1.01 0.97

060 1.00 0.92

CK5PT 048 0.99 0.94 CC5A/CD5AA 060 1.00 1.00

060 1.00 0.92 CC5A/CD5AC 048 0.97 0.99

CK5PW 048 0.99 0.94 CC5A/CD5AW 060 1.01 0.97

CK5PX 060 1.02 0.92 CD5AA 048 0.99 0.99

COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE

CC5A/CD5AA 060 0.99 0.93 060 1.01 0.97 CC5A/CD5AC 048 0.97 0.92 CK3BA 060 1.00 0.98 CC5A/CD5AW 048 0.99 0.93 CK5A/CK5BA 060 1.00 0.98

060 1.01 0.93 CK5A/CK5BT 060 1.00 0.98 CD5AA 048 0.99 0.93 CK5A/CK5BX 060 1.02 0.97 CD5PX 060 1.02 0.93 CK5PA 060 1.00 0.98 CE3AA 048 1.00 0.94 CK5PT 060 1.00 0.98

060 1.01 0.93 CK5PX 060 1.02 0.97 CK3BA 048 0.99 0.93

060 1.00 0.92 CC5A/CD5AA 060 1.00 1.00

CK5A/CK5BA 048 0.99 0.93 CC5A/CD5AW 048 0.99 0.99

060 1.00 0.92 060 1.01 0.97

CK5A/CK5BT 048 0.99 0.93 CE3AA 048 1.00 1.00

060 1.00 0.92 060 1.01 0.97

CK5A/CK5BW 048 0.99 0.93 CK3BA 048 0.99 0.98

CK5A/CK5BX 060 1.02 0.92 060 1.00 0.97

CK5PA 048 0.99 0.94 CK5A/CK5BA 060 1.00 0.97

060 1.00 0.92 CK5A/CK5BT 060 1.00 0.97 CK5PT 048 0.99 0.94 CK5A/CK5BW 048 0.99 0.98

060 1.00 0.92 CK5A/CK5BX 060 1.02 0.97

CK5PW 048 0.99 0.94 CK5PA 060 1.00 0.97

CK5PX 060 1.02 0.92 CK5PT 060 1.00 0.97

COILS + 355MAV060080 VARIABLE SPEED FURNACE

CC5A/CD5AA 060 1.00 1.00 CK5PX 060 1.02 0.97

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 355MAV060100 VARIABLE SPEED FURNACE

CE3AA 048 1.00 1.00

COILS + 355MAV060120 VARIABLE SPEED FURNACE

CK5PW 048 0.99 0.98

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—37—

DETAILED COOLING CAPACITIES* Continued

EVAP

AIR

CFM EWB

75 85 95 105 115 125

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

CONDENSER ENTERING AIR TEMPERATURES °F

Total

Sys

kW**

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

kW**

Sys

Capacity

MBtuh†

Total

Sys

kW**

Capacity

MBtuh†

550A060-H Outdoor Section With CD5PX060 Indoor Section

57 57.89 57.89 4.31 55.67 55.67 4.76 53.35 53.35 5.27 50.80 50.80 5.83 47.87 47.87 6.43 44.52 44.52 7.08 62 59.84 53.84 4.33 57.09 52.53 4.78 54.23 51.17 5.28 51.12 49.67 5.84 47.85 47.85 6.43 44.51 44.51 7.08

1750

67 65.37 45.55 4.39 62.27 44.22 4.84 59.00 42.86 5.34 55.44 41.38 5.89 51.48 39.77 6.47 47.02 37.98 7.11 72 71.38 37.24 4.45 67.95 35.91 4.91 64.32 34.50 5.41 60.36 33.01 5.96 55.94 31.39 6.53 50.98 29.58 7.15

57 60.22 60.22 4.42 57.88 57.88 4.89 55.28 55.28 5.39 52.49 52.49 5.95 49.40 49.40 6.55 45.73 45.73 7.19 62 61.19 57.67 4.44 58.34 56.29 4.89 55.34 54.77 5.39 52.48 52.48 5.95 49.40 49.40 6.55 45.71 45.71 7.19

2000

67 66.60 48.31 4.49 63.37 46.97 4.96 59.86 45.53 5.45 56.10 44.02 5.99 52.03 42.39 6.58 47.43 40.59 7.21 72 72.67 38.92 4.56 69.11 37.58 5.02 65.22 36.14 5.52 61.05 34.63 6.06 56.50 32.98 6.63 51.36 31.14 7.25

57 62.16 62.16 4.54 59.57 59.57 5.00 56.86 56.86 5.50 53.93 53.93 6.06 50.56 50.56 6.65 46.69 46.69 7.29 62 62.34 61.20 4.54 59.51 59.51 5.00 56.85 56.85 5.50 53.92 53.92 6.06 50.55 50.55 6.65 46.69 46.69 7.29

2250

67 67.52 50.93 4.60 64.07 49.53 5.06 60.43 48.08 5.55 56.59 46.55 6.09 52.42 44.91 6.67 47.72 43.08 7.31 72 73.65 40.55 4.67 69.86 39.16 5.13 65.83 37.69 5.62 61.56 36.15 6.16 56.87 34.48 6.73 51.61 32.64 7.35

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 060 0.95 0.98 CK5A/CK5BT 060 0.97 0.96

CC5A/CD5AW 060 0.98 1.00 CK5A/CK5BX 060 0.99 0.96

CD5PX 060 1.00 1.00 CK5PA 060 0.97 0.96 CE3AA 060 0.98 0.99 CK5PT 060 0.97 0.96

CK3BA 060 0.98 0.99 CK5PX 060 0.99 0.96 CK5A/CK5BA 060 0.98 0.99 CK5A/CK5BT 060 0.98 0.99 CC5A/CD5AA 060 0.95 0.95 CK5A/CK5BX 060 1.00 0.99 CD5PX 060 0.98 0.95

CK5PA 060 0.98 0.99 CE3AA 060 0.98 0.95

CK5PT 060 0.98 0.99 CK3BA 060 0.97 0.95

CK5PX 060 1.00 0.99 CK5A/CK5BA 060 0.97 0.95

F(A,B)4BN(F,B,C) 060 0.98 1.01 CK5A/CK5BT 060 0.97 0.95

FB4BNB 070 1.00 1.00 CK5A/CK5BX 060 0.99 0.95

FC4CN(F,B) 060 0.98 1.01 CK5PA 060 0.97 0.95

FC4CNB 070 1.00 1.00 CK5PT 060 0.97 0.95

FE4ANB 006 1.00 0.94 CK5PX 060 0.99 0.95 FG3AAA 060 0.97 0.99 FK4DNB 006 1.00 0.94 CK3BA 060 0.97 1.01 FV4BNB 006 1.00 0.94 CK5A/CK5BA 060 0.97 1.01 FX4BNB 060 1.00 1.00 CK5A/CK5BT 060 0.97 1.01

COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE

CC5A/CD5AA 060 0.95 0.98 CK5PT 060 0.97 1.01

CD5PX 060 0.98 0.98

CE3AA 060 0.98 0.98 CK3BA 060 0.97 1.00

CK3BA 060 0.97 0.97 CK5A/CK5BA 060 0.97 0.99 CK5A/CK5BA 060 0.97 0.97 CK5A/CK5BT 060 0.97 0.99 CK5A/CK5BT 060 0.97 0.97 CK5PA 060 0.97 0.99 CK5A/CK5BX 060 0.99 0.97 CK5PT 060 0.97 0.99

CK5PA 060 0.97 0.97

CK5PT 060 0.97 0.97 CC5A/CD5AA 060 0.95 0.99

CK5PX 060 0.99 0.97 CK3BA 060 0.97 0.99

COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE

CC5A/CD5AA 060 0.95 0.96 CK5A/CK5BT 060 0.97 0.99

CD5PX 060 0.98 0.96 CK5A/CK5BX 060 0.99 0.99

CE3AA 060 0.98 0.96 CK5PA 060 0.97 0.99

CK3BA 060 0.97 0.96 CK5PT 060 0.97 0.99 CK5A/CK5BA 060 0.97 0.96 CK5PX 060 0.99 0.99

NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.

* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240-94. If additional tubing length and/or

indoor unit is located above outdoor unit, a slight variation in capacity may occur. †Total and sensible capacities are net capacities. Blower motor heat has been subtracted. ‡ Sensible capacities shown are based on 80°F (27°C) entering air at the indoor coil. For sensible capacities at other than 80°F (27°C), deduct 835 Btuh

(245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80°F (27°C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air

per degree above 80°F (27°C). When the required data falls between the published data, interpolation may be performed.

** Total system kW is total of indoor and outdoor unit kilowatts.

†† At TVA rating indoor condition (75°F edb/63°F ewb). All other indoor air temperatures are at 80°F edb.

Capacity Power Capacity Power

Cooling

Indoor

Section Size

COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE

COILS + 355MAV060080 VARIABLE SPEED FURNACE

CK5PA 060 0.97 1.01

COILS + 355MAV060100 VARIABLE SPEED FURNACE

COILS + 355MAV060120 VARIABLE SPEED FURNACE

CK5A/CK5BA 060 0.97 0.99

Cooling

Total

Sys

kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—38—

SST

°F

See notes on page 40.

CONDENSER ONLY RATINGS*

CONDENSER ENTERING AIR TEMPERATURES °F

55 65 75 85 95 105 115 125

550A024-G

TCG 20.9 19.4 17.9 16.2 14.4 12.4 10.2 7.8 SDT 69.8 79.1 88.3 97.6 106.7 115.7 124.7 133.6

KW 0.92 1.07 1.24 1.41 1.60 1.78 1.97 2.16

TCG 24.2 21.7 20.1 18.4 16.6 14.6 12.4 10.0 SDT 71.3 80.6 89.8 99.1 108.2 117.3 126.2 135.1

KW 0.93 1.10 1.26 1.45 1.64 1.84 2.04 2.25

TCG 28.7 25.0 22.5 20.8 19.0 16.9 14.7 12.3 SDT 72.6 82.0 91.4 100.6 109.8 118.9 127.9 136.7

KW 0.94 1.11 1.30 1.48 1.68 1.89 2.11 2.33

TCG 37.2 29.3 25.9 23.4 21.4 19.4 17.2 14.8 SDT 73.5 83.4 92.7 101.9 111.3 120.4 129.5 138.3

KW 0.94 1.12 1.31 1.52 1.73 1.95 2.18 2.41

TCG 44.0 35.9 30.2 27.0 24.3 22.1 19.9 17.5 SDT 74.4 84.6 94.0 103.2 112.4 121.6 130.6 139.5

KW 0.94 1.13 1.32 1.53 1.76 2.00 2.24 2.48

TCG 51.6 45.6 35.8 31.2 27.9 25.3 22.8 20.4 SDT 75.2 85.1 95.3 104.6 113.7 122.8 131.8 140.7

KW 0.90 1.12 1.33 1.55 1.78 2.03 2.30 2.58

550A030-F

TCG SDT

29.9

75.3

1.42

32.9

75.9

1.42

36.1

76.7

1.42

39.5

77.8

1.43

43.1

79.2

1.44

46.9

80.8

1.46

36.3

72.2

1.67

39.8

73.5

1.68

43.5

75.0

1.68

47.4

76.6

1.68

51.5

78.3

1.69

55.9

80.1

1.70

28.2

85.3

1.61

31.1

85.8

1.61

34.2

86.5

1.61

37.5

87.5

1.61

40.9

88.8

1.63

44.5

90.2

1.64

34.4

81.8

1.90

37.8

83.1

1.91

41.3

84.5

1.91

45.1

86.0

1.92

49.1

87.6

1.93

53.2

89.3

1.93

26.6

95.3

1.82

29.4

95.7

1.82

32.3

96.3

1.82

35.4

97.2

1.82

38.7

98.4

1.83

42.2

99.8

1.85

550A036-F, G

32.4

91.3

2.16

35.6

92.7

2.17

39.0

94.0

2.17

42.7

95.4

2.18

46.5

97.0

2.19

50.5

98.6

2.20

25.0

105.0

2.07

27.7

106.0

2.06

30.5

106.0

2.06

33.4

107.0

2.06

36.5

108.0

2.07

39.8

109.0

2.08

30.4

101.0

2.44

33.5

102.0

2.45

36.7

104.0

2.46

40.1

105.0

2.47

43.8

106.0

2.48

47.6

108.0

2.50

23.4

115.0

2.34

25.9

116.0

2.33

28.6

116.0

2.32

31.3

117.0

2.33

34.3

118.0

2.33

37.4

119.0

2.35

28.2

110.0

2.74

31.2

112.0

2.75

34.3

113.0

2.77

37.6

114.0

2.79

41.0

116.0

2.80

44.6

117.0

2.82

21.8

125.0

2.64

24.1

126.0

2.63

26.6

126.0

2.62

29.2

127.0

2.62

32.0

128.0

2.63

34.9

129.0

2.64

26.0

120.0

3.06

28.8

121.0

3.08

31.8

122.0

3.10

34.8

124.0

3.13

38.1

125.0

3.15

41.5

126.0

3.17

20.2

135.0

2.98

22.3

135.0

2.96

24.6

136.0

2.96

27.1

137.0

2.96

29.6

138.0

2.96

32.3

139.0

2.98

23.7

129.0

3.39

26.3

130.0

3.43

29.1

132.0

3.46

32.0

133.0

3.49

35.0

134.0

3.52

38.2

135.0

3.54

18.4

145.0

3.36

20.4

146.0

3.34

22.5

146.0

3.33

24.7

147.0

3.33

27.1

147.0

3.33

29.6

148.0

3.34

21.1

139.0

3.73

23.6

140.0

3.78

26.2

141.0

3.83

28.9

142.0

3.87

31.7

143.0

3.91

34.6

144.0

3.94

—39—

CONDENSER ONLY RATINGS* Continued

SST

°F

* ARI listing applies only to systems shown in Combination Ratings table.

KW — Outdoor Unit Kilowatts Only SDT — Saturated Temperature Leaving Compressor (°F) SST — Saturated Temperature Entering Compressor (°F) TCG — Gross Cooling Capacity (1000 Btuh).

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG

SDT

TCG 57.7 54.6 51.6 48.5 45.4 42.1 38.6 34.6

SDT 75.9 85.1 94.3 103.4 112.5 121.6 130.6 139.4

KW 8.82 9.97 11.22 12.59 14.12 15.83 17.63 19.46

TCG 63.5 60.1 56.8 53.3 49.9 46.3 42.4 38.1

SDT 77.7 86.8 95.9 104.9 114.0 122.9 131.8 140.5

KW 8.98 10.12 11.38 12.76 14.28 15.98 17.79 19.72

TCG 69.6 65.9 62.2 58.4 54.6 50.6 46.3 41.6

SDT 79.6 88.5 97.5 106.5 115.4 124.3 133.0 141.6

KW 9.16 10.29 11.56 12.94 14.44 16.15 17.95 19.9

TCG 76.1 72.0 67.9 63.8 59.5 55.0 50.3 45.10

SDT 81.6 90.5 99.4 108.2 117.0 125.7 134.3 142.7

KW 9.36 10.48 11.76 13.13 14.63 16.32 18.11 20.05

TCG 82.8 78.4 73.9 69.3 64.5 59.6 54.3 48.6

SDT 83.7 92.5 101.2 110.0 118.6 127.2 135.6 143.8

KW 9.57 10.68 11.97 13.36 14.84 16.5 18.28 20.19

TCG 89.8 85.0 80.0 75.0 69.7 64.3 58.5 52.3

SDT 85.9 94.5 103.2 111.8 120.3 128.7 136.9 144.9

KW 9.80 10.9 12.19 13.58 15.07 16.71 18.45 20.34

55 65 75 85 95 105 115 125

41.4

72.3

1.85

45.4

73.7

1.86

49.6

75.2

1.88

54.0

76.7

1.89

58.8

78.4

1.92

63.8

80.2

1.94

45.8

72.0

2.11

50.6

72.0

2.10

55.7

72.3

2.10

60.9

73.6

2.13

66.3

75.1

2.17

72.1

76.7

2.21

39.2

82.0

2.10

43.0

83.4

2.12

47.0

84.8

2.14

51.3

86.3

2.16

55.8

87.9

2.18

60.6

89.6

2.20

43.3

82.0

2.40

47.9

82.0

2.39

52.8

82.1

2.38

57.8

83.2

2.40

63.0

84.6

2.44

68.5

86.1

2.48

CONDENSER ENTERING AIR TEMPERATURES °F

550A042-F

37.0

91.8

2.39

40.6

93.1

2.41

44.5

94.4

2.43

48.5

95.9

2.45

52.8

97.4

2.47

57.4

99.1

2.50

34.8

102.0

2.72

38.2

103.0

2.74

41.8

104.0

2.76

45.7

106.0

2.78

49.7

107.0

2.80

54.0

109.0

2.83

32.5

111.0

3.07

35.7

112.0

3.09

39.1

114.0

3.12

42.7

115.0

3.14

46.6

117.0

3.17

50.6

118.0

3.20

30.2

121.0

3.46

33.2

122.0

3.49

36.4

123.0

3.51

39.8

125.0

3.54

43.3

126.0

3.57

47.1

127.0

3.60

550A048-F

40.9

92.0

2.73

45.2

92.0

2.71

49.9

92.0

2.70

54.7

92.7

2.71

59.7

94.1

2.75

65.0

95.6

2.79

38.5

102.0

3.09

42.6

102.0

3.08

47.0

102.0

3.06

51.7

102.0

3.06

56.4

104.0

3.09

61.4

105.0

3.14

36.0

112.0

3.52

39.9

112.0

3.49

44.1

112.0

3.47

48.6

112.0

3.46

53.1

113.0

3.48

57.8

114.0

3.52

33.6

122.0

3.98

37.2

122.0

3.96

41.1

122.0

3.93

45.4

122.0

3.91

49.8

123.0

3.92

54.2

124.0

3.95

550A060-H

27.8

130.0

3.89

30.6

131.0

3.92

33.5

133.0

3.94

36.7

134.0

3.97

39.9

135.0

4.00

43.4

137.0

4.03

31.0

132.0

4.51

34.4

132.0

4.48

38.1

132.0

4.45

42.1

132.0

4.42

46.2

132.0

4.41

50.5

133.0

4.43

25.3

140.0

4.36

27.8

141.0

4.39

30.5

142.0

4.41

33.3

143.0

4.44

36.3

144.0

4.47

39.5

145.0

4.50

28.4

142.0

5.09

31.5

142.0

5.06

34.9

142.0

5.02

38.5

142.0

4.99

42.5

142.0

4.96

46.5

143.0

4.96

—40—

SYSTEM DESIGN SUMMARY

1. Intended for outdoor installation with free air inlet and outlet. Outdoor fan external static pressure available is less than 0.01-in. wc.

2. Minimum outdoor operating air temperature without low-ambient operation accessory is 55°F (12.8°C).

3. Maximum outdoor operating air temperature is 125°F (51.7°C).

4. For reliable operation, unit should be level in all horizontal planes.

5. Maximum elevation of indoor coil above or below base of outdoor unit is: Indoor coil above = 50 ft, indoor coil below = 150 ft.

6. For interconnecting refrigerant tube lengths greater than 50 ft and/or 20 ft vertical differential, consult the Residential Split-System Application Guideline and Service Manual for Air Conditioners and Heat Pumps using Puron® (R-410A) Refrigerant available from equipment distributor.

7. If any refrigerant tubing is buried, provide a 6 in. vertical rise to the valve connections at the unit. Refrigerant tubing lengths up to 36 in. may be buried without further consideration. Do not bury refrigerant lines longer than 3 ft.

8. Use only copper wire for electric connection at unit. Aluminum and clad aluminum are not acceptable for the type of connector provided.

9. Mismatches of indoor coil capacity more than one size larger than outdoor unit capacity may result in inadequate indoor comfort.

10. Do not apply capillary tube indoor coils to these units.

11. Factory-supplied ﬁlter drier must be installed.

—41—

—42—

—43—

GUIDE SPECIFICATIONS

Air-Cooled, Split-System

Air Conditioner

550A

2 to 5 Tons Nominal

GENERAL

System Description

Outdoor-mounted, air-cooled, split-system air conditioner unit suitable for ground or rooftop installation. Unit consists of a hermetic compressor, an air-cooled coil, propeller-type condenser fan, and a control box. Unit will discharge supply air upward as shown on contract drawings. Unit will be used in a refrigeration circuit to match up to a packaged fan coil or coil unit.

Quality Assurance

Unit will be rated in accordance with the latest standard of ARI Standard 210.

Unit will be certiﬁed for capacity and efﬁciency, and listed in the lastest ARI directory.

Unit construction will comply with latest edition of ANSI/ ASHRAE and with NEC.

Unit will be constructed in accordance with UL standards and will carry the UL label of approval. Unit will have c-UL approval.

Unit cabinet will be capable of withstanding Federal Test Method Standard No. 141 (Method 6061) 500-hr salt spray test.

Air-cooled condenser coils will be leak tested at 250 psig and pressure tested at 450 psig.

Unit constructed in ISO9001 approved facility.

Delivery, Storage, and Handling

Unit will be shipped as single package only and is stored and handled per unit manufacturer’s recommendations.

Warranty (for inclusion by specifying engineer)

U.S. and Canada only.

PRODUCTS

Equipment

Factory assembled, single piece, air-cooled air conditioner unit. Contained within the unit enclosure is all factory wiring, piping, controls, compressor, refrigerant charge Puron® (R-410A), and special features required prior to ﬁeld start-up.

Unit Cabinet Unit cabinet will be constructed of galvanized steel, bonderized,

and coated with a powder coat paint. F

ans

Condenser fan will be direct-drive propeller type, discharging air upward.

Condenser fan motors will be totally enclosed, 1-phase type with class B insulation and permanently lubricated bearings.

Shafts will be corrosion resistant.

Fan blades will be statically and dynamically balanced. Condenser fan openings will be equipped with PVC-coated

steel wire safety guards. Compressor

Compressor will be hermetically sealed. Compressor will be mounted on rubber vibration isolators. Condenser Coil Condenser coil will be air cooled. Coil will be constructed of aluminum ﬁns mechanically bonded

to copper tubes which are then cleaned, dehydrated, and sealed.

Refr

igeration Components

Refrigeration circuit components will include liquid-line shutoff valve with sweat connections, vapor-line shutoff valve with sweat connections, system charge of refrigerant Puron® (R410A), and compressor oil.

Unit will be equipped with a high-pressure switch, low-pressure switch and ﬁlter drier for Puron refrigerant.

Operating Characteristics

The capacity of the unit will meet or exceed _____ Btuh at a suction temperature of _____ °F. The power consumption at full load will not exceed _____ kW.

Combination of the unit and the evaporator or fan coil unit will have a total net cooling capacity of _____ Btuh or greater at conditions of _____ CFM entering air temperature at the evapo-rator at _____ °F wet bulb and _____ °F dry bulb, and air enter-ing the unit at _____ °F.

The system will have a SEER of _____ Btuh/watt or greater at DOE conditions.

Electrical Requirements

Nominal unit electrical characteristics will be _____ v, single phase, 60 hz. The unit will be capable of satisfactory opera-tion within voltage limits of _____ v to _____ v.

Unit electrical power will be single point connection. Control circuit will be 24v.

Special Features

Refer to section of this literature identifying accessories and descriptions for speciﬁc features and available enhancements.

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

UNIT MUST BE INSTALLED IN ACCORDANCE

WITH INSTALLATION INSTRUCTIONS

Cancels: PDS 550A.24.9

—44— PRINTED IN U.S.A. Catalog No. 5255-007 12-04

Bryant 550A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
