Page 1
GLASS
JOB NAME
CONTACT
ORDERING CODE
CANTARA
Canopy, Track
SW
Bruck By Ledra Brands Inc.
ORDERING CODE
LIGHT SOURCE
SHADE COLOR
FINISH
MOUNTING
OPTIONS
ORDERING CODE
88 Maxwell
Irvine, CA 92618
1
MLED
30K 3000K
CCT
35K 3500K
CRI 90 90 CRI
501 black outer / gold inner
502 black outer / silver inner
503 white outer / gold inner
504 white outer / silver inner
505 white outer / white inner
507 bronze outer / white inner
MC
CH
3
BZ
2
P
ECOBK ECO/HALO black
ECOWH ECO/HALO white
ECOMC ECO/HALO matte chrome
GEOBK GEO black
GEOWH GEO white
GEOMC GEO matte chrome
ZONMC zonyx matte chrome
Static White LED, 450lm
3
matte chrome with clear braided cable
3
chrome with clear braided cable
bronze with brown braided cable
canopy pendant
PH: 714.259.9959
FAX: 714.259.9969
www.brucklighting.com
ARTISAN
501 black outer/gold inner 502 black outer/silver inner 503 white outer/gold inner
504 white outer/silver inner
505 white outer/white inner 507 bronze outer/white inner
DESCRIPTION
Bruck has created a pendant lamp which masterfully sets the scene for a modern design with
its clear simple cylindrical form and supreme German craftsmanship. The minimalist design
of Cantara Glass is focused on the essentials: light that bathes the room with a warm glow of
gold or brilliance of silver. The inside is hand-coated with composition gold or silver. The nely
textured metallic interior gives it an elegant charm. The light character of the golden version is
comfortably warm, and thus provides a very cozy appeal. A translucent version without inner
metallic coating is also offered in white. The lamp of the Cantara Glass is encased in a reector
made of hand-blown opal crystal glass. This distributes the light evenly and softly on the
surface below.
HOUSING
The hardware is offered in matte chrome, bronze or chrome nish and seconds as the pendant
thermal heatsink.
MOUNTING
- The pendant can be mounted from Bruck’s eld adjustable canopy. The standard overall cable
length of 59" can be eld-cut or specied when ordering. Overall cable length is measured and
begins from top of canopy. See the decorative Junction Box Cover for open ceiling applications.
- Optional track mounting: Global Trac Systems, GEO track, ECO track / Halo
®
Power track,
and Zonyx track. Overall cable length begins at the shoulder of the ECO/GEO adapter and the
track center of the Zonyx adapter. Cable length measurement ends at the top of glass or to the
mounting arms.
- Kevlar coated cable for easy cleaning, short circuit protection, no discoloration and fraying over
time.
LISTINGS
- Listed to UL1598 and UL1574 (Suitable for dry locations only)
- Listed to CSA C22.2 #250.0 and #9.0
Follow the steps to specify your xture, example:
MLED - 30K - 90 - 504 - MC - P
NOTES
1. For LED info see page 2.
2. Canopy matches the nish chosen.
3. Cable info: 22ga Type SVT Cable. 0.120" outer diameter. Rated to 300V & 105°C.
In a continuing eort to oer the best product possible we reserve the right to change, without notice, specications or materials that in our opinion will not alter the function of the product.
v.11.23.20 Page 1 of 2
CANTARA
Page 2
MOUNTING OPTIONS
7-1/2"
3-3/8"
MLED
1/2"
1-1/4"
Bruck By Ledra Brands Inc.
4-1/2"
2-1/8"
P
1-3/4"
ECO
88 Maxwell
Irvine, CA 92618
PH: 714.259.9959
FAX: 714.259.9969
2-5/8"
GEO
www.brucklighting.com
3-1/4"
ZONMC
LIGHT SOURCE
Light Source MLED - Static White LED
Performance
Cree XHP50
LED
Lumens 450lm
CCT 3000K or 3500K
SDCM 2-Step MacAdam Ellipse
CRI >90
Lumen Maintenance L
Technical Specs
Socket Listing
Mounting
Canopy
Line Voltage Track • 120Vac, 50/60Hz input
> 145,000 hours
70
• Integrated LED module
• ETLus Listed to UL1598, and UL1574 (Suitable for dry locations only)
• cETL Listed to CSA C22.2 #250.0 and #9.0
• 120-277Vac, 50/60Hz input
• 7.0W, 7.5VA
• Tri-mode dimming (Triac, ELV and 0-10V)
• Mount to 3-1/2" to 4" round J-Box
• Short circuit protection
• Thermal protection
• 7.0W, 7.5VA
• Triac and ELV phase dimming
• Connects to line voltage adapter (ECO, GEO, Zonyx)
Warranty
• 5 year limited xture warranty
In a continuing eort to oer the best product possible we reserve the right to change, without notice, specications or materials that in our opinion will not alter the function of the product.
v.11.23.20 Page 2 of 2
