Bruckhoff la belle, junior, headset Operating Manual

B17034 - 8/17

Händlerstempel

Your hearing aid does not restore
normal hearing, nor does it prevent
or improve an organically induced hea­ring loss.

Safety and Warnings

• Your hearing aid must not be worn by
other persons. A risk of hearing dama­ge will ensue.

• Unauthorized modifications to the
hearing aid may damage your hearing.

• Never wear your hearing aid in are­as where there is a risk of explosion.

• Keep the hearing aid out of the reach
of small children, people with cognitive
impairment and pets. The ingestion of
hearing aid parts, in particular of batte­ries, is hazardous to life. There is a dan­ger of suffocation. In case of emergency
call a doctor or a hospital immediately.

• If you are experiencing pain in or be­hind the ear, or if you develop increased
earwax, contact your hearing healthcare
professional or doctor.

• Hearing aids should not be fitted with
a dome or cerumen (earwax) protection
system for customers with perforated
eardrums, inflamed ear canals or other­wise exposed mid-ear cavities. In the­se cases, we recommend the use of a
custom ear mould. In the rather unlikely
event that the dome remains in the au-

ditory canal, we recommend a visit to a
specialist medical practitioner.

• Listening programs in the directional
microphone mode reduce background
noises. Warning signals or noises co­ming from behind are not perceived or
only weakly perceived.

• Never connect your hearing aid to an
external audio device such as a radio,
etc., as this may result in physical injury
(electric shock).

• The use of a hearing aid by persons
with an actively implanted medical de­vice (for example heart pacemaker, defi­brillator, etc.) requires prior consultation
and clarification with a specialist phy­sician. (For further information please
refer to our website at www.bruckhoff.
com/Sicherheitshinweise)

Information on product safety, use
and maintenance

Your hearing aid is very robust and can
be worn during all normal everyday ac­tivities, even under extreme conditions
for short periods.

• Never immerse it in/under water
or use it while showering, bathing or
swimming. The hearing aid electronics
will become damaged.

• Never clean the microphone openings

with moist agents. They will lose their
special acoustic properties.

• Protect your hearing aid from heat.

• Never use a microwave or other hea­ting appliances to dry it.

• The dome must be replaced every
three months, or as soon as it becomes
hard or brittle. This prevents uninten­tional detachment of the dome during
insertion and removal from the ear.

• As far as possible, leave unused hea­ring aids with an open battery com­partment so that moisture can escape.

• For long-term non-use, remove the
battery.

• Always store the hearing aid in a safe,
dry, and clean place

• Do not drop it!

• Always replace weak or defective bat­teries (e.g. liquid loss) immediately. Al­ways use new batteries

• Do not dispose of old batteries in do­mestic waste. Your hearing care pro­fessional will dispose of these for you.

• Use only batteries with max.1.5 Volt.

• Never use silver-zinc or lithium-ion
batteries.

• Some (dental) medical examinations
with x-rays, e.g. CT examination, MRT/
NMRT, can impair the functioning of
your hearing aid. Remove your hearing
aid beforehand.

• Hearing aids do not have to be remo­ved before passing through a security
sluice (e.g. at the airport). The low X-ray
radiation emitted there does not affect
your hearing aid.

• Do not use your hearing aid in lo­cations where electronic devices are
prohibited.

Detailed information can be found on
the internet at www.bruckhoff.com/
Sicherheitshinweise In case of doubt,
please contact your hearing healthcare
professional or a specialist physician.

Magnetic pen

switched on

Battery cover closed

switched off

Battery cover open

Identical for all control units:

When the battery cover is closed, your
hearing aid is always switched on
automatically.

The hearing aid is turned off by simply
opening the battery cover.

Identical for all control units:

Open the battery cover. Remove the
battery with the supplied magnetic
pen.

Insertion is in reverse order:
Insert the new type 312 battery
with the „+“ sign facing up. Close the
cover. The hearing aid is automatically
switched on again!

Battery

Type 312 standard*

* Optional:
Battery
Type 13

Safety, care and use information. Please read before use!

AUDIA AKUSTIK GMBH

Herrenstraße 6

30159 Hannover

Germany

Tel: [phone]

E-Mail: [e-mail]

www.bruckhoff.com

air conduction

bone conduction

Operating manual

- EN -

We understand hearing.

bone conduction

Turning the unit on/off

Changing the battery

bone conduction

headset

i

la bellela belle junior headset

la bellela belle junior headset

Dealer‘s stamp

Air conduction

• la belle (with/without external

microphone)

You can set the following functions
yourself:

• Adjust the volume

• Select the listening programs

• Switch the unit on/off: see the
instructions on the other side

Air conduction

• la belle (with/without external micro­phone)

You can set the following functions
yourself:

• Select the listening programs

• Optional: volume control with remote
control

• Switch the unit on/off: see the
instructions on the other side

Bone conduction

• la belle (control unit above/below)

You can set the following functions
yourself:

• Adjust the volume

• Switch the unit on/off: see the
instructions on the other side

Bone conduction

• la belle (control unit above/below)

• junior

• headset

You can set the following functions
yourself:

• Adjust the volume

• Select the listening programs

• Switch the unit on/off: see the
instructions on the other side

Bone conduction

• junior

You can set the following func­tions yourself:

• Select the listening programs

• Adjust the volume

• Switch the unit on/off: see the
instructions on the other side

Fitting and wearing instructions

Insert the la belle listening module
(1) on your spectacle arm. Use your
glasses without hearing aid - using
the push-on spectacle end piece (2).
The children‘s junior hearing system
(3) is connected to the headband
using two snaps (4).
(5) The headset hearing system can be
easily adjusted to your head shape via
the pull-out adjustment (6).

Setting options on the control unit 1

Setting options on the control unit 2

Setting options on the control unit 3

Setting options on the control unit 4

Setting options on the control unit 5

Function buttons:

1 x short forward:

one step louder

1 x short back:

one step quieter

1 x long forward:

one program further

1 x long back:

one program back

No manual adjust­ment of the hearing
programs necessary

The device is already
pre-programmed
and automatically
adapts to the
external conditions.

The program button
is located on the pro­gramming chamber
and not on the control
unit.

Volume adjustment
is automatic. Manual
adjustment possible
with optional remote
control.

There are 5 control unit versions, each of which differs slightly in its operability.

With external
speaker on
the left

Without

external speaker

With

external speaker

Without

external speaker

With external

speaker on

the right

(1)

(2)

(1) (3) (5)

(6)

(4)

Program button

Program button

Program button

left

left

left

left

left

right

right

right

rechts

right

Volume control

Childlock

Volume control

Button for volume

and

program selection

Volume control

Fitting and wearing instructions

la bellela belle junior headset
