Browning T-Bolt Owner's Manual
™
t-Bolt
Bolt-action rimfire rifle
owner’s manual
Important operating instructions for:
BROWNING T-BOLT™
RIMFIRE RIFLES
If you have any questions about your new firearm, this
owner’s manual or other Browning products, contact:
Browning Consumer Information
One Browning Place
Morgan, UT 84050-9326
Phone: (801) 876-2711
www.browning.com
Please use the space below to record information about
your new firearm.
Model __________________________________________________
Serial Number ____________________________________________
Purchased From __________________________________________
Date of Purchase __________________________________________
THANK YOU FOR CHOOSING
A BROWNING T-BOLT RIFLE.
This next generation T-Bolt is the latest in a revered line of dependable,
accurate Browning rimfire rifles. The T-Bolt rifle incorporates the best
of traditional Browning craftsmanship and advanced technology. The
straight-pull bolt-action design allows fast cycling and eliminates
wasted energy, while being exceptionally accurate.
With a reasonable amount of care, your T-Bolt rifle is designed
to give you many years of dependable, enjoyable service.
CONTENTS PAGE
You are Responsible for Firearms Safety ................................................2
General Description and Operation .......................................................9
Nomenclature ...........................................................................................9
Serial Number ..........................................................................................9
Initial Cleaning .......................................................................................10
Operation of the “Safety” ......................................................................11
Cocking Indicator ..................................................................................12
Inserting and Removing the Bolt ..........................................................12
Ammunition ...........................................................................................14
Magazine Capacity .................................................................................14
Loading ...................................................................................................15
Firing ......................................................................................................18
Unloading ...............................................................................................19
Mounting a Scope ..................................................................................20
Trigger Adjustment ................................................................................21
Magazine Storage (Composite Stock Models) .....................................22
Cleaning and Maintenance Suggestions ...............................................23
Maintenance of Oil Finish Stocks .........................................................26
Models with Special Finishes ................................................................27
Service or Repair ....................................................................................28
1
YOU ARE RESPO N SI BL E FO R F IR EA R MS SA F ET Y
failure to follow any of the following warnings could result
in serious injury or death.
As a gun owner, you accept a set of demanding responsibilities. How
seriously you take these responsibilities can be the difference between
life and death.
There is no excuse for careless or abusive handling of any firearm.
At all times handle this firearm and all other firearms with intense
respect for their power and potential danger.
Please read and understand all of the cautions, warnings, notices,
proper handling procedures and instructions outlined in this owner’s
manual before using your new firearm.
1 always KeeP the muZZle of your firearm Pointed in a safe
direction even though you are certain it is unloaded.
Never point any firearm at anything you do not intend to shoot.
Be extremely alert and aware of all persons and property within
the range of your ammunition.
2 never rely totally on your firearm’s mechanical “safety”
device. liKe any mechanical device, a “safety” can sometimes
fail; it can Be jarred or inadvertently maniPulated into an
unsafe condition.
The word “safety” describes a firearm’s trigger block mechanism,
sear block mechanism, hammer block mechanism or firing pin
block mechanism. Mechanical “safeties” are designed to place your
firearm in a safer status, and no guarantee can be made that the
firearm will not fire even if the “safety” is in the on safe position.
Mechanical “safeties” merely aid safe gun handling and are no
excuse for pointing your firearm’s muzzle in an unsafe direction.
See “Operation of the Safety” on page 11 for instructions on the
operation of this firearm’s “safety.”
2
Remember, safe gun handling does not stop with your firearm’s
mechanical “safety” devices, it starts there. Always treat this firearm
with the respect due a loaded, ready-to-fire firearm.
Some firearms do not have a mechanical “safety.” Many target
firearms, lever-action firearms and pistols do not have manual
“safety” mechanisms. Therefore it is critical to read and
understand the owner’s manual for every firearm which explains
the safe operation of the firearm.
While it is a good idea to “test” your firearm’s mechanical “safety”
periodically for proper function, never test the “safety” while your
firearm is loaded or pointed in an unsafe direction.
3 whenever you handle any firearm, or hand it to someone,
always oPen the action immediately and visually checK the
firearm’s chamBer to maKe certain that the firearm is
comPletely unloaded.
Make certain the firearm does not inadvertently contain any
ammunition. Always keep the chamber empty and the “safety”
in the on safe position unless shooting is imminent.
4 always wear ear and eye Protection when shooting.
Unprotected, repeated exposure to gunfire can cause hearing
damage. Wear hearing protection (shooting ear plugs or muffs)
to guard against such damage.
Wear shooting glasses to protect your eyes from flying particles.
Allow proper distance (eye relief) between a scope and your
eye when firing a scoped rifle, shotgun or pistol. Do not use
unorthodox shooting methods that could cause the rearward
travel of the slide or bolt of a firearm to contact your eyes, face
or hands. Always keep a safe distance between the muzzle of
your firearm and any persons nearby, as muzzle blast, debris
and ejecting cartridges could inflict serious injury.
Always wear eye protection when disassembling and cleaning any
firearm to prevent the possibility of springs, spring-tensioned
parts, solvents or other agents from contacting your eyes.
3
5 KeeP all firearms unloaded during transPort, even
when stored in a holster, gun case, scaBBard or
other container.
6 droPPing or jarring a loaded firearm can cause
accidental discharge.
This can occur even with the “safety” in the on safe position. Be
extremely careful while hunting or during any shooting activity
to avoid dropping any firearm.
7 hunting from elevated surfaces such as treestands
is dangerous.
Doing so may increase the risk of mishandling a firearm. The
following rules should always be observed by you and those you
hunt with. Always make certain that the stand being used is safe
and stable. Always make certain that your firearm is unloaded
when it is being taken up and down from the stand. Always make
certain that your firearm is not dropped from the stand, or
dropped while it is being taken up or down from the stand.
Remember, a loaded firearm may discharge when dropped, even
with the “safety” in the on safe position.
8 store your firearm and ammunition seParately, well Beyond
the reach of children.
Take prudent safeguards to ensure your firearm does not become
available to untrained, inexperienced or unwelcome hands. Store
all firearms in secure, locked cases or a gun safe. Keep your firearm
unloaded when not in use.
9 Beware of Barrel oBstructions.
Mud, snow and an infinite variety of other objects may
inadvertently lodge in a barrel bore. It only takes a small
obstruction to cause dangerously increased pressures that
can damage your firearm and cause serious injury to yourself
and others.
4
Before checKing for a Barrel oBstruction, Be certain
your firearm is comPletely unloaded, there is not a
live cartridge in the chamBer and the “safety” is in the
on safe Position.
After assuring yourself that the firearm is completely unloaded,
open the breech or action and look through the barrel to be sure it
is clear of obstructions. If an obstruction is seen, no matter how
small it may be, clean the bore with a cleaning rod and patch as
described on page 24 of this owner’s manual.
10 Be alert to the signs of ammunition malfunction. if you
detect an off sound or light recoil when a cartridge is
fired, do not load another cartridge into the chamBer.
If your firearm fails to fire, keep the muzzle pointed in a safe
direction for a minimum of 30 seconds. Carefully open the action
and remove the cartridge from the chamber. If the primer is
indented, the defective shell should be disposed of in a way that
cannot cause harm. If the primer is not indented, your firearm
should be examined by a qualified gunsmith and the cause of the
malfunction corrected before further use. Glance down the barrel
to make sure that no obstructions remain in the barrel. Completely
clear the barrel before loading and firing again. Failure to follow
these instructions can cause extensive damage to your firearm and
possible serious injury to yourself and others.
11 never insert a cartridge of the incorrect caliBer into
any firearm.
The caliber of your firearm is marked on the barrel. Store all
cartridges of different calibers in completely separate and
well-marked containers. Never store cartridges of mixed calibers
in a common container or in your pockets. See page 14 for more
information on the correct ammunition for your firearm.
5
12 examine every cartridge you Put in your firearm.
We assume no responsibility for the use of unsafe or improper
firearm and ammunition combinations or damage or injury
caused by damaged ammunition. It is your responsibility
to read and heed all warnings in this owner’s manual and on
ammunition boxes. See page 14 for more information on the
correct ammunition for your firearm.
13 use only saami aPProved ammunition.
The barrel and action of this firearm have been made with
substantial safety margins beyond the pressures developed by
established American commercial loads. Nevertheless, we can
assume no liability for incidents which occur through the use of
cartridges of nonstandard dimensions or which develop pressures
in excess of commercially available ammunition which has been
loaded in accordance with standards established by the Sporting
Arms and Ammunition Manufacturer’s Institute (SAAMI).
14 maKe sure of adequate ventilation in the area that you
discharge a firearm. lead exPosure can occur from
discharging firearms in Poorly ventilated areas, cleaning
firearms or handling ammunition.
Lead is a substance that has been known to cause birth defects,
reproductive harm and other serious injury. Wash hands
thoroughly after exposure to ammunition or after cleaning
a firearm.
15 do not snaP the firing Pin on an emPty chamBer; the
chamBer may not Be emPty!
Treat every firearm with the respect due a loaded firearm, even
though you are certain the firearm is unloaded.
16 KeeP your fingers away from the trigger while loading
and unloading until shooting is imminent.
6
17 Be sure of your target and BacKstoP, Particularly
during low light Periods.
Know the range of your ammunition. Never shoot at water or
hard objects.
18 always unload your firearm’s chamBer Before crossing
a fence, climBing a tree, jumPing a ditch or negotiating
other oBstacles.
Never place your firearm on or against a fence, tree, car or other
similar object.
19 Be defensive and on guard against unsafe gun
handling around you and others.
Don’t be timid when it comes to firearm safety. If you observe
other shooters violating any of these safety precautions, politely
suggest safer handling practices.
20 Be certain your firearm is unloaded Before cleaning.
Because so many firearm accidents occur when a firearm is being
cleaned, special and extreme care should be taken to be sure your
firearm is unloaded before disassembly, cleaning and reassembly.
Keep ammunition away from the cleaning location. Never test the
mechanical function of any firearm with live ammunition.
21 teach and suPervise firearms safety to all memBers of
your family, esPecially to children and non-shooters.
Closely supervise newcomers to the shooting sports. Encourage
enrollment in hunting and shooting safety courses.
22 never drinK alcoholic Beverages or taKe any tyPe
of drugs Before or during shooting.
Your vision, motor skills and judgment could be dangerously
impaired, making your gun handling unsafe to you and to others.
7
23 read and heed all warnings in this owner’s manual, on
ammunition Boxes and with all accessories that you install
on your firearm.
It is your responsibility to secure the most up-to-date information
on the safe handling procedures of your Browning firearm. We
assume no liability for incidents which occur when unsafe or
improper firearm accessories or ammunition combinations
are used.
24 Practice Periodic maintenance, avoid unauthoriZed servicing.
Your firearm is a mechanical device which will not last forever,
and as such, is subject to wear and requires periodic inspection,
adjustment and service. Browning firearms should be serviced by
a Browning Recommended Service Facility or by our Service
Facility in Arnold, Missouri. We assume no responsibility for
injuries suffered or caused by unauthorized servicing, alterations
or modifications of Browning firearms.
25 we reserve the right to refuse service on firearms that
have Been altered, added to or suBstantially changed.
Removal of metal from the barrel, or modifications of the firing
mechanism and/or operating parts, may lead to a refusal of service
on such firearms. We will charge you for parts and labor to return
the firearm to original specifications.
do not, under any circumstances, alter the trigger, safety
or other Parts of the firing mechanism of this or any
other firearm. failure to oBey this warning may result in
injury or death to yourself or others.
BE CAREFUL!
8
Loading...
