INH
™
Lightweight Amp
INH-800
INH-1500
INH-2000
INH-2400
Instruction Manual
© Brooke Products™ 2012. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are
correct at time of print. Instruction Manual dated April 2010.
INH™ Lightweight Amp Instruction Manual
Product Overview
Install ‘N’ Hire Amplifiers meet and exceed needs of both professional Fixed Installations and
Audio Equipment Hire. In an Installation, top performance, reliability and features are a must.
When you Hire you need all this in a robust and portable package. Good job INH Lightweight
Amplifers can survive rough handling on a daily basis.
As the signal processing element of the Install ‘N’ Hire range, Lightweight Power Amplifiers
are designed to get the best from speakers and subs in the rest of the range. Current and
output settings are finely balanced for the unique acoustic profile of INH Plywood and Portable
speakers, ensuring an unsurpassed performance every time. Amplifiers will be run day in,
day out and mainly at high volumes. So, exacting build standards are a must. With INH
Lightweight Amplifers, no compromise is made on design, and only the best components are
used for maximum life. Unique protection circuitry ensure that they withstand even the harshest
conditions.
A number of safety features are integrated into each INH™ Lightweight Amplifier. These protect
the amplifier itself and any other audio equipment that may be connected to it. In particular
• Temperature control circuits ensure operation up to 90°C. At this point a thermal shut-off
protects the unit until the temperature drops to 88°C. During operation, fan speed will vary to
maintain a stable internal temparature and it is normal to hear this.
• Speaker damage is prevented if an overload is detected by automatically removing clipping.
• Anti-surge circuits are fitted to compensate for power spikes that may occur during start up
and shut-down.
B
E
D
A
C
Fitting Dimensions
A 483mm 19”
B 445mm 17½”
C 90mm 3½”
D 435mm 17¼”
E 420mm 16½”
INH™ Lightweight Amp Instruction Manual
© Brooke Products™ 2012. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are
correct at time of print. Instruction Manual dated April 2010.
1- Main Power Rocker Switch & Indicator
2- Channel A Gain
3- Channel Level Indicators
Clip Limit, Signal Input, Amplifier Active/Stable, Amplifier Protect/Fault
4- Channel B Gain
5- Airflow Vent
6- Standard 19” Rackmount Ears
The unit fits standard 19”/483mm racks and cabinets and occupies a 2U rack height.
Front Panel Configuration
1
2 4 65
3
© Brooke Products™ 2012. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are
correct at time of print. Instruction Manual dated April 2010.
INH™ Lightweight Amp Instruction Manual
Rear Panel Configuration
1- Standard 19” Rackmount Ears
The unit fits standard 19”/483mm racks and cabinets and occupies a 2U rack height.22- Channel 1 & 2 Input Connections XLR/TRS
3- Channel 1 & 2 Output Connections XLR
4- Operational Mode
5- Stereo Output Speakon A+B
6- Terminal Output A+B/Bridge
7- Bridge ONLY Output
8- Airflow Vent
4 5 6 81
2 3 7
INH™ Lightweight Amp Instruction Manual
© Brooke Products™ 2012. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are
correct at time of print. Instruction Manual dated April 2010.
Technical Specification
INH-800
™
INH-1500
™
INH-2000
™
INH-2400
™
Stereo Power 8Ω RMS 250w x 2 500w x 2 700w x 2 900w x 2
Stereo Power 4Ω RMS 400w x 2 750w x 2 1000w x 2 1200w x 2
Bridge Power 8Ω RMS 800w x 1 1500w x 1 1800w x 1 2400w x 1
Frequency Response 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz
TH Distortion <0.01% <0.01% <0.01% <0.01%
Input Impedence 20KΩ 20KΩ 20KΩ 20KΩ
Input Sensitivity 0dB 0dB 0dB 0dB
Maximum Input Gain ±20dB ±20dB ±20dB ±20dB
Input Connections ¼” Jack, Female
Neutrik® XLR
¼” Jack, Female
Neutrik® XLR
¼” Jack, Female
Neutrik® XLR
¼” Jack, Female
Neutrik® XLR
Output Connections Neutrik® Speakon
NL4, Binding Post,
Male Neutrik® XLR
Neutrik® Speakon
NL4, Binding Post,
Male Neutrik® XLR
Neutrik® Speakon
NL4, Binding Post,
Male Neutrik® XLR
Neutrik® Speakon
NL4, Binding Post,
Male Neutrik® XLR
Signal to Noise Ratio ≥90dB ≥90dB ≥90dB ≥90dB
Overall Height
Overall Width
Overall Depth
2U / 90mm
19” / 483mm
448mm
2U / 90mm
19” / 483mm
448mm
2U / 90mm
19” / 483mm
448mm
2U / 90mm
19” / 483mm
448mm
Power Supply 240v AC 50-60Hz 240v AC 50-60Hz 240v AC 50-60Hz 240v AC 50-60Hz
Weight 12.0kg 13.0kg 15.5kg 16.0kg
© Brooke Products™ 2012. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are
correct at time of print. Instruction Manual dated April 2010.
INH™ Lightweight Amp Instruction Manual
For your Safety
• Follow all instructions to maintain Manufacturer Warranty and for your own safety.
• There are no user replacement parts inside the product. Do not open the product for any reason.
This will invalidate your Manufacturer Warranty and may cause you harm.
• Do not expose this product to moisture, rain or other fluids.
• Do not use this product near water or other fluids.
• Do not use if the product if you suspect it has been damaged in any way, including being dropped,
is malfunctioning, or has been exposed to liquids or moisture. The unit must be repaired by an
authorised service centre only. Manufacturer Warranty is void if unit is opened or adapted in any
way. Operator safety may be compromised if this product is not operated and maintained in
accordance with the details contained in this Instruction Manual.
• This appliance must be earthed. Do not remove the earth connection in the plug or any other
location- it is essential for user safety.
• Be aware that products are mains powered and may be capable of producing high voltages from
their outputs and have mains voltages inside cabinets.
Product Installation, Use & Maintenance
• Keep this Instruction Manual safe for future reference.
• Clean the product housing with a clean and dry, non-abrasive cloth. Do not use solvents or
liquids to clean the product. Pay particular attention to the lens since this will require cleaning on
a weekly basis to remove any oil residue that may have built up.
• To prevent overheating, do not obstruct any ventilation opening, fan cover or vent. Do not stack
other items on top of the unit. Provide at least 200mm of clear space around any ventilation
holes and ensure no flammable items are nearby.
• Avoid repeated or rapid powering up or shutting down of the unit.
• Power connection to the product is via a UK 240 Volt AC three-pin mains plug. Do not remove or
adapt this plug. If necessary, only replace a fuse with one of the same type, size and value.
• The mains lead must not be crushed or damaged. If any damage occurs, disconnect from
the mains immediately. Replace the damaged cable, or if the mains lead is captive, return the
product to an authorised repair centre for cable replacement. Do not attempt to repair the cable
- it must be discarded and destroyed.
• To maintain the Manufacturer Warranty, only attach authorised accessories and external devices.
This includes cables, connectors and other electrical and/or mechanical devices.
• Unplug the product from the mains during lightning storms or periods of mains fluctuations. If
the product is going to be unused for long periods, unplug from the mains.
• A very strong magnetic field is generated during operation. This can introduce “hum” into nearby
unshielded equipment and damage sensitive magnetic media. We recommend mounting the
unit at the foot of any rack and use of grounded and floating earth settings.
INH™ Lightweight Amp Instruction Manual
© Brooke Products™ 2012. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are
correct at time of print. Instruction Manual dated April 2010.
Product Quality & Compliance
• Products from Brooke Products meet all required safety standards in force at the time of
manufacture and are fully compliant with them.
Unpacking & Inspection
• Inspect the packaging before opening. If the packaging appears to have sustained significant
damage, please take extra care before using the product. If you are in any doubt, consult a
suitably qualified professional.
• If you suspect the product has been damaged, do not use it. Return it to your original supplier
without delay.
• Keep all packaging in a safe place for storage or transport in future.
Manufacturer Warranty
• This Manufacturer Warranty is valid in the UK only.
• Brooke Products warrants that this product is free from workmanship defects and material failure
during normal use and operation for a period of 12 months from first use or from original date
of sale (whichever is the earliest) providing all of the terms indicated in the warranty section have
been fully complied with.
• Expressly excluded is our liability for any directly connected or indirectly connected item or items
or any consequential loss associated with the failure of the product howsoever caused.
• If the product has been opened, modified, tampered with, incorrectly connected, used
inappropriately or in conflict with the instructions herein, or the product model or serial number
has been damaged, removed, tampered with, obliterated or made partly unreadable by any
person or persons, the Manufacturer Warranty is irrevocably null and void.
• No extension, adaption, alteration or modification to the terms of this Manufacturer Warranty
will be permitted, unless expressly authorised in writing (excluding email and fax) by a Director
of Brooke Products. Warranty is transferrable during the Warranty period.
For Further Information about Brooke Products
• Our website can be found at www.brooke-products.com and is available for the benefit of
customers worldwide. Please consult for information, advice and support on this and other
high quality products from Brooke.
www.brooke-products.com
From the latest low weight, switch-mode, Power Amplifiers to full size Line
Arrays, everything here at Brooke is created with a single idea in mind.
Quite simply, a chain is only as strong as its weakest link. And at Brooke
we don’t like weak links.
Brooke can help you through any professional sound project from
beginning to end. From amplifiers and audio processors, line arrays to
architectural speakers, uncompromising quality of build and amazing
design is what Brooke is renowned for.
Brooke
Be confident that when you use anything with a Brooke badge on it, you’ll
experience product features and reliability that will take your breath away.
Professionals accept no compromise and Brooke customers want nothing
less than stunning performance and top-end specification. We know you
won’t settle for second best - so we won’t either.
