BROMIC SMART-HEAT™
Power
240V
30A
Wireless
On/O Remote
Heater Heater
On/O
Control
WIRELESS CONTROLLER
4-CHANNEL REMOTE*
Add control and convenience
to your Smart-HeatTM Range
The Bromic Heating Wireless Controller has the ability to
switch power supply to two separate outputs, enabling
independent ‘On/Off’ control of two single-element heaters
(2kW or 3kW), a single twin-element heater (4kw or 6kW)
per unit, two gas heaters of your choice or up to four gas
heaters controlled in groups of two.
The unit’s 4-channel remote control transmitter is entirely
portable but can be easily mounted with a double sided
adhesive or with screw provisions within the case.
*All Bromic Heating remotes are able to control an infinite
number of heaters within a 100-foot range.
HEATER TYPES INSTALLATION OPTIONS
Option 1:
Electric
Gas
Option 2:
Option 3:
Option 4:
Option 5:
Option 1:
Option 2:
T: 1 800 301 1293 E: INFO@BROMIC.COM W: BROMIC.COM
1 x 6000W
1 x 4000W
2 x 3400W
2 x 3000W
2 x 2000W
1 x Gas Heaters per output
2 x Gas Heater per output
SPECIFICATIONS
Part Number BH3130010-1
Power Supply
Max Output Power CHANNEL
Reception Frequency 916MHz
Operating Temperature Range -4 to 122
Maximum Remote Memorized 42
Dimensions 7”x 5.5” x 3.3”
Protection Class IP54
110/230VAC, 31A max,
Single Phase
3400W @ 230VAC
1500W @ 110VAC
0
F
ON/OFF CONTROLLER DIMENSIONS
7”
5.5” 3.3”
7”
USA 06/11/17
